USER MODELLING FOR DIARY MANAGEMENT BASED ON

INDUCTIVE LOGIC PROGRAMMING

Behrad Assadian, Heather Maclaren

Intelligant systems Lab, British Telecommunications, Adastral Park, Ipswich, United Kingdom

Keywords: Inductive Logic Programming,Personal Assistant,User Modelling

,Software Agents,User Preferences

Abstract: Software agents are being produced in many different forms to carry out different tasks, with personal

assistants designed to reduce the amount of effort it takes for the user to go about their daily tasks. Most

personal assistants work with user preferences when working out what actions to perform on behalf of their

user. This paper describes a novel approach for modelling user behaviour in the application area of Diary

Management with the use of Inductive Logic Programming.

1 INTRODUCTION

There are a few applications of Inductive Logic

Programming (ILP) (Muggleton 1994) to user

modelling (Rogers 2000) already in existence. ILP is

useful for user modelling as it allows the use of

intensional background knowledge, hence we can

incorporate `rules of thumb', and it maintains the

transparency of the agent's actions to the user. i.e.

they can look at the agent's model and understand

what inferences it has made about them, thus

maintaining their trust in their agent.

Current methods of ILP for user modelling deal

with sim

pler concepts such as correcting a user's use

of a unix shell (Jacobs 2000) or predicting which

switches they would use for certain commands.

2 USER MODELLING

This paper proposes a system that learns sequence of

activities from users diaries in order to model how

such sequences should be arranged for future tasks.

A novel method of using ILP is proposed that

lits the learning of the user model into several

stages. It first produces results for each of these

stages, then combines the results to produce a single

user model.

The data is split into distinct clusters, each

represen

ting a sub-concept of the model to be learnt,

and then the learning of each sub-concept is

attempted separately. Each sub-concept is split into a

number of separate learning problems which focus

on a separate attribute within each data item and

only require a subset of the available background

information to solve, thus reducing the number of

possible solutions that the ILP engine must consider

to a size that it is capable of managing. The results

of each learning problem are then combined to

produce a set of rules, each of which contain range-

restrictions for every attribute within each data item.

Each set is then added into a database to produce the

overall user model.

Meanwhile the clusters of data are also used to

roduce a series of probability distributions, which

are stored for later use when querying the model.

The user modelling system consists of two parts:

a const

ruction engine which produces the user

model, and a query engine which allows the user

model produced to be used for the prediction of long

sequences of tasks.

3 BUILDING USER MODEL

The initial user model worked on within the diary

assistant (iMeeting) (Assadian, 2004) was the

learning of sequences of pairs of tasks between

tasks, e.g. if the user schedules a presentation on a

particular project and they usually schedule some

preparation time in before that presentation then we

can learn this habit and either carry out the

scheduling of preparation time automatically or

make suggestions when the user enters the

presentation task into the diary.

327

Assadian B. and Maclaren H. (2005).

USER MODELLING FOR DIARY MANAGEMENT BASED ON INDUCTIVE LOGIC PROGRAMMING.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 327-330

DOI: 10.5220/0002546003270330

 SciTePress

Let us suppose that we have data, which gives

details of three sequences that the user is known to

demonstrate: -

1. Putting in preparation time before an

administration meeting.

2. Putting in preparation time before a project

meeting or presentation.

3. Putting in travel time before paying a visit

to another company.

Examples of the sequences take the form of a pair

of tasks joined via the ‘sequence’ relationship.

All of the sequences(plus any others within the

data set) are collected as a single set of examples,

which must be split into separate clusters so that the

learning of each sequence can take place separately.

We can perform the initial splitting of the data by

using a bottom-up agglomerative clustering

algorithm over the first task of each pair to produce

a group of subsets, and then using the clustering

algorithm again on each subset on the second task of

each pair to produce the final clusters of examples,

which will be used.

Each set is used as the example set for a series of

different learning problems, each problem focuses

on a different attribute within one or other of the

tasks and attempts to find any specialisations which

may be regarded as helping to characterize the

particular sequence under examination. For example,

the first learning problem would focus on the type of

the first task of the pair in each example and would

attempt to find any regularities amongst all the

examples of the set for that particular attribute.

Subsequent learning problems would focus on the

subtype, sub-subtype, and duration of the first task

individually, and then a further set of learning

problems would focus on the individual attributes of

the second task in the same manner.

Each learning problem requires positive

examples, negative examples and background

knowledge. The positive examples are the examples

contained within the set that is currently under

examination. The background knowledge used for

each learning task is a subset of the entire set of

background knowledge available, only those items

of knowledge which directly refer to the attribute

under examination are presented to the learner for

each problem. It is this splitting of the available

background knowledge into subsets in conjunction

with the splitting of the overall learning problem

into separate smaller problems (i.e. where the length

of the clauses required is much smaller) which

enables the learner to be able to tackle the overall

problem of learning a user model as it reduces the

number of possible hypotheses to be considered to a

level which is manageable by the ILP engine.

A set of automatically generated ‘negative

examples’ is produced for the attribute currently

under examination. These are examples of pairs of

tasks that the user would never produce and hence

should not be thought of as being dependent on each

other. Each set of negative examples only differs

from the original data supplied by the user by a

small amount, and all of the negative examples

within a set differ from the original data in such a

way that the ILP engine can use part of the provided

background knowledge to successfully exclude all

the negative examples from the solution that it

produces.

If we were to generate a set of negative examples

for the ‘type’ attribute then we would take a user-

generated (positive) example:-

sequence:<

travel/london,2hrs,10-00, thursday>,

And alter one of the values, producing:-

sequence:<

admin/london,2hrs,10-00, thursday>,

This is repeated several times, using all of the

examples within the set to generate negative

examples. Values to be substituted into the attribute

to be altered must satisfy the criterion that they must

place the new example far enough away from the

original example (using the distance measure used to

produce the original clusters) that it could not be

considered as part of the cluster of original

examples. As it is likely that the amount of data with

which we will be working will not be very large, the

concepts being learnt may not be accurately

characterised by the examples collected. This

criterion allows a little more ‘space’ between the

positive and negative examples and hence allows the

learner to produce a rule which does not adhere so

tightly to the exact details of the examples collected,

hence a more general overall theory is produced

which should provide better results when asked for

predictions.

Generating of values for substitution where the

variables being examined contain real values (for

example the duration of a task) presents a further

complication. In order to ensure that the values

returned for a task prediction are accurate, the range

of values that the variable is capable of being

instantiated to must be limited. Values which are

unacceptable as predicted values can be used to

generate negative examples, but there may be cases

where individual examples within the same cluster

have values for a particular attribute which would be

unsuitable if used within other examples in the same

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

328

cluster. The two sequences listed below illustrate

this problem:-

sequence:<travel/cambridge, 2hrs, 9-00, friday>,

sequence:<travel/bath, 4hrs, 15-00, monday>,

The durations of the second task in each

sequence are so far away from each other that we

cannot allow them to be covered by a single rule.

Negative examples for the first sequence would

include values such as 5hrs and 6hrs. Negative

examples for the second sequence would include

values such as 2hrs and 1hr.

This would mean that generated negative

examples may contradict other positive examples

within the original set. We still need to restrict the

range of values that the attribute can take, so the

solution is to monitor for contradictions during the

negative example generation process and if a

contradiction occurs, split the set into a pair of

subsets with the contradicted positive in one set and

the positive from which the contradicting negative

example was generated in the other. The other

positive examples and their corresponding negatives

are allocated to the new subsets according to

whichever example they are closest to in terms of

the attribute being examined. Negative example

generation then continues, with further

contradictions within the subsets resulting in further

splitting actions, until all the positive examples have

had negative examples generated from them. The

sets are presented to the learner as separate learning

problems and the results from each problem are

added together to form a single set of possible

specialisations for that attribute.

Once all the sub problems listed earlier have been

formulated with the appropriate background

knowledge and generated negative examples, and

presented to the learner. We then have a collection

of results for each attribute that must be combined to

form the overall theory, which will characterise this

particular sequence.

Some rules may contradict each other. This

contradiction will be dealt with when we construct

the rules, which form the theory. To construct the

rules, we take the first two sets of results and

combine them by adding all the rules from the first

set to all of the rules from the second set.

The resultant set of rules is then combined with

the next set of learning results in the same way, and

the process is repeated for each set of results

collected.

Each rule is tested for contradictions by

evaluating it over the set of positive examples that it

is supposed to characterise. If the rule does not

cover any of the examples (i.e. it does not give the

answer ‘true’ when given any of the pairs of tasks),

then it is discarded. This test would remove rules

containing contradictions. The set of rules is filtered

to remove those rules subsumed by other rules, and

each rule is then filtered to remove any redundant

elements. Having performed these final filtering

stages we are then left with a set of rules that form a

theory that characterises the sequence we were

trying to learn. This process is repeated for every

cluster of examples that was initially generated and

all the rules added to a collection which encapsulates

the entire user model.

4 PREDICTING SEQUENCES

Having constructed our user model we then need to

provide a means with which to use it..

When asked to suggest possible tasks, the query

engine takes the task given and feeds it into the

database of rules. It collects two lists; one of

possible tasks to schedule before the user’s task, and

one of possible tasks to schedule after the user’s

task. Each list is then processed to find the most

likely candidate for scheduling and the two answers

returned. If there is no possible suggestion for either

answer then an empty task that describes itself as

‘No Answer’ is returned as an indicator of this

situation.

The generation of the Dirichlet distributions for

use when rating answers makes use of information

saved at the model learning stage. When the

examples were originally clustered, a separate set of

data was saved in which was stored the results of

clustering the examples over the first task (task A) in

the sequence and the results of clustering only over

the second task (task B) in the sequence. This

information represents the basis from which the set

of distributions representing p(B|A) and p(A|B) can

be calculated. As the method for generating

distributions which deal with prediction of following

tasks and distributions which deal with prediction of

preceding tasks is the same, it will only be described

from the point of view of predicting a following

task.

All the possible stereotypes (Rich 1989) for task

B can be determined by looking at the data

representing the results of clustering over task B and

taking the mode of each task B within a cluster as

this will produce examples of the possible values for

task B encountered so far. The data representing the

results of clustering over task A will contain a set of

USER MODELLING FOR DIARY MANAGEMENT BASED ON INDUCTIVE LOGIC PROGRAMMING

329

examples for each distinct task A encountered. Each

set can be used to create a Dirichlet distribution

p(B|A) by counting the number of occurrences of

each type of task B that follows the given task for

that distribution and then normalising the counts to

produce a probability. This version of the Dirichlet

distribution uses a normal prior during construction,

but leaves the possibility open to use of more biased

priors later if required.

The most likely candidates from the two lists of

tasks produced earlier are generated by sorting each

list into sub lists of similar tasks (we may have

generated several possible tasks which only differ by

a very small amount, for example one task may have

a preferred time half an hour later than another task),

and then ascertaining the most suitable candidate

from each sub list using the probability distributions

created from the original set of examples collected.

Two sets of distributions are created; one which

describes P(B|A) and the other describes P(A|B). In

both cases A is chronologically the first task in the

sequence and B the second. If we are looking at the

list of possible tasks which could follow that

specified by the user then we would use the set of

P(B|A) distributions as task A is given and we wish

to ascertain the probability of each possible task B

that has been generated. Conversely, if we are

looking for a task which would precede the user’s

task then we would use the set of P(A|B). We are

working with a set of distributions rather than

simply one because we need to construct a separate

distribution for each possible task given by the user

(i.e. each distinct ‘A’). Once we know the user’s

task then ideally we would concentrate on an

individual distribution, however the distributions are

created using stereotypes for different task types (the

set of stereotypes used contains the mode of each

cluster generated during the learning process) and

the user’s task may not match exactly any of the

tasks over which the distributions are created.

Therefore we pick all the distributions for which the

distance from the base task to the user’s task is

closer than the threshold distance used at the

clustering stage of the learning process.

Task ratings are generated by adding together the

rating from each selected distribution in turn. For

each distribution, the probability given to the

stereotype that is closest to the task being rated is

divided by its distance from the task to form the

rating for that task. This allows us to attempt to

distinguish between tasks that only differ by small

amounts and is based on the idea of the influence of

each point in the instance space represented by a

stereotype degrading with distance (hence the sum

of ratings, which is a simple method of

acknowledging influence from more than one point).

The tasks with the highest rating within each of the

sub lists generated earlier are returned to be

presented to the user as they are all valid sequences

for the task originally entered.

5 CONCLUSION

The system described within this paper has

demonstrated a new method of ILP application that

enables this machine learning method to be used for

user modelling within an Intelligent Diary (iMeeting).

This augmentation allows iMeeting to make

suggestions to the user based on previous

observations.

Sparse data will always be a problem for any

technique that attempts to make predictions based on

previous experience, whether from a generalised

version of the gathered information or from the

examples themselves. In the case of ILP, small

numbers of examples mean that the sort of generalised

rules that were envisaged are not necessarily the ones

that were constructed. Rather than creating a rule that

covers ‘all projects’, a rule or group of rules which

cover specific projects has been created. The system

generates the most accurate hypothesis it can with the

data presented, without continuous human

intervention, and this may mean that the optimum set

of rules is not always created. However, with more

data, the quality of the hypothesis has been shown to

improve.

REFERENCES

Muggleton, S, 1994. ‘Inductive Logic Programming:

Theory and Methods’. Journal of Logic Programming,

Vol 19/20, pp629—679.

Rogers, S, 2000. ‘The Learning Shell’ Adaptive User

Interfaces conference 2000

Jacobs, N, 2000. From Shell Logs to Shell Scripts. The

American Association for Artificial Intelligence 2000.

Rich, E, 1989. Stereotypes and user modelling User

models in dialog systems

Behrad Assadian 2003, An Automatic Meeting Scheduling

for Mobile Users. In ICEIS’2004, 6th International

Conference on Enterprise Information Systems

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

330
