A NEW MECHANISM FOR OS SECURITY

Selective Checking of Shared Library Calls for Security

Dae-won Kim, Geun-tae Bae

Electronics and Telecommunications Research Institute in Korea

Yang-woo Roh, Dae-yeon Park

Department of Electrical Engineering and Computer Science

Korea Advanced Institute of Science and Technology

Keywords: Security attacks, OS security, Dynamic program loader, Software vulnerabilities, Kernel 2.6, Global Offset

Table, Procedure Linkage Table

Abstract: This paper presents a systematic solution to the serious problem of GOT/PLT exploitation attacks. A large

class of security mechanisms has been defeated by those attacks. While some security mechanisms are

concerned with preventing GOT/PLT exploitation attacks, however, they are not complete against

GOT/PLT exploitation attacks or the considerable performance decline occurs. We describe the selective

checking of shared library calls, called SCC. The SCC dynamically relocates a program’s Global Offset

Table (GOT) and checks whether the accesses via Procedure Linkage Table (PLT) are legal. The SCC is

implemented by modifying only the Linux dynamic loader, hence it is transparent to applications and easily

deployable. In experiment results, we show that the SCC is effective in defeating against GOT/PLT

exploitation attacks and is the mechanism with the very low runtime overhead.

1 INTRODUCTION

The C and C++ languages are popular primarily be-

cause of the sensitive control they provide over

system resources including memory. This control is

more than most programmers can handle, as

appeared by the memory-related programming errors

which torment programs written in these languages.

Attacks which exploit memory errors such as buffer

overflows constitute over the 60 percentage of

serious attacks reported by organizations such as the

CERT Coordination Center, and are concerned with

important threats to the computing environment.

A number of attacks which exploit memory

vulnerabilities have been developed. The earliest of

these to achieve widespread popularity was the stack

smashing attacks (Aleph One 2000, Mudge 1997), in

which a stack buffer is overflowed so that a return

address stored in the stack is overwritten with the

starting address of injected shellcode. (See Figure 1).

To avoid such attacks, several approaches were

developed, which, in one way or another, prevent

undetected modifications to a function’s return

address. They include the StackGuard (Crispin

1998) of putting canary values around the return

address, so that the stack smashing can be detected

when the canary value is contaminated; and others

(Arash 2000, Tzi-cker 2001). Despite numerous

technologies designed to prevent buffer overflow

vulnerabilities, the problem persists, and the buffer

overflows remain the dominant attacks of software

security vulnerabilities.

Attacks have moved from stack smashes (Aleph One

2000) to heap overflows (Michel 2001), format

string vulnerabilities (Crispin 2001), multiple free

errors (Anonymous 2001), return-into-library (Rafal

2001), etc. which bypass existing buffer overflow

defences such as StackGuard (Crispin 1998),

LibSafe (Arash 2000) and non-executable memory

segments (Solar Designer). While mechanisms to

collapse these attacks are effective in protecting a

system against the specific attack they focus on,

incorporating many individual techniques to defend

against a wide range of attacks is nontrivial and

often requires resolving conflicting requirements

imposed by the different techniques. Many new

defence mechanisms to prevent new attacks lead us

to conclude that additional ways to exploit the

381

Kim D., Bae G., Roh Y. and Park D. (2005).

A NEW MECHANISM FOR OS SECURITY - Selective Checking of Shared Library Calls for Security.

In Proceedings of the First International Conference on Web Information Systems and Technologies, pages 381-388

DOI: 10.5220/0001226503810388

 SciTePress

memory vulnerabilities of C and C++ will continue

to be emerged in the future. As a first step towards

developing more general solutions against memory

exploits, we observe that an attacker must correctly

determine the runtime address values of the control

information position such as the return address and

the address where the malicious code is located.

This paper proposes, the Selective Checking of

shared library Calls (SCC), a generalized approach

to protect systems against GOT/PLT exploitation

attacks that exploit memory vulnerabilities. The

Linux Kernel 2.6 dynamically and randomly

relocates a program’s stack, heap, shared libraries,

and makes the stack and heap non-executable. (See

Figure 2). To totally overcome a number of

software vulnerabilities, these security mechanisms

will be adapted. The SCC mechanism can support

memory layout randomization mechanisms such as

the Linux Kernel 2.6. In addition to the Linux

Kernel 2.6 security mechanisms, the SCC

dynamically relocates a program’s Global Offset

Table (GOT) and checks whether the accesses via

Procedure Linkage Table (PLT) are legal. Making a

program’s GOT position different each time it

obfuscates the attacker’s assumptions about the

addresses of GOT entries of the vulnerable program

and makes the determination of critical address

values difficult if not impossible. Checking the

accesses via PLT frustrates the trial of attacker to

illegally call shared libraries such as system with

malicious argument ("/bin/bash").

In this paper, the PLT checking is the main

contribution of SCC. The SCC is implemented by

modifying the dynamic program loader compatible

with Linux Kernel 2.6.x, therefore, it is transparent

to the application programs, i.e., existing

applications run without any modification or

recompilation. To date, the SCC has been

implemented on Linux Kernel 2.6.x/IA-32

Figure 1: The stack smashing attack.

void authenticate (char *argv)

{

char buf[128];

strcpy (buf, argv);

printf (“* %s key is authenticated.\n”, buf);

return;

}

buf[128]

prev. frame ptr. (=k)

return address

prev. frame ptr.

return address

shellcode

prev. frame ptr.

return address

*argv

authenticate() stack frame of prev. function

stack growing

address increasing

return

void authenticate (char *argv)

{

char buf[128];

strcpy (buf, argv);

printf (“* %s key is authenticated.\n”, buf);

return;

}

buf[128]

prev. frame ptr. (=k)

return address

prev. frame ptr.

return address

shellcode

prev. frame ptr.

return address

*argv

authenticate() stack frame of prev. function

stack growing

address increasing

return

0xC0000000

CODE

DATA

Heap

0x08000000

Shared Libraries

Stack

0xFFFFFFFF

0x00000000

Non-executable

0xC0000000

CODE

DATA

Heap

0x08000000

Shared Libraries

Stack

0xFFFFFFFF

0x00000000

Non-executable

Figure 2: The linux kernel 2.6 address space.

WEBIST 2005 - WEB SECURITY

382

platforms. It is shown to be effective against

GOT/PLT exploitation attacks, and has the low

runtime overhead.

The rest of this paper is organized as follows. In

Section 2, we describe several related works, and

Section 3 introduces the motivation and detailed

mechanisms of our idea, followed by the analysis of

experiments in Section 4. Finally, Section 5 provides

conclusion.

2 RELATED WORKS

Address randomizing is an instance of the broader

idea of introducing diversity in nonfunctional

aspects of software, and idea suggested by Forrest,

Somayaji, and Ackley (1997). Their implementation

model was called a randomizing compiler, which

can introduce randomness in several non-functional

aspects of the compiled code without affecting the

language semantics. As a proof of concept, they

developed a modification to the gcc compiler to add

a random amount of padding to each stack allocation

request. This transformation defeats most stack

smashing attacks prevalent today, but does not work

against the overflow attacks with a large amount of

NOPs.

The PaX project has developed an approach for

randomizing the memory regions occupied by a

program code and data, called Address Space

Layout Randomization (ASLR). It have modified the

Linux Kernel so that it randomizes the base address

of different segments of memory, such as the stack,

heap, code, and mapped shared library segments.

There are, however, several weak features to ASLR.

ASLR requires changes to the Linux Kernel. Kernel-

level implementation requires re-installation or even

reboot of the operating system. While the GOT is a

frequent target of many attacks, ASLR doesn't

randomize the location of GOT in the SEGMEXEC

mechanism on i386. The performance impact of

ASLR about the PAGEEXEC based on the fault

mechanism is not yet to be officially evaluated.

Finally, the implementation and detailed

mechanisms are seriously architecture-dependent.

Xu, Kalbarczyk, and Iyer developed transparent

runtime randomization (TRR) (Jun 2003), in which

the dynamic loader is modified to randomize the

base address of stack, heap, dynamically loaded

libraries, and GOT. This mechanism, however,

doesn't consider return-into-PLT (Nergal 2001)

attacks. To allow return-into-PLT attacks can't be

concerned with the complete mechanism for

preventing the illegal operations of shared libraries.

3 SELECTIVE CHECKING OF

SHARED LIBRARY CALLS

(SCC)

3.1 Motivation

While TRR (Jun 2003) has the low initialization

overhead and no runtime overhead, it is imperfect

against return-into-PLT (Nergal 2001) attacks. The

PaX project doesn't randomize the location of GOT

or may allow many fault handling overheads due to

the CODE region relocation to prevent return-into-

PLT attacks. We observe that there are a common

characteristic of return-into-PLT attacks. That is the

fact that the number of libraries selected by attackers

to get the critical authorities (root or administrator)

of target system is a few of hundreds and thousands

of shared libraries. The shared libraries they require

to attack are system calls such as execve, system,

setuid32, chmod, etc. Other shared libraries are not

appropriate to accomplish the purposes of attackers,

root shell acquisition and so on.

To exploit critical system calls, attackers can call

normal libraries that include these system calls.

While return-into-PLT can be exploited by attackers

if there are buffer overflow vulnerabilities in

program code, the way to detour normal libraries is

very difficult to find some libraries satisfying some

attack requirements (e.g. system (“/bin/bash”)

included in normal libraries.) and to manipulate

some arguments of critical system calls in memory

layout randomization mechanisms.

In environments of the stack and heap non-

executable such as Linux Kernel 2.6, if attackers

can't run the inserted shellcode to acquire root

authority through overflowing buffers, those

overflows don't mean serious attacks. We arrived in

one conclusion by the facts that to relocate the

CODE region to prevent return-into-PLT generates

continuously some fault handling overheads and the

number of shared libraries required to succeed

return-into-PLT attacks is within the limit of a few

libraries.

The SCC, our mechanism, is designed through

these facts. The SCC relocates Global Offset Table

(GOT) through a similar idea to TRR (Jun 2003) and

checks whether the accesses via Procedure Linkage

Table (PLT) to call shared libraries such as above

system calls are legal. The 'legal' means that the

shared libraries are called from the call instruction

of CODE region. All PLT accesses except for those

are ‘illegal’.

A NEW MECHANISM FOR OS SECURITY: Selective Checking of Shared Library Calls for Security

383

3.2 The Operations of SCC

The objectives of SCC are to randomize the GOT

location and check whether the accesses via the

specified PLT entries are legal. The GOT relocation

is similar to TRR (Jun 2003), and the PLT checking

can be achieved using PLT rewritings and inserting

the Checking Code in a random memory space. Both

the GOT relocation and the PLT checking

mechanisms are only dynamic loader modification

approach, not Kernel.

Figure 3 shows the typical sequence of steps

required to launch an application, using ‘vim’ as an

example. In this example, a user types ‘vim’ at the

shell prompt, and the shell creates a child process

using the fork system call. The new child process

uses the execve system call to load and initialize

‘vim’. Inside the execve system call, the operating

system kernel maps the executable into memory,

sets up its CODE/DATA segments, stack, heap and

dynamic program loader, and then transfers the

program control, which is the program counter

(%eip), to the dynamic program loader. The

dynamic program loader maps the shared libraries

required by ‘vim’ into memory. Finally, the dynamic

program loader hands over the program control to

the entry point of ‘vim’, and ‘vim’ begins to execute.

The SCC operations are shown in 2, 3 and 4 of

‘Dynamic program loader’.

3.3 The Overview of SCC

It is assume that the GOT is already randomized by

the dynamic program loader through a similar

mechanism of TRR (Jun 2003). The PLT, therefore,

must be rewritten to correctly refer to new GOT.

In Figure 4, the PLT can be accessed by the

return of current function when the return address in

stack is overwritten by a attacker (ATTACK), or can

be accessed by the legal call due to the operation of

call instructions in the CODE region. As mentioned

earlier, attackers are primarily concerned with a few

of critical system calls.

We modify the PLT entries (in Figure 4, PLT2)

which a attacker requires to get root shell. The each

entries of PLT are related with each shared library

functions, and when a PLT entry (PLT2) modified

for security is accessed, a changed jmp instruction in

the PLT entry (PLT2) passes the program control to

the Checking Code. The Checking Code checks

whether this PLT access is legal, and if 'legal', the

Checking Code passes the program control to the

related shared library with the reference of address

value in the GOT. In the case of other PLT entries,

only one of three instructions in each original PLT

entries is modified. The accesses to other PLT

entries, therefore, are operated like as no SCC.

3.4 The Checking Code

Figure 5 shows the stack status when the PLT entry

is just accessed by the legal call in the CODE region

and the illegal return in the stack. The PLT2 entry of

Figure 4 assumes the entry related with a critical

library function such as system and the entry that

instructions have been modified by our dynamic

program loader. The main idea of Checking Code is

that the return address value is still remained in the

stack after returning due to the return address

overflowed by a attacker. If the return value in stack

is equal to the accessed PLT entry address, this PLT

access can be determined as the attack trial. In

Figure 5, SP is the stack pointer and the things that

two thunder marks are pointing present the contents

in (SP-4) address. The Checking Code is mapped to

the random position in the shared library region by

the dynamic program loader.

Figure 4: The overview of SCC.

User runs ‘vim’.

Shell creates new process using fork().

Load & init ‘vim’.

execve() system call

1. Maps ‘vim’ to memory.

2. Sets up stack, heap, and dynamic program

loader.

3. Transfers control to dynamic program loader.

Dynamic program loader

1. Maps shared libs. to memory.

2. SCC randomly relocates the GOT.

3. SCC randomly inserts the Checking Code.

4. SCC rewrites the PLT entries.

‘vim’ begins to execute.

User runs ‘vim’.

Shell creates new process using fork().

Load & init ‘vim’.

execve() system call

1. Maps ‘vim’ to memory.

2. Sets up stack, heap, and dynamic program

loader.

3. Transfers control to dynamic program loader.

Dynamic program loader

1. Maps shared libs. to memory.

2. SCC randomly relocates the GOT.

3. SCC randomly inserts the Checking Code.

4. SCC rewrites the PLT entries.

‘vim’ begins to execute.

Figure 3: The SCC operations.

RET in Stack

Call in TEXT

Legal call?

Checking Code

PLT

Attack

GOT

PLT1

PLT2

PLT3

Jump

Reference

RET in Stack

Call in TEXT

Legal call?

Checking Code

PLT

Attack

GOT

PLT1

PLT2

PLT3

Jump

Reference

WEBIST 2005 - WEB SECURITY

384

The Checking Code requires two values to check

whether the critical PLT entry is accessed by attacks

or not. The first value is the content of (SP-4)

address when the PLT entry is just accessed. In

Figure 5, that is the content of a thunder-marked

word, and if this value is related with the accessed

PLT address, the PLT entry access is determined as

the attack trial. If legal call, this value is not related

with the accessed PLT entry. The second value

required for the Checking Code is the address of

accessed PLT entry. It is used to compare with the

content of (SP-4) address.

In the case of real SCC's mechanism, the

accessed PLT entry inserts the XORed offset, (it is

exclusive OR of original offset in the PLT entry and

a random-generated value during the initial phase of

dynamic loader.), value in the stack to help the

Checking Code to identify the accessed PLT entry

address and to defend possibly the other types of

return-into-PLT attacks. There are two types of

return-into-PLT attacks. In the case of first attack

type, the program control is directly changed to the

PLT entry (PLT2) by using the overflowed return

address from the stack. The second attack type

overflows the stack with the offset of critical PLT

entry and returns to the PLT_init. (See Figure 8). To

prevent this second attack type, XORing the offset is

required.

Figure 6 shows the stack status including a

XORed offset inserted by the modified PLT entry

when the Checking Code is just accessed. The

Checking Code can use the values required to check

attacks because the overflowed return address and

the accessed PLT entry address (be calculated by

XORed offset) are in the stack.

Figure 7 shows the operations of Checking Code.

In (1), the original offset is calculated by XOR (the

XORed offset). We can calculate the GOT entry

address related with the original offset because there

are a regular rule between the original offset and

GOT entry address. In (2), the GOT entries related

with the critical PLT entries are initialized as zero

when mapping the new GOT. In the case of lazy-

loading, if a shared library is first called, the

dynamic program loader resolves a called library

address and writes the address to the desired GOT

entry. If the value in the GOT entry is zero, the

Checking Code transfers the program control to the

dynamic program loader to resolve the address of a

desired shared library. If not, the Checking Code

passes the program control to the related shared

library with the reference of address value in the

GOT.

3.5 The PLT Entry Modification

We explain how the selected PLT entries are

modified. Figure 8(a) shows the original PLT entries

in the CODE region. Each PLT entry consists of

three instructions and the PLT entries (In Figure 8,

PLT2) to be selected for security are the entries

jumping to the critical shared libraries such as

system. In Figure 8(b), the dynamic program loader

rewrites PLT entries for pointing at new GOT

entries and jumping to the Checking Code when the

critical PLT entries (PLT2) are accessed. The

dynamic program loader sets the writable flag of

CODE region and rewrites the PLT entries from

PLT_init to the end of PLT. The all GOT_entry

Figure 5: The stack status when the critical PLT entries

are just accessed.

Figure 6: The stack status when the checking code is

just accessed.

Figure 7: The operations of checking code.

Legal call

Illegal return

return addr.

STACK growing

arg1 arg2

overflowed

return addr.

overflowed

4 bytes

overfloweda

rgs

XORed

offset

XORed

offset

Legal call

Illegal return

return addr.

STACK growing

arg1 arg2

overflowed

return addr.

overflowed

4 bytes

overfloweda

rgs

XORed

offset

XORed

offset

Calculates the accessed PLT entry

address by the XORed offset.

Compares the accessed PLT entry

address with the overflowed return

address.

equal

System HALT.

not equal

Calculates the GOT entry address

from original offset.

The value in the GOT entry is

zero

Pushes the second GOT entry

address, increase SP as 8, and

jumps to the dl-resolve().

Jump to the address in the GOT entry.

not zero

(1)

(2)

Calculates the accessed PLT entry

address by the XORed offset.

Compares the accessed PLT entry

address with the overflowed return

address.

equal

System HALT.

not equal

Calculates the GOT entry address

from original offset.

The value in the GOT entry is

zero

Pushes the second GOT entry

address, increase SP as 8, and

jumps to the dl-resolve().

Jump to the address in the GOT entry.

not zero

(1)

(2)

Legal call

Illegal return

return addr.

STACK growing

arg1 arg2

overflowed

return addr.

overflowed

4 bytes

overflowed

args.

Legal call

Illegal return

return addr.

STACK growing

arg1 arg2

overflowed

return addr.

overflowed

4 bytes

overflowed

args.

A NEW MECHANISM FOR OS SECURITY: Selective Checking of Shared Library Calls for Security

385

values of Figure 8(b) are new GOT_entry values.

The dynamic program loader can find out the real

names of shared libraries by using fixup function of

dynamic program loader referring to each offset

values, $0x0 and so on, and can search what are the

critical PLT entries. We assume the PLT2 entry is a

critical PLT entry. The information required for the

Checking Code is a return address in the stack and

the accessed PLT address. The purpose of PLT

modification is to give this information to the

Checking Code.

In the PLT2 entry of Figure 8(b), the first

instruct-ion inserts the XORed_offset value in (SP-

8) address to maintain the malicious return address

of attacker. The accessed PLT address can be

calculated from the XORed_offset value. The

second instruction passes the program control to the

Checking Code.

4 EFFECTIVENESS AND

PERFORMANCE EVALUATION

This section describes the experimental evaluation

of SCC. Subsection 4.1 describes the SCC's

effectiveness against the attacks related with the

GOT and PLT. Subsection 4.2 describes the

performance cost of SCC through various types of

programs. In this experiments, execve(), execl(),

execlp(), execle(), execv(), execvp(), chmod(),

setuid32(), chown32(), setresuid32(), fchown32(),

fchmod(), setpgid() and system(), these 14 system

calls are checked from the PLT entry accesses due to

attacks. The measurement is taken on a PC with

Kore Linux 2004 (Kernel 2.6.7), Pentium III

800MHz processor, 256MB memory and dynamic

program loader ld-2.3.3.so we modified.

4.1 Effectiveness Evaluation

Here we illustrate the SCC's effectiveness in

thwarting attacks related with the GOT and PLT.

The effectiveness of SCC was tested using publicly

available vulnerable programs and attacks against

them. The programs listed in Table 1 are

conventionally installed as SetUID root. If the

attacker can get on of these programs to start a shell,

then the attacker gets a root shell. The vulnerabilities

and the attacks we used are presented below.

Table 1: Evaluation against security attacks.

Program Description No SCC SCC

plt-exploit1

stack overflow

/PLT

local root

shell

detected

plt-exploit2

stack overflow

/PLT

local root

shell

crash

null httpd heap overflow

/GOT

remote root

shell

crash

sendmail integer overflow

/GOT

local root

shell

crash

y We made a simple stack overflow program, plt-

exploit1.c, related with the return-into-PLT

attack. plt-exploit1.c is the attack directly

returning to the critical PLT entry. When a

large number of strings are supplied to the

program by a attacker, the stack buffer is

overflowed, and when the vulnerable function

is returned, the program control is moved to the

critical PLT entry, and a root shell is created.

y We made second simple stack overflow

program, plt-exploit2.c, related with the return-

into-PLT attack. When the vulnerable function

is returned, the program control is returned to

the start address of PLT_init, and a root shell is

created. The details of mechanism are described

to the Phrack document (Nergal 2001).

y null httpd is a web server for Linux. A heap

overflow vulnerability exists in its handling of

the POST request. The attack passes a negative

content length to start a heap overflow,

overwrite a function pointer in the GOT, and

create a remote root shell.

y sendmail is the email agent that sends messages

to remote hosts. An integer overflow

vulnerability exists in sendmail's function when

it uses user-supplied signed integer to address

an array. The attack uses a large number to

overwrite a function pointer in the GOT to

create a local root shell.

Figure 8: The original and modified PLT entries.

jmp *old_GOT_entry4

push $0x0

jmp PLT_init

jmp *old_GOT_entry5

push $0x8

jmp PLT_init

pushl old_GOT_2nd

jmp *old_GOT_entry3

add %al, (%eax)

PLT_init :

PLT0 :

PLT1 :

PLT2 :

(a) Original PLT entries

jmp *GOT_entry4

push $XORed_offset

jmp PLT_init

jmp *GOT_entry5

push $XORed_offset

jmp PLT_init

movl

$XORed_offset,

0x8(%esp)

jmp check_codes

pushl GOT_2nd

jmp *GOT_entry3

add %al, (%eax)

PLT_init :

PLT0 :

PLT1 :

PLT2 :

(b) Modified PLT entries

jmp *old_GOT_entry6

push $0x10

jmp PLT_init

jmp *old_GOT_entry4

push $0x0

jmp PLT_init

jmp *old_GOT_entry5

push $0x8

jmp PLT_init

pushl old_GOT_2nd

jmp *old_GOT_entry3

add %al, (%eax)

PLT_init :

PLT0 :

PLT1 :

PLT2 :

(a) Original PLT entries

jmp *GOT_entry4

push $XORed_offset

jmp PLT_init

jmp *GOT_entry5

push $XORed_offset

jmp PLT_init

movl

$XORed_offset,

0x8(%esp)

jmp check_codes

pushl GOT_2nd

jmp *GOT_entry3

add %al, (%eax)

PLT_init :

PLT0 :

PLT1 :

PLT2 :

(b) Modified PLT entries

jmp *old_GOT_entry6

push $0x10

jmp PLT_init

WEBIST 2005 - WEB SECURITY

386

This is not a comprehensive exploit list, but it

showed that all tests are terminated with the crash or

detection message. They didn't invoke a root shell.

4.2 Runtime Overhead

The runtime overhead occurs when the Checking

Code is accessed, and if the critical PLT entries are

accessed the Checking Code is processed. The

overhead size is, therefore, dependent to the

overhead of Checking Code itself and the accessed

number of modified PLT entries. The Checking

Code may be constructed with 15 line assembly

codes, and the average processing time of Checking

Code is about 0.072us (The avg. of 1000 runs). The

overhead of Checking Code itself is, therefore, very

small because one instruction is processed within

one cycle to the pipelined-architecture.

Table 2: The count of used system calls.

The Count of System Calls

Program

Total Critical Description

traceroute 918 1 setuid32(1)

hanterm 831 4 chown32(1) chmod(1)

setresuid32(2)

passwd 1113 2 fchown32(1) fchmod(1)

emacs 21086 2 chmod(1)

setpgid(1)

vim 689 2 chmod(1)chown32(1)

/bin/bash 928 2 setpgid(2)

mozilla 43088 3 execve(1)

chmod(2)

telnet 514 0

Table 2 shows the count of system calls from the

program start to the program end. The 'strace'

program in Linux can count the number of used

system calls. The above four programs are SetUID

programs and the below four programs are normally

popular programs. In these results, we can know the

accessed number of Checking Code is even smaller

than the accessed number of total system calls.

Although the 'critical' number of some programs

increases according to the running time or other

versions of same program, the increasing number is

relatively very smaller than that of total system calls.

Table 3 shows the elapsed time of pure code

running except for the time waiting for some user

inputs, etc. The evaluation program is supported as

'/usr/bin/time' in Linux. When a specified program

finishes, '/usr/bin/time' writes a message to standard

out giving timing statistics about the program.

Because the resolution of '/usr/bin/time' is

millisecond (ms) unit, we consider the result of '0s

024' as the result of '24000 us'. The 'SCC overhead'

means the total overhead time due to the accessed

Checking Code. We measured the number of clock

cycles and convert them to microseconds using the

processor clock frequency. These experiments show

that the runtime overhead generated by the SCC is

very small. (nearly 0%).

Table 3: The runtime overhead.

The Elapsed Time (usec)

Program

No SCC

SCC

overhead

Overhead (%)

traceroute 24000 0.5821 0.0024

hanterm 308000 1.356 4.403 x 10PP

-4

passwd 29000 0.662 0.0023

emacs 994000 1.17 1.177 x 10PP

-4

vim 107000 0.882 8.243 x 10PP

-4

/bin/bash 128000 0.876 6.800 x 10PP

-4

mozilla 3169000 1.18 3.724 x 10PP

-4

telnet 16000 0.312 0.195 x 10PP

-4

5 CONCLUSION

This paper proposes Selective Checking of shared

library Calls (SCC) against GOT/PLT exploitation

attacks. The underlying principle of SCC follows to

randomize the application memory layout so that it

is virtually impossible to determine locations of

critical program data such as buffers, return

addresses, and pointers of function. New idea

against return-into-PLT attacks is applied to the SCC

because the randomization of CODE region

produces continuously many runtime overheads. The

SCC's mechanism is fully transparent to application

programs because it is implemented by modifying

only the dynamic program loader. The effectiveness

of SCC shows that it can defeat some known

GOT/PLT attacks. Performance measurements show

that the SCC produces very low runtime overhead.

REFERENCES

“Aleph One”, 2000. The Stack for Fun And Profit. Phrack

14(49).

Anonymous, 2001.Once Upon a Free(). Phrack 9(57).

Arash, B., Navjot, S., and Timothy, T., 2000. Transparent

Run-Time Defense Against Stack Smashing Attacks.

In Proceedings of the 2000 USENIX Annual Technical

Conference (USENIX-00), pages 251-262, Berkeley,

CA.

A NEW MECHANISM FOR OS SECURITY: Selective Checking of Shared Library Calls for Security

387

Crispin, C., Calton, P., Dave, M., Jonathan, W., Peat, B.,

Steve B., Aaron, G., Perry W., Qian Z., and Heather

H., 1998. StackGuard: Automatic Adaptive Detection

and Prevention of Buffer Overflow Attacks. In Proc.

7th USENIX Security Conference, pages 63-78, San

Antonio, Texas.

Crispin, C., Matt, B., Steve, B., Greg, K., Mike, F., and

Jamie L., 2001. FormatGuard: Automatic Protection

From printf Format String Vulnerabilities. In USENIX

Security Symposium, Washington, DC.

Jun, X., Zbigniew, K., and Ravishankar, K. I., 2003.

Transparent Runtime Randomization for Security. In

Proceedings of the 22

International Symposium on

reliable Distributed Systems, pages 260-269, Florence,

Italy.

Michel, K., 2001. Vudo Malloc Tricks. Phrack 8(57).

Mudge, 1997. How to Write Buffer Overflows. Published

on World-Wide Web at URL

TUTUhttp://www.insecure.org/stf/mudge_buffer_overflow_t

utorial.html

UUTT.

Nergal, 2001. Advanced return-into-lib(c) exploits (PaX

case study). Phrack 4(58).

PaX Team. Homepage of The PaX Team.

http://pax.grsecurity.net.

Rafal ,W., 2001. Defeating Solar Designer Non-

Executable Stack Patch.

http://www.insecure.org/sploits/non-executable.stack.p

roblems.html.

"Solar Designer". Non-Executable User Stack.

TUTU

http://www.openwall.com/linux/UUTT.

Stephanie, F., Anil, S., and David H. A., 1997. Building

diverse computer systems. In 6th Workshop on Hot

Topics in Operating Systems, pages 67-72, Los

Alamitos, CA. IEEE Computer Society Press.

Tzi-cker C. and Fu-Hau H., 2001. Rad: A Compile-Time

Solution to Buffer Overflow Attacks. In 21st

International Conference on Distributed Computing,

page 409, Phoenix, Arizona.

WEBIST 2005 - WEB SECURITY

388
