AN EFFICIENT PROXY SIGNATURE SCHEME IN HOME

NETWORK DRM

Xiaoyun Wang

1,2

, Kefei Chen

1,2

Department of Computer Science and Engineering, Shanghai Jiaotong University

1954 Huashan Road, Shanghai, People’s Republic of China

State Key Laboratory of Information Security, Institute of Software of

Chinese Academy of Sciences, Beijing, People’s Republic of China

Keywords: Home network DRM, Authorized domain, Certificate Chain, Proxy signature.

Abstract: In this paper we overview the existing home network DRM schemes and especially Philips’

invention. Then we propose to use the proxy signature to simplify the authentication of certificate

chain in Philips’ scheme. And we also give an efficient scheme of proxy signature based on the

characters of certificate chain. We then give a detailed security analysis to show that our scheme

meets the six properties of proxy signature. Finally the paper points that we should go ahead to

improve the efficiency of home network DRM scheme and show a kinder interface to digital home

consumers.

1 INTRODUCTION

Digital contents are the main application in digital

home. Home network Digital Rights management

(DRM) is required by content providers to protect

high-value digital assets and control their

distribution and usage. In digital home DRM,

Authorized Domains (AD) are introduced by DVB

(Digital Video Broadcasting) as a means to enable

the consumer be free to access and distribute

contents within the entire home network.

There are several AD based home network

DRM schemes. Philips’s invention is one of them

and based on certificate chains. The main problem in

it is low efficiency and long feedback delay because

of complex protocols and weak computing

capability of consuming devices. So we should try to

reduce the amount of protocol steps, or computation

to improve efficiency and reduce the delay.

In this paper we will propose an efficient proxy

signature scheme to simplify the device

authentication protocol on content demanding in

Philips invention. This proxy signature scheme

could also be used in proxy signature scenario of

home network. And this scheme is also an example

to improve the efficiency of home DRM protocols

and get a good person kind interface in home

network DRM.

The rest of paper will be arranged as follows:

Section 2 gives an overview of the home network

DRM schemes. Then we propose the proxy signature

to simplify the authentication protocol on content

demanding in section 3. In section 4 we detail the

efficient proxy signature scheme. In section 5 we

give a security analysis to show that our scheme

meets the six properties of proxy signature. Finally

in section 6 we conclude it and give the future

works.

2 OVERVIEW OF HOME

NETWORK DRM

SCHEMES

A number of implementations of AD-like DRM

systems are known.

The SmartRight system (Smartright technical

white paper, 2005) has been proposed by Thomson

Electronic, and relies on smart cards modules

incorporated into CE devices. This scheme is mainly

based on public key certificates and devices in the

domain share the same symmetric domain key,

which is used to encrypt the protected contents. The

main drawback of this approach is its poor designed

protocols and that it’s hard to revoke devices and

update the domain key.

The xCP architecture (xCP Cluster Protocol,

191

Wang X. (2005).

AN EFFICIENT PROXY SIGNATURE SCHEME IN HOME NETWORK DRM.

In Proceedings of the Second International Conference on e-Business and Telecommunication Networks, pages 191-194

DOI: 10.5220/0001419801910194

 SciTePress

2005) has been proposed by IBM, and is based on

broadcast encryption. This is great improvement

from an economical point of view. However the P2P

model are not well suitable for the home network. In

home network there are always

administrators-parents.

The Philips patents WO2004027588 (Philips

patent WO2004027588, 2005) is based on the idea

that an authorized domain is set up with a central

device administering the network. When a device

enters the network, the central device registers the

entering device and issues a domain certificate to the

entering device. This invention designs a certificate

chain, illustrated in Fig. 1, contains the following

certificates:

 The (external) Certificate Authority (CA) root

certificate, self-signed and is used to sign

device certificates.

 The device certificate, signed by the CA root

private key and containing the device public

key.

 The AD root certificate, which is generated by

the ADM (AD Manager) at AD setup and

which signs a new key pair.

 The private key corresponding to this

certificate will be used to issue AD device

certificates.

 The AD device certificate, issued by the ADM

when the device joins an AD.

Figure1: Certificate Chain (Redrawn from (Philips patent

WO2004027588, 2005)).

Philips’ scheme is suitable for today’s digital

home, which is centralized in management but

distributed in location. And the public key

encryption is also more popular than broadcast

encryption in today’s consuming devices.

3 THE AUTHENTICATION

PROTOCOL ON CONTENT

DEMANDING

Figure 2: Home network System (Redrawn from (Philips

patent WO2004027588, 2005))

Fig.2 shows an in-home network system 100

comprising devices 101-105 interconnected via a

network 110. In this system a set top box 101 is the

central administrating device, providing central

control over the others.

When the portable device 103 demands content

from content provider 201, the device 103 should

show the content provider 201 not only its device

certificate, which is issued by device manufacturer

(CA Root), but also its AD device certificate. Since

the certificate is in chain and the content provider

only trusts the CA Root, the device 103 should show

content server 201 the device’s AD device certificate,

AD Root Certificate and the ADM’s certificate. And

the content provider 201 verifies all the certificates

in turn. The certificate chain makes much

complexity in authentication.

We notice that the certificate chain could be

expressed by proxy signature. So we try to use proxy

signature to simplify the authentication.

There’re many paper about proxy signature, the

primary schemes are (Mambo et al., 1996 a)

(Mambo et al., 1996 b)(Usuda et al., 1996) (Kim et

al., 1997) (Jiguo, 2002).

M-U-O proxy signature schemes (Mambo et al.,

1996 a) (Mambo et al., 1996 b)are the first two

schemes of proxy signature but donnot provide

nonrepudiation. It is impossible to decide who is the

actual signer of a proxy signature in their schemes.

Another drawback of these schemes is that they

require a secure channel to transmit the proxy

signature key from the original signer to the proxy

signer. Anyone who can intercept this proxy

signature key can impersonate the proxy signer.

(Usuda et al., 1996) (Kim et al., 1997) (Jiguo,

2002) give some improvement to M-U-O’s scheme.

ICETE 2005 - MULTIMEDIA SIGNAL PROCESSING

192

But they all have the drawbacks that the protocols

are too complicated to consuming devices.

In the next section, we will give an efficient

scheme. And it also meets the six properties of the

proxy signature—Unforgeability, Verifiability,

Undeniability, Distinguishability, Proxysigner’s

Deviation and Stong Identifiability.

4 AN EFFICIENT SCHEME

OF PROXY SIGNATURE

We suppose that the CA Root has the private key

Zs ∈

and the corresponding public key

pgV

mod= . And ADM has the key pair

hZ∈

and

mod

Hg p= . And AD Root

has the key pair

hZ∈

and

mod

Hg p= . ()

is a one-way hash

function.

So in the step (1), CA Root select

kZ∈

and compute mod

Kg p= and

(, ) modsf V H kK q

=+,

Step (2) CA Root sends

(, ,)KV

to ADM.

Since

has the hash of

H , so this message

should not send in secure channel since no one can

impersonate ADM.

Step (3) ADM checks if

(, )

mod

fVH

gV K p

= .

Step (4) ADM select

lZ∈

and compute

mod

Lg p= and computer

1112

'(,) (,)modsf V H kK h f H H lL q

=++ +

Step (5) ADM sends

(',,, ,)VKH L

AD Root. Since

has the hash of

H , so this

message shouldn’t send in secure channel since no

one can impersonate AD Root.

Step (6) AD Root signs message

(' )h

+ , the message m is the certificate of

device.

So in step (7) content provider just uses the

public information

(, , ,, )VKH LH and

constructs a new

112

(, ) ( , )

'mod

fVH f H H

VV KH LH p= to

verify if device is a valid AD device permitted by

CA Root and if the AD device certificate is issued by

ADM and AD root.

5 SECURITY ANALYSIS

Scenario1:

(, , )KH

and

(',, ,, )KH LH

needs no secure channel. Since

has the hash of

H , no one except ADM could reconstructs

And since

has the hash of

H , so only AD

Root could sign message m by its proxy signature

key

(' )h

+ .

Scenario2: The difficulty of finding the

corresponding proxy signature key

from the

equation

(, )

mod

fVH

gV K p

= under the

attacker knowing

,,VH K is equivalent to

AN EFFICIENT PROXY SIGNATURE SCHEME IN HOME NETWORK DRM

193

solving discrete logarithm hard problem. Hence, it is

computationally infeasible for the attacker to derive

proxy signer’s signature key

. And this is same to

the final signature key

Scenario3: Given a valid proxy signature

1112

(,((,) (,)mod ), , )

essage sf V H kK h f H H lL q K L++ +

. Since the proxy signature includes the proxy

signer’s private

h , the original signer could not

forge another valid proxy signature. And if it

randomly selects one number and tries to solve

'K ,

this problem seems to be more difficult than discrete

logarithm hard problem.

Scenario4: Given a valid proxy signature

1112

(,((,) (,)mod),,)

essage sf V H kK h f H H lL q K L++ +

. Since the original signer’s public key is included in

the hash function, neither the original signer nor an

attacker could forge a proxy signature key by public

key substitution attack.

Scenario5: Given a valid signature

1112

(,((,) (,)mod),,)

essage sf V H kK h f H H lL q K L++ +

Since no one could forge the signature except

the proxy signer, the proxy signer could not deny the

signature.

6 CONCLUSION

In this paper we overview the existing home

network DRM schemes. And then we give an

efficient proxy signature scheme to simplify the

device authentication on content demanding in the

Philips scheme. Finally we analyze the security of

our scheme.

And this efficient scheme is also an example to

improve the efficiency of home DRM protocol and

get a kinder interface to consumers. The proxy

signature could be used not only in device

authentication, but also on the scenarios when

mobile device acts as an agent of the central

administering device and the family member takes

the charge of AD administrator. And we should think

over other security technologies to improve the

efficiency of home DRM protocol also.

REFERENCES

Smartright technical white paper.. Retrieved from

Thomson company website. Jan. 2005.

http://www.smartright.org/images/smr/content/

/SmartRight_tech_whitepaper_jan28.pdf,

xCP Cluster Protocol. Retrived from IBM company

website. Jan 2005

http://www.almaden.ibm.com/software/ds/ContentAssu

rance/papers/xCP-DVB.pdf

Philips patent WO2004027588, Retrieved Jan. 2005, from

http://v3.espacenet.com/textdoc?DB=EPODOC&IDX=

WO2004027588&F=0

M. Mambo, K. Usuda and E. Okamoto. Proxy signatures

for delegating signing operation. Proc. 3

ACM

Conference on Computer and Communications

Security, ACM Press, 1996, 48-57, Retrieved from

ACM online database

M. Mambo, K. Usuda and E. Okamoto. Proxy signatures:

Delegation of the power to sign messages. IEICE Trans.

Fundam., 1996, E79-A, (9), 1338-1354

K.Usuda, M.Mambo, T.uyematsu, and E. Okamoto,

“Proposal of an automatic signature scheme using a

compiler”, IEICE Trans. Fundamentals,

vol.E79-A,no.1,1996,pp.48-57.

S. Kim, S. Park, and D. Won, ”Proxy signatures, revisited”,

Proc. Of ICICS’97, International Conference on

Information and Communications Security, LNCS

1334, Springer-Verlag, pp. 223-232, 1997. Retrieved

from Springer online database

Li Jiguo, Cao Zhenfu, Zhang Yichen. Improvement of

M-U-O and K-P-W Proxy Signature Schemes. Journal

of Harbin Institute of Technology. 2002,9(2): 145~148.

ICETE 2005 - MULTIMEDIA SIGNAL PROCESSING

194
