E-EVALUATION TO DETECT LEARNING WEAKNESS

An Agent Based Architecture

Francisca Losavio

LaTecS Laboratory

Centro ISYS, Universidad Central de Venezuela

Nicole Levy, Parinaz Davari

Laboratoire PRISM

Universite de Versailles St Quentin

Keywords:

E-Evaluation, E-Learning, Agent-Based Software Architecture.

Abstract:

A multi-agent architectural framework for evaluation in e-learning situations is proposed. The idea is to

enable e-learning students to detect precisely their weaknesses in some goals within a course program. A

course is composed of several objectives or goals to be mastered by students; a student can master some, but

not necessarily all of them. Each of these objectives are in turn composed of sub-objectives.

The architecture is focused as a tree of intermediate goals, where each node corresponds to a goal to be

mastered, as each of its sub-goals. The ﬂexibility of the architecture being a major concern, the goals to

be mastered are dynamically deﬁned based on the results of tests passed by the student. The corresponding

educational materials are searched on demand and they can be located anywhere on the Web. The quality

requirements of the architecture are speciﬁed and justiﬁed by a standard quality model. Our approach is

illustrated with a case study of a computer architecture course.

1 INTRODUCTION

Architectural design is a stepwise process which

identiﬁes the key strategies for the large-scale or-

ganization of software systems under development

(Krutchen, 1999). Functional components (derived

from functional requirements) and their crosscutting

concerns (components derived from non functional

requirements) must comply with the quality goals es-

tablished by the system requirements (Kiczales et al.,

1997) (Sousa et al., 2004). We propose and justify

an architectural framework that can be used in mul-

tiple domains related with problem solving, in par-

ticular, with scientiﬁc calculation and auto-evaluation

in education. The classical problem solving divide

and conquer strategy is transformed into a divide and

“reuse” approach. The basic idea is to reuse previous

results that are required in a particular problem solu-

tion. In an e-learning context, the results of an auto-

evaluation situation are the goals that the student has

to master with the corresponding educational mater-

ial and they can be located anywhere on the Web. The

ﬂexibility of the architecture is crucial since the re-

sults must be dynamically obtained on demand. The

quality aspects of the overall architecture are speci-

ﬁed using a standard quality model based on ISO/IEC

9126-1 (ISO/IEC, 2001). This work is part of the EEC

e-Forminfo project.

The goal is to apply the architecture to an auto-

evaluation platform for a continuous formation pro-

gram in the e-learning domain. Students in this edu-

cational program usually have incomplete knowledge

on the different subjects they have to master, but they

are not aware of these deﬁciencies. The evaluation

platform aims at both detect these weaknesses and

provide related e-learning material.

The goals are structured as a tree of intermediate

goals, where each node corresponds to a goal to be

mastered within an educational program, as each of

its sub-goals. Each node corresponding to a goal is

composed by the following information:

• An Evaluation to determine whether the spe-

ciﬁc knowledge related to the node is mastered.

This evaluation depends on some required sub-

knowledge;

• Educational program for a course, introducing or

referencing the sub-goals;

• Educational documents (course literature, exer-

cises, references, etc.);

This document is structured as follows, besides this

introduction: Section 2 describes the requirements for

408

Losavio F., Levy N. and Davari P. (2006).

E-EVALUATION TO DETECT LEARNING WEAKNESS - An Agent Based Architecture.

In Proceedings of WEBIST 2006 - Second International Conference on Web Information Systems and Technologies - Society, e-Business and

e-Government / e-Learning, pages 408-411

DOI: 10.5220/0001255204080411

 SciTePress

an auto evaluation system. Section 3 presents the ar-

chitecture and its justiﬁcation. In section 4 a case

study on an evaluation example is presented. Some

related works are discussed in Section 5. Finally, the

conclusion provides ﬁnal remarks and perspectives.

2 REQUIREMENTS FOR AN

AUTO-EVALUATION SYSTEM

2.1 Requirements Speciﬁcation

The aim of an auto-evaluation system is to help stu-

dents to detect their knowledge gaps or weaknesses

in order to orient them toward parts of the focused

course that they should learn more deeply. Such auto-

evaluation are to be done in particular, when prepar-

ing an examination. Each student is registered in a

group with a speciﬁc goal. To reach this goal the

student has to pass (master) several courses, which

in turn have speciﬁc goals. Advisors must have de-

ﬁned the goals. The tutors are responsible for provid-

ing documental support and the evaluations for each

course. The courses are hierarchically ordered.

Students can be connected to Internet in two differ-

ent modes or situations: prepare for an exam (Train-

ing mode) and pass the exam (Evaluation mode).

Training mode: The student logs to the system

and selects a course or a speciﬁc goal among those

offered by the system. The system must propose to

the student some e-learning material corresponding

to the selected course goals. The student decides to

be evaluated either for the complete course or some

speciﬁc goal within the course. The system gener-

ates automatically a corresponding evaluation. The

student fulﬁlls it. For each wrong answer, the system

points out the non mastered learning goals. There is

no time constraint in this mode; the student can spend

any time he/she wants to study and revise any goal.

He/she must also be able to restart a session in the

same state as he/she left.

Evaluation mode: The student passes the exam.

The system must check whether he has passed the pre-

required courses. The system corrects the exam and

adds the results to the student record. There may be

time constraints in this mode.

2.2 Non functional Requirements

Non functional requirements for this system are:

• Actors communicate through a network browser.

• Students must be precisely identiﬁed.

• Course (and goal) documentation must be avail-

able, updated and retrieved on demand.

• Courses (and goals) must be easily modiﬁed.

• Evaluations (for goals) must be available, updated

and retrieved on demand.

• Students must be offered a legible and customized

information on the goal or subgoals required.

• Response-time is critical in the evaluation mode.

3 AN ARCHITECTURE TO

EVALUATE THE STUDENT

KNOWLEDGE

An architectural solution is proposed to fulﬁll the sys-

tem’s requirements discussed in the previous section.

The proposed architecture models the statical view

of a course as a tree of intermediate objectives or

goals. Each node corresponds to a goal to be mas-

tered by the student, together with mastering all the

sub-objectives required. Some evaluations provided

allows the system to detect the weaknesses in the mas-

tering of the precise goals. Lectures documentation

or bibliographical information can be retrieved when

a goal is not mastered as e-learning material (called

courseware in (Garro and Palopoli, 2002) and educa-

tional content in (Pankratius et al., 2004)).

The basic idea of our architectural framework is

the following: each node represents an objective of a

course, which is presented in a top-down decomposi-

tion, possibly introducing sub-objectives to be learnt

in turn. For a course objective, the system will pro-

pose one of the evaluations to the student. From the

results obtained by the student, the system will de-

duce the sub-goals not yet mastered. The system will

develop the tree introducing sub-objectives associated

to the new nodes required.

Since a natural idiom for encoding and execut-

ing goals is through software agents (Wooldridge and

Jennings, 1995), we propose to use a multi-agent style

for this architecture, and this choice will be justi-

ﬁed on the basis of the quality requirements for each

agent.

3.1 Agents Model

We have identiﬁed three kinds of agents:

Course Agent: A Course Agent represents a

precise objective (a node) and its decomposition

into sub-objectives. It is statically deﬁned (by some

tutor). It knows the course name or course program,

the required context of the e-learning situation and

the reference to an associated Evaluation Agent, all

the sub-goals to be mastered represented by their

respective Course Agent and references to some

e-learning material related to the goal.

E-EVALUATION TO DETECT LEARNING WEAKNESS - An Agent Based Architecture

409

Evaluation Agent: An Evaluation Agent repre-

sents a precise evaluation method. It is statically

deﬁned (by some tutor). It knows the reference to the

Course Agent it will evaluate, the required context

of the e-learning evaluation situation, a method to

generate equivalent evaluations.

Student Course Agent: A student, to evaluate if

he/she masters a current course, will create a Student

Course Agent. This agent will know all the informa-

tion concerning his/her mastering situation concern-

ing the course.

3.2 Evaluating Algorithm

When some student wants to evaluate his/her knowl-

edge, he/she ﬁrst looks for a course objective. The

corresponding Student Course Agent will be created.

This agent will start its own evaluation process.

1. The Student Course Agent looks for Course Agents

corresponding to the objective. The student may

then select one among those found.

2. The Student Course Agent asks for an evaluation

to the Evaluation Agent associated to the chosen

Course Agent.

3. The student fulﬁlls the evaluation.

4. The corresponding Evaluation Agent corrects it and

delivers a result.

5. If it is totally correct the objective is said to be mas-

tered.

6. If some parts of the evaluation failed, then sub-goal

are not mastered and the Agent will create sub-

Student Course Agent associated to their respective

course agents.

7. The student will evaluated himself for all the intro-

duced sub-goals according to the same process.

8. The student can re-execute a new evaluation when-

ever he/she wants, even if the sub-goals are not said

mastered. When re-executing an evaluation, a new

list of sub-goals may be introduced.

Justiﬁcation of the architecture: quality model for

the problem domain and analysis of the agents

quality responsibility

• Modiﬁability: changeability . Both the Course and

the Evaluation agents are responsible of this goal

• Functionality: interoperability, suitability, accu-

racy, security . Interoperability is a common prop-

erty of the agents in a multi-agent architectural

style, where data structure play a central role, such

as for example the standard XML for data ex-

change; the suitability or precise execution of the

required functions on the node, is accomplished by

the Student Course Agent; accuracy is the responsi-

bility of the Evaluation Agent; security is required

for the precise identiﬁcation of the student for the

vice of the multi-agent platform.

• U sability : legibility and operability. They will

be provided by the corresponding GUI component

of the agents involved

• Efﬁciency: time behavior (response-time) .Itis

also provided by the agents communication proto-

col of the multi-agent platform.

We use an Agent oriented architecture to achieve

these non functional properties. Agents hold extensi-

bility and ﬂexibility, meaning that they can be easily

created, destroyed and modiﬁed.

4 EVALUATION IN COMPUTER

ARCHITECTURE

Let us take as example an evaluation in Computer Ar-

chitecture to evaluate the knowledge about parameter

passing in assembly language programming. The im-

portant concepts to be mastered are the following:

Parameters are values that you pass to and from a

procedure. Two major mechanisms for passing data

to and from a procedure are studied: (i) pass by value,

(ii) pass by reference.

Let Search be a procedure needing as parameters

an array tab of at most 100 characters (representing

a long string), an integer n in [0..100] (representing

the size of tab) and a character ch (representing

the one to be searched in tab) and as result res an

integer in [0..101] (representing the address of the

ﬁrst occurrence of ch in tab or n+1 if ch is not

found). Then the following question could be asked:

Give the instructions of the calling program to

put these parameters on the stack

The answers must be written in the following table:

The calling program

Call Search

For each answer to be given by the student, a set of

possible answers are deﬁned. For example for answer

(a), the student can either give: push offset tab

or the two instructions lea bx,tab and push

bx.

In the same way, a possible list of errors are deﬁned

and for each one, a set of badly understood parts of

WEBIST 2006 - E-LEARNING

410

the course. For example, again for the answer (a),

one possible error is ti give as answer push tab.

Then a bad understanding of the difference between

the address denoted by a variable and its value will

be detected and it will be recommended to study the

deﬁnition of a variable, the deﬁnition of the keyword

offset and the deﬁnition of the instruction lea.

We can imagine that when evaluating a student, if

the answer given is not found in one of the possible

answers deﬁned, the system will send it to the tutor

who will complete the evaluation with a new possible

erroneous answer.

5 RELATED WORKS

In the educational problem domain, two main ar-

chitectural styles emerges as solutions: services

oriented architecture (SOA) and multi-agent system

(MAS).

The SOA systems for Learning Technology are

based on the IEEE 1484 Learning Technology Stan-

dard Commitee (LTSC) with the participation of the

Educom’s Instructional Management System (IMS)

projet of the Global Learning Consortium, among

others (Farance and Tonkel, 1998).

Some platforms such as (Garro and Palopoli, 2002)

or (Fern

andez-Caballero et al., 2003) use MAS. In

(Garro and Palopoli, 2002), the agents help enrich-

ing, sharing and circulating organization knowledge

and make the organization dynamic and ﬂexible.

(Fern

andez-Caballero et al., 2003) introduces three

MAS in the architecture: The Interaction MAS, which

captures the user preferences. The Learning MAS

composes the contents for the user in accordance to

the information collected by the Interaction MAS and

the Teaching MAS offers recommendations of how to

enhance the layout of the Engineering course.

In our case, if we consider roughly an agent as an

autonomous software component requiring and pro-

viding services, we can establish a correspondence

between the SOA (Service Oriented Architecture)

style and the multi-agent style: the logical frame-

work properties correspond to the general properties

of the multi-agent style which are accomplished inter-

nally by the agents composing the evaluation system

(Course, Student Course and Evaluation Agents), the

data representation is expressed as an exchange facil-

ity that all the agents should accomplish to achieve in-

teroperability and the communication and interfaces

aspects concern the protocols used by the agents to

communicate among themselves and with its environ-

ment, which is responsibility of the platform used to

implement the style.

6 CONCLUSION

In this paper, we have proposed a multi-agent based

architectural framework to evaluate students knowl-

edge weaknesses in an e-learning context. Modiﬁa-

bility (Flexibility to changes) is the main concern of

our multi-agent architecture, since it must respond to

dynamic changes: evaluation agents must be created

on demand for speciﬁc goals, a student may ask for an

evaluation for any goal in a course and static changes

on the proposed evaluations and on the e-learning ma-

terial can occur at any time. As a consequence, the

contextual properties of our agents must be designed

emphasizing the ﬂexibility aspect. The usability as-

pect must be compliant to the standards imposed by

educational e-learning systems and could be solved

using web services or using a GUI agent. Functional-

ity and efﬁciency will also be considered within the

multi-agent platform implementing the framework.

Let us note that currently, the implementation is an

ongoing work.

REFERENCES

Farance, F. and Tonkel, J. (1998). Learning technology sys-

tems archcitecture (ltsa) speciﬁcation. In Version 4.0,

draft, page http://www.edutool.com/ltsa.

Fern

andez-Caballero, A., L

opez-Jaquero, V., Montero, F.,

and Gonz

alez, P. (2003). Adaptive interactor multi-

agent systems in e-learning/e-teaching on the web. In

ICWE, pages 144–153.

Garro, A. and Palopoli, L. (2002). An xml multi-agent sys-

tem for e-learning and skill management.

ISO/IEC (2001). Software engineering - product quality.

Technical Report IEC 9126-1, ISO.

Kiczales, G., Lamping, J., Mendhekar, A., Maeda, C.,

Lopes, C., Longtier, J.-M., and Irwin, J. (1997).

Aspect-oriented programming. In Matsouka, M. A.

. S., editor, ECOOP97 Object-Oriented Program-

ming, pages 220–242. LNCS,vol. 1241.

Krutchen, P. (1999). The Rational Uniﬁed Process. Addison

Wesley, Massachusetts.

Pankratius, V., Sandel, O., and Stucky, W. (2004). Retriev-

ing content with agents in web service e-learning sys-

tems. In The Symposium on Professional Practice in

AI, IFIF WG12.5 - First IFIP Conference on Artiﬁcial

Intelligence and Innovations (AIAI), pages 144–153.

Sousa, G., Soares, S., Borba, P., and Castro, J. (2004). Sep-

aration of crosscutting concerns from requirements to

design: Adapting an use case driven approach. In pro-

ceedings of AOSD-2004, Lancaster, UK. Early Aspect

2004.

Wooldridge, M. and Jennings, N. (1995). Intelligent agents:

Theory and practice. Knowledge Engineering Review,

10(2):115–152.

E-EVALUATION TO DETECT LEARNING WEAKNESS - An Agent Based Architecture

411
