REVEALING THE REAL BUSINESS FLOWS FROM ENTERPRISE

SYSTEMS TRANSACTIONS

Jon Espen Ingvaldsen, Jon Atle Gulla

Department of Computer and Information Science,

Norwegian University of Science and Technology, Trondheim, Norway

Ole Andreas Hegle, Atle Prange

Businesscape AS, Trondheim, Norway

Keywords:

Information Systems Analysis, Change Projects, Business Modeling, Enterprise Resource Planning.

Abstract:

Understanding the dynamic behavior of business ﬂows is crucial when improving or reengineering organiza-

tions. In this paper we present an approach and a tool to business ﬂow analysis that helps us reveal the real

business ﬂows and get an exact understanding of the current situation. By analyzing logs of large enterprise

systems, the tool reconstructs models of how people work and detects important performance indicators. The

tool is used as part of change projects and replaces much of the traditional manual work that is involved.

1 INTRODUCTION

For an enterprise to stay competitive or gain a compet-

itive advantage it must continuously evaluate its per-

formance and quickly adapt to changes at all levels of

the organization. To meet this challenge enterprises

are developing a growing interest in streamlining their

business processes and implementing comprehensive

Enterprise Information Systems (EIS). This process

orientation allows them to concentrate on value-

creating activities and be more responsive to changes

in the environment. Enterprise Resource Planning

(ERP) systems are now in wide-spread use among

both large and midsize companies (van Everdingen

et al., 2000).

Enterprise systems projects today typically involve

a change element that ranges from narrow improve-

ments of current processes to full reengineering of the

whole business. Fundamental to all change projects,

though, is the need to understand how the current

business is run. The key issue is to identify weak-

nesses of the current business ﬂows and work out bet-

ter ways of performing the necessary tasks. Assess-

ing the current business ﬂows of the organization is

also important for more restricted planning or coordi-

nation tasks. A well-known problem is the mismatch

between the intended business processes and their ac-

tual execution. The process of identifying such gaps is

called delta analysis (van der Aalst et al., 2003) and is

continuously important in a process aware organiza-

tion. In general, an accurate account of current busi-

ness ﬂows is needed for proper resource planning and

IT investments.

In this paper we present an approach to business

ﬂow analysis that helps us understand the current sit-

uation and detect weaknesses and bottlenecks of the

existing processes. A newly developed tool called

Enterprise Visualisation Suite (EVS) automatically

extracts business process models from the transac-

tions of the enterprise system and provides a num-

ber of analyses of these transactional data. The tool

is used as part of change projects, in which accu-

rate and detailed descriptions of the AS-IS situation

are needed for the subsequent design of new and op-

timized processes. The EVS tool replaces much of

the traditional manual work of workshops and inter-

views with various stakeholders in the organization.

It speeds up the early phases of change projects with

more accurate accounts of existing workﬂows and can

later be used to monitor the execution of the improved

business processes.

2 THE CHALLENGES OF

ASSESSING CURRENT

BUSINESS FLOWS

Many recent works have pointed out the importance

of analyzing the current business ﬂows as part of

enterprise systems projects or change projects (e.g.

(Bancroft et al., 1997), (Offen, 2002)). If the existing

254

Espen Ingvaldsen J., Atle Gulla J., Andreas Hegle O. and Prange A. (2005).

REVEALING THE REAL BUSINESS FLOWS FROM ENTERPRISE SYSTEMS TRANSACTIONS.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 254-259

DOI: 10.5220/0002530902540259

 SciTePress

processes and structures are not fully understood, de-

cisions may be based on the wrong assumptions and

lead to solutions that do not address the underlying

weaknesses of the existing system. The issue is ad-

dressed by some recent key success factors for en-

terprise systems projects (Esteves-Sousa and Pastor-

Collado, 2000) and also reﬂected in typical problem

indicators for such projects (Gulla, 2004).

However, analyzing the current business processes

is a tedious and challenging task. Workshops, in-

terviews and on-the-job observations are all used to

assess the way people work and the interdependen-

cies between their activities. This involves a num-

ber of people with different backgrounds and possibly

different perceptions of the organization’s processes.

The project needs to allocate time and resources to

the assessment, and the quality of the outcome is hard

to verify. In many cases there is also documenta-

tion available that can be consulted and presented to

the stakeholders. Old project documentation or vari-

ous kinds of user procedures describe how the various

steps of the processes are to be carried out.

Except for the time and resources needed to run

these labor-intensive analyses of existing processes,

there are more fundamental problems related to the

reliability and accuracy of the results. It is not obvi-

ous that people working in different parts of the orga-

nization have the same perception of their processes.

People’s opinions differ, and hidden agendas or power

struggles may hamper the resolution of these differ-

ences. Their attitude towards the change project may

also affect the way they present the current business

processes. Even if they should agree on the overall

processes, they may still ﬁnd it difﬁcult to drill down

to the level of detail needed in the project. The project

needs to know about potential bottlenecks, abilities

to adapt to changing external events, process imbal-

ances, and use of resources in general. Most of these

issues are not documented properly, even though the

people are often aware of these deﬁciencies.

Another interesting issue is the potential discrep-

ancy between the way processes are designed and the

way they are actually run. People tend to ﬁnd ways

around the job descriptions if they for some reason

are not happy with the way they are supposed to work.

Hence, user procedures cannot be assumed to provide

the complete picture of the organization’s processes.

Due to these challenges, many projects do not take

AS-IS analyses of business processes serious enough.

They risk developing the wrong system, or fail to un-

derstand the new processes’ impact on the organiza-

tion and the needs to train employees.

Interestingly, there should be ways of coming up

with more accurate analyses. People leave traces

when they do their jobs, and many of these traces

are stored in enterprise information systems logs. As

more and more of these processes are supported by

the information systems, these systems should be able

to tell us how the real business ﬂow is. A fundamental

problem, though, is how to interpret the logs in terms

understandable to people. There is too much detailed

information in the logs to present to people, and there

is no obvious way of aggregating this information to

a level and a format that can be understood by people

involved in change projects.

3 THE ENTERPRISE

VISUALIZATION SUITE

Enterprise Visualization Suite (EVS), from Business-

cape AS, is a web based process mining package that

enables enterprises to extract explicit process mod-

els and key performance indicators from event logs in

their EIS. EVS aims at giving an exact picture of the

AS-IS situation and a foundation for deﬁning mea-

surable goals for the TO-BE situation. EVS is imple-

mented in Java, has an underlying MySQL database,

and uses Scalable Vector Graphics (SVG) to show

graphical models in the web browser.

Businesscape has currently developed an adapter

for SAP R/3 systems, but EVS is built up of separated

layers and the framework is independent of both spe-

ciﬁc EIS vendors and solutions. The EIS adapters ex-

tract and identify elements like applications, process

hierarchies, document categories, users, user roles,

and departments. Through analysis of event logs and

collections of both document headers and positions,

EVS is able to extract information about when these

model elements where created or modiﬁed, and how

they interrelate. An example of an event log is the

CDHDR (Change Document Header) table in SAP

R/3. As it keeps the history of almost all the doc-

ument changes in the system, it is one of the very

largest database tables in SAP R/3.

Table 1 shows an example of records and columns

in the CDHDR table. As we can see, documents,

users, executed applications, and their interrelations

leave traces in this log. For a certain document, i.e.,

the HANDL

UNIT (Handling Unit) document with

id 0001455075, we can see that it is altered twice by

two different users and applications. By analyzing the

change number we can see that these two alterations

are subsequent. As a result, we know that the appli-

cation LM46 produces a HANDL

UNIT that VL02N

consumes. We are also able to calculate duration mea-

sures as the timestamp for each event is present. In

SAP R/3, LM46 is the transaction code for ”Pick and

Pack by Delivery” and VL02N is the transaction code

for ”Change Outbound Delivery”. An EIS typically

includes dozens of such event logs, including logs

for application executions and document alterations.

However, the structure of how similar information is

REVEALING THE REAL BUSINESS FLOWS FROM ENTERPRISE SYSTEMS TRANSACTIONS

255

Table 1: Examples of data the the CDHDR (Change Document Header) table in SAP R/3

Doc.Type Doc.Id Change Nr. Date Time User Application

HANDL UNIT 0001477919 0008992520 01.04.2004 09:00:49 BARG VLMOVE

HANDL UNIT 0001455075 0008992571 01.04.2004 09:00:52 BARG LM46

HANDL UNIT 0001455075 0008992572 01.04.2004 09:01:26 CI TOR VL02N

LIEFERUNG 0180118548 0008992579 01.04.2004 09:01:25 VIBGF VL02N

MATERIAL 0000000128444 0008992564 01.04.2004 09:04:42 ANTER MR21

(a) Constructed model of the process ”Spare parts processing”

(b) Cause-analysis of execution time variations

Figure 1: Examples of screenshots from EVS

ICEIS 2005 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

256

logged may vary within a single EIS. To cope with

this inconsistency and still keep a general framework,

EVS accesses its data foundation through a meta

model description. The meta model says which event

logs that should be analyzed and where information

attributes within the event logs are located. These in-

formation attributes typically include current and pre-

vious activity, executing application, involved users,

timestamps and textual descriptions. The meta mod-

els may be individually speciﬁed for each installation.

However, for users with similar EIS, i.e. users with

SAP R/3, the structure of how the log information is

located is mostly identical. For such users, meta mod-

els can be reused and only minor modiﬁcations are

necessary. The EIS Adapter is also responsible for

datacleansing. There are several issues and challenge

related to the data quality of event logs, including re-

dundant information and missing values.

The modelstore database is the foundation for both

process model construction and statistical perfor-

mance analysis. Model visualization and analysis

functionality is made available in a web based user

interface. As a result, EVS can be used and accessed

from multiple sites within the organization and by ex-

ternal consultants. Based on the output from EVS

and other information sources, a change team can

evaluate and modify business processes and EIS con-

ﬁgurations. Executions of the redesigned business

processes are then again input for EVS and future

change projects.

4 VISUALIZING BUSINESS

FLOWS

Process models tend to be both large and complex

when many processes are involved. An example of

such complexity appearances is the reference models

of SAP R/3. These models are represented as Event

Process Chains (EPC) (Curran and Keller, 1997),

which lack proper abstraction mechanisms and dupli-

cate event information. When the EVS model formal-

ism was created, two aspects were in focus. First, the

models had to be presented with such simplicity that

any user can grasp the meaning instantly. Second, em-

pirical performance indicators should be presented in

the models, providing users with information about

load distribution and execution times. EVS deﬁnes a

hierarchy of processes and the resource ﬂow between

them. In the model represenation, a process consists

of sets of sub processes or activities. Processes are

shown as arrowed boxes while activities are shown

as boxes with rounded corners. Activities are con-

nected to the executable applications in the EIS, and

their executions are traceable in the event logs. The

dependencies between activities are found by identi-

fying which resources the activities consume and pro-

duce. Dependencies in the higher process layers are

deﬁned as the aggregation of dependencies between

their activities.

Figure 1(a) shows screenshots of how constructed

business process models and empirical performance

indicators are presented in EVS. The user can navi-

gate through the set of layers in the process hierarchy.

The present layer is shown in the main map of the

model view. The super processes and their relation-

ships are shown in a navigation map (upper left corner

of the model view). Both the main model and the nav-

igation map are interactively responsive. By selecting

a process in the navigation map, its sub processes and

their resource ﬂow can be shown in the main map.

If the user expands a super process in the main map,

the content of the present main map is represented in

the navigation map and main map becomes replaced

by sub processes. These can then again be expanded,

and so forth. Users do also have the option of navigat-

ing upwards in the process hierarchy. In ﬁgure 1(a),

the process ”Spare parts processing” is selected, and

its sub activities and their relationships are presented

in the main map.

The size of the circles on each activity indicates

the number of executions, while the size of darker

pie within the circles indicivates the average execu-

tion time. In ﬁgure 1(a), we can see that the activity

”Assign purchase req.” is executed most frequently,

while the activity ”Create contract for spare parts” has

the longest average execution time. The pie charts on

the connectors indicate relative distribution of multi-

ple input or output traﬁc.

To enhance the expressiveness, EVS also exploits

interactive opportunities of the web. Information that

can be shown by clicking on a process or activity

includes produced and consumed resources, and in-

volved user roles and departments.

5 ANALYZING BUSINESS

PROCESS PERFORMANCE

In order to get a detailed understanding of processes

and their execution history, statistical reports that sup-

plement the model map are necessary. In EVS, users

can generate such reports for any selection of interest-

ing processes or activities. Graphs that show the dis-

tribution of measures over time enable users to iden-

tify peaking periods, and tendencies over time. For

process analysis, such measures include throughput

or execution time. By aligning a set of processes in

the same diagram the user can identify if correlations,

propagations of peak values, etc. are present.

Two important issues for process change projects

is to identify causes of variations in process execu-

REVEALING THE REAL BUSINESS FLOWS FROM ENTERPRISE SYSTEMS TRANSACTIONS

257

tions. In order to perform such analyses, data from

the relational database, modelstore, is exported to a

ﬂattened data set structure. In these data sets, process

paths of subsequent activities are individually mea-

sured with respect to start time, end time, user, de-

partment, etc.The ﬂattened data sets can further be

extended by including new features that are found in

other information sources or extracted from cluster-

ing analysis or combinations of the existing features.

Having a deﬁned data sets available, we are able to

identify typical feature co-occurrences and ﬁnd re-

lationships between certain process execution behav-

iors.

Figure 1(b) shows an example of such cause analy-

ses for the activity ”Create contract for spare parts”.

Here we are identifying how features are co-occuring

with clusters of execution time values. Two appar-

ent clusters are identiﬁed, namely high and low. The

K-means algorithm is applied to ﬁnd appaerent clus-

ters of the continuous variable. The list below the fre-

quency diagram show how values of other features are

co-occuring with the respective cluster assignments.

As we can see, only one user role has executed the

activity, and about 2/3 of the executions are in the low

category. We can also see that low execution time is

more apparent in the winter months than in the sum-

mer months.

6 DISCUSSION OF CASE

EVS has been tried out on data from a SAP R/3 im-

plementation at a midsize Norwegian company. SAP

R/3 is delivered with a reference model that shows

best practice business processes. However, this refer-

ence model is not sufﬁcient for documenting their real

business ﬂows, as their implementation included sev-

eral add-ons, speciﬁc conﬁgurations, and interfaces to

external systems. The reference model of SAP is nei-

ther able to show the load distribution of actual and

past execution instances. When EVS was applied to

give a picture of their real business ﬂow and AS-IS

situation, we faced several challenges.

One of the main challenges is how to deal with the

many to many relationships between applications in

the event log and the processes they belong to. In

SAP R/3, transactions belongs to multiple business

processes. The challenge arises as the event logs do

not express which of the business processes that are

involved in a speciﬁc execution of the transaction.

As long as EVS just collected data through the de-

veloped SAP adapter, it could not access event logs

from business processes that were executed in exter-

nal enterprise system. SAP and other EIS vendors

have recently developed process oriented middleware

solutions that ensures process oriented integration of

separated enterprise systems. The solution from SAP

is SAP Netweaver. Future work and effort will in-

clude examining if event logs from such middleware

can enable EVS to show the real business ﬂow across

separated enterprise systems, and even across organi-

zations.

In spite of these problems, EVS has shown itself to

provide valuable insight into the business ﬂow of the

organization. It can deal with the complexities of a

real case, and some of the analysis results were both

interesting and surprising.

7 RELATED WORK

Our approach is related to work both in the academia

and commercial area. We will group these activi-

ties into two categories, namely process discovery and

Business Activity Monitoring (BAM). Both categories

aim at extracting information from event logs, but the

ﬁrst category focuses on extraction of process models

while the latter category focuses on extraction of key

performance indicators.

There are several academic research activities that

are working within the areas of process discov-

ery. Cook and Wolf have shown the applicability of

process discovery within different domains (Cook and

Wolf, 1998)(Cook et al., 2004). In (Cook and Wolf,

1998) they investigate how neural nets, Markovian

approaches and purely algorithmic approaches can

be used to discover models of software engineering

processes.Van der Aalst, et al., describes how the

process mining tool EMiT is used to create Petri nets

from event logs that are represented in a standardized

XML format (van der Aalst et al., 2003). To support

the practical application of EMiT, various adapters

have been developed that allow for the translation of

system-speciﬁc event logs to their XML format. Hav-

ing a Petri net model as a foundation, it is possible to

map the content to less expressive model representa-

tions like EPC. Their approach with use of adapters

and a standardized format for process model con-

structions is similar to EVS’ use of EIS adapters and

the modelstore database. Process Miner is another

tool that is created to visualize process models from

event logs (Schimm, 2004)(van der Aalst et al., 2003).

Its approach is to identify nested building block of

sequences, parallels, alternatives, and loops in the

event logs. Based on these blocks, Process Miner

creates a process model representation. Similar to

EVS, Process Miner has also a hierarchical view of

its processes.

Activities within the BAM area are mostly domi-

nated by commercial software vendors, but there is

also some relevant research in the academic world.

In (Grigori et al., 2004) they have developed a set

ICEIS 2005 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

258

of tools that support analysis, prediction, monitoring,

control and optimization of business processes. ARIS

Process Performance Manager (PPM) is a software

package by IDS Sheer that monitors business process

performance indicators like ﬂow times, bottlenecks,

and utilization. ARIS PPM is a part of the ARIS

tools, which also includes a design platform for busi-

ness process modeling (Sheer, 1998). Other commer-

cial activities within the area of BAM include Cognos

(Notice Cast), FileNet (Process Analyzer), Hyperion

(Business Process Management Suite), Tibco (Busi-

ness Factor). Tools like SAP Reverse Business En-

gineer (RBE) and Intellicorp LiveModel can be used

to monitor how frequent parts of the SAP system are

being used.

8 CONCLUSIONS

The successful execution of change projects requires

that the current processes are well understood and

documented. With the manual approach, the task is

time-consuming and the resulting models are often

unreliable or inaccurate. EVS promises to speed up

the assessment of the AS-IS situation and produce

models and analyses that are at a more suitable level

of detail. It is a tool that supports both incremental

improvements of business processes as well as the

more radical approach favored in business process

reengineering projects.

The ﬁrst version of EVS is now available, and we

are analyzing the data from the SAP R/3 installations

of two Norwegian companies. Both of these two cases

show promising results, revealing some interesting

process data that were not previously known. We are

also considering taking part in reengineering projects

that do not involve R/3 installations, though this re-

quires that we implement adapters for other enterprise

systems.

A problematic aspect of EVS is the construction of

user-friendly hierarchical process models from these

low-level enterprise systems logs. We need to make

sure that the models do not get too detailed, but still

include all the relevant information for assessing the

quality of the processes. Building up semantically

meaningful hierarchies is a non-trivial task.

Another issue here is how to deal with log trans-

actions that can be part of several business processes.

Future work concentrates on graphical presentations

of important aspects of the business processes and

more powerful data mining facilities. We would for

example like to provide process cost estimates and

predictions of Service Level Agreement (SLA) out-

comes. The advantage of our analyses will be that we

can relate the numbers directly to the organization’s

business ﬂows.

REFERENCES

Bancroft, N. H., Seip, H., and Sprengel, A. (1997). Imple-

menting Sap R/3 : How to Introduce a Large System

into a Large Organization, 2nd Edition. Prentice Hall.

Cook, J. E., Du, Z., Liu, C., and Wolf, A. L. (2004). Discov-

ering models of behavior for concurrent workﬂows.

Computers in Industry, 53(3):297–319.

Cook, J. E. and Wolf, A. L. (1998). Discovering models

of software processes from event-based data. ACM

Transactions on Software Engineering and Methodol-

ogy, 7(3):215–49.

Curran, T. and Keller, G. (1997). SAP R/3 Business Blue-

print: Understanding the Business Process Reference

Model. Prentice Hall PTR.

Esteves-Sousa, J. and Pastor-Collado, P. (2000). Towards-

the uniﬁcation of critical success factors for erp imple-

mentations. 10th Annual Business Information Tech-

nology (BIT) 2000 Conference, Manchester.

Grigori, D., Casati, F., Castellanos, M., Dayal, U., Sayal,

M., and Shan, M.-C. (2004). Business process intelli-

gence. Computers in Industry, 53(3):321–343.

Gulla, J. (2004). Understanding requirements in enterprise

systems projects. Proceedings of the 12th IEEE In-

ternational Requirements Engineerings Conference,

pages 163–172.

Offen, R. (2002). Domain understanding is the key to suc-

cessful system development. Requirements Engineer-

ing, 7(3):172–175.

Schimm, G. (2004). Mining exact models of concurrent

workﬂows. Computers in Industry, 53(3):265–281.

Sheer, A. (1998). ARIS - Business Process Modeling.

Springer-Verlag.

van der Aalst, W. M. P., van Dongen, B. F., Herbst, J.,

Maruster, L., Schimm, G., and Weijters, A. J. M. M.

(2003). Workﬂow mining: A survey of issues and ap-

proaches. Data Knowl. Eng., 47(2):237–267.

van Everdingen, Y., van Hillegersberg, J., and Waarts, E.

(2000). Enterprise resource planning: ERP adoption

by European midsize companies. Communications of

the ACM, 43(4):27–31.

REVEALING THE REAL BUSINESS FLOWS FROM ENTERPRISE SYSTEMS TRANSACTIONS

259
