AGENT-BASED INTRUSION DETECTION SYSTEM FOR

INTEGRATION

Jianping Zeng, Donghui Guo

Department of Physics, Xiamen University, Xiamen, Fujian, P.R. China

Keywords: Intrusion Detection, Agent-based, KQML, IDMEF.

Abstract: More and more application services are provided and distributed over the Internet for public access.

However, the security of distributed application severs is becoming a serious problem due to many possible

attacks, such as deny of service, illegal intrusion, etc. Because of weakness of the firewall systems in

ensuring security, intrusion detection system (IDS) becomes popular. Now, many kinds of IDS systems are

available for serving in the Internet distributed system, but these systems mainly concentrate on network-

based and host-based detection. It is inconvenience to integrate these systems to distributed application

servers for application-based intrusion detection. An agent-based IDS that can be smoothly integrated into

applications of enterprise information systems is proposed in this paper. We will introduce its system

architecture, agent structure, integration mechanism, and etc. In such an IDS system, there are three kinds of

agents, i.e. client agent, server agent and communication agent. This paper is also to explain how to

integrate agents with access control model for getting better security performance. By introducing standard

protocol such as KQML, IDMEF into the design of agent, our agent-based IDS shows much more flexible

for built in different kinds of software application system.

1 INTRODUCTION

Many applications, such as e-business, remote

education and Internet-based design, are becoming

popular. As you can see, it becomes a trend to

deploy software application systems in the Internet

to make full use of its all kinds of advantages.

However, because the Internet is an open society so

that anyone can access the resource on it, then the

application may confront with all kinds of attacks or

intrusions, such as Deny of Service (DoS), port scan,

illegal intrusion by hacking user information, etc.

Of all these security events, illegal intrusion is a

more serious issue. But standard security

deployments such as firewalls are limited in their

effectiveness because of simple access control mode

and the evolving sophistication of intrusion methods.

Once an attacker has breached the firewall, he can

roam at will through the network (Loshin, P., 2001).

This makes intrusion detection very important and

necessary. Traditionally, there have been two main

classes of IDSs: host-based and network-based

systems. A host-based IDS monitors the detailed

activity of a particular host, while network-based

IDS monitors networks of computers and other

devices such as, routers, gateways, and primarily

uses data sniffing from network traffic. Network and

host-based IDSs, can be further classified based on

two methods of detection (B. Mukherjee, T. L.

Heberlein, and K. N. Levitt, 1994): anomaly

detection and misuse detection.

However, Masquerading attack is a typical

intrusion and it can be a more serious threat to the

security of computer systems and the computational

infrastructure (Roy A. Maxion, and Tahlia N.

Townsend, 2004). By this kind of attacks, an

assailant attempts to impersonate a legitimate user

after gaining access to this legitimate user’s account.

So, the assailant can understand the exact meanings

of the information he gets, while by other kinds of

attacks, he may just get some segment of data or

encrypted data. A well-known instance of

masquerader activity is about a FBI mole (Roy A.

Maxion, and Tahlia N. Townsend, 2004). Since

masquerading attack happens exactly at application

layer, we call detection methods applied to it as

application-based intrusion detection. And

application-based detection is more difficult to

achieve for the following reasons:

(1) Data of user action are difficult to be

obtained compare to network-based and host-based

Corres

ondence: Prof. Don

hui Guo

176

Zeng J. and Guo D. (2005).

AGENT-BASED INTRUSION DETECTION SYSTEM FOR INTEGRATION.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 176-181

DOI: 10.5220/0002516401760181

 SciTePress

detection, because this kind of data can only be got

from application, while the independency of

application makes an application-based user action

more difficult to acquire.

(2) Application-based detection can affect the

performance of corresponding application due to the

extra work that should be done on data generating

and analysis.

(3) A masquerader may happen to have similar

behavioral patterns as the legitimate user of an

account to which he or she is currently logged,

therefore escaping detection and successfully

causing damage under the cover of seemingly

normal behaviour ( Coull, S.; Branch, J.; Szymanski,

B.; Breimer, E., 2003).

Fortunately, There have been several attempts to

tackle the problem of detecting masqueraders.

Several masquerade-detection algorithms, such as

Sequence-Match, IPAM, Bayes 1-Step Markov, etc

are presented by Schonlau and his colleagues (M.

Schonlau, W. DuMouchel, W.-H. Ju, A. F. Karr, M.

Theus, and Y. Vardi, 2001). However, researches on

data acquiring and overall system structure have

seldom to mention. So, in this paper, we mainly

focus on these topics.

An agent-based intrusion detection system is

proposed. Being different from other agent-based

IDSs, this system can be integrated with enterprise

information system very well. The system mainly

consists of three kinds of agents: client agent, server

agent and communication agent. The system

architecture, agent structure, integration mechanism,

etc, are mainly discussed. And we explain how to

integrate agents with access control model to

achieve better security performance.

The paper is structured as follows. Section 2

describes related work and discusses previous efforts

to utilize agent techniques for intrusion detection.

Section 3 introduces our system that can be

integrated with actual application and performs

application-oriented intrusion detection. Section 4

discusses the overall system performance and design

issues. Finally, Section 5 briefly concludes.

2 RELATED WORK

Agent technology is a very active field of distributed

artificial intelligence (DAI) research in the recent

years. A software agent can be defined as (J. M.

Bradshaw,1997):

It’s a software entity that functions

continuously and autonomously in a particular

environment, and is able to carry out activities in a

flexible and intelligent manner that is responsive to

changes in the environment. Ideally, an agent that

functions continuously would be able to learn from

its experience.

Although agent may not improve the techniques

for intrusion detection directly, it can change the

means of applying detection techniques, which will

lead to high efficiency and validity of intrusion

detection. Recently, there has been an accretion of

approaches for building agent-based IDSs for

Internet applications. In such a system, agents with

differing capabilities can interact with each other to

perform data acquiring, analysis, reporting. Several

related agent-based IDSs can be listed as follows:

(1) Autonomous Agents For Intrusion Detection

(AAFID) (Balasubramaniyan, J.S.; Garcia-

Fernandez, J.O.; Isacoff, D.; Spafford, E.; Zamboni,

D., 1998)

The AAFID system consists of three essential

components: agents, transceivers and monitors.

Agents are used as the lowest-level element for data

collection. All agents in a host report their findings

to a single transceiver. However, the communication

between agents or transceivers is based on SNMP,

System V IPC, this may lead to extra work when

developing a new agent.

(2) Multi-agent based intrusion detection system

(Hegazy, I.M.; Al-Arif, T.; Fayed, Z.T.; Faheem,

H.M, 2003)

The system employs sniffing agent, analysis

agent, decision agent and report agent to detect three

kinds of attack: the Denial of Service attack, the

ping swept attack and the secure coded document

theft. It can be treated as a network-based detection

system.

(3) An intelligent agent security intrusion system

(Pikoulas, J.; Buchanan, W.; Mannion, M.;

Triantafyllopoulos, K, 2002)

The system is an application-based detection

one. It utilizes the Bayesian multivariate statistical

model to predict user action. In such a system, a user

agent resides in a user workstation, while a core

agent resides on the server. User agent monitors and

analyzes the user action according user profile file

downloaded from server via core agent. The file

contains rules that describe the legal past behavior of

the user and the statistical predictions. Therefore, the

file must be kept secure by itself, however, it’s

difficult to ensure this in this system.

Although these IDSs may be effective in

detecting some kinds of intrusion, but how to

integrate them with all kinds of application in

enterprise information system remains a difficult

problem.

AGENT-BASED INTRUSION DETECTION SYSTEM FOR INTEGRATION

177

3 AGENT-BASED INTRUSION

DETECTION SYSTEM FOR

INTEGRATION

3.1 System Architecture

We propose an architecture (which we call AIDSI

for ‘Agent-based Intrusion Detection System for

Integration’) for building IDSs that can be

distributed over Internet-based applications. In this

system, we use Markov model to predict the

probability of user action and then make a fuzzy

decision whether the user is illegal one. The system

consists of three types of agents: client agent,

communication agent and server agent. The

relationship among them is shown in figure 1. All of

the configuration and the information necessary for

prediction and decision are stored in the knowledge

base, and the base is located at the server side.

Client agents are installed on client workstation,

and responsible for collecting extra user information

and then sending to server agents with the help of

communication agents. Also, client agents will

check the newest version of client agents stored on

server and decide whether to download and update

for themselves.

Figure 1: Relationship among agents

Server agents are running in the server process.

They process the message sent from client agents,

write and read from knowledge base, which stores

user information and prediction model presentation.

However, most important of all, server agents can

inference whether the current user is a legal one or

not according to the prediction model.

Communication agents monitor the client agent’s

sending request and check whether the client agent

is a legal one. After the received message is parsed,

the useful message is forwarded to the server agents.

Also, the communication agents can accept other

message that generated from access control module

or user authentication module.

Because the system can run well in client process

and work well with other security services, such as

access control, and exchange message in process-

level with those services. Thus the response time

will greatly decrease and a more security mechanism

will be achieved.

In the following section we describe each

component in more detail.

3.2 Client Agent

Application-based intrusion detection system should

set up a proper model for normal user, and Markov

model is used in this paper. However, in order to

achieve an excellent prediction accuracy, only

knowledge about user’s action on the application is

not enough. So, the main function of client agent is

to collect extra user authentication information.

However, this raises many privacy concerns (Millett,

L.I.; Holden, S.H., 2003), which is a hot topic

recently. In AIDSI, the client agent gets extra

information and sends to the server. This process

needn’t to be disturbed by user or system

administrators, so the user privacy can be kept. Extra

information about client’s machine, such as

Operating System, network card, etc. is used to

improve the decision accuracy.

The structure of client agent can be described in

figure 2. Layer 1 collects extra information by

calling operating system API when the user login

into the application. Layer 2 translates the message

into special format defined by Knowledge Query

and Manipulation Language (KQML), which is a

relatively mature agent communication language

(Liu Yong, Xu Congfu, Chen Weidong, Pan Yunhe,

2004.). Layer 3 simply transmits the KQML

message to remote server.

Figure 2: Structure of client agent

However, the client agent should identify itself

for the server agent that it is a legal agent after

connecting to the server. This is especially important

in such an IDS, because abnormal user may corrupt

the client agent and report wrong message to server.

To achieve this goal, a distinguish ID code is

assigned to each client agent. But when the user

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

178

install the client agent on every workstations. To

avoid this kind of unconvenience, the client agent is

designed to dynamically download from server after

the user logins to server in his own application

software.

Another important feature of the client agent is

reliability in communication. Each client agent is

connected to a default communication agent.

However, when the communication is busy or fails

to response, the client agent may select from local

setting for communication agent lists and then tries

to connect to another communication agent.

From above, we can see that the client agent do

not exchange more with user application, so it can

be well integrated with many kinds of user

application.

3.3 Communication Agent

Firstly, the communication agent performs an

ordinal check to see whether the client agent is a

legal one. The checking process describes as follow:

(1) the communication agent gets the client

agent ID code;

(2) the communication agent checks if the ID is

contained in list of knowledge base; if so, then it

allows client to connect.

(3) however, if the ID is not in list, the

communication agent may give a message to the

user authentication module of user application to

notify the module to try another user session.

Secondly, it monitors the data sent from the

instance of access control model.

In application-based detection, user action can be

acquired from access control model and the user

authentication module. Here we take access control

model as an example.

Because access control model usually embeds in

application system, IDSs can’t get the data flow

from the instance of the access control model.

Although an access control model usually produces

log file which records details about user action, but

this log file can’t be used to perform real-time

detection. So, we define a standard event data

acquiring protocol based on Intrusion Detection

Message Exchange Format (IDMEF). IDMEF (D.

Curry, H. Debar, M. Huang, 2000) is a XML-based

language to describe intrusion events. An example

message about user’s access is as follow:

<?xml version="1.0" encoding="UTF-8"?>

<!DOCTYPE IDMEF-Message PUBLIC

"-//IETF//DTD IDMEF v0.1//EN""idmef-

message.dtd">

<IDMEF-Message version="0.1">

</Time>

<name>myserver.eda</name>

</Node>

</Analyzer>

<Node>

</Address>

</Node>

</Source>

</Alert>

</IDMEF-Message>

However, in order to keep the expansibility of

AIDSI, all kinds of IDMEF message should be also

encapsulated into KQML package by assigning

IDMEF as the content part of KQML package.

3.4 Server Agent

The server agent has several main tasks to be

performed, described as follows:

(1) set up a suitable model for each user

In order to improve the overall effectiveness, the

AIDSI defines different models for each user. The

model is express by the following Markov:

)

(

,,MC X A

Ψ , where X is a discrete

stochastic variable, A is the probability transfer

matrix and

is the initial distribution of X.

where P

stands for the probability from status i

to status j.

So, setting up the model actually should

performs the calculation the values of P

The model is stored at the knowledge base,

which can be a small relational database.

(2) acquire the user action at a certain time

After the communication agent gets the KQML

package about user action from the instance of

AGENT-BASED INTRUSION DETECTION SYSTEM FOR INTEGRATION

179

access control model, the server agent can simply

perform a standard action on KQML package to

acquire the user action in real-time.

(3) predict the probability of user action and

make decision

This is calculated by n-order Markov by the

following equation:

(1) ()(1) (1)(2

(1)()

Vt a Ht A a Ht A

aHtn An

+=× × +× −×

++× −+×L

)

where, ,

∑

()Ht stands for user status at time t

Then, the predict result can be got from V(t+1)

by checking the maximum value.

However, the predict accuracy may be limited.

AIDSI makes full use of extra information collected

by the client agents. And this extra information

reflects the user application environment, so a more

high accuracy can be achieved.

The following explains how to get the result.

Suppose V(t+1) = (0.54 0.43 0.03 0 ) and the

user’s current action is on object 1.

Because the probability difference between

object 1 (0.54) and object 2 (0.43) are small, we may

not make such decision that the user is a legal or an

illegal. So, extra information is used. For example,

AIDSI can check whether the address of network

card is in the lists of history frequent used address. If

not, the user may be illegal.

(4) maintenance the user model

In order to keep the user model in a correct state,

each variable in probability transfer matrix should be

updated every time. And this task is performed by

the server agent.

4 DISCUSSION AND DESIGN

ISSUES

(1) ability for integration

The AIDSI is an agent-based intrusion detection

system, which is easy to be integrated.

The client agent just acts as an extra information

collector, and it need not exchange data with client

of user application. In system implementation, the

client agent can be written in Java language and a

complied language, such as C. Layer 1 of client

agent is written in C to integrate with operation

system API, while layer 2 and layer 3 are developed

by Java to reach the goal of dynamically download

to update itself.

The communication agent and server agent are

written in Java. And they can be deployed at

different computers. The instance of access control

model should send information about user action to

communication agent, so some code can be written

as DLL and export API for user application. By

doing so, the agent and access control module is

loosely coupled.

(2) inference ability

In AIDSI, the inference ability of agent is

important for accuracy detecting application-

oriented intrusion. Because the user’s action in

application forms a time series, Markov model is

suitable for such kind of analysis. And extra user

information is used to make a final decision when

the predict result of Markov model is in confuse

state.

Because the calculation in the inference process

is much more expensive, so, multi-thread program

technology must be introduced when developing

server agent to ensure the overall performance of

user application.

(3) independency

Independency is especially a main requirement in

AIDSI for actual user application may vary from

each other in the software environment, and this is

achieved by introducing standard protocol, such as

KQML, IDMEF. These protocols are application-

oriented, so they are suitable for AIDSI.

5 CONCLUSION

Application-oriented intrusion is a kind of more

serious intrusion since masqueraders can get the

meaning of data in a visual mode. AIDSI, which is

different from other IDS, is proposed to deal with

such intrusion. Agent technology is introduced to get

extra user information to improve the predict

accuracy without influence user’s privacy. Also

standard protocols, such as KQML, IDMEF, are

used in the design of the agent communication

mechanism, so AIDSI is more flexible and can be

integrated with enterprise information systems well.

ACKNOWLODGEMENT

This paper is supported by the funding of Fujian

province of China NSFC Project No. A0410007 and

Corporation Start-up Project. We would like to

thank the anonymous reviewers for their comments,

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

180

which is helpful to improve the quality of the paper.

REFERENCES

Loshin, P., 2001. Intrusion detection. Computer World.

http://www.computerworld.com/hardwaretopics/hard

ware/story/0,10801,59611,00.html.

Roy A. Maxion, and Tahlia N. Townsend, 2004.

Masquerade Detection Augmented With Error

Analysis. IEEE TRANSACTIONS ON

RELIABILITY, VOL. 53, NO. 1, MARCH 2004

B. Mukherjee, T. L. Heberlein, and K. N. Levitt. 1994.

Network intrusion detection. IEEE Network, 8(3):26–

41, May/June 1994.

Coull, S.; Branch, J.; Szymanski, B.; Breimer, E.; 2003.

Intrusion detection: a bioinformatics approach.

Proceedings on Computer Security Applications

Conference, 19th Annual, 2003,Pages:24 – 33

M. Schonlau, W. DuMouchel, W.-H. Ju, A. F. Karr, M.

Theus, and Y. Vardi, 2001. “Computer intrusion:

Detecting masquerades,” Statistical Science, vol. 16,

no. 1, pp. 58–74, Feb. 2001.

J. M. Bradshaw.1997. An introduction to software agents.

In J. M. Bradshaw, editor, Software Agents, chapter 1.

AAAI Press/The MIT Press, 1997.

Balasubramaniyan, J.S.; Garcia-Fernandez, J.O.; Isacoff,

D.; Spafford, E.; Zamboni, D.; 1998. An architecture

for intrusion detection using autonomous agents.

Proceedings on Computer Security Applications

Conference, 14th Annual , 7-11 Dec. 1998 Pages:13 –

Hegazy, I.M.; Al-Arif, T.; Fayed, Z.T.; Faheem, H.M.;

2003. A multi-agent based system for intrusion

detection. Potentials, IEEE , Volume: 22 , Issue: 4 ,

Oct.-Nov. 2003 Pages:28 – 31

Pikoulas, J.; Buchanan, W.; Mannion, M.;

Triantafyllopoulos, K.; 2002. An intelligent agent

security intrusion system. Proceedings on IEEE

International Conference and Workshop on the

Engineering of Computer-Based Systems, Ninth

Annual, 8-11 April 2002 Pages:94 – 99

Liu Yong; Xu Congfu; Chen Weidong; Pan Yunhe;

KQML realization algorithms for agent

communication. Fifth World Congress on Intelligent

Control and Automation, 2004. WCICA

2004.Volume: 3 , June 15-19, 2004 Pages:2376 - 2379

D. Curry, H. Debar, M. Huang. 2000. IDMEF Data Model

and XML DTD http://www.oasis-

open.org/cover/IDMEF-provisional-draft-ietf-idwg-

idmef-xml-02.html , DEC 5,2000

Millett, L.I.; Holden, S.H.; 2003. Authentication and its

privacy effects. Internet Computing, IEEE , Volume: 7

, Issue: 6 , Nov.-Dec. 2003 Pages:54 - 58

AGENT-BASED INTRUSION DETECTION SYSTEM FOR INTEGRATION

181
