DATA INTEGRATION AND USER MODELLING:

An approach based on Topic Maps and Description Logics

Mourad Ouziri

University Paris V René Descartes, 45 rue des Saints-Pères 75270 Paris Cedex 06

Christine Verdier

(1)

, André Flory

(2)

LIRIS-Lyon 2

(1)

,LIRIS-INSA de Lyon

(2)

, bât. Blaise Pascal, 7 av. J. Capelle, 69621 Villeurbanne Cedex

Keywords: Data integration, Intelligent modelling of user profile, Topic Maps, Description logics

Abstract: In the framework of intelligent information systems design, we present an intelligent data integration and

user profile modelling. Our approach uses jointly Topic Maps and Description Logics. Topic Maps are used

to represent semantic of distributed data. Using the formalized semantic, the distributed data is merged into

one repository. Then, Description Logics are used over this repository to compute implicit semantic

relations using logic reasoning such as subsumption. We present then a new user profile management which

uses qualifying attributes rather than identifying attributes. Description Logics are used to formalize profiles

in order to maintain consistency of right attribution to profiles.

1 INTRODUCTION

Web-based applications require access to multiple

sources of data to supply relevant information. This

relevance is due to the research, the choice of the

user and his browsing. So, searching the good,

relevant, up-to-date information in this huge volume

of data is a complex task which is difficult to be

done manually. Many systems are studied in the

semantic web community about this subject. The

main question is how to reconcile the large volume

of data and the precise choice of a user. We remark

that the Web offers heterogeneous sources

concerning data heterogeneity, structure

heterogeneity and semantic heterogeneity. Data

heterogeneity is due to the use of different data types

(integer, string, etc.), measurement units (meters,

miles, etc.) and scales (month, day, year, etc.)

associated to the values. This type of heterogeneity

is solved with conversion rules defined between the

data sources and the federated schema. Structural

heterogeneity consists in using different data

structures to represent the same object. For example

the object Adress can be represented by a tuple

(number, street, zip, city) or by a string. Semantic

heterogeneity is crucial and is seen at conceptual

level. Several cases can be noticed. An object can be

represented as a attribute, or as an entity. So the

merging of different data source can deal with

semantic association problems. Semantic

heterogenity can be observed also with synonyms,

homonyms, generalized ans specialized terms: for

example drug and medicine.

So we propose in this paper a web-based interface

query multiple data sources that have been

merged. Data semantic is garanteed. To build this

interface, we use Topic maps to represent

knowledge, description logics to provide automatic

reasoning on the knowledge and to help in user

profiles.

We present in this first paragraph the related

works, th

en we continue with a presentation of the

Topic Maps and Description Logics approach and

then we finish with the presentation of our system.

2 RELATED WORKS

2.1 Prior d

ata integration approaches

Two main approaches concern the database

community. The first approach concerns the data

integration in the query. The query language is made

to formulate and process multi-databases queries.

The heterogeneity is resolved through the query

171

Ouziri M., Verdier C. and Flory A. (2005).

DATA INTEGRATION AND USER MODELLING: An approach based on Topic Maps and Description Logics.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 171-175

DOI: 10.5220/0002532701710175

 SciTePress

directly by the user. This approach is really difficult

to process when we have to query large and

numerous databases (Breitbart, 1990). Federated

databases consist to integrate the different views of

databases into a unique and global conceptual

schema (Sheth, 1990). Queries are specified on the

global schema and then are parsed and shared into

sub-queries. Each sub-query is sent only to one

database. The major drawback of this approach is

that it is often difficult to build a global schema

because of data heterogeneities. The third approach

is a wrapper-mediator approach (Molina, 1997)

(Karp, 1995). A wrapper is designed for each

datasource and its role consists in translating data

into the common language of the mediator. Then,

the mediator uses the data provided by the wrapper

to build a global schema. Sub-queries are evaluated

by the respective wrappers.

2.2 Ontology-based approach

Ontology represents a pertinent way to resolve

problems related to heterogeneity. Ontology plays an

important role in the knowledge representation. It

allows sharing semantic interpretation of structural

units. Ontology is mainly used like a global schema

of datasources and a query interface. Ontology

concepts are linked to datasources through a global

meta-model. Theses links are used ot identify the

relevant datasources and to transform queries into

sub-queries with the ontology. In the literature, three

main ontology approaches are proposed (Wache,

2001) (Mena, 1998): simple, multiple and hybrid

ontologies. Buster (Meyer, 2001) uses hybrid

ontology. In this system, the ontology is seen as a

knowledge base on which semantic integration is

based. The terms of a datasource are defined with a

local ontology. The integration in Buster consists to

define a common ontology which is used to annotate

the terms resulted from the first annotation. Multiple

ontologies are used in Observer (Mena, 2000). It

associates an ontology to each datasource. This

association is formalized by links between the

concepts of the ontology and the terms of the

datasource. The datasource integration is done with

semantic links (synonymy, hyponymy, disjunction,

etc.) between the concepts of the ontologies.

2.3 Logic-based approaches for data

integration

Description logics (DL) are used to represent

dependencies between concepts in different

datasources in (Catarci, 1993). On these

dependencies are generated reasoning. They are

represented at intentional and extensional levels and

make the connections between concepts belonging

to different datasources. The intentional and

extensional dependencies are distinctly processed

because two equivalent concepts in different

datasources do not imply the equivalence of the

extensions. The knowledge base inter-schemas is

realized with assertions which specify equivalence

and subsumption relations. Therefore, a global graph

is generated from the assertions and used to evaluate

the queries. In (Levy, 1999), two logic-based

approaches are presented. The first approach is

called

global as view. The global relation is a set of

relations. Each relation is described with the

relations of the datasources, which indicates how to

obtain the instances. Queries are specified on the

global relations are rewrited using their descriptions.

The second approach is called

local as view. The

datesources are described with the global relations.

This opposite approach is more interesting when the

updating of the datasources is frequent. Other logic-

based solutions are presented in (Goasdoué, 2000)

and (Calvanese, 1998).

2.4 Web-based approach for data

integration

Data integration represents an important task to

access and query data in a coherent way. In the Web,

data are represented with semi-structured HTML or

XML models. For HTML documents, data

integration consists to link HTML (or XML)

documents with each other by hyperlinks. This is a

static and rigid approach because semantic

relationships are not considered. XML-based data

integration is realized with a query language for

querying multiple XML documents using one query

(Cohen, 2003) or by providing a uniform view of

multiple XML documents (Camillo, 2003). To

integrate XML documents, a mechanism to identify

multiple instances of a same real object is proposed

in (De Brum, 2002). Semi-structured data models,

OEM (Goldman, 1996) and XML, are used in data

integration process (Papakonstantinou, 1995)

(Gardarin, 2002). This type of integration is not

useful for expressing semantic. XML does not give

any semantics about taggs. The suitability of DL for

data integration is illustrated in some projects: SIMS

(Arens, 1993) and PICSEL (Goasdoué, 2000). In

these systems, datasources are linked together and

the knowledge is expressed manually.

ICEIS 2005 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

172

3 BACKGROUND

3.1 An overview of Topic Maps

Topic Maps (Sigel, 2000) is a paradigm used ot

formalize and organize human knowledge to make

creation and retrieval easier in computer processing.

It is also used as a mechanism for representing and

optimizing resource access. As semanic networks,

Topic Maps builds a structured semantic link

network on these resources (Freese, 2000). A topic

map is built with topics in a networked form. A topic

can be anything regardless whether it exists or not. It

is the formal representation of any subject, abstract

or real in a computer system such as a person, John,

the earth, the planet, etc. Topics are linked together

by associations which express some semantics.

Topic Maps applications define the nature of the

associations and the role played by the topics in

these associations. For example, the topics

customer

and

doctor can be related by the association examine

with the respective roles

patient and doctor. So,

semantics is specified by the association and

especially by the roles. Associations are used ot

express knowledge between topics and not between

occurrences. So topics and associations represent the

abstract part of a topic map. The concrete part is

represented by occurrences which are resources

linked to topics. In 1999, a standard defining the

Topic Maps model and its syntax was edited by

ISO/IEC 13250 (ISO/IEC, 1999).

3.2 An overview of Description Logics

Description Logics (DL) are logics developed to

represent complex hierarchical structures and make

reasoning facilities on these structures (Borgida,

1995). DL are used to build ontologies for semantic

web (Horrocks, 2002). A DL is composed of two

parts: abstract knowledge (Tbox) and concrete

knowledge (Abox). Concrete knowledge represents

a set of facts which are expressed by assertions on

individuals. Abstract knowledge is expressed with

concepts and roles. Concepts are unary predicates

which represent an abstraction of individuals. Roles

are binary predicates. They represent relations

between concepts.

4 DATA INTEGRATION USING

TOPIC MAPS AND DL

We present an integration process that combines

Topic Maps and DL to build a semantic data

integration. First, data sources are modeled with

Topic Maps to represent distributed knowledge.

Secondly, we use DL to represent the constraints.

Constraints are useful in data integration to deduce

implicit relations between concepts. The integration

process is shown in the following figure:

Domain

ontology

Distribute

Topic

Maps

DS1 DS2

reasoning

Figure 1: Data integration using TM and DL

The datasources DS1 and DS2 are represented

with Topic Maps. Two datasources types are

considered: relational databases and XML

documents. For relational databases, topics represent

tables and attributes. For XML documents, topics

represent tags. Tables (or tags) are represented by

topic and attributes (or sub-tags) too. These topics

are connected to the ontological concepts they

represent using the

subjectIndicatorRef tag. Semantic

integration based on Topic Maps is so natural. It

consists to merge topics referencing the same

ontological concept into one topic in the federated

topic map.

Table 1: Representation of tables (tags) and attributes

(sub-tags)

/*a relational table or an XML tag*/

<topic name=person

</subjectIdentity>

</topic>

/*a table attribute or a sub-tag*/

</subjectIdentity>

</topic>

Then, description logic reasoning is used to

provide a consistent federated topic map because it

automatically computes implicit relations between

concepts. Let’s consider that the datasource DS1 and

DS2 contain the two descriptions:

: person

Name.String

Adress.String …

: person

Name.String

Adress.String …

: patient

Human

disease.String

…

>=1

disease

: patient

Human

disease.String

…

>=1

disease

DATA INTEGRATION AND USER MODELLING: An approach based on Topic Maps and Description Logics

173

As traditional logics, DL is not able to make

reasoning on distributed knowledge bases. If we do

not use topic maps (especially the subjectIdentity

concept), DL reasoning does not infer any relation

between person and patient.

Semantically, it is not correct.

Now let’s consider that person is numan through

the subjectIdentity tag of the topic map. So:

Therefore, DL reasoning infers that

patient person and gives a semantic connection

between the datasources DS1 and DS2.

5 USER PROFILES

We propose in this section to describe our system

build on the previous integration data and useful for

defining user profiles.The maor idea is to represent

user profiles with qualifying attributes and not with

traditional identity attributes, user-id and password.

Therefore, user profile are represented and managed

at the semantic layer. We use DL to define

automatic and coherent management user profiles.

Let’s consider the following DL knowledge base

of user profiles:

These 5 profiles are described by the qualifying

attributes name, category and specialty. With the DL

reasoning, theses profiles are automatically

organized by subsumption relationship.

When a profile is modified, its hierarchy is

automatically updated. If a new profile is defined, it

is inserted in the hierarchy at the most adequate

position according to its description. This hierarchy

is very important for a coherent attribution of access

rights to the profiles. If we grant the access right d1

to the profile Doctor, reasonably, this access right

should be also granted to the profiles Specialist,

Generalist and Overspecialized which are Doctors:

person

patient

As a general rule, the following formula should be

checked for all the profiles:

∀ P1,P2∈{profiles}, if P1 subsumed_by P2 then

P2.access_rights ⊆ P1.access_rights

We notice that the most specific profile has the

maximum access rights because it gets those of its

parents. This formula allows to grant the access

rights to the profiles in a coherent and automatic

way. Traditionally, access rights have to be specified

for each profile. In our system, the granting is

automatically performed without human

intervention. As the profiles and the access rights are

defined, the system identifies the users and

automatically assigns them to the most adequate

profile. For that, users are also described with

qualifying attributes. Unlike profiles, the users are

described in the Abox. Let’s consider the following

Abox:

So the profiles are represented in the Tbox and the

individuals are represented in the Abox. With the

DL reasoning, the system classifies the users

according to the Tbox and Abox with the biggest

access rights. The users John and Peter are

employees and respectively with a specialty

“radiology” and no specialty. So they will be

classified in the profiles Specialist and Generalist.

6 CONCLUSION

We have jointly used Topic Maps and DL for

semantic data integration. The most advantage is to

perform reasoning on distributed knowledge.

Translating knowledge from Topic Maps to DL is

not always possible. Topic Maps formalism includes

a constraint language and constructors that is very

: human

Name.String

Adress.String …

doctor

specialist

doctor

generalist

doctor

overspecialized

doctor

specialist

doctor

specialist

doctor

generalist

doctor

generalist

doctor

overspecialized

doctor

overspecialized

: human

Name.String

Adress.String …

DSDS

: patient

disease.String

human

…

>=1

disease

: patient

disease.String

human

…

>=1

disease

Table 2: Example of a TBox representing user profiles

Employ (e1) Employ (e2)

Name (e1, « John ») name (e2, « Peter »)

Category (e1, « medical ») category (e2, « medical »)

Specialty (e1, « radiology »)

Doctor Employ Category = « medical »

Employ

name.String

category.String

specialty.String

Specialist Doctor

specialty

>=1

Generalist Doctor

specialty

OverSpecialized

Doctor

specialty

Doctor Employ Category = « medical »

Employ

name.String

category.String

specialty.String

Employ

name.String

category.String

specialty.String

Specialist Doctor

specialty

>=1

Specialist Doctor

specialty

>=1

Generalist Doctor

specialty

Generalist Doctor

specialty

OverSpecialized

Doctor

specialty

OverSpecialized

Doctor

specialty

employ

secretary doctor

medical administrative specialist generalist

overspecialized

employ

secretary doctor

medical administrative specialist generalist

overspecialized

ure 2: Automatic

rofiles or

anization

ICEIS 2005 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

174

expressive. But DL are based on reasoning

algorithms defined on a set of constructors. Thus,

the expressivity of DL is restricted to the reasoning

algorithms. It represents a paradox between the two

formalisms. In our future work, we try to improve

the constraint language specification of Topic Maps.

Constructors will be built to define constraints on a

Topic Maps knowledge base and perform automatic

reasoning.

REFERENCES

Arens, Y., Chee, C., Hsu, C., Knoblock, C., 1993.

Retrieving and integrating data from multiple

information sources. In Journal of Intelligent and

Cooperative Information Systems, vol.2, n°2, p. 127-

158

Borgida, A., 1995. Description Logics in data

management. IEEE Trans. On knowledge and data

engineering, vol.7, n°5, p.671-682

Breitbart, Y. and alii, 1990. Final report of the workshop

on multidatabases and semantic interoperability.

University of Kentucky, Department of Computer

Science, Lexington, KT 188-91, November 2-4.

Calvanese, D., et alii, 1998. Knowledge representation

approach to information integration. In proc. Of AAAI

Workshop on AI and information integration, p. 58-65

Camillo, S.D., Heuser, C.A., Mello, R.S., 2003. Querying

heterogeneous XML sources through a conceptual

scheman. Proc. of ER, p. 186-199.

Catarci, T., Lenzerini, M., 1993. Representing and using

interschema knowledge in cooperative information

systems. Journal of intelligent and cooperative

information systems, vol.2, n°4, p.375-398

Cohen, S., et alii, 2003. Xsearch: a semantic search engine

for XML. VLDB, p. 45-56

De Brum Saccol, D., Heuser, C.A., 2002. Integration of

XML data. Proc. Of EEXTT, p. 68-80

Freese, E., 2000. Using Topic Maps for the representaion,

management and discovery of knowledge. XML

Europe 2000, Palais des congrès, Paris, 12-16 June.

ISO/IEC 13250, 1999. Topic Maps, Dec. ISO/IEC FCD

Gardarin, G., Mensch, A., Tomasic, A., 2002. An

introduction to the e-XML data integraiton suite. Proc.

Of EDBT, p. 297-306

Goasdoué, F., Lattes, V., Rousser, M.C., 2000. The user of

CARIN language and algorithms for information

integration: the PICSEL project. International Journal

of Cooperative Information Systems (IJCIS), vol.9,

n°4, p. 383-401

Goldman, R., Chawathe, S., Crespo, A., McHugh, J.,

1996. A standard tectual interchange format for the

object exchange model (OEM). Department of

computer science, Standford University, California,

USA, 5 p.

Horrocks, I., Patel-Schneider, P.F., Van Harmelen, F.,

2002. Reviewing the design of DAML+OIL: an

ontology language for the semantic web. Proc. Of 18th

National Conf. On Artificial Intelligence, p. 792-797

Karp, P., 1995. A strategy for database interoperation.

Journal of computational biology2, p.573-586

Levy, A.Y., 1999. Logic-based techniques in data

integration. Workshop on logic-based articifial

intelligence, Washington DC, June 14-16, 27 p.

Mena, E., Illarramendi, A., Kashyap, V., Sheth, A., 2000.

Observer: an approach for query processing in global

information systems based on interoperation across

pre-existing ontologies. In the Int. Journal Distributed

and Parallel Databases (DAPD), vol.8, n°2, p.223-271

Mena, E., Kashyap, V., Illarramendi, A., Sheth, A., 1998.

Domain specific ontologies for semantic information

brockering on the global information infrastructure.

Int. Conf. On Formal ontologies in information

systems. FOIS’98, Italy, 15 p.

Meyer, R., et alii, 2001. Intelligent brockering of

environmental information with Buster System. In

Informaiton Age Economy: proc. Of the 5th Int. Conf.

‘Wirtschaftsinformatik’, Physica-Verlag, 8p.

Molina, H.G., et alii; 1997. The TSIMMIS approach to

mediation: data models and languages. In Journal of

intelligent information systems, p.117-132

Moore, G., Nishikawa, M., 2003. The Topic Maps

Constraint Language. ISO/IEC 13250. Available at

http://www.isotopicmaps.org/tmcl

Papakonstantinou, Y., Garcia-Moulina, H., Widom, J.,

1995. Object exchange across heterogeneous

information sources. Proc. Of IEEE int. Conf. On

Data Engineering, p.251-260

Pepper, S. Moore, G., 2001. XML Topic Maps (XTM). 1.0.

TopicMaps.Org Authoring Group, Aug. 2001.

Available at: http://topicmaps.org/xtm/index.html

Sheth, P., Larson J.A., 1990. Federated database system

for managing distributed, heterogeneous and

autonomous databases. ACM Computing surveys,

ACM Press, vol.23, n°3, p.183-236

Sigel, A., 2000. Towards knowledge organization with

Topic Maps. XML Europe 2000, Palais des congrès,

Paris, 12-16 June.

Wache, H., et alii, 2001. Ontology-based integration of

information-a survey of existing approaches.

Workshop ontologies and information sharing. IJCAI

2001, 10 p.

DATA INTEGRATION AND USER MODELLING: An approach based on Topic Maps and Description Logics

175
