A COSMIC-FFP APPROACH TO ESTIMATE WEB

APPLICATION DEVELOPMENT EFFORT

Gennaro Costagliola, Sergio Di Martino, Filomena Ferrucci, Carmine Gravino, Genoveffa Tortora,

Giuliana Vitiello

Dipartimento di Matematica e Informatica, Università di Salerno, Via Ponte Don Melillo, 84084 Fisciano (SA), Italy

Keywords: Web applications, size metrics, effort prediction models, empirical validation

Abstract: Web applications are constantly increasing both in complexity and number of offered features. In this paper

we address the problem of estimating the effort required to develop dynamic web applications, which

represents an emerging issue in the field of web engineering. In particular, we formalize a method which is

based on the main ideas underlying COSMIC-FFP (Cosmic Full Function Point), which is an adaptation of

the Function Point method, especially devised to tackle real-time and embedded applications. The method is

focused on counting data movements and turns out to be suitable for capturing the specific aspects of

dynamic web applications which are characterized by data movements to and from web servers. The method

can be applied to analysis and design documentation in order to provide an early estimation. We also

describe the empirical analysis carried out to verify the usefulness of the method for predicting web

application development effort.

1 INTRODUCTION

In the last years, the introduction of novel

technologies and standards for the web has led to a

deep change in the scenario of traditional

information systems. Indeed, the availability of both

bandwidth for Intranet/Extranet, and new web

solutions (EJB, .NET, SOAP, etc…), allowed

developers to create “web applications”, i.e.

applications able to run in a web browser. Among

major advantages of this approach, it permits to

deploy applications without caring of the client

platform, it fully exploits the MVC architecture, and

it allows different applications to easily interoperate,

by using standard communication protocols and

languages, such as XML.

However, the sudden availability of such many

solutions has created a gap between traditional

software engineering and development approaches.

The discipline of web engineering is quickly

bridging such a gap, but however a lot of research is

still needed. In particular, currently in the literature

there are very few works addressing the problem of

estimating the effort required to develop dynamic

web applications.

This represents an emerging issue in the field of web

engineering, due to the dramatic increasing of

complexity and size of dynamic web applications,

such as e-commerce or back-office platforms, and

the consequent demand for tools supporting project

development planning with reliable cost and effort

estimations (Baresi et al., 2003), (Despande, 2002),

(Mendes et al., 2002) (Rollo, 2000) (Reifer, 2000,

2002. In the context of traditional software systems,

Function Points (FP) have achieved a wide

acceptance to estimate the size of business systems

and to indirectly predict the effort, cost and duration

of their projects (Albrecht, 1979). However, it is

widely recognized that such method is no longer

adequate for web-based systems, since it is not able

to capture the specific features affecting the size and

the effort required for those systems, namely scripts,

applets, multimedia components, etc. (Morisio et al.,

1999), (Ruhe et al., 2003), and there is an inherent

difficult to apply the method (Rollo, 2000).

Nevertheless, the appealing features of the FP

approach have motivated recent proposals of

adaptation/extension of the method, meant to exploit

its main ideas in order to predict the size of web

applications. In particular, Web Objects represent an

extension of FP, especially conceived for web

systems (Reifer, 2000), (Ruhe et al., 2003), which is

Costagliola G., Di Martino S., Ferrucci F., Gravino C., Tortora G. and Vitiello G. (2005).

A COSMIC-FFP APPROACH TO ESTIMATE WEB APPLICATION DEVELOPMENT EFFORT.

In Proceedings of the First International Conference on Web Information Systems and Technologies, pages 80-87

DOI: 10.5220/0001234100800087

 SciTePress

Functional Users

Requirements

Functional

Process Type

Sub-Process Type

Data Movement

Type

Data Manipulation

Type

Software

(a) (b)

Figure 1: Generic flow of data attributes from functional perspective (a), and generic software model for measuring the

functional size (b) (COSMIC-FFP, 2003)

characterized by the introduction of four new web-

related components (multimedia files, web building

blocks, scripts and links) added to the five traditional

function types of FP. A different solution was

outlined by Rollo, who employed COSMIC-FFP, an

adaptation of FP originally defined for real-time

applications, to measure functional size of an

Internet bank system (Rollo, 2000).

Following his suggestion, in (Mendes et al., 2002)

the authors provide a formal method which adopts

COSMIC-FFP to measure size of static hypermedia

web applications. In the paper we propose to apply

the COSMIC-FFP method to estimate the functional

size of dynamic web applications. Since COSMIC-

FFP measure is focused on the counting of data

movements, it turns out to be particularly suitable

for client-server applications, which are

characterized by large amounts of data movements.

To provide an early size estimation, we propose to

apply the method on analysis and design documents.

In particular, to count the data movements from the

analysis documents we suggest to exploit the

approach provided by Jenner to estimate the

functional size of object oriented systems (Jenner,

2002). The approach considers sequence diagrams

describing use cases and provides a set of rules for

automating the counting of data movements.

Moreover, to count data movements from design

documents, we extend the proposal by Mendes et al.,

by defining a set of rules that allow us to measure

functional size of dynamic applications, using class

diagrams.

In the paper we also report on an initial empirical

validation of the approach, based on an Ordinary

Least-Squares (OLS) regression analysis performed

on a set of dynamic applications developed by

undergraduate students of two academic courses on

web engineering.

The rest of paper is organized as follows. In Section

2 we recall the main concepts of the COSMIC-FFP

method. In Section 3 we describe the rules to apply

COSMIC-FFP counting on sequence diagrams and

on class diagrams, respectively. Section 4 presents

the results of the empirical analysis carried out so

far. Section 5 concludes the paper giving some final

remarks and discussion on future work.

2 THE COSMIC-FFP APPROACH

The COSMIC-FFP approach involves to apply a set

of models, rules and procedures to Functional User

Requirements to obtain a numerical value which

represents the functional size of the software,

expressed in terms of CFSU (cosmic functional size

unit) (COSMIC-FFP, 2003). In order to apply the

method, two models are identified: the context

model and the software model.

The context model is used to clearly break up the

software parts that should be sized from the software

parts composing the operating environment (see Fig.

1.a). This is achieved by identifying boundaries and

illustrating the generic functional flow of data

attributes from a functional perspective. In

particular, the flow of data attributes is

characterized by two directions, back-end and front-

end, and by four distinct types of movements:

entries and exits, representing exchange of data with

user, and reads and writes, representing exchange of

data with the persistent storage hardware.

The software model is used to identify the goals of

software modules. It assumes that two general

principles hold for the software to be mapped and

measured: 1) software takes input and produces

useful output to users, and 2) software manipulates

pieces of information designated as data groups

which consist of data attributes. Then, such software

model allows us to consider the functional user

requirements decomposed in a set of functional

processes, where each process is a unique set of sub-

processes performing either a data movement or a

data manipulation (see Fig. 1.b).

The data movement sub-processes entry, exit, read,

write, which move data contained in exactly one

data group, are considered. The COSMIC-FPP

approach, then states that functional size of software

A COSMIC-FFP APPROACH TO ESTIMATE WEB APPLICATION DEVELOPMENT EFFORT

is directly proportional to the number of its data

movement sub-processes. Such an assumption is

justified by the nature of the software the method

was initially targeted at, namely real time

applications, which are characterized by several

movements of data.

3 APPLYING COSMIC-FFP TO

WEB APPLICATIONS

Dynamic web applications are generally

characterized by a significant amount of interactions

with users and data sources/sinks, such as databases,

or web services. Usually these interactions are

relatively easy to develop. To clarify, the

representative task encompasses the delivering of

information to the user (i.e. a shopping cart or a

confirmation of a transaction). Such information is

gained by some straightforward SQL DML

instruction executed on a (eventually remote)

database, and does not require complex

computations. This archetype holds for the most of

web application domains, such as e-commerce, e-

learning or news portal. As a result of such

considerations, dynamic web applications can be

suitably sized by counting data movements. It is

worth to pointing out that the counting of data

movements is the underlying principle of the

COSMIC-FFP method, which turns out to be very

suited to estimate functional size of a dynamic web

application, as suggested by Rollo (2000).

In this paper we propose to apply the COSMIC-FFP

method in the early phases of the development

process by exploiting analysis and design

documents, such as use cases and class diagrams. In

order to count data movements from analysis

documents, we use the adaptation of COSMIC-FFP

method for object oriented applications provided in

(Jenner, 2002), since it can be easily adopted in any

development process which utilizes UML use case

and sequence diagrams during requirement analysis.

The preliminary size estimation obtained from

analysis documents can be later refined by counting

the data movements in the design phase, when more

information is available. To this aim, we extend the

proposal by Rollo (2000) and Mendes et al. (2002),

by defining a set of rules that allow us to measure

the functional size of dynamic applications, using

class diagrams.

In particular, we suitably revised the context model

and the software model to deal with dynamic web

applications. The flow of data attributes gives rise to

the context model illustrated in Fig. 2.a.

(a)

Functional Users

Requirements

Software

Use CaseUse Case Class

Diagram

Class

Diagram

Functional

Process Type

Functional

Process Type

Sub-Process

Type

Sub-Process

Type

(b)

Figure 2: The functional flow of data attributes through

web applications (a) and a generic software model to

measure functional size of web applications (b)

Web applications, which executes on a web server,

are bounded in the back-end direction by Data

Sources/Sinks, and in the front-end direction by the

network and users:

• Data Sources/Sinks component encompasses all

the modules, objects or hardware suited to

provide or gain data from the web application,

such as a Web Service, a local file system or a

Database.

• Front end includes the Internet/Intranet network

useful to deliver to the users the services and/or

information managed by the web application.

Fig. 2.b depicts the generic software model, where

the data movement sub-processes are identified by

analyzing use cases and class diagrams obtained

from functional user requirements.

In Section 3.1 we consider analysis documentation

and describe the approach of Jenner (2002) to count

data movements, and in Section 3.2 we provide

counting rules to count data movements from design

artefacts.

3.1 Identifying Data Movements from

Analysis Documents

In the last years several proposals have been made

meant to apply the COSMIC-FFP method in order to

estimate the functional size of object oriented

applications (Bévo et al., 1999), (Diab et al., 2002),

(Jenner, 2002), (Poels, 2003). For our purpose,

special interest deserves Jenner’s approach, which

WEBIST 2005 - INTERNET COMPUTING

provides suitable rules to be applied on use case and,

more specifically, on the corresponding sequence

diagrams. Sequence diagrams turn out to be

especially useful for capturing the features of

dynamic web applications, highlighting the

interaction between different components.

Let us consider the use case FinalTest depicted in

Fig. 3, which is referred to a web application

designed for e-learning purposes, and the

corresponding sequence diagram shown in Fig 4.

Use Case Final Test

ID: Final Test

Actors: User

Entry condition: The user requests the final test by

registering his/her data, and the system checks the data

Flow of events:

The system prepares the final test.

The user compiles the test (by answering the multiple-

choice questions), then the system evaluates it and sends

the results back to the user.

The system stores the score and the user data into the

database.

Exit condition: the user receives the test results.

Figure 3: The use case modelling the Final test within an

e-learning course

: User : TestRequest : TestCreation : HTMLTest : Scoring : Sco re : DB

1:select()

2:request()

3:ConstructHT MLTest()

4:FillTest()

5:ToScore()

6:ConstructHTMLScore()

7:Display()

8:SaveScore()

The User

requests the the

final test

The system prepares the

test

The user submits the test

The system determines

the score

T h e system saves

the score

Figure 4: The sequence diagram for use case FinalTest of

Fig. 3

According to (Jenner, 2002), the boundary between

the user and the system is represented by the

interface objects (e.g., TestRequest in Fig. 4). Thus,

the following rules can be applied:

1. Each arrow from the actor to an interface object

corresponds to an entry, while each arrow from

an interface object to the actor corresponds to an

exit. For example, in Fig. 4 the arrow from User

to TestRequest determines an entry, and the

arrow from HTMLTest to User determines 1 exit.

2. Arrows not involving actors are used to

determine reads or writes. For instance, in Fig. 4

the arrow from TestCreation to HTMLTest

determines a read, and the arrow from SaveScore

to DB determines a write.

Let us observe that arrows from right to left between

intermediary objects representing return of data on a

read are not counted as further data movements,

since they are already considered in the

corresponding data request. The sum of data

movements is expressed in terms of CFSU. Thus,

the number of CFSU obtained from the sequence

diagram illustrated in Fig. 6 is 8 (2 entries, 1 exit, 4

reads, 1 write).

3.2 Identifying Data Movements from

Design Documents

In order to estimate the functional size of dynamic

web application on design documents, we have

considered class diagrams, expressed in terms of the

UML notation for the web proposed in (Conallen,

1999). It exploits stereotypes, tagged values and

constraints to suitably denote components that are

specific to web applications such as sever pages,

client pages, forms, client scripts, etc.

The counting of the data movement sub-processes

(entry, exit, read and write) has been obtained by

defining the following rules. In rules 2, 4, and 7, we

have a count that has been adjusted with a weight C

associated to the component and determined by

considering its influence on the development

process. In particular, C=1, means little influence;

C=2, means medium influence; C=3, means strong

influence. Thus:

1. For each client web page count 3CFSU, where 3

derives from 1 entry, 1 read and 1 exit. Indeed,

an entry is sent to the application by requesting

the client page (entry), the page is read from the

web server (read) and then shown to the user

(exit).

2. For each multimedia component, visualized after

an explicit request of the client, count C*3CFSU

where the number 3 has been determined by 1

entry, 1 read, and 1 exit. In other words, the

media is considered as another web page

downloaded from the server when it is requested.

3. For each script used to provide a functionality to

manipulate document on the client side, count 1

entry.

4. For each application executed on the client side,

count C*2CFSU where the number 2 has been

obtained as sum of 1 entry and 1 exit. The entry

is considered to run it and the exit to show it.

5. For each server side interpreted script or

compiled module used to produce a dynamic

web page, count 3CFSU, where 3 derives from 1

entry, 1 read, and 1 exit. In this case, a form

allows users to input data and request a dynamic

page (entry). The web server elaborates the input

of the user through the server-side script or

module (read) and produces a web page which is

sent to the user (exit). Moreover, count an

A COSMIC-FFP APPROACH TO ESTIMATE WEB APPLICATION DEVELOPMENT EFFORT

additional read if an access control is first

performed.

6. For each server side script modifying persistent

data through the web server, count 3CFSU

where the number 3 has been determined by 1

entry, 1 write and 1 exit. The user inputs data

through a form (entry), the data is written

through the web server (write) and the result is

shown to the user (exit). Count an additional

read if an access control is first performed.

7. For each reference to external applications

deployed on other servers, such as a Web

Service, a library routine, or an Enterprise Java

Bean, count C*3CFSU, where the number 3 has

been determined by 1 entry, 1 read, and 1 exit. If

the reference requires parameter passing, count

C*4CFSU, where 4 derives from 1 entry, 1 read,

1 write and 1 exit).

Let us note that rules 5, 6, 7 were specifically

conceived to consider dynamic aspects of web

applications, rule 2 refers to multimedia components

and rules 1, 3, 4 take into account elements common

to static web applications. In particular, the latter

rules are analogous to the ones provided by Mendes

et al. in (Mendes et al., 2002) to measure

hypermedia web applications. The sum of the

identified data movements is expressed in terms of

CFSU.

Application of the rules: an example

Now, in order to show the application of the above

rules, let us consider two class diagrams, referring

again to the web application designed for e-learning

purposes. The former is depicted in Fig. 5 and

models the activities for presenting learning objects

in a distance course. The latter, illustrated in Fig. 6,

is concerned with the final test whose use case

description was given in the previous subsection.

As shown in Fig. 5, from the client page HomePage,

9 client pages can be accessed, namely Intro,

Servlet, SessionCookie, JSP, JSPElements, Forms,

DataStoring, Overview and Summary. Each of those

web pages contains a request for a media which is

specified by the stereotype <<media>>. Moreover,

HomePage contains a client script.

By applying rule 1 we obtain 30 CFSUs due to the

presence of 10 client pages. The presence of a client

script in the HomePage determines the application

of rule 3, and then one more CFSU. Finally, the

application of rule 2 determines further 81 CFSUs,

since 9 media are requested by the client pages,

with an estimated weight C=3. Thus, for this class

diagram we have a total of 112 CFSUs.

Now, let us analyze the class diagram modelling the

final test activities for the given learning object (see

Fig. 6). The description of the corresponding use

case (see Fig. 4) can further support us in the

comprehension of the diagram and in the

identification of data movements.

Menu(){ }

MServlet

<<media>>

MSession

<<media>>

MJSP

<<media>>

MOverview

<<media>>

MSum mary

<<media>>

MFor ms

<<media>>

MIntro

<<media>>

MJSPElem ents

<<media>>

MDataStori ng

<<media>>

Servlet

SessionCookie JSP

Summary

DataStoring

FormsJSPElem ents

Overview

Intro

HomePage

<<Link>>

Figure 5: The UML class diagram modelling the activities

for an e-learning course

Session

LastName

Firs tName

STUDENT

LastName

FirstName

Score

InsertScore()

DeleteScore()

TestCreation

UserIdentification

<<Redirect>>

Score

TestForm

<<Build>>

DBUpdating

TEST

LastName

FirstName

LoadTest()

Create_html()

ScoreCalc()

Scoring

<<Build>>

<<Redirect>>

FinalTest

UserRegistration

<<Submit>>

Figure 6: The UML class diagram modelling the final test

The user requests the final test by specifying his/her

data through the HTML form UserRegistration

contained in the client page FinalTest. The server

page UserIdentification verifies whether or not the

user is registered and the server page TestCreation

prepares the form TestForm by using the

information of the class Test. The user fills in the

form by answering the questions and submits his/her

test. Then, the server page Scoring interacts with the

database and determines the score which is sent back

to the user as an HTML page (i.e., Score).

Moreover, the server page DBUpdating inserts the

WEBIST 2005 - INTERNET COMPUTING

score into the database by using the user data

contained in the object Session. The presence of the

three server pages UserIdentification, TestCreation,

Scoring determines three applications of rule 5,

resulting in 9 CFSUs. Rule 6 is instead applied

considering the server page DBUpdating,

determining other 3 CFSUs. Finally, the presence of

the static web page FinalTest which contains the

HTML form UserRegistration, causes the

application of rule 1, counting further 3 CFSUs.

Thus, the total counting for the considered piece of

design documentation is 15 CFSUs.

4 EMPIRICAL EVALUATION

A statistical analysis has been performed to establish

whether the proposed applications of COSMIC-FFP

can be used to predict the development effort of web

based systems, in terms of person-hours. We have

exploited data coming from 32 web projects

developed by students during the course on Web

Engineering of two subsequent academic years. In

both cases, the most skillful students were equally

distributed among the groups in order to allow

uniformity. Each group was asked to implement a

client-server hypermedia application and to record

information on the actual effort required for the

development process in terms of person-hours.

Data of the 32 projects have been collected from the

analysis and design documentations. A descriptive

statistics has been performed both for the variable

Effort (denoted by EFH), expressed in terms of

person-hours, and the variable COSMIC-FFP

(denoted by C-FFPan when it is calculated from the

analysis documents and by C-FFPde from the design

documents), expressed in terms of CFSUs, related to

the 32 systems used. The summary statistics of those

variables are given in Table 1.

In order to perform the empirical validation of the

proposed methods, we have applied an Ordinary

Least-Squares regression analysis. Figures. 7.a and

7.b illustrate the scatter plots obtained by considering

EFH as dependent variable and C-FFPan and C-

FFPde, respectively, as independent variables. For

either measures, the scatter plot shows a positive

linear relationship between the variables involved.

This suggests that a linear regression analysis of

EFH and C-FFPan (EFH and C-FFPde, resp.) can

be performed. The linear regression analysis allows

us to determine the equation of a line, which

interpolates data and can be used to predict the

development effort in terms of the number of person-

hours required.

Table 1: Descriptive statistics of EFH, and size expressed

in C-FFPan and in C-FFPde

Obs MIN MAX MEAN STD.

DEV.

EFH 32 62 172 117.625 33.700

C-FFPan

32 47 509 175.594 107.975

C-FFPde

32 82 833 352.625 222.640

When applying the OLS regression, several crucial

indicators have been taken into account to evaluate

the quality of the prediction. In particular, the

goodness of fit of a regression model is determined

by the square of the linear correlation coefficient, R

Moreover, the F value and the corresponding p-

value (denoted by Signif F) are useful indicators of

the degree of confidence of the prediction.

Specifically, a high F value, together with a low p-

value indicate that the prediction is indeed possible

with a high degree of confidence.

C-FFPan

60050040030 02001000

EFH

180

160

140

120

100

(a)

C-FFPde

10008006004002000

EFH

180

160

140

120

100

(b)

Figure 7: The scatter plots for (a) EFH and C-FFPan, and

(b) EFH and C-FFPde

Moreover, for each model, we have considered the

p-values and t-values for the corresponding

coefficient and the intercept. The p-values give an

insight into the accuracy of the coefficient and the

intercept, whereas their t-values allow us to evaluate

their importance for the generated model. In

particular, a significance threshold of 0.05 for the p-

value is commonly used to establish whether a

variable is a significant predictor. In other words,

when it is less than 0.05, the variable is significant

with a confidence of 5%. As for the t-value, a

variable is significant if the corresponding t-value is

greater than 1.5. Moreover, it is useful to evaluate

the confidence interval. We can observe that the

linear regression analysis shows a high R

value for

A COSMIC-FFP APPROACH TO ESTIMATE WEB APPLICATION DEVELOPMENT EFFORT

C-FFPde, while a lower R

value for C-FFPan. For

C-FFPde we have R

=0,776, which indicates that

77.6% is the amount of the variance of the

dependent variable EFH that is explained by the

model related to C-FFPde, whereas for C-FFPan we

have R

= 0.523 indicating that 52,3% is the amount

that is explained by the model related to C-FFPan.

In Fig. 8.a we can observe a high F value and a low

p-value, for both measures, which indicate that the

prediction is indeed possible with a high degree of

confidence. We have also considered the p-values

and t-values for the corresponding coefficient and

the intercept (see Fig. 8.b).

The equation of the regression model for C-FFPde

obtained with this data set is:

EFH = 0.133*C-FFPde + 70.647,

where the coefficient 0.133 and the intercept 70.647

are significant at level 0.000, as from the T test. The

equation of the regression model for C-FFPan is

instead:

EFH = 0.225*C-FFPan + 78.034,

where the coefficient 0,225 and the intercept 78.034

are again significant at level 0.000.

In order to assess the acceptability of the derived

effort prediction models, we have considered the

Magnitude of Relative Error, which is defined as

MRE = |EFH

real

— EFH

pred

| / EFH

real

where EFH

real

and EFH

pred

are the actual and the

predicted efforts, respectively. The rationale behind

this measure is that the gravity of the absolute error

is proportional to the size of the observations. Such

value has been calculated for each of the 32

observations in the data set, using the models

derived for both C-FFPan and C-FFPde. We have

evaluated the prediction accuracy by taking into

account a summary measure, given by the Mean of

MRE (MMRE), to measure the aggregation of MRE

over the 32 observations. In particular, from Table 2,

we can observe that both models exhibit an MMRE

value less than 0.25. As suggested in (Conte et al.,

1986), this represents an acceptable threshold for an

effort prediction model. Moreover, we have

considered another meaningful measure, namely the

prediction at level l, defined as

PRED (l)= k /N

where k is the number of observations whose MRE is

less than or equal to l, and N is the total number of

observations. Again, according to Conte et al., at

least 75% of the predicted values should fall within

25% of their actual values. In other words, a good

effort prediction model should have PRED(0.25) ≥

0.75. This condition turns out to be satisfied by the

model derived for C-FFPde, i.e. based on design

documentation. On the contrary, the model derived

for C-FFPan indicates a lower accuracy in the

prediction. Such results are consistent with the fact

that analysis documents contain less information on

the projects, with respect to design documents.

5 FINAL REMARKS

In this paper we have proposed an approach for

estimating the functional size of dynamic web

applications, exploiting the COSMIC-FFP method,

both during analysis and design phases. Indeed, the

measure turns out to be suitable for capturing also

the dynamic aspects of such applications which are

characterized by data movements to and from web

servers. and defining appropriate procedures to

measure the functional size of software by counting

the data movements. Two sets of rules have been

provided to be applied on analysis and design

documents, respectively. In particular, sequence

diagrams are analysed by exploiting the COSMIC-

FFP rules which Jenner suggested to estimate the

size of object oriented systems (Jenner, 2002).

Conallen’s web extensions of UML class diagrams

are instead examined by applying a set of rules

which have been specifically conceived for dynamic

web applications and represent an extension of the

rules proposed by Mendes et al. for static web

applications (Mendes et al., 2002).

Prediction Model R

R Std Err F Signif F

C-FFPan EFH= 0.225*C-FFPan + 78.034 0.723 0.523 23.643 32.869 0.000

C-FFPde EFH=0.133*C-FFPde + 70.647 0.881 0.776 16.1969 103.962 0.000

(a)

Value Std. Err t-value p-value

Coefficient 0,225 8.072 5.733 0.000 Model for C-FFPan

Intercept 78.034 0.039 9.667 0.000

Coefficient 0.133 0.013 10.196 0.000 Model for C-FFPde

Intercept 70.647 5.425 13.023 0.000

(b)

Figure 8: The results of the OLS regression analysis for evaluating the EFH using C-FFPan and C-FFPde

WEBIST 2005 - INTERNET COMPUTING

Table 2: Aggregate accuracy evaluation for

C-FFPan and C-FFPde

MMRE PRED(0.25)

C-FFPan

0.18 0.72

C-FFPde

0.11 0.81

A formalization of the method has been provided by

suitably revising some basic concepts of the method,

The results of the initial empirical analysis that we

have carried out are encouraging, suggesting that the

counting of data movements can be useful for

estimating the development effort of dynamic web

applications. In particular, the application of the

method on design documents exhibits a slightly

better performance than its application to analysis

documents. This is not surprising, since during

analysis less details are usually available. For that

reason, we suggest to apply the method at the

beginning of the development process, during the

analysis phase, in order to obtain a preliminary effort

estimation, which can be later refined during design,

when further information is available, by employing

the suitable rules defined for class diagrams.

Several research directions can be planned as future

work. First of all, further analysis is needed for the

assessment of the method. Indeed, the empirical

evaluation provided in the paper has to be

considered a preliminary analysis, useful for

encouraging us in further investigation. More data

coming from the industrial world are presently being

collected, in order to obtain more reliable results.

Such data will be also used to perform a comparative

analysis with respect to other proposals, such as Web

Objects (Reifer, 2000).

Moreover, we plan to consider possible use of

adjustment factors similar to those used in the FP

approach, in order to verify their usefulness to

improve the performance of the proposed method in

the cost estimation process.

Furthermore, we focused our attention mainly on

web applications, where multimedia aspects were

marginal. It could be very interesting to tune up the

3rd rule, to better describe the efforts needed for

multimedia productions. As an example, we could

classify the digitalized media (easy to make) from

the ones created from scratch (requiring more

resources). The final result could be a taxonomy of

multimedia objects, depicting for each media the

estimated effort.

Another interesting extension of the work may come

by taking into account page templates. The sites we

considered were characterized by many structurally

different pages. Probably, if a site is composed by a

number of static pages using the same template, the

1st rule may require some tuning.

REFERENCES

Albrecht, A.J., 1979. Measuring Application Development

Productivity. In Proc. of the Joint SHARE/GUIDE/IBM

Application Development Symposium, pp. 83-92.

Baresi, L., Morasca, S., Paolini, P., 2003. Estimating the

Design Effort of Web Applications. In Proc. of the 9th

International Software Metrics Symposium, pp. 62-72.

Bévo V., Lévesque, G., Abran A., 1999. Application de la

Mèthode FFP à partir d'une spécification selon la

notation UML: compte rendu des premiers essais

d'application et questions, International Workshop on

Software Measurement (IWSM99).

Conallen, J., 1999. Building Web Applications with UML,

Addison-Wesley Object Technology Series.

Conte, D., Dunsmore, H.E., Shen, V.Y., 1986. Software

engineering metrics and models, The

Benjamin/Cummings Publishing Company, Inc.

COSMIC: COSMIC-FFP Measurement manual, version

2.2, http://www.cosmicon.com, 2003.

Deshpande, Y., 2002. Consolidating Web Engineering as a

Discipline. Software Engineering Australia, pp. 31–34.

Diab, H., Koukane, F., Frappier, M., and St-Denis, R.,

2002. McRose: Functional Size Measurement of

Rational Rose RealTime”, In Proc. of Sixth

International Workshop Quantitative Approaches in

OO Software Engineering, pp. 15-24.

Jenner, M.S., 2002. Automation of Counting of Functional

Size Using COSMIC-FFP in UML. In Proc. 12th

International Workshop Software Measurement, pp.

43-51.

Mendes, E., Mosley, N., Counsell, S., 2002. Comparison

of Web Size Measures for Predicting Web Design and

Authoring Effort”, IEE Proceedings-Software 149 (3),

pp. 86-92.

Morisio, M., Stamelos, I., Spahos V., and Romano, D.,

1999. Measuring Functionality and Productivity in

Web-based applications: a Case Study. In Proc. of the

6th International Software Metrics Symposium, pp.

111-118.

Poels, G., 2003. Definition and Validation of a COSMIC-

FFP Functional Size Measure for Object-Oriented

Systems. In Proc. International Workshop Quantitative

Approaches in OO Software Engineering.

Rollo, T., 2000. Sizing E-Commerce. In Proc of the

ACOSM 2000 - Australian Conference on Software

Measurement.

Reifer, D., 2000. Web-Development: Estimating Quick-

Time-to-Market Software. IEEE software, 17(8), pp.

57-64.

Ruhe, M., Jeffery, R., and Wieczorek, I., 2003. Using Web

Objects for Estimating Software Development Effort

for Web Applications. In Proc. of the IEEE Software

Metrics Symposium.

A COSMIC-FFP APPROACH TO ESTIMATE WEB APPLICATION DEVELOPMENT EFFORT
