EARLY DETECTION OF COTS FUNCTIONAL SUITABILITY

FOR AN E-PAYMENT CASE STUDY

Alejandra Cechich

Departamento de Ciencias de la Computación, Universidad del Comahue, Neuquén, Argentina

Mario Piattini

Escuela Superior de Informática, Universidad de Castilla-La Mancha, Ciudad Real, España

Keywords: Component-Based System Assessment, COTS co

mponents, Software Quality.

Abstract: The adoption of COTS-based development brings with it many challenges about the identification and

finding of candidate components for reuse. Particularly, the first stage in the identification of COTS

candidates is currently carried out dealing with unstructured information on the Web, which makes the

evaluation process highly costing when applying complex evaluation criteria. To facilitate the process, in

this paper we introduce an early measurement procedure for functional suitability of COTS candidates, and

we illustrate the proposal by evaluating components for an e-payment case study.

1 INTRODUCTION

COTS-Based System Development is now

recognised as the way forward in building software

architectures that can operate in advanced

distributed, intranet, and Internet environments. In

essence, using components to build systems reduces

complexity because composers do not need to know

how a component works internally. They only need

to know what the component is and the services it

provides. Ideally, most of the application

developer’s time is spent integrating components.

Components become unwieldy when combined and

re-combined in large-scale commercial applications.

What are needed are ensembles of components that

provide major chunks of application functionality

that can be snapped together to create complete

applications.

COTS component filtering is to decide which

com

ponents should be selected for more detailed

evaluation. Decisions are driven by a variety of

factors – foremost are several design constraints that

help define the range of components. So a balance is

struck, depending upon the level of abstraction,

complexity of the component, goals and criteria, and

so forth. Some methods include qualifying

thresholds for filtering. For example, during the

activity "Collect Measures" of the COTS

Acquisition Process (Ochs et al., 2000), data

according to a measurement plan are collected on a

set of COTS software alternatives. Data are used in

the filtering activity to eliminate those COTS

alternatives that are unacceptable for use.

Identification of COTS candidates is a complex

activ

ity itself. It implies not only dealing with an

impressive number of possible candidates but also

with unstructured information that requires a careful

analysis. In this context, some proposals use

description logics to develop an ontology for

matching requested and provided components

(Braga et al., 1999; Pahl, 2003); others suggest

extending the identification stage with a learning

phase, which provides support to the COTS

component discovery process (Jaccheri and

Torchiano, 2002). Some other approaches try to

measure the semantic distance between required and

offered functionality (Alexander and Blackburn,

1999; Jilani and Desharnais, 2001) but these

measures usually need detailed information as input

to the calculations.

In addition to learning and classification issues, a

filterin

g process is concerned with the pre-selection

of candidates. It actually takes place by matching

several properties of COTS components, including

some inexact matching. Moreover, there are some

cases where goals cannot be entirely satisfied

without considerable product adaptation and other

Cechich A. and Piattini M. (2005).

EARLY DETECTION OF COTS FUNCTIONAL SUITABILITY FOR AN E-PAYMENT CASE STUDY.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 11-18

DOI: 10.5220/0002507700110018

 SciTePress

cases where these goals must be resigned to match

product features (Alves and Filnkestain, 2002);

(Cooper and Chung, 2002).

As a possible improvement, the Six Sigma

approach has been suggested selecting packaged

software (Tayntor, 2002); however the evaluation

mainly relies on the information provided by demos

and additional documentation of the software. Then,

the lack of measures makes this process perfectible.

Along these lines, our approach based on Six-

Sigma precepts, focuses on fact-based decisions,

teamwork, and measurement as a way of driving the

identification and filtering process (Cechich and

Piattini, 2004a; Cechich and Piattini 2004b).

We refer to a component-based system as a

system that uses at least one component in

conjunction with other components, legacy systems,

and other pieces of software – including COTS

components – to satisfy user’s requirements. This

concept is introduced to emphasize the fact that the

output from the system satisfies the user’s

requirements by using the functionality supplied by

at least one COTS component. Particularly, we

consider functional suitability as the main aspect to

be measured; however, measures should be

expressed in such a way that calculation is possible

at early stages.

Our proposal aims at improving the filtering

process by performing three steps: (1) a

“commitment” step, which produces a committed

required specification of a component; (2) a “pre-

filtering” step, in which COTS candidates are pre-

selected according to their functional suitability; and

(3) a “filtering” step, in which architectural

semantics adaptability produces an indicator of

stability that serves as a basis for the final candidate

filtering. In this paper, we particularly address the

second step (“pre-filtering”), in which functional

suitability measures are calculated and analysed.

Metrics for COTS based systems are emerging

from the academic and industrial field (Martín-Albo

et al., 2003). However, many of these definitions do

not provide any guideline or context of use, which

makes metric’s usability dependable on subjective

applications. Measures are not isolated calculations

with different meanings; on the contrary, capability

of measures is strongly related to the process of

calculating and providing indicators based on the

measures. Our approach intends to define a filtering

process in which measures are included as a way of

providing more specific values for comparison. At

the same time, the process guides the calculation, so

ambiguity is decreased.

Among other relationships, resulting measures

are related to the artefact to be measured. In our

approach, the artefact is expressed as functionality

required by a particular application, and

functionality offered by COTS candidates. Generally

speaking, both cases are subject to analysing

information that is modelled and weighted by people

– composers or integrators on one side, and

component’s suppliers on the other. Different

interpretations, perceptions, and judgements are then

affected by the expressiveness of information.

Nevertheless, our comparisons are abstract-level

definitions, which allow us to customize the filtering

process by instantiating the calculation procedure

according to different contexts of use.

Since information needed to compute the

measures depends on how COTS suppliers

document COTS component’s functionality (Bertoa

et al., 2003), and how requirements are specified, in

this paper we illustrate how metrics might be

calculated by measuring functional suitability on

COTS candidates for an E-payment case study.

In section 2 we briefly introduce our compact

suite of measures (Cechich and Piattini, 2004c) that

should be used during the pre-filtering process.

Then, section 3 shows how measures might be

applied to our case and provides some discussion. A

final section addresses conclusions and topics for

further research.

2 MEASURING FUNCTIONAL

SUITABILITY

In the previous section, we have emphasized the fact

that a system should satisfy the user’s requirements

by using the functionality supplied by at least one

COTS component. Then, given a specification S

for

an abstract component type C, a candidate

component K to be a concrete instance of C must

conform to the interface and behaviour specified by

. Mappings in S

, which represent the different

required functionalities, are established between

input and output domains. We focus on

incompatibilities derived from functional differences

between the specification in terms of mappings of a

component K

) and the specification in terms of

mappings of S

Our measures have been defined to detect

domain compatibility as well as functional

suitability. Let us briefly clarify this point: domain

compatibility measures show that there are some

candidate components able to provide some

functionality. However, we cannot be certain of the

amount of functionality that is actually provided –

matching input data does not certify that output data

match too. Therefore, even a component might be

full domain compatible, there is still another set of

measures to be applied in order to determine the

functional suitability.

ICEIS 2005 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

Let us illustrate the measurement procedure by

using an credit card payment system as an example.

We suppose the existence of some scenarios

describing the two main stages of the system –

authorization and capture. Authorization is the

process of checking the customer’s credit card. If the

request is accepted, the customer’s card limit is

reduced temporarily by the amount of the

transaction. Capture is when the card is actually

debited. Scenarios will provide an abstract

specification of the mappings of S

that might be

composed of:

- Input domain:

(AID) Auth_IData{#Card, Cardholder_Name, Exp-

Date};

(CID) Capture_Idata{Bank_Account, Amount}.

- Output domain:

(AOD) Auth_Odata{ok-Auth};

(COD)

Capture_Odata{ok_Capture, DB_Update}.

- Mapping: {AID → AOD};{CID → COD}

Suppose we pre-select two components to be

evaluated, namely K

and K

respectively. A typical

situation for inconsistency in the functional

mappings between S

, S

and S

is illustrated in

Figure 1, where dashed lines indicate (required)

mappings with respect to S

, and the solid lines are

(offered) mappings with respect to S

(grey) and S

(black). Note that the input domain of the

component K

does not include all the values that the

specification S

requires, i.e. the capture

functionality is not provided. Besides, the input

domain of the component K

includes more values

than the required by S

, although the mapping

satisfies the required functionality. We should also

note that there is another functionality provided by

, i.e. {Taxes → Statistics}, which might inject

harmful effects to the final composition.

Figure 1: Functional mappings of S

and S

Table 1: Description of Functional Suitability measures

Measure Id. Description

Component-Level

Compatible

Functionality

The number of functional

mappings provided by S

and

required by S

in the scenario S

Missed Functionality

The number of functional

mappings required by S

and

NOT provided by S

in the

scenario S.

Added Functionality

The number of functional

mappings NOT required by S

and provided by S

in the

scenario S.

Component

Contribution

Percentage in which a component

contributes to get the functionality

required by S

in the scenario S.

Solution-Level

Candidate Solution

The number of components that

contribute with compatible

functionality to get the

requirements of S

in the scenario

Compatible

Functionality

The number of functional

mappings provided by SN and

required by S

in the scenario S.

Missed Functionality

The number of functional

mappings required by S

in the

scenario S and NOT provided by

SN.

Added Functionality

The number of functional

mappings NOT required by S

the scenario S and provided by

SN.

Solution Contribution

Percentage in which a solution

contributes to get the functionality

required by S

in the scenario S.

Our measures on functional suitability have

been classified into two different groups:

component-level measures and solution-level

measures. The first group of measures aims at

detecting incompatibilities on a particular

component K, which is a candidate to be analysed.

However, it could be the case that we need to

incorporate more than one component to satisfy the

functionality required by the abstract specification

. In this case, the second group of measures

evaluates the functional suitability of all components

that constitute the candidate solution.

•AID

•CID

dom S

•Taxes

dom S

•AOD

•COD

ran S

• Statistics

ran S

(i)S

(i)

Table 1 lists our suite of functional suitability

measures. We refer the reader to (Cechich and

Piattini, 2004c) for their formal definition. Solution-

level metrics are listed here for completeness

reasons, since our case study only needs to apply

component-level measures; i.e. combination of

EARLY DETECTION OF COTS FUNCTIONAL SUITABILITY FOR AN E-PAYMENT CASE STUDY

components from the marketplace is not necessary to

get the required functionality, therefore a solution-

level analysis is not required.

3 MEASURING COTS

CANDIDATES: A CASE STUDY

Scenarios describing the two main stages of a credit

card payment, as we introduced in the previous

section, represent here a credit card (CCard)

payment system, which provide an abstract

specification of the input (AID, CID) and output

domains (AOD, COD) of a component C, and their

corresponding mappings.

After a quick browse on the Web as a COTS

repository, we chose COTS components catalogued

by the ComponentSource organization

(www.componentsource.org) as members of the

“Credit Card Authorization” group. Following, we

introduce some examples of our analysis.

Firstly, we chose one component –

AcceptOnline by Bahs Software – as a candidate to

provide the required functionality. Properties of

AcceptOnline are grouped into the following

classes: merchant fields, transaction fields, and

response fields. From those classes, we identify:

• transaction_type: This field identifies the type

of transaction being submitted. Valid

transaction types are: “CK” (System check),

“AD” (Address Verification) “AS”

(Authorization), “ES” (Authorization and

Deposit), “EV” (Authorization and Deposit with

Address Verification), “AV” (Authorization

with Address Verification), “DS” (Deposit), and

“CR” (Credit).

• cc_number: The credit card number to which

this transaction will be charged.

• cc_exp_month and cc_exp_year: The numeric

month (01-12) and the year (formatted as either

YY or CCYY) in which this credit card expires.

• billing phone: The shopper’s telephone number.

• grand total: The total amount of the transaction.

• merchant email: This is the Email address of the

merchant.

• order type: This field determines which fields

are used to validate the merchant and/or hosting

merchant.

• transactionStatus: Transaction Status. Valid

values are: G - Approved, D -Declined, C -

Cancelled, T - Timeout waiting for host

response, R – Received.

Table 2: Required Fields by Transaction Type

Field CK AD AS ES EV AV DS CR

authorization Y

billing_address1;

billing address2

Y Y Y

billing_zip Y Y Y

billing_pone Y Y Y Y Y

cc_number;

cc_exp_month;

cc_exp_year

counter Y Y Y Y Y Y

debug Y Y Y Y Y Y Y

grand_total Y Y Y Y Y Y

merchant_email Y Y Y Y Y Y Y

order_numer Y Y

…. …

Methods of AcceptOnline are specified in terms

of their main focus and required input. Particularly,

the SendPacket method is used to send the

transaction info to the ECHOOnline server, and

required properties should be filled as shown in

Table 2 (requirements for CR are partially listed).

From the AcceptOnline (AOnline) description

above, we might derive the following mappings

related to our authorization (AS) and capture (DS)

required functionality:

– Input domain:

(AOnline.ASI) {billing_phone, cc_number,

cc_exp_month, cc_exp_year, counter, debug, grand

total, merchant_email};

(AOnline.DSI) {authorization, cc_number,

cc_exp_month, cc_exp_year, counter, debug,

grand_total, merchant email}.

– Output domain:

(AOnline.ASO) {TransactionStatus};

(AOnline-DSO) {TransactionStatus}.

– Mapping:

{AOnline.ASI → AOnline.ASO;

AOnline.DSI → AOnline.DSO} .

There are also other possible functional

mappings as follows:

{AOnline.ADI → AOnline.ADO;

AOnline.EVI → AOnline.EVO;

AOnline.AVI → AOnline.AVO;

AOnline.CRI → AOnline.CRO},

which represent address verification,

authorization and deposit with address verification,

and so forth.

ICEIS 2005 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

For brevity reasons, we assume here that input

domain compatibility measures have indicated that

the AcceptOnline component is a candidate for

further evaluation – after comparing AID, CID

(from specification S

) to AOnline.ASI and

AOnline.DSI. We should note that values of the

input domain do not exactly match: billing_phone is

used instead of cardholder_name to identify

cardholders; and merchant_email is used for

Bank_id. Similarly, ok_Auth, ok_Capture, and

BD_Update might correspond to the different values

of TransactionStatus. However, in all cases

matching is possible since purpose is similar. Then,

similarity is basically determined by analysing

semantics of concepts with respect to their use.

Now, computing measures from Table 1

produces the following results:

= 2; MF

= 0; AF

= 4; and CC

= 1

These results indicate that the AcceptOnline

component has proved being 100% (CC

= 1)

functionally suitable, and thus a candidate for further

evaluation during the filtering process – for example

by analysing size and complexity of adaptation.

Measures also indicate that there are four added

functions (AF

= 4), which deserve more careful

examination.

Let us analyse a second component from the

same group, i.e. catalogued as a member of “Credit

Card Authorization”. This time, we have chosen the

Energy Credit Card component by Energy

Programming as the candidate to provide the

required functionality.

The Energy Credit Card component provides two

functions described as follows:

1. Functionality “Extract_Card_Data”, which

provides the ability to decode the magnetic data on

the swipe card; and

2. Functionality “Validate_Card_Details”, which

provides the ability to validate keyed entry data from

other systems.

To accomplish both functionalities, input data is

required as follows:

Input:

{surname, initials, salutation, card_number,

card_type, startDate, expiryDate, issue}

Output: {error_number, error_text}

As we easily can see, this second component

does not provide the required functionality of our

scenario. Although the component is classified as a

member of the “Credit Card Authorization” group,

functionalities show that only validation of credit

card data is provided. Therefore, calculating

measures from Table 1 would produce the following

results:

= 0; MF

= 2; AF

= 0; and CC

= 0

These results indicate that the Energy Credit

Card component is 0% (CC

= 0) functionally

suitable, and we should not invest more time and

effort in more evaluation. However, note that

functionalities provided by the Energy Credit Card

component might be part of the required

functionality associated to the “Authorization”

scenario. To make this point explicit, if necessary,

evaluators should expose the different functionalities

through a more detailed description of the required

scenario; hence calculation of partially satisfied

functionality would be possible. In our example,

“Authorization” could be expressed as “Credit Card

Validation” and “Amount Authorization”. In this

way, calculating measures for the Energy Credit

Card component would result in:

= 1; MF

= 2; AF

= 0; and CC

= 0.33

These results would indicate that the Energy

Credit Card component might be a candidate to be

combined along with other components to provide

the required functionality (and not necessarily

discharged). Of course, decisions on how detailed an

scenario should be depend on requirements on a

particular domain; i.e. components that do not

provide the whole authorization procedure might not

be useful in a particular case. We suppose here that

balanced requirements among all stakeholders have

been considered to provide the appropriated

scenarios (Cechich and Piattini, 2004b).

Now, let us consider a third component for our

evaluation procedure: the PaymentCardAssist

component by Aldebaran, that supports e-mail

verification, event logging, data encryption, file

compression, and payment card detail validation.

The PaymentCard object within the

DeveloperAssist Object Library validates payment

card (credit, debit and charge card) information. The

PaymentCard object does not provide authorization

or clearing functionality, but rather provides a means

to validate payment information entered by a site

visitor, before pursuing a full authorization. After

considering detailed data to be validated, we can see

that our measures will result as:

= 0; MF

= 2; AF

= 4; and CC

= 0;

or after considering a more detailed scenario, in

which card data validation is made explicit,

measures will result as:

EARLY DETECTION OF COTS FUNCTIONAL SUITABILITY FOR AN E-PAYMENT CASE STUDY

= 1; MF

= 2; AF

= 4; and CC

= 0.33

Finally, let us consider another component from

the same group – the CCProcessing component by

Bahs Software. It supports the authorization,

settlement (capture) , and credit/refund operations.

“Authorization” is divided into

“PerformAuthorization” and “AddToBatch”

operations, meanwhile “Capture” corresponds to the

“PerformSettlement” operation. Transaction

descriptions are presented as follows:

• “PURCHASE”: Standard purchase

transaction (In "card not present" mode);

• “PURCHASE_TRACK1”: Purchase

transaction in "card present" mode. Track1

property should be set for such transaction

type.

• “VALIDATE_CARD”: Card authentication

to determine only if a card has been reported

lost or stolen.

• “REVERSE_AUTHORIZATION”: On-line

Authorization Reversal.

• “REVERSE_SETTLEMENT”: Store &

Forward Authorization Reversal.

• “CREDIT”: Credit/refund operation.

By analysing input and output domains of

CCProcessing, we have identified mappings that

cover the functionalities described by our scenario.

Considering “credit” and address validation (part of

“validate card”) as additional functionality (reverse

authorization and reverse settlement might be

considered as part of a “Cancel” operation),

measurement results might be expressed as:

= 2; MF

= 0; AF

= 2; and CC

= 1

A similar treatment was applied to evaluate the

other components in the group. From 22

components, we consider 12 for analysis since the

other 10 components differ only in terms of their

implementations, preserving the same functionality.

Results of our calculations are shown in Table 3.

Note that only four components provide the

functionality required by our scenario. This fact

would indicate that those components are pre-

selected for more evaluation, since they are 100%

functionally suitable. A special remark should be

made on values assigned to the ComponentOne

Studio Enterprise: this component is a combination

of four individual components that support

reporting, charting, data manipulation, and user

interface capabilities for .NET, ASP.NET, and

ActiveX applications. As readers easily can see, this

component essentially differs from the others in the

group; however it is classified as a “Credit Card

Authorization” component. For this reason,

additional functionality (AF

) has not been scored.

Table 3: Measurement results for components in the

“Credit Card Authorization” category

Component CF

AcceptOnline 2 0 4 1

CCProcessing 2 0 2 1

CCValidate 0 2 0 0

CreditCardPack 0 2 0 0

EnergyCreditCard 0 2 0 0

IBiz 2 0 2 1

InaCardCheck 0 2 0 0

IPWorks 2 0 1 1

LuhnCheck 0 2 0 0

PaymentCardAssist 0 2 4 0

SafeCard 0 2 0 0

ComponentOneStudio 0 2 ** 0

3.1 Discussion

Scenarios have been widely used during design as a

method to compare design alternatives and to

express the particular instances of each quality

attribute important to the customer of a system.

Scenarios differ widely in breadth and scope, and its

appropriate selection is not straightforward. Our use

of scenarios is a brief description of some

anticipated or desired use of a system. We

emphasize the use of scenarios appropriated to all

roles involving a system. The evaluator role is one

widely considered but we also have roles for the

system composer, the reuse architect, and others,

depending on the domain.

The process of choosing scenarios for analysis

forces designers to consider the future uses of, and

changes to, the system. It also forces to consider

non-functional properties that should be properly

measured during the COTS selection process. In

some cases, this diversity of concerns produces fine-

grained functionality described by scenarios, but

coarse-grained functionality might be described as

well.

As a consequence, our measures are affected by a

particular scenario’s description since calculation

refers to the number of functions – without further

discussion about their particular specification. For

example, in our CCard system, “validation with

address” and “reverse authorization” could be

considered as part of an ordinary credit card

authorization process. Assuming that, scores for

added functionality (AF

) would be decreased (only

“credit” would be considered as added

functionality). As another example, we could choose

a more detailed description of the functionality and

ICEIS 2005 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

decompose “Authorization” into “Credit Card

Validation” and “Credit Card Authorization”. In this

case, calculation of provided and missed

functionality would be different and contribution

(CC

) would show which components partially

contribute to reach credit card authorization.

Table 4 shows our measures considering the last

two assumptions: (1) including validation

with/without address and reverse authorization as

part of the procedure, and (2) splitting

“Authorization” into two processes – validation and

authorization itself. By comparing scores from Table

3 and Table 4 we illustrate the importance of

standardizing the description of required

functionality as well as providing a more formal

definition of scenarios.

Also, note that components providing all

required functionality remain unchanged on both

tables: only four components provide authorization

and capture as required in our case (4 / 12 = 33%). It

would indicate that searching a catalogue by

category is not enough to find appropriated

components. In our example, better categorizations

would help distinguish credit card validation from

authorization. Moreover, a better categorization

would help avoid that a component that does not

provide any functionality (accordingly to the

category), like ComponentOneStudio, be catalogued

as a member of any of those classes.

Table 4: Measurement results after changing scenarios

Component CF

AcceptOnline 3 0 1 1

CCProcessing 3 0 1 1

CCValidate 1 2 0 0.33

CreditCardPack 1 2 0 0.33

EnergyCreditCard 1 2 0 0.33

IBiz 3 0 1 1

InaCardCheck 1 2 0 0.33

IPWorks 3 0 0 1

LuhnCheck 1 2 0 0.33

PaymentCardAssist 1 2 4 0.33

SafeCard 1 2 0 0.33

ComponentOneStudio 0 3 *** 0

Our measures indicate that four components are

candidates to be accepted for more evaluation, i.e.

the components are functionally suitable but there is

some additional functionality that could inject

harmful side effects into the final composition.

Identifying and quantifying added functionality are

subject to similar considerations – the number of

functions essentially is a rough indicator that might

be improved by weighting functionality; i.e. clearly

the four functions added by the component

PaymentCardAssist are different in scope and

meaning from the other added functions. However,

just counting functions would help decide on which

components the analysis should start.

Table 4 also shows that there are some candidates

which are able to provide some required

functionality – “credit card validation”. But making

this functionality more visible not necessarily

indicate the type of validation that actually is taking

place, for example whether or not a MOD10/Luhn

check digit validation is carried out. Our measures

are just indicators of candidates for further

evaluation, on which additional effort might be

invested. Nevertheless, our measures do not detect

the best candidates at a first glance but a possible

interesting set. A process guides calculations so

ambiguity is decreased (Cechich and Piattini,

2004a), but committed scenarios still depend on

particular system’s requirements.

Besides, there are another types of analysis the

component should be exposed before being eligible

as a solution – such as analysis of non-functional

properties, analysis of vendor viability, and so forth

(Ballurio et al., 2002). Our set of measures are only

providing a way of identifying suitable components

from a functional point of view. We might provide a

more precise indicator when calculating the

maintenance equilibrium value as introduced in

(Abts, 2002): “Maximise the amount of functionality

in your system provided by COTS components but

using as few COTS components as possible”.

A final remark brings our attention into the

necessity of balancing required and offered

functionality during COTS-based developments.

After analysing candidates, we might also change

our expectations on finding appropriated

components. In this case, we could potentially resign

most of our expectations on a particular requirement

letting offered services prevail. For example, we

could keep some of the alternative services resigning

others whether COTS candidates are hard to find or

adapt. An additional measure on modifiability of

goals (Cechich and Piattini, 2004b) would help

detect the degree in which certain functionality can

be changed when selecting COTS components. Of

course, we could also decide not to select

components at all, and build a solution from scratch.

4 CONCLUSION

We have briefly presented some measures for

determining functional suitability of COTS

candidates by applying the calculations on a case

study. It showed how COTS information may be

mapped onto our measurement model leading to an

early value for decision making.

EARLY DETECTION OF COTS FUNCTIONAL SUITABILITY FOR AN E-PAYMENT CASE STUDY

However, differences in COTS component

documentation make evaluation harder. Our

application clearly remarks the importance of

standardising COTS component documentation and

analysing the diverse ways of structuring COTS

component’s information to facilitate functional

matching detection. However, successful matching

also depends on how functional requirements are

specified. Then, a formal procedure for

identification of candidates should be defined to

make the process cost-effectively.

Constraints on the component’s use and

constraints relative to a context might be also useful

to be considered. These aspects would indicate that

providing more complex classifications, such as

taxonomies of components, would help catalogue

them in a marketplace. Additionally, more complex

descriptions might be provided by using ontologies

and contexts. Along these lines, our future work

aims at defining some guidelines and hints on the

searching and learning process of COTS component

candidates.

ACKNOWLEDGMENTS

This work was partially supported by the CyTED

project VII-J-RITOS2, by the UNComa project

04/E059, and by the MAS project supported by the

Dirección General de Investigación of the Ministerio

de Ciencia y Tecnología (TIC 2003-02737-C02-02).

REFERENCES

Abts C. COTS-Based Systems (CBS) Functional density -

A Heuristic for Better CBS Design, 2002. In

Proceedings of the First International Conference on

COTS-Based Software Systems, Springer Verlag

LNCS 2255, pages 1–9.

Alexander R. and Blackburn M., 1999. Component

Assessment Using Specification-Based Analysis and

Testing. Technical Report SPC-98095-CMC,

Software Productivity Consortium.

Alves C. and Filkenstein A., 2002. Challenges in COTS-

Decision Making: A Goal-Driven Requirements

Engineering Perspective. In Proceedings of the

Fourteenth International Conference on Software

Engineering and Knowledge Engineering, SEKE’02.

Ballurio K., Scalzo B., and Rose L, 2002. Risk Reduction

in COTS Software Selection with BASIS. In

Proceedings of the First International Conference on

COTS-Based Software Systems, ICCBSS 2002,

Springer-Verlag LNCS 2255 , pp. 31-43.

Bertoa M., Troya J., and Vallecillo A., 2003. A Survey on

the Quality Information Provided by Software

Component Vendors. In Proceedings of the ECOOP

QAOOSE Workshop.

Braga R., Mattoso M., and Werner C., 2001. The use of

mediation and ontology for software component

information retrieval. In Proceedings of the 2001

Symposium on Software Reusability: putting software

reuse in context, ACM Press, pp. 19-28.

Cechich A. and Piattini M., 2004a. Managing COTS

Components using a Six Sigma-Based Process. In

Proceedings of the 5th International Conference on

Product Focused Software Process Improvement,

PROFES 2004, volume 2009 of LNCS, Springer-

Verlag, pp.556-567.

Cechich A. and Piattini M., 2004b. Balancing

Stakeholder’s Preferences on Measuring COTS

Component Functional Suitability. In Proceedings of

the 6th International Conference on Enterprise

Information Systems, ICEIS 2004, pp. 115-122.

Cechich A. and Piattini M., 2004c. On the Measurement

of COTS Functional Suitability. In Proceedings of the

3 International Conference on COTS-based Software

Systems, ICCBSS 2004, volume 2959 of LNCS,

Springer-Verlag, pp. 31-40.

Cooper K. and Chung L., 2002. A COTS-Aware

Requirements Engineering and Architecting

Approach: Defining System Level Agents, Goals,

Requirements and Architecture, Technical Report

UTDCS-20-02, Department of Computer Science, The

University of Texas at Dallas.

Jaccheri L. and Torchiano M., 2002. A Software Process

Model to Support Learning of COTS Products.

Technical Report, IDI NTNU.

Jilani L. and Desharnais J., 2001. Defining and Applying

Measures of Distance Between Specifications. IEEE

Transactions on Software Engineering, 27(8):673—

703 .

Martín-Albo J., Bertoa M., Calero C., Vallecillo A.,

Cechich A., and Piattini M., 2003. CQM: A Software

Component Metric Classification Model. In Proc. of

the 7th ECOOP Workshop QAOOSE 2003, pages 54-

60, Darmstadt, Germany.

Ochs, D. Pfahl, G. Chrobok-Diening, and Nothhelfer-

Kolb, 2000. A Method for Efficient Measurement-

based COTS Assessment and Selection - Method

Description and Evaluation Results. Technical Report

IESE-055.00/ E, Fraunhofer Institut Experimentelles

Software Engineering.

Pahl C., 2003. An Ontology for Software Component

Matching. In Proceedings of the Sixth International

Conference on Fundamental Approaches to Software

Engineering, volume 2621 of LNCS, Springer-Verlag,

pp. 6-21.

Tayntor C., 2002. Six Sigma Software Development.

Auerbach Publications.

ICEIS 2005 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION
