HARDENING WINDOWS SYSTEMS

George Davida

P.O. Box 784

Department of Electrical Engineering and Computer Science

University of Wisconsin - Milwaukee

Milwaukee, WI 53201

Jon Peccarelli

Department of Electrical Engineering and Computer Science

University of Wisconsin - Milwaukee

Milwaukee, WI 53201

Keywords:

Operating system security, intrusion detection, vulnerability assessment, restricted tokens.

Abstract:

Microsoft Windows systems have been the favourite target of viruses, worms and spyware in recent years.

Through a kernel level process, we can secure Windows™processes by running them in a form of a sandbox.

These sandboxes are conﬁgured to only allow a subset of rights to be granted to the process, therefore limiting

the ability of a rogue process or a compromised process to inﬂict damage on the rest of the system.

1 INTRODUCTION

Microsoft Windows™has been a target of viruses,

worms, spyware and other malicious code due to a

history of insecure systems. In recent years, a con-

certed effort has been made to secure Windows™.

The software ﬁrewall has been enabled by default.

Hotﬁxes have been made available for any security re-

lated issues once they are discovered. Microsoft has

released an anti-spyware product to combat the spy-

ware issue. And they have published whitepapers on

hardening the operating system through security, ac-

count and local policies. Yet the operating system is

still venerable to malicious processes that run in the

user context. Many problems with security breaches,

viruses, worms and spyware can be traced to systems

that allow too many rights to processes.

Therefore, the focus is to control the bounds of a

process. In other words, put the process in a sand-

box. However, these sandboxes would work differ-

ently than the typical sandbox. This sandbox could

then be modiﬁed by a master kernel level process to

grant speciﬁc rights approved by the user, administra-

tor or some other external, trusted source. Processes

that were not predeﬁned would run in a default sand-

box with very limited rights, thus limiting the risk of

running, either knowingly or unknowingly, untrusted

processes. This would limit the ability of a virus in

an e-mail to be able to infect, or install, itself on the

host computer, since the process would be unknown

and therefore run in a limited sandbox. For example,

spyware would be blocked from installing on the host

system since it would not have rights to write to the

disk and registry.

A beneﬁt of this approach is that system perfor-

mance remains nearly unaffected by this method of

protection, since there is not a constantly running

process watching the other processes on the system,

unlike the typical sandbox. When a process is created,

its security context is adjusted. The process may take

a few more clock cycles to start, but this should be

fairly invisible to user in terms of performance degra-

dation. This is in stark contrast to anti-virus soft-

ware which is constantly running and scanning every

process and ﬁle that is accessed on the system, and to

other past attempts that are constantly intercepting all

system calls.

2 SECURING PROCESSES

Security in Windows™(NT,2000,XP) is handled by

security identiﬁers (SIDs), tokens and access checks

at many different levels. Files, devices, volumes, and

registry keys are all examples of items that can be pro-

tected. This list also includes processes. Access to-

kens are utilized by Windows™to handle system se-

curity. The security reference monitor (SRM) is re-

sponsible for the deﬁnition and use of these access

tokens. (Russinovich and Solomon, 2005)

User-level processes typically inherit the rights of

367

Davida G. and Peccarelli J. (2005).

HARDENING WINDOWS SYSTEMS.

In Proceedings of the Second International Conference on e-Business and Telecommunication Networks, pages 368-371

DOI: 10.5220/0001416703680371

 SciTePress

Notification of new

process creation

Retrieve Hash of Binary

Set access token

on process

Return

Capture security

token requests

from application

Apply default

access token

Logging

Enabled

Match Hash

Yes

Figure 1: Filter Kernel Driver

the main user-mode process (userinit.exe). The main

user-level process is originally created during the lo-

gon process for the user. (Russinovich and Solomon,

2005) Since this user-level process has the same rights

as the logged on user, any program launched un-

der this user will have these rights. There is an in-

herit problem with this blanket approach. Processes

that the user may not want to launch, or may be un-

aware of, can be run under the users security con-

text, namely viruses and spyware. It would be nice to

have a way to control the access token each process

inherited, and even grant limited security rights to

processes not known by the user and/or system. By

utilizing restricted tokens in Windows™, we can cre-

ate processes with limited privileges and limited ac-

cess control lists.

2.1 Related Work

Many techniques have been developed to secure

processes above the standard operating system secu-

rity.

In a client-server architecture, execution manage-

ment was controlled by system administrators us-

ing an execution management utility (EMU). In this

scheme, each user has a unique execution control list

(ECL) which is essentially a database of programs the

user is allowed to execute. Identiﬁcation of programs

is accomplished by the MD5 hash of the executable

binary and the executable name. Through the use of

a kernel driver, all new process creation is controlled.

(Schmid et al., 2001)

Microsoft added a technology called group policy

to its Active Directory environments. An adminis-

trator can control which executables are able to run

on a computer through a software restriction policy.

(Trent, 2004) Programs are either allowed to run or

not, with no change to security of the running process.

This technology also requires a computer to be part

of an Active Directory environment, therefore home

computers are not able to use a software restriction

policy.

The idea of a sandbox is to control and monitor a

user-level process, through a set of instructions from

a conﬁguration or policy ﬁle. A sandbox runs as a

process wrapper, intercepting all system calls from

the ”wrapped” process. The sandbox either allows

or denies the system call based on a conﬁguration

ﬁle. This can be used to limit access to the entire

ﬁlesystem, for example, by presenting a subdirectory

in the ﬁlesystem as the root of the ﬁlesystem to the

”wrapped” process. Janus was developed to monitor

a user-level process and deny harmful system calls.

(Goldberg et al., 1996) Janus is an example of a sand-

box.

Kernel hypervisors are a layer of software that pro-

vides a set of ”virtual” system calls. These can be

used to provide ﬁne-grained security control, for ex-

ample. (Mitchem et al., 1997)

2.2 Methodology

The EMU and Microsoft approaches are an all-or-

nothing scheme, i.e. a user is either allowed or de-

nied the ability to run an application. Once an ap-

plication is allowed to run, no additional security is

provided. The sandbox and hypervisors are processes

that run and constantly monitor, and possibly deny,

system calls and requests. Our approach is to mod-

ify the security token of the process before execution

and leverage all of the granularity and security of the

operating system.

The following list is the basic steps for creating a

process via the CreateProcess function. (Russinovich

and Solomon, 2005)

1. Open the image ﬁle to be executed.

2. Create the executive process object.

3. Create the initial thread.

ICETE 2005 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS

368

4. Notify the subsystem of the new process so that it

can set up for the new process and thread.

5. Start execution of the initial thread

6. In the context of the new process and thread, com-

plete the initialization of the address space and be-

gin execution of the program.

The item of interest in this list is step two, creat-

ing the executive process object. During this step, a

copy of the parent’s access token is made, which be-

comes the new process’s access token. Since this to-

ken grants access under the user’s security context, it

is the key to hardening the system.

The ﬁrst step to controlling the security context of

processes is to take control of the process creation

process. This is accomplished through a kernel driver.

The idea is to capture the process creation process,

locate the proper security context for the process and

execute the process with the appropriate access token.

For this whole process to work correctly and se-

curely, the security credentials need to be stored in a

manner that prevents, and in the worst case detects,

tampering. The security context for each process are

stored in a Execution Control List database. This in-

formation is stored in a format that is encrypted and

digitally signed for security and authentication pur-

poses. The kernel driver is the only process that is

allowed to write to thi database.

An important point to note is that this concept, by

itself, cannot successfully secure a system. When

combined with proper techniques already available to

secure a Windows™system, this concept can yield

a much more secure system. This technique also

requires the use of an access-based ﬁlesystem, like

NTFS, to work properly. If write access cannot be

restricted to the ECL database, the kernel driver will

be able to identify a compromised system through an

invalid digital signature.

This entire methodology is related to the idea of

running each and every process on the computer un-

der a unique user id. Each process would have a se-

curity context that would be inherited from a unique

user id. However, there are some concerns using this

methodology. First, how does one process access

shared information from another process, since they

are running under different user contexts? And sec-

ondly, how does one manage such a large number of

user accounts, especially in the example of multiple

users running on one system (i.e. Terminal Services)?

2.3 Process Identiﬁcation

For this technique to function properly, a method

needs to be used to accurately identify processes.

This method needs to be able to determine if a ma-

licious process is trying to run as a known validated

process. For example, assume notepad.exe has previ-

ously been identiﬁed, validated and has a ECL entry

in the database. Now a malicious process names it-

self notepad.exe. This process should not be allowed

to run under the original notepad.exe security context.

Therefore, a method of process identiﬁcation needs to

developed to ensure that the proper security context is

assigned to the intended process only.

A digital signature or hash will be created from the

process’s executable image. This signature will then

be stored in the database to identify the process. Be-

fore a process is allowed to execute, it’s signature will

be compared to those in the database. If a match is

found, the access token associated with that signature

will be used. Otherwise, the process will be handled

as an unknown process as described in Section 2.5. If

an executable ﬁle is updated through a service pack,

patch or upgrade, the digital signature will need to be

updated as well, otherwise it could be denied the abil-

ity to execute properly.

2.4 Extracting an ECL

Two approaches can be utilized to create an Execu-

tion Control List for a process. The ﬁrst approach is

to start the process without any rights and add rights

as needed. This approach is very secure, however

it requires an in-depth knowledge of the process in

question. Since most Windows™programs are closed

source, this is usually not possible by the end-user,

unless a trial and error approach is attempted. The de-

velopers would have the knowledge required to create

an ECL for each process as described in Section 2.6 .

The second approach is to run the process with a

monitor in place. The kernel driver can log all secu-

rity token requests of the monitored process. Once

this has been completed, the ECL information can be

incorporated into the ECL database. From this point,

the user can just use this ECL as is or make modiﬁ-

cations to the ECL. This allows the user to limit the

rights of the process without generating this list from

scratch.

2.5 Default Execution Control List

What happens when a process is launched that doesn’t

have an Execution Control List associated with it?

If the process were allowed to run without an ECL,

this would be a breach of the hardening of the sys-

tem. Therefore, an approach needs to be developed to

eliminate this potential threat.

When a process is created that does not have an

ECL associated with it, the process is created with

a default access token. This token can be deﬁned

with predetermined access rights. These predeter-

mined access rights could deny all rights to the sys-

tem - thereby eliminating the ability of any unknown

HARDENING WINDOWS SYSTEMS

369

Kernel Driver

Monitor

ECL Database

Process

Figure 2: ECL Extraction

process from executing on the system. The kernel

driver can also be conﬁgured to automatically log the

token access requests and start building an ECL for

the new process. This would allow the user to incor-

porate this information in the system-wide ECL data-

base. Multiple default Execution Control Lists could

be deﬁned and utilized depending on the process’s

parent.

2.6 Future Use

Execution Control Lists could be delivered with an

application installation. The developers would be

responsible for identifying the appropriate rights re-

quired for each process in the application to work

properly. Currently, many Windows™developers as-

sume the application will have full access to the entire

system, which is a large security problem. This would

slow, or maybe even stop, that practice.

For tighter security, incorporation into kernel

would be the next logical step. Therefore, a callback

would not have to be registered to catch process cre-

ation. The process would be created with the proper

security token directly from the operating system, in-

stead of catching the process creation and modify-

ing the initial process access token. The most logi-

cal place for this incorporation would be the security

reference monitor (SRM).

A central execution management server could be

developed to control an Execution Control List for a

corporation, thereby limiting the exposure of individ-

ual corporate computers to spyware, viruses and other

malicious executables.

REFERENCES

Goldberg, I., Wagner, D., Thomas, R., and Brewer, E. A.

(1996). A secure environment for untrusted helper ap-

plications. In Proceedings of the 6th Usenix Security

Symposium, San Jose, CA, USA.

Mitchem, T., Lu, R., and O’Brien, R. (1997). Using kernel

hypervisors to secure applications. Proceedings of the

13th Annual Computer Security Applications Confer-

ence (ACSAC’97).

Russinovich, M. and Solomon, D. (2005). Microsoft Win-

dows Internals. Microsoft Press, Redmond, 4th edi-

tion.

Schmid, M., Hill, F., and Ghosh, A. K. (2001). Preventing

the execution of unauthorised win32 applications. In

Proceedings of the 2001 DARPA Information Surviv-

ability Conference and Exposition, Anaheim, CA.

Trent, R. (2004). Using software restriction policies to

block spyware-adware.

ICETE 2005 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS

370
