SMS Communication and Announcement Classification

in Managed Learning Environments

Ross Clement

, Mark Baldwin

, Clive Vassell

and Nadia Amin

Harrow School of Computer Science, University of Westminster, Northwick Park, Harrow,

Harrow Business School, University of Westminster, Northwick Park, Harrow, UK

Keywords. Managed learning environments, Text classification.

Abstract. A prototype system for sending SMS text messages to students

telling them about announcements has been designed and partially

implemented. Experiments have been performed to test whether automatic text

classification can be used to decide which announcements posted by tutors are

urgent and that a SMS text message should be sent informing students. The

accuracy of a naive Bayes classifier is not sufficient in itself to decide this, but a

flexible classifier and the ability of tutors to override its decisions has promise.

How the system would be used would depend on management policies

concerning the effects of classification errors.

1 Introduction

In this paper we investigate using machine learning based text classification in

managed learning environments. In particular, we report experiments designed to

evaluate the feasibility of using text classification to decide which announcements

made by tutors on a managed learning environment should be sent to students as SMS

text messages.

There has been considerable research into the use of Managed (and Online) Learning

Environments [7] in higher education. These allow the publication of course

materials, creation of interactive revision aids, and also communication between

people enrolled in courses and modules. The authors of this paper have noticed that

student participation in MLE mediated communication was initially good, but rapidly

declined over time. Perhaps because the novelty factor wore off. Beasley & Smyth

[1] investigated the real-world usage of MLEs and found a number of problems,

including that even students who found the learning environment valuable did not

interact with them properly. Research such as that of Ubon and Kimble [9]

investigates the participation of students in MLEs and “online learning communities”

from a human viewpoint, investigating what they call “social presence” of tutors and

Clement R., Baldwin M., Vassell C. and Amin N. (2005).

SMS Communication and Announcement Classiﬁcation in Managed Learning Environments.

In Proceedings of the 1st International Workshop on Web Personalisation, Recommender Systems and Intelligent User Interfaces, pages 116-124

DOI: 10.5220/0001422201160124

 SciTePress

students. We take a much simpler approach to addressing the problems of students

failing to make use of the materials posted on MLEs. If students are occasionally, but

not too frequently reminded of the existence of the MLE by text message, then they

may be more likely to make better use of the MLE.

Mobile phones are being increasingly important vehicles for accessing online services

of various types. The authors believe that the mobile phone will become the vehicle of

choice for conducting online transactions. Mobile phones are frequently carried by

students at all times, and therefore we believe that material sent to phones has the

highest probability of being read by students in a short time span, including in

comparison to email messages. The sending of SMS messages would also mean that a

data “push” aspect is added to the MLE environment, rather than the current “pull”

scenario, where the student will not receive information from the MLE or even be

aware that such information is waiting until they choose to view it.

2 Context

The Blackboard managed learning environment divides content into a number of

sections, storing course documents such as lecture slides, assignment and coursework

information, general module details, dicussion groups, and many other educational

resources.

In this paper we concentrate on the Announcements section where short

announcements are posted. An example announcement is:

New Assignment 2 Deadline – Assignment 2 is now due in on the 27

of April 2004,

at 4pm.

Announcements are frequently used to communicate urgent material such as lecture

timetable changes, as well as less urgent material Announcements are typically very

short, making them far from ideal for text classification which relies on counting the

frequencies of words in text.

A prototype system is being developed that will be able to send SMS messages to

students when new announcements are added to Blackboard sites for modules they

are taking. We assume that it is not sensible to send an SMS message for every

announcement posted to Blackboard because; (i) of the cost involved, approximately

5.5p per message per student, and (ii) because students may object if they are sent a

continuous stream of largely non-urgent messages.

The Blackboard system is easily extensible. Extensions to the system can be written

as Java Server Pages (JSPs), or Java Servlets, and easily integrated into a Blackboard

installation. These extensions can add new functionality, interface between

Blackboard and external software systems, and perform other functions.

Should our initial prototype system be a success, we intend to implement a full

Blackboard extension that can send SMS text messages to students when “important”

changes are made to the content of relevant Blackboard sites. Our initial prototype is

not implemented as an extension because we have not yet obtained “buy-in” from the

relevant technical and management personnel to modify the university's Blackboard

installation. Our current system uses HTML pages and JavaScript to poll the

117

announcement pages of modules. The page source is then submitted to a CGI

application written in Perl that can then serve the announcement text upon request to a

'bot also written in Perl. It is this 'bot that will send SMS messages. The

implementation of this 'bot has not yet progressed to the point where it actually sends

SMS messages, but rather this is simulated through a GUI.

The default method that our system will use is the use of special keywords. An

instructor entering an urgent message into Blackboard adds the keyword “[sms]” into

the announcement. This will be noticed by the 'bot, and a SMS message sent to

students on that module. This paper describes experiments investigating whether

automatic text classification can be used to remove the necessity of labelling

announcements. The effort required to label texts is small. However, we believe that

it is worthwhile investigating machine learning approaches for the following two

reasons. First, a fully automated approach would allow all modules to be connected to

the SMS messaging 'bot whether or not the instructors are aware of or willing to use

the “[sms]” syntax. Even if an instructor is using the syntax, it is possible that they

may forget to mark up urgent announcements. It would be useful if an automatic

system could identify these and send a message anyway.

Messages are classified as either low priority, where no SMS message need be sent,

and high priority, where a message should be sent. In the remainder of this paper we

view the task of classifying announcements as that of identifying which messages are

low priority such that no message need be sent. Because Receiver Operating

Characteristic Curves are used to visualise results, we arbitrarily abstract this

classification task as that of deciding that a message is of low priority and no message

need be sent. In this abstraction a true accept is a true low priority message identified

as such, a true reject a high priority message correctly identified. Two types of error

can occur; a false accept is a high priority message identified as low priority, and a

false reject is a low priority message identified as high priority. The two types of

errors will not be equally deleterious. A false reject incurs expense and inconvenience

to the student, while a false accept may result in students missing vital information.

For a fully automated system, we expect that the text classification procedure should

be biased towards reducing the number of false accepts at the cost of increasing false

rejects. Hence we should assume that messages are high priority, and send the

message unless there is strong evidence that the message truly is of low priority. If the

text classifier is to be used to catch accidentally unlabelled high priority messages,

then the the 'bot should only send a message in the case where an announcement is

unlabelled, but there is strong evidence that the message is of high priority.

Over and above the application to MLEs and SMS messages, another motivation for

this research is to measure the limit of “background knowledge free” artificial

intelligence techniques. The text classifier used does not use any information about

announcements and teaching other than the content of a set of announcements. A

skilled human attempting to classify announcements would bring a large amount of

both common sense knowledge and domain (teaching and education) knowledge to

bear on the task. Comparing and contrasting human and machine performance on

tasks such as that described in this paper will hopefully throw light on the importance

of such knowledge in short text classification.

118

3 Experimental methods

In this paper we detail experiments that will investigate whether it is possible to use

Machine Learning based text classification techniques to identify high and low

priority announcements on Blackboard.

The classifier used in our experiments is a standard naive Bayes' classifier (NBC).

The use and derivation of the NBC is described in [5]. The implementation of the

NBC used in this research is currently being used extensively in research on

authorship attribution [3]. The NBC was selected for experiment as unpublished

research into text suggests that the NBC performs better than other popular text

classifiers on short texts.

If we assume that w

is the i

word from an announcement, and p( w

| P ) is the

probability of w

appearing in an announcement of priority P, then we assign a

priority to an announcement using (1).

∏

∈

highlowP

PwpP

},{

)|(maxarg (1)

Note that (1) makes both the naive Bayes assumption of independence between

evidence, and also assumes that low and high priority messages have equal prior

probability. This latter assumption is true in our training sets which include equal

numbers of low and high priority announcements.

As of yet we have not established the acceptable error rates for potential users of the

system. As a substitute benchmark for evaluating the accuracy of any such system, we

have evaluated the accuracy of human classification of messages. Both of the first two

authors (RC and MB) created two files of announcements each. The files all

contained 10 high priority announcements and 10 low priority announcements,

making a total of 80 announcements. These were a combination of real

announcements taken from our own Blackboard sites, and fictitious announcements

made up for this experiment.

The announcement files were anonymised by stripping (using a program) the labelling

of high and low priority, and randomly reordering the messages. Each of RC and MB

then classified each other's messages. Note that there was no “training” data, and

hence we were using our knowledge of education and common sense to classify these

messages. We were aware that each file had ten high priority messages and ten low

priority messages, making classification slightly easier than if we were not aware of

this. The reason for measuring human accuracy on this task is because we expect that

most instructors would be prepared to accept a human as being sufficiently accurate to

judge whether SMS messages should be sent.

The first automated experiment was to use a NBC on all 80 announcements, using 10-

fold cross-validation. Experiments were also performed to measure the accuracy of

the classifier on announcement training sets of 20, 30, 40, 50, 60, 70, and 80

announcements. A 20 announcement training set can be constructed by simply

choosing 10 random announcements each for the two authors. Note that as we only

119

have 80 announcements in total, the 100 randomly sampled 80 announcement training

sets all had the same 80 announcements. The results for different training sets still

differed due to selection of announcements in the 10-fold cross-validation. These

experiments were intended to show whether prediction is more accurate when text

classifiers are trained using a single instructor's announcements, and also how fast the

accuracy of the classifier improves as the amount of training data increases. The latter

results should allow a prediction as to whether performance of the text classification

system would improve significantly given additional training data.

We have previously discussed biasing the classifier to change the balance between the

two types of error. When using (1) an announcement is classified as low priority when

the product of p( w

| low priority ) is greater than the product of p( w

| high priority )

and vice versa. This is equivalent to classifying an announcement as low priority

when the ratio in (2) is greater than 1, and classifying as high priority when the ratio

is lower than 1.

∏

highwp

lowwp

ratio

)|(

(2)

We can raise the strength of evidence required to classify an announcement as low

priority (and hence not send an SMS message) by requiring this ratio to be greater

than a number other than 1.0. If we raise the required threshold to 1.05, then we raise

the strength of evidence required to classify a message as low priority. If we lower the

ratio to 0.9, then we reduce the amount of evidence required to classify a message as

low priority. In this latter case it is possible that we would classify an announcement

as low priority even though we have greater evidence that the announcement is high

priority. As this threshold is adjusted up and down the balance between the false

acceptance rate (FAR) and the true acceptance rate (TAR) will change. Note that we

could also have adjusted the amount of evidence required to conclude that an

announcement is low priority by defining a risk function and minimising risk rather

than maximising probability, or by assigning unequal priors to the two priorities. This

method of adjusting the standard of evidence required for classification has been

previously used in experiments on authorship attribution, but have not yet been

submitted for publication [2].

For each threshold value, the TAR and the FAR can be measured. By allowing the

threshold to vary across all possible values, a number of (FAR,TAR) pairs can be

gathered. Some examples can be seen in Table 1. These (FAR,TAR) pairs are plotted

to create a Receiver Operating Characteristic curve [8] summarising the accuracy of

the system for all values of this threshold. Any particular value for this threshold will

give us TAR and FAR values for that threshold. We plot a ROC curve by mapping the

FAR values to the x-axis, and the TAR values to the y-axis.

120

4 Results

In the human classification experiments, we achieved 0.8 (80%) accuracy. There were

16 misclassified announcements out of the total 80, with there being exactly 8 false

accepts, and 8 false rejects. This gave as a FAR of 0.2, a FRR of 0.2, and hence an

equal error rate (EER) of 0.2.

When the NBC was used for the full set 80 announcements , the accuracy was 0.65.

The EER was 0.275. The accuracy of prediction for the files written by one author

were 0.70 for announcements written by RC, and 0.625 for announcements written by

MB. This compares with an average of 0.64 for training sets of 40 announcements

selected from those written by either RC or MB. Figure 1 shows the results of

experiments for training sets of different sizes.

Table 1.Thresholds and Error Rates

Threshold FAR FRR

1.028 0.050 0.800

0.991 0.275 0.275

0.945 0.800 0.050

There were 1226 distinct words in total in the 80 sample announcements. The words

most indicative of each class of announcement were extracted according to the

probability ratios in (3).

)

)|(

max(

highwordp

lowwordp

highwordp

ratio=

(3)

The top 30 such words are shown in Table 2.

Table 2. Most Indicative Words

Word Indicates Ratio

deadline High 40.3148

3 High 36.2832

two High 32.2518

presentation High 28.2204

file Low 27.7831

hand High 24.1888

timetable High 20.1574

monday High 20.1574

discussion Low 19.845

take Low 19.845

121

Note the performance decreasing for the full 80 instances. This was unexpected as, all

else being equal, more training data usually results in higher accuracy. Investigating

the raw data shows that of the 100 experiments, there were 56 results with 0.65

accuracy, and 24 results with 0.687.

Fig. 1. Classification Accuracy Versus Training Set Sizes.

Fig. 2. Receiver Operating Characteristic Curve for Classification of All Announcements.

Figure 2 shows the Receiver Operating Characteristic Curve obtained when the cut-

off for the probability ratio for accepting an announcement as low priority is allowed

to range across all possible values.

Finally we extract some useful information from the raw data used in Figure 2.

Arbitrarily choosing 0.05 as an “acceptable error rate”, we look for the cut-off values

that give us an 0.05 FAR, and a 0.05 false reject rate (FRR), and the equal error rate

(EER).

10 15 20 25 30 35 40 45 50 55 60 65 70 75 80

0.590

0.595

0.600

0.605

0.610

0.615

0.620

0.625

0.630

0.635

0.640

0.645

0.650

0.655

0.660

0.665

0.670

0.675

0.680

Training set size

Accuracy

0.000 0.100 0.200 0.300 0.400 0.500 0.600 0.700 0.800 0.900 1.000

0.000

0.100

0.200

0.300

0.400

0.500

0.600

0.700

0.800

0.900

1.000

False Accept Rate

True Accept Rate

122

5 Conclusions

The accuracy of automated classification is currently insufficient for a fully

automated system with no input from the tutor as to which announcements are sent to

students. This is not surprising given the short length of most announcements. In the

experiments showing how performance improved with increasing amounts of training

data the performance appears to still be steadily improving, although the accuracy for

the single data point for 80 announcements does confuse this issue. Also, it is not

unusual for automated systems to perform worse than humans and yet prove to be of

use. This can be due to cost implications, or if there is a problem getting tutors to

manually label announcements. Language translation systems are an example of a

technology where although human translators produce results of much higher quality,

they still have many uses. Either as a “first pass” later improved by human translators,

or in situations where a human translator would be too expensive and slow, such as

when browsing foreign language documents on the internet.

However, it is important to note that the human classification was also quite low.

Since the two authors who created the training data had taught together on a number

of modules over some years, higher accuracy near to 100% might have been expected.

The fact that only 80% accuracy was achieved suggests that the content of the

announcements is insufficient for very high accuracies, no matter how much

intelligence and background knowledge is bought to the task.

It was noted that many of the most indicative words had meaning in the context of the

module, rather then being generally applicable across many modules. This is a serious

problem, as if the system needs to be trained on a module by module basis, even the

80 announcements used here then many announcements will be required before the

system starts working. This is a strong indication that background-knowledge free

text classification will not be applicable in this domain.

Hence both human classification, applying full human intelligence and background

knowledge, and a good machine classification technique indicate that announcement

classification is unlikely to be useful. Our conclusions are that there does not appear

to be enough information in announcements themselves to classify correctly, and

larger amounts of context knowledge will be necessary.

Despite these negative results, several enhancements to the classifier are planned,

most of which are fed by parallel research into author attribution. In particular,

information fusion [4] approaches have shown promise in improving the confidence

we can have in automated authorship attributions, if not the total accuracy. Like much

technology, we would expect steady improvements in the performance of the

automated system, while human requirements and performance are likely to remain

static. We are encouraged by the comments of Christensen et al (2001) who argue that

technology advances faster than user requirements. However, our results from human

classification do call into question whether any amount of technology will really be

able to solve this problem.

Whether sending a SMS text that should not be sent, or failing to send an SMS text

that should not be sent is a greater error is a question for management, not technology.

The ability to tweak the classifier to achieve different balances between false accept

and false reject means that different management policies can be implemented in the

system. This is also important given that tutors may (or may not) choose to override

123

the system with [sms] and [nosms] messages in different ways, and may prefer the

ability to customise automatic text sending according to their own preferences.

At present we are using a generic text classification method and implementation. It

may be possible to improve performance by building a recogniser that extracts

features from the text particularly relevant to the classification being performed. For

example noting text patterns such as “URGENT MESSAGE” and “must

immediately”, “no rush”, atypical use of all capitals, and other features might be

useful in improving classification.

Announcements on Blackboard and other MLEs are not the only web-based

applications where very small sections of text need to be classified. Therefore we feel

that work on short text classification, as well as the management and usability issues

concerning text classification of limited accuracy, will have wide application in many

online contexts.

REFERENCES

1. Beasley, N., & Smyth, K. 2004. Expected and actual student use of an online learning

environment: A critical analysis. Electronic Journal on E-Learning 1: 43-50.

2. Clement R. (unpublished). Verifying authorship. Unsubmitted draft paper.

3. Clement R., & Sharp, D. 2003. Ngram and Bayesian classification of documents for topic

and authorship. Literary and Linguistic Computing 18 (4): 423-47.

4. Kuncheva, L. 2004. Combining Pattern Classifiers: Methods and Algorithms. Wiley.

5. Mitchell, T. 1997. Machine Learning. McGraw-Hill.

6. Richter, U. 2001. An exploration of using web enhanced teaching and online

communication in a conventional context. Proceedings of the Fifth Romanian Internet

Learning Workshop. Romania. http://rilw.emp.paed.uni-

muenchen.de/2001/papers/richter.html

7. Stiles, M. 2000. Effective learning and the virtual learning environment. Proceedings:

EUNIS 2000 - Towards Virtual Universities. Poland.

http://www.staffs.ac.uk/COSE/cose10/posnan.html

8. Swets, J. 1988. Measuring the accuracy of diagnostic systems. Science 240: 1 285-93.

9. Ubon, A., & Kimble, C. 2004. Exploring social presence in asynchronous text-based online

learning communities (OLCs). Proceedings of the 5th International Conference on

Information Communication Technologies in Education 292-7. Greece.

124
