INTERNATIONAL STANDARDS AND USABILITY

MEASUREMENT

Hema Banati and P.S.Grover

Department of Computer Science

University Of Delhi

Delhi-110007, India

Keywords: Usability, Standards, Understandability, Learnability

, Operability, Attractiveness, Information oriented

website

Abstract: The current trend of increased web usage has recognized the need of usable websites.

A site containing

relevant information may not gain user acceptance if the user finds it difficult to use. A quantifiable

measure of usability can provide a measurable estimate of improvement required in the website. It can also

help in comparing different websites. This measure would gain wider acceptability, if obtained, by applying

the international standards of measurement. This paper measures usability quantitatively using the

international standard ISO/IEC TR 9126-2. Metrics specified in the standards are used to measure the four

sub-characteristics of usability, “Learnability”, “Operability”, “Understandability” and “Attractiveness” for

an academic website. It was found that the “Learnability” level of the website was very low, as compared to

the Understandability level. This is not in conformation with the standards, which mention the latter to be

an indicator of the former. The significance and relevance of each metric to usability of the website was

then examined in this light. The study also highlight the long due need of standardizing the process of

usability measurement.

1 INTRODUCTION

Websites can have different level of acceptance by

users, depending on their sensitivity towards the

needs of users. A site containing all relevant

information may not gain acceptance if the user

finds it difficult to use. This issue attains significant

relevance for an academic website which addresses

the technologically aware new generation.

Studies of different websites of universities have

been conduct

ed in the past. (Strauss, 2000)

identified the need of web portals, for universities,

which can provide information as required by the

users. In order to make these more useful, the

website designers need to identify different class of

users and their specific requirements. Usefulness, as

discussed by (Nielsen, 1993), includes both utility

and usability. The term “utility” of a site implies the

presence of features, required to achieve the specific

goals. “Usability” refers to the capability of utilizing

these features efficiently and effectively to achieve

desired goals with complete user satisfaction.

(Corry, Frick and Hansen, 1997) studied effect of

issues such as ease of

information location, scrolling

and key presses on usability of Indiana University

website. (Dhillon, 2001) stressed upon the need of

organizing relevant information on the university

websites to improve upon their user-friendliness.

(Rao, 2002) explored the best possible information

presentation style for a particular web portal for a

specific class. All these attempts were made to

enhance the usability of a website. However, no

study was undertaken to measure and improve

usability of a website using the international

standards.

Researchers across the globe have developed

various

qualitative and quantitative methods to

measure usability. It is felt that a quantifiable

measure of usability can affect the process of

planning and designing of websites. It allows for a

measurable estimate of each sub-characteristic and

the overall usability of the product. This measure

gains wider acceptability and reliability, if obtained,

by applying the international standards of

measurement.

This paper is an attempt to highlight the need of

stan

dardizing the process of usability measurement.

The sub-characteristics specified in the standard

184

Banati H. and S.Grover P. (2005).

INTERNATIONAL STANDARDS AND USABILITY MEASUREMENT.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 184-188

DOI: 10.5220/0002536701840188

 SciTePress

ISO/IEC 9126-2[5] are measured on a website. The

relationship between these was explored and was

found to be in non-conformation with the standards.

This could be attributed towards the non-

measurement of all metrics specified by the

standards. The priority and significance of each of

the usability metric is hence questioned.

The following section discusses the site studied and

the method adopted for measurement. The measures

obtained are analyzed in the next section. The

impact of the study is explained in the final section

where we outline the significance of this study.

2 METHOD

This paper applies the international standard

ISO/IEC TR 9126-2 to measure the usability of

Indira Gandhi National Open University

(commonly known as IGNOU) website. The URL

for this site is www.ignou.ac.in.

IGNOU has been a

pioneer in distance education in India. It is the

recipient of the Center of Excellence in Distance

Education award, in 1993, conferred by the

Commonwealth of Learning

. It was amongst the first

universities in India to host a website. Students

(prime users) scattered geographically across the

country, find the website a forceful, reliable

platform for interaction between them and the

university. The study of usability of such a website

is relevant, as it is the most timely and reliable form

of communication between the users and university.

Usability measurement of IGNOU website was done

by employing the external usability metrics specified

in the international standard ISO/IEC TR 9126-2.

These metrics measure the extent to which a given

software product is compliant with usability

regulations and guidelines.

The standard specifies measurement of five sub-

characteristics of usability: Understandability,

Learnability, Operability, Attractiveness and

Compliance. However, we measured only the first

four, because of non-availability of compliance

standards, being followed by the university. Since

links are central to a website functionality, the term

functions is interpreted as links in the metrics.

Understandabilit

Learnability

Operability

Attractiveness

Metrics as per

standards

Metrics

Measured

Figure 1: Number of metrics, measured v/s specified in the

standards

Initial study of the site revealed the absence of

certain features due to which all the metrics

specified in the standards could not be measured.

Fig 1 depicts the number of metrics measured as

against the total number of metrics specified in the

international standards. Table 1 lists the 12 metrics

that were measured.

The standards specify two types of method for

measurement of metrics. In “User Test” method a

sample set of users, representative of the actual

users, are requested to use a function. In the other

method, “Test of Product in Use”, the usage of

function, during a general use of the product, is

observed. However certain functions may be hardly

used during normal use. These might not be

measured using the “Test of Product in Use”

method. Therefore we adopted the “User Test

Method” of measurement. Eight users (as per the

standards) representing the student user group were

selected. We assigned specific tasks to each of these

eight users. Measurements were taken, based on

observations made during the test session.

There are two main categories of metrics, the

Performance metrics and the Preference metrics

(Nielsen and Levy, 1994). Preference metrics

provide a quantifiable measure of the user

preferences whereas the performance metrics

provide a measure of the actual use of the system by

the user, Constantine and Lockwood (1999).

We measured the preference metric “Attractive

Interaction”, on a preferential scale (Fig 2). The

users were asked to rate the attractiveness of the site,

by the following question.

Q. How would you rate the site?

1 2 3 4 5

Least Very

Attractive attractive

Figure 2: Scale to measure the attractiveness of the site

INTERNATIONAL STANDARDS AND USABILITY MEASUREMENT

185

Table 1: List of metrics measured for IGNOU website

S.No Metric Name

1 Understandability

1.1 Evident functions

1.2 Function understandability

1.3 Understandable input and output

2 Learnability

2.1 Ease of Function learning

2.2 Ease of learning to perform a task in use

3 Operability

3.1 Operational consistency

3.2 Error correction

3.3 Error correction in use

3.4 Default value availability in use

3.6 Self explanatory error messages

3.8 Time between human error operations in use

4 Attractiveness

4.1 Attractive Interaction

Table 2: List of tasks designed

The performance metrics were measured by

observing the users perform a set of tasks. A survey

of the actual targeted users was done to identify the

most critical, important and frequently performed

tasks. Table 2 lists the set of tasks, which were

designed based on this survey

3 RESULTS

The mean of measures obtained while users

performed the assigned tasks, are listed in Table 3.

The absence of certain features in the website

inhibited the measurement of all metrics. Prominent

features not available in the website are the Help

facility, Demonstration capability, Customizability

and Accessibility features for physically challenged.

Fig 3 shows the measured values (except the time

metrics) against the value range specified in the

standards. The metric numbers as per table 1 are

specified on the X-axis (names have not been given

due to space constraint). The figure indicates that the

measures for features like input and output, default

value and self-explanatory error messages

approximate the ideal value of 1. This corroborates

that an information oriented website (Banati, Grover

2004) has limited scope for input/output and hence

default values and errors Although the users could

interpret the links (metric “Function

understandability”) the low value of metric “Evident

functions” indicated difficulty in identifying links

and hence in navigating through the website

Low values are recommended for metrics measuring

time, except for the metric “Time between human

error operation”. However, it is evident from table 3

that users spend a lot of time in learning to use a

function, performing task or correcting error. Users

found the site to be moderately well designed, in

terms of cosmetic appearance (a value of 3 for the

Appearance metric in Table 3). During the process

of measurement, we failed to measure the metric

“Error correction in use”. Usability of the website

was measured to be approximately 26%.

Task

number

Task

Task 1 Observe the home page and identify all the

possible links (functionalities) which website

provides

Task 2 Observe the home page and interpret the meaning

each link

Task 3 Get the Result for specified course

Task 4 Identify the centers at specified place

Task 5 Subscribe to E-journal

Task 6 Send complaint about non-receipt of starter kit of

course

Task 7 Check for admission announcement for Entrance

examination for year 2005

Task 8 Fill examination form for a course

4 DISCUSSION

The site under study is predominantly an

information-oriented website where the user

activities are directed towards search and/or retrieval

of information rather than input and output. Such

websites should provide for a good comprehension,

quick learning, and easy navigational facilities. The

measured values of metrics indicated that the site

was lacking this. Fig 4 depicts the percentage level

contribution of each sub-characteristic (what it

should be as per standards v/s what it is in the

IGNOU website).

Table 3: Results

Metric Name Mean value

Evident functions 0.10

Function understandability 0.80

Understandable input and output 0.96

Ease of function learning 15.22(sec)

Ease of learning to perform a task in

use

41.52(sec)

Operational Consistency 0.35

Error Correction 15.94(sec)

Error Correction in use -----

Default value availability in use 0.82

Self explanatory error messages 0.70

Time between human error operations

in use

49.37(sec)

Attractive interaction 3

ICEIS 2005 - HUMAN-COMPUTER INTERACTION

186

0.5

1.1 1.2 1.3 3.1 3.4 3.6

Actual

Value

Obtained

Figure 3: Measured values against the standard range

The significantly low value of Learnability is

alarming. The standards mention that

Understandability is an indicator of Learnability.

However, the measurements indicate that does not

hold true for this site. This could be attributed to

non-measurement of certain metrics due to non-

availability of the relevant features in the website.

However, the metrics measured are almost in the

same ratio, as to what could have been measured

(Fig 1). The question raised is “Are the metrics, that

could not be measured, more significant than those,

that could be measured”. The issue of priority of

metrics therefore gains significance. In case certain

metrics have higher relevance than the others,

neglecting features relevant to those metrics might

be critical.

5 CONCLUSIONS

The usability of an academic website was measured

by applying international standards. The study

helped us obtain quantitative measure of usability

and it’s sub-characteristics. The standards mention

Understandability as an indicator of Learnability.

This was not corroborated by the measurement

obtained in the study. The issue of relevance and

criticality of each metric towards the total usability

of the website needs to be looked into. The case

study also exemplifies that the process of

standardizing usability measurement can help in

quantifying the amount of improvement required in

usability of a website, which cannot be achieved by

non-standardized methods. A singular study cannot

conclusively comment on this, but the question

raised is crucial, as it can influence future usability

studies. We are in the process of examining such

websites to substantiate the findings of this paper.

Understandability

Learnability

Operability

Attractiveness

Contribution level

specified by the

standards

Contribution level

found in the

website

Figure 4: Comparison of percentage contribution of

usability characteristics (Standard v/s Measured)

REFERENCES

Banati, Hema and Grover P.S, 2004.A Structured

Approach To Study Usability, National Conference on

Software Engineering Principles and Practices

Constantine Larry L and Lockwood Lucy A.D, 1999.

Software For Use: A Practical Guide to the Models

and Methods Of Usage-Centered Design, ACM Press,

New York

Corry, M.D., Frick, T.W., and Hansen, L., 1997. User-

Centered Design and Usability Testing of a Web Site:

An Illustrative Case Study. Educational Technology

Research and Development, 45, 65-76.

Dhillon, J.K, 2001.Challenges and strategies for

improving the quality of information in a university

setting: a case study. Total Quality Management, 12i2,

167.

ISO/IEC TR 9126-2:2003 Software engineering -- Product

quality -- Part 2: External metrics

Nielsen J. 1993.Usability Engineering, Boston: Academic

Press

Nielsen, J and Levy, J. ,1994. Measuring usability:

Preference vs. performance. Communications of the

ACM

, 37(4) 67-75.

Strauss, H., 2000. Techtalks. Interview conducted by

CREN.

Sushma Rao, 2002. “Application of Human-computer

Interaction Theories to Information Design on Internet

Portals” A Masters Thesis, available at

http://scholar.lib.vt.edu/theses/available/etd-

11192002-164448/unrestricted/ThesisSushmaRao.pdf

www.ignou.ac.in - Website of Indira Gandhi National

Open University

INTERNATIONAL STANDARDS AND USABILITY MEASUREMENT

187

ICEIS 2005 - HUMAN-COMPUTER INTERACTION

188
