AUTOMATIC IDENTIFICATION OF SPECIFIC WEB

DOCUMENTS BY USING CENTROID TECHNIQUE

Udomsit Sukakanya, Kriengkrai Porkaew

School of Information Technology, King Mongkut's University of Technology Thonburi, Thungkru, Bangkok, Thailand

Keywords: Search, Web Mining, Centroid, Identification, Classification

Abstract: In order to reduce time to find specific information from high volume of information on the Web, this paper

proposes the implementation of an automatic identification of specific Web documents by using centroid

technique. The Initial training sets in this experiment are 4113 Thai e-Commerce Web documents. After

training process, the system gets a Centroid e-Commerce vector. In order to evaluate the system, six test sets

were taken under consideration. In each test set has 100 Web pages both known e-Commerce and non e-

Commerce Web pages. The average system performance is about 90 %.

1 INTRODUCTION

Nowadays, the World Wide Web is the largest

source of information available almost freely to the

world. People throughout the world contribute

information seen here. This makes it diverse,

dynamic and ever changing. Most Internet users find

the information on the web by using search engines.

However, most search engines are based on the same

query-list paradigm. The user types a list of words or

keywords, and the system returns a ranked list of

documents, which matches that query. This

approach is acceptable since the user can refine his

query to narrow the search space; however it is

proven that most Internet users use short, generic

queries of 1-3 words (Bharat and Henzinger, 1998),

which usually produce millions of matching

documents in the result list. Usually, users give up

their search completely if they don’t get a good

result after a few tries of refining their queries.

Designers of search engines have been struggling

with this problem for years with better or worse

results.

In Thailand, the latest status of Thai Web

documents, based on databases crawling on June

2003

(Surasak and Kasom,2003) is summarized by

NontriSpider. They focus on web servers whose

names must be registered only under “.th” and they

found that there are 3,589,961 HTML documents on

26,826 Web servers (all servers are categorized into

7 major domains: .ac.th, .co.th, .go.th, .in.th, .mi.th,

.net.th and .or.th). In fact, the actual number of pages

and servers should be bigger than this because there

are still many web servers behind firewalls which

are not intended for public access and some servers

(.com, .org, .net, etc.). From the large size of Web

documents in Thailand, it is difficult to identify

specific Web documents manually. This paper tries

to fill the gaps mentioned above by using the

suitable algorithms to implement and evaluate an

automatic identification system working for Thai

specific Web documents.

The remainder of this paper is organized as

follows. Section 2 provides literature review.

Section 3 provides the proposed system. Section 4

provides the details in experiments and system

performance evaluation. Finally, Section 5 provides

the conclusion and future work.

2 LITERATURE REVIEW

Numerous methods for improving the quality of the

ranked list presentation have been proposed from

simple filtering techniques to complex algorithms

employing Artificial Intelligence techniques.

However, due to the rapidly growing and unstable

characteristic of the Web, such directories very often

point to outdated, even not existing documents. Data

classification, one of the search techniques, is the

process which finds the common properties among a

set of objects and classifies them into different

classes. The objective of classification is to analyze

333

Sukakanya U. and Porkaew K. (2005).

AUTOMATIC IDENTIFICATION OF SPECIFIC WEB DOCUMENTS BY USING CENTROID TECHNIQUE.

In Proceedings of the First International Conference on Web Information Systems and Technologies, pages 333-338

DOI: 10.5220/0001234903330338

 SciTePress

settrainingindocumentsofnumbertotaltheisN

termiththecontainthatdocumentsofnumbertheisdfwhere

))

log(tf),....

log(tf),

log(tf(W

ntfidf

the input data and to develop an accurate model for

each class using the features presented in the data.

The class descriptions are used to classify future test

data for which the class labels are unknown. Web

document classification is an attempt to merge the

quality and user-friendliness of directories with the

popular ranked list presentation. By classification

the results, increasing their readability by showing

thematic groups, instead of a mixture of documents

on all possible subjects matching the query.

Web Mining is an important field that aims to

make good use of the information available on the

web and find the data that was either previously

unknown or hidden. An important step in the mining

process is information retrieval and extraction. The

retrieval and extraction methods differ in what

aspect of a document is used in extraction

information (Lan and Bing, 2003). In general there

are two schools of thought; natural language

processing techniques and techniques that use the

structure of the web. Natural language processing

techniques involve using the data of the web using

string manipulation. Structural methods build a

structure from the structure of the document itself.

The research in web mining also derives from the

research in other fields like natural language

processing, artificial intelligence and machine

learning. The techniques that are dealt in these fields

mostly deal with a subset of the web pages. Efforts

to combine the content and structure of a web page

to build a model that is suitable for mining a wide

variety of web documents are few and certainly

insufficient.

2.1 Centroid Technique

In centroid-based classification algorithm, the Web

documents are represented using the vector-space

model (Salton, 1989) (Raghavan and Wong, 1986).

In this model, each Web document is considered to

be the term-frequency vector as following equation.

(1)

A widely used refinement to this model is to

weigh each term based on its inverse document

frequency (IDF) in the Web document collection

(Salton, Wong, and Yang, 1975). The motivation

behind this weighting is that terms appearing

frequently in many Web documents have limited

discrimination power, and for this reason they need

to be de-emphasized. This is commonly done by

multiplying the frequency of each term i by

log(N/df

), This leads to the tf-idf representation of

the Web document as equation 2 .

(2)

In order to account for documents of different

lengths, the length of each Web document vector is

normalized so that it is of unit length. Given a set N

of N Web documents and their corresponding vector

representations, the centroid vector (Han and

Karypis, 2000) is described as equation 3.

(3)

Equation 3 is nothing more than the vector

obtained by averaging the weights of the various

terms presented in N Web documents. N is referred

as the supporting set for the centroid. In the vector-

space model, the similarity between two Web

documents and is commonly measured using

the cosine function, given by equation 4

(4)

The advantage of the summarization performed

by the centroid vectors is that the computational

complexity of the learning phase of this centroid-

based classifier is linear on the number of Web

documents and the number of terms in the training

set. Moreover, the amount of time required to

classify a new Web document x is at most O(km),

where k is the number of centroids and m is the

number of terms present in x .

2.2 Web Document Indexing

In order to reduce the complexity of the Web

documents and make them easier to handle, they

have to be transformed to the vectors. The vector

space model procedures can be divided in to three

steps. The first step is content extraction where

content bearing terms are extracted from each Web

page. The second step is term weighting to enhance

retrieval of Web document relevant to the user. The

last step ranks the Web document with respect to the

query according to similarity measure.

vectors two the of product-dot the denotes “·” where

W*W

W.W

)W,Wcos(

∑

∈

tfidfC

tfidf

termiththeoffrequencytheistf

vectordocumentWebisWwhere

)tf,....tf,tf(W

ntf

WEBIST 2005 - WEB INTERFACES AND APPLICATIONS

334

Web document indexing is based on term

frequency, which has both high and low frequency.

In practice, term frequency has been difficult to

implement in automatic indexing. However, the use

of a stop list which holds common words to remove

high frequency words (stop words), which makes the

indexing method language dependent. In general,

40-50% of the total numbers of words in a Web

document are removed with the help of a stop list.

Non linguistic methods for indexing have also

been implemented. Probabilistic indexing is based

on the assumption that there is some statistical

difference in the distribution of content bearing

words and stop words. Probabilistic indexing ranks

the terms according to the term frequency in the

whole collection. The stop words are modeled by a

Poisson distribution over all Web documents, as

content bearing terms cannot be modeled. The use of

Poisson model is expanded to Bernoulli model.

Recently, an automatic indexing method which uses

serial clustering of words in text has been

introduced. The value of such clustering is an

indicator if the word is content bearing.

3 THE PROPOSED SYSTEM

In order to identify any type of Web documents, a

large amount of Web pages were collected

manually. This is a difficult task since it required a

precise search over the Internet. This system will

focus on Thai e-Commerce Web documents. The

sample have to be representative, consistent and

rather large in order to form the Thai e-Commerce

Vector sufficiently. The content of each Web page is

classified to the meta-tags, to some special tags and

to disseminated plain text. Figure 1 presents the

details in the Thai e-commerce identification system.

The main processing steps in this system involve:

Training process

1. Define the Thai e-Commerce Web Document

specifications. (Table 1)

2. Set the Thai e-Commerce Web document

training set. (Section 3.1)

3. Execute English and Thai word segmentation.

(Section 3.2)

4. Create the Thai e-Commerce Vector then do

normalization (Section 2.1).

5. Find the Centroid of all vectors. (Section 2.1)

6. Remove stop words or common words then

repeat step 4 to 6

Testing process

7. Test and evaluate the system. (Section 4)

3.1 Web Document Collection

For the purpose of information identification in the

Thai e-Commerce Web documents and with a view

to facilitate the implementation of the identification

system, a more formal definition of Thai e-

Commerce is followed. It helps to decide cleary

which “Thai electronic business activities” fall into a

well-defined, quantifiable framework of Thai e-

Commerce. Thus, an implicit distinction of Thai e-

Commerce from the structures of the traditional

commerce is required, since new ways are invented

in order to measure the revolutionary elements and

methods. In an attempt to investigate and measure

the ways Thai e-Commerce has fundamentally

changed the way of transactions, a sharp criterion in

distinguishing the Thai e-Commerce pages is taken

under consideration.

Therefore, following the concepts of the

Business Media Framework (BMF) (Klose, Lechner

and Ulrike, 1999) and Thai e-Commerce properties,

a Thai e-Commerce model can be analyzed into a

series of concurrent processes, while these processes

are implemented by elementary transactions.

According to the accepted transaction cost theory,

four phases distinguish an e-Commerce transaction.

The knowledge phase, the intention phase, the

contract phase and the settlement phase. The

distinction of these four phases serves as an

analytical tool in order to identify Thai e-Commerce

pages. Table 1 presents Thai e-Commerce Web

Document Training Sets that correspond to these

phases respectively. The initial Thai e-Commerce

Web document collection in this system is 4113

Web pages. However, it must be noted that some

Web pages were categorized into more than one

type, during the first review. To avoid any potential

misidentification, these Web pages were once more

examined in order to be finally categorized into the

most appropriate type.

AUTOMATIC IDENTIFICATION OF SPECIFIC WEB DOCUMENTS BY USING CENTROID TECHNIQUE

335

Figure 1: Thai e-commerce identification system

Internet

Identification

Process

Analysis of Thai e-Commerce

Web document Process

Web Content Extraction

Process

WEBIST 2005 - WEB INTERFACES AND APPLICATIONS

336

Table 1: Web Document Training Sets

Thai e-Commerce Web Document Training Set

1. Product detail, Categories, Homepage

2. Order detail, Order form

3. Payment detail

4. Delivery detail

3.2 Word Segmentation

Extracting the content of Web document in this

system, the problem found is Thai word

segmentation. Thai writing system has some minor

similarities to English; however, it is more similar to

Chinese and Japanese scriptures due to its

possession of the same system of sequential

continuances. It is done as a sequence of continuous

symbols, without word boundaries or punctuation

marks to indicate words, phrases, or sentences.

Word building in Thai writing system is based on

phonetic rules. The smallest linguistic unit in Thai is

called a monosyllable. Most Thai words are

monosyllable. However, Some Thai words can also

be formed by combining two or more words.

SWATH algorithm (Meknavin, Charoenpornsawat,

and Kijsirikul, 1997) is used to perform Thai word

segmentation.

3.3 The Identification Threshold

This system uses a relevance threshold in the

similarity value between Web page vectors and

Centroid vector as explained in Section 2.1. This

threshold is considered to be the minimum value,

which will define Thai e-Commerce Web

documents. In other words, Web pages with score

above the threshold are considered to be Thai e-

Commerce web page, while those with lower

scoring values are not.

In the proposed work, 95% of the selected Thai

e-Commerce Web pages presented a scoring value

above 0.10. The rest of the Web documents

presented lower scores. Thus, the threshold value for

Thai e-Commerce Web documents identification in

the proposed system was set to 0.10.

4 SYSTEM PERFORMANCE

After the training process (Section 3.1 to 3.3), the

system get a Centroid vector of all Thai e-

Commerce Web document vectors. In order to

evaluate the system performance in Thai e-

Commerce Web document identification, 6 test sets

(600 Web pages- 300 known e-Commerce Web

pages and 300 non e-Commerce Web pages) were

taken under consideration.

The corresponding e-Commerce identification

performance for each test is presented in Table 2.

The average system performance for Thai e-

Commerce Web documents is about 90%.

5 CONCLUSION

This paper proposes the implementation of a system

and experiment, which identify Thai e-Commerce

Web documents. The test Web pages are considered

as vectors and are compared with Thai e-commerce

vector under the centroid algorithm for knowledge

representation. The similarity metric used for

comparing these vectors is the cosine coefficient.

The average system performance is about 90%.

Future work involves another specific Web

document types such as government, education, and

others. Moreover, Thai e-Commerce Web document

identification can be recommended in the

experiment of another algorithm such as Self

Organized Map (SOM).

AUTOMATIC IDENTIFICATION OF SPECIFIC WEB DOCUMENTS BY USING CENTROID TECHNIQUE

337

Table 2: Thai e-Commerce Web document identification performance

Thai e-Commerce Web document identification performance

e-commerce Web documents Non e-commerce Web documents

Test

Total Success

1 0 - - 100 95 95.00

2 20 18 90.00 80 78 97.50

3 40 37 92.50 60 59 98.33

4 60 53 88.33 40 40 100.00

5 80 72 90.00 20 19 95.00

6 100 92 92.00 0 - -

Average

90.57 Average

97.17

REFERENCES

Bharat, K., Henzinger, M., 1998. Improved Algorithms for

Topic Distillation in a Hyperlinked Environment. In

Proceedings of the 21st ACM SIGIR Conference on

Research and Development in Information Retrieval.

Han, E.H., Karypis, G., 2000. Centroid-Based Document

Classification: Analysis & Experimental Results,

Technical Report TR-00-017, Department of Computer

Science, University of Minnesota, Minneapolis.

Klose, M., Lechner and Ulrike., 1999. Design of Business

Media- An Integrated Model of Electronic Commerce,

Proceeding of the fifth America Conference on

Information Systems (AMCIS’99), Milwaukee, WI.

Lan, Y., Bing, L.,2003. Web Page Cleaning for Web

Mining through Feature Weighting. In Proceedings of

Eighteenth International Joint Conference on

Artificial Intelligence (IJCAI-03), Acapulco, Mexico.

Meknavin, S., Charoenpornsawat, C. and Kijsirikul, B.

1997. Feature-based Thai Word Segmentation. In

Proceedings of the Natural Language Processing

Pacific Rim Symposium (NLPRS’97), Phuket,

Thailand.

Raghavan, V.V., Wong, S.K.M.,1986. A Critical Analysis

of the Vector Space Model for Information Retrieval,

Journal of the American Society for Information

Science (JASIS).

Salton, G., 1989. Automatic Text Processing: The

Transformation, Analysis, and Retrieval of

Information by Computer. Addison-Wesley, 1989.

Salton, G., Wong, A., and Yang, C.S., 1975. A Vector

Space Model for Automatic Indexing, Communication

of the ACM.

Surasak, S., Kasom, K., 2003 Structure Properties of the

Thai WWW: The 2003 Survey, The Conference on

Internet Technology (CIT2003), Asian Institute of

Technology., Thailand.

WEBIST 2005 - WEB INTERFACES AND APPLICATIONS

338
