Detection of the Operating System Configuration

Vulnerabilities with Safety Evaluation Facility

Peter D. Zegzhda, Dmitry P. Zegzhda, Maxim O. Kalinin

Information Security Centre of Saint-Petersburg Polytechnical University,

P.O. Box 290, K-273, Saint-Petersburg, 195251, Russia

Abstract. In this paper, we address to formal verification methodologies and

the system analyzing facility to verify property of the operating systems safety.

Using our technique it becomes possible to discover security drawbacks in any

IT-system based on access control model of 'state machine' style. Through our

case study of model checking in Sample Vulnerability Checking (SVC), we

show how the evaluation tool can be applied in Microsoft Windows 2000 to

specify and verify safety problem of system security.

1 Introduction

Assurance that system's behavior will not result in an unauthorized access is

fundamental to ensuring that the enforcing of the security policy will guarantee

system security. The greater the assurance, the greater the confidence that the security

system will protect its assets against the threat with an acceptable risk. A fall down

occurs in suitably secure commercial operating systems, applications, and network

components, especially with respect to security. Commercial offerings have serious

security vulnerabilities. The sources of security faults are concealed at abundant

errors of the system designing, coding, and administrating processes. The widely

known lacks of security are those of programming origin, and they are resolved with

regular patches and service packs. At the same time, sophisticated analysis of the

well-known operating systems made by the world-renowned organizations, e.g. CERT

or Secunia, testify to the 20 percents of vulnerabilities caused by incorrect security

configuring and adjustment arranged by users or administrators. We consider the

errors made at the time of security administrating as reasons of variety of operating

system configuration vulnerabilities (OSCV).

The OSCVs take after:

• ignoring the security bulletins, published by vendors or security experts;

• setting the different security adjustments that unobviously may conflict with each

other or alternate other settings;

• setting the security settings that may be contradicting to the applied security policy.

The most typical examples of the OSCVs are using of trivial passwords, default

security settings, or accidental system folder permissions. For instance, in Microsoft

Windows 2000, if there is a shared folder created by administrator, the system grants

D. Zegzhda P., P. Zegzhda D. and O. Kalinin M. (2005).

Detection of the Operating System Conﬁguration Vulnerabilities with Safety Evaluation Facility.

In Proceedings of the 3rd International Workshop on Security in Information Systems, pages 263-276

DOI: 10.5220/0002564902630276

 SciTePress

'Full Access' to new object for 'Everyone'. If administrator is a novice in security, she

could miss such fault and others could access to somebody's private files. Another

example is that Dr.Watson, the built-in debugger in Microsoft Windows, starts every

time after system fault. This program creates a dump file, e.g. C:\Winnt\user.dmp.

Now imagine that OE falls down, and Dr.Watson runs. The dump corresponding to

OE includes all mail accounts and passwords as plain text. Besides this, the NT file

system (NTFS) creates a new file with default properties (the default access

permissions among them) taken from the parent folder, e.g. C:\Winnt. The 'Everyone'

group thus has a 'Full Control' over the dump file. And consequently, all private email

passwords saved in the file becomes open for every user. The Linux-style operating

systems obtain the OSCVs of the same sort: for instance, they have a SUID-related

problem. Such kind of mistakes in protection environment reduces every solid and

well-engineered security to 'zero'.

To eliminate the OSCVs, administrator has to know the operating system on-the-

fly, observe its structure permanently, and analyze the security bulletins and updates

operatively. Therefore, administrator needs to be in good knowledge of system inside.

She should control countless numbers of the system securable objects. For instance,

there are 36 types of the Microsoft Windows 2000 entities that are used with access

differentiation. Among them there are 9 entities of the user level (e.g. group accounts,

NTFS objects, system registry), and 27 kernel-level objects (e.g. jobs, processes,

threads, objects of synchronization). Each object refers to the access control list

(ACL), every entity (ACE) of which is a 32-bit mask. Users and groups obtain up to

37 privileges. What is more, 38 local security settings specify the system-native

security policy. Thus, even in the isolated station, a number of security combinations

exceeds tens of millions, and it is a hard work to control them all manually.

Consequently, to solve the task of security faultlessness we need a special facility for

system security analysis.

This paper discusses a technique of the security system analysis and a formal veri-

fication tool, the Safety Evaluation Workshop (SEW). It allows to specify the

system's security-related elements and verify the system's safety against the OSCVs.

This paper is structured as follows. Section 2 addresses the classification of

security models and illustrates the safety problem background. Section 3 analyzes the

related works in the field of safety modeling and evaluation. Section 4 introduces our

safety problem resolving approach. Section 5 gives a review of the SEW's structure to

analyze the safety of the operating system. In section 6, we explain the example of

logical specification and security flaws detection for Sample Vulnerability Checking

in Microsoft Windows 2000 using the SEW tool. Finally, section 7 discusses

conclusion and future directions.

2 A Safety Problem

In general, security represents the combination of confidentiality, integrity or

availability. The term of security model [1] could be interpreted as formal represen-

tation of secure system's confidentiality, integrity or availability requirements. In

264

more general usage of the term, a security model specifics a particular mechanism for

enforcing confidentiality, called access control, which brought over into computer

security from the world of documents and safes. Security concerns arise in many

different contexts; many security models have been thus developed. Access control

models can be grouped into two main classes according to security policies [2]:

• Mandatory Access Control (MAC): based on mandated regulations determined by a

central authority;

• Discretionary Access Control (DAC): based on the identity of the requestor and on

access rules stating what requestors are allowed to do.

Getting assurance that a system behavior will not result in an unauthorized access

is called a safety problem [1]. For the listed model types, the security problem can be

specified in the following manner:

• MAC: governs access on the base of classification lattice of subjects and objects in

the system. There is no safety problem for MAC, because safety of MAC has been

proved theoretically in general case [3]. Verification of the safety of any kind of

MAC policy is obvious as mathematical proof, but it becomes necessary in

particular cases of real world realizations;

• DAC: has a drawback that it does not provide real assurance on the flow of

information in a system. Harrison, Ruzzo, and Ullman showed that the safety

problem was undecidable in general case [4], and research was focused on

determining whether safety could be decided for access control models with

limited expressive power (e.g. [5][6]). They mathematically demonstrated that an

access control model could be designed for which safety is efficiently decidable in

polynomial time but given a few restrictions.

Unfortunately, MAC-policies are not particularly well suited to the leading world-

known solutions and industry organizations that process sensitive information and. On

the contrary, a great majority of the systems (e.g. operating systems, DBMS,

firewalls) uses the DAC-based security models as the basis of access control

mechanism. For instance, Microsoft Windows, Linux, Trusted Mach, and other

protected systems use DAC realizations in form of ACLs, access bits, messages

control, etc. Thus, the safety verification is the actual problem for security evaluation,

especially for the wide-spread computer systems. In theory, safety can not be resolved

for the DAC in general case, e.g. HRU model, on the whole. But the determining

whether the system implementing access control model is safe or not can be resolved

for the restricted case, i.e. for the definite system and for its definite states. In this

paper, we use this statement to solve the safety problem of DAC-related access

control by proposing universal specification and model checking tools. These tools

allow the Evaluator to describe the system security elements, calculate the safety

estimation for any security computer system based on the 'state machine' model, and

detect the vulnerabilities of operating system security configurations.

3 The Related Works

Most of the other works on security resolving relates to safety evaluation and

vulnerabilities detection. The ASL [7] is an example technique based on the formal

265

logic language for security specification. Although it provides support for role-based

access control, the language does not scale well to real systems because there is no

way of modeling real access control rules. There is no specification of delegation and

no way of modeling the rules for groups of identities.

LaSCO [8] is a graphical approach for evaluating the security constraints on

objects, in which the policy consists of two parts: domain (the system abstraction) and

the requirements (authorization rules). The scope of this approach is good for

demonstration, but far from implementation in life systems.

Ponder [9] language is a specification language with object-oriented basis. It is the

closest to the safety evaluation purposes. It has JAVA implementation, but it is not

prepared for automated evaluation. For example, we need manually compose the

system's structure, if we want to specify the hierarchical system. The Ponder-based

system does not support the state modification and state transition.

We have observed characteristics of the Windows-oriented vulnerabilities detectors

(Enterprise Security Manager, Symantec Corp.; Intrusion SecurityAnalyst, Intrusion

Inc.; NetIQ Security Analyzer, NetIQ Inc.; XSpider, Positive Technologies; Microsoft

Baseline Security Analyzer, Microsoft Corp., etc). After analyzes, we have made

some conclusions:

• no solution investigates the system inside. For example, the known products have

an eye on the well-known file paths or the security-critical folders. No one looks at

security of the kernel mode objects;

• no product allows composing the detection criteria. For example, the analyzed

solutions use either the predefined checks or the scripts of the check sequence;

• no detector predicts an effect of the security settings upon the reachable states of

the system.

However, to our knowledge, the general problem of the evaluation of the operating

system security enforcement including weakness detection has never been addressed

by any author.

4 Safety Evaluation Resolving

According to principals of the computer system modeling, we use the term of security

model as the combination of system security states and transitions through access

control rules. To check the safety of the system, we add to this schema of security

model the term of constraints like a set of access restrictions given by user. If the

constrains are set properly, there will be no OSCVs in the system. Criteria for the

OSCVs checking we will call OSCV-criteria.

The term of safety states that "something bad never happens". If a security system

has safety problem in security, it means that the OSCV exists and secret information

is leaked by unauthorized access. Assurance that a system behavior will not result in

the unauthorized access is fundamental for ensuring that the enforcing of the access

control model will guarantee the system security. An important feature of an access

control model is the ability to verify the safety of its configurations. Using the

266

approach of the system states, the definite system is safe according to the DAC

model, if the following conditions met:

1. The security state corresponding to the given initial system state conforms to the

OSCV-criteria.

2. The system access control mechanism realizes the access control rules.

3. Every security state reachable from the initial one keeps the OSCV-criteria fair.

The process of producing of the sets of the reachable states and the evaluating of

the criteria is called a safety problem resolving. Formally, procedure of the states

verification can be presented in the following manner.

A system Σ is a state machine: Σ = {S

, T,

init

, Q}, where:

• S

denotes the set of the system states;

• Q denotes the set of the queries executed by the system;

• T denotes state transition function, T: Q×S

→ S

that moves the system from one

state to another. A request q issued in the state s

moves the system to the next

state

*Σ

=T(q, s

);

•

init

is the initial system state.

A system Σ is a finite machine: a state s

is reachable iff there is a sequence <(q

init

), ..., (q

)> such that

= s

, and

=T(q

−

), 0<i<n. Note that

init

trivially reachable.

A general security model M is an ensemble of sets, M={S, R, C}, where:

• S denotes the set of the security states defined by the security model;

• R is the set of the access control rules in the form of logical predicates r(s, s')

defined on S×S and checking that the transition from s to s' meets to the security

model;

• C is the set of the OSCV-criteria in the form of logical predicates c(s) defined on S

and checking security of the state s. A state s∈S is secure iff for every criterion c

the predicate c(s) succeeds: ∀c∈C: c(s)=true.

A system safety property Λ can be formulized as Λ={M,

, D}, where D is the

mapping function, D: S

→S, which sets the relation between the system states and the

security states.

By the definitions being specified, the System Safety Statement can be formulated.

The system Σ implementing the model M is safe iff:

1. ∀c∈C: c(D(

init

))=true,

2. ∀

∈S

=T(i,

) ∃s

=D(

), s

i+1

=D(

) and ∀r∈R: r(s

, s

i+1

)=true,

3. ∀

∈S

is reachable from

init

, ∀c∈C: c(D(

))=true.

This statement declares an analogous of the General Security Theorem [1, 3], but

in reference to the safety problem in real computer systems. The System Safety

Statement allows the system's security to be evaluated in practical realization of the

DAC systems (e.g. Microsoft Windows series, Linux, BSD systems, all UNIX-related

versions) and all other systems, security of which needs to be checked. Our approach

267

also makes possible to discover the nature of the OSCVs, because it uses the states

and the states transitions for the security evaluation. To make the checking of the

System Safety Statement a routine procedure we have constructed a security

configuration evaluation facility — Safety Evaluation Workshop (SEW).

5 The Safety Evaluation Workshop

For safety evaluation of systems security, we have proposed the SEW's structure [10]

which consists of 7 components. The following figure shows the evaluation

framework in the SEW.

Fig. 1. The Safety Evaluation Workshop

The functions of the SEW's parts are as follows:

• Safety Problem Specification Language (SPSL): allows to specify the system state,

the access control rules, and the OSCV-criteria, and thus to obtain the formal

model of the evaluated system for further resolving;

• Scopes:

− Model-related System Security State Scope (M3S-scope): specifies the system

security state in SPSL. For example, the scope for Microsoft Windows 2000

contains the predicates describing all of the securable objects and their

attributes, e.g. users, files, processes, kernel objects, ACLs, owners,

memberships, etc;

268

− Access Control Rules Scope (ACR-scope): specifies the access control rules in

SPSL. For example, in Microsoft Windows 2000, this scope contains the rules

that regulate the access control to the securable objects and that are realized in

the system reference monitor (SRM). Rules have a form of Prolog clauses and

allow the state transactions resolving and computing of the authorized accesses

for any user;

− State Security Criteria Scope (SSC-scope): expresses the OSCV-criteria in

SPSL. For example, in Microsoft Windows 2000, this scope allows users to set

checking of the Microsoft security bulletins or the firm security policy;

• State Analyzer: investigates the system being evaluated and builds the M3S-scope

of the system automatically according to the access control model;

• Criteria Manager: allows the Evaluator to input the OSCV-criteria in convenient

graphical mode and construct the SSC-scope;

• Safety Problem Resolver: processes the scopes and detects the security

vulnerabilities;

• Security Flaw Explorer: demonstrates the sequence of events that lead to the

security fault, and finds the security settings that are the reasons of the OSCVs;

• Evaluation Reporter: produces the final report containing an initial state (in the

terms of security settings), access control rules that lead to the security faults,

OSCV-criteria that were resolved and found to be true, and an overall safety

evaluation result.

The core components of the SEW are the SPSL and the SPR. To specify the system

security-related elements we have developed the language — SPSL. SPSL is a logical

specification language to express the security states, access control rules, and OSCV-

criteria. The expressive power of SPSL allows specification of protection mechanisms

of common-used operating systems such as Microsoft Windows 2000, Linux, etc.

We also have composed the SPR tool which helps the Evaluator to process the

SPSL-based specifications and to verify whether system security policy involves a

safety problem. The SPR interprets the SPSL-based specifications and checks the

system to meet the System Safety Statement: it evaluates the initial security settings by

the given OSCV-criteria; then it generates all reachable states and checks them by the

criteria. SPR tool is a logical machine based on the Prolog kernel and supplies with

API implemented in C++ programming language.

Other components of the SEW are built around the core modules and make the

user's work more handy.

6 Security Evaluation Example

6.1 Sample Vulnerability Detection

For easy understanding of security specification and SEW's functionality technique,

we show a Sample Vulnerability Checking (SVC) applied in Microsoft Windows

2000.

269

Like in office workstation, our sample computer has MS Office installed. All of the

MS Word templates of the user documents are located in the given folder, e.g.

C:\Documents and Settings\Administrator\Application Data\Microsoft\Templates.

Now let's imagine the situation when user named 'Administrator' shares her template

with other users. To do it, she grants the access to read and write the template for the

Microsoft Windows built-in group named 'Users'. If the violator, the member of the

'Users' group changes the Normal.dot template file in the given folder so it contains

the malicious code (e.g. macro viruses), all new documents of Administrator will be

infected. This is the sample of the OSCV, in which user ignores or forgets the

recommendations to protect the MS Word templates.

6.2 The State Scope

Like in well-known security models, our security states are the collections of all

entities of the system (subjects, objects) and their security attributes (e.g. ACLs). In

our example, we assume that a target of OSCV-criteria is a C:\Documents and

Settings\Administrator\Application Data\Microsoft\Templates folder. The system

security states may be presented as the M3S-scope.

According to M3S-scopc mentioned above, we used the State Analyzer component

of SEW to specify SVC's security state. The following code example shows the M3S-

scope of SVC generated with the State Analyzer.

..........[abbreviation]........

subj('s-1-5-21-73586283-484763869-854245398-500',

[type(user),name('administrator'),

privileges([security,...,remoteinteractivelogon]),

groups(['s-1-5-32-544'])]).

..........[abbreviation]........

subj('s-1-5-32-545',

[type(group),name(['users']),

privileges([shutdown,...,networklogon])]).

..........[abbreviation]........

obj('c:\\documents and settings\\user\\application

data\\microsoft\\templates\\normal.dot',

[type(file),

owner(['s-1-5-21-73586283-484763869-854245398-

500']),inheritance(yes)],

[['s-1-5-21-73586283-484763869-854245398-

500',tnn,[0,1,2,3,4,5,6,7,8,16,17,18,19,20]],

['s-1-5-18',tnn,[0,1,2,3,4,5,6,7,8,16,17,18,19,20]],

270

['s-1-5-32-544',

tnn,[0,1,2,3,4,5,6,7,8,16,17,18,19,20]],

['s-1-5-32-545',tnn,[0,1]]]).

..........[abbreviation]........

This state specifies three entities: two subjects (one user, one group) and one object

(the template file). Every entity is specified in SPSL format. Each predicate declares

the security attributes of the corresponding unit. For example, user 'Administrator' has

SID equal to S-1-5-21-73586283-484763869-854245398-500, some system

privileges, and owns membership in the 'Administrators' group. The second predicate

specifies the group named 'Users', which is characterized with some system privileges

only. The third expression declares the object, the template file C:\Documents and

Settings\Administrator\Application Data\Microsoft\Templates, which is the goal of

vulnerability evaluation. The attributes of this file are: the owner SID, inheritance

flag, and the object's ACL. As in the operating system, ACL is a set of access control

entities, presented in the form of " SID – 'rights delegation' – 'access bits' ".

In the same manner, using the State Analyzer, we can gather all of the system

objects of the user mode as well as of the kernel mode. For example, the following

predicate specifies the COM-object and its security configuration:

obj('tlntsvr.exe',

[type(com), owner(['s-1-5-32-544']),

appID(['{b8c54a54-355e-11d3-83eb-00a0c92a2f2d}'])],

[['s-1-5-32-544',tnn,[0]],['s-1-5-4',tnn,[0]],

['s-1-5-18',tnn,[0]],

['s-1-5-18',tnn,[1]]]).

6.3 The Access Control Rules

Access control rules express the restrictions on a system behavior. The system states

transformation is able after the access authorized by the system reference monitor

(access control mechanism). It checks the authorization possibility against the security

policy requirements represented by access control rules. In SVC example, a subject

can have actions of reading or writing according to the SRM policy of Microsoft

Windows. To embody this mechanism we have investigated the Microsoft Windows

inside (e.g. using the black-box testing strategy) and looked through innumerous

Microsoft Press. It made us able to re-compose the protection subsystem in the form

of clauses.

Such specification can be called as the ACR-scope. The following code example

shows the ACR-scope of SVC. For want of paper space, we do not describe all of the

Microsoft Windows ACR-scope in SPSL. We just prepared a sample of the read

access checking with some comments describing the SRM working:

271

..........[abbreviation]........

allow_file_read(U, F):-

% System security settings allow user U to traverse

% through containers of file F

allow_traverse(U, F),

% EPL is effective permissions list

% for user U and file F

effective_permissions(U, F, EPL),

% Get PL, the list of privileges granted to user U

privileges_list(U, PL),

% Privilege "Backup files and directories"

% is granted to user U

( member(backup, PL), !;

% Permission "Read data" is granted to user U

member(0, EPL),

% Permission "Read attributes" is granted to user U

( member(7, EPL),!;

% P is direct container of file F

container_of_file(P, F),

% Permission "List folder" is granted to

% user U for direct container of file F

group_permissions(U, P, 0) ),

% Privilege "Backup files" is granted to user U

( member(restore, PL), !;

% Permission "Synchronize" is granted to user U

member(20, EPL) ) ).

..........[abbreviation]........

The 'read' access to the file is granted, if user has a 'traverse' permission for the file,

or she has a 'Read Data' bit in her ACE referred to the file, or the user's group

membership gives her some abilities to access the file.

6.4 The Criteria

The security criteria allow the customer or evaluator to delimit the secure and

insecure states in security model. The criteria have the form of constraints which state

272

the necessary conditions of the secure state. The system is safe by the OSCV-criteria

if all logical goals corresponding to the criteria are true. If some criterion goal is true,

then system breaks the safety conditions specified in the criterion. In SEW facility,

security criteria can be noted as the SSC-scope. The special component of SEW, the

Criteria Manager, allows to compose and edit the vulnerability criteria. This code

example shows the SSC-scope written in SPSL.

..........[abbreviation]........

criterion('Criterion #1: Users are not allowed to edit

the file Normal.dot',

mask,

[obj('c:\\documents and settings\\administrator\\

application data\\microsoft\\templates\\normal.dot'),

inheritance('tnn'),

's-1-5-32-544'(0,1,2,3,4,5,7,8,6,16,17,18,19,20),

's-1-5-18'(0,1,2,3,4,5,7,8,6,16,17,18,19,20)]).

..........[abbreviation]........

The logical predicate denotes one of the criteria to be checked in Microsoft

Windows system. It specifies the criterion description: criterion refers to Normal.dot.

The type 'mask' points that there is a mask criterion, i.e. the checking of the concrete

access rights to the given Normal.dot object. There is also a condition of safe system:

only SYSTEM (its SID equals to S-1-5-18) and 'Administrators' group (S-1-5-32-544)

are allowed to do 'Full Access' to Normal.dot. All other cases are considered to be

vulnerable.

In the mentioned style, we can compose a full range of OSCV-criteria. It becomes

able to handle even context-related conditions, such as "The system is vulnerable, if

Administrator can modify object X, provided she is connected to the local console".

Such conditions are indeed part of Microsoft Windows security model. From the point

of security, all kinds of user's activity in the system (such as connection to the local

console, applications running, etc) are mapped to Win32API functions calls operated

with the Windows recourses. List of functions calls and set of resources maintained

by the Windows security (so named as securable objects) are defined in MSDN.

Because of monitoring a variety of operations over the securable objects, we can

analyze the user's activity in the system.

6.5 Safety Evaluation Results Processing

We have SPR input with a triple (M3S-scopc, ACR-scope, and SSC-scope) written in

SPSL. Then we have run the resolving program for SVC. After the running

273

procedure, we have got a result file — the security evaluation Report. The following

text example shows the report file for SVC.

*** SYSTEM SAFETY RESOLUTION ***

CRITERION #1:

Users are not allowed to edit the file Normal.dot

>> VIOLATION DETECTED:

subject group <Users>

has unauthorized permissions

bits [0, 1]

[Read Data, Write Data]

for object(s) file c:\documents and settings\

administrator\

application data\

microsoft\templates\

normal.dot

..........[abbreviation]........

The result for checking criterion 1 is failed. It means that there is some

vulnerability in the security configuration. After analyzing unsafe state, the SEW

discloses nature of security flaw, detecting the subject, object, and their attributes that

lead to weakness. The evaluation verdict is "system is unsafe by this criterion",

because members of group 'Users' have the 'Read Data' and 'Write Data' bits in the

ACL, corresponding to the file Normal.dot.

7 Conclusion

In this paper, we have addressed to formal specification and vulnerability verification

approach for secure operating systems. We discussed a technique of the security

system analysis and a formal evaluation tool, the SEW. All these allow to specify the

system security-related elements and verify the system safety.

We illustrated the SEW-based checking which enables to verify safety property for

secure systems, based on the security scopes. The SEW tool is to be useful for

customers and evaluators of secure systems. These kinds of tools are rare in the

security field, and no one of the known tools allows the criteria composing, the

system inside inspecting, and the configurations influence predicting. The SEW

facility brings the safety problem resolving to practice. The targets of its applications

274

are the computer systems based on state machine presentation: the operating systems,

DBMSs, and firewalls.

At last decades, a number of individual countries developed their own security

evaluation standards (e.g. [11]). In addition to, opening the way to world-wide mutual

recognition of security evaluation results, the new Common Criteria (CC) [12] have

been developed. For example, CC define 7 levels (EAL1…7) of assurance for

security systems. To get a higher assurance, over EAL5, developers require to specify

security model and verify its safety property using formal methods approach. Vendors

are discouraged from offering secure systems because significant time and efforts are

needed to develop a system capable for meeting the evaluation criteria and to marshal

it through the evaluation process. Moreover, because of evaluation delays, an

evaluated product is typically no longer the current version of the system, which

necessitates repeated reevaluation. For high assurance systems, the difficulties of

using formal methods add further complexity to both development and evaluation.

However, given the lack of suitable mature, "industrial-strength tools" and the cost of

a formal verification activity, informal approach represents a suitable compromise.

The SEW is very useful for administrators and security officers to monitor the

system securable resources (files, printers, accounts, processes, etc). The SEW allows

any user to discover security of her system in-the-depth, and thus open the 'holes' in

the protection. The OSCVs, as mentioned, represent a very serious problem in the

modern operating systems. Contemporary systems operate with a huge number of

security settings, and the user needs some tools that could explain the whys and

wherefores of security weaknesses. The SEW utility makes this process closer to

person than ever, because while logical resolving it marks the clause that caused fault

of OSCV-criterion, and supplies user with a true reason of the security flaw.

The current versions of the mentioned facility are aimed at such well-known

systems as Microsoft Windows 2000/XP and Linux-style systems. For the future

works, we will develop and elaborate the SEW components such as the State

Analyzer, Criteria Manager, and Security State Explorer to support easy modeling and

analyses for safety problem in Microsoft Windows Server solutions (i.e. Active

Directory and Group Policy support). Besides, we are targeted at the remote security

analysis. To achieve this we develop the Remote Agent module of the SEW which

starts the State Analyzer remotely and transmits the scope through the networks.

References

1. J. McLean. Security Model, In Encyclopedia of Software Engineering, Wiley Press, 1994.

2. J. Goguen and J. Meseguer. Security Policies and security models, In Proceedings of the

1982 IEEE Symp. on Research in Security and Privacy, IEEE Computer Security Press.

3. L.J. LaPadula and D.E. Bell. Secure computer systems: A mathematical model, ESD-TR-

278, VOL.2, The Mitre Corp., Bedford, MA, 1973.

4. M.H. Harrison, W.L. R.uzzo, and J.D. Ullman. Protection in operating systems,

Communications of the ACM, 19(8):461-471, 1976.

5. M. Bishop and L. Snyder. The transfer of information and authority in a protection system,

In Proceedings of the 7th ACM Symp. on Operating System Principles, pp. 45-54, 1979.

275

6. S. Castano, M.G. Fugini, G. Martella, P. Samarati. Database Security, Addison-Wesley,

1995.

7. S. Jajodia, P. Samarati, and V.S. Subrahmanian. A Logical Language for Expressing

Authorizations. Proc. of the IEEE Symposium on Security and Privacy, Oakland, CA,

1997.

8. 2. J.A. Hoagland, R. Panday, and K.N. Levitt. Security Policy Specification Using a

Graphical Approach. Tech. report CSE-98-3, UC Davis Computer Science Dept., 1998.

9. 3. N. Damianou, N. Dulay, E. Lupu, M. Sloman. The Ponder Policy Specification

Language. Proc. Policy 2001: Workshop on Policies for Distributed Systems and Networks,

Bristol, UK, 2001.

10. P.D. Zegzhda, D.P. Zegzhda, M.O. Kalinin. Logical Resolving for Security Evaluation,

MMM-ACNS, pp. 147-156, 2003.

11. Trusted Computer System Evaluation Criteria, DOD 5200.28-STD, Dec 1985.

12. Common Criteria for Information Technology Security Evaluation, Part, 1: Introduction

and General Model, Version 2.1. CCIMB-99, Aug 1999.

276
