ON STATE CLASSES AND THEIR DYNAMIC SEMANTICS

Ferruccio Damiani, Elena Giachino

Dipartimento di Informatica, Universit

a degli Studi di Torino

Corso Svizzera 185, 10149 Torino, Italy

Paola Giannini, Emanuele Cazzola

Dipartimento di Informatica, Universit

a del Piemonte Orientale

Via Bellini 25/G, 15100 Alessandria, Italy

Keywords:

Java, concurrent object-oriented language, small-step semantics, core calculus, implementation by translation.

Abstract:

We introduce state classes, a construct to program objects that can be safely concurrently accessed. State

classes model the notion of object’s state (intended as some abstraction over the value of ﬁelds) that plays a

key role in concurrent object-oriented programming (as the state of an object changes, so does its coordination

behavior). We show how state classes can be added to Java-like languages by presenting STATEJ, an extension

of JAVA with state classes. The operational semantics of the state class construct is illustrated both at an

abstract level, by means of a core calculus for STATEJ, and at a concrete level, by deﬁning a translation from

STATEJ into JAVA.

1 INTRODUCTION

The notion of object’s state, intended as some ab-

straction on the values of ﬁelds, plays a key role

in concurrent object-oriented programming. Various

language constructs for expressing object’s state ab-

stractions have been proposed in the literature (see,

e.g., (Philippsen, 2000) for a survey). We propose

state classes, a programming feature that could be

added to JAVA-like programming languages. The

main novelties in our proposal are: (1) The abil-

ity of states to carry values, thanks to the fact that

states may be parameterized by special ﬁelds, that we

call attributes; and (2) The presence of a static type

and effect system guaranteeing that, even though the

state of the objects may vary through states with dif-

ferent attributes, no attempt will be made to access

non-existing attributes (this is, for state attributes, the

standard requirement that well typed programs cannot

cause a ﬁeld not found error).

This paper focuses on the dynamic semantics of

state classes. Typing issues are addressed in (Damiani

et al., 2006). The paper is organized as follows: Sec-

tion 2 introduces STATEJ, an extension of JAVA with

state classes, through an example. Section 3 gives the

FSJ calculus (a core calculus for STATEJ). Section 4

outlines how STATEJ can be implemented by transla-

tion into plain JAVA. Sections 5 and 6 conclude by

discussing related and further work, respectively.

2 AN EXAMPLE

In this section we motivate STATEJ through an ex-

ample. The state class construct is designed to pro-

gram objects that can be safely concurrently accessed.

Therefore, in a state class, all the ﬁelds are private

and all the methods are synchronized (that is, they

are executed in mutual exclusion on the receiver ob-

ject). A state class may extend an ordinary (i.e.,

non-state) class, but only state classes may extend

state classes. Each state class speciﬁes a collection

of states. Each state is parameterized by some special

ﬁelds, called attributes, and declares some methods.

The state of an object o can be changed only inside

methods of o, by means of a state transition state-

ment, this!!S(e

, . . . , e

), where “S” is the name of

the target state and “e

, . . . , e

” (n ≥ 0) supply the

values for all the attributes of S. An object belonging

to a state class is always in one of the states speciﬁed

in its class. Each state class constructor must set the

state of the created object. The default constructor of

the root of a hierarchy of state classes sets the state to

the ﬁrst state deﬁned in the class.

The class ReaderWriter (in Fig. 1) implements

a multiple reader, single-writer lock — see (Bir-

rel, 1989), for an implementation using traditional

concurrency primitives in a dialect of MODULA 2,

and (Benton et al., 2004), for an implementation using

chords in POLYPHONIC C♯.

Damiani F., Giachino E., Giannini P. and Cazzola E. (2006).

ON STATE CLASSES AND THEIR DYNAMIC SEMANTICS.

In Proceedings of the First International Conference on Software and Data Technologies, pages 5-12

DOI: 10.5220/0001317700050012

 SciTePress

public state class ReaderWriter {

state FREE {

public void shared() {this!!SHARED(1);}

public void exclusive() {this!!EXCLUSIVE;}

}

state SHARED(int n) {

public void shared() {n++;}

public void releaseShared()

{n--; if (n==0) this!!FREE;}

}

state EXCLUSIVE {

public void releaseExclusive()

{this!!FREE;}

}

Figure 1: A multiple-reader, single-writer lock.

public state class ReaderWriterFair

extends ReaderWriter {

state SHARED(int n) {

public void exclusive()

{this!!PENDING_WRITER(n);

pre_exclusive();

this!!EXCLUSIVE;}

}

state PENDING_WRITER(int n) {

public void releaseShared()

{n--; if (n==0) this!!PRE_EXCLUSIVE;}

}

state PRE_EXCLUSIVE {

private void pre_exclusive() { }

}

Figure 2: A fair multiple-reader, single-writer lock.

When a thread e invokes a method m on an ob-

ject o belonging to a state class (e.g., to the class

ReaderWriter in Fig. 1), if either o is in a state that

does not support the invoked method (e.g., shared

invoked on an EXCLUSIVE ReaderWriter) or some

other thread is executing a method on o, then the exe-

cution of e is blocked until o reaches (because of the

action of some other thread) a state where the invoked

method is available and no other thread is executing a

method on o.

The policy implemented by the ReaderWriter

class above is prone to writers’ starvation. The class

ReaderWriterFair (in Fig. 2) extends the class

ReaderWriter to implement a writer starvation free

policy.

An extending class inherits all the states of

the extended class, and may add/override meth-

ods and introduce new states. Thus, class

ReaderWriteFair has states FREE, SHARED,

EXCLUSIVE, PENDING

WRITER and PRE EXCLUSIVE.

When the request exclusive is received by an

object o in state SHARED(n), then the state of o is

set to PENDING

WRITER(n) and the method body

suspends; in this state o can only execute up to n

requests of releaseShared; after the n-th such

request, the state of o is set to PRE

EXCLUSIVE;

in state PRE

EXCLUSIVE the method body for

exclusive can continue, and will set the state of o

to EXCLUSIVE.

The ReaderWriterFair class illustrates a com-

mon pattern in state class programming: the pri-

vate method pre

exclusive has an empty body, and

acts as a test that the receiver has reached the state

PRE EXCLUSIVE.

3 A CALCULUS FOR STATEJ

This section gives syntax and operational seman-

tics of FSJ, a minimal imperative core calculus

for STATEJ. FSJ models the innovative features of

the state construct (namely state classes, state at-

tributes and methods, and state transitions) and multi-

threaded computations.

A FSJ program consists of a set of class deﬁnitions

plus an expression to be evaluated, that we will call

the main expression of the program.

3.1 Syntax

The abstract syntax of FSJ class declarations (L),

class constructor declarations (K), state declarations

(N), method declarations (M), and expressions (e) is

given in Fig. 3. The metavariables A, B, C, and D range

over class names; S ranges over state names; f and

g range over attribute names; m ranges over method

names; x ranges over method parameter names; and

a, b, c, d, and e range over expressions.

We write “¯e” as a shorthand for a possibly empty

sequence “e

, · · · , e

” (and similarly for C, f, S, x)

and write “

N” as a shorthand for “N

· · · N

” with no

commas (and similarly for

M). We write the empty

sequence as “•” and denote the concatenation of se-

quences using either comma or juxtaposition, as ap-

propriate. We abbreviate operations on pair of se-

quences by writing “

f” for “C

, . . . , C

”,

where n is the length of

C and

f. We assume that se-

quences of state declarations or names, attribute dec-

larations or names, method parameter declarations or

names, method declarations do not contain duplicate

names.

The class declaration

state class C extends D {K

deﬁnes a state class of name C with superclass D.

The new class has a single constructor K and a set

of states

N. The state declarations

N may either re-

ﬁne (by adding/overrinding methods) states that are

already present in D or add new states.

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

Syntax:

L ::= state class C extends C {K

K ::= C(

f){this!!S(

f)}

N ::= state S (

f){

M ::= C m (

C ¯x) {e}

e ::= x | this | this.f | e; e | new C(¯e)

| this!!S(¯e) | spawn(e) | e.m(¯e)

Subtyping:

C <: C

<: C

state class C

extends C

· · · {· · · }

<: C

State attributes lookup:

state class C · · · {· · · state S(

f){· · · } · · · }

attributes(C, S) =

state class C extends D {K

N} S 6∈

attributes(C, S) = attributes(D, S)

Method deﬁnition lookup:

state class C · · · {K

N} state S{

M} ∈

A m(

A ¯x) {e} ∈

mDef (m, C, S) = A m(

A ¯x) {e}

state class C extends D {K

(S 6∈

N or (state S{

M} ∈

N and m 6∈

M))

mDef (m, C, S) = mDef (m, D, S)

Figure 3: FSJ syntax, subtyping rules, and lookup func-

tions.

The constructor declaration C(

f) {this!!S(

f)}

speciﬁes how to initialize the state and the state at-

tributes of an instance of C. It takes exactly as many

parameters as there are attributes of the state S and its

body consists of a state transition statement.

The state declaration state S(

f) {

M} introduces

a state with name S and attributes of names

f and

types

C. The declaration provides a suite of methods

that are available in the state S of the class C contain-

ing the state declaration. A state S declared in a class

C inherits all the (not overridden) methods that are de-

ﬁned in the (possible) declarations of S contained in

the superclasses of C.

The method declaration C m (

C ¯x) {e} introduces

a method named m with result type C, parameters ¯x of

types

C, and body e. The variables ¯x and the pseudo-

variable this are bound in e.

The class declarations in a program must satisfy the

following conditions: (1) Object is a distinguished

class name whose declaration does not appear in the

program; (2) For every class name C (except Object)

appearing anywhere in the program, one and only one

class with name C is declared in the program; and (3)

The subtype relation induced by the class declarations

in the program (denoted by <: and formally deﬁned

in the middle of Fig. 3) is acyclic. To simplify the

notation in what follows (as in (Igarashi et al., 2001)),

we always assume a ﬁxed program.

The lookup functions are given at the bottom of

Fig. 3. We write S 6∈

N to mean that no declaration

of the state S is included in

N, and m 6∈

M to mean

that no declaration of the method m is included in

Lookup of the attributes of a state S of a class C, writ-

ten attributes(C, S), returns a sequence

f pairing

the type of each attribute declared in the state with its

name. Lookup of the deﬁnition of the method m in the

state S of a state class C is denoted by mDef (m, C, S).

Note that attributes(C, S) and mDef (m, C, S) are un-

deﬁned when C = Object.

3.2 Operational Semantics

In this section we introduce the operational semantics

of FSJ, by deﬁning the reduction rules that transform

conﬁgurations representing multi-threaded computa-

tion. A conﬁguration is a pair “¯e, H”, where ¯e is a se-

quence of n ≥ 1 runtime expressions and H is a heap

mapping addresses to objects. Addresses, ranged over

by the metavariable ι, are the elements of the denu-

merable set I. Objects are ﬁnite mappings associ-

ating: (1) the distinguished name “class” to a class

name indicating the class of the object; (2) the dis-

tinguished name “state” to a state name indicating

the state of the object; and (3) a mapping associat-

ing a ﬁnite number (possibly zero) of state attribute

names to addresses. Objects will be denoted by

[[class : C, state : S,

f : ¯ι]].

The ﬁrst component of a conﬁguration, ¯e, will be

called “sequence of threads”. A thread of compu-

tation is represented by the evaluation of a runtime

expression e

in the heap H. The different threads

share the same heap H. Threads do not have, as in

full STATEJ and JAVA, an associated stack, keeping

the association between parameters and values. In

fact, since FSJ does not include assignment, method

calls are evaluated by directly substituting the for-

mal parameters and the metavariable this with the

corresponding values (in FSJ the only values are ad-

dresses). We call the result of this substitution, which

is no longer an expression of the source language, a

simple runtime expression. Simple runtime expres-

sions, ranged over by s, are obtained from the pseudo

grammar deﬁning expressions (in Fig. 3) by replacing

the clauses “x | this | this.f |” with the clauses

“ι | ι.f |” (see the top of Fig. 4).

Runtime expressions, ranged over by e, are de-

ﬁned by the grammar at top of Fig. 4. In FSJ ev-

ery method is synchronized, therefore on method call

the lock of the object receiving the call must be ac-

In full STATEJ, like in JAVA, the lookup functions take

into account method overloading, that (for simplicity) is not

included in FSJ.

In full STATEJ the class Object has several methods.

ON STATE CLASSES AND THEIR DYNAMIC SEMANTICS

Simple runtime expressions, runtime expressions, evaluation contexts, redexes, and auxiliary functions:

s ::= ι | ι.f | s; s | new C(¯s) | ι!!S(¯s) | spawn(s) | s.m(¯s)

e ::= ι | ι.f | e; s | new C(¯ι, ˙e, ¯s) | ι!!S(¯ι, ˙e, ¯s) | spawn(e) | e.m(¯s) | ι.m(¯ι, ˙e, ¯s)

| ret(ι, m, e) | unlock(ι.m(¯ι))

r ::= ι.f | ι; s | new C(¯ι) | ι!!S(¯ι) | spawn(ι) | ι.m(¯ι) | ret(ι , m, ι) | unlock(ι.m(¯ι))

lockedBy(e) = {ι | ret(ι, · · · , · · · ) is a subexpression of e and unlock(ι. · · · (· · · )) is not a subexpression of e}

lockedBy(e

· · · e

) =

1≤i≤n

lockedBy(e

)

Reduction rules:

H(ι) = o o(f) = ι

′

¯a E[ι.f] ¯c, H −→ ¯a E[ι

′

] ¯c, H

(R-ATTR)

¯a E[ι; s] ¯c, H −→ ¯a E[s] ¯c, H

(R-SEQ)

state class C · · · {C(

f){this!!S(

f)} · · · } o = [[class : C, state : S,

f : ¯ι]] ι 6∈ Dom(H)

¯a E[new C(¯ι)] ¯c, H −→ ¯a E[ι] ¯c, H[ι : o]

(R-NEW)

H(ι)(class) = C attributes(C, S) =

f o = [[class : C, state : S,

f : ¯ι]]

¯a E[ι!!S(¯ι)] ¯c, H −→ ¯a E[ι] ¯c, H[ι : o]

(R-TRANS)

¯a E[spawn(ι)] ¯c, H −→ ¯a E[ι] ¯c ι.run(), H

(R-SPAWN)

ι 6∈ lockedBy (¯a¯c) H(ι) = [[class : D, state : S, · · · ]] mDef (m, D, S) = C m (

C ¯x) {e}

¯a E[ι.m(¯ι)] ¯c, H −→ ¯a E[ret(ι, m, e[this := ι, ¯x := ¯ι])] ¯c, H

(R-INVK-1)

ι ∈ lockedBy (E[ι.m(¯ι)]) H(ι) = [[class : D, state : S, · · · ]] mDef (m, D, S) undeﬁned

¯a E[ι.m(¯ι)] ¯c, H −→ ¯a E[unlock(ι.m(¯ι))] ¯c, H

(R-INVK-2)

ι 6∈ lockedBy (¯a¯c) H(ι) = [[class : D, state : S, · · · ]] mDef (m, D, S) = C m (

C ¯x) {e}

¯a E[unlock(ι.m(¯ι))] ¯c, H −→ ¯a E[ret(ι, m, e[this := ι, ¯x := ¯ι])] ¯c, H

(R-UNLOCK)

¯a E[ret(ι, m, ι

)] ¯c, H −→ ¯a E[ι

] ¯c, H

(R-RET)

Figure 4: FSJ (simple) runtime expressions, evaluation contexts, redexes, auxiliary functions, and reduction rules.

quired, unless the call is inside a method of the object

itself, in which case the call can proceed (the lock is

reentrant). Moreover, when the method call is on a

method not deﬁned in the current state, the lock of the

object must be released. This gives to other threads

a chance to change the state of the object to a state

in which the method is deﬁned. Both these situa-

tions are modelled by particular runtime expressions:

(1) ret(ι, m, e), where e does not contain occurrences

of unlock(ι. · · · (· · · )), speciﬁes that a thread is cur-

rently holding the lock of the receiver ι, in order to

evaluate the expression e, which represents the body

of the method m, and (2) unlock(ι.m(¯ι)) speciﬁes that

the lock of ι has been released in order to give a

chance to another thread to change the state of ι to a

state in which m is deﬁned. Note that, the deﬁnition of

the syntax for runtime expressions implies that there

can be nested ret expressions but only one unlock.

The metavariables a, b, c, d, and e range over runtime

expressions. We write ¯a as a shorthand for a possibly

empty sequence a

· · · a

and ˙a as a shorthand for a

possibly empty sequence of length almost one. The

function lockedBy(¯e), deﬁned in Fig. 4, returns the

set of addresses that are locked by the thread sequence

¯e.

The reduction relation has the form “¯a b

¯c, H

−→

¯a b

¯c

d, H

”, read “conﬁguration ¯a b

¯c, H

reduces

to conﬁguration ¯a b

¯c

d, H

in one step”. The (empty

or singleton) sequence

d indicates that a new thread

might have been spawned because of the reduction of

a spawn expression. We write −→

⋆

for the reﬂexive

and transitive closure of −→.

By using the deﬁnition of evaluation context and

redex (see E and r in Fig. 4), the reduction rules en-

sure that inside each thread the computation follows

a call-by-value left-to-right reduction strategy. This

implies that expressions such as ret and unlock can

only be preceded by values and followed by simple

runtime expressions, which do not contain ret and

unlock (see the deﬁnition of s and e in Fig. 4).

The following property asserts that a context can be

decomposed in a unique way in sub-contexts showing

the activation stack of method calls.

Property 1 (Unique Decomposition) Every evalua-

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

tion context E can be written as

1,1

[ret(ι

, m

1,1

, · · · E

1,q

[ret(ι

, m

1,q

· · ·

p,1

[ret(ι

, m

p,1

, · · · E

p,q

[ret(ι

, m

p,q

, E

)] · · · )]

· · · )] · · · )],

where E

1,1

, . . ., E

1,q

, . . ., E

p,1

, . . ., E

p,q

(p ≥ 0,

≥ 1, . . ., q

≥ 1) and E

do not contain ret(· · · )

subexpressions.

The reduction rules are given at the bottom of

Fig. 4. Each reduction rule rewrites a conﬁguration

of the form “¯a E[r] ¯c, H

”, where E is an evaluation

context and r is a redex, into a conﬁguration of the

form “¯a E[e] ¯c

d, H

”. The metavariable o ranges over

objects. We use H[ι : o] to denote the heap such that

H[ι : o](ι) = o and H[ι : o](ι

′

) = H(ι

′

), for ι

′

6= ι.

The reduction rules for attribute selection,

(R-ATTR), and sequential composition, (R-SEQ),

are standard. The rule for object creation, (R-NEW),

stores the newly created object at a fresh address of

the heap and returns the address. The pseudo ﬁelds

class and state, and the parameters of the initial state

are initialized as speciﬁed by the class constructor.

The rule for state transition, (R-TRANS), changes

the current state of the object and returns its address.

Rule (R-SPAWN) replaces the spawn expression

with the address ι and adds a new thread evaluating

the call of the method run on the object at ι. Rule

(R-INVK-1) is applied if the method m is deﬁned in

the current state of the receiver, ι, and no other thread

holds the lock of ι. The expression produced replaces

the call with ret(ι, m, e

′

), indicating that the current

thread holds the lock of ι . The expression e

′

is the

body of the method m in which this and the formal

parameters are replaced with the address ι and the

actual parameters. Rule (R-INVK-2) is applied if the

method m is not deﬁned in the current state of the

receiver and the current thread holds the lock of ι. In

this case, the lock of ι must be released and the thread

must wait that some other thread changes the state of

ι to a state in which m is deﬁned. This is achieved by

replacing the method call redex with the expression

unlock(ι.m(¯ι)). Note that, since the current thread

had the lock of ι, the newly introduced unlock

expression is a subexpression of an expression

ret(ι, m

′

, e

′

) for some m

′

and e

′

. Rule (R-UNLOCK)

replaces the expression unlock(ι.m(¯ι)), if ι is not

locked and the method m is deﬁned in its state, with

ret(ι, m, e

′

), where e

′

is the body of the method

m in which this and the formal parameters are

replaced with the address ι and the actual parameters.

Rule(R-RET), that applies when the body of the

method m on object ι has been evaluated completely,

producing a value, releases the lock of ι by removing

the ret(ι, m, ι

) subexpression.

Example 2 (Application of the reduction rules)

First we deﬁne the following classes CR and CW repre-

senting the class of threads that have a shared access

to a ReaderWriter object rw and the class of threads

that have an exclusive access to it, respectively.

state class CR extends Object {

CR(ReaderWriter rw) { this!!S(rw) }

state S (ReaderWriter rw) {

Object run () {

rw.shared();

...

rw.releaseShared();

this.run() } }

}

state class CW extends Object {

CW(ReaderWriter rw) { this!!S(rw) }

state S (ReaderWriter rw) {

Object run () {

rw.exclusive();

...

rw.releaseExclusive();

this.run() } }

}

We consider as the main expression of the program,

that is the expression to be evaluated,

spawn(new CR(ι)); (new CW(ι)).run(),

where ι is a ReaderWriter object, so the computa-

tion starts from the following conﬁguration:

spawn(new CR(ι)); (new CW(ι)).run(), H

where H = ι : [[class : ReaderWriterFair, state : FREE]].

A possible computation is as in Fig. 5, where SH

stands for SHARED, PW stands for PENDING

WRITER,

EX stands for EXCLUSIVE, and PE stands for

PRE EXCLUSIVE. We adopt the following notations:

(1) Threads e

, e

being part of the conﬁguration are

written





; (2) Redexes are underlined; (3) Redexes

of suspended threads are underlined and written in

grey; (4) the arrow =⇒ indicates one step of reduction

for each thread of the sequence; (5) In ret expres-

sions we omit method names. As we see in Fig. 5, in

the example we assumed to have integers, decrement

and if-statement. These are assumed, in line (#), to be

reduced following the standard semantics.

4 FROM STATEJ TO JAVA

This section brieﬂy illustrates a translation from

STATEJ to plain JAVA. The basic idea of the trans-

lation is to map a state class into a JAVA class using

synchronized methods and the primitives wait()

and notify(). A class contains a ﬁeld indicating the

ON STATE CLASSES AND THEIR DYNAMIC SEMANTICS

spawn(new CR(ι)); (new CW(ι)).run(), H −→ spawn(ι

′

); (new CW(ι)).run(), H

−→ ﬁrst by (R-NEW) and second by (R-SPAWN)

′

; (new CW(ι)).run()

′

.run()

, H

=⇒ by (R-SEQ) and (R-INVK-1)

(new CW(ι)).run()

ret(ι

′

, ι.shared(); ...; ι.releaseShared(); ι

′

.run())

, H

=⇒ by (R-NEW) and (R-INVK-1)

′′

.run()

ret(ι

′

, ret(ι, ι!!SH(1)); ...; ι.releaseShared(); ι

′

.run())

, H

=⇒ by (R-INVK-1) and (R-TRANS)

ret(ι

′′

, ι.exclusive();...; ι.releaseExclusive(); ι

′′

.run())

ret(ι

′

, ret(ι, ι)

; ...; ι.releaseShared(); ι

′

.run())

, H

−→ by (R-RET)

ret(ι

′′

, ι.exclusive(); ...; ι.releaseExclusive(); ι

′′

.run())

ret(ι

′

, ι; ...; ι.releaseShared(); ι

′

.run())

, H

−→

⋆

by ﬁrst applying (R-INVK-1) and (R-SEQ)

ret(ι

′′

, ret(ι, ι!!PW(1); ι.pre exclusive(); ι!! EX); ...; ι.releaseExclusive(); ι

′′

.run())

ret(ι

′

, ι.releaseShared(); ι

′

.run())

, H

−→ by (R-TRANS)

ret(ι

′′

, ret(ι, ι; ι.pre exclusive(); ι!!EX); ...; ι.releaseExclusive(); ι

′′

.run())

ret(ι

′

, ι.releaseShared(); ι

′

.run())

, H

−→ by (R-SEQ)

ret(ι

′′

, ret(ι, ι.pre exclusive(); ι!! EX); ...; ι.releaseExclusive(); ι

′′

.run())

ret(ι

′

ι.releaseShared(); ι

′

.run())

, H

−→ by (R-INVK-2)

ret(ι

′′

, ret(ι, unlock(ι.pre exclusive()); ι! ! EX); ...; ι.releaseExclusive(); ι

′′

.run())

ret(ι

′

, ι.releaseShared(); ι

′

.run())

, H

−→ by (R-INVK-1)

(#)

ret(ι

′′

, ret(ι, unlock(ι.pre exclusive()); ι!!EX); ...; ι.releaseExclusive(); ι

′′

.run())

ret(ι

′

, ret(ι, n − −; if (n = 0) ι !! PE); ι

′

.run())

, H

−→

⋆

ret(ι

′′

, ret(ι, unlock(ι.pre exclusive()); ι! ! EX); ...; ι.releaseExclusive(); ι

′′

.run())

ret(ι

′

, ι; ι

′

.run()

)

, H

=⇒ by (R-UNLOCK) and (R-SEQ)

ret(ι

′′

, ret(ι, ret(ι, ); ι!!EX); ...; ι.releaseExclusive(); ι

′′

.run())

ret(ι

′

, ι

′

.run())

, H

−→

⋆

by (R-RET) and (R-INVK-1)

ret(ι

′′

, ret(ι, ι.releaseExclusive(); ι

′′

.run()))

ret(ι

′

, ret(ι

′

, ...))

, H

−→

⋆

· · ·

where

H = ι : [[class : ReaderWriterFair, state : FREE]]

= H[ι

′

: [[class : CR, state : S, rw : ι]]] H

= H

[ι

′′

: [[class : CW, state : S, rw : ι]]]

= H

[ι : [[class : ReaderWriterFair, state : SH, n : 1]]] H

= H

[ι : [[class : ReaderWriterFair, state : PW, n : 1]]]

= H

[ι : [[class : ReaderWriterFair, state : PE]]] H

= H

[ι : [[class : ReaderWriterFair, state : EX]]]

Figure 5: An example of reduction.

current state of the object, and methods correspond-

ing to the methods of the original STATEJ class. The

translation can be brieﬂy described as follows.

Method. Methods deﬁned in more than one state have

more than one body. To be able to execute differ-

ent bodies in different states our translation creates

a unique synchronized method containing all the

different bodies. At run-time, when the method is

called, we have to check the current state of the object,

and see whether the method was deﬁned in this state

or not. In case it is deﬁned, then the corresponding

body is executed, otherwise the thread calls a wait()

putting it in hold. To keep the information on the

methods deﬁned in a certain state we use a hash ta-

ble. Due to the limitation of the switch statement of

JAVA, states are codiﬁed by the primitive type int.

For example the following class

state class Ex extends Object {

Ex() { this!!A(); }

state A () {

Object m() { /

body of m in A

/ } }

state B () {

Object m() { /

body of m in B

/ } } }

is translated into

class Ex extends Object {

Ex() { ... }

final static int A = 1;

final static int B = 2;

Hashtable stateMethods;

int currentState;

synchronized Object m() {

while (!existsInCurrentState) wait();

switch (currentState) {

case A : /

body of m in A

/ break;

case B : /

body of m in B

/ break;

} } }

where the existence of a method in a given state and

its selection are done using the hash table of methods.

State Transition. The state transition expression

this!!A() is translated into

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

currentState = A; notifyAll();

so in addition to change the state of the objects it no-

tiﬁes all the threads waiting for the lock of the cur-

rent object. When the current thread will release the

lock the notiﬁed threads will compete to get it to have

a chance to see whether the method that caused the

waiting is deﬁned in the current state. If the method

is deﬁned, then the thread can proceed, otherwise it

calls a wait(). Due to the non deterministic nature of

JAVA scheduling we cannot insure the order in which

notiﬁed threads will be waken up.

Constructor. The constructor of the translated class

should initialize the hash table and then include the

translation of the constructor of the original class.

Inheritance. A state class may extend another class

(either state or not). In the subclass we inherit all

the states and may add others. Therefore, we have

to be careful to clashes of constants of state. More-

over, methods may be added/redeﬁned. For instance

method exclusive() of the example in Sect. 2, is

deﬁned in state FREE of ReaderWriter, and rede-

ﬁned in state SHARED of ReaderWriterFair. When

a method is redeﬁned in its translation we use the

default clause as follows.

class ReaderWriterFair

extends ReaderWriter {

...

synchronized void exclusive () {

while (!existsInCurrentState) wait();

switch (currentState) {

case SHARED:

currentState =PENDING_WRITER;

notifyAll();

pre_exclusive();

currentState =EXCLUSIVE;

notifyAll();

break;

default :

super.exclusive;

break; } } }

The current implementation of the translator

(www.di.unito.it/˜giannini/stateJimpl/) takes as in-

put a program written in JAVA 1.4 extended with

state classes with attribute-free states (attributes can

be straightforwardly codiﬁed by class ﬁelds; however,

their implementation would require to implement the

type and effect analysis). The translation uses the

tool for Language Recognition ANTLR, see (Parr and

project group, 2005), and the StringTemplate tecnol-

ogy, see (Parr, 2005). We ﬁrst made a JAVA 1.4 to

JAVA 1.4 translation taking advantage of the grammar

deﬁned by Parr and then modiﬁed the grammar to in-

clude our state related constructs. The use of ANTLR

and StringTemplate makes the translator easily adapt-

able to different translation schemes and also to addi-

tion to the input language.

5 RELATED WORK

According to (Philippsen, 2000) states provide

a boundary coordination mechanism (we refer to

Sect. 4.2 of (Philippsen, 2000) for a survey of several

COOLs with boundary coordination). In particular,

the state class construct is related to the actor model

(Agha, 1986) and to the behaviour abstraction and

behaviour/enable sets proposals (Kafura and Laven-

der, 1996; Tomlinson and Singh, 1989).

At the best of our knowledge, the main novelties

in our proposal are: the ability of states to carry val-

ues (thanks to the presence of attributes); the for-

malization of an abstract operational semantics of a

notion of state for expressing coordination in JAVA-

like languages; and the presence of a static type and

effect system (presented in (Damiani et al., 2006))

guaranteeing that during the execution there can-

not be any access to undeﬁned attributes of objects.

Type systems for concurrent objects have been in-

vestigated in the literature, see, e.g., “regular object

types” (Nierstrasz, 1993), the TYCO object calcu-

lus (Ravara and Vasconcelos, 2000), and the Fickle

proposal (Damiani et al., 2004).

Various improvements of the concurrency model

of JAVA-like languages have been proposed. In JOIN

JAVA (Itzstein and Kearney, 2001) and POLYPHONIC

C♯ (Benton et al., 2004) the synchronization mecha-

nism relies on the join pattern, called chord in POLY-

PHONIC C♯, construct. Chords can be used to codify

the state of an object through the pattern (illustrated,

for instance, in (Benton et al., 2004)) of using private

asynchronous method to carry object state. However,

this pattern could be misused leading to deadlock or

errors. In STATEJ the notion of object state is in the

language deﬁnition, thus eliminating the possibility of

many of such errors. In JEEG (Milicia and Sassone,

2005) the synchronization conditions on an object o

are expressed with linear temporal logic constraints

involving the value of ﬁelds and the method invoca-

tion history of o. These constraints could be used to

codify the state of an object o. However, state at-

tributes have to be mapped on object ﬁelds and there

is no way to express the fact that some ﬁelds should

be accessible only in some states.

STATEJ (as JOIN JAVA, POLYPHONIC C♯, and

JEEG) focuses on a speciﬁc coordination mechan-

ishm. The JR programming language (Keen et al.,

2004) takes a different approach: it extends JAVA pro-

viding a rich concurrency model with a variety of

mechanisms. None of this mechanisms directly mod-

els the notion of object state.

ON STATE CLASSES AND THEIR DYNAMIC SEMANTICS

6 FUTURE WORK

The current prototypical implementation of STATEJ

(www.di.unito.it/˜giannini/stateJimpl/) is based on

the translation scheme outlined in Sect. 4. It con-

sists of a preprocessor that maps code written in JAVA

1.4 extended with state classes into plain JAVA. The

current approach favors simplicity over efﬁciency. Its

major drawback is that each state transition of an ob-

ject o notiﬁes all the threads waiting for any state of

o. Note that, notifying just the threads waiting for

the target state of the transition would not represent a

signiﬁcative improvement, since multiple state transi-

tions may occur before the lock on o is released. A

more signiﬁcative improvement would be moving no-

tiﬁcation from state transition on o to lock release on

o: this would allow notifying just the threads wait-

ing for the current state of o. Note that, however,

all but the ﬁrst (according to the scheduling mecha-

nism of JAVA) of such threads have to sleep again. We

are currently investigating a quite different approach

that support selective wakeups. It can be roughly de-

scribed as follows:

• Each object o is equipped with a set of FIFO queues

(one for each state).

• Whenever a thread invokes a method m on o, IF o is

locked by some other thread OR m is not available

in the current state of o

– THEN the thread is suspended and enqueued in

all the queues associated to the states of o

where m is available, and the lock on o (if held

by the suspended thread) is released

– ELSE the method executed and the lock on o (if

not already held by the invoking thread) is taken.

• Whenever the lock on o is released, IF the queue

associated to the current state of o is not empty,

THEN a thread e is extracted from the queue, re-

moved from all the other queues, resumed, and it

takes the lock on o.

Other future work includes: Reﬁnement of the type

and effect system given in (Damiani et al., 2006);

Further investigations on the expressivity of the state

class construct and on its integration in JAVA-like lan-

guages (by analyzing the interaction of state classes

and their types with the advanced features of JAVA-

like languages); Development of a new prototype

(based on the translation scheme outlined above) in-

cluding state attributes and the related type and effect

analysis; and Development of benchmarks.

REFERENCES

Agha, G. A. (1986). ACTORS: A Model of Concurrency

Computation in Distribuited Systems. MIT Press.

Benton, N., Cardelli, L., and Fournet, C. (2004). Mod-

ern Concurrency Abstractions for C♯. ACM TOPLAS,

26(5):769–804.

Birrel, A. D. (1989). An introduction to programming with

threads. Technical Report 35, DEC SRC.

Damiani, F., Dezani-Ciancaglini, M., and Giannini, P.

(2004). On re-classiﬁcation and multithreading. JOT

(www.jot.fm), 3(11):5–30. Special issue: OOPS track

at SAC 2004.

Damiani, F., Giachino, E., Giannini, P., Cameron, N., and

Drossopoulou, S. (2006). A state abstraction for co-

ordination in java-like languages. In Electronic pro-

ceedings of FTfJP’06 (www.cs.ru.nl/ftfjp/).

Igarashi, A., Pierce, B., and Wadler, P. (2001). Feather-

weight Java: A minimal core calculus for Java and

GJ. ACM TOPLAS, 23(3):396–450.

Itzstein, G. S. and Kearney, D. (2001). Join Java: an alterna-

tive concurrency semantics for Java. Technical Report

ACRC-01-001, Univ. of South Australia.

Kafura, D. G. and Lavender, R. G. (1996). Concur-

rent object-oriented languages and the inheritance

anomaly. In Casavant, T., Tvrdil, P., and Pl

asil, F., ed-

itors, Parallel Computers: Theory and Practice, pages

221–264. IEEE Press.

Keen, A. W., Ge, T., Maris, J. T., and Olsson, R. A. (2004).

JR: Flexible distributed programming in an extended

java. TOPLAS, 26(3):578–608.

Milicia, G. and Sassone, V. (2005). Jeeg: Temporal Con-

straints for the Synchronization of Concurrent Ob-

jects. Concurrency Computat.: Pract. Exper., 17(5-

6):539–572.

Nierstrasz, O. (1993). Regular Types for Active Objects. In

OOPSLA’93, volume 28 of ACM SIGPLAN Notices,

pages 1–15.

Parr, T. (2003-2005). StringTem-

plate Documentation. Available at

www.stringtemplate.org./doc/doc.html.

Parr, T. and project group (2005). ANTLR Ref-

erence Manual, Version 2.7.5. Available at

www.antlr.org./doc/index.html.

Philippsen, M. (2000). A Survey of Concurrent Object-

Oriented Languages. Concurrency Computat.: Pract.

Exper., 12(10):917–980.

Ravara, A. and Vasconcelos, V. T. (2000). Typing Non-

uniform Concurrent Objects. In CONCUR’00, volume

1877 of LNCS, pages 474–488, Berlin. Springer.

Tomlinson, C. and Singh, V. (1989). Inheritance and syn-

chronization with enabled-sets. In OOPSLA’89, pages

103–112. ACM.

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES
