ELECTRONIC DOCUMENT CLASSIFICATION USING

SUPPORT VECTOR MACHINE-AN APPLICATION FOR E-

LEARNING

Sandeep Dixit

NPTI Badarpur New Delhi India

L.K.Maheshwari

BITS Pilani Rajasthan India

Keywords: Support Vector Machines (SVM), Term Frequency (TF), Term Frequency – Inverse Document Frequency

(TF – IDF).Internet services, Dial-up networking.

Abstract: Appplication of the machine learning techniques to embed adaptivity in the E-Learning frameworks is

receiving considerable attention. Text Classification, or the task of automatically assigning semantic

categories to natural language text, has therefore become one of the key methods for organizing digital

content.Reports on SVM have mainly focussed on the theory or conceptual application of the SVM with

little, if any, concern to applicability to E-Learning domain. In this paper we present a holistic approach

towards building a text classifier suited for E-Learning domains. We present theory, application and use of a

specific SVM software(SVM Torch) for classification of electronic documents giving every detail of how

the downloaded SVM software can be used to apply the SVM concept and categorise text document in the

context of E-Learning domains. Experimental results obtained by applying SVM to text document are

presented. Pre-processing of the document is also presented. The experiment was conducted using SVM

Torch software with ten documents for training and five documents for testing. SVMs performed the best

when used with binary representation. We are confident that the extent of details provided could well serve

as a useful component in E-Learning frameworks and even provide curriculum component for UG level

students.

1 INTRODUCTION

Text Classification, or the task of automatically

assigning semantic categories to natural language

text, has become one of the key methods for

organizing online information. Since hand-coding

classification rules is costly or even impractical,

most modern approaches employ machine learning

techniques to automatically learn text classifiers

from examples. Other text classification techniques

reported are the word based soft clustering

Algorithm,[King-Ip Lin, Ravi Kumar, Dept. of

science university of Memphis, USA]where a

comparative study of the quality of clusters by K-

Means, WBSC, Buckshot and Fractionation has bee

shown. However the tuning of parameters of the

algorithms in these studies is left out. Another text

classification technique reported (.H.Li, et.al.in The

Computer Journal, Vol.41, No.8, 1998l ) uses Naïve

Bayesian, Neural Networks, Decision Trees, and

Subspace Classifier. However use of SVM has been

left out in such applications specifically, even

though the high dimensionality is efficiently handled

with SVM. Support Vector Machines (SVM) theory

is finding increasing application in the classification

of the documents as it combines high performance

and efficiency with theoretical understanding and

improved robustness. In particular, it is highly

effective without greedy heuristic components and

computationally efficient in training and

classification. With SVMs the generalization error

gets optimised and the mean and standard deviation

of the error are improved. In this paper we have used

the ‘SVMTorch by Collobert and Bengio’ for

experimentation as it could work even with very

high dimensional data.

191

Dixit S. and K.Maheshwari L. (2005).

ELECTRONIC DOCUMENT CLASSIFICATION USING SUPPORT VECTOR MACHINE-AN APPLICATION FOR E-LEARNING.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 191-198

 SciTePress

The paper is organised as follows: Section I

provides an overview of SVM, its working and how

it lends itself for the type of categorisation work

necessary in e-learning paradigm, Section II

provides a brief description of the SVM Torch

software. Section III describes the approach used

and the pre-processing of the document. Section IV

gives the complete implementation of the Text

categorisation using the SVM software and gives

experimental results and the analysis. The method

for representing the documents and the use of SVM

Torch in classification of text documents has been

dealt therein. The code for the document pre-

processing, commands to be executed for training

SVM and classification of documents and sample

screen shots have also been included.

2 SECTION I

2.1 Support Vector Machines

The foundations of Support Vector Machines (SVM)

have been developed by Vapnik (Vapnik,V.,1995)

and are gaining popularity due to many attractive

features, and promising empirical performance. The

formulation embodies the Structural Risk

Minimisation (SRM) principle, which is superior

(Gunn, S.R., et al., 1997), to traditional Empirical

Risk Minimisation (ERM) principle, employed by

conventional neural networks. SRM minimises an

upper bound on the expected risk, as opposed to

ERM that minimises the error on the training data.

This is the difference that equips SVM with a greater

ability to generalise, which is the goal in statistical

learning. SVMs were developed to solve the

classification problem, but recently they have been

extended to the domain of regression problems

(Vapnik,V., et al., 1997). The term SVM is typically

used to describe classification with support vector

methods and support vector regression is used to

describe regression with support vector methods.

Kernel Selection is an important issue and the

obvious question that arises is that with so many

different mappings to choose from, which is the best

for a particular problem? This is not a new question,

but with the inclusion of many mappings within one

framework it is easier to make a comparison. The

upper bound on the VC dimension is a potential

avenue to provide a means of comparing the kernels.

However, it requires the estimation of the radius of

the hypersphere enclosing the data in the non-linear

feature space.The problem of empirical data

modelling is germane to many engineering

applications. In empirical data modelling a process

of induction is used to build up a model of the

system, from which it is hoped to deduce responses

of the system that are yet to be observed. Ultimately

the quantity and quality of the observations govern

the performance of this empirical model. By its

observational nature data obtained is finite and

sampled. This sampling is non-uniform and due to

the high dimensional nature of the problem the data

will form only a sparse distribution in the input

space. Consequently the problem is nearly always ill

posed (Poggio,T. et al., 1985) in the sense of

Hadamard (Hadamard,J., 1923). Traditional neural

network approaches have suffered difficulties with

generalisation, producing models that can over fit

the data. This is a consequence of the optimisation

algorithms used for parameter selection and the

statistical measures used to select the ’best’ model.

As a final caution, even if a strong theoretical

method for selecting a kernel is developed, unless

this can be validated using independent test sets on a

large number of problems, methods such as

bootstrapping and cross-validation will remain the

preferred method for kernel selection.

2.2 SVM and Document

Classification

The emergence of Student Centred Learning Models

in E-Learning has led to lecture presentation as per

the learner’s choice and state of knowledge. In this

context text categorization has become an area of

intense research. Several methods have been

proposed for such purpose(Y.H.Li, et.al.in The

Computer Journal, Vol.41, No.8, 1998) but we chose

Support Vector Machines as they can be used

efficiently for document classification by using a

feature representation and a kernel method that best

represents the features. The process of representing

the document by a feature representation is termed

as pre-processing. The features need to be mapped

to numerals as SVM software work with numerals.

Support Vector Machine is essentially calculated as

weighted sum of kernel function outputs. The kernel

itself could be polynomial, RBF Gaussian or any

other function satisfying Mercer’s conditions. We

used the polynomial as the kernel function.

Conceptually the Lagrangian formed with the

objective function (constructed from the SVM

output expression) is minimised and the

classification margin maximised for the training set.

2.3 Feature representation

A feature is a word in the document classification. A

feature vector consists of the various words from a

dictionary formed by analysing the documents.

There are various alternatives and enhancements in

ICEIS 2005 - SPECIAL SESSION ON EFFICACY OF E-LEARNING SYSTEMS

192

constructing the feature vectors. Some of them are

(Drucker,H. et al., 1999):

• Term Frequency (TF)

• Term Frequency Inverse Document

Frequency (TF-IDF)

The i

component of the feature vector is the

number of times that the word appears in the

document. Sometimes, the feature vector is

normalized to unit length Binary Representation.TF-

IDF uses the above TF multiplied by the IDF

(inverse document frequency). The Document

Frequency (DF) is the number of times that a word

occurs in all the documents or some (based on

specifications). The inverse document frequency is

defined as

IDF(w

) = log(|D|/DF(w

Mod D is number of documents.

Binary Representation

Binary Representation represents whether a

particular word occurs in a particular document

presentation In addition to the any of the above, stop

words may or may not be used. Words like “of”,

“and”, “the”, etc., are used to form the stop list.

Words on the stop list are not used in forming a

feature vector. The argument against the use of stop

words is that it is not obvious which words, beyond

the trivial, should be on the stop list

Polynomial Kernel

A polynomial mapping is a popular method for non-

linear modeling,

The kernel used is usually the second equation, a

slightly modified form with addition of 1 to the right

hand side of the above expression as it avoids

problems with the Hessian becoming zero.

3 SECTION II

The SVMTorch Software

SVMTorch is the software tool used for using SVMs

for classification. SVMTorch (Source: www.support-

vector.com) is a new implementation of Vapnik's

Support Vector Machine that works both for

classification and regression problems, and that has

been specifically tailored for large-scale problems

(such as more than 20000 examples, even for input

dimensions higher than 100).

Commands

SVMTorch software enables user to train the SVM

and use it for classification with the help of two

commands. They are SVMTorch and SVMTest. The

command SVMTorch is used for training the SVM

using the training data set and the command

SVMTest is used for classifying the test documents.

The syntax of both these commands are given below

The general syntax:

• SVMTorch SVMTorch [options]

example_file model_file

• SVMTest SVMTest [options] model_file

test_file

where "example_file" is the file obtained from the

training set file after preprocessing, "test_file" is the

file obtained from the testing set file after

preprocessing and "model_file" is the SVM-model

created by SVMTorch.

Options

SVMTorch provides the above commands with

multiple options. All the options are described when

SVMTorch or SVMTest is launched without any

argument. By default, SVMTorch is a classification

machine. If the regression machine is needed, the

option –rm is to be used. The current error displayed

by SVMTorch is only an indicator. It can oscillate.

SVMTorch

The major options of the command SVMTorch are:

- multi <int> for multiclass problems. The data must

be in multiclass format.

-mlc <int> for multiclass problems. The last class to

learn can be specified here.

-c <float> <float>is the trade-off between training

error and margin. Defult=100.

- unshrink if the optimality of removed variables at

the end of learning phase is to be checked. It will

possibly restart the optimization. The SVMTorch

will be slower with this option.

-d <int> where <int> is the parameter d in the

polynomial kernel.

- std <float> where <float> is the parameter std in

the Gaussian kernel.

- s <float> where <float> is the parameter s in the

sigmodial or in the polynomial kernel.

ELECTRONIC DOCUMENT CLASSIFICATION USING SUPPORT VECTOR MACHINE-AN APPLICATION FOR

E-LEARNING

193

- r <float> where <float> is the parameter r in the

sigmodial or in the polynomial kernel.

- u <string> where <string> is a parameter for the

user defined kernel.

- t <int> <int> defines kernel:

0 is the linear kernel

1 is the polynomial kernel (a,b)

2 is the gaussian kernel

3 is the sigmoidal kernel

SVMTest

The options of the command SVMTest are:

- multi for multiclass problems. The data should also

be in the same format.

-norm when in multiclass mode, this option

normalizes (with the inverse of the margin norm) the

output of each model before deciding in which class

the example should be. To avoid time conconsuming

the margin is now approximated by the sum of the α

where α

is the coefficient related to i

support

vector. (In the separable case it is the same as the

margin)

- sparse for the sparse mode. This is used when the

data is in the sparse format.

- bin if the data is in binary, set this flag.

- load <int> loads only <int> examples in the test

set.

- oa <file> prints the output of the model in <file>,

in ASCII.

- ob <file> prints the output of the model <file>, in

binary..

File format

The files that are given to the above commands can

in be various formats. The default format of

SVMTorch and SVMTest is the ASCII format.

Therefore, -bin is to be given in the command line

while using binary files. No tests are made with

binary files, and it could have an error such as

"Check your data" or "Segmentation fault". Also, -

sparse is to be given if the data is in sparse format.

There are two main input formats for "input_file"

and "test_file" in SVMTorch. They are:

• ASCII format

• Binary format

The general format of a file in ASCII format is given

below.

<Number n of training/testing

samples> <Dimension d of each

sample+1>

> <a

> .... <a

> <a

1_out

> <a

> .... <a

> <a

n_out

where <a

> is an ASCII floating point number

corresponding to the j

value of the i

example and

i_out

> is the i

desired output (in classification, it

should be +1/-1). The binary format is the same,

without carriage returns.There is another special

input format for SVMTest, when there is no desired

output. (-no option is to be used).

4 SECTION III

Programming and categorization approach

This section explains the coding and use of SVM

Torch and mentions the steps to be followed for the

classification of documents. Broadly the two aprts

are The problem posed is shown in the Table 1.and

gives the approach used by us

Esentially, preprocessing involves conversion of the

text document into a file with format supported by

SVM for classification. The format used is ASCII

mode- Standard. The training documents as well as

the test documents must be preprocessed. The

preprocessing can be done using any one of the

alternatives present (Ex: Term frequency, Term

frequency-Inverse Document frequency, Binary

representation etc.) along with defining some rules

for building the library. We have developed

programs for preprocessing using the techniques

Term frequency (TF), Term frequency-Inverse

Document frequency (TF-IDF), Binary

representation along with

The following points must be strictly followed while

executing any of the above programs:

• The files given as input to any of the above

mentioned programs are to be in the same

directory as that of the program being

executed.

• The number of input files should be less

than 20.

• The value given as input for class should be

either 1 or -1 as we are dealing with only

binary classification.

In case of pre-processing of training files, no. of files

corresponds to no. of training samples (documents)

and class to which category the document belongs

while in case of processing for test files, no. of files

corresponds to the documents to be classified and

class corresponds to the expected category to which

it is to be classified.

In case of pre-processing with the help of rules,

an additional input of the value of rule is to be

provided. This value represents the minimum

ICEIS 2005 - SPECIAL SESSION ON EFFICACY OF E-LEARNING SYSTEMS

194

Table 1: Gives an overview of the approach used in using SVM Torch.

INPUT : A set of text documents based on a kew descriptor of lecture content

OUTPUT: Classify the favourable documents against a mix of other text documents.

STEPS

1.Preprocessing

1.1Documents for both training and testing are converted into a file with ASCII format (which is supported by

SVMTorch)

The following steps are involved in converting the documents into a file with ASCII format. This stage also involves

the removal of articles and irrelevant terms

1.1.1 A dictionary is built based on the training files.

1.1.2 All the documents are represented in the form of feature vector.

1.1.3.These feature vectors are written into a file.

2.Classification

2.1.Takes the preprocessed output from previous stage .and uses them for training and testing the SVM.

SVMTorch [option] example_file

model_file

number of times the word should occur (when

counted it’s occurrence in all the documents).

where “example_file” is the file generated from

training examples and “model_file” is the output

model generated by the command.

Classification Stage

The files generated from the preprocessing stage are

used for training and testing the SVM by SVMTorch

software with the help of the two commands

SVMTorch and SVMTest mentioned previously..

Testing

SVMTest is the command used for classifying the

documents using SVM. Its syntax is given below

The code has been developed in C and tested in

UNIX and LINUX platforms. For executing the

commands given in the previous section for training

and testing the SVM, SVMTorch software should be

downloaded and all the files mentioned above

should be present in the directory SVMTorch

SVMTest [options] model_file test_file

where “model_file” is the output model generated by

SVMTorch and “test_file” is the file generated from

the test documents

Once the preprocessing is done, the classification of

the test documents could be done by training the

Support Vector Machine using the file created out of

the training documents. For training the Support

Vector Machine, any of the available software could

be used (with proper changes in the file created out

of the training documents). We have used

SVMTorch software for this purpose. It is free

software downloaded from the net. It provides two

commands for training the SVM and for classifying

the documents using SVM. They are:

5 SECTION IV

Experimental Results

For experimentation purpose we have included text

from diverse categories of documents so as to

• SVMTorch

• SVMTest

These two commands are provided with several

options

Training

SVMTorch is the command used for training the

SVM. Its syntax is given below:

ELECTRONIC DOCUMENT CLASSIFICATION USING SUPPORT VECTOR MACHINE-AN APPLICATION FOR

E-LEARNING

195

Table 2: Results of categorization.

Contents of Test file Expected Classification Actual Classification

Bitmap Indexing 1 1

September 11 attacks -1 -1

Climatic Conditions -1 -1

Bitmap Indexing 1 1

Bitmap Indexing 1 -1

Figure 1: Sample Screenshot. It shows one of the ouput samples. Number of Support Vectors is 11, Input dimension being

611(small)

ICEIS 2005 - SPECIAL SESSION ON EFFICACY OF E-LEARNING SYSTEMS

196

Table 3: SVM application for E-Learning framework-Learner Centered Model

Student Needs SVM role for classification of the Digital content for E-Learning Paradigm

Review selected text

only (before exams)

Provides the keyword

Classified and Categorize

Slides, Text using SVM

All about ‘Router’ Categorize and produce select set of documents from lecture on ‘Computer

networks’using SVM

What are good

candidate documents for

reviewing on ‘Concept

X’

Present a list of documents classified based on the given concept category.

Rank Lecture

documents based on

relevance to coming

exam

Prioritise the documents so as to optimise on the time to be given for each

document before a presentation or talking the exam

Q & A Session,

e.g.‘What is an SVM ?’

Lookup the lecture sets for the string with the given ‘Question’ keyword and

classify that document for further presentation.

subject the SVM to worst testing environment. The

categories cover ‘bitmap indexing’, ‘climate

conditions’ etc.

The screenshot in fig.1.above shows the runtime

environment while the table 2 indicates the success

results obtained on testing the SVM trained on ten

documents using first order polynomial as the kernel

function. Of the ten input documents, five are about

Bitmap indexing and the remaining files are about

irrelevant matter.

E-Learning Application Scenario

Here we briefly present the use of SVM in the

context of larger perspective of learner centered E-

Learning frameworks wherein adaptivity and

student/learner context is to be perceived prior to the

delivery of content. The table 3 above provides a

brief glimpse of one such possible framework. The

digital content takes the form of Text( slides, books),

Graphics, videos and the student requirement is to

extract only the needed material.Such techniques are

making the E-learning systems increasingly dynamic

with features exhibiting the human tutor

characteristics. The various documents and data

relevant to a course of study are digitally preserved

and on request from the user, these data are

presented in the available form with minimal

processing. The learner seeks to acquire tailor made

information as per his choice of keyword. It is here

that the appropriate document classification must

take place so that the classified document forms the

input to the overall personalized E-Learning system.

Analysis

The paucity of space did not permit us to give

complete details. However it is important to note

that text classification is a high dimensional problem

and speeds as well as accuracy are major concerns.

Due to the capability of the SVM to produce

acceptable generalization error even with small size

of training data, they are expected to be better than

the ML techniques like NN, BN etc. at least in the

matter of text classification. Text classification poses

a challenge due to its unique characteristics like–the

vector size being proportional to the vocabulary, and

the rare words having same weight as normal words,

etc. In the case of subjects in engineering stream

these characteristics are further accentuated due to

multi dimensional nature of ‘term meaning’

depending on context. Therefore it is necessary to

employ an efficient technique such as SVM for

categorization of text. The time for the classification

in the tested documents is shown as zero due to

small size of the document and hence the dimension

6 CONCLUSION

In this paper we have presented the detailed use of

SVM and SVM Torch software for categorization of

document in the larger context of E-Learning

frameworks. The results were slightly optimistic due

to smaller number and size of test documents. The

number of support vectors was 11 and the dimension

was 611.The reports of other techniques used for

classification like Naïve Bayesian, Neural Networks,

Decision Trees also provide encouraging results.

However the SVM approach to classification is

expected to be superior from the point of view of

size of training data particularly for text

classification tasks where high dimensionality and

speed are major concerns. Specifically, SVMs could

yield acceptable generalization errors even with

small size training data as compared to the

ELECTRONIC DOCUMENT CLASSIFICATION USING SUPPORT VECTOR MACHINE-AN APPLICATION FOR

E-LEARNING

197

techniques like NN and BN. The use of Reduced Set

SVM could further enhance the speed of the

classification. Our next work covers the effect of

natural languages and context on the SVM vector

size and dimensionality issues.

REFERENCES

Vapnik,V.,1995 The Nature of Statistical Learning

Theory,

Gunn, S.R., Brown, M., and Bossley, K.M.,1997,

Network performance assessment for neurofuzzy data

modeling, Intelligent Data Analysis, volume 1208 of

Lecture Notes in Computer Science, pages 313–323.

Vapnik,V., Golowich,S., Smola,A., 1997 Support vector

method for function approximation, regression

estimation, and signal processing, In M. Mozer, M.

Jordan, and T. Petsche, editors, Advances in Neural

Information Processing Systems 9, pages 281–287,

Cambridge, MA, MIT Press.

Poggio,T., Torre,V.,Koch,C.,1985 Computational vision

and regularization theory, Nature, 314–319.

Hadamard,J.,1923, Lectures on the Cauchy Problem in

Linear Partial Differential Equations, Yale University

Press.

Vapnik,V., 1998, Statistical Learning Theory, Springer,

N.Y.

Minoux,M.,1986, Mathematical Programming: Theory

and Algorithms, John Wiley and Sons.

Drucker,H., Donghui Wu, Vapnik,V.N.,1999, Support

Vector Machines for Spam Categorization,

Proceedings of the IEEE Transaction on Neural

Networks, vol. 10, no. 5, September.

Aronszajn,N.,1950 Theory of reproducing kernels, Trans.

Amer. Math. Soc., 686:337–404.

Girosi,F.,1997, An equivalence between sparse

approximation and Support Vector Machines, A.I.

Memo 1606, MIT Artificial Intelligence Laboratory.

Heckman, N.,1997, The theory and application of

penalized least squares methods or reproducing kernel

hilbert spaces made easy.

Wahba,G.,1990 Spline Models for Observational Data.

Series in Applied Mathematics, Vol. 59, SIAM,

Philadelphia.

www.support-vector.com.

ICEIS 2005 - SPECIAL SESSION ON EFFICACY OF E-LEARNING SYSTEMS

198
