MUSICAL RETRIEVAL IN P2P NETWORKS UNDER THE

WARPING DISTANCE

∗

Ioannis Karydis, Alexandros Nanopoulos, Apostolos N. Papadopoulos and Yannis Manolopoulos

Department of Informatics, Aristotle University, 54124 Thessaloniki, GREECE

Keywords:

Music Information Retrieval, Similarity Searching, Peer-to-peer Networks, Multimedia Databases.

Abstract:

Peer-to-peer (P2P) networks present the advantages of increased size of the overall database offered by a

the network nodes, fault-tolerance support to peer failure, and workload distribution. Music ﬁle storage and

exchange has long abandoned the traditional centralised server-client approach for the advantages of P2P

networks. In this paper, we examine the problem of searching for similar acoustic data over unstructured

decentralised P2P networks. As distance measure, we utilise the time warping. We propose a novel algorithm,

which efﬁciently retrieves similar audio data. The proposed algorithm takes advantage of the absence of

overhead in unstructured P2P networks and minimises the required trafﬁc for all operations with the use of

an intelligent sampling scheme. Detailed experimental results show the efﬁciency of the proposed algorithm

compared to an existing baseline algorithm.

1 INTRODUCTION

The increasing popularity of the availability of mu-

sic in computer ﬁles gives further impulse to the de-

velopment of digitised music databases as well as to

new methods for Music Information Retrieval (MIR)

in these collections. Although abundantly used, even

nowadays, the traditional metadata (title, composer,

performer, genre, date, etc.) of a music object give

rather minimal information about the actual content

of the music object itself. Their use aims solely in

avoiding including musical content in the query. On

the other hand, queries based on humming (using a

microphone) or on a small piece of musical ﬁle, are

a more natural approach to MIR. This type of queries

lies within the Content-Based MIR (CBMIR). In CB-

MIR, an actual music piece is required in order to

compare its content with the content of the music

pieces already available in the database.

As far as the type of the database is concerned,

music ﬁle storage and exchange has long abandoned

the traditional centralised server-client approach for

the advantages of the peer-to-peer networks (P2P).

Within the advantageous qualities of the P2P net-

works lies the increased size of the overall database

∗

Research funded by the IRAKLITOS national program

(2003-2005) under the EPEAEK framework

offered by a P2P network, its fault tolerance support

to peer failure by other peers and the workload distri-

bution over a network of available CPUs, since CB-

MIR is computationally highly intensive. Nonethe-

less, the very advantages of the P2P network are the

same parameters that make P2P information retrieval

much more complex than the traditional search meth-

ods. That is, the lack of central repository for the doc-

uments to be retrieved, the large number of documents

available and the dynamic character of the network,

introduce an increased degree of difﬁculty in the re-

trieval process.

Among numerous classiﬁcations, P2P networks

can be classiﬁed based on the control over data lo-

cation and network topology in unstructured, loosely

structured and highly structured (Li and Wu, 2004).

Unstructured P2P networks follow no rule in where

data is stored while the network topology is arbi-

trary (e.g., Gnutella). The absence of structure al-

lows for resilience in dynamic environments (peer

join/leave) while no guaranties can be given on the

retrieval of existing documents. Moving towards in-

creased structure, both the probability of retrieving

existing documents and the overhead of handling peer

join-leave augment (e.g., Freenet and Chord). Addi-

tionally, P2P networks can also be classiﬁed accord-

ing to the number of central directories of document

100

Karydis I., Nanopoulos A., N. Papadopoulos A. and Manolopoulos Y. (2005).

MUSICAL RETRIEVAL IN P2P NETWORKS UNDER THE WARPING DISTANCE.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 100-107

DOI: 10.5220/0002548201000107

 SciTePress

locations in centralised (e.g., Napster), hybrid (e.g.,

Kazaa) and decentralised (e.g., Chord). Centralised

P2P networks are subject to the same drawbacks for

which the traditional server-client model was origi-

nally abandoned (network failures due to central peer

failure, impaired scalability, joining/leaving of peers

not easily handled, possible undesirable dominion of

controllers). For these reasons, we focus on decen-

tralised unstructured P2P networks, which overcome

the aforementioned drawbacks. The absence of struc-

ture was selected for the looseness of control over the

data location, that is each peer can share its own doc-

uments without hosting any documents of other peers

due to locality restrains.

Music representation can primarily be separated in

two classes: the symbolic representation (MIDI for-

mat) and the acoustic representation (audio format -

wav, mp3). The focus of this work is on acoustic

data, thus a musical piece can be considered as a time

series of signal intensity over time. To measure the

similarity of two musical pieces, we utilise the Dy-

namic Time Warping (DTW) method. The main ﬂex-

ibility of the DTW method is its capability to with-

stand distortion of the comparing series in the time

axis. Accordingly, it allows for two locally out of

phase time series that are nevertheless similar to align

in a non-linear manner. Since different performances

of the same musical piece may include locally differ-

entiated tempo, DTW seems a natural choice for this

problem (Large and Palmer, 2002). For this reason, it

has been recently proposed for shake of MIR in cen-

tralised environments (Zhu and Shasha, 2003; Maz-

zoni and Danneberg, 2001; Jang et al., 2001; Adams

et al., 2004).

In this paper, we focus on the problem of search-

ing, based on DTW, for similar acoustic data over un-

structured decentralised P2P networks. The technical

contributions of this paper are summarised as follows:

• The development of a novel algorithm that efﬁ-

ciently retrieves audio data similar to an audio

query in an decentralised unstructured P2P net-

work.

• The proposed algorithm takes advantage of the ab-

sence of overhead in unstructured P2P networks

and efﬁciently minimises the required trafﬁc for all

operations with the use of an intelligent sampling

scheme on the lower and upper bounds used. The

proposed algorithm has such a design that no false

negative results occur.

We must notice that with the examined framework we

refer to applications that support content sharing for legal

subscribers (e.g., iTunes). Moreover, it is interesting to no-

tice that the proposed approach can be adopted as a means

of identiﬁcation of illegal sharing, by ﬁnding sites that share

unregistered content.

• The detailed experimental results which show the

efﬁciency of the proposed algorithm, and the per-

formance gains compared to an existing baseline

algorithm.

The rest of the paper is organised as follows. Sec-

tion 2 describes related work. Section 3 provides a

complete account of the algorithm proposed in this

paper. Subsequently, Section 4 presents and discusses

the experimentation and results obtained. Finally, the

paper is concluded in Section 5.

2 BACKGROUND AND RELATED

WORK

2.1 Searching methods in

unstructured P2P networks

In this section we summarise a number of different

searching methods for decentralised unstructured P2P

networks. Initially, we examine the Breadth-First

Search (BFS) algorithm. In the BFS, a query peer

Q propagates the query q to all its neighbor peers.

Each peer P receiving the q initially searches its lo-

cal repository for any documents matching q and then

passes on q to all its neighbors. In case a P has

a match in its local repository then a QueryMatch

message is created containing information about the

match. The QueryMatch messages are then transmit-

ted back, using reversely the path q travelled, to Q.

Finally, since more than one QueryMatch messages

have been received by Q, it can select the peer with

best connectivity attributes for direct downloading of

the match. It is obvious that the BFS sacriﬁces perfor-

mance and network trafﬁc for simplicity and high-hit

rates. In order to reduce network trafﬁc, the TTL para-

meter is used (see Section 2). In a modiﬁed version of

this algorithm, the Random BFS (RBFS) (Kalogeraki

et al., 2002), the query peer Q propagates the query q

not to all but at a fraction of its neighbor peers.

In an attempt to rectify the inability of the RBFS to

select a path of the network leading to large network

segments, the >RES algorithm was developed (Yang

and Garcia-Molina, 2002). In this approach, a node Q

propagates the q to k neighboring peers, all of which

returned the most results during the last m queries,

with k and m being conﬁgurable parameters. >RES

can be characterised as quantitative than qualitative,

since it does not consider the content of the query.

With ISM (Kalogeraki et al., 2002), on the other

hand, for each query, a peer propagates the query q to

the peers that are more likely to reply the query based

on the following two parameters; a proﬁle mechanism

and a relevance rank. The proﬁle is is built and main-

tained by each peer for each of its neighboring peers.

The information included in this proﬁle consists of the

MUSICAL RETRIEVAL IN P2P NETWORKS UNDER THE WARPING DISTANCE

101

t most recent queries with matches and their matches

as well as the number of matches the neighboring peer

reported. Obviously, the strong point of the ISM ap-

proach is in environments that show increased degree

of document locality.

2.2 MIR in P2P networks

The ﬁeld of combined CBMIR and P2P networks is

deﬁnitely very young as the inaugural research pa-

per dates back in 2002 (Wang et al., 2002). Despite,

the limited number of works that exist, are presented

thereinafter.

In this ﬁrst attempt, the authors of (Wang et al.,

2002) present four P2P models for CBMIR. The four

models include all centralised, decentralised and hy-

brid categories. Accordingly, the authors of (Wang

et al., 2002) propose a retrieval acceleration algorithm

based on difference in pitch between two tones of mu-

sic and a result ﬁltering method relying on replication

removal techniques. Additionally, the authors pro-

pose an architecture of a CBMIR P2P system, that

falls within the hybrid category of P2P systems.

Another research based on a hybrid conﬁguration

is presented in (Tzanetakis et al., 2004). Therein the

authors propose a system that utilises both manually

speciﬁed attributes (artist, album, title, etc.) and ex-

tracted features in order to describe the musical con-

tent of a piece. The underlying P2P network is a DHT-

based system. In such systems each node is assigned

with a region in a virtual address space, while each

shared document is associated with a value of this ad-

dress space. Thus, locating a document requires a key

lookup of the node responsible for the key.

The author in (Yang, 2003) proposed the utilisation

of the feature selection and extraction process that is

described in (Yang, 2002) for CBMIR in a decen-

tralised unstructured P2P system. The research con-

siders both a replicated database and a general P2P

scenario, while special attention is given on the con-

trol of the workload produced at queried peers during

query time. Each query is divided into two phases,

the ﬁrst of which includes only a subpart of the actual

query vectors, in order to distinguish high probability

response peers. Accordingly, a peer ranking occurs

and the full query vectors are sent to all peers. Given

that a peer has free CPU resources, it decides whether

to process a query or not based on the ranking that

the speciﬁc query received. It is obvious that this ap-

proach produces large network trafﬁc, since the full

query vectors are sent to all peers, instead of the most

promising.

2.3 DTW background information

The efﬁcient processing of similarity queries requires

the addressing of the following important issues:

• the deﬁnition of a meaningful distance measure

D(S, C) in order to express the similarity between

two time series objects S and C,

• the efﬁcient representation of time series data, and

• the application of an appropriate indexing scheme

in order to quickly discard database objects that can

not contribute to the ﬁnal answer.

One of the most fundamental research issues in

time series is the deﬁnition of meaningful measures

towards time series similarity expression. Given two

time series S and C the problem is to deﬁne a distance

measure D(S, C) which expresses the degree of sim-

ilarity between S and C. One of the most widely used

distance measures for time series is the Euclidean dis-

tance (L

norm), which has the restriction that both

series must be of the same length. Given two time se-

ries S and C of length N, the Euclidean distance is

deﬁned as follows:

euclidean

i=1

− C

)

(1)

where S

, C

are the value of S and C for the i-th time

instance. The Euclidean distance has been widely

used as a similarity measure in time series literature

(Agrawal et al., 1993; Faloutsos et al., 1994; Chan

and Fu, 1999; Kontaki and Papadopoulos, 2004), due

to its simplicity.

Several alternative distance functions have been

proposed in order to allow translation, rotation and

scaling invariance. Consider for example the time se-

ries depicted in Figure 1. Note that although all time

series have the same shape, they will be considered

non-similar if the Euclidean distance is used to ex-

press similarity. Translation, rotation and scaling in-

variance are studied in (Agrawal et al., 1995; Yi et al.,

2000; Chan and Fu, 1999; Yi and Faloutsos, 2000).

Taking into consideration that the Euclidean dis-

tance does not always meet the application’s require-

ments, Dynamic Time Warping (DTW) has been pro-

posed as a more robust similarity measure. DTW

can express similarity between two time series even

if they are out of phase in the time axis, or they

do not have the same length. The DTW distance

DT W

(S, C) between time series S and C is es-

sentially a way to map S to C and vice-versa. This

process is also known as alignment of time series. If

S is of length N and C is of length M, then the dis-

tance D

DT W

can be evaluated by using the following

method:

1. An N × M matrix is constructed, where the cell

in the i-th row and the j-th column contains the

distance d(S

, C

) = (S

− C

)

2. A warping path is deﬁned which is a contiguous

set of matrix cells that deﬁnes a mapping between

elements of S and elements of C.

ICEIS 2005 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

102

Although there are many warping paths that map

S to C, what is required is to determine the most

promising one, by trying to optimise the cumula-

tive distance γ(i, j) in each cell of the warping path.

Therefore, the following recurrence is deﬁned:

γ(i, j) = d(S

, C

) + min{γ(i − 1, j − 1),

γ(i − 1, j), γ(i, j − 1)} (2)

Figure 1 illustrates an example of two time series

aligned by means of the Euclidean distance (Figure

1(a)) and by DTW distance (Figure 1(b)). It is evident

that the two time series are similar but their phases are

different. However, their similarity can not be cap-

tured by the Euclidean distance.

(a) alignment using Euclidean distance (b) alignment using DTW distance

Figure 1: Time series alignment with Euclidean and DTW

distances.

The most important disadvantage of the DTW

method is that it does not satisfy the triangular in-

equality, which is a desirable property for construct-

ing efﬁcient indexing schemes and pruning the search

space. Moreover, the calculation of D

DT W

(S, C) is

signiﬁcantly more CPU intensive than the calculation

of D

Euclidean

(S, C). Therefore, an interesting direc-

tion for performance improvement is the deﬁnition of

a lower bound, in order to take advantage of indexing

schemes and avoid the computation of DTW when

there is a guarantee that the two time series are not

similar. In this work we utilise the lower bound pro-

posed in (Keogh and Ratanamahatana, 2004) which is

termed LB

Keogh and it is deﬁned as follows:

Keogh(S,C) =

i=1







− U

)

, if C

> U

− L

)

, if C

< L

0, otherwise

(3)

where U and L is the upper and lower bound respec-

tively for the time series S. Essentially, for each i,

the upper bound guarantees that U

≥ S

and the

lower bound guarantees that L

≤ S

. In (Keogh

and Ratanamahatana, 2004) it has been proven that

Keogh(S, C) ≤ D

DT W

(S, C), and therefore

the distance measure LB

Keogh(S, C) can be effec-

tively used for pruning, resulting in considerably less

number of D

DW T

computations.

3 PROPOSED METHOD

3.1 Overview

As explained, P2P searching algorithms are based on

the following scheme: the node that poses the query

examines its contents and ﬁnds documents that sat-

isfy the query. Then, it selects a subset of its peers and

propagates the query to them. Each peer in its turn ex-

amines its contents to ﬁnd qualifying documents, and

then propagates the query to a subset of its peers. To

avoid the involvement of a prohibitively large number

of nodes, the propagation of queries is restrained by a

MaxHop parameter, which determines the number of

peers a query should be forwarded. (The MaxHop pa-

rameter is equivalently called Time To Leave (TTL).)

In the context examined in this paper, each query

searches for similar music documents (i.e., query

by content and not by metadata, like title, artist,

etc.), where similarity is measured through DTW. To

speedup searching, we use lower bounds (LB) that

have been developed for DTW, the LB

Keogh in par-

ticular (Keogh, 2002). As mentioned, LB

Keogh is

based on a bounding envelope, which is deﬁned by

the U and L sequences (see Section 2.3). Therefore,

in this context, the information that is propagated be-

tween nodes comprises the U and L sequences. A

node that receives these sequences, computes the LB

value between its documents and the envelope. When

a LB value is smaller than the user-speciﬁed similar-

ity threshold, then the actual query sequence is prop-

agated to this node

and the actual DTW distance is

computed between the query and the corresponding

document.

The queries we consider constitute music phrases,

that is, excerpts of the music documents that are a type

of units of music information

. This holds especially

in the context of query by humming, where users tend

to hum a piece that is (i) relatively short, (ii) well iden-

tiﬁed and separated within a song. The identiﬁcation

of phrases can be done following the methodology

presented in (Zhu and Shasha, 2003). In particular,

a transcription algorithm (Klapuri, 2004) can produce

the pitch information of the acoustic sequence. Time

intervals, corresponding to phrases in the pitch infor-

mation, are detected in between the time instances

that silence exists (the same time intervals produce

the phrases in the corresponding acoustic sequence).

In summary, we are interested in ﬁnding music doc-

uments that contain phrases similar to the query se-

The query can be directly propagated from the node

that initially posed the query, since the currently visited

node always knows the address of this initial node.

A minimum-length portion of the musical piece that is

meaningfully independent and complete within a piece of

music.

MUSICAL RETRIEVAL IN P2P NETWORKS UNDER THE WARPING DISTANCE

103

quence. Similarity through DTW is suitable in this

context, since the properties of DTW help in alleviat-

ing errors that humming produces.

An important observation is that acoustic data tend

to be very large. Although queries are music phrases

(i.e., parts of the music sequences), the number of el-

ements in a phrase of even few seconds can be several

hundred thousands. The length of the U and L se-

quences is equal to the length of the query sequence.

This means that a straightforward approach, which di-

rectly propagates U and L sequences between nodes,

will result into an extremely large trafﬁc over the P2P

network. Moreover, when the length of the envelope’s

sequences are large, the computation of LB in each

node can become rather costly. This violates the need

of a P2P network to burden the participating nodes as

little as possible. Notice that the aforementioned re-

quirements are not present in other contexts, like the

searching of similar text documents over a P2P net-

work, where queries consist of up to some tenths of

terms.

We propose a two-fold scheme which signiﬁcantly

reduces the trafﬁc over the P2P network when query-

ing music documents by content. The scheme works

as follows:

• It reduces the length of the envelope’s sequence

by sampling them. However, plain sampling can

be ineffective, since it leads to underestimation of

LB. For this reason, we describe a novel sampling

method to reduce the length of the sequences with-

out signiﬁcantly affecting the computation of LB.

Additionally, we are interested in not introducing

false-negatives due to the use of sampling.

• It uses (whenever possible) a compact representa-

tion of the sampled sequences of the envelope. The

representation comprises a kind of compression for

the sequences, but it does not burden the nodes of

the P2P network with the cost of decompression.

If the latter is not undesirable, further compression

can be achieved through the use of existing meth-

ods. We do not explore this direction, since it does

not affect the relative performance of the proposed

scheme against the plain one that directly propa-

gates the envelope (i.e., the performance of both

methods will be equally improved).

In the following we describe the aforementioned

issues in more detail. We have to notice that, for

simplicity, we use the BFS algorithm as a basis for

searching over the P2P network. The examination of

the proposed scheme in more advanced searching al-

gorithms (e.g., ISM, >RES) is actually a matter of

current research. In a larger version of this work, we

will include a comparison that considers such search-

ing algorithms as well.

3.2 Sampling and representation

Let the considered phrase length be equal to N. The

length of each query Q, and therefore of its upper (U)

and lower (L) sequences, will also be equal to N. We

would like to sample U and L, so as to obtain two se-

quences U

′

and L

′

, each of length M ≪ N. Initially,

we assume that uniform sampling is performed. In

this case, we simply select each time the (i × N/M)-

th element of U and L, where 1 ≤ i ≤ M . When we

compute the LB

Keogh between the query sequence

Q and a data sequence, we consider each phrase C of

length N in Q. Each phrase has to be sampled in the

same way as U and L. This leads to a sampled phrase

′

. Therefore, we get a lower-bound measure LB

′

given as:

′

i=1







′

− U

′

)

, if C

′

> U

′

− L

′

)

, if C

′

< L

′

0, otherwise

(4)

In the aforementioned equation, the third case (i.e.,

when L

′

≤ C

≤ U

′

) does not contribute in the com-

putation of LB

′

. The problem of uniform sampling is

that, as it selects elements without following any par-

ticular criterion, it tends to select many elements from

U and L that result to this third case. Therefore, LB

′

may become a signiﬁcantly bad underestimation of

LB that would have been computed if sampling was

not used. The underestimation of the lower-bound

value will result to an increase in false-alarms, thus

incurring high trafﬁc.

To overcome this problem, we propose an alterna-

tive sampling method. We sample U and L separately.

Initially, we store the elements of U in ascending or-

der. In U

′

we select the ﬁrst M elements of this or-

dering. Respectively, we sort L in descending order

and we select the ﬁrst M elements in L

′

. The intu-

ition is that the selection of the smallest M values of

U, helps in increasing the number of occurrences of

the ﬁrst case (i.e., when C

′

> U

′

), since the smallest

the value of U

′

is, the more expected is to have a C

′

larger than it. An analogous reasoning holds for the

sampling of L

′

It is easy to see the following:

Lemma 1 The sampling of U and L does not produce

any false negatives.

Proof. While computing LB

′

, due to sampling, the

ﬁrst and second cases of Equation 4 occur less times

than while computing LB (i.e., without sampling).

Therefore, LB

′

≤ LB. Since LB ≤ D (where D

the actual distance computed with DTW), we have:

′

≤ D. Thus, no false negatives are produced. 

The separate sampling of U and L presents the re-

quirement of having to store the positions from which

ICEIS 2005 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

104

elements are being selected in U

′

and L

′

. If the

positions are stored explicitly, then this doubles the

amount of information kept (2M numbers for stor-

ing U

′

and L

′

and additional 2M numbers for stor-

ing the positions of selected elements). Since this

information is propagated during querying, trafﬁc is

increased. For this reason we propose an alternative

representation. To represent U

′

, we use a bitmap of

length N (the phrase length). Each bit corresponds to

an element in U. If an element is selected in the sam-

ple U

′

, then its bit is set to 1, otherwise it is set to 0.

Therefore, the combination of the bitmap and the M

values that are selected in U

′

are used to represent U

′

The same is applied for L

′

. This representation is efﬁ-

cient: the space required for U

′

is M + ⌈N/8⌉ bytes.

The plain representation requires 5M bytes (since it

requires only one integer, i.e., 4 bytes, to store the po-

sition of each selected element). Thus, the proposed

method is advantageous when N < 32M, i.e., for

sample larger than about 3% (our experiments show

that samples with size 10% are the best choice).

3.3 The similarity searching

algorithm

As previously explained, the similarity searching al-

gorithm is on the basis of breadth-ﬁrst-search over the

nodes of the P2P network. The algorithm that uses the

proposed sampling and representation methods, is de-

noted as BFSS (breadth-ﬁrst-search with sampling).

The pseudo-code for BFSS is given in Figure 2. Each

time, the current node n is considered. A TTL value

denotes how many valid hops are remaining for n,

whereas T

is the user-deﬁned similarity threshold. It

is assumed that sequences U

′

and L

′

carry also the

associated bitmaps.

Evidently, the movement of the actual query se-

quence from the node that commenced the query to

the currently visited node, increases the trafﬁc (not

being sampled, the query sequence has rather large

length). For this reason, it is important not to have a

large number of false-alarms.

The algorithm that does not use sampling (denoted

as BFS) may produce less false-alarms. However, be-

tween each pair of peers it has to propagate U and L

sequences, with length equal to the one of the query

sequence. Therefore, it is clear that there is a trade-off

between the number of additional false-alarms pro-

duced due to sampling and the gains in trafﬁc from

propagating sampled (i.e., smaller) envelopes. This

trade-off is examined through the experimental results

in the following section.

Each element in an acoustic sequence is in the range

0-255, thus it requires one byte.

Procedure BFSS(Node n, int TTL, Sequence U

′

Sequence L

′

, ﬂoat T

)

begin

1. foreach data sequence D in n

2. foreach phrase C of D

3. l = LB

′

(C, U

′

, L

′

)

4. if l < T

5. get query sequence

6. compute actual DTW distance, D,

between phrase C and query sequence

7. if D ≤ T

8. include C in answer set

9. if TTL > 0

10. foreach peer p of n that has not been visited yet

11. BFSS(p, TTL-1, U

′

, L

′

, T

)

end

Figure 2: The BFSS algorithm.

4 EXPERIMENTAL RESULTS

The performance of the considered similarity search-

ing algorithms was compared through simulation.

The P2P network had 100 nodes and the average num-

ber of neighbors for each node was a random vari-

able with average value equal to 7 (this kind of topol-

ogy is called logarithmic). We used 500 real acoustic

sequences, which correspond to various pop songs.

Each song was sampled at 11 KHz and the average

duration was about 5 minutes. To represent the fact

that music songs (especially popular ones) are shared

among several nodes, we replicated each sequence.

The number of replications for each sequence was

randomly variable with average value equal to 10.

The evaluation metric is the average trafﬁc (mea-

sured in MB) that each query incurs. The parameters

we examine are: the sample size, query size (length

of query sequence), query range (the user-deﬁned

threshold for similarity), and TTL value (max allowed

number of hops).

In our ﬁrst experiment, we focused on BFSS

and compared the proposed sampling method (this

method is denoted as BFSS) against uniform sam-

pling (this method is denoted as BFSS-UNI). The re-

sults are depicted in Figure 3. Figure 3a illustrates the

relative trafﬁc between BFSS and BFSS-UNI (i.e., the

trafﬁc of the latter is normalised w.r.t. the trafﬁc of the

former) against the query range. As shown, BFSS-

UNI incurs about twice the trafﬁc that BFSS does. As

already explained, this is due to the fact that uniform

sampling produces a bad underestimation of the lower

bound value. This can be further understood when

examining the discrepancy, denoted as error, between

the bounds produced by BFSS and BFSS-UNI, and

the actual bound produced by LB

Keogh. The relative

error between BFSS and BFSS-UNI (i.e., the latter is

normalised w.r.t. the former) is given in Figure 3b,

MUSICAL RETRIEVAL IN P2P NETWORKS UNDER THE WARPING DISTANCE

105

against the query size. The error of BFSS-UNI ranges

between 1.3 times the error of BFSS (for smaller

queries) and 2.8 times (for medium sized queries).

1.3

1.6

1.9

2.2

2.5

2.8

316 548 707 837 949

query range

rel. traffic

BFSS-UNI

BFSS

(a)

1.3

1.6

1.9

2.2

2.5

2.8

20 40 60 80 100 150 200 500

query size (x1000)

rel. error

BFSS-UNI

BFSS

(b)

Figure 3: BFSS vs. BFSS-UNI (a) Relative trafﬁc. (b) Rel-

ative error w.r.t. actual LB

Keogh value.

We now move on to compare BFSS against BFS

(i.e., the method that does not use any sampling at

all). For BFSS we examined several sample sizes.

The results are depicted in Figure 4, whereas BFS has

a constant value, as it does not use sampling. In Fig-

ure 4a, TTL was set to 4, query size was 100,000, and

query range was set to 0 (i.e., exact match). As shown,

for very small samples (with 1,000 elements), BFS

performs better. This is expected, since the use of a

very small sample affects BFSS by resulting to a large

number of false alarms (due to bad underestimation of

lower bound values), which increase trafﬁc. However,

by increasing the sample size, BFSS becomes better

and clearly outperforms BFS. It is interesting to no-

tice that the best performance is for sample size equal

to 10,000 (i.e., 10% of the original query size). Fi-

nally, for large sample sizes, both methods converge

to the same trafﬁc. Analogous results are obtained for

the case where TTL is set to 5. It also worths noticing

that the trafﬁc of BFS is signiﬁcantly more increased

than the trafﬁc of BFSS does, compared to the case

when TTL was 4.

Next, we compared BFSS against BFS for varying

query size and query range. Figure 5a illustrates the

TTL = 4

1 5 10 25 100

sample size (x1000)

traffic (MB)

BFSS

BFS

(a)

TTL = 5

1 5 10 25 100

sample size (x1000)

traffic (MB)

BFSS

BFS

(b)

Figure 4: BFSS vs. BFS (a) Trafﬁc (in MB) when TTL=4.

(b) Trafﬁc (in MB) when TTL=5.

results for the former case. The size of sample for

BFSS was set each time to 10% of query size, TTL

was set to 4 and query range was set to 0. As shown,

BFSS clearly outperforms BFS in all cases, except

for rather small queries. Again, for very very small

queries, the resulting sample is very small and many

false-alarms are produced. Finally, Figure 5b depicts

the results for the latter case (varying query range).

Query size was set to 100,000, sample size was 25%,

and TTL was set to 5. BFSS clearly compares favor-

ably with BFS.

5 CONCLUSIONS

We have presented a novel algorithm, which efﬁ-

ciently retrieves similar audio data. The proposed al-

gorithm takes advantage of the absence of overhead

in unstructured P2P networks and minimises the re-

quired trafﬁc for all operations with the use of an

intelligent sampling scheme. Additionally, the algo-

rithm has such a design that no false negative results

occur. Detailed comparative evaluation to an already

existing algorithm showed signiﬁcantly reduction in

the trafﬁc produced by a query.

ICEIS 2005 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

106

25 50 100 150 200

query size (x1000)

traffic (MB)

BFS

BFSS

(a)

141 200 245 283 316

query range

traffic (MB)

BFS

BFSS

(b)

Figure 5: BFSS vs. BFS w.r.t. (a) query size, (b) query

range.

Further work is oriented towards the examination

of the proposed scheme in more advanced searching

algorithms (e.g., ISM, >RES).

REFERENCES

Adams, N. H., Bartsch, M. A., Shifrin, J. B., and Wake-

ﬁeld, G. H. (2004). Time series alignment for music

information retrieval. In Proceedings 5th ISMIR.

Agrawal, R., Faloutsos, C., and Swami, A. (1993). Efﬁcient

similarity search in sequence databases. In Proceed-

ings 4th FODO, pages 69–84.

Agrawal, R., Lin, K. I., Sawhney, H. S., and Swim, K.

(1995). Fast similarity search in the presence of noise,

scaling, and translation in time-series databases. In

Proceedings 21st VLDB.

Chan, K. and Fu, A. W. (1999). Efﬁcient time series match-

ing by wavelets. In Proceedings 15th ICDE, pages

126–133.

Faloutsos, C., Ranganathan, M., and Manolopoulos, Y.

(1994). Fast subsequence matching in time-series

databases. In Proceedings ACM SIGMOD, pages 419–

429.

Jang, J. S. R., Lee, H. R., and Chen, J. C. (2001). Super

mbox: An efﬁcient/effective content-based music re-

trieval system. In Proceedings 9th ACM MM, pages

636–637.

Kalogeraki, V., Gunopulos, D., and Zeinalipour-Yazti, D.

(2002). A local search mechanism for peer-to-peer

networks. In Proceedings 11th CIKM, pages 300–307.

Keogh, E. (2002). Exact indexing of dynamic time warping.

In Proceedings 28th VLDB, pages 406–417.

Keogh, E. and Ratanamahatana, A. N. (2004). Exact index-

ing of dynamic time warping. Knowledge and Infor-

mation Systems.

Klapuri, A. (2004). Automatic music transcription as we

know it today. Journal of New Music Research.

Kontaki, M. and Papadopoulos, A. N. (2004). Similarity

search in streaming time sequences. In Proceedings

16th SSDBM.

Large, E. and Palmer, C. (2002). Perceiving temporal regu-

larity in music. Cognitive Science, 26(1):1–37.

Li, X. and Wu, J. (2004). Searching techniques in peer-to-

peer networks. In Handbook of Theoretical and Algo-

rithmic Aspects of Ad Hoc, Sensor, and Peer-to-Peer

Networks. CRC Press.

Mazzoni, D. and Danneberg, R. B. (2001). Melody match-

ing directly from audio. In Proceedings 2nd ISMIR,

pages 17–18.

Tzanetakis, G., Gao, J., and Steenkiste, P. (2004). A scal-

able peer-to-peer system for music information re-

trieval. Computer Music Journal, 28(2):24–33.

Wang, C., Li, J., and Shi, S. (2002). A kind of content-based

music information retrieval method in a peer-to-peer

environment. In Proceedings 2nd ISMIR, pages 178–

186.

Yang, B. and Garcia-Molina, H. (2002). Improving search

in peer-to-peer networks. In Proceedings 10th ACM

MM, pages 5–15.

Yang, C. (2002). Efﬁcient acoustic index for music retrieval

with various degrees of similarity. In Proceedings

10th ACM MM, pages 584–591.

Yang, C.(2003). Peer-to-peer architecture for content-based

music retrieval on acoustic data. In Proceedings 12th

WWW, pages 376–383.

Yi, B. K. and Faloutsos, C. (2000). Fast time sequence in-

dexing for arbitrary lp norms. In Proceedings 26th

VLDB.

Yi, B. K., Jagadish, H. V., and Faloutsos, C. (2000). Ef-

ﬁcient retrieval of similar time sequences under time

wrapping. In Proceedings 16th ICDE, pages 201–208.

Zhu, Y. and Shasha, D. (2003). Warping indexes with enve-

lope transforms for query by humming. In Proceed-

ings ACM SIGMOD, pages 181–192.

MUSICAL RETRIEVAL IN P2P NETWORKS UNDER THE WARPING DISTANCE

107
