MODELLING ADAPTIVE CONTROLLERS WITH

EVOLVING LOGIC PROGRAMS

Pierangelo Dell’Acqua, Anna Lombardi

Department of Science and Technology (ITN) - Link

oping University

601 74 Norrk

oping, Sweden

ıs Moniz Pereira

Centro de Intelig

encia Artiﬁcial (CENTRIA) - Departamento de Inform

atica, Universidade Nova de Lisboa

2829-516 Caparica, Portugal

Keywords:

Adaptive controllers, non-monotonic reasoning, evolving logic programming.

Abstract:

The paper presents the use of Evolving Logic Programming to model adaptive controllers. The advantage of

using well-deﬁned, self-evolving logic-based controllers is that it is possible to model dynamic environments,

and to formally prove systems’ requirements.

1 INTRODUCTION

Intuitively, an adaptive controller can change its be-

haviour in response to changes in the dynamics of

the process and the disturbances (

Astrom and Witten-

mark, 1990).

One of the ﬁrst approaches proposed for adap-

tive control is gain scheduling, which implements

an open-loop compensation. Other approaches have

been proposed based on model-reference adaptive

system (MRAS) or self-tuning regulator (STR). They

both can be seen as composed of two loops. These

classical approaches to deterministic adaptive control

have some limitations when unknown parameters en-

ter the process model in complicated ways. In this

case, it may be difﬁcult to construct a continuously

parameterized family of candidate controllers.

An alternative approach to control uncertain sys-

tems has been proposed (Hespanha et al., 2003). The

main feature which distinguishes it from conventional

adaptive control is that controller selection is carried

out by means of logic-based switching rather than

continuous tuning. Switching among candidate con-

trollers is performed by a high-level decision maker

called a supervisor, hence the name supervisory con-

trol. The supervisor updates controller parameters

when a new estimate of the process parameters be-

comes available, similarly to the adaptive control par-

adigm, but these events occur at discrete instants of

time. This results in a hybrid closed-loop system.

Another class of adaptive controllers is fuzzy logic

controllers (Mamdani and Baaklini, 1975). They are

based on adaptation algorithm to update parameters of

the controller as classical adaptive control but they are

capable of incorporating linguistic information from

human operators or experts. This characteristic is par-

ticular important for systems with a high degree of un-

certainty, i.e. systems that are difﬁcult to control from

a control theoretical point of view but they are often

successfully controlled by human operator.

Evolving Logic Programming (EVOLP) is an ex-

tension of logic programming (Alferes et al., 2002). It

allows one to model the dynamics of knowledge bases

expressed by programs, as well as speciﬁcations that

dynamically change. In this paper EVOLP is used to

model adaptive controllers. A case study will be illus-

trated where the controller is implemented by using

EVOLP.

The paper is structured as follows: Section 2 in-

troduces the notion of adaptive control with particular

focus on model reference adaptive control and adap-

tive fuzzy control, Section 3 presents the language

and semantics of Evolving Logic Programming. Sec-

tion 4 describes a case study to model adaptive con-

trol systems using evolving language programming.

Finally, Section 5 discusses some future work.

2 ADAPTIVE CONTROL

A deﬁnition of adaptive control that is widely ac-

cepted is (

Astrom and Wittenmark, 1990) a controller

with adjustable parameters and a mechanism for ad-

justing the parameters. An adaptive controller has a

distinct architecture, consisting of two loops: a con-

trol loop and a parameter adjustment loop.

107

Dell’Acqua P., Lombardi A. and Moniz Pereira L. (2006).

MODELLING ADAPTIVE CONTROLLERS WITH EVOLVING LOGIC PROGRAMS.

In Proceedings of the Third International Conference on Informatics in Control, Automation and Robotics, pages 107-112

DOI: 10.5220/0001220501070112

 SciTePress

Model

Adjustment

rule

Controller

Process

Figure 1: Scheme of a model reference adaptive system.

2.1 Model Reference Adaptive

Control

In the model reference adaptive system (MRAS)

(

Astrom and Wittenmark, 1990) the control is spec-

iﬁed in terms of a reference model which tells how

the process output ideally should respond to the com-

mand signal. A block diagram of the system is shown

in Fig. 1.

The regulator system consists of two loops. An

inner loop which is an ordinary feedback loop com-

posed of the process and a controller. The parameters

of the regulator are adjusted by the outer loop in such

a way that the error e between the model output y

and the process output y becomes small. This scheme

is so-called direct approach because the adjustment

rules tell directly how the regulator parameter should

be updated.

The key problem is to determine the adjustment

mechanism so that the process output becomes close

to the model output making the error going to zero.

2.2 Fuzzy Control Systems

Fuzzy logic control (Feng et al., 1997) has proved to

be a successful approach for complex nonlinear sys-

tems. In many cases it has been suggested as an alter-

native approach to conventional control techniques.

Fuzzy logic control techniques represent a means of

both collecting human knowledge and expertise and

dealing with uncertainties in the process of control.

Fuzzy control usually decomposes the complex

system into several subsystem according to the human

expert’s understanding of the system and uses a sim-

ple control law to emulate the human control strategy

in each local operating region. The global control law

is then constructed by combining all the local control

actions through fuzzy membership functions.

Many physical systems are very complex in prac-

tice so that rigorous mathematical models can be very

difﬁcult if not impossible to obtain. However many

physical systems can be expressed in some form of

mathematical model locally, or as an aggregation of

a set of mathematical models. The fuzzy dynamic

model, proposed by Takagi and Sugeno (Takagi and

Sugeno, 1985) is described by fuzzy IF-THEN rules

which locally represent nonlinear systems. The fol-

lowing fuzzy model represents a complex single-

input-single-output system and it includes rules and

local analytic linear models:

: IF

THEN

is F

AND . . . AND z

is F

˙x(t) = A

x(t) + B

u(t)

(t) = C

x(t)

(1)

where i = 1, 2, . . . , m, R

denotes the i−th fuzzy in-

ference rule, m the number of inference rules, F

(j =

1, 2, . . . , s) are fuzzy sets, x(t) ∈ ℜ

the system state

variables, u(t) ∈ ℜ

the system input variables, y

(t)

and (A

, B

, C

) the output and the matrix triple of

the i − th subsystem, and z(t) = [z

, z

, . . . z

] some

measurable system variables.

Let µ

(x(t)) be the normalized membership func-

tion of the inferred fuzzy set F

where

j=1

i=1

= 1 (2)

then the ﬁnal output y(t) of the system is inferred by

taking the weighted average of the outputs y

(t) of

each subsystem, that is

y(t) =

i=1

(t) (3)

It should be noted that the global fuzzy model is non-

linear time-varying since the membership functions

are nonlinear and time-varying in general. The de-

veloped fuzzy model includes two kinds of knowl-

edge: one is the qualitative knowledge represented by

the fuzzy IF-THEN rules, and the other is the quan-

titative knowledge represented by the local dynamic

models. The model has a structure of a two level con-

trol system with the lower level providing basic feed-

back control and the higher level providing supervi-

sory control or scheduling. A basic idea of control

is to design local feedback controllers based on local

models and then construct the global controller from

the local controllers.

In (Feng, 2002) an adaptive control design method

for a class of fuzzy dynamic models has been pro-

posed. The basic idea is to design an adaptive con-

troller in each local region and then construct the

global adaptive controller by suitably integrating the

local adaptive controllers together in such a way

that the global closed-loop adaptive control system

is stable. Adaptive fuzzy control, often called self-

organizing fuzzy control (SOC) (Mamdani and Baak-

lini, 1975), can be classiﬁed as a MRAS. It has a hi-

erarchical structure in which the inner loop is a table

ICINCO 2006 - INTELLIGENT CONTROL SYSTEMS AND OPTIMIZATION

108

based controller and the outer loop is the adjustment

mechanism. The idea behind self-organization is to

let the adjustment mechanism update the values in the

control table on the basis of the current performance

of the controller.

3 EVOLVING LOGIC

PROGRAMMING

In this section we recap the paradigm of Evolving

Logic Programming (EVOLP), a simple though quite

powerful extension of logic programming (Alferes

et al., 2002)

. EVOLP allows to model the dynamics

of knowledge bases expressed by programs, as well

as speciﬁcations that dynamically change.

3.1 Language

To make a logic program evolve one needs some

mechanism for letting older rules be supervened by

more recent ones. That is, one must include a mech-

anism for deletion of previous knowledge. This can

be achieved by permitting negation not just in bod-

ies of rules, but in their heads as well

. Moreover,

one needs a means to state that, under some condi-

tions, some new rule is to be added to the program. In

EVOLP this is achieved by augmenting the language

with a reserved predicate assert/1, whose argument

is itself a rule, so that arbitrary nesting becomes pos-

sible. This predicate can appear both as rule head (to

impose internal assertions of rules) as well as in rule

bodies (to test for assertion of rules).

In the following we let L be any propositional lan-

guage not containing the predicate assert/1. Given

L, the extended language L

is deﬁned inductively as

follows:

• All propositional atoms in L are propositional

atoms in L

• If every L

, . . . , L

(n ≥ 0) is a literal in L

(i.e. a

propositional atom A or its default negation not A),

then L

← L

, . . . , L

is a rule

over L

• If R is a rule over L

, then assert(R) is a propo-

sitional atom of L

• Nothing else is a propositional atom in L

Given a rule L

← L

, . . . , L

, then L

is the head

of the rule, and L

, . . . , L

is the body. Rules with

An implementation of EVOLP is available from

http://centria.fct.unl.pt/˜jja/updates.

A well known extension to normal logic programs (Lif-

schitz and Woo, 1992).

Rules of the form L

← L

, . . . , L

, where each L

a literal, are typically called generalized logic programming

rules.

empty body (that is, n = 0) are written as L

← and

are called facts.

An evolving logic program over L is a (possibly

inﬁnite) set of rules over L

. Consider the two rules:

assert(not a ← b) ← not c

a ← assert(b ←)

Intuitively, the ﬁrst rule states that, if c is false, then

the rule not a ← b must be asserted. The 2nd rule

states that, if the fact b ← is going to be asserted, then

a is true.

The language L

allows one to model the knowl-

edge base self-evolution. What is needed now is a

way to make the system aware of events that happen

outside it, e.g., the observation of facts (or rules) that

are perceived at some state or assertion commands

imparting the assertion of new rules on the evolving

program. Both observations and assertion commands

can be represented as EVOLP rules: the former by

rules without the assert predicate in the head, and the

latter by rules with it. Thus, in EVOLP outside in-

ﬂuence can be represented as a sequence of sets of

EVOLP rules. This leads us to the following notion.

An event sequence E over an evolving logic program

P is a sequence of evolving logic programs over the

language L of P .

3.2 Semantics

The meaning of a sequence of EVOLP programs is

given by a set of evolution stable models, each of

which is a sequence of interpretations. The basic idea

is that each evolution stable model describes some

possible evolution of one initial program after a given

number n of evolution steps with respect to an event

sequence E.

The construction of these program sequences is as

follows: whenever the atom assert(Rule) belongs

to an interpretation in a sequence, i.e. belongs to a

model according to the stable model semantics of the

current program, then Rule must belong to the pro-

gram in the next state; asserts in bodies are treated as

any other predicate literals.

Program sequences are treated as in the framework

of dynamic logic program (DLP). A dynamic logic

program P

◦ · · · ◦ P

is a sequence of generalized

logic programs (P

being the most recent one). The

idea of DLP is that the most recent rules (i.e., the

ones belonging to the most recent programs in the se-

quence) are set in force, and previous rules are valid

(by inertia) insofar as possible, i.e. they are kept for

as long as they do not conﬂict with more recent ones.

For the formal deﬁnition of the declarative and proce-

dural semantics of DLP see (Alferes et al., 2000).

MODELLING ADAPTIVE CONTROLLERS WITH EVOLVING LOGIC PROGRAMS

109

Consider the program P :

a ←

assert(b ← a) ← not c

c ← assert(not a ←)

assert(not a ←) ← b

For simplicity suppose that all events in E are empty.

The (only) stable model of P is I = {a, assert(b ←

a)} and it conveys the information that program P is

ready to evolve into a new program P ◦ P

by adding

rule (b ← a) at the next step, i.e. in P

. In the only

stable model I

of the new program P ◦ P

, atom b

is true as well as atom assert(not a ←) and also c,

meaning that P ◦ P

is ready to evolve into a new

program P ◦ P

◦ P

by adding rule (not a ←) at the

next step, i.e. in P

. Now, the (negative) fact not a ←

in P

conﬂicts with the fact a ← in P , and so this

older fact is rejected. The rule added in P

remains

valid, but is no longer useful to conclude b, since a is

no longer valid. So, assert(not a ←) and c are also

no longer true. In the only stable model of the last

sequence both a, b, and c are false.

This example simpliﬁes the problem of deﬁning

the semantics in that it does not consider the inﬂu-

ence of events from the outside. In fact, as stated

above, all those events are empty. To take into con-

sideration outside events, the rules that came in the

i-th event are added to the program of state i. Sup-

pose that at state 2 there is an event from the outside

= {assert(d ← b) ← a; e ←}. Since the

only stable model of P is I = {a, assert(b ← a)}

and there is an outside event at state 2, the program

should evolve into the new program obtained by up-

dating P not only with the rule b ← a but also with

the rules in E

, i.e. P ◦ {b ← a; assert(d ← b) ←

a; e ←}. The only stable model I

of this pro-

gram is now {a, b, e, assert(not a ←), assert(d ←

b), assert(b ← a)}.

In EVOLP the rules coming from the outside, be

they observations or assertion commands, are under-

stood as events given at a certain state, but which are

not to persist by inertia. That is, if a rule R belongs

to an event E

of an event sequence E, then R was

perceived after i − 1 evolution steps of the program,

and this perception event is not to be assumed by iner-

tia from then onward. Thus, in the previous example,

when constructing subsequent states, the rules com-

ing from events in state 2 should no longer be avail-

able and considered. This understanding is formal-

ized as follows.

An evolution interpretation of length n of an evolv-

ing logic program P over L is a ﬁnite sequence

I = hI

, I

, . . . , I

i of sets of propositional atoms

of L

. The evolution trace associated with an evo-

lution interpretation I is the sequence of programs

, P

, . . . , P

i where:

= P and P

= {R | assert(R) ∈ I

i−1

}

for each 2 ≤ i ≤ n. An evolution interpre-

tation of length n, hI

, I

, . . . , I

i, with evolution

trace hP

, P

, . . . , P

i, is an evolution stable model

of P given E = hE

, E

, . . . , E

i iff for every i

(1 ≤ i ≤ n), I

is a stable model at state i of

◦ P

· · · ◦ (P

∪ E

Notice that the rules coming from the outside in-

deed do not persist by inertia. At any given state i,

the rules from E

are added to P

and the (possibly

various) stable models I

are calculated. This deter-

mines the programs P

i+1

of the trace, which are then

added to E

i+1

to determine the stable models I

i+1

Being based on stable models, evolving logic pro-

grams may have various evolution stable models, as

well as no evolution stable models at all. Consider

the following program:

assert(a ←) ← not assert(b ←), not b

assert(b ←) ← not assert(a ←), not a

it has two evolution stable models of length 3 wrt. the

event sequence E = h∅, ∅, ∅i of empty events. Each

model represents one possible evolution of the pro-

gram:

h{assert(a ←)}, {a, assert(a ←)}, {a, assert(a ←)}i

h{assert(b ←)}, {b, assert(b ←)}, {b, assert(b ←)}i

Given an evolution trace hP

, . . . , P

i and an event

sequence E = hE

, . . . , E

i, a state i (1 ≤ i ≤ n) is

deterministic iff P

◦ P

◦ · · · ◦ (P

∪ E

) has a unique

stable model. P is deterministic wrt. E iff every state

i is deterministic.

Since various evolutions may exist for a given

length, evolution stable models alone do not deter-

mine a truth relation. But one such truth relation can

be deﬁned, as usual, based on the intersection of mod-

els. One important case is when the program is strat-

iﬁed, for then there is a single stable model, and a

deterministic evolution.

Given a program P and an event sequence E of

length n, a propositional atom A is: true iff A ∈ I

for every evolution stable model hI

, I

, . . . , I

i of

P and E; false iff A 6∈ I

for every evolution stable

model hI

, I

, . . . , I

i of P and E; unknown other-

wise.

4 MODELLING ADAPTIVE

CONTROLLERS WITH EVOLP

The simplest way to model an adaptive logic-based

controller is to employ EVOLP as the language of

the controller as illustrated in Fig. 2. In this case,

we have a discrete, adaptive controller governed by

logic-based rules. This scheme can be seen as a sim-

pliﬁed version of MRAS (see Fig. 1), where the ad-

justment rule block is composed of the logic rules

ICINCO 2006 - INTELLIGENT CONTROL SYSTEMS AND OPTIMIZATION

110

Controller

assert(.)

do(.)

EVOLP

Process

Figure 2: Adaptive logic-based controller.

deﬁning the predicate assert. This makes it possible

that old rules of the controller are replaced by new

rules. The theory of the controller is formalized by

an (initial) evolving logic program that can evolve

via its (internal) assertion commands, and/or via the

input to the controller received as events. The lan-

guage of the controller contains distinguished atoms

expressing the actions the controller wants to execute

on the process/environment through its actuators. We

assume that such atoms take the form do(action). The

intuition is that whenever an atom do(action) is true

at the current state, the corresponding action is per-

formed by the actuator on the process. Then, the out-

put of the process is received by the controller in the

form of facts (or more generally rules) represented as

events. At each state n, the controller considers all

the stable models of P

◦ P

◦ · · · ◦ (P

∪ E

), and (i)

sends to the actuators the actions corresponding to all

the atoms do(action) that are true at n, and (ii) self-

evolves by considering all the atoms assert(R) that

are true.

Example: a controller for a lift

Consider the controller of a lift that receives from out-

side signals of the form push(N), when somebody

pushes the button for going to ﬂoor N, or ﬂoor, when

the lift reaches a new ﬂoor. Upon receipt of a push(N)

signal, the lift records that a request for going to ﬂoor

N is pending:

assert(request(F )) ← push(F )

Mark the difference between this rule and the rule

request(F ) ← push(F ). When the button F is

pushed, with the latter rule request(F ) is true only

at that moment, while with the former request(F )

is asserted to the evolving program so that it remains

inertially true (until its truth is possibly deleted after-

wards).

Based on the pending requests at each moment, the

Rules with variables stand for all their ground in-

stances.

controller must prefer where to go:

going(F ) ← request(F ), not unpref(F ),

not ﬁre

alarm

unpref(F ) ← request(F 2), better(F 2, F )

better(F 1, F 2) ← at(F ), |F 1 − F | < |F 2 − F |

better(F 1, F 2) ← at(F ), |F 1 − F | = |F 2 − F |,

F 2 < F

Notice that the body of the ﬁrst rule above contains

the non-monotonic condition, not ﬁre

alarm. This is

needed to stop the lift (i.e., it makes going(F ) false) in

situations where the event ﬁre

alarm is received from

the outside. Predicate at/1 stores, at each moment,

the number of the ﬂoor where the lift is located. Thus,

if a ﬂoor signal is received, depending on where the

lift is going, at(F ) must be incremented (resp. decre-

mented):

assert(at(F + 1)) ← ﬂoor, at(F ), going(G), G > F

assert(not at(F )) ← ﬂoor, at(F ), going(G), G > F

When the lift reaches the ﬂoor to which it was going,

it must open the door. After that, it must remove the

pending request for going to that ﬂoor:

do(open(F )) ← going(F ), at(F )

assert(not request(F )) ← going(F ), at(F )

Modelling uncertainty

Consider a scenario where one wants to formalize

a controller that monitors the room temperature and

consequently activates a heating device to maintain

the temperature within some speciﬁed range. Assume

that the controller receives contradictory/uncertain

data from its sensors, e.g., it contemporaneously re-

ceives two distinct temperatures x and y whose differ-

ence is greater than a speciﬁed value. The behaviour

of the controller can be deﬁned in such a situation by

a simple rule of the form:

do(action) ← tempA(x), tempB(y), x > y + 5

In other situations, the controller may have incom-

plete knowledge of the outside environment. Suppose

that in the lift example above, the controller receives

a signal that may (or may not) be a ﬂoor signal. This

can be coded as an event consisting of two rules:

ﬂoor ← not no

signal

no signal ← not ﬂoor

At this state there are 2 stable models: one corre-

sponding to the evolution in case the ﬂoor signal is

considered; the other, in case it isn’t. The truth re-

lation can here be used to determine what is certain

despite the undeﬁnedness of the events received, i.e.,

true in every stable model, e.g., what may be triggered

if ﬁre

alarm is also received: do(stop) ← ﬁre alarm.

Properties of the system

Since the controller is axiomatized by logic rules, it

MODELLING ADAPTIVE CONTROLLERS WITH EVOLVING LOGIC PROGRAMS

111

is possible to formally prove a number of properties.

Typically, such properties take one of the following

two forms. Let P be the (initial) evolving logic pro-

gram that axiomatizes the theory of the controller, and

E a (ﬁnite) event sequence representing the input to

the controller.

∀E ∃n. Property (weak)

∀E ∀n. Property (strong)

Reconsider the example of the lift controller. Then,

one can guarantee: (i) the safety condition that the lift

will never open its door if it is not at some ﬂoor by

proving that:

∀E ∀n ∀x. not (open(x) ∧ not at(x))

or (ii) the fairness condition that if the button of a cer-

tain ﬂoor has been pushed, then the lift will eventually

go to that ﬂoor by proving that:

∀E ∃n ∀x. push(x) ⊃ at(x)

It is easy to prove that the above property does not

hold if the policy to handle the pending requests is

the one axiomatized by the rules for going/1.

5 CONCLUSION

In this paper we have addressed the problem of mod-

elling adaptive logic-based controllers by means of

Evolving Logic Programs. One advantage of using

a well-deﬁned, logic-based approach is that it is pos-

sible to formally prove properties of the controller.

Moreover, various forms of logic reasoning (e.g., ab-

duction, hypothetical reasoning, rule mining) can be

integrated into the logic framework and employed to

enhance the controller’s performance in cases where

there is uncertainty due to the complexity of the envi-

ronment.

The use of abduction, a well-developed technique

in the Logic Programming paradigm, will enable us

to diagnose erroneous controller behaviour, by auto-

matically hypothesizing possible faults. Furthermore,

abduction can be employed to prove correctness of a

controller speciﬁcation, by showing that no physically

meaningful hypothesized sequence of events can re-

sult in some integrity violation by the controller, as in

the approach in (de Castro and Pereira, 2004).

Since the semantics of EVOLP is stable model

based, it is possible to characterize uncertainty by

having at a certain state several stable models. This

corresponds to the case where there exist branches in

the evolution stable model of the program. Clearly, it

is possible to guarantee that the program will evolve

into a unique branch by enforcing syntactic restric-

tions on programs. In fact, if the program is stratiﬁed

then there will be only one stable model, and therefore

no branching can occur. This hypothesis is however

unrealistic in most of the cases. A better solution to

the problem would be to exploit preference reasoning

in order to prefer among alternatives when a branch-

ing situation occur. This is possible since preference

reasoning can be employed to prefer among alterna-

tive stable models (Alferes and Pereira, 2000). More-

over, preferences themselves are updatable, and this

empowers a form of meta-control.

Additionally, EVOLP can be used to simulate pos-

sible futures, and then preferences may be used to

chose desired futures or to avoid undesirable ones.

This means one can have lookahead proactive control.

REFERENCES

Alferes, J. J., Brogi, A., Leite, J. A., and Pereira, L. M.

(2002). Evolving logic programs. In Procs. 8th

European Conf. on Logics in Artiﬁcial Intelligence

(JELIA’02), vol. 242 of LNAI, pp. 50–61.

Alferes, J. J., Leite, J. A., Pereira, L. M., Przymusinska,

H., and Przymusinski, T. C. (2000). Dynamic updates

of non-monotonic knowledge bases. The J. of Logic

Programming, 45(1-3):43–70.

Alferes, J. J. and Pereira, L. M. (2000). Updates plus pref-

erences. In Aciego, M. O., de Guzmn, I. P., Brewka,

G., and Pereira, L. M., editors, Logics in AI, Procs.

JELIA’00, LNAI 1919, pp. 345–360.

Astrom, K. J. and Wittenmark, B. (1990). Computer-

Controlled Systems.Theory and Design. Prentice Hall

Internal Inc.

Castro, J. F. and Pereira, L. M. (2004). Abductive validation

of a power-grid expert system diagnoser. In Procs.

17th Int. Conf. on Industrial and Engineering Appli-

cations of Artiﬁcial Intelligence and Expert Systems

(IEA-AIE’04), vol. 3029 of LNAI, pp. 838–847.

Feng, G. (2002). An approach to adaptive control of fuzzy

dynamic systems. IEEE Transactions on Fuzzy Sys-

tems, 10(2):268–275.

Feng, G., Cao, S., Rees, N., and Cheng, C. (1997). Analysis

and design of model based fuzzy control systems. In

Proc. Sixth IEEE Int. Conf. on Fuzzy Systems, vol. 2,

pp. 901 – 906.

Hespanha, J. P., Liberzon, D., and Morse, A. S. Overcom-

ing the limitations of adaptive control by means of

logic-based switching. Systems and Control Letters,

49(1):49-65.

Lifschitz, V. and Woo, T. (1992). Answer sets in gen-

eral non-monotonic reasoning (preliminary report). In

Nebel, B., Rich, C., and Swartout, W., editors, KR’92.

Morgan-Kaufmann.

Mamdani, E. and Baaklini, N. (1975). Prescriptive method

for deriving control policy in a fuzzy-logic controller.

Electronic Letters, 11(25/26):625–626.

Takagi, T. and Sugeno, M. (1985). Fuzzy identiﬁcation of

systems and its applications to modeling and control,

IEEE Trans. Syst. Man. & Cybern., 15(1):116–132.

ICINCO 2006 - INTELLIGENT CONTROL SYSTEMS AND OPTIMIZATION

112
