FLOODING ATTACK ON THE BINDING CACHE IN MOBILE

IPv6

Christian Veigner

, Chunming Rong

University of Stavanger, N-4036, Norway

Keywords: Binding Cache flooding attack, Mobile IPv6, Return Routability, ROM.

Abstract: In the next generation Internet protocol (IPv6), mobility is supported by means of Mobile IPv6 (MIPv6).

As a default part of the MIPv6 protocol, route optimization is used to route packets directly to a mobile

node’s currently used address at the mobile node’s visited subnet. Return Routability is the protocol

suggested by the IETF for managing this task. Route optimization is often carried out during handovers,

where a mobile node changes network attachment from one subnet to another. To offer seamless

handovers to the user it is important that route optimizations are carried out quickly. In this paper we will

present an attack that was discovered during design of a new and more seamless protocol than the Return

Routability. Our improved route optimization protocol for Mobile IPv6 suffers this attack; therefore we

wanted to investigate if a similar attack was feasible on the Return Routability protocol. In this paper, we

show that our new route optimization protocol offers no less security than the already standardized

Return Routability protocol in this field.

1 INTRODUCTION

Route optimization is introduced to the Mobile IPv6

(MIPv6) protocol (Johnson, 2004). However, it is

important that the new feature doesn’t result in new

vulnerabilities to the IPv6 protocol. If not properly

designed, it is believed that certain attacks on this

optimization protocol could cause serious problems

to the stability of the entire Internet. Hence, it is

most important to investigate different attacks and

their countermeasures.

Authentication of mobile nodes (MNs) is one of

the most important features of such a mobility

protocol. Initially, strong authentication was thought

to be the only solution, and IPsec was at some point

of time believed to be the best fit for this purpose.

Due to the fact that IPsec, in addition to other

protocols that relies on additional infrastructure, is

not very scalable, the strong authentication demand

evolved into a weaker authentication demand. The

lack of scalability when using IPsec, stem from the

key exchange necessity of each pair of

communicating nodes. The protocol finally

suggested by the IETF was the Return Routability

(RR) (Johnson, 2004).

__________________________________________

This work was supported by UiS 95310, Rogaland University

Fund.

As an example, RR decreases an attacker’s range

of launching a redirecting attack (Deng, 2002) from

the entire Internet, to the necessity of being on the

route between MN’s home agent (HA) and one of

MN’s corresponding nodes (CNs). The HA is a node

at MN’s home subnet that cooperates with MN when

MN is visiting a foreign subnet. Any other node

communicating with MN is referred to as a CN. The

redirecting attack is possible due to weak

authentication. However, this is a huge

improvement, reducing an attacker’s range from the

entire Internet to the HA-CN route, without the need

of any additional infrastructure.

Focusing on the main drawback of the RR

protocol, the possibility of experiencing lack of

seamless handovers, we designed a new route

optimization protocol for Mobile IPv6 (ROM)

(Veigner, 2004). This protocol intends to decrease

the latency of route optimization when actually

needed, that is, when the MN suddenly changes

subnet.

We investigate (Veigner, 2004) to which extent

the ROM protocol suffers from redirecting attacks

(Deng, 2002), bombing attacks (Aura, 2002),

amplification attacks (Aura, 2002) and flooding

attacks. Flooding attacks on route optimization

protocols in general are briefly described in

(Nikander, 2005).

Veigner C. and Rong C. (2005).

FLOODING ATTACK ON THE BINDING CACHE IN MOBILE IPv6.

In Proceedings of the Second International Conference on e-Business and Telecommunication Networks, pages 36-43

DOI: 10.5220/0001414400360043

 SciTePress

During analyses of the ROM protocol design, we

discovered that flooding attacks on a corresponding

node’s (CN’s) binding cache (BC) easily might be

carried out. A BC is a cache allocated at CN’s for

storing bindings between home and foreign

addresses of mobile nodes. A flooding attack aims to

fill such BCs with spurious entries. A CN may

thereby be unable to perform route optimization with

new MNs.

In this paper we will further describe flooding

attacks in detail, and also show to which extent such

attacks are feasible on the Return Routability (RR)

protocol as well as on our ROM protocol.

Even though the RR protocol does not store any

state at a CN before the initiating MN’s authenticity

is verified, we will show that flooding attacks on a

CN’s BC are possible.

The rest of this paper is organized as follows. In

Section 2, an introduction to route optimization and

the binding cache (BC) is given. Section 3

introduces our ROM protocol design and

exemplifies the BC flooding attack. Section 4

focuses on the RR protocol and elaborates the

possibilities of similar BC flooding attacks on the

RR protocol. Finally our paper is concluded in

Section 5.

2 ROUTE OPTIMIZATION AND

THE BINDING CACHE

The key advantage of route optimization is a

corresponding node’s (CN’s) ability to continue its

session with a MN over an optimal route, even when

the MN changes its point of attachment to the

Internet. Now the MN’s home agent (HA) does not

have to reroute all of MN’s incoming packets to

MN’s dynamically changing location. Due to route

optimization, latency of data transmissions and

bandwidth misuse may be substantially reduced.

Figure 1: Movement of a mobile node.

Figure 2: Route optimization.

A MN having an ongoing session with a CN is

shown in figure 1. If the MN moves to another

subnet (figure 1), the packets should be routed

directly from CN to MN as shown in figure 2 (route

optimization). The alternative suboptimal solution is

seen as dotted lines in figure 2. The other way

around however, sending packets directly from MN

to CN (also shown in figure 2), is a problem solved

long ago (Johnson, 2004), and will hence not be

discussed in this paper.

By means of route optimization, only the initial

packets from a CN may be routed through the MN’s

HA. This may occur if the CN has no entry of the

receiving MN in its binding cache (BC). The CN

thereby assumes that MN is situated at its home

subnet. Whenever a packet forwarded by the HA

arrives at the MN, MN initiates route optimization,

informing the CN of its current location. The

remaining packets from CN may from now on be

routed directly to MN.

We will now give a brief introduction to the

binding cache (BC) located at CNs. Mobile and

fixed nodes are not differentiated in IPv6; thereby a

packet-sending node always has to check its BC for

an entry of the receiving node before a packet is

transmitted. If an entry exists, the transmitting node

must route its packets directly to the MN’s care-of

address (CoA).

Generally, a BC contains home addresses

(HoAs) and care-of addresses (CoAs) of mobile

nodes (MNs). This is shown in figure 3. A HoA is

the address of a MN at its home subnet and a CoA is

the address currently associated with the MN at its

visited subnet. This information is contained in a

CN’s BC for each of the MNs that the CN has been

in contact with recently.

Figure 3: Binding cache.

HoA

CoA

2) Movement

1) Session

Session over

optimal route

Non-optimal route

FLOODING ATTACK ON THE BINDING CACHE IN MOBILE IPv6

Additionally, the BC will often maintain

remaining lifetime of these bindings, and maybe the

highest received sequence number associated with

each binding. The sequence numbers may be used

for replay attack prevention. Both CNs and HAs

must be able to allocate memory for a BC.

We will in this paper focus on the BC at CNs,

and elaborate the possibility of launching a BC

flooding attack, filling the BC with non-real

bindings of non-existing MNs. Since every node in

MIPv6 may become a CN to a MN, and the MIPv6

protocol is supposed to be a default part of the IPv6

protocol, every IPv6 node must able to allocate

memory resources for a BC.

Even a small handheld unit may become a CN.

Such units are normally equipped with quite limited

memory resources, and may easily become targets of

BC flooding attacks.

3 THE ROM PROTOCOL

In this section an overview of our ROM protocol is

given. The protocol is described in more depth in

(Veigner, 2004). The ROM protocol is supposed to

be an alternative to, and a more seamless protocol

than the IETF Return Routability (RR) protocol

(Johnson, 2004). Hopefully, ROM offers security

characteristics similar to the RR protocol.

A MN uses the ROM protocol to assign a unique

hash value to its currently used CN. The hash value

is sent via the HA. Simultaneously the home subnet

of MN is authenticated by the CN by means of a

three-way handshake. When moving into a new

subnet, MN now only has to send a binding update

(BU) message directly to the CN. The CN considers

the BU message authentic due to MN’s knowledge

of the nonce value. The nonce value included in the

BU message was previously used when generating

CN’s unique hash value. Routing packets over the

optimal route may now begin.

The main part of the ROM protocol messages is

shown in figure 4. These messages are sent in

advance of MN’s movement to a new subnet. The

messages shown in figure 5 are sent as the final part

of the handover procedure when MN arrives at its

new subnet.

We will now introduce the messages of our

ROM protocol. We’ll start with the messages of

figure 4. For more in depth explanation, see

(Veigner, 2004).

Figure 4: The ROM protocol.

Message 1: This message is sent by the MN to its

HA. It contains the address of a CN and a unique

hash value (h(n)). This message might of course

contain a list of CNs and unique hash values for

increased efficiency.

Message 2a: The received hash value is sent to

the CN’s address, along with MN’s identifier (HoA).

The source address of the 2a message is the address

of the HA.

Message 2b: CN returns the hash value and

includes a challenge for the HA.

Message 2c: HA returns the challenge, and once

again the hash value is sent along with MN’s HoA

address. CN may thereby remain stateless until the

MN’s home subnet is authenticated by the 2a - 2c

procedure.

Message 2d: If the HA doesn’t receive a 2b

message in reply of a 2a message, HA notifies MN

of CN’s absence. It is now in vain to proceed with

the route optimization protocol with this CN.

Figure 5: BU messages sent from MN’s new location.

2c) challenge + h(n) + HoA

2b) h(n) + challenge

1) CN’s address + h(n)

2d) Error if 2b) doesn’t arrive from CN

2a) h(n) and MN’s identifier (HoA)

3a) BU

4) BU Ac

3b) BU with HoA + n

ICETE 2005 - WIRELESS COMMUNICATION SYSTEMS AND NETWORKS

The messages of figure 5 are as follows.

Message 3a: An ordinary BU message is sent to

MN’s HA.

Message 3b: A BU message is also sent to the

CN. This message contains MN’s identifier (HoA)

and the nonce value previously used when CN’s

unique hash value was generated. The source

address of both the 3a and 3b messages is the MN’s

CoA address.

Message 4: As in the RR protocol, HA must

always return a BUAck message.

Whenever a CN receives a BU message from a

MN, the hash value used for authenticating the MN

is deleted from its cache. A new hash value must

now be assigned to the CN, otherwise CN will be

unable to authenticate MN’s next BU message, if

one is ever to arrive.

We will in the following introduce a BC flooding

attack on the ROM protocol.

3.1 BC flooding attack on the ROM

protocol

A BC flooding attack aims to flood a CN’s BC with

spurious bindings of non-existing nodes. A CN,

which may be any node in an IPv6 network, must be

able to allocate memory resources for this BC,

mapping home addresses (HoAs) to care-of

addresses (CoAs).

We will not go into all the details of our ROM

protocol design in this paper, but rather focus on the

possible binding cache (BC) flooding attack. Later

on, in Section 4.1 and Section 4.2, we will show to

which extent a similar attack may be launched on the

RR protocol.

Due to the three-way handshake of the ROM

protocol, an Eve may attack a CN from anywhere in

the entire Internet.

As shown in figure 6, we may consider an Eve

transmitting a 2a message to its victim CN. On

reception of the 2b message from the attacked node,

Eve replies with a 2c message. By repeatedly doing

this, Eve may be able to fill the BC at the attacked

CN. In this attack, Eve may simply generate random

hash (h(n)) values and HoA addresses, and insert a

new pair for each of her 2a messages. The only

requirement is that the HoA addresses must be equal

in subnet prefix to the prefix of the address used by

Eve when Eve is acting as a HA. Otherwise the CN

will not reply with a 2b message, and the attack will

not be successful (Veigner, 2004).

Figure 6: Attacking a CN’s binding cache.

Figure 7: The BC at CNs in the ROM protocol.

Even though Eve has to send twice as many

messages as the attacked node, Eve may easily carry

out her BC flooding attack.

The BC at CNs when using the ROM protocol is

shown in figure 7. For each of the MNs that carry

out route optimization with the CN, a new row is

added to the CN’s BC. Each row consists of the

following: The mapping from MN’s home address

(HoA) to its care-of address (CoA), a hash value

(h(n)), a sequence number containing highest

received sequence number from MN, and finally,

remaining lifetime of MN’s current binding.

The described BC flooding attack aims to flood

the HoA, h(n) and Lifetime columns of the BC. The

CoA and Seq# values are only added if a verifiable

BU message is received later on (Veigner, 2004).

A MN’s BC entry is deleted after 420 seconds if

not updated (Veigner, 2004). By re-initiating the

ROM protocol, a legitimate MN may update its

entry in CN’s BC. This solution was chosen for

several reasons. The first reason was the fact that

there are no known existing one-way hash functions

yet. By restricting the valid time of an entry to 420

seconds, and at the same time using a fairly secure

hash function, we obtain a one-way hash function

for the duration of the 420 seconds. No adversary is

able to divert a valid nonce value of an

eavesdropped hash value, and is thereby unable to

launch a redirecting attack (Veigner, 2004). Due to

this 420 seconds validity, a MN must during this

period send its BU message to authenticate its

current location. Otherwise, a new protocol run is

required to update the CN with a new hash value.

Another reason for including this validity period in

our protocol was to delete unused entries from a

CN’s BC. As mentioned, a CN may be any node,

even a node with limited resources allocating

memory for such a BC. Thereby, it is beneficial to

delete entries that are not in use.

As a bonus, the described BC flooding attack on

the ROM protocol suffers from the deletion of BC

HoA

h(n)

CoA

Seq#

Lifetime

Eve

2c) challenge + h(n) + HoA

2b) h(n) + challenge

2a) h(n) and HoA

FLOODING ATTACK ON THE BINDING CACHE IN MOBILE IPv6

entries. An attacker must now be very efficient, or

launch the attack in a distributed manner, to flood

the attacked BC within 420 seconds.

When the BC flooding attack on the ROM

protocol was discovered, it became in our interest to

search for a similar attack feasible on the RR

protocol. Studying (Hinden, 2003) gave us the idea

of how this could be done. The attack is introduced

in Section 4.1 and Section 4.2.

4 THE RETURN ROUTABILITY

(RR) PROTOCOL

In this section an overview of the RR protocol is

given. RR is the route optimization protocol

suggested by the IETF for authenticating a MN’s

binding update (BU) message sent to a CN.

Whenever a MN moves from one subnet to another,

it has to initiate route optimization with its CNs.

When updating its binding at a CN, MN has to send

and receive the messages of figure 8. The message

exchange with the CN is carried out subsequent to

the BU and BUAck message exchange with the HA.

In RR, the message exchange of figure 8 is carried

out when MN arrives at its new subnet.

In brief, the MN receives a key-generated token

in the HoT message and another key-generated

token in the CoT message. When a BU message is

finally sent from MN to CN, MN must use its

received tokens to make CN confident in MN’s

authenticity. MN has shown its ability to receive

tokens at its two stated addresses (HoA and CoA)

via two different routes, and is thereby authenticated

by CN (weak authentication). The data from CN

may now be routed directly to MN’s new CoA

address.

Figure 8: The Return Routability protocol.

We now introduce the RR protocol messages.

Message 1 and message 2 are left out. The so-called

home routability test and the care-of routability test

are the two parts of the RR procedure.

The home routability test consists of the HoTI

and HoT messages. The care-of routability test

consists of the CoTI and CoT messages.

HoTI = {HoA, CN, C

}

The HoTI message comprises the following. The

home address (HoA) of the MN is the source address

and the CN’s address is the destination address. A

home init cookie generated by MN is included. This

cookie is returned in the response message from CN.

MN is now able to match request with response. The

HoTI message is reverse tunnelled through MN’s

HA.

CoTI = {CoA, CN, C

}

The CoTI message consists of the following. The

care-of address (CoA) of the MN appears as the

source address. The care-of address is the address

used by MN at its foreign subnet. The destination

address of the message is the CN’s address. A care-

of init cookie generated by MN is also included.

This cookie must be returned in the response

message from CN.

HoT = {CN, HoA, C

, Token

, i}

CN generates the HoT message on reception of

the HoTI message. This message is sent from CN to

MN’s HoA address. It is the HA at MN’s home

subnet that is responsible for redirecting the HoT

message to MN when MN is away from its home

subnet. On reception of the HoT message, MN uses

the C

cookie to match request with response. MN is

now in possession of a key generated token called

home keygen token (Token

Token

= First (64, HMAC_SHA1 (K

, (HoA|

nonce

|0)))

The CN generates the home keygen token by

using the first 64 output bits from a MAC function.

Input to the MAC function is CN’s secret key (K

)

and the concatenation of MN’s HoA address, a

nonce value and a 0 octet.

The final parameter of the HoT message is the

home nonce index (i). MN must later on return this

index in its BU message. The CN may thereby

remain stateless until the BU message is received.

From a list at the CN, containing valid nonce values,

the correct nonce value is easily recovered due to

this index. The CN may then regenerate the home

3a) HoTI

3b) CoTI

4a) HoT

4b) CoT

5) BU

1) BU

2) BU-

Ack

ICETE 2005 - WIRELESS COMMUNICATION SYSTEMS AND NETWORKS

keygen token. Both the MN and CN use this token in

the generation of their shared binding management

key (K

). Another token is also needed in the

binding management key generation. This token is

sent to the MN in the CoT message.

CoT = {CN, CoA, C

, Token

, j}

CN generates a CoT message on reception of the

CoTI message. The address of CN is source and the

MN’s CoA address as destination. This message is

sent directly to MN at its current location. The

cookie from the CoTI message is included, and a

care-of keygen token (Token

) is generated quite

similar to the Token

Token

= First (64, HMAC_SHA1 (K

, (CoA|

nonce

|1)))

Finally the care-of nonce index (j) is included in

the CoT message. Later on this index is returned in

the BU message from MN. Thereby helping the

stateless CN identifying the nonce value used in the

generation of the care-of keygen token (Token

The MN is now in possession of both the keygen

tokens and may generate a binding management key

by hashing the tokens in the following way:

= SHA1 (Token

|Token

)

Finally the RR procedure is finished. The MN

may now generate and send its BU message to the

CN.

BU = {CoA, CN, HoA, Seq#, LT, i, j, MAC

}

MAC

= First (96, HMAC_SHA1 (K

, (CoA|

CN|BU)))

In the BU message, MN’s CoA address is source

and the CN’s address is destination. The MN’s home

address (HoA), a sequence number, proposed

lifetime for the binding and the nonce indices are all

part of the BU message. The HoA and indices are

needed by the CN to be able to regenerate the

keygen tokens. The CoA is also needed for this

purpose. A MAC is finally appended to the BU

message.

On reception of the BU message, the CN

generates the K

from its regenerated keygen

tokens. By use of the K

, CN is able to verify the

MAC. Whenever a BU message is considered

authentic, CN updates its binding cache (BC) with

an entry of the MN.

4.1 BC flooding attack on the RR

protocol I

In this section we introduce our BC flooding attack

on the RR protocol.

In general, whenever there is a cache or buffer

that needs to be allocated memory resources,

attackers might try to take advantage of it. An

attacker may simply fill such storages with random

data, resulting in others, non-fraudulent nodes,

impossibility of updating the storages with usable

information.

An attack with similar outcome as our proposed

attack is briefly described in (Nikander, 2005). An

attacker sends a spoofed packet to a MN. The packet

appears to originate from a CN wanting to initiate

communication with the MN. The CN is the attacked

node in this scenario. The packet must be sent via

the MN’s home subnet, i.e. non-optimized routing.

On reception of the packet, MN will initiate route

optimization with the attacked CN. The protocol will

be executed according to the specifications, and an

entry of the MN will be added to the CN’s BC. The

proposed attack (Nikander, 2005) manage to flood

the attacked CN’s BC only if a sufficient number of

entries are added to the BC before to many

previously added entries starts expiring. In other

words, the cache must be filled to maximum

capacity, leaving the attacked node unable to

perform route optimization with other MNs. To

succeed in its attack, the attacking node must know

the addresses of sufficiently many MNs. Unless such

a MN is a MN away from its home subnet, the

attacker will not succeed in getting the MN to

initiate the Return Routability protocol with the

attacked node.

However, the described attack is possible against

any binding update authentication protocol, but

finding sufficiently many MNs to succeed in the

attack, might become challenging. Ingress filtering

also renders the attack more difficult, since it makes

it harder to forge the source address of the spoofed

packets. We will therefore introduce a new way of

launching BC flooding attacks on the RR protocol,

showing that RR as well as our ROM protocol easily

may become target of BC flooding attacks.

An IPv6 node may allocate several IPv6

addresses to a single interface (Hinden, 2003). This

gave us the idea of how a CN may be victim to a

similar BC flooding attack when using the RR

protocol, as when using the ROM protocol.

Consider an Eve configuring lots of IPv6

addresses to a single interface. This may be done in

an IPv6 stateless address autoconfiguration manner

(Thomson, 1998). Eve is now associated with

several IPv6 addresses, all with subnet prefixes

FLOODING ATTACK ON THE BINDING CACHE IN MOBILE IPv6

Figure 9: Two Eves, both associated with numerous IPv6

addresses.

equal to the prefix of the subnet where Eve is

located.

Finally, by having two Eves at different subnets,

both associated with lots of IPv6 addresses as shown

in figure 9, the BC flooding attack is possible.

The attack may be launched in the following

way. If Eve_1 initiates a home routability test with a

victim node as shown in figure 10, i.e. sends a HoTI

message to the victim, she will receive a HoT

message in reply. The HoT message contains a home

keygen token (Token

). To the attacked CN, the

source address of the HoTI message seams to be the

home address (HoA) of a legitimate MN. But in this

attack, the address is actually one of Eve_1’s

previously configured addresses.

If Eve_2 initiates a care-of routability test she

will receive a CoT message, and will thereby also be

in possession of a keygen token, not a home keygen

token (Token

), but a care-of keygen token (Token

Figure 10: Flooding attack on CN’s BC.

Now, if Eve_1 forwards her Token

to Eve_2,

Eve_2 will be capable of sending a verifiable BU

message to the attacked CN. The BU message must

be generated using the binding management key

). This key is generated by means of the

received keygen tokens.

From the attacked CN’s point of view, it seams

as if a MN with HoA address equal to the address

used by Eve_1 has moved to the address used by

Eve_2. Whenever a verifiable BU message is

received, a mapping from the MN’s HoA address to

the MN’s currently used care-of address (CoA) is

added as an entry in the CN’s BC. If an entry of this

MN already exists, the existing entry is only

updated.

The functionality of the RR protocol makes this a

perfectly feasible attack, having two conspiring Eves

flooding a CN’s BC. The CoTI-initiating Eve should

be responsible for sending the final BU messages.

This Eve is associated with the CoA addresses, and

the BU messages must originate from these

addresses to succeed in the attack. However, the

HoTI initiating Eve could also be doing this, but

then its source address must be spoofed, appearing

to be its conspiring node. Due to ingress filtering

this might become challenging. Hence, the CoTI

initiating node should generally be sending the BU

messages.

In the RR protocol, a CN should generate a new

private key (K

) and nonce value every 30 seconds.

The CN should also remember eight of its

previously used private keys and nonce values. A

private key and nonce value pair is used as a part of

the keygen token generation. If every K

and nonce

value pair is employed by CN for the duration of 30

seconds (Johnson, 2004), the issued Token

and

Token

are valid for the duration of 210–240

seconds from first being issued, depending on where

within the 30 seconds time interval the tokens were

generated by the CN. To summarize; the tokens are

valid, and may be used by the attacking Eves to

generate a verifiable BU message, as long as the CN

may use the tokens to authenticate the received BU

message, i.e. as long as CN has the previously used

and nonce value in its memory.

The tokens are independent of each other, and

hence, the HoTI and CoTI messages of figure 10

must not necessarily be sent simultaneously.

Synchronization of the attacking Eves is hence

unnecessary. To succeed in the BC flooding attack,

the tokens must be considered authentic by the

attacked CN. This is verified by the CN on reception

of the BU message.

Initiating the home and care-of routability tests

repeatedly, using the previously configured IPv6

addresses, and sending of BU messages as

explained, may eventually fill the BC at the attacked

Eve_1

IPv6

Eve_2

Eve_1

Eve_2

1a) HoTI

2a) HoT

1b) CoTI

2b) CoT

3) home keygen token

ICETE 2005 - WIRELESS COMMUNICATION SYSTEMS AND NETWORKS

CN. New IPv6 addresses may of course be

dynamically configured by the attacking Eves during

the attack.

To minimize the effect of different known and

unknown attacks, the designers of the RR protocol

introduced a 420 seconds durability of the mapping

from a MN’s HoA address to the MN’s CoA

address. If not updated, MN’s entry in CN’s BC is

deleted. In addition to making different attacks more

complicated, the deletion of BC entries is used as

memory management. A CN may delete entries

from its BC when not in use.

Due to the removal of BC entries, even an honest

MN must initiate the RR procedure and send new

BU messages to its CNs at least every 420 seconds.

This feature was also used in the design of our ROM

protocol. Attackers must now execute their BC

flooding attacks within a 420 seconds time interval.

4.2 BC flooding attack on the RR

protocol II

IPv6 will continue to use the model from IPv4

(Hinden, 2003); a subnet prefix is associated with

one link and multiple subnet prefixes may be

assigned to the same link, e.g. an Ethernet. This will

ease our flooding attack, reducing the need of two

cooperating Eves to launch the attack, to only one

Eve. If the subnet where an Eve is located is

assigned multiple subnet prefixes, Eve may act as

both Eve_1 and Eve_2. Eve may now configure lots

of IPv6 addresses using two different subnet

prefixes. Eve may then by herself launch the attack

of Section 4.1. Of course Eve may have to be a more

powerful node in this attack scenario than in the

scenario of Section 4.1.

Since every node in MIPv6 may become a CN of

a MN, and the MIPv6 protocol is supposed to be a

default part of the IPv6 protocol, any IPv6 node may

be victim to this BC flooding attack. However,

attacking a node that is often used as a CN by other

MNs, will be more harmful than attacking a node

that is never used, and hence not in need of its BC.

5 CONCLUSION

Return Routability (RR) is the route optimization

protocol suggested by the IETF (Johnson, 2004). RR

is used to authenticate binding updates sent from

mobile nodes (MNs) to corresponding nodes (CNs).

Our ROM protocol (Veigner, 2004) intends to make

MIPv6 route optimization more seamless than RR

manage; in other words, to speed up the procedure

and at the same time provide similar security

characteristics. The importance of the protocol being

seamless is the fact that route optimizations are often

carried out during a MN’s handover from one subnet

to another.

This paper focuses on flooding attacks on the

binding cache (BC) at CNs, and shows to which

extent the RR protocol as well as our ROM protocol

is vulnerable to such attacks.

Certain countermeasures have been suggested.

The 420 seconds durability of BC entries is already

included in both protocols. Nevertheless, the BC

flooding attack discovered on the IETF suggested

RR protocol is important to point out. Another

countermeasure is to keep the number of entries

allowed in a BC low. This is not necessarily a good

solution, making DoS attacks easier to carry out by

means of BC flooding attacks. Strong authentication

was also considered, but the solution has a major

disadvantage in scalability due to the lack of a global

PKI. Use of asymmetric cryptography would also be

a very CPU-consuming feature; resulting in

increased DoS attack vulnerabilities.

As we all know, bandwidth in mobile and

wireless networks is unpredictable and often low. In

comparison to RR, the main benefit of the ROM

protocol is the reduction of messaging when re-

establishing route optimization from a new subnet.

It is important that we understand all the threats

the new technology creates before a possible

deployment.

REFERENCES

Aura, T., 2002. Mobile IPv6 Security, Cambridge Security

Protocols Workshop.

Deng, R. H., Zhou, J., Bao, F., 2002. Defending Against

Redirect Attacks in Mobile IP, Proceedings of the 9th

ACM conference on Computer and communications

security.

Hinden, R., Deering, S., 2003. Internet Protocol Version 6

(IPv6) Addressing Architecture, IETF RFC 3513.

Johnson, D., Percins, C., Arkko, J., 2004. Mobility Support

in IPv6, IETF RFC 3775.

Nikander, P., Arrko, J., Aura, T., Montenegro, G.,

Nordmark, E., 2005. Mobile IP version 6 Route

Optimization Security Design Background, IETF

Internet-draft.

Thomson, S., Narten, T., 1998. IPv6 Stateless Address

Autoconfiguration, IETF RFC 2462.

Veigner, C., Rong, C., 2004. A new Route Optimization

protocol for Mobile IPv6 (ROM), International

Computer symposium 2004, Taipei.

FLOODING ATTACK ON THE BINDING CACHE IN MOBILE IPv6
