ACCESS CONTROL MODEL FOR GRID VIRTUAL

ORGANIZATIONS

Nasser B., Benzekri A., Laborde R., Grasset F., Barrère F.

Insitut de Recherche en Informatique de Toulouse-IRIT, Paul Sabatier Univeristy, 118 route de Narbonne,Toulouse,France

Keywords: Grid, Distributed systems, Security, Access control, RBAC, OrBAC

Abstract: The problems encountered in the scientific, industrial and engineering fields entail sophisticated

processes

across widely distributed communities. The Grid emerged as a platform that has a goal enabling coordinated

resources sharing and problem resolving in dynamic multi-institutional Virtual Organizations (VO). Though

the multi-institutional aspect is considered in the grid definition, there is no recipe that indicates how to

fabricate a VO in such environment where mutual distrust is a constraint. Excluding a central management

authority, the different partners should cooperate to put in place a multi-administrated environment. The

role of each partner in the VO should be clear and unambiguous (permissions, interdictions, users and

resources to manage…). Organizing a large scale environment is error prone where not well formalized

models lead to unexpected security breaches. Within the access control models RBAC has proved to be

flexible but is not adapted to model the multi-institutional aspect. In this context, we propose a formal

access control model, OrBAC (Organization Based Access Control model), that encompass concepts

required to express a security policy in complex distributed organizations. Its generality and formal

foundation makes this model the best candidate to serve as a common framework for setting up Virtual

Organizations.

1 INTRODUCTION

The problems encountered in the scientific,

industrial and engineering fields entail a

sophisticated process across widely distributed

communities involving huge data amounts to be

managed, analyzed using complex computing

applications and finally stored (Fedak,2001)(Foster,

1997)(Baru,1998). The needed cooperation across

the communities is no more trivial file exchange but

rather direct access to computers, software, data, and

other resources. It involves hundreds of processes

that necessitate acquiring resources dynamically and

communicate efficiently.

The grid has emerged as a platform that has as

goal

enabling coordinated resource sharing and

problem solving in dynamic multi-institutional

virtual organization (Foster, 2001). The grid as a

middleware leverages the cooperation level between

the different partners higher than primarily

connectivity level. It offers layers and protocols (see

http://www.gridforum.org/) that hide the underlying

nfrastructure (computer, hard disk, CPU,

services…), facilitate their exploitation, and employ

them in different scenarios as Data grids

(Baru,1998), Computing grids (Foster,1997) and

Desktop grids (Fedak,2001). From conceptual point

of view, the different communities in a grid

environment, federating into an alliance for a certain

goal, put in place a Virtual Organization. The

Virtual Organization (VO) constitutes the common

shared space between the different institutions. It

embraces topics as shared resources (data, computer

hardware and software), sharing relationships, fine-

grained access control…

Though the Grid defines the VO notion, it

doe

sn’t indicate how to create and manage this large

scale, multi-organizational structure. Constructing a

VO necessitates tracing its boundaries, specifying

the different access rights within it and assuring

management during its life time.

Solutions as the Community Authorizations

Serv

ice (CAS) (Cannon, 2003) allow enforcing

access control policies within the VO using X.509

extensions. The extensions include low level user’s

permission to grid resources as read/write file

permissions. Another system is the Virtual

Organization Management System (VOMS)

(Alfieri,2003), where a server supplies the user with

152

B. N., A. B., R. L., F. G. and F. B. (2005).

ACCESS CONTROL MODEL FOR GRID VIRTUAL ORGANIZATIONS.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 152-158

DOI: 10.5220/0002535001520158

 SciTePress

an X.509 certificate extended with role and group

information. The destination resource needs to know

the access policies concerning the role/group to

make authorization decisions.

Other projects as GRASP (Djordjevic, 2004) and

DAME (Russell,2004) offer architectures based on

X.509 certificates to enable formation of VOs

responding to their proper needs.

These aforementioned solutions propose

mechanisms to put in place a Virtual Organization

by enforcing a certain access control policy.

However there is no clear method how such policy

would be conceived. Recalling that each partner

needs to keep control on his assets where delegating

others to specify the way to use his resources or its

access control policy is often not acceptable.

A central management of the shared space is

then excluded and the different partners should

cooperate to create a scalable, dynamic, multi-

administrated system.

As a first step, we think that the VO should refer

to abstract entities rather than concrete users and

resources. Abstraction improves scalability, enables

adding users and resources dynamically according to

the local administrative domain policy. As a second

step, the relations between the different entities have

to be specified. Informally specifying these relations

is error prone causing potential security breaches. It

is judicious to achieve these two steps within a

formal access control model that governs the shared

space (Samarati).

Towards a dynamic creation of virtual

organizations in a multi-domain grid environment,

we start by introducing the Grid along with the

complexities confronted in a decentralized dynamic

environment. The need for an access control model

is emphasized and within this context RBAC and its

limits are reviewed (Sandhu 1996)(Sandhu 1999).

We then propose OrBAC (Organization based

Access Control model) (Abou El Kalam, 2003)

(Cuppens,2003) as the access control model that

specifies the different relationships within the VO.

OrBAC abstracts “users, object and action” with

“role, view and activity” and models flexibly the

different responsibilities within a VO. Finally, we

show how the grid environment can be modelled

using OrBAC and conclude with the future works.

2 GRID

The grid has emerged as a platform that has as goal

enabling coordinated resource sharing and problem

solving in dynamic multi-domain virtual

organization (Foster 2001).

Figure 1: Multiple partners participate in different VOs

The grid is founded on the idea of dispersed

resources as well as applications that necessitate

acquiring these resources dynamically on demand.

This on-demand approach provides tremendous

values toward scalability, in addition to aspects of

enhanced reusability. The resources are

heterogeneous (devices, HD, CPU, clusters…) and

attributed by multiple organizations. Take for the

example in Figure 1, a physicist at “Lab1” uses a

simulation application at a laboratory “Lab2” and

then analyzes the data using certain application

using a cluster in “Enterprise3” and finally stores the

whole results at a storage provider.

The different organizations in a grid

environment, federating into an alliance for a certain

goal, put in place a Virtual organization. The Virtual

Organization (VO) constitutes the common shared

space between the different partners. An

organization may participate in several Virtual

Organizations for different cooperation purposes

(ex. Lab2).

The Virtual organization creation embraces

topics as management of shared resources and

specification of sharing relationships for precise

levels of control over how shared resources are put

in place and used.

Creating a VO under a single administration, that

is one partner controlling the shared space, is not

always acceptable. A partner in a VO may be a rival

in another, so delegating him the control and

management of local resources is inadmissible.

Each domain has to manage its resources locally

taking into consideration the cooperation services’

availability. For example, a storage provider may

need to move the data on other storage devices

locally for maintenance reasons without referring

back to the client.

Excluding a central authority, the VO requires

scalable multi-administration by the involved

partners.

ACCESS CONTROL MODEL FOR GRID VIRTUAL ORGANIZATIONS

153

By multi-administration we don’t mean a

domain with multiple administrators having the

same rights, but rather an environment with different

administrators having each partial administration

rights within the whole structure (Wedde,2003).

Though the grid considers inter domains aspects in

virtual organization, it doesn’t specify how to put in

place such a space. The boundaries of a VO should

be defined as well as the responsibilities of each

organization within it. An access control model is

needed to avoid informal methods’ errors and

security breaches.

An access control model has to specify the

relations between the entities within the VO. Since

we are dealing with large scale structure and

dynamic resources allocation within multi-

administered environment, the access control model

should be compliant with that. An access control

management model should consider the multi-

administration aspect within the virtual organization.

On the other hand, to scale well, subjects and

objects within VO should be abstracted. For

example, dealing with the role “engineer” avoids

addressing individually the engineering department

users. The same is needed for the resources because

of their large number as well as heterogeneity.

Moreover, such abstraction separates the policy

from the physical dynamic infrastructure. Policy is

then expressed with abstract entities at the VO level,

and enforced locally by mapping it to the available

demanded resources.

3 RBAC

From the existing access control models, RBAC

(Role Based Access Control) (Sandhu,

1997)(Sandhu,1999) has emerged as an access

control model more flexible and easier to manage

than the traditional MAC, DAC models (Samarati).

RBAC aims to facilitate the security management by

introducing the “role” notion. A role represents a

function in a system (engineer, administrator...).

Each role is associated with a set of permissions (or

privileges) which is a set of rights corresponding to

the tasks which could be realized by this role.

Contrary to traditional models, RBAC doesn’t

associate privileges directly to subjects but it passes

via roles. A subject may have several roles, and roles

may be attributed to different subjects. Moreover, a

role may have multiple permissions and permission

may be associated to different roles.

The role definition reflects the organization

structure where the role is defined. Roles can be

structured hierarchically to facilitate attributing

permissions. However RBAC is unable to tackle the

complexity of distributed and decentralized

organizations. RBAC doesn’t express contextual

permissions or interdictions which are important in

the grid environment example: role “engineer” has

the right to use application “appl. 1” for 3 hours.

On the other hand, RBAC doesn’t reflect the

multi-organizational aspect where each organization

controls solely certain parts of the system. In such

environment, different administrators get into the

scene each having his assets that he only controls.

We find RBAC limited for modelling the grid virtual

organization.

4 ORBAC (ORGANIZATION

BASED ACCESS CONTROL)

In the grid environment each partner has resources

that are put in common to be shared by the

community. However each partner needs to keep the

management of his resources local maintaining the

internal structures as confidential as possible and

revealing only needed information for the well

functioning of the system.

What we need is an access control model that

indicates: who can do what in which context.

OrBAC (Abou El Kalam,2003) (Cuppens,2003)

access control model is proposed for modelling a

security policy that is not restricted to static

permissions and include contextual rules related to

permissions prohibitions and obligations. It aims at

introducing an abstraction level that separates access

control policy from its implementation.

Figure 2: ORBAC access control model

In the grid environment, or the multi-domain

environment in general, there are several access

stakeholders. The access control model should take

into consideration the nature of this multi

administered environment.

ICEIS 2005 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

154

OrBAC model offers a flexible mean to model

such environment employing abstract notions as

“role, activities and views” to abstract the traditional

“subject action object”.

We recall here the principal notions in this

model:

- Organization: it is an organized group of active

entities, i.e. subjects, playing some role or other.

This notion can be mapped to the Virtual

Organization which is the scene of the different

activities.

- Role: It corresponds to certain privileges in an

organization. The entity Role is attributed to a

subject within an organization. Dealing with Roles

facilitates users’ management in such a large scale

environment. On the other hand, roles are well

adapted to our environment where users are

dynamic. Policy expressed in terms of roles stay

valid even if users change. It is sufficient to

assign/revoke a role to a new/departing user.

- View: a view corresponds to a set of properties that

can be supplied by a set of objects (storage device,

databases, files etc). This notion corresponds well to

referencing resources by properties as explained

above in the “resources” and “reutilization” issues.

- Activity: It is used to abstract actions as “read",

“write". An activity may correspond to a

combination of actions.

Or-BAC with these notions responds to the grid

requirements. We may consider a Virtual

Organization to be an organization in Or-BAC

context. Entities in the virtual organization would be

roles instead of users, and views instead of objects.

The large scale problem of the grid (users,

resources) is overcome by the offered abstraction.

On the other hand, the multi-administration is also

taken into consideration as we will see in the

following sections.

5 BASIC COMPONENTS OF

ORBAC

There are eight basic sets of entities: Org

(organization: an organized group of subjects,

playing some role within the group), S (a set of

subjects), , A (a set of actions), O (a set of objects),

R (a set of roles), A (a set of activities), V (a set of

views), C (a set of contexts).

OrBAC considers that org ⊆ S, S ⊆ O. Any

entity may have attributes, for instance if S is a

subject, then name(S), address(S) represents the

name and the address of subject S.

Reviewing the relations in OrBAC:

- Empower is a relation over domains Org x S x

R. Empower (org, s, r) means that org empowers

subject s in role r.

- Use is a relation over domains Org x O x V.

Use (org, o, v) means that org uses object o in view

v. This helps to give different definitions for the

same view.

- Consider is a relation over domains Org x A x

A., Consider (org, α , a) means that org considers

that actions α falls within the activity a.

- Define is a relation over domains Org x S x A x

O x C. Define (org, s, α, o, c) means that within

organization org context c holds between subject s,

action α and object o.

- Policy definition: access control policy is

defined by the relation permission. Permission is a

relation over domains Org x R x A. x V x C,

Permission (org, r, a, v, c) means that organization

org grants role r permission to perform activity a on

view v within context c.

We consider that VO is the organization Org in

the OrBAC context. To construct this space, add

users, attribute users to roles and resources to views

and specify access permissions, a management

model [Munawer,Cuppens] is needed. It should

control the activities: management of organizations,

management of roles, activities, views and contexts,

assignment of users to roles, assignment of

permissions to roles, assignment of users to

permissions.

For this mission AdOrBAC (Administration

model for OrBAC) (Cuppens,2003) defines views as

URA (user/role assignment), PRA (permission/role

assignment)... Objects belonging to these views have

special semantics, namely they will be respectively

interpreted as an assignment of user to role,

permission to role. Intuitively inserting an object in

these views enables an authorized user to

respectively assign a user to a role and a permission

to a role.

Conversely, deleting an object from these views

will enable a user to perform a revocation.

Distributing the administration functions consists

of defining which roles are permitted to access the

views URA, PRA … or to more specific views when

ACCESS CONTROL MODEL FOR GRID VIRTUAL ORGANIZATIONS

155

the role has not complete access to one of these

views.

5.1 URA in AdOr-BAC

This view is used to determine who is allowed to

assign a user to a role and on which conditions.

Assigning a user to a role equals adding a new

object in a given view called URA. Three attributes

are associated with this view: subject to designate

the subject which is related to the assignment, role

that corresponds to the role to which the subject will

be assigned and org to represent the organization to

which the subject is assigned.

So to add a user to a special role (engineer) in

the engineering department eng-dept at organization

H, we have to create a view URA-engineer-eng-dept

defined as follows:

∀ ura, Use (H, ura, URA-engineer-

eng-dept) -> Use (H, ura, URA) ^ role

(ura) = engineer ^ org (ura) = eng-dept

This way we defined a view for the engineers in

the eng-dept. there is a link between adding an

object to this view and the relation empower:

∀ Org, ∀ ura, Use (org, ura, URA)

->Empower (org (ura), subject (ura),

role (ura))

“Assign” is the acitivity to be given to the

administrator to do this assignment job.

Permission (H, administrator, assign, URA-

engineer-eng-dept, default)

We may consider the activity “manage” as a

combination of two sub-activities (assign , revoke):

Permission (H, administrator,

manage, URA-engineer-eng-dept, default)

Permission (H, administrator, assign,

URA-engineer-eng-dept, default)^

Permission (H, administrator, revoke,

URA-engineer-eng-dept, default)

5.2 PRA in AdOr-BAC

Permission role assignment follows the same logic

as URA concerning adding an object to a view;

however the object has 5 attributes:

Issuer= issuing organization

Grantee, privilege, target = role, activity and

view concerned by the permission

Context = designate the context in which the rule

can be applied.

There is a link between adding an object to this

view and the relation permission:

∀ org, ∀ context, Use (org, pra, PRA)

-> Permission (issuer(pra),

grantee(pra), privilege(pra),

target(pra), context(pra))

5.3 VOA in AdOrbac

As in URA (user role assignment), the administrator

(ex. Role administrator) adds ura object to the

defined view URA. In analogy [9], we would like to

define a view including certain collection of objects

and attribute the “manage” activity to an

administrator (ex. “View-admin”)

Associating a user with the role “View-admin”

Empower (org, user, View-admin)

Attributing permission “manage” to the role

“View-admin”:

Permission (org, View-admin, manage,

VOA-org2, default)

Where VOA-org2 is the view of a group of

resources having an attribute “org” that is equal to

org2, it can be defined as follows:

∀ voa, Use(org, voa, VOA-org2) <->

Use(org, voa, VOA)^org(voa)=org2

So finally attributing a resource or object to a

view in the organization is equivalent to adding a

voa with attributes (object to be added, view to

which it should be added, organization) to the VOA-

org2 view. This can be done by the view-admin.

6 ORBAC MAPPING TO THE

GRID

Figure 3: ORBAC model in Grid environment

ICEIS 2005 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

156

Consider the scenario in figure 3 where two

organizations need to cooperate forming a Virtual

Organization. Consider that organization org2

supplies the resources where org1 contains the users.

Putting in place the VO needs to define the

participating entities from both sides this includes

roles, views, activities and the administration

authorities.

Modelling this environment using OrBAC, we

start by the virtual organization management itself.

Considering that VO is the organization of OrBAC.

Then such an entity may have attributes. As

discriminating attributes there are the involved

participants, a name discriminating a certain VO

within the different VOs that can be set up with the

same partners, and may be a certain expiry date after

which the cooperation is terminated:

Name (VO) =cooperation 1

Partners (VO) = org1, org2

Time= deadline

For the administration plan, we should define the

relevant roles in the Virtual Organization as:

Relevant-role (VO, Role-org1Admin);

Relevant-role (VO, PR-org1Admin);

Relevant-role (VO, ViewAdmin);

Relevant-role (VO, ActivityAdmin).

Also the Relevant activities and the Relevant

views names.

To attribute to a certain “org1admin” the role

“Role-org1Admin” that has the responsibility to

assign/revoke roles to the users of organization org1:

Empower (VO, org1admin, Role-org1Admin)

Permission (VO, roleadmin, manage, URA-

org1,default)

Where URA-org1 is defined as:

∀ Ura, Use (VO, ura, URA-org1) <=>

Use (VO, ura, URA) ^ org (ura) = org1

To attribute to a certain “org1admin” the role

“PR-org1Admin” that has the responsibility to

assign/revoke permissions to roles of organization

org1:

Empower (VO, org1admin, PR-org1Admin)

Permission (VO, PR-org1Admin, manage,

PRA-org1, default)

Where PRA-org1 is defined as:

∀ pra, Use (VO, pra, PRA-org1) <=>

Use (VO, pra, PRA) ^grantee(pra)∈ {r/ ∃

ura∈ URA-org1, role(ura)=role}^

privilege (pra) ∈ activities(VO)

To attribute to a certain “org2admin” the role

“ViewAdmin” that has the responsibility to

assign/revoke views to objects of organization org2:

Empower (VO, org2admin, View-org2Admin)

Permission (VO, View-org2Admin, manage,

VOA-org2, default)

Where VOA-org2 is defined as:

∀ voa, Use (VO, voa, VOA-org2) <=>

Use (VO, voa, VOA) ^ org (voa) = org2 ^

view(voa) ∈ views(VO)

To attribute to a certain “org2admin” the role

“ActivityAdmin” that has the responsibility to

assign/revoke activities to actions comprehensible

by organization org2 and its different resources:

Empower (VO, org2admin, ActivityAdmin)

Permission (VO, ActivityAdmin, manage,

AaA-org2, default)

Where AaA-org2 is defined as:

∀ aaa, Use (VO, aaa, AaA-org2) <=>

Use (VO, aaa, AaA) ^ org (aaa) = org2

Assigning concrete level to the abstract level

entities (of course done by authorized roles/users as

indicated in the administration plan above):

Role-org1Admin:

Empower(VO, Rlocal1, Rvo1)

Empower(VO, Rlocal2, Rvo2)

ViewAdmin:

Use(VO,storagedevice,Objlocal1&Objlo

cal2)

Use(VO,applicationserver, Objlocal1)

ActivityAdmin:

Consider (VO, action1, Activity1)

Consider (VO, action2, Activity2)

Consider (VO, execute, Execution)

Consider (VO, write, Update)

Consider (VO, read&write, Modify)

PR-org1Admin:

Permission(VO,Rvo1,Update&activity1,

storage device, workTime)

Permission(VO,Rvo2,Execution&Modify,

application server, day&night)

7 CONCLUSION AND FUTURE

WORKS

The grid has a goal enabling coordinated resource

sharing and problem solving in dynamic multi-

domain virtual organization. For this reason it sets

up a virtual organization which constitutes the

ACCESS CONTROL MODEL FOR GRID VIRTUAL ORGANIZATIONS

157

shared common space between the different

partners.

On the way to dynamically create virtual

organizations we needed an access control model

that takes into consideration the grid environment

constraints as inter-domain aspect, large scale,

dynamic resource allocation…. We presented

OrBAC as the candidate having too many features

appropriate for this mission. OrBAC models a multi-

administered environment using the “role view

activity” abstraction which abides to the Grid

constraints (large scale and dynamic resources).

However, since the dynamic resources allocation

can be propagated on multiple sites on behalf of the

user, the model should realize delegation aspects

(Welch, 2004). Delegation will be discussed in

details in another paper. After completing the model

an analysis is needed to study the appropriate way

for implementing OrBAC within the different Grid

layers (Foster, 2001).

REFERENCES

Alfieri R., Cecchini R., Ciaschini V., dell’Agnello L.,

Frohner A., Gianoli A., L˝orentey K., and Spataro F.

(2003). VOMS, an authorizatuin system for virtual

organizations. Presented at 1st European Across Grids

Conference, Santiago de Compostela, February 13-14,

2003.

http://grid-auth.infn.it/docs/VOMS-Santiago.pdf

Abou El Kalam A., El Baida R., Balbiani P., Benferhat S.,

Cuppens F., Deswartes Y., Miege A., Saurel C.,

Trouessin G. (2003). “Organization Based Access

Control”. In Proceedings

of the 4th IEEE

International Workshop on Policies for Distributed

Systems and Networks (Policy'03), p.120-131, June 4-

6, 2003, Lake Como, Italy.

Cannon S., Chan S., Olson D., Tull C., Welch V.,

Pearlman L. (2003). Using CAS to manage Role based

VO sub-groups. In CHEP 2003. La Jolla, California.

Baru C., Moore R., Rajasekar A., Wan M. (1998). The

SDSC Storage Resource Broker. In Proc. CASCON'98

Conference, Nov.30-Dec.3, 1998, Toronto, Canada.

http://www.npaci.edu/DICE/Pubs/CSI-paper-sent.doc

Djordjevic I., Dimitrakos T., Phillips C. (2004). An

Architecture for Dynamic Security Perimeters of

Virtual Collaborative Networks. In Proceeding 9th

IEEE/IFIP Network Operations and Management

Symposium, (NOMS 2004), April 2004. IEEE-CS.

Cuppens F., Miege A. (2003). Ad-OrBAC: An

Administration Model for Or-BAC. Workshop on

Metadata for Security, International Federated

Conferences (OTM'03), Catania, Sicily, Italy,

November 3-7, 2003.

Foster I., Kesselman C., Tuecke S. (2001). The Anatomy

of the Grid: Enabling Scalable Virtual Organizations.

In, International J. Supercomputer

Applications,15(3),2001.

Foster I., Kesselman C., (1997). A Metacomputing

Infrastructure Toolkit. Intl J. Supercomputer

Applications, 11(2):115-128.

Fedak G., Germain C., Neri V., and Cappello F. (2001).

XtremWeb: A Generic Global Computing System.

CCGRID2001, workshop on Global Computing on

Personal Devices, May 2001, IEEE Press.

Karl Czajkowski, Ian Foster, Carl Kesselman, Volker

Sander, Steven Tuecke, (2002). SNAP: A Protocol for

Negotiation of Service Level Agreements and

Coordinated Resource Management in Distributed

Systems. Draft submission to JSSPP’02 April 30,

2002. Retrieved January 26, 2005 from:

http://www-unix.mcs.anl.gov/~schopf/ggf-

sched/GGF5/sched-GRAAP.3.pdf

Nitin Nayak, Tian Chao, Jenny Li, Joris Mihaeli, Raja

Das, Annap Derebail, Jeff Soo Hoo, (2001). Role of

Technology in Enabling Dynamic Virtual Enterprises.

Retrieved January 26, 2005 from:

http://cersi.luiss.it/oesseo2001/papers/13.pdf

Samarati P., De Capitani di Vimercati S.. Access Control:

Policies, Models, and Mechanisms. Retrieved January

26, 2005 from:

http://www.ic.unicamp.br/~rdahab/cursos/inf712/mate

rial_didatico/docs/LNCS2171_Cap3.pdf

Russell D., Dew P., Djemame K (2004). Access control

for dynamic virtual organizations. In Proceedings of

Sept 2004. Retrieved January 26, 2005 from:

http://www.allhands.org.uk/2004/proceedings/proceed

ings/proceedings.pdf

Sandhu R., Coyne E., Feinstein H., Youman C. (1996).

Role-Based Access Control Models. IEEE Computer,

vol. 29, n° 2, pp.38-47, février, 1996.

Sandhu R., Munawer Q. (1999). The ARBAC99 Model

for Administration of Roles. In Proceeding of the 15th

Annual Computer Security Applications Conference

(ACSAC’99), Phoenix, Arizona, 6-10 December 1999,

IEEE Computer Society, pp. 229-241.

Welch V., Foster, I., Kesselman, C., Mulmo, O.,

Pearlman, L., Tuecke, S., Gawor, J., Meder, S. and

Siebenlist, F. (2004). X.509 proxy certificate for

dynamic delegation. Proceedings of the 3rd Annual

PKI R&D Workshop.

Wedde H.F., Lischka M., (2003).Cooperative Role-Based

Administration. Proceedings of the eighth ACM

symposium on Access control models and technologies

Como, Italy 2003

ICEIS 2005 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

158
