A Unit Testing Framework for Network Conﬁgurations

⋆

Dominik Jungo, David Buchmann and Ulrich Ultes-Nitsche

telecommunications, networks & security Research Group

Department of Computer Science, University of Fribourg

Chemin du Mus

ee 3, 1700 Fribourg, Switzerland

Abstract. We present in this paper a unit testing framework for network conﬁg-

urations which veriﬁes that the conﬁguration meets prior deﬁned requirements of

the networks behavior. This framework increases the trust in the correctness, se-

curity and reliability of a networks conﬁguration. Our testing framework is based

on a behavioral simulation approach as it is used in hardware design [1]. The unit

testing framework is part of the SNSF VeriNeC project [2].

1 Introduction

The difﬁculty of administration of networks increases with a network’s size and het-

erogeneity. The VeriNeC project offers a network conﬁguration solution, which tackles

and solves these problems. VeriNeC offers an implementation-independent solution for

conﬁguring nodes in a network using XML as the conﬁguration language. Using an

implementation-independent conﬁguration facility simpliﬁes the task of conﬁguration

and solves the problem of heterogeneity. There is a single conﬁguration facility the ad-

ministrator will use. VeriNeC can handle the conﬁguration of the different nodes and

services in the network from the abstract XML conﬁguration. Therefore it transforms

an abstract XML conﬁguration into an actual conﬁguration and deploys it over a given

conﬁguration facility such as SNMP, SSH, SCP or any other.

VeriNeC offers a centralized conﬁguration facility integrated into a graphical user

interface, which helps to reduce the problem of handling vast networks. But there is

more to VeriNeC: Large network conﬁgurations suffer easily from misconﬁguration,

causing the network to behave in an undesired way. A simulator facilitates testing ex-

isting applications in the conﬁgured network and helps understanding the behavior re-

sulting from a given conﬁguration. Misconﬁguration can also lead to security holes in

a network. Such security holes comprise unnecessary availability of services, unneces-

sary open ﬁrewall ports, unnecessary or wrong entries in a routing table, transport of

security relevant data over unencrypted and insecure channels, and the use of empty or

weak passwords.

This paper presents a tool for testing automatically a network’s conﬁguration with

respect to a given set of tests; i.e. a unit testing framework for network conﬁguration,

which helps to increase trust in the correctness, security and reliability of a network.

⋆

Supported by the Swiss National Science Foundation under grant number 200021-100645/1.

Jungo D., Buchmann D. and Ultes-Nitsche U. (2005).

A Unit Testing Framework for Network Conﬁgurations.

In Proceedings of the 3rd International Workshop on Modelling, Simulation, Veriﬁcation and Validation of Enterprise Information Systems, pages 77-82

DOI: 10.5220/0002573500770082

 SciTePress

2 Network Conﬁguration

Network nodes and the services they provide are conﬁgured using an XML syntax.

As we want to focus on functionality of services and not speciﬁc products, the XML

schema is an abstract representation of actual implementations, representing all kinds

of features found in concrete conﬁgurations of given service implementations. To con-

ﬁgure actual devices, the Translator module is used to generate implementation speciﬁc

conﬁgurations.

A node conﬁguration consists of a section for its hardware setup and a list of ser-

vices it runs. Services are for example a server for the domain name system (DNS) or a

chain-ruled packet-ﬁltering ﬁrewall. We aimed at identifying the important features of

each service and at expressing them conceptually in the schemas. Using VeriNeC, one

does not conﬁgure a bind8 DNS server, but just the information needed to automatically

generate the necessary conﬁguration ﬁles for various target platforms.

2.1 Applying the Conﬁguration

As the aim of VeriNeC is ﬁnally to conﬁgure a real network, the abstract XML network

conﬁguration needs to be distributed, applying it to actual machines.

Applying the conﬁguration is divided into two parts. The ﬁrst is the conﬁguration

language/grammar which is used natively to conﬁgure the node. This can be a Unix-

style conﬁguration ﬁle, an ini ﬁle, a batch ﬁle for an SNMP client, a batch ﬁle for Win-

dows Management Instrumentation (WMI), a bunch of registry settings or any other

kind of conﬁguration syntax used in the actual conﬁguration context. The second part

considers the protocol with which the conﬁguration ﬁle is distributed to the target ma-

chine. Such protocols can be simple ﬁle transfer protocols such as (s)ftp or smb to

transfer plain-text conﬁguration ﬁles, ssh, rsh and rexec to execute remote commands,

SNMP to transmit the conﬁgurations, or any other existing conﬁguration protocol. Split-

ting the conﬁguration process into translating the XML to device speciﬁc conﬁguration

data and deploying that data to the machines makes that process modular, highly ﬂexible

and extensible.

The conﬁguration schema deﬁnes the data structure for deployment. It contains

commands to execute before and after the conﬁguration data is applied, information

on the deployment method, and the device speciﬁc conﬁguration data to deploy. Con-

ﬁguration data can either be the content in a plain text ﬁle or arbitrary

XML.

The actual translation from abstract XML conﬁguration ﬁles to conﬁguration doc-

uments uses the XML style sheets transformation [3] language. There is one translator

document for each implementation of each service. XSLT documents for new services

or new implementations of an existing service can easily be added to extend VeriNeC.

Translation is the point where we may encounter implementation speciﬁc problems.

Some implementations of a service may not support all features that can be expressed

in the abstract XML conﬁguration. VeriNeC tells the user whether he/she will lose

conﬁguration details using service implementation speciﬁc restrictors. The restrictors

Of course, the deployment implementation must know what to do with this XML, so it better

won’t really be arbitrary

are implemented as XSLT documents, generating warnings for problematic tags in the

abstract conﬁguration.

The deployment is implemented in Java. A distributor pushes the conﬁguration data

generated by the translation process to the target system.

The translators generate device speciﬁc data, the distributor is however very generic.

This allows to keep the number of deployment mechanisms small. We can use one for

ﬁle distribution using various ﬁle transfer protocols and others for the conﬁguration

protocols SNMP and WMI.

3 Simulation

The network simulator [4] was initially developed to test the behavior of a conﬁguration.

The simulator is a partial rebuild of the Internet layer model [5]. We have chosen the

discrete event-based simulation framework desmoj [6] to model the network, because

desmoj allows to combine the event-based approach with the process-oriented simula-

tion approach. We have implemented stateless protocols as event driven-modules and

stateful protocols as process-driven modules. The simulator consists of a set of net-

work nodes and services that can be conﬁgured using the VeriNeC XML conﬁguration

format.

3.1 The Simulator’s Architecture

The network simulator is a partial rebuild of the Internet layer model with some of

its protocols. As interface to existing applications we have chosen Java sockets with

extended functionality. This makes it possible to use any existing application using Java

sockets together with the simulator. During the simulation we replace the default factory

by a factory that creates Socket implementations which redirect the whole trafﬁc to the

simulator. Because the Java sockets are constructed by means of the SocketImplFactory,

any Java application using Java sockets redirects its trafﬁc via the simulator sockets to

the simulator, allowing the use of any socket application within the simulator. This

helps us avoiding implementing these applications ourselves and allows testing any

application on the network with the simulator.

The simulator offers the possibility to test whether any given application works

within the conﬁgured network as expected. A graphical user interface [7] displays the

simulator’s log ﬁle by means of graphical animation, which helps to understand why a

conﬁguration part behaves in a certain way.

The network simulator needs events that start a simulation. Such input events can

be any of the schedulable events in the simulator. Sending, receiving, dropping, and

routing a packet, launching, or ﬁnishing an application are some of the existing events

that can initially be fed into the simulator. Interesting are events that cause other events.

Initially the simulator schedules the input events within the used simulation frame-

work, which are then ﬁred on the scheduled time. Normally each event causes other

E.g. sending an IP Packet causes creating layer 2 events by sending the IP Packet over a layer 2

protocol, receiving the IP Packet, and passing its data to a higher-level protocol, causing layer

4 events as well.

<event time="0" node="client" layer="5" service="application"

src="client" dst="webserver" id="unique1">

<application program="wget" parameters="http://webserver/index.html"

type="launch"/>

<event time="2" node="client" layer="4" service="udp" id="unique1"

packetid="dns1" src="134.21.3.8" dst="134.21.6.8">

</events>

Fig.1. A sample output ﬁle of a HTTP client causing a DNS lookup

events to happen. Figure 1 shows the result of the processed input event. It shows a tree

structure of events with the initial input event as the root. A child event is an event that

is caused by its parent. Each event gives hints about which conﬁguration part caused

the node or service to behave the way it did. This can be a single conﬁguration rule or

a set of rules. These hints help the user to debug the conﬁguration with respect to the

observed (simulated) protocol run initiated by the root event.

The simulator output is hardly human readable and comprehensible. Therefore an

animated graphical user interface displays all events of interest.

4 Veriﬁcation

The Simulator with its GUI helps to understand the effects of a network conﬁguration

and helps to ﬁnd out why the conﬁguration may not work as desired. It is, however, not

suitable to verify automatically whether a conﬁguration satisﬁes a given set of proper-

ties. Therefore a unit testing framework for the network conﬁgurations was chosen to

carry out the task of testing the network conﬁgurations. The unit testing framework for

the network conﬁgurations uses the services of the earlier described network simulator

to test the behavior against a given list of rules with desired behavior.

4.1 A Low-level Veriﬁcation Language

Test cases are generally structured in ﬁve phases: Before any simulation is run, checks

can be executed on each node that concern the conﬁguration itself (so-called static

analysis) and not its impact on the behavior. A candidate for such a test is the test for

weak passwords. The password attributes are chosen by an xpath expression. Within

the configtest element there exist a couple of possible tests like the password test,

which are implemented in Java.

In the second phase a series of tests is executed which should test, whether the

simulation could reach expected goals. For example, we test whether the HTTP daemon

is running on the server node. These tests are within the pretest elements. Figure 2

presents a test whether or not the HTTP daemon is running on port 80 on the destination

host. If we did not test this and at a later stage a simulation failed because no HTTP is

running on the server node, we would have no information about why the test failed.

The next phase is the setup phase, where the whole testing environment is set up and

the input events are scheduled. This is followed by execution of the test in the testing

environment against a given set of properties. As a last step, the testing environments is

deconstructed.

Figure 2 shows a network conﬁguration test example. A test consist of a conﬁgu-

ration which is referenced by the conﬁguration attribute in the testcase element. The

input event element contains a list of input events which are fed into the simulator. The

simulation’s resulting log can then be explored by a series of tests, which consist of

xpath expressions and a target value, which the xpath expression should evaluate to in

order for the test to pass. On failing tests, the output from the simulator gives hints

about which conﬁguration part caused the node or service to behave such that the test

failed. Tests need either be grouped by the not, and or the or-operator. Existing test

expressions are: assertequals, assertcontains and assertexists.

<weakpassword node="webserver"

password="/node/services/authentication/user/@password" />

</configtests>

<and><assertequals node="webserver" expression="/node/services/httpd/@port"

expectedresult="80" /></and>

</pretest>

<test>

<or><assertexist expression="//event[@src=’client’ and @dst=’webserver’]

/application[@program=’wget’ and @type=’success’]"></or>

</test>

</testcase>

Fig.2. An example that ensures the availability of the HTTP service from a given node

The pretest concerns tests that are executed prior to the simulation tests. Pretests

cover tests directly related to the static conﬁguration information. Candidates for these

tests are checking for weak passwords or testing whether a required service for a tests

is conﬁgured and running. Within a test case, there exist two special nodes, named ex-

ample.com and eve.com, which both represent nodes on the Internet, but which do not

exist in the network conﬁguration itself. On example.com, a number of services are

running. Its purpose is testing the reachability of these services on the Internet. exam-

ple.com is connected to the network Internet. Each node directly connected to this net-

work should reach example.com. The other special node, eve.com, which represents the

evil (wo)man-in-the-middle, snifﬁng every unencrypted (or weakly encrypted

) packet

passing the Internet, is also directly connected to the Internet. eve.com is directly con-

nected to each unencrypted (or weakly encrypted) wireless LAN and listens passively

to each packet which passes such a network. In the network testing unit, eve.com helps

ﬁnding conﬁguration problems where conﬁdential data can be read by means of sniff-

Weakly encrypted means that the encryption can be broken easily and the transmitted messages

are not properly protected.

ing. eve.com can also try to attack the network actively from the Internet or through

wireless connections, by trying to connect to any service in the network and sending

faked or invalid packets.

5 Conclusion

The immense complexity of network conﬁguration makes using a formal veriﬁcation

mechanism difﬁcult. The complexity of formal network veriﬁcation results from the

complex functionality of nodes and services in a network, the amount of conﬁguration

information and its impact on network behavior, and the vast size of networks and

conﬁguration ﬁles.

To cater for the practical impossibility to formally verify the network behaviour

fully formally, we have developed a test framework based on a network simulator, which

simulates the behavior of a network with respect to a given conﬁguration. The correct

behavior of the conﬁgured network is deﬁned as a set of constraints that must be met by

the network conﬁguration. A constraint can be, for instance, the availability of a given

service from every node inside a company’s private network, which must be invisible to

the outside. The set of possible constraints depends on the network and the used under-

lying simulation techniques. Possible future extensions to our approach are constraints

on data throughput — network throughput has been neglected up to now in the VeriNeC

context for the sake of focussing on functional network behavior (e.g. correct routing,

packet ﬁltering, etc.).

References

1. Haque, K., Michelson: The Art of Veriﬁcation With Vera. Veriﬁcation Central (2001)

2. Ultes-Nitsche, U., Jungo, D., Buchmann, D.: Veriﬁed network conﬁguration. Technical report,

University of Fribourg, http://diuf.unifr.ch/tns/projects/verinec/ (2004–2005)

3. Clark, J.: Xsl transformations (xslt). Technical report, W3C, http://www.w3.org/TR/xslt

(1999)

4. Jungo, D., Buchmann, D., Ultes-Nitsche, U.: The role of simulation in a network conﬁgura-

tion engineering approach. In: ICICT 2004, Multimedia Services and Underlying Network

Infrastructure, Cairo, Egypt, Information Technology Institute (2004)

5. Tanenbaum, A.S.: Computer Networks. 4th edn. Prentice Hall (2003)

6. Bernd Page, T.L., Claassen, S.: Objektorientierte Simulation in Java mit dem Framework

DESMO-J. BoD GmbH, (Norderstedt)

7. Loeffel, R.: Verinec studio, ein gui fuer den verinec simulator. Bachelor thesis, University of

Fribourg (2004)
