A FRAMEWORK FOR WEB APPLICATIONS DEVELOPMENT

A SOAP based communication protocol

Samar Tawbi, Jean-Paul Bahsoun

Institut de Recherche en Informatique de Toulouse, Paul Sabatier University, 118, route de Narbonne 31062 Toulouse,

France

Bilal Chebaro

Lebanese University, Faculty of Sciences I, Hadath, Lebanon

Keywords: Generic Web development, Web services, SOAP, Communication Protocol.

Abstract: The rapid evolution of interactive Internet services has led to both a constantly incr

easing number of

modern Web sites and to an increase in their functionality, which makes them more complicated to be built.

In this context, we have proposed a generic approach for Web site development that manages the

operational content of this kind of applications. A framework has been defined to support the development

of web applications’ processing tasks as Web services and the communication protocols with the users of

these services. In this paper, we will expose the general structure of this framework, and we will focus on

the communication protocol defined between the users and the system. Our approach in this protocol

addresses universal clients; it is based on the SOAP protocol, XML language and their related technologies.

It adopts the concept of Web services but uses it for providing code results rather than information results as

it is known in the Web society.

1 INTRODUCTION

In the last few years the World Wide Web has been

growing rapidly. The rapid evolution of interactive

Internet services has led to both a constantly

increasing number of modern Web sites and to an

increase in their functionality, which makes them

more complicated to be built.

In the early Web development practices, it was

current for

b applications creators to simply build

the solution, emphasizing in certain cases the

development side of these applications (Ceri et al.

2000). But with the quick evolution of the Web and

its related technologies on one hand, and the

increasing requirements of users, on the other, many

new features were implemented. And the Web

applications became more dynamic, interactive and

as a consequence more complex. This leads to a

more difficult management and maintenance.

Many tools and technologies were proposed in order

to increase

web applicatio

ns performance and the

facility of their creation.

In this paper, we make an overview on the tools

creat

ed f

or helping Web applications development

and discuss how these products neglect to a certain

level, development issues of these applications. We

describe how we introduce the e-development

concept to respond to this issue. So we define a

framework that proposes a platform for managing

operational functionalities for Web sites’ creation. It

gives a solution for the development difficulties by

providing Web services for application development

and management (Tawbi et al. 2002). This

framework constitutes a basis for deploying servers

providing development services in different Web

domains. We will describe along the paper the

communication protocol adopted in this framework

that is based on Web services. But unlike what is

usually done, the concept ‘Web services’ is used for

providing development functionalities and not

business services.

The paper will be organized as follows: In the

section 2

we will talk about

some previous work in

term of tools for Web sites development and

management and some of their shortcomings

regarding the development side of Web sites.

Section 3 will give an overview on the web services

technology, its standards and how we could use it in

Tawbi S., Bahsoun J. and Chebaro B. (2005).

A FRAMEWORK FOR WEB APPLICATIONS DEVELOPMENT - A SOAP based communication protocol.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 82-89

DOI: 10.5220/0002537100820089

 SciTePress

our work. We will outline our general approach in

the section 4. Then, in section 5, we will give the

structure of this framework and its properties

especially the communication protocol that it uses.

Section 6 will give an implementation example

based on this framework. And finally, concluding

remarks will be given.

2 WEB DEVELOPMENT TOOLS

A large variety of tools and technologies was created

to support the publishing of static and dynamic data

on the web. The first generation of this kind of tools

was HTML editors (Elderbrock et al. 2002) (Lowery

et al. 2001). Although, they helped the Web site

creation by automating certain tasks concerning

HTML code generation, they soon proved to lack a

lot of dynamism and interaction. Web content

managers (Aberdeen et al. 2002) (Kerer et al. 2002)

(Vignette 2001), constitute the next generation of

products for Web site engineering. They focus on

offering sophisticated tools and architectures for

delivering the information in a fast and scalable way.

Their principle approach is to separate the content

from the presentation of Web applications. From a

technical point of view, although these products may

offer component reuse, they do not rely on an

explicit model. Their main problem is that they

approach Web content management from the side of

management and generation documents rather than

the semantic of contents. Meanwhile, the research

community has also worked on this problem and

many models and systems were proposed like (Ceri

et al. 1999) (Chauvet 2002) (Florescu et al. 1998)

(Fernandez et al. 1999) (Gardner 2001) (Sadoski et

al. 2000).

In general, all these tools take their idea from

experiences in the database and hypertext fields.

And they adopt for the data and for the Web site

itself, structured data models very often close to

relational databases, and a query language to

communicate with the database. They focus the

information content and address data intensive Web

applications. This kind of systems have a primordial

disadvantage that they don’t take into consideration

the operational and development aspects of Web

applications especially complex ones.

In our approach we solve this specific issue by

defining a framework that offers automated

development tasks as online services, to the Web site

creators. In other words it will be capable to provide

services for Web code generation (HTML in a first

step, and later XML). This framework separates

completely the implementation from the presentation

of applications. It defines a protocol for service

management and a generic prototype for those ones

in order for the framework implementations to be

easily adaptable and upgradeable.

The next step was to choose a protocol of

communication with the clients. We have found the

concept of Web services the most appropriate for

our problem. This issue is discussed in the next

section.

3 WEB SERVICES TECHNOLOGY

To solve new difficulties that appear, organizations

and enterprises try to define new technologies that

are often very soon adopted by the wide public. In

order to stay informed in the world of software

development, one has to keep an eye on what is

happening essentially in the big enterprises and all

the new technologies used or created by those ones.

We know that the most important enterprises in the

Web society are in permanent competition. Even

though, these enterprises all admit that the concept

of ‘Web Services’ will be very soon the principal

and common language for business application.

Experts in this domain, have a future vision for web

services in which there will be some kind of

electronic services’ ‘cloud’ on the Web; allowing

users to choose anything they want for their

applications. It’s all the software industry that seems

to be animated by some kind of conquest tendency

for new virtual territories for economical exchange

(Java Sun 2002).

The software applications, in general, are less and

less considered as static programs executed on

mainframes or PCs, but as applications functioning

on a network of servers, located indistinctly in this

‘cloud’ of services, and that are generally accessed

via Web interfaces. So, the design and

implementation of Web applications became one of

the major challenges for software industry in this

century.

As its name shows, the term ‘Web services’ refers to

accessing services over the Web. This term is now

also used for the architecture, standards, technology

and business models. In other words, it includes all

techniques that make this possible(Gamma et al.

1995). IBM defines Web services as a new breed of

Web application. They are self-contained, self-

describing, modular applications that can be

published, located and invoked across the Web. Web

services perform functions, which can be anything

form simple requests to complicated business

processes (Vignette 2001). In other words, web

services are interoperable building blocks for

constructing applications.

Where the current web enables users to connect to

A FRAMEWORK FOR WEB APPLICATIONS DEVELOPMENT: A SOAP based communication protocol

applications, the web services architecture enables

applications to connect to other applications. Web

services are therefore a key technology in enabling

business models to move from B2C (Business to

Consumer) to B2B (Business to Business) (Java Sun

2002). In addition, they present a black box

functionality that can be reused regardless of their

implementation. While technologies as DCOM

(Brown & Kindel 2002), RMI (Elderbrock &

Karlins2001) (Fernandez et al. 1997) and IIOP use

object-model-specific protocols, Web services use

normal Web protocols like HTTP and data format

like XML.

Actually, as the researchers predict that XML will be

soon the language of choice for Web development

(Lowery et al.2001). In fact, the World Wide Web

Consortium –W3C– created this language, in order

to overcome the shortcomings of HTLM. Therefore,

the relatively slow adoption of XML may refer to its

complexity and the many related technologies and

languages that must be used with it like XSL, XML

Schema, DTD, etc. Furthermore, until now the XML

based development tools are in their beginning if

compared to HTML based ones. So it is important to

create such a tool to support Web application

development. For this reason, in our framework we

have switched to XML. We adopted the concept of

‘Web services’ as well as its associated tools like

SOAP (Brown 2001) (Ceri et al. 2000).

On another hand, even though the Web services

concept was created and used originally to provide

information or data result; we think it is possible to

use it in our framework for code result

corresponding to the operational tasks of Web

applications.

4 A GENERIC APPROACH FOR

WEB SITE DEVELOPMENT

Since the needs for sophisticated web sites is more

and more relevant especially for the functionalities

that are related to business domains like commerce,

education and banking, and as we said that this

domain is now adopted not only by computer

experts but by the large public, we have proposed a

generic approach for Web site development (Tidwell

2000).

It is a framework that offers a platform capable to

provide the web site designers storage, access and

processing of the information. It is independent of

business domains and it defines a protocol for

service creation. Servers created as implementation

of this framework offer processing services in

different Web domains.

The main idea is to approach Web site automated

creation from the operational side and to separate the

formatting tasks from the processing ones. Thus the

framework defines the structure of servers that offer

complex functionalities concerning the processing

means in a Web site as interaction with users,

database access, etc. Web applications creator could

call these functionalities in their pages while

remaining completely free in choosing any layout

and formatting. The services to propose using this

framework are specific to a certain domain on the

Web like article publishing, emailing, e-commerce

or others, unlike what we used to have in the

automated Web page creation tools. Usually, these

tools offer general-purpose services, leaving the task

of specifying these services to the Web site

developer. However, we focus in our work on more

specific services in order to optimise their

personalization task. For example, in an online

article-publishing instance of this framework(Tawbi

et al. 2002), we can find services for conferences or

journal sites like paper submission, viewing,

categorization, management, etc. This needs not

only to define the development part of the

functionality but to foresee also a certain data

structure like database tables or XML files. Thus, we

have complete independent services that could be

used, with minimal personalization effort, in any

Web application in the online article-publishing

domain.

In order to have more flexibility, the framework

offers two types of pages depending on the time

when the service calls they contain are analysed and

executed:

Dynamic pages are real time analysed, we mean

when accessing the page by a certain Web browser.

Service calls are added to the content of these pages

when creating them, and they are hosted in this

format. The processing of the services called is not

done until the page is accessed by an end-user.

And Static pages that execute service calls at

creating time. The result of these services processing

is added to the content of the pages before they are

published as any other page on the Web.

The figure 1 shows how the browser accesses the

two kinds of pages. Dynamic pages are accessed via

the service provider in our example it is the article-

publishing server. Its role is to retrieve the page

from the hosting server, to analyse it and to generate

results for the service calls that it contains. This

mechanism stays completely transparent to the end-

user. In fact, there is no need to make any special

processing from the navigator side to access these

pages correctly.

On the other hand, static pages are directly accessed

from the hosting server like any Web page without

any additional processing effort.

ICEIS 2005 - SOFTWARE AGENTS AND INTERNET COMPUTING

Site Web

5 THE FRAMEWORK

STRUCTURE

A principal concern in our framework is to reach a

high level of genericity and independence from

business domains. But at the same time, we must

propose an architecture that allows easy instantiation

and specification to any of these domains. After all,

our aim is to propose development services for

specific business processing tasks. Indeed, we must

fix certain guidelines drawing the overall function of

the framework and a common communication and

management protocol. So we had to define a

prototype for services’ implementation

independently of their application domain. This

prototype represents a model of abstract classes that

will be extended in order to create components

representing concrete services. This allows easy

specification to different Web domains.

Therefore, to create a service provider, for a certain

field, based on the framework, we should implement

the services needed in this field according to the

proposed prototype and following the

communication strategy adopted in the framework

(figure2). At any time, server’s developers can add a

service component to their system in transparency of

server users (Web site developers) and

independently from the core work.

However, we may have some functionalities that are

not specific to a certain business field like user

authentification or registration to a mailing list for

example. This kind of tasks is deployed in domain

less services that constitute with the management

and communication component, the server core

representing the common part of these servers in any

business domain on the Web. The services defined

for a certain field constitute a layer over this

common core.

This is true from the deployment and

implementation point of view only. At this level of

abstraction, we would like to point to the fact that

the services are implemented and deployed in a late

step, we mean after the framework has been defined

with its common services, its communication and

management protocols.

Architecturally speaking, the system has a three-tiers

architecture (Shaw 1996) where we have a light

client tier, a middle tier representing the service

provider that is conceived in a layered architecture

(Bahsoun et al. 2003) and a database tier (figure 4).

In the next sections we will talk about these three

tiers.

5.1 The Client tier

It represents the interface threw what users access

the services offered by the provider. This is a thin

client with almost no processing responsibilities; all

you need is a browser to view the pages containing

service calls. No need for any special component to

be able to contact the server. In fact, all

communications are based on Web standards like

HTTP, XML, etc. this frees the web application

developers from any programming effort.

5.2 The Processing tier

It contains the essential part of the services provider.

It contains all processing, communication protocol

and management, testing and security. Domain

services will be developed in this tier based on the

prototype defined by the framework. It has a

modular loosely coupled object-oriented layered

architecture (Bahsoun et al. 2003) in order to take all

the advantages of the independence that this kind of

architecture offers. So the framework architecture

consists of four opaque layers (figure 3):

PubliWeb

Static pages retrieval

Dynamic pages

retreival

End user (navigator)

Figure 1: Accessing static and dynamic pages.

A FRAMEWORK FOR WEB APPLICATIONS DEVELOPMENT: A SOAP based communication protocol

Connection Servlet: it is the interface of

communication of the servers developed from this

framework. It is a Java servlet that received users’

requests representing Web pages to be analyzed.

This connection layer represents the only gate to

contact the server. In general, it communicates with

the end-users’ browsers, if we are talking about

dynamic pages. Otherwise it is the Web site

developer that contacts the server and in this case the

communication is done via an interface for Web

pages creation dedicated to this purpose.

Page Analyzer: this layer is responsible for

analyzing the Web pages to extract service calls and

sending them to the ‘Service Dispatcher’. Page are

analyzed in this layer at two levels, syntax level to

verify if the call is well formed and semantic level to

check for any incoherence in service calls, order and

types of parameters for example.

Service Dispatcher: its job is to send service calls to

the corresponding services after they have been

analyzed. And in return it receives service results

and sends them to the analyzer after it reformulates

them in order to be conform to the format of the

Web pages content.

Services Layer: this is the layer that will be specified

to Web domains. It contains service management

and the prototype for defining services if we talk

from the framework side. But if we

consider a server

implemented using the framework, this layer

contains the services offered in a certain domain in

addition to basic services that are common to all

domains.

5.3 The Database tier

It centralizes the data related to the applications in a

repository database managed by a DBMS. It is

accessed through the services offered to users, but

stays completely transparent in order to allow

independent updates and changes. It is accessed

through an interface implementing the DAO pattern

(Gamma et al. 1995). This makes the deployment of

the Database server changeable and upgradeable

independently of the services management from one

side and of the clients from the other.

For this reason, we have standardized the

management of the services and defined a

communication protocol between the different actors

of the application independently of the business

domain of the server deployed. In the next section

we will go more into the details of this protocol of

communication.

6 A COMMUNICATION

PROTOCOL

6.1 Introduction

The communication protocol to be adopted in our

framework must respond to the constantly evolving

needs. Besides, there is an important point to take

into account is the genericity that we should

preserve in all steps of our work including of course

the communication protocol. This protocol should be

independent of business domains in order to be

applicable to all these domains when specifying the

framework. Furthermore, when we talk about web

server we address different types of users and by

consequence different types of communication

interfaces and devices as Wap phones or others.

Figure 2: Specifying servers by creating domain specific services.

Server 1 Server 2

The framewor

Services

creation

Client Tier Processing Tier DB Tier

DBMS

Connection Servlet

Page Analyzer

Browser

Service Dispatcher

Services Layer

Figure 3: The system’s architecture.

ICEIS 2005 - SOFTWARE AGENTS AND INTERNET COMPUTING

6.2 From HTML to XML based

protocols

Several approaches were possible each one is based

on a set of Web technologies and languages.

However, it was necessary to adopt the most

adequate one to our work taking into account all

constraints previously exposed. Since we are

working in Web applications development, HTML is

the first language one can think to use for this field,

as it is the most known standard. It is characterized

by its simplicity and facility to use. One approach

was based on this language where a Web site, using

a service provider must be implemented in HTML.

Knowing that HTML is text based, service calls

consist of normal HTML text preceded by a specific

keyword for example and inserted in the ‘body’ of

the pages. Although, this way simplifies

tremendously Web pages creation but it makes the

page analysis process heavy and slow. Indeed,

textual service calls require a textual parsing of the

page, the HTML content will be analysed character

by character in order to detect keywords indicating

service calls. We can notice that by adopting this

textual mode we loose a lot of performance and

extensibility. These two characteristics are

extremely important especially because we are

working in the Web domain. In fact, the Web is

wide spread this means thousands of users accessing

the server. Besides, this domain is in permanent

evolution from the two sides user needs and

technologies. The use of a more extensible language

at this stage seemed to be a must to preserve the

genericity and the reusability of the framework. As

we said in the previous section, XML offers an

extensible way for representing information and it is

now widely used. The free tags definition aspect that

this language offers has allowed researchers to

derivate mark-up languages for different domains as

WML for WAP users, MathML for mathematics,

and many others. For this reason, adopting XML

makes the framework more flexible and adaptable to

different types of users. Furthermore, XML parsers

that have been specified by the Web community

have proven their performance in comparison with

textual parsers. Thus by adopting the XML language

in our communication protocol, we could dispense

with HTML browsers and use already specified

XML parsers.

Now, we had to define a new protocol of

communication between the Web applications and

the service provider instantiated from the

framework. This protocol should take advantage of

strong points in XML language. Of course, we had

to propose also a new service calls mode replacing

the textual mode adopted.

In the following section we will describe this new

approach, its functioning and its characteristics.

6.3 The functioning principle of the

protocol

In general, using standard technologies in a certain

system has two major benefits: first, the system is

more universally accessible because standards are

widely known. And second, the system inherits the

advantages and the characteristics of these standard

technologies and tools. This is due to the fact that

these technologies are the result of many

experiences’ work in the domain. As we have seen

in previous sections many standards were proposed

for the Web at different levels and sides. As we are

working on online service development, the ‘Web

Services’ concept is very important for our new

approach. Using Web services implies the use of

certain related tools as the SOAP communication

protocol (see section 3). The functionalities defined

in our framework will be deployed as Web services

using the SOAP protocol for communication.

Usually a SOAP message consists of an XML

document that contains a service call and its

parameters (Ceri et al. 2000).

Therefore, in our system a Web page may contain

many service calls in addition to normal content.

Standard SOAP servers are not appropriated for

managing this kind of documents. For this reason

and in order to respect pages conceiving politic, we

have considered a service call as a SOAP message

but that will be inserted as an XML content in the

Web document. We had to create a layer above the

standard SOAP server representing a filter that is

responsible of receiving Web pages and retrieving

service calls for processing. The figure 5 shows this

structure.

At analysis time, the filter extracts of the document

all parts representing service calls and creates the

corresponding message to send it to the SOAP

server that in turn forwards the message to the

appropriate service. We could import and use any

SOAP server available like APACHE SOAP server

or others.

6.3.1 The pages format

As with HTML, XML web pages in this protocol

will contain normal content corresponding to the any

information the Web site creator would like to put

and service calls when necessary. Each one of these

calls represents a SOAP message containing all

required fields like SOAP Header and Body

(Ceri et al.

2000)

within a tag called ‘ServiceBLock’. And

normal content must be written within a

A FRAMEWORK FOR WEB APPLICATIONS DEVELOPMENT: A SOAP based communication protocol

‘ContentBlock’ tag. So, a page consists of a

sequence of content and service blocks as in the

figure 6.

So the pages will be hosted in the format previously

described, surely this concerns dynamic pages only

as static pages call services before they are hosted as

we mentioned above. So, when analysing a page as

in the example of the figure 6, blocks that

correspond to XML text will be copied as they are to

the response page and blocks representing a service

call will be packed in a SOAP messages and sent for

processing. In return, service responses are added to

the page according to their order. Thus, we allow

this way the Web site creator to have more of

flexibility in managing the graphical format and

design of the pages.

In fact, by adopting XML for page content, we make

the servers compatible with more users in different

types. However, as the XML is a free mark-up

language, we should have a common language for

the communication in order to allow the openness of

the protocol. This issue will be discussed in the next

section

6.3.2 A protocol for universal users

As we are dealing with an open language like XML

and due to the many languages derived from this

one. Web pages will contain then XML code

according to a specific schema that is common to all

servers implemented based on this framework. The

content blocks of the request pages enclose

information matching also to this same schema. This

is because the analyser will not process this data, it

will be sent as it is to the response page. So it must

have the same structure of response page’s content.

By imposing a schema for pages definition we

restrict the XML code of the Web developers to

what is defined in this schema. However, this allows

for the framework to propose a common format of

the output data in the Web services and as a

consequence unifies the pages analysing and the

service processing.

According to this strategy, the response Web page is

sent to the browser in XML format if this one

supports the XML language. Otherwise, the server

transforms the page to the language compatible with

the browser depending on its type.

When a request is sent to the server, the SOAP filter

receives it and detects the type of the browser WML,

HTML or others. Then it send service calls to the

SOAP server and to the service provider. Services

produce result in XML then depending on the type

of the browser the response page is either sent as it is

in XML either translated to the browser languages

according to XSL style sheets defined by the

framework to each format (figure 7).

7 CONCLUSION

In this paper, we have presented a framework for

Web application development. It offers a generic

platform managing services that generate

development tasks. This framework was created in

< ContentBlock ...>

Normal Web content

</ ContentBlock >

< ServiceBlock ...>

A SOAP message block with

all its required parameters

It calls a Web service.

</ ServiceBlock >

< ServiceBlock ...>

- - -

</ ServiceBlock >

ContentBlock ...

A document may contain

many Service Blocks

Content Blocks

enclose web content

of the page in XML,

HTML…

Figure 6: The structure of a Web document

Figure 5: The SOAP filter constitutes a layer between the SOAP server and the users

Services

Provider

Imported

SOAP server

SOAP Filter

End use

Web docs +

service calls

SOAP

Res

onses

Service

invocations

SOAP messages

Complete

Web docs

Service

Results

ICEIS 2005 - SOFTWARE AGENTS AND INTERNET COMPUTING

…

rowse

WML

rowse

HTML

rowse

SOAP Filte

two steps. The first one was to build the structure of

a server managing services in a generic manner in

order to keep a high level of extension and

evolution. So that this framework could be used

universally, the second step consisted of adopting

standard concepts and tools for the definition of a

communication protocol like Web services, SOAP,

etc. A layer was created over the SOAP protocol so

that it could respond to the needs presented by the

framework.

REFERENCES

Aberdeen Group Inc., 2002, ColdFusion MX: Raising the

Return on Investment of Internet Application

Development, White Paper.

Brown, N. & Kindel, C., 2002, Distributed Computing

Object Model Protocol – DCOM/1.0,

www.grimes.demon.co.uk/ DCOM/DCOMspec.htm.

Bill Brown, 2001, SOAP Programming, Sybex.

Ceri, S., Fraternali, P., & Bongio, A., 2000, Web

Modeling Language (WebML): a Modeling Language

for Designing Web Sites, In IWWW00 the 9th

International. World Wide Web Conference.

Ceri, S., Fraternali, P., & Paraboschi, S., 1999, Design

Principles for Data-Intensive Web Sites, SIGMOD

Record : ACM Special Interest Group on Management

of Data, 28(1).

Chauvet, J.M., 2002, Services Web avec SOAP, WSDL,

UDDI, ebXML, Eyrolles.

Java Sun, 2002, http://java.sun.com/ blueprints/

corej2eepatterns/ Patterns/DataAccessObject.html.

Elderbrock, D. & Karlins, D., 2001, Front Page 2002

Bible, John Wiley & sons.

Farly, J., 1998, Java Distributed Computing, O’REILLY.

Fernandez, M., Florescu, D., Kang, J., Levy, A., & Suciu,

D., 1997, STRUDEL: a Web Site Management

System.

Florescu, D., Levy, A., & Mendelzon, A., 1998, Database

Techniques for the World Wide Web: A Survey,

SIGMOD Record (ACM Special Interest Group on

Management of Data), 27(3).

Fernandez, M., Suciu, D., & Tatarinov, I., 1999

Declarative Specification of Data-Intensive Web Sites,

In Proceedings of the 2nd Conference on Domain-

Specific Languages, Berkeley, CA.

Gardner, T., An Introduction to Web Services, 2001,

http://www.ariadne.ac.uk/issue29/gardner/intro.html.

Gamma, E., Helm, R., Johnson, R., & Vlissides, J., 1995,

Design Patterns: Elements of Reusable Object-

Oriented Software, Addison-Wesley.

Interwoven Inc., 2000, Application Development using

Interwoven: Version 1.1, White Paper.

Kerer, C., Kirda, E., Krügel, C., 2002, XGuide - A

Practical Guide to XML-based Web Engineering, In

the International Workshop on Web Engineering &

Networking, Pisa, Italy.

Lowery, J. W., & Lynch, K., 2001, the DreamWeaver 4

Bible, John Wiley & sons.

Sadoski, D., & Comella-Dorda, S., 2000, Three Tier

Software Architecture, http://www.sei.cmu.edu/str/

descriptions/ .

Shaw, M., 1996, Some Patterns for Software

Architectures, Pattern Language Of Program Design,

Addison Wesley.

Bahsoun, J. P., Chebaro, B., & Tawbi, S., 2003, A Web

Services Provider: Generic Architecture and Patterns

for Business Applications, In IFIP03 the third IFIP

International conference on E-business, E-commerce,

E-government, Sao Paolo, Brazil.

Tawbi, S., & Chebaro, B., 2002, GenericServ: A generic

server for web application development, In the web

requirements & e-services workshop of the 1st

EURASIA conference for Advances in information &

communication technology, workshop proceedings,

Austrian computer society.

Tidwell, D., 2000, http://www-106.ibm.com/ developer

works/webservices/edu/ws-dw-wsbasics-i.html.

Vignette Corp, 2001, Vignette Content Management

Server, White Paper.

Service 1 Service 2 Service n

SOAP Package

XSLT

sheets

Result in XML + XSL

doc. for HTML, WML,

…

Service Provider

Figure 7: The response is sent to users depending on the type of the browse

A FRAMEWORK FOR WEB APPLICATIONS DEVELOPMENT: A SOAP based communication protocol
