XPACK: A HIGH-PERFORMANCE WEB DOCUMENT ENCODING

Daniel Rocco

Department of Computer Science, University of West Georgia

Carrollton, GA 30118 USA

James Caverlee, Ling Liu

College of Computing, Georgia Institute of Technology

Atlanta, GA 30332, USA

Keywords:

XML compression, path queries.

Abstract:

XML is an increasingly popular data storage and exchange format whose popularity can be attributed to its

self-describing syntax, acceptance as a data transmission and archival standard, strong internationalization sup-

port, and a plethora of supporting tools and technologies. However, XML’s verbose, repetitive, text-oriented

document speciﬁcation syntax is a liability for many emerging applications such as mobile computing and dis-

tributed document dissemination. This paper presents XPack, an efﬁcient XML document compression system

that exploits information inherent in the document structure to enhance compression quality. Additionally, the

utilization of XML structure features in XPack’s design should provide valuable support for structure-aware

queries over compressed documents. Taken together, the techniques employed in the XPack compression

scheme provide a foundation for efﬁciently storing, transmitting, and operating over Web documents. Initial

experimental results demonstrate that XPack can reduce the storage requirements for Web documents by up

to 20% over previous XML compression techniques. More signiﬁcantly, XPack can simultaneously support

operations over the documents, providing up to two orders of magnitude performance improvement for certain

document operations when compared to equivalent operations on unencoded XML documents.

1 INTRODUCTION

The XML document format (Bray, 1998) is emerging

as a popular document encoding for online informa-

tion exchange. Standardized Web document formats

like XML are advantageous for a variety of reasons.

XML has well-deﬁned semantics, strong internation-

alization support (Savourel, 2001), and a plethora

of developer tools for managing and exchanging

data. In addition, XML derived languages, such as

WSDL (Christensen et al., 2001) and SOAP (Mitra,

2003), provide higher level interaction standards that

leverage existing XML technology. XML data is self-

describing and authors are encouraged to use clear en-

tity names to assist other users in understanding the

data (Bray, 1998). Since many parties interested in

data exchange interact with different entities during

the course of a transaction, predeﬁned data exchange

standards are a must. In the highly dynamic world

of the Web, the set of data exchange partners an en-

tity may use will evolve over time, which provides a

strong argument for the use of industry-standard com-

munication technologies rather than ad hoc solutions.

However, XML has two disadvantages that present

obstacles to widespread adoption as an information

exchange medium for many applications: the size

penalty and textual representation. Many entities that

might consider XML would need to convert existing

proprietary document formats into XML, which typ-

ically produces an undesirable and dramatic increase

in the size of the stored data (Liefke and Suciu, 2000).

Another concern stems from the fact that XML is

stored in a text document encoding like ASCII, which

incurs signiﬁcant computational costs for parsing and

validation.

Many applications exist that could beneﬁt from the

standardization of XML but require a more efﬁcient

document representation. For example, data distri-

bution and routing applications require large num-

bers of documents to be handled quickly (Altinel and

Franklin, 2000), while today’s mobile devices have

limited processing power, communication bandwidth,

and storage capacity. For these and other applications,

it is advantageous to minimize the storage space re-

quired by documents and to provide efﬁcient access

to application-speciﬁc areas of interest. While XML

provides advantages with its self-describing charac-

teristics and universally recognized format, these ap-

Rocco D., Caverlee J. and Liu L. (2005).

XPACK: A HIGH-PERFORMANCE WEB DOCUMENT ENCODING.

In Proceedings of the First International Conference on Web Information Systems and Technologies, pages 32-39

DOI: 10.5220/0001233000320039

 SciTePress

plications cannot afford the performance penalty that

has previously been the price of converting to XML.

There have been several efforts to reduce the stor-

age impact of converting to or otherwise utilizing

XML. XMill (Liefke and Suciu, 2000) is an XML

document compressor designed to alleviate the con-

cern of data expansion due to XML conversion. The

WAP Binary XML Format (World Wide Web Con-

sortium, 1999) and its extension Millau (Girardot and

Sundaresan, 2000) have been introduced for the efﬁ-

cient encoding and streaming of XML structure, par-

ticularly in a wireless environment. These compres-

sion schemes addressed the data expansion concern

but do not provide explicit support for querying com-

pressed documents. There have been subsequent ef-

forts to provide query support over compressed XML

documents with systems that compress the content of

the document (Min et al., 2003) or its structure (Bune-

man et al., 2003).

This paper presents XPack, a document compres-

sion system providing both good compression and

strong query support for compressed documents. The

design goal of XPack is to support the acceptance of

XML as a viable data exchange mechanism by min-

imizing the performance penalty incurred by appli-

cations that use it. XPack’s compression and query

techniques are built upon these fundamental design

principles:

1. Redundancy Elimination. XPack reduces much of

the redundancy found in XML documents, yielding

a smaller document footprint.

2. Binary Format. XPack’s binary encoding requires

no parsing when loading a document from disk.

Document parsing and veriﬁcation is a resource

intensive operation, so applications using XPack

can expect better performance when loading doc-

uments.

3. Compartmentalization. XPack separates various

document components to provide faster access to

interesting aspects of a document, such as its tree

structure information or node tag list.

4. Compressed Data Access. Unlike other widely

used document compression systems, XPack pro-

vides general query facilities that operate over the

compressed documents. Compressed data access

allows applications to store data in a compact,

space-saving format without sacriﬁcing the ability

to do ad hoc querying.

2 RELATED WORK

The XPack document encoding leverages ideas from

our previous work on the Page Digest system (Rocco

et al., 2003) for efﬁcient representation of HTML

Web pages. The Page Digest was designed to support

efﬁcient document processing in applications such as

Web change monitoring (Buttler et al., 2004; Buttler

et al., 2003). XPack is an extension of this work that

targets XML documents, in particular, by providing a

more ﬂexible framework that supports containerized

document compression and efﬁcient path querying.

The foundation work for modern data compression

was done by Ziv and Lempel (Ziv and Lempel, 1977),

who proposed the idea of the dictionary compres-

sor. Dictionary compressors operate by substituting

repeated occurrences of a given string with a shorter

sequence; the original ﬁle can be reconstructed by re-

versing the substitution. This technique and its vari-

ants have become integral components of many stan-

dard computing tools such as the Gzip (loup Gailly

and Adler, 2004) ﬁle compression tool. For a more

general introduction to data compression, we refer the

reader to (Sayood, 2000; Witten et al., 1999).

Recently, there have been several efforts to de-

sign XML-speciﬁc compression algorithms. The ﬁrst,

XMill (Liefke and Suciu, 2000), was designed to pro-

mote standardized document storage and transmission

formats while alleviating the concern of data expan-

sion that is often the penalty of converting data to

XML. The XMill compressor achieves this goal by

creating a container for each document tag and plac-

ing the data values for each tag into the same con-

tainer. The containers are then compressed using

a standard dictionary compression library. The in-

tuition behind this approach is that grouping values

by their tag names would arrange repetitious sections

of the document closer to each other, which would

yield greater compression efﬁciency from the dictio-

nary compressor. The fundamental problem with the

XMill approach is its opaque nature: data compressed

with the XMill compressor is only available for use

after being decompressed, a costly overhead step that

must be added to the overhead of parsing the text doc-

ument.

The Millau (Girardot and Sundaresan, 2000) bi-

nary format—an extension to the WAP Binary XML

Format (World Wide Web Consortium, 1999)—has

been introduced for the efﬁcient encoding and stream-

ing of XML structure, particularly in a wireless envi-

ronment. A technique using multiplexed hierarchical

PPM models was introduced in (Cheney, 2001). It

has been shown to be slower than XMill, but in some

cases achieves a higher degree of compression.

There have been several recent efforts to provide

query support over compressed XML documents,

typically by making a trade-off between the degree

of compression and support for queries. The ﬁrst

of these techniques, XGRIND (Tolani and Haritsa,

2002), compresses XML documents by using Huff-

man encoding for non-enumerated types. If a doc-

ument conforms to a known DTD, additional com-

XPACK: A HIGH-PERFORMANCE WEB DOCUMENT ENCODING

pression may be achieved by encoding the enumer-

ated types listed in the DTD. XGRIND supports exact

match and range queries over the compressed XML

document. Similarly, XPRESS (Min et al., 2003)

maintains the original structure of each XML doc-

ument to support path queries, but instead uses a

technique called reverse arithmetic encoding for com-

pressing labeled paths of the document. In exper-

iments, the XPRESS system is shown to be faster

than XGRIND for compression and query resolu-

tion. In (Buneman et al., 2003), the authors present

an XML compression technique that supports path

queries over the compressed XML. Their technique

relies on the identiﬁcation of shared subtrees across a

single document.

3 XPACK DOCUMENT

ENCODING

XPack is a document encoding and compression sys-

tem designed to operate over XML data. In this sec-

tion, we construct a formal model of an XML doc-

ument to facilitate the explanation of the techniques

that XPack employs. Using this document model,

we deﬁne a set of document operators, which are re-

versible functions that transform the XML data to re-

duce representation redundancy and provide efﬁcient

access to interesting document components.

3.1 Reference Document Model and

Design Concepts

We model an XML document as an ordered tree of

nodes where each node has a name and optionally

contains a namespace qualiﬁer, attributes, and text

content. More formally, an XML document D is a set

of tags {t

, . . . , t

}; each tag t

is a string of char-

acters denoting the tag’s name and value. We say that

tag t

is a closing tag if the tag name begins with the

slash character ‘/’; otherwise the tag is an opening tag.

A document D is required to have the same number

of opening and closing tags, which occur in tag pairs.

A tag pair describes a node used in a document’s tree

model: a node is a descendent of the tag pairs that

enclose it and an ancestor of the tag pairs that it en-

closes. The document D’s tag set {t

, . . . , t

} must

satisfy the following invariants:

1. ∀ opening tags t

, ∃ t

s.t.

Actual XML documents can also have “self closing”

tags which combine the opening and closing tag. We model

such tags as a tag pair t

, t

i+1

; in the ASCII version the

closing tag t

i+1

is implied.

(a) i < j

(b) t

is a closing tag for t

, t

s.t. i < k < j < l, and

(d) ∄ a tag pair t

, t

s.t. k < i < l < j

2. D contains the same number of opening and clos-

ing tags

3. t

is an opening tag

4. by extension of the above, t

is the closing tag for

Invariants 1 and 2 require all documents to contain a

balanced tag set, i.e. each open tag must have a corre-

sponding close tag. (a) and (b) state that open tags are

required to preceed their closing tag. (c) and (d) are

concerned with the proper nesting of tags; Figure 1

demonstrates proper nesting along with two examples

of improper nesting. Finally, invariants 3 and 4 state

that the ﬁrst tag must be an open tag and that the last

tag must be the corresponding closing tag.

...

<k>

</k>

...

(a)

...

<k>

</k>

...

(b)

...

<k>

</k>

...

(c)

Figure 1: Examples of improperly nested tags (a) and (b)

along with a properly nested example (c).

3.2 XPack System Overview

The XPack encoding system operates over this docu-

ment model to produce an XPack-encoded version of

the document that retains the same structural elements

and semantic meaning as the original document rep-

resented in a more efﬁcient format. XPack espouses a

container-oriented document structure that is created

and modiﬁed by a set of unary document operators:

• PagePack (φ): document container encoding

• PathPack (ψ): path structure encoding

• NamePack (ρ): node tag name encoding

• URLPack (γ): document URL encoding

• AttributePack (α): attribute encoding

• ContentPack (χ): content encoding

XPack’s document operators are designed to support

ﬂexible redundancy reduction. The PagePack oper-

ator is unique in that it operates over the original

XML, while the remaining operators take a docu-

ment that has already been containerized as their in-

put. PagePack’s purpose is to transform the text-

oriented representation of an XML document into

WEBIST 2005 - INTERNET COMPUTING

a compact tree-oriented representation of the docu-

ment’s structure augmented by a series of content

containers. These containers can then be transformed,

augmented, or replaced by subsequent operators. To

as great an extent as possible, the remaining operators

are designed to work in parallel so that overlapping

computation can be used on parallel machines.

Figure 2 shows the XPack document compression

process. When a document enters the system, a type

detector module determines the document’s type and

loads a document type proﬁle. The document type

proﬁle determines the default set of operators XPack

will use in the redundancy elimination phase and also

speciﬁes how the document is split into components.

Next, the document enters the redundancy elimination

phase, which uses the selected XPack document oper-

ators to reduce the redundancy, and therefore the size,

of the document. The minimized document compo-

nents are then passed to the aggregator for reassem-

bly and compressed to yield the ﬁnal XPack-encoded

document.

The heart of the XPack system is the redundancy

elimination operators. The PathPack operator tries to

reduce the space consumed by the document’s tree

structure. This encoding works best on documents

that utilize structure more than content to convey

meaning. PathPack is also designed to provide ef-

ﬁcient access to the paths between document nodes

for faster path matching and query operations. The

NamePack operator utilizes observations about the

tag names in XML documents to reduce their size.

The URLPack operator reduces the space consumed

by a document’s URLs. The AttributePack operator

combines the concepts found in the NamePack and

URLPack operators and reduces the space consumed

by element attribute names and values. AttributePack

performs identiﬁer substitution on attribute names and

substitution and preﬁx production on attribute values.

PagePack The PagePack operator φ creates a node

structure container S by assigning a unique identiﬁer

to each node in the document and extracting the struc-

ture information inherent in the opening and clos-

ing tag sequence. φ(D) = (S, M ) is a reversible

function mapping an XML document D to a com-

pact tree-structure representation and a set of contain-

ers for the document’s content. S = {a

, . . . , a

}

where a

is the number of child nodes under the open-

ing tag t

. S preserves the document’s tree structure

by recording the relationship between opening tags.

Node content is placed into a list of containers M =

, . . . , m

}, which retain the information from the

original document regarding each node’s name, asso-

ciated attributes, and content. The PagePack trans-

formation stands as the basis upon which the other

document operators are constructed.

Conceptually, PagePack encodes the document in

File Type

Detector

XML

HTML

Operator Selection

Content

Pack

PathPack URLPack NamePack

Attribute

Pack

XPack Aggregator

XPack

Compressed File

Compressor

Type

determination

phase

Redundancy

elimination

phase

Aggregation &

compression

phase

...

PagePack

Figure 2: XPack system overview.

three steps. First, the document tree is traversed in

depth-ﬁrst order and each node in the tree is assigned

a unique identiﬁer. For the sake of convenience, we

choose an identiﬁer equal to the visit order of each

node; the root of the tree is assigned identiﬁer “1.” Af-

ter each node has an ID, PagePack constructs a struc-

ture array that succinctly encodes the relationships be-

tween document nodes. Finally, node containers are

constructed for each node in the document.

The remaining containers in the PagePack structure

hold the information contained in the original nodes

of the document tree, such as each node’s tag name,

attributes, and any associated content. Node contain-

ers are stored in index order, so the ﬁrst node con-

tainer holds the data belonging to the node with index

“1,” the root node.

PathPack Path structure encoding transforms the

tree structure of an XML document into a sequence

that encodes the paths found in the document tree

to support efﬁcient execution of path-style queries.

Given a node structure container S, PathPack ψ(S)

is a reversible function that generates a sequence

, 1 ≤ j ≤ m, where m ≤ n and each x

is a

subpath tuple of the form < start

, end

, parent

Each subpath in the sequence represents a nonbranch-

ing fragment of a root-leaf path; later paths in the se-

quence are further to the right and further down the

tree than earlier paths in the sequence. For example,

the subpath < 2, 3, 1 > represents a two-node non-

branching path between nodes 2 and 3; the start node

of path, 2, is a child of node 1. Given a node structure

container S for document D, the following algorithm

sketch highlights the main components of the Path-

Pack operation:

XPACK: A HIGH-PERFORMANCE WEB DOCUMENT ENCODING

1. set the start of the next path to the root node a

∈ S

2. for each node a

∈ S

(a) if a

is a branch or leaf, output the current path.

for each child c, set c to the start of the next path

and run PathPack with it as the root.

(b) otherwise continue.

NamePack The NamePack operator ρ eliminates

document tag name redundancy by storing each

unique tag name once and assigning a short reference

to each name. For a document D with node container

M = {m

, . . . , m

}, ρ(M ) = (I, M

′

) is a reversible

function that generates a set of tag name identiﬁers

I = {i| unique tag names in M }, stored in lexical

order for efﬁcient tag name searching.

NamePack reduces the redundancy of a Web docu-

ment by generating tag name references and substi-

tuting the shorter references for the occurrences of

the name in the document, eliminating the extra char-

acters needed to store long and repeated tag names.

NamePack is effective because the opening and clos-

ing tags that are the main structural feature of XML

documents require tag names to be repeated; this ne-

cessity stems from the design of the document storage

model but is not fundamental to representing struc-

tured documents in a computer system. Repetition of

tag names can amount to a considerable proportion of

the document’s size.

NamePack collects the tag names from the node

container M and stores each unique name in a new

container. Occurrences of the names in the document

are then replaced with a name reference that indicates

which container and what name from that container is

being referenced. M

′

is the new node container for D

where tag names have been replaced with the appro-

priate index into the tag name container I.

<env:Envelope

xmlns:env="http://www.w3.org/2003/05/soap-envelope">

<env:Header>

<n:alertcontrol

xmlns:n="http://example.org/alertcontrol">

<n:priority>1</n:priority>

<n:expires>2001-06-22T14:00:00-05:00</n:expires>

</n:alertcontrol>

</env:Header>

<env:Body>

<m:alert xmlns:m="http://example.org/alert">

<m:msg>Pick up Mary at school at 2pm</m:msg>

</m:alert>

</env:Body>

</env:Envelope>

Figure 3: Example SOAP Message

URLPack A common feature found in many Web

documents is the hyperlink reference, which directs

the application processing the document to further in-

formation or provides additional material for an end-

user to explore. Hyperlinks are described via a URL

that typically speciﬁes a protocol, a target site, and a

document reference. Figure 3 shows an example of a

SOAP message used to invoke a remote Web service.

SOAP messages make heavy usage of namespace ref-

erences, which are externally linked documents that

deﬁne the semantics of the call. The example mes-

sage contains three such references.

We have observed that many URLs contain com-

mon preﬁxes. For example, two of the URLs in

the SOAP message in Figure 3 start with the preﬁx

“http://example.org/alert” and all three have the same

“http://” protocol speciﬁer. The URLPack operator

γ is designed to eliminate repetition in a Web doc-

ument’s URLs by factoring out these common pre-

ﬁxes. URLPack uses a modiﬁed dictionary substi-

tution mechanism (Bharat et al., 1998) for encoding

URLs that is restricted to start of string preﬁxes to

maximize efﬁciency.

In general, the URLPack operator γ(M ) =

(U, M

′

) where U = {u|u ∈ extractU RLs(M)};

extractURLs encodes the document’s URLs

through the following steps:

1. Retrieve the document’s URLs from the node con-

tainer M

2. Sort the URLs into lexical order, remove duplicates

3. For each u

, replace the preﬁx shared with the ex-

panded form of u

i−1

with the count of shared char-

acters

AttributePack The AttributePack operator α is

a logical combination of the ideas found in the

NamePack and URLPack operators that is used to

compress document attributes and expose them for

faster processing. Attributes are associated with

nodes: a single node can have zero or more attributes,

each of which consists of a name and a possibly empty

value. Attribute names are frequently reused through-

out the document; certain attribute values—hyperlink

reference URLs, for instance—will also appear mul-

tiple times in a document’s attributes.

Consistent with the approach we have espoused

with the other XPack operators, AttributePack ex-

tracts attribute names and values from a docu-

ment D’s node containers M. For a document

D with node container M = {m

, . . . , m

the AttributePack operator α(M) = (X, Y, M

′

)

where X = {x| unique attribute names in M},

stored in lexical order for efﬁcient searching, and

Y = {y|y ∈ extractAttributeV alues(M )};

extractAttributeV alues operates identically to the

function extractU RLs used in the URLPack opera-

tor γ.

ContentPack The ContentPack operator χ elimi-

nates duplication of document content and organizes

WEBIST 2005 - INTERNET COMPUTING

the content to achieve better document compression.

ContentPack χ(M ) = (C, M

′

) is a reversible func-

tion mapping a document D’s node containers M to

a content list C and an updated list of node contain-

ers M

′

. The updated node containers replace each

node’s content with a reference to the appropriate en-

try in the content list for that node. Any duplicated

text nodes in the original document will receive refer-

ences to the same entry in C. It is common for ASCII-

encoded XML documents to contain many equivalent

whitespace nodes for formatting purposes to assist hu-

man readability of the document. ContentPack elim-

inates this and any other content redundancy that is

present in the document’s non-markup content.

4 EXPERIMENTAL EVALUATION

The experiments in this section are designed to test

the features of the XPack system. Due to space limi-

tations, we restrict our experimental evaluation to two

sets of experiments that are designed to provide a rep-

resentative sample of XPack’s performance character-

istics. The ﬁrst set of experiments demonstrate the

compression performance of XPack over several doc-

ument sets. The second set of experiments test the

query performance of XPack and demonstrate that it

is possible to achieve both good compression and per-

formance. The experiments show the power of the

XPack encoding system: many interesting document

operations can be completed with only a partial de-

compression of the document.

4.1 Experimental Environment

To test the XPack design experimentally, we have

implemented a prototype XPack encoder and query

processor. The prototype is implemented in Java.

All experimental results presented here were con-

ducted on a PC with an AMD Athlon XP proces-

sor at 1.4GHz with 512MB RAM running Windows

XP Professional. The experiments were run on Sun’s

Java virtual machine for Windows, version 1.4.2. The

Apache Foundation’s Xerces XML parser was used

for testing SAX and DOM document materialization

performance and the Xalan XSLT library provided

XPath query evaluation support for DOM documents.

4.1.1 Experimental Data

Random Walk. The random walk data set consists

of approximately 2000 Web pages gathered by an au-

tomated crawler. To gather the data, the crawler’s

URL frontier was seeded with a small set of start

pages. At each iteration, a URL was chosen at ran-

dom from the frontier and the corresponding docu-

ment retrieved. The document was then converted

from HTML into XML and annotated with a single

comment tag recording the originating URL of the

document and a timestamp. The document’s links

were then added to the URL frontier for possible se-

lection in the next iteration. The average size of the

documents collected after normalization to XML was

43,888 bytes with a minimum of 161 bytes, maximum

of 898,924 bytes, and standard deviation of 37,150

bytes.

Shakespeare. The Shakespeare data set is a pub-

lic domain collection of Shakespeare’s plays that

have been converted into XML. The tag set is small

and consists of such tags as LINE, SPEECH, and

SPEAKER. None of the nodes have attributes. The

data set contains 37 documents whose average size

is 213,448 bytes with a minimum of 141,345 bytes,

maximum of 288,735 bytes, and standard deviation

of 36,345 bytes.

4.2 XPack Compression

Performance

Our ﬁrst set of experiments test the aggregate perfor-

mance of the XPack compression system. The data

sets that we have selected are intended to represent a

broad cross-section of the types of XML documents

typically used by applications. The random walk data

set contains documents representative of the XHTML

format used by modern, standards compliant Web ap-

plications. An important characteristic of this data

set is the large number of attributes containing long,

somewhat similar values. In contrast, the Shakespeare

data set is characterized by a large amount of text con-

tent with no attributes and a small, terse tag set.

The documents in these experiments were con-

verted from XML to three compressed document for-

mats: gzip compressed XML, XMill, and XPack. The

XPack documents were encoded with the PagePack,

NamePack, and AttributePack redundancy elimina-

tion operators. The resulting XPack document con-

tainers, including the node containers holding the text

content of the document, were then sent through a

gzip compression ﬁlter and written to disk.

The random walk data set contains documents hav-

ing a relatively small tag dictionary consisting of

short names—each document employs a subset of the

HTML tag set. These documents contain many at-

tributes with repeated or similar values, such as hyper-

link URLs. The documents also have signiﬁcant text

content but are not dominated by it as in the Shake-

speare data set. Figure 4 demonstrates the effective-

ness of the XPack encoding system for compressing

the random walk data set. The graph shows the size

of the XMill, gzip, and XPack compressed versions of

the documents, whose original sizes appear on the x-

XPACK: A HIGH-PERFORMANCE WEB DOCUMENT ENCODING

2000

4000

6000

8000

10000

12000

1 27 34 40 46 55

Average Document Size (kilobytes)

Compressed size (bytes)

XPack

gzip

XMill

Figure 4: XPack document compression, random walk

data set.

142 179 194 209 221 250 282

Document size (kilobytes)

Compressed size (kilobytes)

XPack

gzip

XMill

Figure 5: XPack document compression, Shakespeare

data set.

axis. The documents have many repetitive attributes,

such as navigation URLs, that provide a signiﬁcant

opportunity for redundancy elimination by Attribut-

ePack, allowing XPack to achieve compression rates

up to 20% better than the other systems’ rates.

In contrast with the random walk dataset, the

Shakespeare data set is content-heavy, with the ma-

jority of the size of the documents occupied by ac-

tors’ lines. None of the documents contained node

attributes, eliminating any potential savings from At-

tributePack. The tag dictionaries are composed of a

few short names. Even in the Shakespeare data set,

with its limited redundancy, XPack achieves compres-

sion rates comparable to the other systems. Com-

pression results for the Shakespeare data set are pre-

sented in Figure 5, which demonstrates that XPack

can achieve compression rates comparable to XMill

and gzip. XPack enjoys a signiﬁcant usability advan-

tage over the systems due to its query-capable format.

4.3 Query Performance Experiments

The next experiment evaluates the XPack system’s

ability to provide query support over compressed doc-

uments by testing the performance of XPath path ex-

pression queries on XPack documents. Path queries

over XML documents using the XPath node selec-

tion language are a popular means for extracting data

from XML documents. Table 1 presents the per-

formance results obtained for two test queries over

the Shakespeare data set and compares these results

with the performance of the same queries over stan-

dard and compressed XML. The ﬁrst query, “//PER-

SONA,” selects all the nodes in the document with

the name “PERSONA” while the second selects all

SCENE nodes with a parent ACT and a root grand-

parent PLAY. For each of the three document types

used in the experiment—DOM, compressed DOM,

Table 1: XPath Evaluation Time, Shakespeare data set.

//PERSONA

Time (ms) DOM gzDOM XPack

≤ 100 0 0 15

101–200 0 0 22

201–500 0 0 0

501–600 28 8 0

601–700 9 29 0

/PLAY/ACT/SCENE

≤ 100 0 0 15

101–200 0 0 22

201–500 0 0 0

501–600 29 5 0

601–700 8 32 0

and XPack—Table 1 lists the frequencies of query ex-

ecution times obtained executing the query over each

of the 37 documents in the Shakespeare data set. Note

that these are “cold start” measurements: the time

recorded for each test is the sum of the time needed to

load the document from disk, parse it into an internal

memory representation, and execute the query.

These results indicate that XPack can support ef-

ﬁcient evaluation of path queries while simultane-

ously reducing the storage and materialization costs

for XML documents. For many types of interesting

queries, XPack’s compartmentalization and separa-

tion of document components supports faster query-

ing than the original documents: as shown in Ta-

ble 1, document queries requiring more than 500 ms

using a standard XML parsing and querying library

can be executed in less than 200 ms with XPack. Be-

cause the queries in question require only the docu-

ment structure and tag names to be satisﬁed, XPack

can service the query without reading the entire doc-

ument, which is an impossibility with XML. These

WEBIST 2005 - INTERNET COMPUTING

measurements also demonstrate XPack’s advantage

over opaque XML compression systems like gzip

and XMill, which must add document decompression

overhead to the cost of a complete parse of the docu-

ment.

5 CONCLUSION

The XPack document encoding and compression sys-

tem achieves both good compression and strong query

support for compressed documents. Redundancy

elimination allows XPack to signiﬁcantly reduce the

size of Web documents, while compartmentalization

separates the components of a document into logical

containers. XPack’s binary encoding scheme elim-

inates the expense of parsing XML text into mem-

ory objects by instead storing the document in a for-

mat that can be read directly into memory and im-

mediately operated upon. XPack’s compression per-

formance compares favorably with other widely used

XML compression systems in testing with document

sets having considerably different structural and con-

tent characteristics. XPack’s document compartmen-

talization enables efﬁcient document querying using

XPack’s aggregate document operators and the more

general XPath query mechanism, which enjoys up to a

95% performance increase over queries using a stan-

dard XPath processor and text-based XML.

REFERENCES

Altinel, M. and Franklin, M. J. (2000). Efﬁcient ﬁltering

of xml documents for selective dissemination of in-

formation. In Proceedings of the 26th International

Conference on Very Large Databases (VLDB ’00).

Bharat, K., Broder, A., Henzinger, M., Kumar, P., and

Venkatasubramanian, S. (1998). The connectivity

server: Fast access to linkage information on the web.

In Proceedings of the Seventh International World

Wide Web Conference (WWW ’98).

Bray (1998). Extensible markup language (XML) 1.0.

Technical report, W3C.

Buneman, P., Grohe, M., and Koch, C. (2003). Path queries

on compressed xml. In Proceedings of the 29th Inter-

national Conference on Very Large Databases (VLDB

’03).

Buttler, D., Liu, L., and Rocco, D. (2003). Efﬁcient process-

ing of web page sentinels using page digest. Technical

report, Georgia Institute of Technology.

Buttler, D., Rocco, D., and Liu, L. (2004). Efﬁcient web

change monitoring with page digest. 13th Annual In-

ternational World Wide Web Conference WWW2004

(poster symposium).

Cheney, J. (2001). Compressing XML with multiplexed hi-

erarchical PPM models. In Data Compression Con-

ference.

Christensen, E., Curbera, F., Meredith, G., and Weer-

awarana, S. (2001). Web services description lan-

guage (WSDL) 1.1. Technical report, W3C.

Girardot, M. and Sundaresan, N. (2000). Millau: an encod-

ing format for efﬁcient representation and exchange of

xml over the web. In Proceedings of the Ninth Inter-

national World Wide Web Conference (WWW 2000).

Liefke, H. and Suciu, D. (2000). XMill: an efﬁcient com-

pressor for XML data. In ACM International Confer-

ence on Management of Data (SIGMOD), pages 153–

164.

loup Gailly, J. and Adler, M. (2004). Gzip compression

algorithm. http://www.gzip.org/algorithm.txt.

Min, J.-K., Park, M.-J., and Chung, C.-W. (2003). Xpress:

A queriable compression for xml data. In Proceedings

of the 2003 ACM Conference on Management of Data

(SIGMOD ’03).

Mitra, N. (2003). Soap version 1.2 part 0: Primer. Technical

report, World Wide Web Consortium.

Rocco, D., Buttler, D., and Liu, L. (2003). Page digest for

large-scale web services. In Proceedings of the IEEE

Conference on Electronic Commerce.

Savourel, Y. (2001). XML Internationalization and Local-

ization. SAMS.

Sayood, K. (2000). Introduction to Data Compression.

Morgan Kaufmann, New York, second edition.

Tolani, P. and Haritsa, J. R. (2002). XGRIND: A query-

friendly XML compressor. In ICDE.

Witten, I. H., Moffat, A., and Bell, T. C. (1999). Manag-

ing Gigabytes: Compressing and Indexing Documents

and Images. Morgan Kaufmann, New York, second

edition.

World Wide Web Consortium (1999). WAP binary XML

content format.

Ziv, J. and Lempel, A. (1977). A universal algorithm for

sequential data compression. IEEE Transactions on

Information Theory, 23(65):337–343.

XPACK: A HIGH-PERFORMANCE WEB DOCUMENT ENCODING
