Tree Distance in Answer Retrieval and Parser

Evaluation

Martin Emms

Department of Computer Science, Trinity College, Dublin, Ireland

Abstract. The use of syntactic tree-distance as a surrogate for semantic distance

in an answer retrieval task is investigated. The feasibility of this is conﬁrmed by

showing that retrieval performance increases with parse quality, and an applica-

tion of this to parser evaluation is discussed. Variant deﬁnitions of tree-distance

involving parameters such as whole vs sub-tree, node weighting, wild-card trees

and lexical emphasis are compared with each other and with sub-string distance.

1 Introduction

The concern of this paper is the use of tree-distance in an answer retrieval (AR) task.

Given a question (such as Q below) and a collection of sentences (eg. a manual), the

task is to retrieve the sentences that best answer the question, (such as A below):

Q: what does malloc return ?

A: the malloc function returns a null pointer

The paper presents results on this AR task in which questions and answers are com-

pared on their syntactic structures, using tree-distance to quantify the amount of editing

needed to derive the question structure from the answer structure. The less editing an

answer needs, the higher it is rated as an answer to the question.

Two results are presented. The work uses tree-distance as a stand-in for semantic

distance. As evidence that this can be done, the ﬁrst result is that improving the syntax

structures does improve performance on the AR task. This also indicates that using

tree-distance in AR has a potential for parser evaluation. The second result compares

some variants of tree-distance with each other, and also with standard string-distance.

We show that a particular variant of tree-distance out-performs string-distance.

2 Tree Distance

The tree distance between two trees can be deﬁned by considering all the possible 1-

to-1 partial maps, σ, between source and targets trees S and T , which preserve left

to right order and ancestry

. Nodes of S which are not in the domain (resp. range)

if S

and S

are mapped to T

and T

, then (i) S

precedes S

iff T

precedes T

and

(ii) S

is descended from S

iff T

is descended from T

Emms M. (2005).

Tree Distance in Answer Retrieval and Parser Evaluation.

In Proceedings of the 2nd International Workshop on Natural Language Understanding and Cognitive Science, pages 155-160

DOI: 10.5220/0002565101550160

 SciTePress

of σ are considered deleted (resp. inserted) with an associated cost. Otherwise, where

= σ(S

) 6= S

, there is a substitution cost. The least cost mapping between the trees

deﬁnes the tree distance. In the example below, a distance of 3 assuming unit costs is

obtained. Deleted (resp. inserted) nodes are shown with a double outline in the lefthand

(resp. righthand) tree, substituted nodes are linked with an arrow, and unaltered nodes

are displayed at the same height.

b b a

whole tree matching dist=3.0

In the work reported in this paper the deﬁnition of tree distance is varied along a

number of dimensions.

Sub-tree: in this variant, the sub-tree distance is the cost of the least cost mapping

from a sub-tree of the source.

Structural weights: in this version, nodes have a weight between 0 and 1, and

weights are assigned according to the syntactic structure. The procedure for assigning

structural depends on classifying the daughters as head vs. complement vs. adjunct vs.

other, with essentially adjuncts given 1/5th the weights of heads and complements, and

other daughters 1/2.

Wild cards: If a node is labeled as a wild card, it (and the sub tree it dominates) can

have zero cost matching with sub-trees in the source. In the tree structures assigned to

wh-questions, such wild card trees can be put in the position of the gap.

Lexical emphasis: the leaf-nodes of the tree are words. In a lexically emphasized

version of tree distance, the leaf nodes have weights which are scaled up relative to

tree-internal nodes.

An alignment between two trees is shown in Figure 1, using the weighted, wild-card

variant. The nodes associated with the auxiliary verb get a low weight and are cheaply

deleted. The subject position of the target is taken by a np wild tree, and matches for

0 cost with the subject np in the source tree.

The basis of the algorithm used is the ZhangShasha algorithm [1] to compute the

cost of the least cost mapping. The implementation is an adaptation of [2], allowing for

wild-cards, sub-tree matching and human-readable display of the chosen alignments

(such as seen in ﬁgure 1).

3 The Answer Retrieval Task

Queries were formulated whose answers are single sentences in the manual of the GNU

C Library

. For example

www.gnu.org

155

process

np np_wild

rhs

be rhs

call be

memory

allocation

something

pro

rhs

memory

allocation

sub tree matching dist=1.6

Fig.1. An alignment using weights and wild cards

Q what is a page fault

A When a program attempts to access a page which is not at that moment backed by

real memory , this is known as a page fault

Q what does the free function do

A - Function : void free ( void * ptr ) The free function deallocates the block of

memory pointed at by ptr

In the retrieval task, each sentence in the manual is assigned a distance rating, mea-

suring the distance from it, to the question. For a given query, q, its correct cutoff –

cc(q) – is the proportion of the answers whose distance is less than or equal to the dis-

tance for the correct answer

. The lower this number is for a given query, the better the

system performs on that query.

There are 88 queries. The text from which the answers come was turned into a

part-of-speech tagged version which contains 360326 tokens, split into 31625 units.

4 Parse Quality vs Retrieval Performance

The above-deﬁned approach to AR could be described as using syntactic distance to

serve as a stand-in for semantic distance. Can this work ? Grouping items which are se-

mantically related is one of the aims of syntactic structure, but there are rival aims, the

fulﬁlling of which may pull syntactic structures away from semantics. On a pessimistic

equivalently this is the rank of the correct answer divided by the total number of answers

156

view, these non-semantic aims have the upper hand to such an extent that semantic

structure is mostly very difﬁcult to discern from syntactic structure; syntactic structure

is then more of an encryption of semantics than a useful gateway into it. This section

addresses this question, and provides some evidence that one need not be overly pes-

simistic.

What we look at is the relationship between parse-quality and AR performance.

First we establish the performance of a particular parsing system, making uses of par-

ticular linguistic knowledge bases (see full in the tables below). For this discussion the

details of this parsing system are not important, save to say that it is a chartparser whose

ﬁnal step is to select a sequence of edges spanning the input. Though the parsing system

is imperfect, it could be worse. Randomly removing 50% of the linguistic knowledge

base should make for worse structures (see thin50), as should manually stripping out

parts of it (see manual), while worst of all should be the entirely ﬂat parses which result

if the knowledge bases are empty. In each case, the AR performance was determined. To

try to get a picture of AR performance if the parse quality improved, we hand-corrected

the parses of the queries and their correct answers – see gold in the tables below.

The tables below give the results using the sub-tree distance and weighted sub-tree

distance. The numbers describe the distribution of the correct cutoff over the queries,

so lower numbers are better. Figure 2 shows the empirical cumulative density function

(ecdf) for the correct cutoff obtained with weighted sub-tree with wild cards measure:

so for each cut-off d, it plots the percentage of queries q with cc(q) ≤ d. Clearly as we

move through the different parse settings, the performance improves.

sub tree

Parsing 1st Qu. Median Mean 3rd Qu.

ﬂat 0.1559 0.2459 0.2612 0.3920

manual 0.0349 0.2738 0.2454 0.3940

thin50 0.01936 0.1821 0.2115 0.4193

full 0.0157 0.1195 0.1882 0.2973

gold 0.00478 0.04 0.1450 0.1944

weighted sub tree

Parsing 1st Qu. Median Mean 3rd Qu.

ﬂat 0.1559 0.2459 0.2612 0.3920

manual 0.0215 0.2103 0.2203 0.3926

thin50 0.01418 0.02627 0.157 0.2930

full 0.00389 0.04216 0.1308 0.2198

gold 0.00067 0.0278 0.1087 0.1669

The results indicate that the more successful the parser is in recovering correct syn-

tax structure, the more successfully tree-distance can be used in the AR task. By re-

versing this implication, this is also suggestive of a way in which the AR task could

be used as an evaluation metric for a parser. Such an application has some attractions,

the main one being that the raw materials for the AR task are questions and answers, as

plain text, not syntactic structures. This avoids the difﬁculties that arise when trying to

evaluate by comparing a parser’s native output with non-native gold-standard treebank

parses. Just so long as the parser can assign tree-structures to queries and answers, the

tree-distance measure can compare them, regardless of that parser’s native notational or

theoretical commitments.

5 Distance Measures Compared

In section 2 some parameters of variation in the deﬁnition of tree-distance were intro-

duced: sub-tree vs whole tree, weights, wild cards, and lexical emphasis. The perfor-

157

0.0 0.1 0.2 0.3 0.4 0.5

0.0 0.4 0.8

gold

full

thin50

manual

flat

Fig.2. Success vs Cut-off: x = correct cutoff, y = proportion of queries whose correct cutoff ≤ x

mance of these distance measures was compared, along with the performance of the

sub-string distance

. The table below summarises the distribution of the correct cut-off

over the queries for the different settings, whilst in Figure 3 the ecdf plots are given (we

= structural weights, wi = wild cards, lex = lexical emphasis, sub = sub-tree).

sub weights wild lex 1st Qu. Median Mean 3rd Qu.

+ + + + 0.00009 0.00152 0.04662 0.02929

sub string 0.00022 0.00361 0.05137 0.04375

+ + + - 0.00071 0.01919 0.1119 0.2058

+ + - - 0.00389 0.04216 0.1308 0.2198

+ - - - 0.01517 0.1195 0.1882 0.2973

- - - - 0.04071 0.1596 0.2846 0.5077

What the data show is that the version of tree distance which uses sub-trees, weights,

wild-cards and lexical emphasis, performs better than the sub-string distance, and that

each of the parameters make a contribution to improved performance.

Lexical emphasis makes a large contribution to the performance. Without it, what

can happen is that a structurally similar but lexically completely dissimilar false answer

can be rated about the same as a lexically more similar but structurally less similar

correct answer.

6 Conclusion and Future Work

By showing that improved parse quality leads to better AR driven by tree-distance,

we have shown that syntax structures can be used as a stand-in for semantic structures

– the syntax structures do not encode matters entirely unrelated to semantics. Also a

this is the least number of insertions, deletions and substitutions needed to turn a sub-string of

the answer word sequence into the query word sequence [3]

158

0.0 0.1 0.2 0.3 0.4 0.5 0.6

0.0 0.4 0.8

sub we wi lex

substring

sub we wi

sub we

sub whole

Fig.3. Success vs Cut-off: x = correct cutoff, y = proportion of queries whose correct cutoff ≤ x

particular variant of tree-distance was shown to perform better than string-distance. We

also suggested that performance on AR driven by tree-distance could be used as an

evaluator for parsers.

This paper does not argue that tree-distance be used as the sole ingredient in practi-

cal AR. In all probability, practical AR will use syntactic structure as an input to further

processing. For example [4] convert parser output to relational triples, and model the

question/answer relation as entailment. Perhaps the places where AR by tree-distance

works worst can function as hot-spots for deeper processing by such systems.

We have argued that AR using tree-distance allows for a portable assessment of

how successful, and how semantic a parser is. A direction for future work is to prove

portability by using further parsers, such as the statistical parser of [5]. A question de-

serving attention is whether the methodology can be adapted to parsers which generate

dependency structures rather than trees.

References

1. K.Zhang, D.Shasha: Simple fast algorithms for the editing distance between trees and related

problems. SIAM Journal of Computing 18 (1989) 1245–1262

2. Fontana, W., Hofacker, I.L., Stadler, P.F.: (Vienna rna package)

www.tbi.univie.ac.at/

ivo/RNA.

3. V.I.Levenshtein: Binary codes capable of correcting insertions and reversals. Sov. Phys. Dokl

10 (1966) 707–710

4. Molla, D., Hutchison, B.: Intrinsic vs extrinsic evaluations of parsing systems. In: Proceed-

ings European Association for Computational Linguistics (EACL), workshop on Evaluation

Initiatives in Natural Language Processing. (2003) 43–50

5. Collins, M.: Head-driven statistical models for natural language parsing. PhD thesis (1999)

159
