VISUAL DATA MINING TOOLS: QUALITY METRICS

DEFINITION AND APPLICATION

Edwige Fangseu Badjio, François Poulet

ESIEA Recherche,

Parc Universitaire Laval – Changé

38, r

ue des Docteurs Calmette et Guérin

53000 Laval France

Keywords: HCI, visual data mining, software quality, utility, usability, acceptability, evaluation, GQM model

Abstract: The main purpose of this work is to integrate HCI (Human Co

mputer Interaction) requirements in visual

data mining tools engineering. We present the definition of metrics/measurements in order to improve the

quality of those tools at all the steps or after the development process. On the basis of these

metrics/measurements, we have derived a questionnaire for the evaluation of the utility, the usability and the

acceptability of visual data mining environments. A case study enables us to concretely materialize the

contribution of the measurements and also to detect and explain (design and usage) errors.

1 INTRODUCTION

According to (Fayyad et al. 1996) data mining is the

non-trivial process of identifying valid, novel,

potentially useful and ultimately understandable

patterns in data. Visual data mining consists in the

use of visualization as a communication channel for

data mining. For (Wong, 1999), visual data mining

lies in tightly coupling the visualizations and

analytical process into one data mining tool that

takes advantage of the strengths of all worlds.

The standards ISO 9241, ISO/IEC 9126, ISO

3407, (Nielsen, 1993), (Bastien et Scapin, 1999)

criteria propose attributes which characterize

software quality in terms of usability. These

attributes include: the facility to learn the software,

the user’s satisfaction, comprehensibility, efficacy,

operability, attractiveness etc... How can we

concretely incorporate these various attributes in a

visual data mining environment? We know that

finding and fixing a software problem after delivery

is often 100 times more expensive than finding and

fixing it during the requirements and design phase

(Boehm et Basili, 2001).

From the user’s point of view, the interface is the

ost important element of the software because it is

the user’s mediator with the system for the

achievement of his task (Costabile, 2000). We try to

bring replies to this question. Indeed, some research

works (Kolski et al., 2001) insists on the fact that

when the software is highly interactive, an adapted

methodological step is essential, the traditional

cycles of the software engineering being insufficient.

We have defined a set of metrics/measurements

(rec

ommendations) for the improvement of the

quality of visual data mining tools. The application

of these recommendations allows the correction of

errors likely to occur with less expense than at the

end of the design process. Based on the formal

model GQM (Basili et al., 1994), the proposed

approach also allows an evaluation after the tool

design and development in order to explain the

minor and major errors detected.

The overview of this paper is the following: first,

we e

xplain the theoretical foundations of our work

before the measurement definition and the

questionnaire presentation, section 4 presents a case

study followed by the conclusion and future works.

2 THEORETICAL FOUNDATIONS

The utility of a visual data mining tool relates to the

adequacy existing between the functions provided

by the system and those necessary to the user in

order to achieve the visual mining tasks assigned to

him.

The usability is the quality of hardware or

soft

ware which is easy and pleasant to use and to

understand, even by somebody who has little

Fangseu Badjio E. and Poulet F. (2005).

VISUAL DATA MINING TOOLS: QUALITY METRICS DEFINITION AND APPLICATION.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 98-103

DOI: 10.5220/0002547700980103

 SciTePress

knowledge in data processing. Usability is a critical

quality of the success of a software product.

The acceptability relates to the adequacy

between the decision to use the visual data mining

environment and the compatibility of the tool for the

user and the organization to which he belongs.

A measurement is a support allowing answering

a variety of questions related to the software

development process. It also allows evaluating and

measuring the quality of the end products.

A metric is a mathematical number that shows a

relationship between two variables.

The theoretical base of this research work is

software quality studies. Quality is the aptitude of a

product or a service to satisfy the user's needs. One

of the earlier works of the software quality field is

McCall’s (McCall et al, 1977) model which counts

around fifty criteria allowing the expression of

software quality in general. Another set of software

quality factors was carried out by (Boëhm, 1978).

These factors are related to the software

functionalities and performances from the software

engineering point of view and the usability. From

the human machine interaction and software

engineering point of view, the awaited aptitudes of

the software analysis and different level of

evaluation: the satisfaction of the user's needs,

reliability, interoperability, conformity with the

standards and a good ratio cost/performance. More

recently, case studies such as (Nielsen, 1993),

(Bastien et Scapin, 1999) stress the ergonomic

evaluation and improvement of the user interface

much more. Cognitive psychology work related to

data visualization (Healey, 1996) proposes also

interesting primitives in such cases.

The principal advantage of ergonomic inspection

is its level of detail. Indeed, this method guarantees

an exhaustive analysis of the overall software.

For the needs of data mining algorithm's

technical aspect evaluation, data sets repository

creation efforts was the object of projects such as

UCI (Blake et al, 1998). In visualization for mining

purpose, Grinstein's research work (Grinstein et al,

1997) allowed the evaluation of data representation

methods. The evaluation criteria were: the memory

size of the computers, their execution speed and

their graphical capacities. It should be noted that we

have taken into account all the various details

explained in this section for the development of our

evaluation method so that it is as most complete as

possible.

For the visual data mining tools measurements

specification, our formal framework is GQM

"Goal/Question/Metrics" (Basili and al. 1994)

model. GQM is a support making it possible to

better clarify the objectives to be reached, a set of

attributes are identified via questions. Downwardly,

measurements are defined. For the evaluation and

the explanation, one proceeds in an ascending way.

If one is located in the measurement

specification model (figure 1), our objective will be

to find the means of specifying each usability

criterion described by the various ISO standards in

order to apply it to visual data mining specificities.

For example in order to develop the user’s guidance

(goal), the question will be how to advise, direct our

end-users? One of the answers is to provide decision

support or recommendation for the selection of the

data mining algorithm to be performed.

Figure 2 describes the measurement definition

process. First, we have done an analysis of end users

followed by a task analysis, the usability goals

definition in a visual data mining context. More

description of the new evaluation approach is the

subject of the following section.

Goal 2

Goal 1 Goal 3

Definition

User

analysis

Task

Analysis

Usability

goals

Questions

DERIVE

Measures

DERIVE

Figure 2: Measure definition process

uestion

Measure Measure

Measure

Interpretation

Figure 1: GQM Model (Basili et al 1994)

VISUAL DATA MINING TOOLS: QUALITY METRICS DEFINITION AND APPLICATION

3 METRIC DEFINITION

Metrics/measurements are important for software

engineering activity. Developers use metrics for

controlling software quality throughout the project

life cycle. By using software measurements, the

managers can see measurable attribute of the

software quality. Customers look for the

measurements in order to determine the quality of

the products. Maintainers use metrics as an indicator

for reusability or reengineering.

3.1 User analysis

The end-user of visual data mining tools could be

the data specialist. He has a basic knowledge in data

analysis. This data mining approach has been

developed for the need of integrating the user in the

knowledge discovery process in order to combine

the human potentialities of judgement with the

computer calculation capacities.

3.2 Task analysis

(Ankerst, 2000) describe a task model for visual

data mining field. This model includes data

visualization and application of mining algorithms

steps. Ankerst’s model more explicitly reduced the

visual data mining to the use of data visualization

during the pre-treatment (data exploration phases),

the treatment (knowledge discovery step) or the post

processing (knowledge representation step). This

model does not correspond to our visual data mining

model detailed by the figure 3. The user can

visualize the data in pre-treatment. The fundamental

difference is the fact that the user interacts with a

graphical representation (chart) of that data in

knowledge discovery in the data. The data model

(knowledge) is built in an interactive way.

3.3 Usability goals: G of GQM

The ISO 9241, ISO/IEC 9126, ISO 13407 standards,

(Bastien et Scapin, 1999) and (Nielsen, 1993) work

propose metrics for software usability improvement.

(Bastien et Scapin, 1999) metrics are used like

support. These metrics constitute the G (goals) side

of the GQM model. These metrics are:

Guidance: means implemented in order to

advise, direct, inform and lead users.

Workload: the interface elements must reduce

the users’ perceptive load, just as in the

improvement of the dialogue efficacy.

Explicit control: possibility for the system to

take into account the explicit actions of the users and

the control they have, relating to their actions

treatment.

Adaptability: system capacity to react according

to the context, the needs and the user preferences.

Error management: means allowing to reduce

errors and to correct them when they occur.

Compatibility: agreement between the users’

characteristics, the tasks and their organisation.

In the following sections, we will use the GQM

model (figure 1) to formalize these usability needs

according to the visual data mining field.

3.4 Questions to answer for

improving usability and utility: Q

of GQM

After having defined our GQM model goals, the

second stage consists of the definition of a set of

questions whose responses will allow the

achievement of the goals. The task analysis enabled

us to define also a set of questions related to utility

(technical quality of tools) and to mix them with

usability questions. Due to space constraints, the set

of questions can not be presented here.

3.5 Usability and utility measures: M

of GQM (top level)

We studied the visual data mining process in order

to bring responses relating to usability’s and utility’s

questions. These responses include the specificities

of visual data mining tools. For example, for the

users’ workload reduction, it is judicious to give

them the possibility of choosing a visualization

method among several possible alternatives.

Several analysis methods can be included in a

data mining environment. For the usability

(guidance) improvement, the developers have to

advise users in the choice of the most suitable

Data

User in

Visualization

Results

Interactions

Knowledge

Figure 3: our visual data mining task model

ICEIS 2005 - HUMAN-COMPUTER INTERACTION

100

method. The execution of an analysis method is time

consuming. If the method execution does not finish

under good conditions it is necessary to envisage the

re-use of training data. In order to take into account

user preferences, developers must also envisage

several visualisation methods.

3.6 Usability and utility measures: M

of GQM (lower level)

There are several methods for software evaluation

needs. We have chosen a questionnaire for the

setting up of our evaluation method because its does

not require any user competence. The questionnaire

has six topics. It provides a methodology to verify if

the desired quality requirements (G of GQM) have

been satisfied. It is also used to conduct tests,

conduct reviews and audits and to review software

program design. Table 1 presents rating levels in

order to fill in the questionnaire. The best level

possible with our rating level is 5, the worst possible

level is 1.

Mark Rating

1 Absent, Strongly disagree, Extremely

(difficult, confusing, boring)

2 Poor, Somewhat disagree, Somewhat

(difficult, confusing, boring)

3 Fair, Neutral

4 Good, Somewhat agree, Somewhat

(easy, clear, fun)

5 Excellent, Strongly agree, Extremely

(easy, clear, fun)

The first topic of our questionnaire is the visual

data mining tool technical quality, (table 2) it

relates to technical aspect: data-processing

capabilities, operating system, speed, compatibility,

etc… The perception of the tool technicality allows

the measurement of the tool power given the

capacities offered. The evaluation on this level refers

to the adaptability to the task, with the

implementation precision, the capacity of knowledge

prediction. The measurements based on technology

also allow the evaluation of the degree with which

the system can handle data of variable sizes.

The Scenario topic refers to the execution

details of the visual data mining software. These

details particularly relate to the interaction quality

and time necessary for this purpose.

The topic Interface presentation model (IPM)

refers to the elements of the graphic interface (color,

typography …) and allows the consideration of

aesthetics and attracting aspects of the tool.

The Visualization topic relates to the relevance

of the charts and their structure compared to the

mining objectives of the user and his profile. It is

question here of seeing in which cases the charts

used facilitate knowledge perception and

comprehension.

The Usability topic is based on general

recommendations for the ergonomic design of the

interface.

The topic User allows defining explicitly the

user profile and takes it into account for the software

improvement. User topic also makes it possible to

have an overall perception of the use of the visual

data mining tool, of its design features, such as the

adaptability and the adequacy of the system, of its

communication and control facilities, its robustness

and its effectiveness, its simplicity of

implementation and comprehension, as well as its

convivial and personalized character. This topic

makes it possible to understand the total reaction of

a user compared to the mode and structure of the

interaction, the communication means used,

flexibility and assistance.

Table 1: Rating levels

Table 2: Technical quality

1 2 3 4 5

Installation

Assistance

Portability

Architecture

Heterogeneous data

access

Algorithms diversity

Data models validation

Results appearance

Models exportation

Interoperability

Efficiency

Robustness

Re use of training data

Treatment of data sets

with large dimension

4 CASE STUDY

In this section, we will apply the questionnaire in

order to evaluate the quality of two methods

included in a visual data mining tool. These methods

are CIAD (Poulet, 2001) and PBC (Ankerst et al.,

1999). We listed four visual data mining methods.

But two of these methods are not free.

These evaluated methods relate to visual data

mining: the use of two dimensional visualizations

VISUAL DATA MINING TOOLS: QUALITY METRICS DEFINITION AND APPLICATION

101

techniques and the capacity of the system to treat

complex interactions between all the possible pairs

of attributes. The test is performed by four

autonomous users (a researcher and three PhD

students in visual data mining field). This evaluation

aims to detect and explain design problems (usage

step).

4.1 Evaluation tasks

For our evaluation needs, the prescribed task is the

interactive construction of decision trees starting

from representations of small data sets like Iris (150

records, 4 numerical attributes, 3 classes), glass (214

records, 6 numerical attributes, 9 classes),

ionosphere (351 records, 2 numerical attributes, 34

classes) data sets from the UCI (Blake et Merz,

1998). The decision trees allow partitioning a great

quantity of data in small segments by application of

a series of decision rules. They are very much used

in data mining. Their coupling with data

visualization leads to tools for interactive

construction of decision trees in which the end-users

could be the data field specialists. The quality of the

models resulting from the visual data mining

depends on the quality of the method used. It is thus

necessary to develop tools useful, usable and

acceptable for data field expert’s users. The

following paragraph describes the interpretation of

the obtained results.

4.2 Evaluation results

Table 3 presents the mean ratings of the case study

evaluation questionnaires. The first six lines

represent the topics of the evaluation questionnaires.

We present also five sub topics (the last five lines of

the table 3) which we considered to be more

relevant.

The evaluators agree on the fact that the tools are

very useful. The error’s treatment is done in a

relevant manner; CIAD and PBC are thus

convenient. Also, for an autonomous user, the tool is

very easy to understand and to use. The interfaces

presentation models are well developed. The

elements disposal on the screen is very good;

graphics and colours are well used. CIAD allows the

training data set re-use, which makes it possible to

reduce the users’ workload. Such is not the case for

PBC.

The evaluators also agree on the fact that the

installation of these tools is not obvious. These tools

are designed for experimental purposes. Only one

algorithm and only one visualization method are

implemented for PBC and CIAD. The users can not

assess prefered analysis methods or visualization

tools. It is not possible to access various data set

formats. For CIAD and PBC, the users are not

directed (guided), also, it misses the on line help, the

contextual menus, the user manual. The results of

this evaluation allow the designers of CIAD and

PBC to develop the aspects related to the usability

(assistance modules, user manual, several

alternatives possible with regard to data analysis

methods and data visualization, cognitive aspects of

visualization for data mining, user preferences) of

these tools and thus to work on their acceptability.

Table 3: Mean rating scores

PBC CIAD

Guidance 1 1.5

Workload 1 1.5

Explicit control 1 1.5

Adaptability 1 1

Error management 3.5 3.75

Compatibility 2 3

Usefulness 5 5

Ease of use 3.25 3.75

Assistance 1 1

Learning ability 3.5 3.5

Installation 1 1

5 CONCLUSION

In order to avoid the redevelopment of design which

generates wastes of time and high cost of production

without however guaranteeing performance, we

study the development of useful, usable and

acceptable visual data mining software. To this end,

we have drawn up a list of criteria having to be taken

into account for a development of reliable tools of

this type and for their evaluation. Also, in order to

cover all the aspects of that type of tool analysis, we

listed six topics. Those topics are defined in the form

of a tree structure including the principal topic,

under topics or meta-criteria and criteria. These

various criteria have been used for the evaluation of

CIAD and PBC, modules dedicated to the interactive

construction of decision trees. The evaluation

allowed us to use one of the advantages of our

analysis approach. It allows a thorough evaluation of

the software (interface, technical quality, ergonomic

(usability), visualization and scenario). The design

problems are thus discovered on all the tool levels.

The end users of visual data mining tools could

be data domain specialists. They don’t have

knowledge needed for the selection of the best tool

available for the treatment of their data. From the

method presented above, we work now on the

ICEIS 2005 - HUMAN-COMPUTER INTERACTION

102

definition of a preference index for the

recommendation of visual data tools to these users.

REFERENCES

Ankerst M., 2000. "Visual Data Mining", PhD Thesis,

Ludwig Maximilians University of Munich, 2000.

Ankerst, M., Elsen C., Ester, M., and Kriegel, H.-P., 1999.

Visual classiffication: An interactive approach to

decision tree construction. In Proceedings of ACM

SIGKDD International Conference on Knowledge

Discovery and Data Mining, p. 392-396.

Basili, V., Caldiera, G. and Rombach, D., 1994. The Goal

Question Metric Approach.

Encyclopedia of Software

Engineering. Wiley 1994.

Bastien, J.M.C., and Scapin, D.L., Leulier C., 1999. The

ergonomic criteria and the ISO/DIS 9241-10 dialogue

principles: a pilot comparison in an evaluation task.

Interacting with Computers, Vol. 11, n° 3, p. 299-322,

1999.

Blake, C., Merz, C., 1998. UCI Repository of machine

learning databases, [www.ics.uci.edu/~mlearn/MLRe

pository.html]. Irvine, University of California,

Department of Information and Computer Science.

Boehm, B. and Basili, V., 2001.

Software Defect

Reduction Top 10 List

, IEEE Computer, Vol.. 34, No.

1, January 2001.

Boëhm, B., 1978. Characteristics of software quality, Vol

1 of TRW series on softwaretechnology, North-

Holland, Amsterdam, Netherlands, 1978.

Costabile, M.F., 2001. Usability in software life cycle In

Handbook of of Software Engineering and Knowledge

Engineering, SK Chang Ed., World Scientific, Vol ,

World Scientific Publ. Company, 2001.

Fangseu Badjio E., Poulet F., 2004, A decision support

system for data miners, in proc. of AISTA'04, The

International Conference on Advances in Intelligent

Systems - Theory and Applications in cooperation

with IEEE, Luxembourg-Kirchberg, Luxembourg,

November 15 – 18 2004, ISBN 2-9599776-8-8.

Fangseu Badjio E., Poulet F., Usability of Visual Data

Mining Tools, in proc. of ICEIS'04, the 6th

International Conference on Enterprise Information

Systems, Porto, Portugal, April 2004, Vol.5, 254-258,

ISBN: 972-8865-00-7.

Fayyad, U. M., Piatetsky-Shapiro, G., and Smyth, P. 1996.

editors Advances in Knowledge Discovery and Data

Mining. AAAI Press / MIT Press, Menlo Park, CA.

Grinstein ,G. G., Hoffman, P., Laskowski ,S. J. and

Pickett, R. M., 1997. Benchmark Development for the

Evaluation of Visualization for Data Mining Proc. of

the Workshop: Issues in the Integration of Data

Mining and Data Visualization, Newport Beach,

California, August 17, 1997.

Han, J., Cercone, N., 2001. "Interactive Construction of

Decision Trees" in proc. of PAKDD'2001,LNAI 2035,

575-580, 2001.

Healey, C.G., 1996. Choosing Effective Colours for Data

Visualization , in Proceedings of the 7th conference on

Visualization '96, p 263-270.

ISO (International Organization for Standardization),

1997. ISO 9241: Ergonomics Requirements for Office

Work with Visual Display Terminal (VDT) - Parts 1-

17.

ISO (International Organization for Standardization),

1998. ISO 13407: Human-Centered Design Process

for Interactive Systems, 1998.

ISO/IEC (International Organization for Standardization

and International Electrotechnical Commision), 1998.

ISO/IEC 9126-1: Information Technology – Software

Product Quality, 1998.

Kolski, C., Ezzedine, H., Abed, M., 2001. Développement

du logiciel: des cycles classiques aux cycles enrichis

sous l'angle des IHM. In Kolski C. (Ed.), Analyse et

Conception de l'IHM. Interaction Homme-machine

pour les SI, vol. 1, Hermès, Paris, pp. 23-49, ISBN 2-

7462-0239-5.

McCall, J.A., Richards, P.K., and Walters, G.F., 1977.

Factors in software quality, Vols I-III, Rome Air

Development Centre, Italy.

Murine, G. and Carpenter, C., 1984. Measuring software

product quality", Quality progress, Vol 7(5), p16-20,.

Nielsen, J., 1993. Usability Engineering, Academic Press,

Cambridge, MA.

Nielsen, J., 2000.

Why You Only Need to Test With 5

Users

http://www.useit.com/alertbox/20000319.html.

Poulet, F., 2001. "CIAD: Interactive Decision Tree

Construction, in proc. of VIII Rencontres de la Société

Francophone de Classification, Pointe-à-Pitre, 275-

282.

Ware, M., Franck, E., Holmes, G., Hall, M., Witten, I.,

2001. "Interactive Machine Learning: Letting Users

Build Classifiers", in International Journal of Human-

Computer Studies (55), 281-292, 2001.

Wong, P.C., Visual Data Mining, in IEEE Computer

Graphics and Applications, 19(5), p.20-21, Sept.Oct.

1999.

VISUAL DATA MINING TOOLS: QUALITY METRICS DEFINITION AND APPLICATION

103
