Bagging KNN Classiﬁers using Different Expert Fusion

Strategies

Amer. J. AlBaghdadi and Fuad M. Alkoot

Telecommunication and Navigation Institute

P.O.Box 6866, Hawally,32043, Kuwait

Abstract. An experimental evaluation of Bagging K-nearest neighbor classiﬁers

(KNN) is performed. The goal is to investigate whether varying soft methods of

aggregation would yield better results than Sum and Vote. We evaluate the per-

formance of Sum, Product, MProduct, Minimum, Maximum, Median and Vote

under varying parameters. The results over different training set sizes show minor

improvement due to combining using Sum and MProduct. At very small sample

size no improvement is achieved from bagging KNN classiﬁers. While Minimum

and Maximum do not improve at almost any training set size, Vote and Median

showed an improvement when larger training set sizes were tested. Reducing the

number of features at large training set size improved the performance of the

leading fusion strategies.

1 Introduction

Bagging Predictors [4], proposed by Breiman is a method of generating multiple ver-

sions of a predictor or classiﬁer, via bootstraping and then using those to get an aggre-

gated classiﬁer. Methods of combining suggested by Breiman are Voting when classiﬁer

outputs are labels, and Averaging when classiﬁer outputs are numerical measurements.

The multiple versions of classiﬁers are formed by making bootstrap [8] replicas of the

training set, and these are then used to train additional experts. He postulates the nec-

essary condition for bagging to improve accuracy as a perturbation of the learning set

causes signiﬁcant changes in the classiﬁer, namely the classiﬁer must be unstable. Bag-

ging has been successfully applied to practical cases to improve the performance of

unstable classiﬁers. A sample of such papers includes [6]. Many have investigated its

performance and compared it to boosting or other methods [9, 12,7,2,13, 5]

Breimans results [4] show that bagging more than 25 replicas does not further im-

prove the performance. He also notes that a fewer replicas are required when the classi-

ﬁer outputs are numerical results rather than labels, but more are required as the number

of classes increases. Regarding the bootstrap training set size, he used the size equal to

the cardinality of the original training set and his tests showed no improvement when

the boot training set was double the size of the original training set.

In this paper we Bagg K-NN classiﬁers, in order to ﬁnd whether it is possible to

achieve an improvement under varying parameters. We focus on the small training set

case in which the KNN classiﬁer can be expected to be unstable. We aggregate the

generated bootstrap sets using six different methods, namely: Sum, Product, MProduct,

J. AlBaghdadi A. and M. Alkoot F. (2005).

Bagging KNN Classiﬁers using Different Expert Fusion Strategies.

In Proceedings of the 5th International Workshop on Pattern Recognition in Information Systems, pages 219-224

DOI: 10.5220/0002572002190224

 SciTePress

Minimum, Maximum, Median and Vote. MProduct is a method proposed by [1] which

improves Product under small sample size situations where the veto effect exists. The

rest of the rules are commonly used [11, 10]. We repeat the experiments under varying

feature set sizes and training set sizes. In our experiments one synthetic, two class, sym-

metric data set, was used, in addition to nine real data sets which were obtained from the

UCI- Repository, via the web [3]. We follow Breimans guidelines in our experiments

and limit the bagging to 25 bootstrap sets using a training set size equal to the size of

the original training set. K is selected to be the square root of the number of training

samples N in a bootstrap or learning set,i.e. K =

√

N . We evaluate the performance of

the adopted fusion strategies under varying parameters. The results over varying train-

ing set sizes show minor improvement due to bagging in conjunction with the Sum and

MProduct combination rules. At very small sample size, no improvement is achieved

from bagging KNN classiﬁers. While Minimum and Maximum do not improve for al-

most any training set size, Vote and Median show an improvement when larger training

set sizes were tested.

This paper is organized as follows; In section 2 the experiment methodology, data

types used and the method of calculating expert error rates are explained. Experimental

results are presented in section 3. Discussion of the obtained results and the conclusion

are noted in sections 4 and 5, respectively.

2 Experiments

2.1 The Synthetic Data Set

Controlled experiments were carried out using the computer generated data set involv-

ing two features and two classes. The two class densities have an overlap area which

was designed to achieve the maximum instability of the class boundary. The theoretical

Bayes error of this data set is 6.67%. Using the generated samples the empirical Bayes

error was found to be 6.82.

2.2 Methodology

A single training set is taken from the original sample space, The K-NN classiﬁer built

using this original learning set is referred to as the single expert. From the remaining

samples 600 randomly selected samples were used as a test set. Using the learning set,

25 boot sets are generated, by sampling randomly with replacement, i.e. by bootstrap-

ping. The decision of the 25 boot sets are aggregated to classify a test set. These results

are referred to as the bagged expert results. We wish to compare these results to those

obtained from the single expert.

The above is repeated for varying training set sizes. When applied to real world

data, relatively similar percentages of samples from the original data set were used for

the learning set. In Contrast to the synthetic data experiment, all the remaining samples

were used as the test set.

220

Table 1. Data sets and the number of training samples used for each data set. Under the training

set size columns, the ﬁrst row indicates the number of samples, while the second row indicates

the training size in percentage.

Data Name Total No. of samples No. of features Training set size

Synthetic 1231 2 12 25 49 86 123 616

1 2 4 7 10 50

Diabet 768 8 8 15 31 54 77 614

1 2 4 7 10 80

Breast cancer 699 9 7 14 28 49 70 559

1 2 4 7 10 80

Ionosphere 351 34 4 7 14 25 35 281

1 2 4 7 10 80

Liver disorder 345 6 3 7 14 24 35 276

1 2 4 7 10 80

Ecoli 336 7 3 7 13 24 34 269

1 2 4 7 10 80

Wine 178 13 4 7 12 18 89 142

2 4 7 10 50 80

Iris 150 4 6 11 15 45 75 120

4 7 10 30 50 80

Lung Cancer 32 56 3 6 10 16 26 -

10 20 30 50 80 -

Lens 24 4 2 7 12 19 - -

10 30 50 80 - -

3 Results

3.1 Using Synthetic data

The results for the best combiner, i.e. MProduct, are summarized in table 2. The results

indicate that Maximum and Minimum have the highest error rates, and were never better

than the single expert. Only for a very small sample size of 12 samples, did the single

expert outperform all combiners. In all other sizes Sum and MProduct were the best

rules, followed by Median and Vote, which were identical. Product was the most sen-

sitive to the training set size. At low set sizes it performed as bad as Minimum, while

at large training set sizes, it performed close to Sum and MProduct. At medium size

ranges it was much better than Minimum but not always better than the single expert.

This behavior of Product was consistent for all data sets used. For all set sizes we notice

that Median and Vote have identical performance and mostly lag behind Sum, but are

very close. Maximum and Minimum give relatively close results. As we decrease the

learning set size the error rate of all rules increased. However, bagging did improve the

KNN performance at larger training set sizes, although the amount of improvement de-

creased as the set size increased. An improvement is considered signiﬁcant if it is larger

than:

e(1−e)

, where N is the number of test samples used.

3.2 Using Real data

The above tests were repeated using real data obtained from the UCI repository, [3].

The performance of the rules when using the diabetic, liver, lens, ecoli, wine and iris

data is similar to when using the synthetic data. For brease cancer Sum and Mproduct

221

Table 2. Difference between single expert error rate and combiner error rate decreases as the

training set size increases for the synthetic data experiment

Training set size 12 25 49 86 123 616

Improvement in percent over single KNN -0.2598 0.0624 0.0277 0.047 0.0187 0.0112

Signiﬁcance 0.0174 0.0137 0.0125 0.012 0.0114 0.0108

had an error rate lower than the KNN single expert, by .02, but only for training set

sizes above 10%. Otherwise, the single expert outperformed all aggregation methods.

For the Ionosphere data they showed a very variable performance from one training

size to another. MProduct and Sum were best at three sizes. Vote at one, Minimum and

Maximum at one and the single expert at the largest training set size. The lung cancer

was a very difﬁcult data, with small number of samples and a very large dimension of

56 features. At small sizes MProduct and Sum were better than the single expert, but at

larger sizes the single expert was better.

3.3 Reduced features

When we randomly reduced the number of features used for each of the real data sets,

we did not notice any change in the relative performance of the rules. An exception was

observed for the training set size of 80%. In this case the relative performance changes

as the number of features used is reduced.

We repeated the experiments for a reduced number of features, equaling to half the

total number of features available, and ﬁnally reduced to 2 features. Contrary to our

expectation reducing the number of features did not always increase the error rates. For

the BCW and Iris data sets we observed the error rate to increase as the number of

features is decreased. On the other hand for the diabetic data we observed the error rate

to decrease as the number of features is reduced to 4. When it was reduced to 2 we

still had an improvement over the full feature set experiment, but not over the 4 feature

experiments. Although the relative performance did not change when four features were

used at a training set size of 80%, the Sum and MProduct were no longer better than the

single expert. They exhibited error .01% higher. These discrepancies point to the need

of more investigation in this regard.

4 Discussion

The aggregation method which was the most sensitive to the training set size was Prod-

uct. It improves at larger set sizes, and sometimes reaches the best performance pos-

sible, while at small set sizes it performed worse than all the other rules in line with

Minimum and Maximum.

The results over the varying training set sizes show minor improvement due to bag-

ging and combining using Sum and MProduct. While Minimum and Maximum do not

improve at almost any training set size, Vote and Median, in general, show an improve-

ment for larger set sizes. Vote was the best for three data sets when a very small training

set size was tested.

222

Between the six aggregation methods MProduct had the best overall performance

followed very closely by Sum. Vote had very bad performance at many phases of the

experiment. This suggests that one should be using an aggregation method other than

Voting if level III information is available. Classiﬁers producing level III outputs are

ones that output measurement values in addition to the ranked labels.

Table 3. The best performance rule as a function of training set size. Initial letters have been

used to indicate each rule. SE:single expert, S:Sum, M:MProduct, P:Product, MX:Maximum,

MN:Minimum, V:Vote, MD:Median

Data name Training set size

1 2 3 4 5 6

Artiﬁcial data SE M & S M & S M & S M & S M & S

Pima Indian Diabetes SE M & S M & S M & S M & S M, P & S

Wisc. Breast Cancer SE SE SE SE M & S M & P

Ionosphere V M & S M & S M & S MN SE

Liver Disorder M & S M & S M & S M & S M & S M & P

Ecoli V M, S & SE M, S & SE M, S & SE M, S P

Wine M & S SE SE M & S M & S M, P & S

Iris V SE M & S M M M, P & S

Lung cancer SE M & S M & S SE SE -

Contact lenses SE M & S M M, S & SE - -

We also notice that Vote performed best three times when data was very noisy, i.e.

for very low training set size (size 1). Also, for the same data set Sum and MProduct

were the best rules at the very low training size. In general Bagging did not work for

very small training set size (size 1). At this size, the single expert was the best for six

out of ten data sets.

5 Conclusion

It is possible to improve the performance of the KNN classiﬁers, especially if MProduct

or Sum are used as an aggregation method.

It was noticed that for very small sample sizes bagging may degrade the perfor-

mance as compared to the single expert. At very small sample sizes the single expert

outperforms the bagged experts because the bootstrap sets often contain samples from

one class only. In such situations the resulting very high error rates dominate the boot-

strap expert outputs and the underlying beneﬁts of bagging are canceled. In order to

beneﬁt from bagging, the investigation should be directed towards methods of selecting

best bootstrapped classiﬁers and ignoring the worst ones.

References

1. F. M. Alkoot and J. Kittler. Improving the performance of the product fusion strategy. In

Proceedings of the ICPR 2000 conference, Barcelona, Spain, 9 2000.

223

2. E. Bauer and R. Kohavi. An empirical comparison of voting classiﬁcation algorithms: Bag-

ging, boosting and varients. Machine Learning, pages 1–38, 1998.

3. C.L. Blake and C.J. Merz. UCI repository of machine learning databases, 1998.

4. L. Breiman. Bagging predictors. Machine Learning, 24:123–140, 1996.

5. L. Breiman. Bias, variance and arcing classiﬁers. Technical Report 460, Statistics Depart-

ment, University of California at Berkeley, 4 1996.

6. P. deChazal and B. Celler. Improving ecg diagnostic classiﬁcation by combining multiple

neural networks. In Computers in Cardiology, volume 24, pages 473–476. IEEE, 9 1997.

7. T. Dietterich. An experimental comparison of three methods for constructing ensembles of

decision trees: Bagging, boosting, and randomization. Machine Learning, pages 1–22, 1998.

8. B. Efron and R. Tibshirani. An Introduction to the Bootstrap. Chapman and Hall, 1993.

9. T. Heskes. Balancing between bagging and bumping. In M. Mozer, M. Jordan, and

T. Petsche, editors, Advances in Neural Information Processing Systems 9, pages 466–472.

MIT press, 1997.

10. J. Kittler. Combining classiﬁers: A theoretical framework. Pattern Analysis and Applica-

tions, 1:18–27, 1998.

11. J. Kittler, M. Hatef, R. Duin, and J. Matas. On combining classiﬁers. IEEE Trans Pattern

Analysis and Machine Intelligence, 20(3):226–239, 1998.

12. D.W. Opitz and R. F. Maclin. An empirical evaluation of bagging and boosting for artiﬁ-

cial neural networks. In IEEE International Conference on Neural Networks - Conference

Proceedings, volume 3, pages 1401–1405, Univ of Montana, Missoula, MT, USA, 6 1997.

IEEE.

13. J. Quinlan. Bagging, boosting and c4.5. In Proceedings of the 13th National Conference on

Artiﬁcial Intelligence, volume 1, pages 725–730, Portland, OR, USA,, 8 1996. AAAI, Menlo

Park, CA, USA.

224
