Empirical Study of Ad Hoc Collaborative Activities in

Software Engineering

Sébastien Cherry

Pierre N. Robillard

Software Engineering Research Laboratory, Computer Engineering Department,

École Polytechnique de Montréal, C.P. 6079. succ. Centre-Ville, Montréal, Canada

Abstract. This paper presents empirical research on ad hoc collaborative activi-

ties found in an industrial software engineering setting. We believe that a better

understanding of these activities and their content will help us to propose soft-

ware development process enhancements and also provide some insight into the

tools needed to support communications in a distributed software development

environment. Further details of our motivations are included, followed by a dis-

cussion on our research methodology, and, finally, some results of a prelimi-

nary analysis confirming the significance of our data and the importance of the

observed phenomenon.

1 Introduction

It is well supported in the literature that some problems encountered in software de-

velopment are not attributable to technical factors, but rather to the human aspects of

software engineering [2], [4], [5], [7], [11], [13], [14], [15]. While some aspects, such

as “communication” [7], [15], “coordination” [4], [5] and “collaboration” [2], [13],

are gaining recognition in the research community, some methodological challenges

emerge. Human factors, for example, have been overlooked in the past for many

reasons, but principally because of the difficulty in measuring these facets quantita-

tively [11]. Nevertheless, empirical research in software engineering is growing in

popularity and beginning to be adapted to studying this new topic of interest, namely

people, and methods and techniques are being borrowed which were formerly used in

the human sciences such as psychology and sociology. Like many researchers, we

think that this domain will offer research opportunities for years to come.

This paper presents in-progress empirical research in the context of a case study in

the industry, and explores collaborative work in software engineering; specifically,

the ad hoc collaborative activities that take place during the software development

process. By ad hoc collaborative activities, we mean activities which are not formally

prescribed, and which occur between two or more developers working on a specific

project task and which happen informally and spontaneously. They can take many

forms, such as in peer-to-peer conversations, electronic mail exchanges, and so on.

Details of our motivations are to be found in the next section of this paper, fol-

lowed by a discussion of the research methodology used, including data collection

methods, and the need to place greater emphasis on the analysis techniques that will

Cherry S. and N. Robillard P. (2004).

Empirical Study of Ad Hoc Collaborative Activities in Software Engineering.

In Proceedings of the 1st International Workshop on Computer Supported Activity Coordination, pages 116-125

DOI: 10.5220/0002682701160125

 SciTePress

be used to explore the large quantity of amassed data. Finally, some results of a pre-

liminary analysis are revealed, which confirm both the relevance of the collected data

and the importance of the observed phenomenon.

2 Motivations

2.1 Why collaborative work?

As previously mentioned, a growing number of researchers support the view that

many of the problems that arise during software development could be imputable to

human factors associated with the software engineering process. Perry, Staudenmayer

and Votta (1994) [11], among others, believe that too much attention is given to the

technological aspects of software engineering. They say that one of the reasons fre-

quently mentioned is the difficulty of measuring these human factors quantitatively.

The same comments are also supported by Seaman (1999) [16].

Many approaches have been envisaged to study the human aspects of software en-

gineering. Some researchers have examined the communication occurring during

software development [7], [15], while others have studied the coordination aspect [4],

[5] and still others were interested in the collaborative work [2], [13].

With regard to collaborative work, Robillard and Robillard (2000) [13] have em-

pirically identified four types of collaborative activities performed during the soft-

ware engineering process. They defined “ad hoc” collaborative activities, for exam-

ple, as the work carried out simultaneously by teammates on a particular task of the

project and which is not prescribed by a formal process. One of the conclusions of

this research was that ad hoc collaborative activities can play a major role in team

communication dynamics, accounting for 41% of this dynamics during the case

study. Furthermore, these activities constitute the longest of the working sessions, and

in addition seem to have an important impact on individual activities, since they often

precede long individual working sessions.

Also, Perry, Staudenmayer and Votta (1994) [11] found during another case study

that informal communications take up an average of 75 minutes per day per software

developer. Seaman (1996) [15] also supports the view that this type of communica-

tion is a non-negligible element to be taken into account during a development proc-

ess, and which is essential if developers are to carry out their tasks adequately.

Because they monopolize quite a considerable part of a software project and con-

stitute an important element of it, as established above, exploratory research is essen-

tial to understanding the content of these ad hoc collaborative activities and the com-

munication that ensues, and to measuring the impact, both positive and negative, on

the rest of the development process. We believe that such research will help us to

subsequently propose software engineering process enhancements which will be

better adapted to the human and empirical realities of software development.

By contrast, collaborative software development, also known as “distributed soft-

ware development”, is an increasingly fashionable domain of research these days.

117

Both these expressions refer to software development distributed over time and

over relatively long distances, something that has become quite common business

practice nowadays in cases where it occurs.

However, according to recent research in this domain [5], the distances between

the members of virtual teams tends to obstruct informal communications, resulting in

problems of coordination. This is another important reason for undertaking research

in this field. It will also provide some insight into the tools needed to support com-

munications in a distributed software development environment.

2.2 Why an empirical study?

Empirical research based on the experimental method has been conducted for a long

time now, in many of the human sciences, such as psychology and sociology. It is,

moreover, very often considered to be the only valid scientific method accepted in

these domains. Although empirical research has been conducted in software engineer-

ing for many years, it is on a much smaller scale and only quite recently has it seen an

increase in popularity. One reason for this is the growing interest in the human as-

pects of software engineering [16].

Further arguments supporting this new tendency, and strengthening the evidence

for it, have been expressed by Tichy (1998) [17] in his paper, “Should Computer

Scientists Experiment More?” However, those who uphold this practice in software

engineering believe that, since the quantity of empirical research is on the increase, its

quality should increase as well [10], [18].

3 Research Protocol

3.1 Problem Statement

Research Objectives. As discussed previously, the importance and the necessity for

ad hoc collaborative work and the communications that ensue in software

development are widely supported by many authors [2], [4], [5], [6], [7], [11], [13],

[15]. Although some research has quantified the importance of the phenomenon,

there has been no known attempt to determine and describe the content of that work.

These considerations led us to define the following research objectives:

 To observe the collaborative work taking place in a case study in the industry

to design a conceptual model and distinguish some patterns of exchanges.

 To characterize the ad hoc collaborative activities found, the communications

that ensue, and to identify and describe their content.

 To generate a series of hypotheses which emerges from the results of this re-

search, and which could later be validated by confirmatory research.

118

Theoretical Relevance of the Research. The fact that there has been little or no

empirical study of ad hoc collaborative activities gives this research theoretical rele-

vance. It will make it possible to establish a model of these activities and to gain a

sense of the cognitive aspects involved from which we will be able to generate a

series of hypotheses to create a theoretical base in this domain.

Practical Relevance of the Research. Based on the fact that good collaboration is an

indispensable condition of a software development team working effectively to make

a quality product which meets the needs of the user, in the time required and at the

expected cost, this research is relevant in practice because it will potentially pave the

way to the proposal of improvements to software engineering processes. Also, as

previously mentioned, it will allow us to better understand the informal collaboration

and communication aspects of software engineering, and provide some insight into

the tools needed to support communications in a distributed software development

environment.

3.2 Research Methodology

General Approach. The research is carried out by means of participant observation

within the framework of a case study in an industrial environment. This type of

approach is suitable in our case because this is exploratory research. Also, as

Jorgensen (1989) [8] and Babbie (2001) [1] have stressed, study in the field combined

with participant observation are appropriate when it is not a question of empirically

verifying hypotheses formulated in advance, but rather of inductively generating

theories from observations and from the empirical data collected.

Target-setting. The setting in which the chosen software development team works is

a large enterprise which produces software for commercial purposes. It is a well-

established, mature concern which has been in operation for several years, and where

there exists a clearly defined development process. Nevertheless, even if the

observations are done in a large company, this last also contains some attributes of

smaller organizations since the development of software components is divided into

small teams.

Also, based on a common-sense judgment (face validity) [1], we can say that the

chosen team of eight individuals is representative of the majority of development

teams, with a wide range of ages, amounts of schooling, years of experience in soft-

ware development and length of service in the company.

Data Collection. The following data collection methods were identified from a

preliminary ethnography period within the chosen team which lasted several months.

An initial data collection phase, which took place in the autumn of 2003, is now

completed and was spread out over 8 weeks. The results presented in this paper were

produced from these earliest data. The purpose of this collection was to gather the

119

maximum amount of information from the beginning to the end of the development

of an update (patch) of a given version of the software produced.

The data collected during this first phase includes:

 185 hours of audio-video recordings of working sessions over 37 workdays

 The capture of a total of 2496 e-mails exchanged by the 8 teammates

 A daily backup of the source code and other documents and artifacts found

E-mails were captured automatically, by means of triggers defined in the messag-

ing software used in the company. This capture included both e-mails received and

those sent by teammates, in order to permit cross-validation.

The daily backup of the source code, and the various documents and artifacts, was

available for potential use for subsequent content analysis.

Data Analysis. One of the techniques that will be used for the analysis is Exploratory

Sequential Data Analysis (ESDA) [3]. This technique is suited to exploratory

research, where the objective is to find answers to research questions or to find

patterns among the empirical data and to describe them using, for example, simple

statistical representations.

ESDA allows researchers to define, from these descriptions, hypotheses which are

subsequently verified by means of confirmatory research using statistical inference

methods. However, the important feature of ESDA is that it applies more specifically

to research where the sequential integrity of the data must be preserved.

Of the eight operations proposed by ESDA, encoding is certainly the most impor-

tant. This involves labeling each sequence of data by means of a code formed using a

particular syntax and contained in an exhaustive, exclusive and relatively restricted

category list, and doing so to decrease the variability of the data, as well as to facili-

tate its subsequent manipulation. This encoding makes it possible to transform quali-

tative data into quantitative data, on which it is then possible to perform statistical

analysis [3], [16].

The ESDA process, such as proposed by Fisher and Sanderson (1996) [3], is an it-

erative one, involving the definition of a series of concepts stemming from research

questions of interest. The process will subsequently drive what should be observed

among the collected raw data and what manipulations should be made to obtain de-

rived data on which it is possible to generate theories or define hypotheses. It is itera-

tive because it is often necessary to revisit certain steps; for example, to add, remove

or redefine concepts or categories that are sometimes found intuitively and validated

by their statistical representations.

Research Validity. To satisfy the validity criterion for the research, the empirical

measure must faithfully translate the empirical reality of the measured phenomenon

[1]. To enhance the validity of our research, particular attention is directed to the

definition of the concepts or categories chosen to encode the data. These concept

definitions, which must arise from the ESDA traditions that concern us [3], as well as

from the context of the research field, ensure a degree of representativeness of the

phenomenon under study by common-sense validity (face validity) [1], [8].

The concepts or categories under which the data will be encoded, as well as the

number of categories chosen, will also be very important as far as content validity is

120

concerned [1]. This aspect of validity refers rather to the coverage of the meanings

encompassed by the concepts. Furthermore, the validity of the connections or the

relations (construct validity) [1] should be assured among the concepts forming the

theoretical model appearing from the data. This can be done by means of certain

correlation measures or statistical associations.

Finally, a data triangulation will be made between qualitative and quantitative data,

as well as of data resulting from various sources [16], [18]. Concerning this last point,

other phases of data collection are to be anticipated.

4 Preliminary Results

The results presented in this section are the product of a preliminary analysis concern-

ing four of the eight developers in the team who were observed over a period of 8

hours. The choice of these individuals was not made by means of a sampling method,

but from direct observations in the field: they had been identified as being likely to

work more collaboratively than the others. This choice is justified because the objec-

tive of this research is not to find a magic number indicating the time spent on ad hoc

collaborative work, but rather to investigate the content of these collaborative activi-

ties. It should also be noted that the results below do not take into account e-mail

interactions, but only the peer-to-peer conversations and telephone exchanges.

As can be seen from Figure 1, 51% of the time is spent on ad hoc collaborative

work, as against 49% for the other types of activities. This result tends to corroborate

the observations made in the field that suggested the importance of the phenomenon.

51%

49%

Ad hoc collaborative activities

Other types of activities

Fig. 1. Distribution of time spent on ad hoc collaborative activities in comparison with other

types of activities

Figure 2 indicates the percentage of time spent on ad hoc collaborative activities

by the subjects observed. As was noted in the field, subjects MS2 and MS3 seem to

have spent a large amount of their time collaborating and communicating in a sponta-

neous way with their colleagues. This can be explained by the nature of the work

performed by these subjects. MS2 occupies the position of project manager in the

team, and one of his functions is to circulate relevant information needed by the de-

velopers on his team. When we examine more closely the interactions in which MS2

is involved, we note that, for 78.13% of the time, his colleagues initiate the interac-

tions. We can suggest hypothetically that MS2 constitutes a source of the information

his colleagues require. However, it was noted in the field that a great deal of the in-

formation passed on by MS2 to his teammates is in the form of e-mails. It would be

interesting to investigate this method of communication. MS3 is, for his part, respon-

sible for the infrastructure of the software built, and often the individual consulted to

121

resolve problems. He manages several tasks at the same time, which brings him into

communication with some of his colleagues more often.

42 44 46 48 50 52 54 56

Percentage of time spent on ad hoc activities

collaboratives

MS1

MS2

MS3

MS4

Subjects

Fig. 2. Percentage of ad hoc collaborative activities per subject

By contrast, the average duration of the interactions analyzed by the four develop-

ers is 6:31 minutes, and these interactions involve, on average, 2.3 stakeholders. We

should remember that an interaction is defined as a communicative unit which pre-

sents an evident internal continuity, while it breaks with what precedes it and what

follows it [11]. Moreover, these results were based on a total of 82 observed interac-

tions.

Figures 3 and 4 give an initial outline of a distribution as a percentage with regard

to the number of occurrences and time spent on the various categories of ad hoc col-

laborative activities identified. “Cognitive synchronization” exists when two or more

developers exchange information to ensure that they share the same knowledge or the

same representation of the object in question. “Problem resolution” occurs when two

or more developers are aware of the existence of a problem and attempt by different

means to solve the problem or to mitigate it. “Development” occurs when two or

more developers contribute to the development of a new feature or component of the

software. “Management” is the result of two or more developers coordinating and

planning activities such as meetings, common working sessions or setting schedules.

“Conflict resolution” is the process of two or several developers taking part in discus-

sions to resolve a difference of opinion. Ad hoc collaborative activities under the “not

relevant” category group together all interactions which do not concern the project or

the software built.

122

12.63%

8.42%

11.58%

14.74%

52.63%

Cognitive synchronization

Problem resolution

Development

Management

Conflict resolution

Not relevant

Fig. 3. Distribution in number of occurrences of ad hoc collaborative activities identified

24.50%

8.24%

7.37%

3.32%

56.57%

Cognitive synchronization

Problem resolution

Development

Management

Conflict resolution

Not relevant

Fig. 4. Distribution in terms of time spent on ad hoc collaborative activities identified

As Figure 3 suggests, 52.63% of the ad hoc collaborative activities that arose are

forms of cognitive synchronization. This agrees with the direct observations made in

the field. The figure is not surprising when we consider that the exchange of informa-

tion and knowledge constitutes an essential element in software development, which

is to crystallize [16] all the information required in quality software to meet the needs

of the user. As shown in Figure 4, cognitive synchronization occupies 56.57% of the

time spent on ad hoc collaborative work, which also supports the previous finding.

The other significant category, problem resolution, does not seem important in

Figure 3 in terms of number of occurrences. Figure 4, however, suggests that this

activity monopolizes almost a quarter of the time spent on ad hoc collaborative work

by the four subjects observed. It demonstrates that perhaps, while problem resolution

activities are relatively few in number, when they do arise, they monopolize a rather

considerable amount of time. An analysis of the mean time spent by sequence as a

function of ad hoc collaborative activity tends to confirm this, showing that problem

resolution takes up to 9:48 minutes when it occurs, as opposed to the interaction av-

erage of 6:31 minutes.

The results relative to management activities also reveal an interesting finding.

Unlike problem resolution activities, they are relatively numerous considering the

fairly short time that they occupy. This may tend to confirm the theories of certain

authors [7], who maintain that informal communications are necessary in order that

the members of a team can coordinate their activities effectively.

123

5 Conclusion

It is clear, and widely supported, that good collaboration and communication are an

essential condition of the successful delivery of a quality product by a software de-

velopment team, one that meets the user’s needs in a timely fashion and at the ex-

pected cost.

It was revealed by previous research that ad hoc collaborative activities and infor-

mal communications occupy a considerable portion of the time that a developer

spends on a software project. However, no research has attempted to describe the

content of these activities, which leaves a vast field open for exploration.

The empirical research described in the present paper suggests the importance of

investigating this field, because the authors believe that understanding how people

collaborate will make it possible to propose practices to enhance collaboration and

communication within a development team, as well as improve software development

processes.

This article has briefly presented the methodology used to meet our research objec-

tives. It was influenced by previous empirical research which was also aimed at in-

vestigating the human aspects of software engineering, but which was, however,

adapted to the context of the field on which this study focuses.

The embryonic results that were partially presented in this paper, and that arise

from a tiny portion of the considerable quantity of data that was collected, are very

interesting. Although more analysis is needed, a model of data and patterns already

seems to be emerging which will allow us to subsequently form hypotheses which

can be validated by other, confirmatory research, thereby forging a knowledge base in

this, as yet unknown, domain of software engineering.

6 Acknowledgments

This research would not have been possible without the agreement of the company in

which it was conducted, and without the generous participation and patience of the

software development team members from which the data was collected. To all these

people, we extend our grateful thanks.

References

1. Babbie, E.: The Practice of Social Research, 9th ed., Wadsworth Publishing Company,

Belmont, CA (2001)

2. D’Astous, P., Robillard, P.N.: Les aspects de l’échange d’information dans un processus de

génie logiciel, Rapport interne, École Polytechnique de Montréal, EPM/RT-97-06 (1997)

3. Fisher, C., Sanderson, P.: Exploratory Sequential Data Analysis: Exploring Continuous

Observational Data, Interactions, Vol.3, No. 2, Mar. (1996)

4. Grinter, R.E., Herbsleb, J.D., Perry, D.E.: The geography of coordination: Dealing with

distance in R&D work, GROUP'99: International Conference on Supporting Group Work,

Coordination and Negotiation, (1999) 306-315

124

5. Herbsleb, J.D., Grinter, R.E.: Splitting the Organization and Integrating the Code: Con-

way’s Law Revisited, Proceedings, International Conference on Software Engineering, Los

Angeles, CA (1999) 85-95

6. Herbsleb, J.D., Moitra, D.: Guest Editors' introduction: Global software development.

IEEE Software, Vol.18 No.2, March/April (2001) 16-20

7. Herbsleb, J.D., Mockus, A.: An empirical study of speed and communication in globally

distributed software development, IEEE Transactions on Software Engineering, Vol.29,

No.6, June (2003) 481-494

8. Jorgensen, D.L.: Participant Observation: A Methodology for Human Studies, Applied

Social Research Methods Series; v.15, Sage Publications, Newbury Park, CA (1989)

9. Kerbrat-Orrecchioni, C.: Les Interactions Verbales, Armand Colin, Paris (1998)

10. Kitchenham B. et al., Preliminary guidelines for empirical research in software engineer-

ing, IEEE Transactions on Software Engineering, Vol.28, No.8. (2002) 721–734

11. Perry, D.E., Staudenmayer N., Votta, L.G.: People, Organizations, and Process Improve-

ment, IEEE Software, July (1994)

12. Robillard, P.N.: Études des aspects cognitifs applicables au génie logiciel, Rapport interne,

École Polytechnique de Montréal, EPM/RT-96/18 (1996)

13. Robillard, P. N., Robillard, M.P.: Types of Collaborative Work in Software Engineering,

The Journal of System and Software, No.53 (2000) 219-224

14. Robillard, P. N., Kruchten, P., D’Astous, P.: Software Engineering Process with the

UPEDU, Addison Wesley, Pearson Education (2002)

15. Seaman, C.: Organizational Issues in Software Development: An Empirical Study of

Communication, PhD Thesis, Computer Science Department, University of Maryland,

Technical Report CS-TR-3726, UMIACS Technical Report UMIACS-TR-96-94 (1996)

16. Seaman, C.: Qualitative methods in empirical studies of software engineering, IEEE Trans-

actions on Software Engineering, Vol.25, No.4 (1999) 557–572

17. Tichy, W.: Should computer scientists experiment more? Computer, Vol.31, No.5 (1998)

32–40

18. Walker, R.J., Briand, L.C., Notkin, D., Seaman, C.B., Tichy, W.F.: Panel: Empirical Vali-

dation–What, Why, When, and How, Proceedings, International Conference on Software

Engineering, Portland, Oregon (2003) 721-722

125
