MULTILATERAL SECURITY CONSIDERATIONS

FOR ADAPTIVE MOBILE APPLICATIONS

Adrian Spalka, Armin B. Cremers

Institute of Computer Science III

University of Bonn

omerstr. 164, 53117 Bonn, Germany

Marcel Winandy

Horst G

ortz Institute for IT-Security

Ruhr-University Bochum

Universit

atsstr. 150, 44780 Bochum, Germany

Keywords:

Multilateral security, mobile computing, adaptive applications.

Abstract:

Adaptive mobile applications are supposed to play an important role in the future of mobile communication.

Adaptation offers a convenient and resource-saving way of providing tailored functionality. But to make this

technology a success, the security of all concerned parties must be addressed. This work presents a multilateral

security examination in two stages. We ﬁrst introduce a co-operation model and state the security requirements

from the perspective of each party. In the second stage we investigate the set of all requirements with respect

to conﬂicts, state each party’s role in the enforcement and suggest a realisation. The result is a comprehensive

picture of the security aspects of adaptive applications in mobile environments.

1 INTRODUCTION

Today’s applications in mobile computing consist of

voice, text and video communication. Several Java or

operating system speciﬁc applications exist as well.

All applications are installed by the hardware manu-

facturer or must be downloaded by the user.

Network operators and service providers are enga-

ged in ﬁerce competition. They constantly enhance

their services to satisfy customer needs: the require-

ments change, services evolve and software applica-

tions must be adapted. Therefore, ﬂexible software

architectures and adaptive applications are needed to

quickly adopt these changes.

Future applications in mobile computing must al-

low for unanticipated evolution. In particular the sup-

port of context-sensitive behaviour, eg location-based

services, requires a frequent adaptation of the soft-

ware. To avoid re-installation of the whole appli-

cation, adapting parts of it is more convenient and

resource-saving. New techniques for software adap-

tation are developed now (M

ugge et al., 2005).

To give an example, consider a user equipped with

a smart-phone running a adaptive application. He can

take the application to any other device, eg a desktop

computer or a laptop. His mobile device will also be

able to connect to external displays with different pro-

perties. The application should be automatically ad-

apted according to the changing environment. If new

features are introduced, the application must be adap-

ted accordingly.

This work considers technologies for mobile app-

lications with adaptable and replaceable components.

To make them a success, the security of all involved

parties must be addressed. The following parties are

regarded as stakeholders: users (U), software produ-

cers (SWP), content providers (CP), service providers

(SP), network operators (NO), and hardware manu-

facturers (HWM).

The aim of this work is to identify party-speciﬁc se-

curity requirements and to extract non-conﬂicting and

possibly conﬂicting requirements in a multilateral ex-

amination. In the subsequent section we identify indi-

vidual security requirements from the perspective of

each party. In section 3 the requirements are exami-

ned with respect to conﬂicts. We state each party’s

role in the enforcement and suggest a realisation.

2 MULTILATERAL SECURITY

REQUIREMENTS

In adaptive mobile applications components thereof

can be replaced or adapted. We assume that a party

does not trust the other parties.

131

Spalka A., Cremers A. and Winandy M. (2005).

MULTILATERAL SECURITY CONSIDERATIONS FOR ADAPTIVE MOBILE APPLICATIONS.

In Proceedings of the Second International Conference on e-Business and Telecommunication Networks, pages 133-137

DOI: 10.5220/0001420101330137

 SciTePress

2.1 Stakeholder 1: The Users

In our scenario the user has a mobile device which

can execute adaptive applications and receive updates.

The user wants to make the best use of the services

at the least cost. The user also wishes to retain in-

tegrity, conﬁdentiality, availability and privacy of his

data. These constraints result in the following secu-

rity requirements with respect to the other parties.

Software producer

1. The software is written by the intended authors ⇒

Veriﬁcation of the authors’ authenticity.

2. The software accesses and modiﬁes only authori-

sed resources ⇒ Preservation of conﬁdentiality and

integrity of his data.

3. The software passes only data admitted by the user

⇒ Respect for his decisions on his privacy.

4. The software performs only intended modiﬁcations

⇒ Veriﬁcation of the semantic integrity of data (sa-

fety of the software).

5. The software does not block access to previously

accessible data ⇒ Preservation of availability.

6. The software does not prevent future adaptations ⇒

Preservation of availability of software adaptations.

The ﬁrst requirement can be satisﬁed with digital

signatures. Access control mechanisms can be used

to enforce requirement 2, or cryptographic hash func-

tions can be used, at least, to discover a violation of

integrity. Data outside the intended working set can

be encrypted to preserve conﬁdentiality. To satisfy

requirement 3, the user must be able to conﬁrm or ob-

ject to a data transmission. This implies the provision

of a trusted input and display by the hardware and the

operating system. Since the general user cannot verify

the safety of software, a recovery mechanism is indis-

pensable to achieve requirement 4. This also supports

requirements 5 and 6.

Content provider

1. Software is not modiﬁed during distribution ⇒ Ve-

riﬁcation of software integrity.

2. The process of the software transmission is not re-

vealed for privacy reasons.

The ﬁrst requirement can be satisﬁed with digi-

tal signatures. The second requirement implies the

ability to buy content anonymously. On the other

hand, content providers may need to identify a user

to process payment.

Service providers and network operators Here,

the requirements are the same as for the content pro-

viders. If the user’s identiﬁcation is not needed, en-

cryption of the transmission preserves privacy.

Hardware manufacturers

1. The software does not disable critical hardware

functions ⇒ Maintenance of their availability.

2. The hardware device prevents the execution or ad-

aptation of software at the user’s request.

3. The software transmission process is not revealed

for privacy reasons ⇒ Prevention of identiﬁcation.

To partially satisfy requirement 1 the manufacturer

can provide a function to reset the mobile device in a

safe state. Requirement 2 cannot be enforced by the

user without the help of the hardware manufacturer.

Requirement 3 calls for a device which can switch

off hardware identiﬁcation at the user’s request. Ho-

wever, (Rannenberg, 2000) mentions that it may not

solve the problem.

2.2 Stakeholder 2: Software

Producers

The software producer can be author of a complete

program or a part thereof. We assume a traditional

vendor model, in which software is sold as a product.

Content providers, service providers and network

operators

1. The producer’s proﬁt depends on his reputation ⇒

Proof of software integrity and authenticity.

2. To charge for software usage, the producer wants

to prevent unlicensed software distribution.

Again, requirement 1 can be satisﬁed with digital

signatures along the distribution chain. The second

requirement can be satisﬁed in this setting in several

ways (the detailed description of which will be given

in a separate paper).

Users and hardware manufacturers

1. Licence compliant usage ⇒ Veriﬁcation of licen-

ses.

This requirement relies on the veriﬁcation of the

execution environment, eg, device identiﬁcation.

2.3 Stakeholder 3: Content

Providers

The content provider’s role resembles that of a mer-

chant in the traditional world. His primary goal, pro-

ﬁt, implies the following security requirements.

Software producers

1. Reputation of selling genuine software ⇒ Veriﬁca-

tion of authenticity and integrity.

Simple solution: digital signatures.

ICETE 2005 - WIRELESS COMMUNICATION SYSTEMS AND NETWORKS

132

Service providers

1. Reliability of the services.

2. Genuineness of the offered products.

While requirement 1 cannot be enforced by the CP

with technical means, digital signatures are sufﬁcient

for the second one.

Network operators

Should distribute CP’s data:

1. without modiﬁcation (integrity)

2. in a timely fashion (availability)

3. only to the designated address (fraud prevention)

4. having access only to data germane to the transmis-

sion (business privacy).

Solutions are already presented.

Users We take the users to be the primary source of

proﬁt for the content provider.

1. Self-veriﬁcation to build up reputation

2. Licence compliant usage ⇒ Veriﬁcation of licen-

ses.

Solutions already discussed.

Hardware manufacturers No apparent security

requirements.

2.4 Stakeholder 4: Service Providers

A service provider offers technical services to con-

tent providers for the distribution of products to cu-

stomers. To put it simple, a service provider puts the

products of content providers in data packages, which

can be transmitted by network operators. Its main ob-

jective, proﬁt, dictates the following security require-

ments.

Network operators

1. The proﬁt depends on the availability of its services

The satisfaction of this requirement relies on

quality-of-service mechanisms. Otherwise, compen-

sation of downtime can be regulated by contract.

Content providers

1. Authentication of the content provider for accoun-

ting purposes ⇒ Digital signatures.

In contrast to a traditional carrier, eg UPS, a network

operator need not have access to the contents or value of a

package.

Software producers

1. Software updates or adaptations do not affect the

availability of the services. If it cannot be enforced,

the service provider must verify the origin of the

software ⇒ Digital signatures.

Hardware manufacturers No apparent security

requirements.

Users

1. Identify users and devices for billing purposes.

2.5 Stakeholder 5: Network

Operators

A network operator exchanges data between a service

provider and a user. Its main goal is proﬁt, which he

generates by charging fees for network usage. It is

also inclined to provide services, which attract custo-

mers. From its perspective there is no need to discern

between the service provider and the user.

1. No bypassing of the billing mechanism.

2. High quality of transmission.

3. Provision of attractive services.

The ﬁrst requirement is stated on the grounds of re-

cent fraud, cf (Prasad et al., 2003). Requirement 2

calls for quotas, eg limited bandwidth allocation. The

last requirement is optional; to give an example, regis-

tered mail can be realised with digital signatures and

express delivery resorts to a priority-based allocation

of resources.

2.6 Stakeholder 6: Hardware

Manufacturers

A hardware manufacturer provides to a user a mobile

device with an operating system. Its basic objective

is proﬁt. In view of this article’s focus, it is directly

concerned only with its reputation among users. Indi-

rectly, it can be favoured by other parties if its devices

provide trusted functions or services that support their

security requirements.

Users

1. The device remains operational irrespective of soft-

ware behaviour.

This requirement relates to the quality of the design

and manufacturing, which is the sole responsibility

of the manufacturer and does not imply any speciﬁc

techniques.

MULTILATERAL SECURITY CONSIDERATIONS FOR ADAPTIVE MOBILE APPLICATIONS

133

Table 1: Multilateral evaluation of security requirements.

Requirement Required by Objected

to by

Participation Supported

Conﬂict Possible realisation

1) Authenticity of the software

producer and integrity of the soft-

ware product

CP and U no party SWP SP no Software product is digitally signed by

SWP; digital signature can be veriﬁed

by each party in the distribution chain.

2) Limitation of access to data U no party HWM SWP no Access control in the operating system.

3) User privacy: Limitation of

distribution of data by the appli-

cation

U no party

(possibly

HWM SWP no Access control in the operating system;

manual conﬁrmation data transmission;

trustworthy hardware display and input.

4) Safety of SW functionality. U no party HWM SWP no Undo function of the operating system.

5) Privacy of software transmis-

sion/purchase

U (optio-

nally)

CP, optio-

nally SWP

no party no party yes Mediated payment scheme.

6) Availability of equipment U, HWM no party HWM all parties no Reset function of the operating system.

7) Limitation of sources of soft-

ware

U (optio-

nally)

no party HWM, CP,

SWP

N/A no Selective installation of digitally signed

applications from white-listed sources.

8) Unlicensed distribution of soft-

ware by the content provider

SWP no party U N/A no User must register the application at the

software producer.

9) Unlicensed software usage/re-

distribution by the user

SWP and CP no party HWM and U N/A no User must register the application with

an ID of the execution environment,

which is provided by the HWM, at the

SWP.

10) Availability of services resp. party no party no party all parties no Controlled resource allocation.

11) Accounting for services resp. SP possibly U

(privacy)

service-

using party

N/A possibly Authentication of service-requesting

party.

12) Fraud prevention by eaves-

droppers and business privacy

SWP and CP no party U all other

parties

no Encryption of the software by CP with

the user’s public key.

Other parties

1. The mobile device provides security related functi-

ons, which are not under the control of the user.

This optional requirement depends on the manufac-

turer’s commitment to perform security related opera-

tions on behalf of other parties, eg, the provision of a

serial number or a service, which limits the usage of

an application to the terms of its licence.

3 MULTILATERAL EVALUATION

We now extract the intersections, ie non-conﬂicting

security requirements. They constitute the minimum

set of requirements that can be supported in an envi-

ronment with adaptive mobile applications. And, se-

condly, we extract conﬂicting security requirements,

ie those that are demanded by one party but opposed

by another. See table 1 for the evaluation results.

4 CONCLUSION

The idea to use adaptive applications in mobile envi-

ronments is in its early stage. This provides a unique

opportunity to include security techniques in their de-

sign. The starting point for this paper is the assump-

tion that the security requirements of all parties must

be considered in order to make it a success. We have

introduced a co-operation model, in which all par-

ties are considered: the software producer, the con-

tent provider, the service provider, the network opera-

tor, the user and the hardware manufacturer. The ﬁrst

stage of the investigation concentrated on the state-

ment of all individual security requirements from the

perspective of each party. In the second stage we have

combined all these requirements into a set. We have

found that nearly all security requirements are satis-

ﬁable without a conﬂict and that most of them can be

enforced with accredited security mechanisms. We

have identiﬁed the role and effort of each party in the

enforcement with the insight that a concerted contri-

bution results in a secure mobile environment for ad-

aptive applications.

REFERENCES

ugge, H., Rho, T., Winandy, M., Won, M., Cremers,

A. B., Costanza, P., and Englert, R. (2005). To-

wards Context-Sensitive Intelligence. In Proceedings

of EWSA 2005, LNCS Vol. 3527. Springer.

Pﬁtzmann, A. (2001). Multilateral Security: Enabling Tech-

ICETE 2005 - WIRELESS COMMUNICATION SYSTEMS AND NETWORKS

134

nologies and Their Evaluation. In Informatics - 10

Years Back. 10 Years Ahead., pages 50–62, London,

UK. Springer-Verlag.

Prasad, A., Wang, H., and Schoo, P. (2003). Network Ope-

rator’s Security Requirements on Systems Beyond 3G.

In Proceedings of WWRF 8. Wireless World Research

Forum.

Rannenberg, K. (2000). Multilateral Security - A Concept

and Examples for Balanced Security. In Proceedings

of the 2000 Workshop on New Security Paradigms

(NSPW ’00), pages 151–162. ACM Press.

MULTILATERAL SECURITY CONSIDERATIONS FOR ADAPTIVE MOBILE APPLICATIONS

135
