A PROTOTYPE FOR INTEGRATION OF WEB SERVICES INTO

THE IRULES APPROACH TO COMPONENT INTEGRATION

Susan D. Urban, Vikram V. Kumar, and Suzanne W. Dietrich

Department of Computer Science and Engineering

Arizona State University

Tempe, Arizona USA

Keywords: web services, component integration, integration rules, event generation, component relationships

Abstract: The Integration Rules (IRules) environment provides a framework for using events and rules in the

integration of EJB components. This research has investigated the extensions required to integrate Web

Services into the IRules architecture and execution environment. The IRules language framework and

metadata have been extended for Web Services, with enhancements to Web Service interfaces for

describing services that represent object manipulation operations as well as component enhancements such

as event generation, stored attributes, and externalized relationships between distributed components. Web

service wrappers provide the additional IRules functionality for the enhanced Web Service interfaces, with a

state management facility in the IRules environment providing persistent storage of stored attributes and

externalized relationships. The IRules Web service wrappers are client-side, component-independent

wrappers for Web Services, thus providing a more dynamic approach to the modification of service

interfaces as well as the dynamic entry and exit of participants in the integration process.

1 INTRODUCTION

A Service-Oriented Architecture (SOA) (Brown et

al., 2003) is a paradigm that has recently emerged,

where software components are exposed as services

that can be consumed by clients over the network.

While an SOA represents an important concept for

the interconnection of software components, Web

Services (Web Services, 2000) provide a framework

for a platform and programming language-

independent implementation of SOAs.

The integration of Web Services is typically

performed in a procedural manner. Languages such

as BPEL4WS (Curbera et al., 2002) have been

developed specifically to support the composition of

Web Services into business processes. The

Integration Rules Project (IRules) (Urban et al.,

2001) has taken a different approach to business

process specification, defining an event and rule-

based environment for the integration of black-box

components. The IRules approach provides an

event-driven architecture, where an event, such as

the execution of a method, triggers the execution of

integration rules. An integration rule provides a

declarative framework for the specification of

conditions that are to be checked in response to

events. If the condition is satisfied, additional

methods or transactions can be invoked.

In the initial implementation of the IRules

environment, integration rules were specifically used

for the integration of Enterprise JavaBeans (EJBs)

components (EJB, 2001). The Component Definition

Language (CDL) of the IRules environment is used

to enhance EJB components with IRules

functionality, defining named extents, stored

attributes, externalized relationships between

components, and events for existing components.

This functionality is provided through IRules

wrappers for EJB components that are automatically

generated from the compilation of the CDL (Patil,

2003). The wrappers, also implemented as EJB

components, serve as proxies to components,

generating events before and after the execution of

component methods and providing persistent storage

for extents, stored attributes, and externalized

relationships.

One of the goals of the IRules project is to

support the integration of different types of

component models. Since many component models

will likely expose their capabilities as Web Services,

the primary objective of this research has been to

develop a prototype for the use of Web Services

within the IRules event and rule-based integration

D. Urban S., V. Kumar V. and W. Dietrich S. (2005).

A PROTOTYPE FOR INTEGRATION OF WEB SERVICES INTO THE IRULES APPROACH TO COMPONENT INTEGRATION.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 3-10

DOI: 10.5220/0002527900030010

 SciTePress

framework (Kumar, 2004). To make use of the

existing IRules execution environment, our

investigation has experimented with the use of Web

Services as an interface to EJB components.

The incorporation of Web Services into the

IRules environment introduced several challenging

design and architectural issues. Unlike EJB

components, Web Services do not have any naming

conventions for identifying create, remove, and findAll

methods. Since these methods are needed for query

processing within the condition evaluator of

integration rules, this research has incorporated

language features for identifying such methods in

CDL for Web Services. Another difference between

the original IRules environment and the use of Web

Services is found in the state management

capabilities. The IRules environment was originally

developed with EJBs providing state management

for the storage of stored attributes and externalized

relationships defined in CDL. This research has

defined a state management facility for Web

Services within the IRules execution framework.

The state management facility is a relational

database that is constructed dynamically using the

metadata generated by CDL together with Java

Database Connectivity (JDBC) for incremental

definition of relations.

The placement and nature of the IRules wrapper

for Web Services has also been redefined as a result

of this research. Web Services represent true black-

box components, where the integrator does not have

control over how the services are exposed. The

containers where services exist are also not

accessible to the integrator. For this reason, this

research has defined the IRules Web Service

wrappers to exist in the integrators environment

rather than within the component’s container. In

addition, the Web Service wrapper design is

dynamic in nature, where services can be added and

removed from the overall integration process

without the need to regenerate the Web Service

wrapper as with the EJB design.

The remainder of this paper is structured as

follows. Section 2 provides an overview of the

IRules environment. Section 3 presents the Web

Service wrapper architecture and design. Section 4

discusses the IRules property repository for

providing state management. Related work is

presented in Section 5. The paper concludes with a

summary in Section 6.

2 OVERVIEW OF IRULES

The IRules environment enhances distributed EJB

components with IRules specific semantics that

enable event and rule-based integration. IRules

follows a declarative approach where the integration

logic and component enhancements are explicitly

specified by the integrator using various IRules

languages.

CDL is used as a semantic layer over components

and provides a way of defining externalized

relationships between components, event definitions,

extents, and stored attributes. The syntax of CDL is

presented in Figure 1 from (Patil, 2003). Extents

provide a mechanism for iterating through the objects

of a specific component type. Stored attributes are a

persistent capability provided by the IRules wrapper.

Externalized relationships are also persistent and are

used to establish associations between component

instances. IRules also provides the capability of

defining before and after events on methods as part of

CDL. Before events are generated before the

invocation of a component method, while after events

are invoked after method invocation. Events in IRules

are used to trigger integration rules expressed using

the Integration Rule Language (IRL) (Dietrich et al.,

2001).

Component ComponentName implements ComponentType

(extent ExtentName)

{

attribute AttributeType AttributeName

[{SessionBeanName.MethodName (SessionParameters) } ];

relationship TargetOfPath RelationshipName inverse

InverseRelationshipTarget::InverseRelationshipName;

event IRulesEventName (EventParameters)

{method Modifier MethodName (MethodParameters) };};

Figure: 1: Syntax of CDL (Patil, 2003)

The IRules Scripting Language (ISL) is used to

create application transactions that invoke methods on

components (Kambhampati, 2003). The Event

Definition Language (EDL) is used to specify

additional events associated with application

transactions and other external events (Kambhampati,

2003; Urban et al., 2004). IRL is used to define

integration rules and is based on Event-Condition-

Action (ECA) rules from active database systems.

Each integration rule consists of an event, a condition,

and an action. An event triggers a rule associated with

the event. A condition is evaluated over distributed

components. The action is a call to a method of a

component or an application transaction if the

condition evaluates to true. Several coupling modes

have been defined to handle the transactional

relationships that exist between the event, condition,

and action parts of an integration rule (Jin et al.,

2002).

ICEIS 2005 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

3 WEB SERVICE WRAPPER

ARCHITECTURE AND DESIGN

To generalize the use of the IRules approach, this

research has investigated the use of Web Services as

an interface to EJB components. Web Services,

however, must still be wrapped to provide the IRules

functionality described in Section 2.

3.1 Web Service Wrapper Location

Two approaches have been investigated for the

location of the IRules Web Service wrapper. The

wrapper can exist in the integrator’s environment, or

the wrapper can exist with the service provider as in

the original EJB wrapper design of the IRules

environment. In the later case, the provider wraps the

component with the IRules wrapper and exposes the

wrapped service as a Web Service, as shown in Figure

2. One of the restrictions of this approach is that all

clients of the Web Service must have access to the

service through the IRules wrapper. This approach is

unnecessary for applications that are not a part of the

IRules environment. Moreover this approach assumes

an environment where the integrator has access to the

implementation of each of the Web Services involved

in the integration. In a service-oriented environment,

this approach for the use of wrappers may not be

possible for access to services provided by business

partners. In addition, different wrappers would have

to be developed for different component models,

defeating the purpose of achieving component

independence.

The other approach to the design of the IRules

Web Service wrapper is to wrap the Web Service

proxy as shown in Figure 3. This approach provides a

more flexible environment since every client who

uses the Web Service need not go through the IRules

environment. Furthermore, the service wrapper is

common irrespective of the component model

employed by the Web Service provider, thus helping

to achieve component independence within the IRules

environment. The Web Service provider is therefore

not concerned about the implementation and

deployment of the IRules wrapper since the burden of

integration is placed on the integrator at the client

side.

In a Web Service environment, Web Services can

also be dynamically discovered. The service provider

approach shown in Figure 2 does not support these

dynamic requirements. The service provider approach

also suffers from the disadvantage of having to

generate and re-compile the wrappers for each of the

services involved in the integration. This is a limiting

factor that hampers seamless and flexible integration.

The wrapped proxy approach is more generic and

does not require modifications to be done by the

service. As a result, the wrapped proxy approach of

Figure 3 was chosen for this research.

IRules wrapper

Component

SERVICE PROVIDER

SERVI CE

CONSUMER

Web Ser vi ce

Figure 2: IRules Wrapper with the

Service Provider

Component

Wrapper

SERVI CE PROVI DER

SERVI CE

CONSUMER

Web Service

Wrapper

Figure 3: IRules Wrapper on the

Web Service Proxy

Figure 4 illustrates the architecture of the IRules

Web Service integration prototype. The core of the

architecture is composed of the Web Service proxies

and the IRules Web Service wrapper that encapsulates

the proxies. The IRules Web Service wrapper is

responsible for providing an enhanced interface to the

Web Service. The service wrapper implements

externalized relationships and stored attributes (i.e.,

IRules properties), which are made persistent in the

IRules Property Repository. The repository is a

centralized database storing all of the tables that are

created to maintain IRules property values. These

tables are created dynamically according to

integration needs. An IRules Web Service wrapper is

responsible for retrieving the required contents from

these tables when the IRules Property accessor

methods are called. The IRules Web Service Wrapper

is also responsible for generating method events as

shown in Figure 4.

The execution environment shown in Figure 4

makes extensive use of metadata generated from

CDL, EDL, ISL and the IRL. This metadata is made

A PROTOTYPE FOR INTEGRATION OF WEB SERVICES INTO THE IRULES APPROACH TO COMPONENT

INTEGRATION

JMS

Proxy

Web

Service

Proxy

Method

Events

Method

Events

IRules Property Repository

Stored

Attribute

Stored

Attribute

IRulesMetadata

CDL Space

Sync Space

(Java Space)

Web

Service

IRules Service Wrapper

IRULES ENVIRONMENT

Transac-

tion

Manager

Object

Manager

JINI

Event

Handler

Event

Queue

Rule

Manager

Rule

Processor

A pp lica tio n

Transaction

processor and

application event

detector

External Event

Detector

IRules Property

Generator

Externalized Relationship

Figure 4: IRules Service Integration Environment.

persistent using the storage capabilities of

JavaSpaces. In addition, JavaSpaces provides a

synchronization mechanism that is used to

coordinate the execution of rules with the invocation

of Web Services. The coordination algorithm

appears in (Kambhampati, 2003; Urban et al., 2004).

3.2 IRules Web Service Specification

The syntax of the extended CDL for Web Services is

illustrated in Figure 5. The ComponentName is the

name given to the component being exposed. The

syntax implements WebService identifies that the

component is exposed as a Web Service. Every

WebService has a proxy class that is used to access the

service. The syntax proxy ProxyClassName identifies

the proxy class associated with the component

exposed as a Web Service. The name of the proxy

class is used to instantiate wrapper objects. The

syntax (extent extentName) is used to specify the name

of the extent for the component.

For integration of components in the IRules

environment, it is necessary to identify the create,

remove, and the findAll methods of a component. Create

methods are responsible for creating an instance of a

bean, while the remove method deletes an instance.

The findAll method is responsible for retrieving the

extent of a particular EJB. Extents are used in IRL to

query instances of objects representing rows in a

database. Unlike EJBs, which have naming

conventions for creating, removing, and finding

instances of EJBs, Web Services do not have any

naming conventions. These methods are explicitly

identified by the integrator as shown in the extended

CDL for Web Services in Figure 5.

ICEIS 2005 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

Component ComponentName implements WebService proxy

ProxyClassName (extent extentName)

{return_value create (method parameters)

{method Name (method parameters)};

void remove (method parameters)

{method Name (method parameters};

return_value findAll ()

{method Name (method parameters)};

relationship TargetOfPath RelationshipName inverse

InverseRelationshipTarget::InverseRelationshipName;

event IRulesEventName (EventParameters)

{method Modifier MethodName (MethodParameters) };}

Figure 5: Extended CDL for Web Services

3.3 IRules Web Service Wrapper

Design

Every method of a Web Service in the IRules

environment is accessed through the IRulesWrapper

class. A single IRulesWrapper class exists for all of the

services in the IRules environment. The constructor of

the class takes the name of the service that needs to be

invoked as a parameter. The name of the service is the

same as the name of the Web Service proxy class.

Thus, depending on the value of the parameter passed

to the constructor of the wrapper class, an instance of

the wrapper is configured for that particular Web

Service. As a result, many instances of IRulesWrapper

are created - one for each service. Once a particular

instance of the wrapper is created, the integrator

cannot change the Web Service for which that

particular instance of the wrapper is configured.

The methods of a Web Service are called through

the callWebService generic method of the

IRulesWrapper class. The parameters to the

callWebService method, indicated in Figure 6, include

the name of the method to be called, the parameters of

the method to be called, and an additional transaction

identifier to be passed with each method. Therefore a

call to callWebService is actually a call on a proxy of a

particular Web Service. This approach provides a

dynamic nature to method invocation in IRules Web

Service composition.

The implementation of callWebService takes care

of invoking the appropriate method on the Web

service using reflection as illustrated in Figure 6. The

value of the wsProxy variable is the name of the proxy

class of a particular Web Service, the value of which

is passed as a parameter during the creation of the

wrapper instance.

There are several advantages to the IRules Web

Service wrapper design. One advantage is that there

is no need for code generation for each of the

components involved in the integration as in the

original EJB wrapper design. An instance of each

generic wrapper is simply created using the

IRulesWrapper class. If a separate wrapper existed for

each Web Service, a new wrapper would have to be

generated for each new service added to the system.

The IRules Web Service wrapper design makes it

possible to dynamically change the underlying Web

Service.

The wrapper instance also reads the appropriate

metadata corresponding to the particular Web

Service invoked and generates the method events

required by the IRules environment. In addition, the

wrapper instance maintains the externalized

relationships through calls to create and remove

methods on CDL relationships. Since all methods on

the Web Service, including the methods of the

IRules enhanced interface, are accessed through the

generic callWebService method, there is no

regeneration of the wrapper needed when new

externalized relationships are created for a

component exposed in a service. This enables the

dynamic creation of relationships between

components, where externalized relationships can be

added at any point in the integration process without

regenerating the wrappers. Similarly, the integrator

can define new method events at run time.

public class IRulesWrapper {

private string wsProxy;

public Object callWebService (String methodName, Object []

methodParams, int TransactionID)

{ Class cls = Class.forName(wsProxy);

Object obj = cls.newInstance();

Method method = obj.getMethod(methodName,null);

Object returnValue =

meth.invoke(obj.methodParams);}}

Figure 6: Invoking the Service Method through Reflection

3.4 A Motivating Example

This section presents an ONLINE SHOPPING

APPLICATION to illustrate the integration of Web

Services using the IRules service-oriented

architecture. The application consists of six Web

Services as shown in Figure 7. These Web Services

access EJB components, which

A PROTOTYPE FOR INTEGRATION OF WEB SERVICES INTO THE IRULES APPROACH TO COMPONENT

INTEGRATION

+Create()

+getCustName()

+getCustZipCode()

+getCustCardIno()

-CustomerID : String

-CustomerName : String

-CustomerAddress : String

-CusotmerZipCode : String

-CustomerPhone : String

CustomerInfo

-CustomerID : String

-CustomerNameOnCard : String

-CustomerCardNo : String

-CustomerCardName : String

-CustomerCardExpDate : String

CustomerCard

+Create()

+Remove()

+addItems()

+getItems()

+setShipper()

+setPaymentStatus()

+setShippingStatus()

-CustomerOrderNo : String

-CustomerLoginName : String

-CustomerCardName : String

-OrderDate : String

-PaymentStatus : String

-Shipper : String

-ShippingStatus : String

-Price : String

CusomerOrder

-ItemID : String

-ItemName : String

-QtyOrdered : String

-ItemPrice : String

-CustomerOrderNo : String

LineItems

+CreateShppingOrder()

+CancelOrder()

+getTrackingInfo()

-TrackingNo : String

-ItemShipped : String

-Source : String

-Destination : String

-DateOfShipping : String

-TrackingInfo : String

ShippingService

+getCreditRating()

+makePayment()

CreditPayment

-hasCustomers

-hasCards

-hasOrder

-hasItems

-hasItem

-hasLineItems

-suppliesItems

-hasSuppliers

-hasOrder1

-hasTrackingNo1

Customer Info

Service

Customer

Order Service

Item Stock Service

Supplier

Service

+getSupplier()

+supplierID : String

+supplierName : String

+supplierAdd : String

+supplierZipCode : String

+supplierPhone : String

Supplier

Customer Information Container

Supplier Container

Customer

Order

Container

+Create()

+Remove()

+updateQty()

+itemID : String

+itemCode : String

+itemDescription : String

+itemPrice : String

+itemQty : Integer

-reorderQty : Integer

-reorderStatus : String

-threshHold : Integer

ItemStock

-hasCustomer1

-relatedOrders*

+Create()

+Remove()

+addItems()

+getItems()

+setShipper()

+setPaymentStatus()

+setShippingStatus()

-CustomerOrderNo : String

-CustomerLoginName : String

-CustomerCardName : String

-OrderDate : String

-PaymentStatus : String

-Shipper : String

-ShipperStatus : String

-Price : String

CustomerOrder

Figure 7: Online Shopping Application Components with Externalized Relationships

have been developed using the Web Logic

application server. The Web Services were

developed using BEA Web Logic Workshop,

accessing the underlying EJBs.

Figure 7 depicts the various containers and

components for the O

NLINE SHOPPING APPLICATION.

The CustomerInfo and CustomerCard components are

located in one container. The CustomerOrder

component, the LineItems component, and the

ItemStock component are located in a separate

container. A third container is used to store the

Supplier component. These containers provide Web

Services that are internal to the organization.

The application also makes use of two external

Web Services. A CreditPayment service is used to

approve credit card payments from customers.

ShippingService is used to handle the shipping of the

purchased items to the customer destination.

When a CustomerOrder is created, it needs to be

associated with the customer information for that

particular order. Since CustomerInfo is stored in a

separate container, an externalized relationship is

needed to associate a particular CustomerOrder with

the CustomerInfo of the customer who created the

order. Figure 8 illustrates the CDL definition for the

Web Service associated with CustomerOrder. The

definition enhances the CustomerOrder component

with an explicit relationship to CustomerInfo. The

Web Services wrapper for the CustomerOrder will

provide the appropriate accessor methods to

establish such relationships, with the details of the

relationship stored in the IRules Property Repository

(described in Section 4). A similar relationship

exists between ItemStock and Supplier to indicate the

supplier of a specific inventory item.

ICEIS 2005 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

Component CustomerOrder implements WebService proxy

CustomerOrder (extent orders)

{CustomerOrder create (String orderId, String custId, String

orderDate, String creditCardName, String paymentStatus, String

shipper, String shippingStatus, String price)

{CustomerOrder createOrder (String orderId, String custId, String

orderDate, String creditCardName, String paymentStatus, String

shipper, String shippingStatus, String price);}

Void remove (String orderId)

{Void removeCustomerOrder (String orderId);}

Collection findAll ()

{Collection findAllCustomerOrder ();}

relationship CustomerInfo hasCustomer inverse

CustomerInfo::relatedOrders;

relationship Shipper hasTrackingNo inverse Shipper::hasOrder;}

Figure 8: CDL of CustomerOrder

Externalized relationships can also exist with

services outside of the enterprise. In Figure 7,

ShippingService is an external service used by the

application. The ShippingService provides a unique

tracking number for items being shipped. An

externalized relationship is used to relate a

CustomerOrder with its ShippingService tracking

number.

4 THE IRULES PROPERTY

REPOSITORY

The IRules Property Repository shown in Figure 4 is

a centralized state management facility for storing

the stored attributes and externalized relationships of

distributed components. The repository has been

designed to take care of the dynamic aspects of Web

Service composition by dynamically generating the

relational tables for storing these IRules properties.

The necessary SQL statements for creation of the

appropriate tables are constructed using the CDL

metadata at run time, using JDBC to send create table

statements to the property repository for each stored

attribute and externalized relationship to be defined.

Therefore, any addition of services can be

dynamically incorporated into the overall integration

process.

For example, to relate an instance of

CustomerOrder with the CustomerInfo component

across Web Services, the primary keys that are used

as references to instances of EJBs across the two

Web Services are stored in an externalized

relationship table, named CustomerOrderCustomerInfo

within the IRules Property Repository. The table is

dynamically constructed through an algorithm that

retrieves the IRules Web Service metadata to issue

the following create table statement:

create table CustomerOrderCustomerInfo (

customerOrderNo varchar(5) primary key

customerId varchar(30));.

Since the relationship is an N:1 relationship (i.e.,

many orders related to one customer), the

customerOrderNo is determined to be the key of the

table. To set the value of an externalized

relationship, the integrator calls the

setCustomerOrderCustomerInfo (keyCustomerOrder,

keyCustomerInfo) accessor method for that particular

relation. Accessor methods are provided by default

by the Web Service wrapper for each relationship

defined. On calling the relationship method, the keys

passed to the method are stored into the externalized

relationship table. Additional accessor methods can

be called to retrieve the details of relationships

between component instances. As with the

invocation of methods on components, the

relationship accessor methods are invoked by

calling the generic callWebServiceMethod for the

appropriate instance of the IRulesWrapperClass.

5 RELATED WORK

There are several recent projects related to the use of

Web Services in the IRules event and rule-based

integration environment. The research in (Benatallah

et al., 2002) presents a novel declarative language

for composition of Web Services using state charts.

A state chart is composed of states and transitions,

where transitions are represented as active rules. The

eFlow system (Casati et al., 2000) is a service

process engine that supports specification,

enactment, and management of composite e-

services. A composite service in eFlow is described

as a process schema that may include services,

decisions or rules, and event nodes. Rules control

the business flow while event nodes enable sending

and receiving different types of events. The research

in (Zeng et al., 2002) presents a rule-based approach

for composition of Web Services, enabling dynamic

composition of Web Services with run-time

activation of rules. The research in (Zeng et al.,

2002) provides a declarative language for the

composition of services. The service composition

models are generated on demand and can be re-

configured at runtime.

In comparison to the related work described above,

the IRules project follows a database centric

approach. The concept of externalized relationships

and stored attributes are absent in the Web Services

A PROTOTYPE FOR INTEGRATION OF WEB SERVICES INTO THE IRULES APPROACH TO COMPONENT

INTEGRATION

project of (Benatallah et al., 2002). The research

presented in this paper demonstrates the use of

IRules functionality within Web Services. The

eFlow system (Casati et al., 2000) provides features

for service processes to be adaptive and change

according to business requirements and environment

conditions. Similar functionality can be achieved in

the IRules system by defining integration rules,

which may change according to business

requirements to enable adaptive integration of

components.

6 SUMMARY

This research has developed a prototype for

extending the IRules environment for the use of

Web Services as a service interface to EJB

components. The IRules Web Service Wrappers

have been designed to give a dynamic nature to the

IRules integration environment, in addition to

supporting the functionality of the IRules

environment. This research has also developed a

state management facility for the dynamic creation

and storage of IRules properties without

recompilation of the wrappers, thus enabling

dynamic business processes.

There are several directions for future research.

One direction involves the incorporation of other

component models into the IRules framework using

the Web Services interface to demonstrate the

component independence of the environment.

Furthermore, a Grid Service provide a means for

exposing a Web Service as one that provides a set of

well-defined interfaces that follow specific

conventions. Future research should extend the

IRules approach for the integration of Grid Services.

The ISL can also be enhanced to provide an XML-

based process specification language, such as that of

BPEL4WS, together with a mechanism for handling

events and integration rules. The processing

language can be further extended to support Grid

Services.

REFERENCES

Benatallah, B., Dumas, M., Sheng, Q., and Ngu, A. 2002.

Declarative Composition and Peer-to-Peer

Provisioning of Dynamic Web Services. Proc. of 18th

Int. Conf. on Data Eng. (San Jose, USA), pp. 297–

308.

Brown, A., Johnston, S., and Kelly K., 2003. Using

Service Oriented Architecture and Component Based

Development to Build Web Services Application.

Rational-IBM White paper.

Casati, F., Ilnicki, S., Jin, L., and Krishnamoorthy, V.,

Shan, M. 2000. eFlow: a Platform for Developing and

Managing Composite e-Services, Software

Technology, Hewlett-Packard, HPL-2000-39 (March).

Curbera, F., Y. Goland, J. Klein, F. Leymann, D. Roller,

S. Thatte, S. and Weerawarana 2002. Business Process

Execution Language for Web Services, Version1.0.

http://www.ibm.com/developerworks/ li-brary/ws-

bpel.

Dietrich, S., Urban, S., Sundermier, A., Jin, Y.,

Kambhampati, S., and Na, Y. 2001. A Language and

Framework for Supporting an Active Approach to

Component-Based Software Integration, Informatica,

volume 25, number 4, pp. 443-454.

EJB, 2001. Enterprise JavaBeans Specification 2.0.

Proposed Final Draft 2.

Jin, Y., Urban, S., Sundermier, A., Dietrich, S. 2002. An

Execution and Transaction Model for Active, Rule-

Based Component Integration Middleware, Proc. of

the Engineering and Deployment of Cooperative

Information Systems, (Sept) (Beijing, China), pp. 403-

417.

Kambhampati S, 2003. An Event Service For A Rule-

Based Approach To Component Integration, M.S.

Thesis, Arizona State University, Dept. of Computer

Sci. and Eng.

Kumar, V. 2004. A Prototype for Integration Of Web

Services Into The IRules Approach To Component

Integration, M.S. Thesis, Arizona State University,

Dept. of Computer Sci. and Eng.

Patil, R. 2003. A Framework for supporting an active

approach to component based software integration,

M.S. Thesis, Arizona State University, Dept. of

Computer Sci. and Eng.

Urban, S., Dietrich, S., Na, Y., Jin, Y., Sundermier, A.,

Saxena, A. 2001. The IRules Project: Using Active

Rules for the Integration of Distributed Software

Components, Proc. of the 9th IFIP 2.6 Working Conf.

on Database Semantics: Semantic Issues in E-

Commerce Systems, (Hong Kong), pp. 265-286.

Urban, S., Kambhampati, S., Dietrich. S., Jin, Y., and

Sundermier, A., 2004. An Event Processing System

for Rule-Based Component Integration Int. Conf. on

Enterprise Information Systems, (Porto, Portugal), pp.

312-319

Web Services, 2000. Web services architecture overview.

The next stage of evolution for e-business, IBM

Technical Document, Web Architecture Library.

Zeng, L., Benatallah, B., Lei, H., Ngu, A., Flaxer, D., and

Chang, H., 2002. Flexible Composition of Enterprise

Web Services, IBM T.J. Watson Research Center.

ICEIS 2005 - DATABASES AND INFORMATION SYSTEMS INTEGRATION
