EXECUTION OF IMPERATIVE NATURAL LANGUAGE

REQUISITIONS BASED ON UNL INTERLINGUA AND

SOFTWARE COMPONENTS

Flávia Linhalis

Institute of Mathematics and Science Computing. São Paulo University, Av. Trabalhador São-Carlense, São Carlos, Brazil

Araraquara University Center (Uniara), Rua Voluntários da Pátria, Araraquara, Brazil

Dilvan de Abreu Moreira

Institute of Mathematics and Science Computing. São Paulo University, Av. Trabalhador São-Carlense, São Carlos, Brazil

Keywords: Natural language, Universal Networking Language (UNL), Ontology, Software Component.

Abstract: This paper describes the use of an Interlingua as a new approach to the execution of imperative natural

language (NL) requisitions. Our goal is to embed a natural language interface into applications to allow the

execution of users requisitions, described in natural language, through the activation of specific software

components. The advantage of our approach is that natural language requisitions are first converted to an

interlingua, UNL (Universal Networking Language), before the suitable components, methods and

arguments are retrieved to execute each requisition. The interlingua allows the use of different human

languages in the requisition (other systems are restricted to English). The NL-UNL conversion is

preformed by the HERMETO system. In this paper, we also describe SeMaComp (Semantic Mapping

between UNL relations and Components), a module that extracts semantic relevant information from UNL

sentences and uses this information to retrieve the appropriated software components.

1 INTRODUCTION

The idea of a restricted natural language interface is

very appealing because natural language is the way

which humans communicate with each other. That is

why several systems, developed throughout the last

twenty-five years, have pursued the goal of

describing user intentions in restricted natural

language and have them executed by computers

(Ballard & Bierman, 1979; Price et al., 2000; Cheyer

& Martin, 2001; Tsai et al., 2003).

Despite the intuitive appeal of a natural language

interface, it has been argued that a language like

English has too many ambiguities to be useful for

communicating with computers. The UNL

(Universal Networking Language) project aims to

represent, in the cyber world, the functions of

natural languages used in human communication.

But, different from natural languages, UNL

expressions are unambiguous. UNL is an interlingua

that enables computers to process information and

knowledge across language barriers. UNL enables

people to express knowledge conveyed in natural

languages (English, French, Spanish, Portuguese,

and so on). It also enables computers to

intercommunicate, thus providing people with a

linguistic infrastructure for distributing, receiving

and understanding multilingual information (UNL

Center, 2003).

Our goal is to be able to execute user requisitions

described in several restricted natural languages,

such as English, Portuguese, French, and so on. In

order to do this, user requisitions are first converted

into UNL. The UNL representation is used to extract

relevant semantic information from the input

sentences that will be necessary to retrieve and

execute software components. The user requisitions

will be executed through the activation of specific

component methods.

In this paper, requisitions refer to user intentions

described in a high level semantic abstraction and

related to a specific domain. For example,

considering the domain of web course management,

valid requisitions could be:

254

Linhalis F. and de Abreu Moreira D. (2005).

EXECUTION OF IMPERATIVE NATURAL LANGUAGE REQUISITIONS BASED ON UNL INTERLINGUA AND SOFTWARE COMPONENTS.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 254-259

DOI: 10.5220/0002528902540259

 SciTePress

(a) “Add student John Smith to the Hypermedia

course.”

(b) “Send an e-mail to the students of the

Operating Systems course saying that the test

will be on December 14

.”

The main advantage and innovation of our

approach is the use of UNL as an interlingua. In this

way, natural language requisitions, expressed in

different human languages, can be translated into the

same UNL representation before being executed. To

convert natural language into UNL, the HERMETO

(Martins et al., 2004) system was used.

To achieve our goal, a new system, the

SeMaComp (Semantic Mapping between UNL

relations and Components) system is being

developed. It uses ontologies to identify what

components, methods and arguments will be

necessary to execute requisitions expressed in UNL.

This paper is organized in the following way:

Section 2 discusses related works about interfaces

for the execution of natural language requisitions.

Section 3 describes the UNL project and the

HERMETO system. Section 4 presents an

imperative natural language requisition system using

SeMaComp. Section 5 describes an application in

the web course management domain. Section 6

concludes the paper with some remarks on future

work.

2 RELATED WORKS

The first efforts to execute user requisitions

expressed in natural language began in the later 70s.

The NLC (Natural Language Processing) system

(Ballard & Bierman, 1979) was designed to process

data stored in matrices or tables. It enables a

computer user to type English commands into a

display terminal and watch them executed on the

screen. A more recent example of the same idea is

NaturalJava system (Price et al., 2000). Its interface

accepts English sentences as input and generates the

Java source code to execute the sentences. Both

systems are very limited because input must be in a

restricted algorithmic fashion. Higher semantic level

sentences are not allowed.

Some approaches, such as OAA (Open Agent

Architecture) (Cheyer & Martin, 2001) and SOTA

(Tsai et al., 2003), have worked with software

components and agents to get a higher level of

abstraction. OAA is a framework for constructing

agent-based systems that makes it possible for

software services to be provided through the

cooperative efforts of distributed collections of

agents. OAA provides an interface that accepts

English sentences as input that are converted to ICL

(Interagent Communication Language), a Prolog-

based language. ICL is used, by the agents, to

communicate with each other and to register their

capabilities with a facilitator agent. The facilitator is

responsible for matching ICL requests to choose the

most suitable agents to execute these requests.

SOTA is an office task automation framework

that uses web services, ontology, and software

agents to create an integrated service platform that

provides user-centric support for automating intranet

office tasks. SOTA can take plain English text

sentences as input and serve users with a single and

integrate user-interface form to access web services,

thus avoiding the need to access each distributed

service manually. SOTA performs its tasks in three

phases: first it parses user input sentences to identify

possible web services using an ontology, next it

prepares most of the input data fields the services

requires, and, finally, it combines related services to

define a single task flow.

Such as OAA and SOTA, our work aims to use a

restricted natural language interface to describe user

requisitions and software components to execute

these requisitions. One of the major differentials of

our approach is that the natural language requisitions

are first converted to an interlingua (UNL (Ushida &

Zhu, 2001)), and then the requisitions are analyzed

and the appropriated component methods are called

(to process the requisitions). References to systems

that convert user requisitions into an interlingua and

use that interlingua semantic information to choose

the appropriated software components have not been

found in the literature.

3 THE UNL PROJECT

The UNL project started in 1996 and currently

embraces several universities and research

institutions in the world. The project proposed an

interlingua, entitled Universal Networking Language

(UNL), which has sufficient expressive power to

represent relevant information conveyed by natural

languages. For each natural language, two systems

should be developed: a "Deconverter" capable of

translating texts from UNL to this natural language,

and an "Enconverter" which has to convert natural

language texts into UNL.

UNL represents sentences using three elements

(UNL Center, 2003):

• Universal Words (UWs): Each UW relates to a

concept and is represented as an English word

that can be optionally supplied with semantic

specifications to restrict its meaning. The

following are examples of UWs: book,

book(icl>publication), book(icl>reserve). In the

EXECUTION OF IMPERATIVE NATURAL LANGUAGE REQUISITIONS BASED ON UNL INTERLINGUA AND

SOFTWARE COMPONENTS

255

two last examples, the meaning of book is

restricted by other UWs (“publication” and

“reserve”). The restrictions allow representing

UWs as disambiguated English words.

• Relation Labels (RLs): RLs express semantic

relations between UWs. There are today 44 RLs

defined. The RLs are represented as a pair

relation_label(UW1, UW2). For example:

o obj (move, table): This relation defines a

thing in focus that is directly affected by an

event or state. In our example, it means the

“table moved”.

• Atribute Labels (ALs): ALs express additional

information about UWs, such as verb tense,

intention, emphasis, etc. ALs are represented as

UW.@atrib

.@atrib

...@atrib

. For example:

obj(eat.@past, apple.@pl). The AL “@past”

indicates past and “@pl” indicates plural.

We do not intend to describe the UNL language

here in details. A full specification of UNL can be

found at http://www.undl.org.

3.1 HERMETO

HERMETO is a standalone environment for fully

automatic syntactic and semantic natural language

analysis (Martins et al., 2004). It can be used to

convert any natural language into the Universal

Networking Language (UNL). It receives as input a

dictionary and a grammar that should be

parameterized for each language, in a way very

similar to the one required by the UNL Center

Enconverter program (UNL Center, 2003). However,

HERMETO brings together three special distinctive

features: 1) it takes rather high-level syntactic and

semantic grammars; 2) its dictionaries support

attribute-value pair assignments; and 3) its user-

friendly interface comprises debug, compiling and

editing facilities. In this sense, it provides a better

environment for the automatic production of UNL

expressions.

Figure 1 shows examples of HERMETO

dictionary entries and Figure 2 presents examples of

its grammar rules. We do not intend to describe the

dictionary syntax and the rules formalism in this

paper. This information can be found in Martins et al

(2004).

Figure 1: Examples of dictionary entries

[a.m.] {} a.m. "a.m.(icl>ante meridiem)" (pos:abr)

<EN,1,1>;

[AM] {} a.m. "a.m.(icl>ante meridiem)" (pos:abr)

<EN,1,1>;

[a] {} a "a" (pos:art,typ:ndf) <EN,1,1>;

[access] {} access "access" (pos:ver) <EN,1,1>;

[add] {} add "add(icl>do)" (pos:ver) <EN,1,1>;

[admin] {} administrator "administrator" (pos:nou)

<EN,1,1>; [after] {} after "after(icl>how)"

(pos:adv,typ:tme) <EN,1,1>;

[after] {} after "after(icl>time)" (pos:pre) <EN,1,1>;

Figure 2: Grammar rules examples

; 2. PHRASE LEVEL

; 2.1. IMPERATIVE VERB PHRASE (IVP)

IVP[1] := VER.@entry + NOU + NOU -> nam(:02,:03),

obj(:01,:03)

IVP[2] := VER.@entry + NOU + NOU + PRE + ART +

NOU + NOU -> nam(:02,:03), nam(:06,:07), bj(:01,:02),

gol(:01,:07)

IVP[2] := VER.@entry + NOU + NOU + PRE + NOU +

NOU -> nam(:02,:03), nam(:05,:06), obj(:01,:02),

gol(:01,:06)

; 3. WORD LEVEL

; 3.1. VERB

VER[1] := ver.@entry

; 3.2. NOUN

NOU[1] := nou.@entry

NOU[2] := ppn.@entry

4 THE PROPOSED SYSTEM

As stated in section 1, our goal it to execute user

requisitions described in restricted natural language.

Figure 3 illustrates our approach.

Currently, the input requisitions must be

imperative sentences. The input requisitions also

have to obey grammar rules and words defined in a

dictionary. Both, grammar and dictionary have to be

defined according to a specific application domain.

HERMETO will use them to convert natural

language sentences into UNL.

The UNL sentence is the input for the

SeMaComp (Semantic Mapping between UNL

relations and Components) module. The SeMaComp

goal is to identify what components, methods and

arguments will be required to execute the UNL

requisition. To achieve this goal, the SeMaComp

module uses the Component Ontology (described in

session 4.1). Some concepts of this ontology are

shared with a Domain Ontology.

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

256

Figure 4: Component Ontology

Figure 3: The Proposed System

The application domain software components

have to be already installed in the system and ready

to be used. These components can make simple

queries and modify the Domain Ontology (and its

instances) according to user requisitions. They also

can perform external actions to the system, such as

send e-mail. The Domain Ontology is currently

developed using the Protégé tool (Noy et al., 2001),

hence the components access it through the Protégé

API. This API can be used directly by external

applications to access Protégé knowledge bases

without running the Protégé tool.

Natural Language Requisition

HERMETO

Dictionary Grammar

UNL representation

_______

SeMaComp

4.1 The Component Ontology

Ontology of

Components

Figure 4 presents the Component Ontology classes

and relationships. This ontology has to be

instantiated in accordance with the characteristics of

the application domain software components.

The instances of the class OntoDomainConcepts

correspond to concepts of the application domain

that are present in the Domain Ontology. The

instances of the class Components correspond to the

components of the application domain that can be

related to one or more concepts of the

OntoDomainConcepts class. The instances of class

Method correspond to the methods of each software

component of the application domain. The instances

of class Params correspond to the arguments of

each method. Finally, the instances of class Actions

correspond to imperative verbs. Each verb (action) is

Components,

methods an

argum

ents.

omponents Domain C

Methods Call

Domain

Ontology

Can query and

modify the domain

Protégé API

EXECUTION OF IMPERATIVE NATURAL LANGUAGE REQUISITIONS BASED ON UNL INTERLINGUA AND

SOFTWARE COMPONENTS

257

related to one or more methods, and each method is

related to one verb.

The class UNLRelations relates UNL relations to

information about components. The aim of this class

is to indicate the mapping between a particular

relation_label(UW1, UW2) and the components,

methods, arguments and actions in the Component

Ontology. This class contains instances representing

all the UNL relations currently being used in the

imperative sentences related to the application

domain.

Before defining the UNLRelation instances, it is

necessary to observe what semantic information can

be extracted from the UNL relations that are relevant

to the UWs-Components mapping.

5 WEB COURSE EXAMPLE

We can demonstrate our approach with a scenario

that involves a web course management domain.

The software components must be set and ready to

use. For this particular domain, we defined a set of

components; each one related to a specific concept

of the domain. For example, we have a

“TeacherComponent” that is responsible for the

execution of actions related to the “Teacher” concept.

This component has methods to create, delete and

list teachers, to assign a specific teacher to a specific

course, to update information about a particular

teacher, and so on. In a similar way, we have

components related to the concepts “User”,

“Student”, “Candidate”, “Course”, “Class”,

“Monitor” and “Administrator”. After the

development of these components, we defined a

Domain Ontology, with relationships between the

concepts of the underlined domain.

Figure 5 shows some examples of natural

language imperative sentences (requisitions) that can

serve as input to the system.

The requisitions must obey the grammar rules

and dictionary entries created for the domain.

Figures 1 and 2 showed a small part of the

dictionary and rules created for this domain. The

requisition will be converted into UNL (using

HERMETO). For example, consider the following

requisition:

“Delete administrator Mary from course Java.” (c)

HERMETO will generate the UNL representation

showed on Figure 6.

Figure 5: Imperative Sentences Examples

- Create course Operating System.

- Delete course Java.

- Add student John Smith to the class xxx.

- List classes of teacher Susan.

- Delete administrator Mary from the course Java.

- Update course Java candidate name from Mary Smith

to Maria Smith.

Figure 6: UNL representation generated by HERMETO

for the sentence on (c)

obj(delete,administrator)

gol(delete,course)

nam(administrator,Mary)

nam(course,Java)

The UNL relations, shown in Figure 6, will serve

as input to the SeMaComp module. It will use the

Component Ontology to detect which components

methods and arguments should be used to execute

the requisition. The Component Ontology should

have been previously instantiated according to the

characteristics of the domain software components.

Special attention should be given to the class

UNLRelations. Before defining this class, in the

Component Ontology, it is necessary to observe

what semantic information can be extracted from the

UNL relations, present on the application domain,

that is relevant to the UWs-Components mapping.

Figure 7 illustrates the UNL relations present in the

imperative sentences of the domain as instances of

the class UNLRelations. This class instances and

their relationships indicate which information can be

extracted from the UNL representation of the

sentence to help finding the most suitable

components, methods and arguments to execute the

requisition. This class should state if a UW, related

to a particular relation label, corresponds to a

component, an action, an argument type, an

argument value or a return value.

As shown in Figure 7, UW1 of obj relation is

Params

Actions

Components

UNLRelations

obj

UW1

UW2

gol

UW1

UW2

nam

UW1

UW2

mod

UW1

UW2

Instances

Figure 7: UNL-Components Mapping

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

258

always related to an Action (it means that the value

of UW1 can be any instance of class Actions in the

Component Ontology). Similarly, UW2 is related to

a Concept – that should have one or more software

components related to it and have to be present at

the Domain Ontology.

SeMaComp separates the tokens of the UNL

sentence and classify them using the Component

Ontology. For the UNL representation of the

requisition in Figure 6, SeMaComp will identify the

relevant information shown in Figure 8.

Figure 8: Relevant information extracted from the UNL

sentence of Figure 6

With this information, SeMaComp searches the

Component Ontology to discover which methods are

related to the action “delete” and belong to one of

the components associated to the “administrator”

concept. This search returns the methods

deleteAdmin and deleteAdminCourse. Still

in the Component Ontology, SeMaComp retrieves

data about the number of arguments, argument types

and return type of each identified method. These

information are used to analyze the available

methods and to conclude which one is the most

suitable to execute the requisition.

6 CONCLUSIONS AND FUTURE

WORK

This paper described a new approach to the

execution of natural language requisitions. This

approach proposes a semantic mapping between

UNL relations and software components. UNL is an

interlingua, the advantage of using an interlingua to

describe user requisitions is that it can represent

requests derived from different languages (English,

Spanish, Portuguese, French, etc.).

In our system, natural language requests can be

translated into UNL and the SeMaComp module can

perform the semantic mapping between those UNL

requests and software components and activate

methods in these components to fulfill the requests.

The semantic mapping can be used in different

application domains; it is just necessary to write the

appropriate software components, define the

dictionary and grammar rules (that will be used by

HERMETO), create instances of the Component

Ontology and define the Domain Ontology.

The semantic mapping between UNL relations

and software components currently performed is

limited to the information given by the user in the

natural language requisition. As future work, we

intend to extend the Component Ontology to support

context information. Another future work is to

perform the semantic mapping between UNL

relations and software components using not only

imperative sentence structures, but also interrogative

and conditional sentence structures.

Action = delete

Main Concept: administrator

Other Concept: course

Argument: Mary

Argument type: administrator

Argument: Java

Argument type: course

Number of arguments: 2

Return type: none

Our ultimate goal is to provide a restricted natural

language interface that could be used by other

systems to allow computer-based actions to be

described in several natural languages.

REFERENCES

Ballard, B. A.; Bierman A. W., 1979. Programming in

Natural Language: NLC as a Prototype. In: ACM

SCS’79, ACM Annual Computer Science Conference.

Proceedings. ACM Press. pp. 228-237.

Cheyer, A.; Martin, D., 2001. The Open Agent

Architecture. Journal of Autonomous Agents and

Multi-Agent Systems, v.4, n.1, pp.143-148.

Martins, R. T.; Hasegawa, R.; Nunes, M. G. V., 2004.

HERMETO: A NL Analysis Environment. In: TIL’04,

2nd Workshop da Tecnologia da Informação e da

Linguagem Humana. Proceedings. Brazil, pp. 64-71.

Noy, N. F.; Sintek, M.; Decker, S.; Crubezy, M.;

Fergerson, R. W.; Musen, M. A., 2001. Creating

Semantic Web Contents with Protégé-2000. IEEE

Intelligent Systems. v.16 n.2, pp.60-71.

Price, D.; Riloff, E.; Zachary, J.; Harvey, B., 2000.

NaturalJava: A Natural Language Interface for

Programming in Java. In: 5

ACM International

Conference on Intelligent User Interfaces. Proceedings.

ACM Press. pp. 207-211.

Tsai, T et al., 2003. Ontology-Mediated Integration of

Intranet Web Services.

IEEE Computer. v. 36, n. 10,

pp. 63-71.

UNL Center, 2003. The Universal Networking Language

(UNL) Specifications. Version 3, edition 2.

Ushida H.; Zhu M., 2001. The Universal Networking

Language beyond Machine Translation. In:

International Symposium on Language and

Cyberspace, Seoul (South Korea).

EXECUTION OF IMPERATIVE NATURAL LANGUAGE REQUISITIONS BASED ON UNL INTERLINGUA AND

SOFTWARE COMPONENTS

259
