SEMANTIC INTEGRATION OF DIGITAL LIBRARIES

José Francisco Aldana-Montes, Ismael Navas-Delgado, María del Mar Roldán-García

Computer Languages and Computing Science Department. University of Malaga. Spain.

*This work has been supported by the MCyT grant (TIC 2002-04186-C04-04) convinced that conceptual meditation (as

offered in our architectural technical solution) is a very good alternative for integrating DLs.

Keywords: Semantic Mediation, Integrating Heterogeneous Digital Libraries, Ontologies

Abstract: Semantic Integration/Interoperability of heterogeneous data sources offers several key features. These

characteristics include the following: publication of the data source's semantics, expressive query

capabilities (viz. semantic queries), dynamic integration of data sources, interoperability between semantic

integration systems that cooperate in the same or in different application domains, etc. The integration of

digital libraries and their interoperability are two of the main issues that still have to be addressed by the

Digital Libraries community. In this paper we present the application of a semantic mediator architecture to

the domain of Digital Libraries and by means of several use cases we show the main advantages it offers.

1 INTRODUCTION

Digital Libraries (DLs) are vast collections of

entities stored and maintained by multiple

information sources, including databases, image

banks, file systems, etc. Characteristics of DLs

include (Adam et al., 2000): (1) massive amounts of

data; (2) structured, semi-structured, and

unstructured data; (3) frequent modification of the

information sources. Therefore, integrating them is a

central issue in order to facilitate user access to

them. Currently, there is still very little

interoperability across heterogeneous digital library

systems. Interoperability means the cooperation

between these heterogeneous and distributed

information sources in a way that is transparent to

the user, maintaining their autonomy. Portability,

data exchange, scalability, federation, extensibility

and open network architectures are also noteworthy

research issues in DLs (Borgman, 1999).

Database techniques could be very fruitfully

applied to the DLs field. Database research mainly

deals with efficient storage and retrieval and with

powerful query languages. This community has been

seriously disturbed with the massive increment of

data sources in the web and the need to integrate

them. Large amounts of integration techniques have

been developed in the past few years. Furthermore,

in recent years, mediators have emerged as a way of

integrating databases, using wrappers to translate the

different data source information to a common

model.

(Ibrahim et al., 2001) and (Adam et al., 2000) are

good studies about integration in DLs. In addition to

the wrapper-mediator approach, they analyse other

approaches that have also been widely studied by the

database community; However, mediators are the

most common approach for heterogeneous data

source integration.

On the other hand, although we believe that

mediation is a good approach for integrating digital

library information sources, mediators present some

deficiencies related to the reusability of common

wrapper components, high coupling of wrapper and

mediators, and the difficulty of adding new sources

dynamically. To provide good integration systems to

digital library users, it is necessary to find a solution

for these deficiencies. Furthermore, we believe that

DLs are more suitable for conceptual, rather than

structural, browsing and navigation. In order to solve

these problems, we propose a novel mediation

architecture which aims at making wrappers

independent entities and eliminating their ties to the

mediator, thus increasing its reusability in different

applications and contexts. It entails additional

advantages providing elements to obtain major

interoperability among integration systems, that

cooperate in the same application domain or have

certain relations, such as digital libraries.

Our proposal tries to go beyond traditional

mediation architecture at all its points. That is, we

hope that by distributing all mediation components

we can obtain a more scaleable and reusable

application. The focus of this paper is to integrate

DLs by using this proposed architecture for semantic

mediation (see section 4). We are firmly convinced

313

Francisco Aldana-Montes J., Navas-Delgado I. and del Mar Roldán-García M. (2004).

SEMANTIC INTEGRATION OF DIGITAL LIBRARIES.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 313-318

 SciTePress

that conceptual mediation (as offered in our

architectural technical solution) is a very good

alternative for integrating DLs.

2 RELATED WORKS

The wrapper-mediator approach provides an

interface to a group of (semi) structured data

sources, combining their local schemas into a global

one and integrating the information of local sources.

So the views of the data that mediators offer are

coherent, performing semantic reconciliation of the

common data model representations carried out by

the wrappers. Some good examples of wrapper-

mediator systems are TSIMMIS (Papakonstantinou

et al., 1995) and Manifold (Levy et al., 1996).

Several improvements have been made of traditional

mediators. One of the most important is the use of

standard representation languages, like XML. Thus,

MIX (Baru et al., 1999a) (the successor to the

TSIMMIS project) and MOCHA (Rodriguez et al.,

2000) projects are XML-based.

The next level of abstraction on Web integration

corresponds to ontology-based systems. Their main

advantage with respect to mediators is their capacity

to manage schemas that are unknown a priori. This

is achieved by means of a mechanism that allows

contents and query capabilities of the data source to

be described declaratively. OBSERVER (Mena et

al., 1996) uses different ontologies to represent

information data sources. Users explicitly select the

ontology that will be used for query evaluation. The

existence of mappings among ontologies allows the

user to change the ontology initially selected.

Model-Based Mediation (Ludascher et al., 2001)

is a paradigm for data integration in which data

sources can be integrated, taking advantage of an

auxiliary expert knowledge. This knowledge

includes information about the domain and it is the

glue that joins data source schemas together. The

expert knowledge is captured in a data structure

called Knowledge Map. In Model-Based Mediation

the mediation architecture is extended, carrying data

sources from the data level without semantics to the

conceptual model level. This architecture introduces

semantics into data sources and mediators, but they

are not published and accessible to agents or

applications. Mediators are monolithic systems and

they are strongly coupled to wrappers, limiting

dynamic integration and interoperability.

In (Navas et al., 2004) we proposed an

architecture for semantic mediation. This

architecture includes directories in which an

ontology and several resources with semantics

relevant to the domain information are published.

We also improve the wrapper generation process by

publishing them as web services and making their

semantics accessible. As a result of this evolution

from traditional wrappers to data services, the

following objectives were achieved: (1) data

services can be used by other applications (maybe

mediators); (2) semantics of the data services is

published on the web and is available for other

applications; (3) Wrapper query capabilities can be

enveloped into one or more services.

There are some previous works that use traditional

mediator architectures in the domain of DLs. In

(Baru et al., 1999b), a prototype to integrate DLs

using MIX technology is presented. This is a

traditional monolithic approach; therefore reusability

of mediator components, expressive query

capabilities as well as dynamic data source

integration are not possible. (Melnik et al.,2000)

introduces reusability of mediator components. It

proposes an infrastructure to integrate DLs that

allows mediators to be composed from a set of

modules. However, it does not deal with the other

problems mentioned. Section 3 describes how all

these problems can be addressed in the context of

semantic mediation (Navas et al., 2004).

Wrapper

Data Service

Semantic Directory

Planner

Domain Ontology

Mappings be tween

Schem as an d

Domain Ontology

Available Resources

Query Plan

Query ij

Result

Wrapper

Data Service

Query ik

Results

Query Capabilities

Data Schema

Data Sources

Semantic

Information

Semantic

Informatic

Semantic

Information

API API

Query Cap abilities

Data Schema

Data Sources

Applic ation

User Interface

Query

Processor

Query Result

Figure 1: Architecture for Semantic Integration

ICEIS 2004 - HUMAN-COMPUTER INTERACTION

314

3 SEMANTIC MEDIATION

Our Semantic Mediation Architecture seeks to make

wrappers independent entities and to eliminate their

ties to the mediator, thus increasing their reusability

in different applications. We emulate P2P

(Schollmeier, 2001) hybrid systems, which

implement a directory with location information of

available resources. In these systems the applications

access the resources directly by means of point to

point connections provided by the directory.

Our proposal for semantic mediation stems from

the need in several domains for dynamic integration,

and from two main considerations on the basic

architecture of mediation: (1) on the one hand the

isolation of wrappers, which are encapsulated as

web services (W3C, 2002) (Data Services for us);

and (2) on the other hand, the added directory

(Semantic Directory) with information about these

Data Services (See Figure 1). This architecture

allows wrappers to contribute data, schemas of

information and query capabilities in a decentralized

and easily extensible way. Public interfaces of data

services and semantic directories will allow other

applications, which share its communication

protocol, to take advantage of knowledge about

available directory resources. Next we briefly

present the components of the proposed architecture.

3.1 Semantic Directory

Semantic directories are at the core of this

architecture because they provide essential services

for solving user queries. We can define a semantic

directory as “a server that offers information about

available web resources (data services), a domain

ontology, mappings between resource schemas and

this ontology, and provides a query planner”.

A semantic directory stores an ontology described

with OWL (OWL, 2003), which must be generic for

the application domain. This ontology describes the

core knowledge that is shared by a set of users.

Information about data services will be added to a

semantic directory when services register in it. This

information includes the Resource’s Schemas, the

location of these resources (the URL of the Data

Service, the Query Web Method, etc.) and several

mappings between the domain ontology and the

resource’s schemas. Note that all this information

allows the system to solve any kind of query, and

not only predefined queries like most mediation

systems.

3.2 Data Services

Semantic directories offer essential services for

query processing, and data services provide minimal

elements for solving queries. We have designed an

extensible and adaptive architecture in which we can

define a data service as “a service that offers

wrapper query capabilities using web protocols”.

That is, this type of service will solve specific

queries for a data source and offer its query

capabilities as a web service. The publication of

these online web services using UDDI (Universal

Description Discovery Integration) (UDDI, 2003)

could allow other applications to dynamically

discover wrappers by means of an easy interface.

However, our data services have been devised for

publication in a specialized and previously described

type of directory: the semantic directory. Thus, a

data service needs to be registered in one or more

semantic directories in order to be used by a

mediator or other software agent.

4 USE CASES

In this section we present a use case of the proposal

described for the integration of digital library data

sources. After that, we describe several advanced

queries that highlight the advantages of the

proposed architecture. As a first step we have

generated a domain ontology to be used in a

semantic directory. This ontology represents the

domain knowledge of a group of digital library users

(see Figure 2). This ontology is based on terms

described by the Dublin Core Metadata Initiative

(Dublin, 2003). Then we implement the application

that will use this directory and includes an evaluator

and user interface.

Once semantic directories have been developed,

they are autonomous and do not need human actions,

but a semantic directory and an application are not

enough to solve user queries. In order to illustrate

how our architecture works we present a simple

example, together with all the elements that are

necessary to solve the query example. Suppose that

we have developed several data services about

computer science publications and added them to the

semantic directory. For example, we can add to our

system data services that access to the BNE (Spanish

National Library), DBLP (Database & Logic

Programming) and CSB (The Collection of

Computer Science Bibliographies).

Now, we can solve a query like: “Find articles

whose author is Ullman and were published the

same year as the book titled ‘Data on the Web’”.

SEMANTIC INTEGRATION OF DIGITAL LIBRARIES

315

Figure 2: Domain Ontology

This query is represented internally by the user

interface in logical terms:

This query is sent to the semantic directory,

which analyzes it taking advantage of mappings

between resources and the domain ontology

(Figure 3a shows an example of mapping between

part of the CSB schema and part of the domain

ontology). In our example we map the data retuned

by the BNE to the Book class, the data retuned by

the DBLP to Article and Book classes and the data

returned by the CSB to the ConferencePaper,

JournalArticle, and Book classes.

Taking into account all these mappings, the

proposed query is divided into two sub-queries:

Note that the second sub-query needs the year of

publication from the first sub-query, so the

evaluation must be sequential. Now, these queries

must be evaluated in resources in which they can

be solved. For this task the semantic directory also

makes use of mappings, and determines that the

first query can be solved in all resources. Thus, it is

sent to the resources, and we obtain inconsistent

results (see Figure 3b), which are resolved in this

case with the result that most resources return.

However, we could use quality measurements of

each resource in order to solve possible

inconsistencies, and apply a balanced average.

Once the year of publication (1999) has been

obtained, we can try to solve the second sub-query,

and finally achieve the user-query result. If we

perform this task with a traditional mediator (that

uses an ontology as the integration schema), we

can only send this query to the DBLP data service.

However, using our architecture, before solving

queries we can use inference mechanisms to get

better query plans. Thus, we use the class-subclass

inference mechanism to obtain that a

ConferencePaper, a BookArticle and a

JournalArticle are also instances of Article class

(Figure 2). Using this knowledge our architecture

sends the second sub-query to the DBLP and CSB

data services (Figure 4). In this way, we can obtain

more results than if we only use the first service,

which is what happens in traditional mediators.

Finally, sub-query results are composed in order to

obtain ontology instances that will be returned to

the end-user. In our example these instances

include received data, but the system removes

duplicate instances of the paper titled “Optimizing

Large Join Queries in Mediation Systems”. Note

that the instance of the paper “Computing

capabilities of mediators” will not be returned by

the traditional mediator, because we have obtained

them taking advantage of the class-subclass

inference capabilities of our system.

ans(A) :- Article(A) , author(A,P), surname(P,”Ullman”) , publishYear(A,Y) ,

Book(B) , publishYear(B,Y) , title(B,”Data on the Web”)

(1) ans(Y) :- Book(B) , title(B,”Data on the Web”) , publishYear(B,Y)

(2) Q(Y): ans(A) :- Article(A) , author(A,P), name(P,”Ullman”) , publishYear(A,Y)

4.1 Advanced Queries

This section tries to illustrate differences

BNE

Data Service

DBLP

Data Service

CSB

Data Service

ans(Y) :- Book(B) , title(B,"Data on the Web") , publishYear(B,Y)

Y = 2000

Y = 1999

Figure 3: (a) Mapping example; (b) First sub-query evaluation

ICEIS 2004 - HUMAN-COMPUTER INTERACTION

316

CSB

Data Service

DBLP

Data Service

ans(A) :- Article(A) , author(A,P), name(P,"Ullman") , publishYear(A,1999)

ans(A) :- ConferencePaper(A) , author(A,P),

name(P,"Ullman") , publishYear(A,1999)

ans(A) :- JournalArticle(A) , author(A,P),

name(P,"Ullman") , publishYear(A,1999)

Figure 4: Second sub-query evaluation

between traditional mediators and the proposed

architecture with respect to query complexity. By

exploiting the reasoning capabilities of ontologies it

is possible to solve queries that are impossible to

solve by means of traditional systems. These

reasoning capabilities allow us to derive new

knowledge that the ontology does not describe

explicitly. Ontology definition languages like OWL

provide the possibility of adding rich semantic

information to the ontologies; this information can

be used to infer knowledge that helps us improve our

queries.

In order to clarify these ideas we present some

extensions of the previous ontology and we describe

how we can use the ontology knowledge to derive

new knowledge. Suppose that we add to the

ontology some knowledge about which classes are

disjoint classes. For example, an article and a

technical report cannot be a thesis, thus Article and

Thesis are disjoint classes and TechnicalReport and

Thesis too (Figure 5a). Since a publication has to be

an article, a book or a technical report and always

one of them, we can infer that every thesis is also a

book. Therefore, a query such as “Find all books

whose author is Ullman” will return all books

written by Ullman plus his thesis (because we infer

that a thesis is also a book). A traditional mediator

has no mechanism to identify this information, so

only Ullman’s books would be returned.

The next example shows that it is possible to

infer that a class has no instances and also that two

classes are equivalent (contain the same set of

instances). For example (Figure 5b), if we know that

an article has to be a Journal article or a book and

always one of them, and every book is also a Master

Thesis, we can infer that each article is also a journal

article and therefore, that no articles are book

articles (i.e. BookArticles class has no instances).

Finally, the ontology definition language allows

us to define special properties of relationships.

These properties also encapsulate knowledge about

the domain that it is not explicitly asserted. For

example, we can define a relationship as a transitive

one. Figure 6 shows an extension of our ontology

where the relationship Contains (defined between

two Publications) is a transitive relationship.

Therefore, we could assert that a Journal contains

Journal Papers and a Journal Paper contains

abstracts, because Journal, JournalPaper and

Abstract are subclasses of Publication. Since the

relationship “contain” is transitive, we can infer that

a Journal contains Abstracts. This information can

also be used to make a query like “find all Abstracts

contained in the Journal title Journal of Digital

Libraries”. In a traditional mediator it is not possible

to know that a Journal has Abstracts, because this

information would not be in the integration schema.

5 CONCLUSIONS AND FUTURE

WORK

In this paper we present an architecture to integrate

Digital Libraries which is based on an extension of

traditional mediation, called semantic mediation. A

mediator typically uses an integration schema as a

global view of the local schemas of the data sources

that are integrated. Thus, queries are limited to the

information that the integration schema provides. In

our approach, the semantics introduced in the

Semantic Directories allows users to make more

expressive queries, viz. semantic queries.

Furthermore, information inferred from the

ontology-explicit knowledge is used to make queries

that a traditional mediator could not evaluate.

Therefore, in several domains in which there are no

technical users, such as librarians, dynamic

integration is a very important issue.

SEMANTIC INTEGRATION OF DIGITAL LIBRARIES

317

Figure 5: Extending the ontology with knowledge about (a) disjoint classes (b) equivalent classes

contains

Figure 6: Extending the ontology with knowledge about transitive relationships

In this context, it is necessary to give users a simple

environment for integrating data information without

modifying the mediator code. The directories supply

an easy way to integrate data sources, opening up

new directions for dynamic integration.

As future work, we intend to study the

possibility of giving data services more semantics,

taking into account service quality, relations with

other domain ontologies, etc. Besides, the scalability

of this architecture will provide the possibility of

integrating not only Digital Library services but also

semantic directories, making possible a full semantic

integration of resources and the interoperability

between applications and between different

domains. This will allow us to make complex

queries, relating domains like Digital Libraries and

Molecular Biology. These kinds of queries will

really exploit the advantages of the proposed

architecture. For example, we could query a Digital

Library using both the results of a biological

experiment stored in a Biological data source and

the related specific domain knowledge.

REFERENCES

Adam, N. R., Atluri, V., Adiwijaya, I.. 2000. SI in Digital

Libraries. Communications of the ACM, vol. 43, no.

6, pages 64-72.

Baru, C., Gupta, A., Ludäscher, B., Marciano, R.,

Papakonstantinou, Y., Velikhov, P., Chu, V.. 1999.

XML-based Information Mediation with MIX. In

Demostrations, ACM/SIGMOD, pages 597-599.

Borgman, C.L.. 1999. What are digital libraries?

Competing visions. Information Processing and

Management 35, 227-243.

C. Baru, A. Gupta, V. Chu, B. Ludaescher, R. Marciano,

Y. Papakonstantinou, and P. Velikhov. 1999. XML-

Based Information Mediation for Digital Libraries. In

Demo Session, ACM Digital Libraries'99.

Dublin Core Metadata Initiative. http://dublincore.org/

Ibrahim, I. K., Schwinger, W.. 2001. Data Integration in

Digital Libraries: Approaches and Challenges,

Proceedings of the International Seminar on Digital

Library and Knowledge Management.

Levy, A., Rajaraman, A., Ordille, J.. 1996. Querying

Heterogeneous Information Sources Using Source

Descriptions. In Proc. VLDB, pages 251-262.

Ludascher, B., Gupta, A., Martone, M. E.. 2001. Model-

based Mediation with Domain Maps. In ICDE'01. pp.

81-90.

Melnik, S., Garcia-Molina, H., Paepcke, A.. 2000. "A

Mediation Infrastructure for Digital Library Services,"

Proc. ACM Digital Libraries Conf., ACM Press.

Mena, E., Kashyap, V., Sheth, A., Illarramendi, A.. 1996.

OBSERVER: An Approach for Query Processing in

Global Information Systems based on Interoperation

across Pre-existing Ontologies. Conference on

Cooperative Information Systems.

Navas, I., Aldana, J.F.. 2004. Towads Conceptual

Mediation. ICEIS.

OWL Web Ontology Language 1.0 Reference. 2003.

http://www.w3.org/TR/owl-ref.

Papakonstantinou, Y., Garcia-Molina, H., Widom, J..

1995. Object Exchange Across Heterogeneous

Information Sources. In Proc. ICDE.

Rodriguez-Martinez & Roussopoulos. 2000. “MOCHA:

Self-Extensible Database Middleware System for

Distributed Data Sources”. In Proc. of the ACM

SIGMOD Conference.

Schollmeier, R.. 2001. A Definition of Peer-to-Peer

Networking for the Classification of Peer-to-Peer

Architectures and Applications. Peer-to-Peer

Computing: 101-102.

UDDI Spec Technical Committee Specification.

http://uddi.org/pubs/uddi-v3.0.1-20031014.pdf.

W3C Web Services Activity. http://www.w3.org/2002/ws/

ICEIS 2004 - HUMAN-COMPUTER INTERACTION

318
