Validating the Security of Medusa:
A survivability protocol for security systems
Wiebe Wiechers, Semir Daskapan
Faculty Technology, Policy and Managment, Delft University of Technology, Delft,
Netherlands
Abstract. In this
paper a new approach for enabling survivable secure
communications in multi agent systems is validated through CSP/FDR state
analysis. The security validation of this approach centers around three security
properties: confidentiality, integrity and authentication. Requirements for these
security properties are defined for every message generated by this security
protocol during its life cycle. A logical analysis of these requirements is
followed by a thorough security validation, based on a model-checking
CSP/FDR analysis. Both analyses show that with minor modifications the
protocol is able to deliver on its security requirements for the three tested
security properties. Finally, the protocol is optimized with possible
improvements that increase its efficiency whilst maintaining the security
requirements.
1 Introduction
Traditionally, the trust management service in most networks is provided by a
centralized authority: the Security Distribution Center (SDC). This centralized
approach (Steiner, 1988) brings advantages such as efficiency and trustworthiness (an
agent only has to trust the centralized entity), which are lost in decentralized [2] and
distributed [4] [20] [21] solutions. The downside of having one or multiple centralized
SDC’s is that without it the network entities have no means of efficient secure
communication. Hence these SDC’s form multiple single points of failure and are at
risk from a variety of threats, ranging from “normal errors” to service blocking
attacks by nefarious entities. The traditional approach to dealing with a single point of
failure is adding redundancy through static replication of the security centres. This
approach brings high investments in the dedicated hardware and bad performance,
since most of the time the backup hardware is not used efficiently. The Medusa
protocol set was developed to capture the advantages of a centralized approach while
dealing with its deficiencies [7]. Medusa counters random failures in the SDC,
possibly caused by a service blocking attack, through volatile trust management.
According to the volatile trust management principle trust is seen as a moveable
software object that can be exchanged between several SDC’s [6]. In Medusa this
moveable software object, called the trust token, is moved to another location when
the SDC goes down, so that the service can be continued. To that end, Medusa creates
a pool of possible successors to the current SDC. In theory, this aspect of Medusa
Wiechers W. and Daskapan S. (2005).
Validating the Security of Medusa: A survivability protocol for security systems.
In Proceedings of the 3rd International Workshop on Security in Information Systems, pages 319-330
DOI: 10.5220/0002565503190330
Copyright
c
 SciTePress

increases the survivability of the SDC indefinitely, because Medusa uses resource
sharing between undedicated systems. Survivability denotes that a system can
continue providing essential services in the presence of attacks or failures, and can
recover full services in a timely matter [10].
Medusa’s ability to provide enhanced survivability was already proven in earlier
research [19] however for Medusa to be successful it must also be secure. In this
paper the security of the Medusa process is put to the test.
In the discussion of related works two types of works are distinguished. First, there
are works related to Medusa. Group Communication Systems (GCS) [1] [14] also
offer a trusted infrastructure and some [11] [13] [3], like Medusa, are specifically
designed to withstand failures and malicious agents, however these GCS’s feature an
unranked infrastructure. A Medusa-like hierarchical structure is proposed in [11], but
it does not achieve survivability through the use of undedicated systems and resource
sharing.
Second, there are works similar to this specific paper, a security validation using
the CSP/FDR approach. A similar approach is used in [9] for validating existing
protocols, but not for Medusa.
Medusa is designed to cover both internal security (systems security) and external
security (communications security). In this theory testing research the external
security of the Medusa process is analysed. The objective is to: assert the security of
the Medusa process by performing a thorough security validation on predefined
essential security properties and recommend alterations to Medusa to improve either
security or efficiency.
To validate the security of the Medusa process, two research methodologies are
used. First a general logic based analysis is performed followed by a more thorough
model-checking approach by state enumeration (in this process every possible state of
the protocol is analysed). The main reason for choosing this combination is its merit
in the field of security validation [16].
In section 2 an overview is given of Medusa’s security requirements, the
communication during its lifecycle, together with a logical analysis of the security
requirements. In section 3, the CSP/FDR state enumeration approach is introduced
and used to find any possible attacks an intruder could use to subvert Medusa’s
requirements. Also, this approach is used to see whether the security properties can be
asserted more efficiently. Finally, the results of these analyses are summarized and
discussed further in section 4.
2 MEDUSA: Security Requirements & Overview
First the three security requirements are defined. Following Medusa is introduced and
its communication evaluated. Each security requirement is analyzed to see whether it
is required and delivered (in a friendly environment).
320

2.1 Security Requirements
Although Medusa was designed as a single solution for security services, it consists of
multiple security protocols occurring either sequentially or concurrently. A security
protocol is defined as: a prescribed sequence of interactions between entities to
achieve a certain end [16]. To reduce complexity the number of agents participating
in a protocol is kept to a minimum. For instance during the primary elections phase all
CE’s communicate with all candidates. This can be modelled as a protocol between
one CE and one candidate, which is run between all CE’s and candidates. The
analysis of the latter situation is much less complex but does not reduce the quality of
the security validation.
The three security properties that are validated in this paper are: confidentiality,
authentication or integrity. They are defined here as follows. Confidentiality: no
plaintext data of a message passing between honest entities may be derived by
unauthorized entities. Integrity: any corruption of data contained in a message must
always be detected Authentication: if a message alleges to be from a certain entity, it
was indeed originated by that entity.
Of these security requirements integrity should be upheld for every message. If the
contents of a message can be tampered with a disruption of the Medusa process is
easily achieved. The other two properties, confidentiality and authentication, may or
may not be required depending on the message. For authentication two forms are
distinguished: one-way authentication, signifying that the initial sender must be
authenticated to the receiver, and two-way authentication meaning that the receiver
should also be authenticated to the sender.
2.2 Medusa Overview
The Medusa process consists of three phases: bootstrapping, preparation and
resurrection. The preparation and resurrection phases are part of Medusa’s operational
lifecycle. The preparation phase ensures the survival of the ad-hoc SDC, through
continuous replication and distribution of its trust token. When the SDC goes down
the resurrection phase begins and another SDC is established by reconstructing the
trust token. Medusa’s bootstrapping protocol is the self-organizing process that leads
to the creation of the SDC and its pool of successors. Through interactions between
agents (not dedicated to Medusa) a network of unrelated and untrusted agents is
converted into a trusted hierarchical structure.
In the following sections an overview is presented of the different phases of
Medusa. The various security protocols taking place are shown with their sequence of
messages. For coherency with the Medusa pseudo code the methods in which the
messages are sent are shown as well. For every method the necessary security
requirements are defined. By looking at the various security tools used in the
protocols it is determined if and how these requirements are met. Here is an overview
of the various security tools used in Medusa communication and their abbreviations:
A,B : identity of a or b
K
ab
: symmetric key shared by A and B
{m}SK
a
: message encrypted with SK
a
TS : timestamp
H(M) : a hash of M
M : the actual message
N
a
: nonce generated by a
321

PK
a
, SK
a
: public and secret key pair
2.2.1 The Bootstrapping Phase
The bootstrapping phase itself can be further divided into three subphases: Primary
Elections, Pool Formation, Ratification.
Primary Elections
Before bootstrapping can begin, a network must exist with a number of agents (CE’s).
These agents are not dedicated Medusa agents, but have background Medusa
functionality. Furthermore these agents must have initial but limited access to one or
more Central Exogenous Authority’s (CEA), i.e a trust dealer. A CEA can provide
them with a trust certificate that contains a quantitative indication of their
trustworthiness. In the intended Medusa structure one or several chosen agents will
perform the centralized trust management service. Agents that opt to become a
candidate leader inform all other agents of this fact. When all candidates are known
the actual voting process takes place. All agents create a list of ballots containing a
voting score for each candidate. These scores are based on the absolute trust value
given by the CEA, and the agent’s individual level of trust in the CEA itself. After
receiving all the votes the candidates individually calculate the score of each
candidate by weighting the votes of every agent with their respective trust value and
summing up the results. This means that every candidate will have a greater
appreciation for the voting scores of the agents it trusts most. The top scoring
candidates are the prospect SDC’s.
1. CE Æ CEA : (IDlist request)
2.
CEA Æ CE : (IDlist)
Initialize
3. Cand(A)ÆCE(B): {M,A,N
a
}SK
a
, {H(M,A,N
a
),TS}SK
a
(candidacy declaration)
4. CE(B) Æ Cand(A): {H(M,A,N
a
,N
b
),TS}SK
b
, N
b
(acknowledge receipt)
ModPublishCand
5. CE(B) Æ Cand(A): {M,B,N
b
}PK
a
, {H(M,B,N
b
),TS}PK
a
(ballot list)
6. Cand(A) Æ CE(B): {H(M,B
b
,N
a
),TS}SK
a
, N
a
(acknowledge receipt)
Initialize: In this initial protocol every CE acquires an initial IDlist from the CEA
containing the ID’s and trust certificates of most CE’s in the network space. Correct
authentication both from the CE to the CEA and from the CEA to the CE is essential
in the method. Confidentiality is an issue, although later in the process most CE’s will
share their trust certificates for privacy reasons they should retain the right to keep
their certificates private. It was decided not to give a specification of the Initialization
protocol. The implementation of this protocol will undoubtedly differ with each
Central Exogenous Authority. It is assumed that a CEA in the Medusa environment
has some protocol in place which offers confidentiality and 2-way authentication.
ModPublishCand: In this method the candidates broadcast their candidacy
declaration over the network. Since the candidacy declaration does not contain any
sensitive information confidentiality of the message is not an issue here.
Authentication however is relevant; and is provided through the use of the
Candidate’s secret key.
ModCastBallots: A CE sends its list of ballots to all known candidates. Similar to
the method Initialize confidentiality is an issue here for reasons of privacy. It is
provided by encrypting the message with the candidate’s public key. Authentication is
ModCastBallots
322

also required but is not provided, anybody could have encrypted this message since
the key used for encryption is public.
Pool Formation
The goal of this sub phase is creating a pool of possible successors to the SDC in case
it should at some point cease to exist. To that end the leader invites other agents to
join its pool. The invited pool members evaluate whether to indeed become a pool
member of the inviting prospect. They must have sufficient trust in the inviting
prospect to do so. Once enough pool members agree the pool formation is finished.
1. Pros(A)ÆCE(B): {{M}SK
a
,A,N
a
,K
ab
}PK
b
,{H(M,A,N
a
)TS}PK
b
(Covenant)
2. CE(B) Æ Pros(A): {H(M,K
ab
,A,N
a
,N
b
),TS}SK
b
, N
b
(Acknowledge Receipt)
3. CE(B) Æ Pros(A): {{H(M)}SK
b
,A,N
b
}K
ab
,{H(M,A, N
b
)TS}K
ab
(Signed covenant)
4. Pros(A) Æ CE(B): {H({M}SK
b
,,A,N
b
,N
a
),TS}SK
a
, N
a
(Acknowledge Receipt)
ModProcessVotes: This method only features communication for candidates that
go on to become prospects. These prospects send a covenant for signing to a number
of prospect pool members. This covenant is clearly meant only for the pool members
and should therefore remain confidential. Confidentiality is provided by encrypting
the entire message with the CE’s public key. Also, authentication should be
established from the prospect to the future pool member. Authenticity is guaranteed
because M is signed with the prospect’s private key.
ModVouches: In Modvouches the prospect pool member signs and returns the
covenant. The pool member should be authenticated to the prospect. Confidentiality
does not seem to be required since only a signed hash of the covenant is returned to
the prospect leader. However another (untrusted) prospect could use such a covenant
to fool other CE’s into believing it has a strong pool. Therefore the hashed and signed
covenant should remain confidential. Both authenticity and confidentiality are
achieved by encrypting the message with its symmetric key supplied by the prospect.
ModVouches
ModProcessVotes
Ratification
The final step in establishing a Medusa structure is ratification of the prospects by end
members. All prospects that have managed to form a pool invite agents to subscribe to
them by advertising themselves and their pool structure. This pool structure indicates
their possible survivability rate as their pool members are possible future successors.
The agents individually decide whether or not to become a client of a certain leader
(or SDC). Even when clients have subscribed they may still switch to another leader,
which presents an increase in trustworthiness or survivability. When all leaders have
invited clients they evaluate their clientele. If it is large enough to warrant the leader’s
existence the leader can start providing its security service. If not the leader will
disband its pool and group of clients, leaving it and its former pool members available
to join new pools or subscribe to other SDC’s.
1. Pros(A)ÆCE(B): {M,A,N
a
}SK
a
, {H(M,A,N
a
),TS}SK
a
(Subscr Inivitation)
2. CE(B)ÆPros(A): {H(M),A,N
a
,N
b
),TS}SK
b
, N
b
(Acknowledge Receipt)
3. CE(B)ÆPros(A):{{M}PK
a
,A,N
b
}SK
b
,{H(M,A,N
b
),TS}SK
b
(Subscr Answer)
4. Pros(A)ÆCE(B): {H(M,A, N
b
,N
a
),TS}SK
a
, N
a
(Acknowledge Receipt)
5. Pros(A)ÆCE(B): {M,K
ab,
A,N
a
}PK
b
, {H(M,A,N
a
)TS}PK
b
(Secret Key)
6. CE(B)ÆPros(A): {H(M,A,N
a
,TS,N
b
)}SK
b
, N
b
(Acknowledge Receipt)
ModRatification
ModSubscribe
ModMembership
323

ModRatification: As in the method ModPublishCand the leader broadcasts it
subscription request over the network, hence confidentiality is not an issue. Because
the clients need to know to whom they will or will not subscribe the leader should be
correctly authenticated to the receivers. This is provided by encrypting the
subscription request with the leader’s secret key.
ModSubscribe: The CE chooses whether or not to subscribe and replies to the
leader. If the client subscribes it sends a hashed secret to the leader which should
remain confidential. The CE must also be authenticated to the leader. Confidentiality
is achieved by encrypting the whole message with the prospect’s public key; the
hashed secret is encrypted with the client’s private key to provide authenticity.
ModMembership: The leader acknowledges the client’s subscription. This message
also contains the symmetric server key that the client can use for efficient
communication through the SDC (the leader) and therefore must be kept confidential.
Authentication of the leader to the client is essential, as the client must be certain that
its key was issued by its leader. Confidentiality is provided by encrypting the message
with the client’s public key. Although no private key is used authenticity is still
guaranteed because the leader returns the hashed secret (stored in M) which no one
knows other than the leader and its client.
2.2.2 The Preparation Phase
Once the trust infrastructure has been created it must be maintained. The goal of the
preparation phase is to prepare the leader to resist future failures. To this end the
leader creates a survival kit, containing a list of its clients, an ordered list of possible
successors and the trust token, the combination of the individual secrets of each client.
The trust token is divided into several pieces through twisted secret sharing [18] [5].
Each pool member receives the client list, the successor list, and a piece of the trust
token. The pieces of the trust token are encrypted and distributed amongst the pool
members with non-matching keys in such a way that a majority of the pool members
can reconstruct it in case the leader ceases to exist.
There are two security protocols that run during the preparation phase: the trust
token sharing protocol and the alive protocol. The first is run only periodically when a
significant change to the secret has occurred (due to for instance a new client being
added) while the latter is run almost continuously.
Trust Token Sharing:
1. Ldr(A) Æ Plmbr(B): {M,A, N
a
}K
ab
,{H(M,A,N
a
),TS}K
ab
(piece of token)
2. Plmbr(B) Æ Ldr(A): {H(M,A, N
a
,N
b
),TS}K
ab
, N
b
(Acknowledge Receipt)
Alive:
1. Ldr(A) Æ Plmbr(B): {M,A,N
a
}K
ab
, {H(M,A,N
a
),TS}K
ab
(Alive message)
2. Ldr(B) Æ Plmbr(A): {H(M,A,N
a
,N
b
),TS}K
ab
, N
b
(Acknowledge Receipt)
ModPreparation: this method handles the division and distribution of the
survivability objects. Although the different parts of the trust token cannot be opened
with the keys sent with them confidentiality must still be maintained for else an
intruder could acquire the clients’ secrets by intercepting enough pieces of the trust
token to reconstruct it. Authentication is also essential and must be established both
ways. The leader must be certain that he is indeed sending the trust token to the pool
ModPreparation
ModSelfAssess
324

members whilst the pool members must only accept the new token when they are
convinced their leader has sent it. Both authenticity and confidentiality are provided
through a symmetric key shared by the leader and the respective pool member.
ModSelfAssess: This method contains a leader’s functionality for sending “alive”
signals to each pool member. The security requirements for “alive” messages are
limited. Confidentiality is not required, authenticity from the leader to the pool
members is required; the pool members must know that it is the leader sending out
alive signals and not an imposter. Authenticity is guaranteed through symmetric keys.
2.2.3 The Resurrection Phase
The resurrection phase allows the pool members to resurrect the trust token and
appoint the successor as the new leader in case of leader failure. First each pool
member determines the successor based on the successor list. Before sending its piece
of the trust token to the successor a pool member checks whether the successor is
alive. If the successor is operational all pool members send their piece of the trust
token to the successor. The successor gathers all pieces and reconstructs the token.
With the trust token the successor assumes the leadership role and starts to refresh
both the pool member and the client keys. Subsequently the clients acknowledge the
new leader by refreshing their secret. The new leader combines the fresh secrets into a
new trust token and enters the preparation phase.
The resurrection phase features two security protocols: resurrection and key &
secret refreshment. Contrary to the preparation phase these protocols run sequentially.
Resurrection:
1. Plmbr(A) Æ Ldr(B): {M,A,N
a
}K
ab
,{H(M,A,N
a
),TS} K
ab
(request Alive)
2. Plmbr(A)ÆPlmbr(C):{M,A,N
a
}K
ac
,{H(M,A,N
a
),TS}K
ac
(death decl.)
3. Plmbr (C) Æ Plmbr(A): {H(M,A,N
a
,N
c
),TS}K
ac
, N
c
(Acknowledge dd)
4. Plmbr(A)ÆScssr(C):{M,A,N
a
}K
ac
, {H(M,A,N
a
),TS}K
ac
(trust token)
5. Sccssr(C) Æ Plmbr(A): {H(M,A,N
a
,N
c
),TS}K
ac
, N
c
(Ackn. receipt)
Key & Secret Refreshment
1. Ldr(A) Æ CE(B): {H(M),A,N
a
,K
ab2
)K
ab
, {H(K
ab2
,A,N
a
),TS}K
ab
(new key)
2. CE(B) Æ Ldr(A): {H(K
ab2
,A,N
a
,N
b
),TS}K
ab
, N
b
(Acknowledge Receipt)
3. CE(B) Æ Ldr(A): {H(M
2
),B,N
b
}K
ab2
, {H(M
2
,B,N
b
),TS}K
ab2
(updated sectret)
4. Ldr(A) Æ CE(B): {H(M
2
,B,N
a
,N
b
),TS}K
ab2
, N
b
(Acknowledge receipt)
ModCheckCondition: After a failed alive check, a poolmember informs the others
of the leader’s demise and starts the resurrection protocol. Informing the other pool
members of the leader’s demise can be achieved with few security requirements. Only
authenticity from the sender to the receiver is required. The receiving pool members
must be certain that the declaration of death was sent by a pool member so that agents
outside the pool cannot confuse it with false declarations. Authenticity is provided
through the symmetric keys
ProcSendToken: In this method all pool members send their piece of the token to
the successor. Confidentiality is critical since together the pieces of the token contain
highly sensitive information. Also two-way authentication must be established. All
requirements are achieved by the symmetric keys used in both messages.
ModCeckCondition
ProcRefreshSecr
ProcRefreshKeys
ProcSendToken
325

ProcRefreshKeys: The successor has assumed the leadership role and refreshes all
keys. Since this is in essence a key-exchange protocol again both confidentiality and
two-way authentication need to be established. These requirements are provided via
the symmetric keys of the former leader which the successor has successfully rebuilt.
ProcRefreshSecr: After receiving a fresh key the CE also resends its secret to the
leader. As implied by its name the secret contains sensitive information, requiring
confidentiality. Furthermore the secret must be sent to none other than the respective
leader, and the leader must be sure of the identity of the sender. This leads to the
conclusion that again two-way authentication is required. Both authenticity and
confidentiality are provided through the use of the new symmetric keys, just issued by
the new leader in procRefreshKeys.
2.3 Summary
The following table summarizes the different requirements for each method that were
established in the previous text. For Integrity and Confidentiality a “–“ value signifies
that the respective property is not required, while a “+” signifies the opposite. For
authentication “1-way” means that the sender must be authenticated to receiver, and
“2-way” represents a two-way authentication requirement.
Table 1. Security Requirements
Methode Auth. Int Con Methode Auth. Int Con
Initialize 2-way + + ModMembership 1-way + +
ModPublishCnd 1-way + - ModPreparation 2-way + +
ModCastBallots 1-way + + ModSelfAssess 1-way + -
ModProcessVts 1-way + + ModChkCndition 1-way + +
ModVouches 1-way + + ProcSendToken 2-way + +
ModRatification 1-way + - ProcRefreshKeys 2-way + +
ModSubscribe 1-way + + ProcRefreshSecr 2-way + +
All messages in the Medusa process include a signed hash of the message contents.
Therefore the integrity of all messages is guaranteed. In most cases the other
requirements are also met except for one: the authenticity requirement in
modCastBallots. Authenticity is not achieved because the message is only encrypted
using the receiver’s public key. If instead the message is also encrypted with the
sender’s private key, as seen in modProcessVotes, both authenticity and
confidentiality will be guaranteed as is required.
3 CSP/FDR Analysis
Now that the various security requirements for the Medusa protocol have been
established and validated in a “friendly” environment, the analysis continues in an
environment where active intruders attempt to subvert the Medusa process. To
validate Medusa in a hostile environment the CSP/FDR approach is introduced.
The CSP/FDR approach consists of the CSP (Communicating Sequential
Processes) process algebra and the model checker FDR (Failures/ Divergences
Refinement). CSP is a mathematical framework for the description and analysis of
326

systems consisting of components (processes) interacting via the exchange of
messages [12] [15] [17]. The fact that CSP is designed specifically for describing
parallel processes communicating with each other makes it inherently suited for
modelling security protocols. In CSP, clients, pool members and leaders can be
modelled as processes performing a sequence of actions. By default the network will
deliver a message to its specified destination but an intruder is active on the network.
The intruder conforms to the Dolev-Yao model [8]. This model introduces an attacker
able to manipulate messages passing through the network by deleting, faking,
redirecting replaying and so on, only bound by cryptographic constraints. This
intruder is present in each run of the security protocol and tries everything in its
arsenal to subvert the security properties of the protocol. With regards to
cryptography, perfect encryption is assumed.
For generating the CSP language a high level compiler was used: Casper (Lowe,
1998). Casper takes a fairly abstract description of a security protocol (similar to the
description used in section 3) and generates the corresponding CSP description. By
using Casper both the time required for generating the CSP description and the
likelihood of errors in the description is greatly reduced.
3.1 Protocol Validation
In this section CSP/FDR is used to validate the various security protocols described
earlier. Only the confidentiality and authenticity requirements can be checked with
this approach. However when a message is correctly authenticated and contains a
signed hash of its contents, integrity should also be guaranteed. To catch replay
attacks by the intruder, the authentication requirement is enhanced with the following
condition: if an entity A believes it has run a protocol once with another entity B then
B has run the protocol with A exactly once. The protocol specifications of section 3
are in several systems, containing various initiators and responders. The following
scenarios are a reasonably complete list of the checks worth making [16]:
1. An initiator A, and a responder B
2. An initiator A, and a responder A
3. An initiator A, a responder A,
and an initiator B
All of these systems were tested for each Medusa security protocol. The following
text describes the attacks that were found on the various protocols and, if possible, a
solution. If a protocol is not mentioned, no attack was found.
4. An initiator A, a responder A,
and a responder B
5. An initiator A, and two responders B
6. Two Initiators A, and a responder B
Pool formation: In the first scenario an attack is discovered on the authentication
requirement of ModProcessVotes. The attack proceeds as follows:
1.Pros(A)ÆInt :{{M}SK
a
,A,N
a
,K
a,int
}PK
int
,{H(M,A,N
a
)TS}PK
int
1.Int(A)ÆCE(B):{{M}SK
a
,A,N
a
,K
a,int
}PK
b
,{H(M,A,N
a
)TS}PK
b
2.CE(B)ÆInt(A):{H(M, K
a,int
,A,N
a
,N
b
),TS}SK
B
, N
b
3.CE(B)ÆInt(A):{{H(M)}SK
b
,A,N
b
}K
a,int
,{H(M,A,N
b
)TS}K
a,int
4.Int(A) ÆCE :{H({M}SK
b
,,A, N
b
,N
a
),TS} K
a,int
, N
a
This attacks presents a rather unlikely situation where prospect A invites the
intruder into its pool. The intruder subsequently redirects this invitation to B posing as
A. The intruder acts as though the symmetric key it is issued by A is instead a key
327

between A and B. B finishes the protocol with the intruder and believes it is now a
pool member of A. This is not the case because in fact it did not run the protocol with
A. Although it is unlikely that a prospect would actually invite an intruder, this attack
can be negated completely by adding the message’s destination in the part encrypted
with A’s secret key. The protocol is changed as follows: (the change is printed bold):
1. Pros(A)ÆCE(B):{{M,B}SK
a
A,N
a
K
ab
}PK
b
{H(M,A,N
a
)TS}PK
b
2. CE(B)ÆPros(A): {H(M,K
ab
,A,N
a
,N
b
),TS}SK
b
, N
b
3. CE(B)ÆPros(A): {{H(M)}SK
b
,A,N
b
}K
ab
, {H(M,A, N
b
)TS}K
ab
4. Pros(A)ÆCE(B): {H({M}SK
b
,,A,N
b
,N
a
),TS}SK
a
, N
a
After this change was adopted no more attacks were discovered in any of the
scenarios.
Trust Token-Sharing: In scenario 4 Casper detects the following attack on the
authentication of ModPreparation:
1.Ldr(A) Æ Int(B) : {M,A, N
a
} K
ab
, {H(M,A, N
a
),TS} K
ab
1.Int(A)ÆPlmbr(B) : {M,A, N
a
} K
ab
, {H(M,A, N
a
),TS} K
ab
2.Plmbr(B) Æ Int(A) : {H(M,A, N
a
,N
b
),TS}K
ab
, N
b
1.Int(A) Æ Plmbr(B) : {M,A, N
a
} K
ab
, {H(M,A, N
a
),TS} K
ab
2.Plmbr(B) Æ Int(A) : {H(M,A, N
a
,N
b
),TS}K
ab
, N
b
This is a textbook replay attack. The intruder poses as B and A sends the secret.
The intruder sends this to B twice and B responds accordingly. Now A thinks it is still
running the protocol with B while B thinks it has already run it twice. The data
integrity is still in tact because the message is still the same. Whether this attack is
possible in practice depends on the implementation of the protocol. If B saves the
nonce supplied by A for as long as the timestamp is valid, or saves the last timestamp
it has received, this replay attack becomes impossible. The attack can also be solved
regardless of implementation by adapting the protocol as follows:
1.Ldr(A) Æ Plmbr(B) : {M,A, N
a
} K
ab
, {H(M,A, N
a
),TS} K
ab
2.Plmbr(B) Æ Ldr(A) : {H(M,A, N
a
,N
b
),TS, N
b
}K
ab
,
3.Ldr(A) Æ Plmbr(B) : N
b
The nonce generated by B is sent to A encrypted, and subsequently returned to B.
Every time B receives its nonce it can therefore be certain that A has run the protocol.
Although the above attack does not cause any discernable damage (as long as the
validity of the time stamp is shorter than the intervals of refreshing the token) to the
Medusa process, it is recommended that either of the above solutions is adopted. Both
solutions are easily implemented and with both, strong authentication is guaranteed.
3.2 Protocol Improvements
To optimize the Medusa protocol further, CSP/FDR was used to check the security
requirements could still be achieved if the various sub protocols were “slimmed
down”. The main goal for this section is to remove Medusa’s dependency on
timestamps especially in the Bootstrapping phase. Although limited time
synchronization may be possible, even in open and ad-hoc networks, it would greatly
benefit to the protocol if the time synchronization dependency were removed.
Primary Elections:
328

1. Cand(A)ÆCE(B) : {M,A,N
a
}SK
a
, {H(M,A,N
a
)}SK
a
2. CE(B)ÆCand(A) : {M,B,N
b
,A,N
a
}PK
a
,{H(M,B,N
b,
A,N
a
}SK
b
3. Cand(A)ÆCE(B) : N
b
Pool Formation:
1. Pros(A)ÆCE(B) : {M,,A,K
ab
}PK
b
,{H(M,A,K
ab
),B}SK
a
2. CE(B)ÆPros(A) : {{H(M)}SK
b
,B,N
b
}K
ab
,{H(M,B,N
b
)}K
ab
3. Pros(A)ÆCE(B) : N
b
Ratification:.
1. Cand(A)ÆCE(B) : {M,A,N
a
}SK
a
, {H(M,A,N
a
)}SK
a
2. CE(B)ÆCand(A) : {M,B,N
b
,A,N
a
}PK
a
,{H(M,B,N
b,
A,N
a
}SK
b
3. Cand(A)ÆCE(B) : {M,A,N
b,
K
ab
} PK
b
,{H(M A,N
b,
K
ab
)}SK
b
Trust Token Sharing:
1.Ldr(A) Æ Plmbr(B) : {M,A, N
a
} K
ab
, {H(M,A, N
a
),TS} K
ab
2.Plmbr(B) Æ Ldr(A) : {A,N
a
,N
b
} K
ab
, {H(A,N
a
,N
b
)}K
ab
,
3.Ldr(A) Æ Plmbr(B : N
b
Alive:
1. Plmbr(A) Æ Ldr(B) : N
b
2. Ldr(A) Æ Plmbr(B) : {M,A, N
b
} K
ab
, {H(M,A, N
b
} K
ab
1. Ldr(A) Æ Plmbr(B) : {M,A,TS} K
ab
, {H(M,A,TS} K
ab
Resurrection:
1. Plmbr (A) Æ Ldr(B) : {M,A,N
a
} K
ab
, {H(M,A,N
a
)} K
ab
2. Plmbr (A) Æ Plmbr(C) : {M,A,N
a
} K
ac
, {H(M,A,N
a
)} K
ac
3. Plmbr (C) Æ Plmbr(A) : {C, H(M,A,N
a
,C)}K
ac
4. Plmbr (A) Æ Sccssr(C) : {M,A,N
a
} K
ac
, {H(M,A,N
a
)} K
ac
5. Sccssr (C) Æ Plmbr(A) : N
a
Key & Secret Refreshment:
1. Ldr(A)ÆCE(B):{H(M),A,K
ab2
)K
ab
,{H(K
ab2
,A)}K
ab
2. CE(B)ÆLdr(A): {H(M
2
),B,N
b
} K
ab2
, {H(M
2
,B,N
b
)} K
ab2
3. Ldr(A)ÆCE(B): N
b
Comparing these protocols to the original protocols a number of improvements are
visible. First and foremost the timestamps have been removed without sacrificing the
required security. Any replay attacks are avoided through the use of nonces.
Furthermore most individual protocols have become much smaller, with in some
cases a 50 percent reduction in the number of messages required.
For the Alive protocol two possible implementations are shown. The first does not use
timestamps but consists of two messages. The second consists of only one message (a
50 percent reduction in the number of messages) but does require the use of a
timestamp. Because the Alive protocol is run almost continuously the reduction in
messages can yield a significant performance benefit. The Alive protocol is run after
the structural hierarchy is in place so time synchronization should be easily achieved.
4 Conclusions
The analyses in this paper have shown that the Medusa protocol with some minor
alterations can provide the security requirements: confidentiality, integrity and
authentication, even with an active intruder out to subvert the Medusa process. Also,
further alterations have been suggested to the various sub protocols to increase their
efficiency whilst maintaining the security requirements. These changes have lead to a
329

protocol that is not dependent on time synchronizations during the bootstrapping
phase. In this phase, time synchronization poses a real problem, and the fact that
Medusa is able to do without it is a great improvement. Furthermore if for some
reason time synchronization in the latter phases is unavailable, the Medusa protocol
can be adapted to avoid time synchronization altogether.
References
1. Birman, K. The Process Group Approach to Reliable Distributed Computing, In
Communications of the ACM, 36(12), 1993, 37-53.
2. Blaze, M., Feigenbaum, J., Ioannidis, J., Keromytis, A.D. The Role of Trust Management in
Distributed Systems Security, Secure Internet Programming, J.Vitek, C. Jensen, ed.,
Springer-Verlag, 1999, 185-210.
3. Cachin, C. and J. Poritz (2002). Secure Intrusion Tolerant Replication on the Internet,
International Conference on Dependable Systems and Networks, Washington.
4. Capkun, S., Buttyán, L., Hubaux, J.P. Self-Organized Public-Key Management for Mobile
Ad Hoc Networks, IEEE Transactions on Mobile Computing, Vol. 2(1), 2003.
5. Daskapan, S. Dependable security by twisted secret sharing, 19th IFIP Information Security
Conference, Toulouse, 2004.
6. Daskapan, S., Verbraeck, A., Vree, W.G. The merge of computing paradigms, 5th Int.Conf.
on computer and information technology, Dhaka, 2002, 553-558.
7. Daskapan, S., Vree, W.G., Sol, H.G. Building a Distributed Security Defence System. In
Proc of the IEEE Int Conf. on Systems, Man & Cybernetics, Delft, 2004.
8. Dolev, D., Yao, A.C. On the Security of Public Key Protocols, IEEE Transactions on
Information Theory, 29(2), 1983.
9. Donovan, B., Norris, P., Lowe G., Analyzing a library of security protocols using casper and
FDR. In Proceedings of the Workshop on Formal Methods and Security Protocols, 1999
10. Ellison, R., Fisher, D., Linger, R., Lipson, H., Longstaff T., Mead, N. Survivable network
systems: An emerging discipline, Tech. Report CMU/SEI-97-153, CMU, Pittsburgh, 1997.
11. Gong , L. (1993). "Increasing Availability and Security of an Authentication Service." IEEE
Journal on Selected Areas in Communications 11(5): 657-662
12. Hoare, C.A.R. Communicating Sequential Processes, MIT Press, 1988.
13. Reiter, M. Secure Agreement Protocols: Reliable and Atomic Group Multicast in Rampart,
In Proceedings of 2nd ACM Conf. on Comp. and Comm. Security, ACM, 1994, 68-80.
14. Renesse, R. van, Birman, K., Maffeis, S. Horus: A Flexible Group Communication system,
In Communications of the ACM, 39(4), 1996, 76-83.
15. Roscoe, A.W. The Theory and Practice of Concurrency, Prentice-Hall, 1997.
16. Ryan, P. Y. A., Schneider, S. A. The Modelling and Analysis of Security Protocols: the CSP
Approach. Addison Wesley Publ. Co., Reading, Massachussetts, 2000.
17. Schneider, S.A., Concurrent and Real Time Systems: the CSP Approach,Addison-
Wesley,1999.
18. Shamir, A., How to Share a Secret, Communications of the ACM 22(11), 1979.
19. Wiechers, W.K., Daskapan, S., Vree, W.G. Simulating the Establishment of Trust
Infrastructures in Multi-Agent Systems, In 6h Int. Conference on E-Commerce, Delft 2004.
20. Zhou, L., Haas, Z. J. Securing Ad Hoc Networks, IEEE Network Magazine, Vol. 13(6),
1999
21. Zimmermann, R. The Official PGP User's Guide, MIT Press, Cambridge, 1995.
330
