SAGA: AN ADAPTIVE INFRASTRUCTURE FOR SECURE

AVAILABLE GRID ON AD-HOC NETWORKS

Manel Abdelkader, Noureddine Boudriga and Mohammad S. Obaidat

University of November 7

at Carthage, Tunisia and Monmouth University, NJ, USA

Corresponding Author: Prof. M. S. Obaidat, Department of Computer Science,

Monmouth University, W. Long Branch, NJ 0764, USA

Keywords: System security, grid computing, ad hoc networks, adaptive infrastructures.

Abstract: Security management is a major issue in Grid computing systems. One approach to provide security is to

implement techniques such as encryption and access control on all grid elements. The overhead generated

by such an approach may however limit the advantages of Grid computing systems; particularly, when the

network experiences different types of variations. This paper examines the integration of the notion of

adaptive Grid service along with security management and accounting. It also provides a fault tolerance

technique to build Grid systems that are intrusion tolerant.

1 INTRODUCTION

Recently, Grid computing has emerged as an

attractive area characterized by large scale resource

sharing, innovative applications and high-

performance capabilities. The Grid problem has

been defined as a flexible, secure, coordinated

resource sharing among dynamic sets of individuals,

institutions, and resources. In such settings, one can

come across authentication, authorization, resource

access, resource discovery, and quality of service

(QoS) provision challenges.

Until recently, the main pri

ority for grid

developers has been to design working prototypes

and demonstrate that applications can be developed

over a grid environment with a restricted support to

application-level fault tolerance in computational

grids. Limited work also has addressed the

integration of quality of service (QoS) and security

while allocating resources. However, failure

detection services were among the main supportive

tools in developing grid environments; but, neither

solution has considered the intrusion detection and

intrusion tolerance (Casanova et al., 2003) (Song

and Hwang, 2004), nor did they provide schemes for

the management of GRID resources when variability

in the network dynamics is experienced.

Several recent studies have investigated security

d trust management while allocating Grid

resources (Butt et al., 2002) (Azzedin and

Maheswaran, 2002) (Czajkowski et al., 1999). Quite

a few models have been proposed to quantify trust in

Grid applications, including fuzzy model that was

provided for e-commerce applications by (Gefen et

al., 2003). Even though these studies have made

interesting contributions, they did not address

situations where multi-level trust is required, which

is a natural assumption in environment where

businesses are provided.

Wireless ad-hoc networks do not rely on a pre-

isting network infrastructure and are characterized

by a wireless multi-hop communication. Wireless

ad-hoc networks are increasingly used in situations

where a network must be deployed rapidly without

an existing infrastructure. Unlike fixed wired

network, wireless ad-hoc networks may have many

operational limitations such as the transmission

range, bandwidth, and energy. Additionally, wireless

ad-hoc networks are vulnerable to more threats than

those observed for the wired network, due to the

dynamic nature of the routing infrastructure and the

mobility of nodes. Applications of ad-hoc networks

are emerging tremendously. New applications are

nowadays getting more interest including target

sensing, tactical battlefield and GRID computing.

Abdelkader M., Boudriga N. and S. Obaidat M. (2006).

SAGA: AN ADAPTIVE INFRASTRUCTURE FOR SECURE AVAILABLE GRID ON AD-HOC NETWORKS.

In Proceedings of the International Conference on e-Business, pages 22-30

 SciTePress

Different features and challenges are introduced

by the deployment of a GRID system over wireless

ad-hoc networks. Among these features, one can

consider the provision of protection to the whole

GRID structure, the completion of the GRID

execution, and the need for authentication and

access control to resources, processes and messages

involved in the GRID execution. In fact, to ensure

distributed resources provision, different nodes in

the wireless ad-hoc network should contribute, in the

presence of the fact that each node of this structure

does not have to know (or communicate directly

with) all the other participants in the service

provision.

Typically, wireless ad-hoc networks raise

additional challenges to the provision of intrusion

tolerant GRID systems, for which the effectiveness

of wired solutions can be limited. To access a GRID

service, a node needs to be under the coverage of an

access point. In addition, a node agreeing to

participate in a GRID service needs to stay

connected until the service has terminated; otherwise

a procedure for its replacement should be

implemented. This is induced by the fact that a

GRID architecture may vary in terms of time,

location, and even availability. Security mechanisms

must be deployed in order to counter threats against

GRID over wireless ad-hoc networks. While

cryptography-based mechanisms provide protection

against some types of attacks from external nodes

(with respect to the GRID service), they cannot be

able to protect against malicious internal nodes,

which may already have legitimate cryptographic

keys. Therefore, mechanisms are necessary to

provide intrusion tolerance for GRID applications.

The work presented in this paper aims at

developing a general framework for the

implementation of Grid applications in ad-hoc

networking. The framework provides a generic

extension mechanism for integrating multi-level

trust management, QoS, and intrusion tolerance

functionalities into Grid applications and handle

variations in topology and availability. It consists of

three models: a) a resource management scheme,

which is responsible for resource description,

request handling, and service continuity; b) an

intrusion tolerance scheme; which integrates a

scheme for event passing, a model for event

correlation, and an alert notification procedure; and

c) an accounting scheme, which includes the

definition of a third party role, payment

authentication, and payment processing.

We have addressed, in (Abdelkader and

Boudriga, 2005), the design of a GRID architecture

on ad hoc networks, which includes service

discovery, service request and service allocation. In

addition, we have introduced the notion of real-time

control and management of trust in ad hoc nodes.

This work can be considered as a first step in the

development of SAGA. In the present paper, we

extend this architecture by addressing other issues

for the GRID service provision, the availability of

GRIID services and the tolerance to attacks and

failure. Considering the high variability of ad hoc

topology, we also discuss the role of rescue plans to

ensure GRID service provision continuity.

The remaining of this paper is organized as

follows. Section 2 provides a definition and

architecture for the GRID system. Section 3

develops the main characteristics of SAGA service

continuity and system flexibility to cope with ad-hoc

variability and node autonomy. Section 4 defines an

approach to integrate intrusion tolerance capabilities

in Grid computing systems and the management of

multi-level trust. Section 5 discusses an application

of SAGA to micro-payment environment. Finally,

section 6 concludes this paper.

2 ADAPTIVE INFRASTRUCTURE

Resource and connectivity protocols facilitate the

sharing of individual resources in Grid systems.

These protocols are designed so that they can be

implemented on top of a large spectrum of resource

types defined at a Grid layer, called Fabric layer (as

depicted by Figure 1). They also can be used to

construct a wide range of services and applications.

Figure 1 depicts a layered Grid architecture for ad-

hoc networks and its relationship to the Internet

protocol architecture. Our architecture presents some

similarities with the one discussed in (Abdelkader

and Boudriga, 2005), but it builds a number of

useful services for GRID continuity and protection.

Figure 1: Layered Grid architecture.

SAGA: AN ADAPTIVE INFRASTRUCTURE FOR SECURE AVAILABLE GRID ON AD-HOC NETWORKS

The Grid Fabric layer provides the resources to

which shared access is mediated by Grid protocols.

A resource may be a logic entity, a storage resource,

a network resource or a computational resource. The

Fabric layer provides a resource-specific description

of capabilities such as: (a) mechanisms for starting,

monitoring and controlling of the resulting processes

and controlling the resources allocated to these

processes; (b) mechanisms for storing and retrieving

files and (c) management mechanisms that allow

control over resources allocated to processes and

data transfers.

The Communication layer defines the

communication and authentication protocols

required for Grid-specific transactions. While

communication protocols enable the exchange of

data between fabric layer resources, the

authentication protocols build on communication

services to provide security services, such as

authentication and integrity of users and resources

and tolerance to intrusions. The communication

layer should provide mechanisms for delegation,

integration of local security and trust management.

The Resource layer builds on top of the

connectivity layer for the secure negotiation,

initiation, monitoring, accounting and billing of

sharing operations on individual resources.

Therefore, resource layer protocols are concerned

entirely with individual resources and ignore issues

of global state and atomic actions. Examples of

resource layer protocols include information

protocols, which collect information about the

structure and state of a resource, and management

protocols, which are used to negotiate access to

shared resources while specifying resource

requirements and the operation to be performed.

The Collection layer contains protocols and

services that are able to capture interactions across

the collection of resources. Example of services

include (but are not restricted to): (a) the directory

services that allow Grid users to discover resources;

(b) the brokering services that allow users to request

the allocation of one or more resources and the

scheduling of tasks related to these resources; (c)

software discovery services that help discovering

and selecting execution platforms (or nodes) based

on user/application parameters and (d) collaboration

services that support accounting GRID services.

In Grid systems with distributed resources and

task ownership, it is important to consider quality of

service and security while discovering, allocating,

and using resources. The integration of QoS has

been examined with resource management systems

by different studies. However, little work has been

done for the integration of security considerations.

Most cases have assumed that security is

implemented as a separate subsystem from the Grid

and the resource management system.

In a previous work, (Abdelkader and Boudriga,

2005), we have developed a scheme to search and

use resources and access a GRID application. In

particular, we have demonstrated that after finding

the resource responding to the node requirements on

security and QoS, the requester delegates to this

resource the rights to use other resources that may be

needed during service provision. In this section, we

recall the major features of this scheme and extend it

to provide an adaptive behaviour that takes into

consideration the variability of network topology,

autonomy of nodes and security requirements.

Figure 2 depicts a Grid service setup. Three tasks

are basically involved in this process:

1. A node requesting a Grid service discovers the

ad-hoc nodes that are able to allocate tasks and

resources to establish the desired service.

2. Upon receiving the request, a node willing to be

involved in the Grid service answers the request

by sending a response specifying the accepted

tasks, the amount of resources it can allocate, the

security level of the process (engaged in that

node), the cost and whether the node will act as a

service provider or service operator.

3. On receiving the responses, the requestor selects

the set of nodes that will be engaged in the

provision of the grid service. A negotiation may

take place between the requestor and a

respondent before completing the service

established. The negotiation involves QoS

parameters, resources parameters and security

services.

Features of the aforementioned process include

the following three items:

• A service operator is a node that is in charge of

offering the service using its own resources and

the resources it can request on behalf of the

requester. Therefore, the original requester does

not need to know the identity of nodes involved

in that share. In this case, the service operator is

called delegated requestor.

• A service provider designates a node that acts as

a server. It allocates the resources needed to the

contracted tasks. It can leave the Grid on a

simple message informing the requestor of its

leave. It also can be dropped from the established

Grid for various reasons, including security

needs or renegotiation.

ICE-B 2006 - INTERNATIONAL CONFERENCE ON E-BUSINESS

• Nodes contributing to a grid service are

autonomous in the sense that they act as ad-hoc

network node. They can move out of radio

coverage, power off, or be attacked.

Figure 2: Grid application on Ad-hoc network.

Illustrative example: An application of Grid can be

demonstrated by a micro-payment system for packet

service delivery similar to the one provided in

(Tewari and O’Mahony, 2003) and which has the

following properties:

• The application is only employed for paying

packets forwarding: a node desiring to send a set

of packets to a given set of destinations can

request the delivery of these packets to other

nodes that are known to be on the routes to

destinations (neighbours or close cluster heads).

• Each node involved in the delivery has a prior

knowledge of the routes that the packets it sends

should follow.

• Each node should be able to know the costs of all

paths leading to destination and details of costs

for each intermediate nodes (or at least the costs

to pay to the next nodes involved in the

delivery).

3 ADAPTIVE GRID BEHAVIOUR

To fulfill its objectives, a Grid service has to cope

with the ad-hoc topology variability, node

autonomy, and security intrusiont. The continuity of

Grid service and the guarantee of the offered quality

of service should be maintained as long as it is

needed; otherwise correcting measures should be

taken to correct any deviation. Measures fall into

two classes: predictive and reactive.

A. Predictive Infrastructure Modification

When a server S (service provider or service

operator) realizes that it cannot continue acting

within a Grid to a requestor R, it starts searching for

a replacement resource that can replace it and

provide the remaining part of its agreement with R.

This can be done as follows:

Resource reservation: To perform the replacement

task, S uses the delegation firstly given by R. It starts

by negotiating with the servers it has involved in its

offers to R. Let S

, 1

<m< n be these servers; S

checks with resources S

, 1

<m< n, whether one of

them can fulfil the QoS agreement of the Grid

service provided to R. If there is a server, say S

, S

presents to S

the tasks required by the client R, the

state of their execution, the remaining jobs and the

related QoS information including the period of time

t after which S will make the transfer to S

, and S

reserves the necessary resources to be used after t.

Then, S gives S

the list of the other resources

participating to the execution of the job J

requested

by R.

Node

Ad-hoc cell

Node request

Announcement: After that, S informs the resources

involved with it about their new manager S

which they should send the results related to J

after

t. On the other hand, S informs its cluster head CH

and the cluster head of R, CH

, about this

modification. CH

liberates the connection between

S and R. However, CH

starts building a new route

between R and the new server S

. Further, the

cluster head of S

, CH

S(m)

, starts to establish new

routes between S

and the other elementary

resources. At the end of this phase, one can say that

the 3-tuple (R, S, {S

, 1

<m< n}) is replaced by the

3-tuple (R, S

, { S

, i≠m and 1

<i< n}) in the Grid

service.

Job transfer: Before making the transfer to S

, R

generates a new delegation credential to S

to be

used after time t. In this credential, R allows S

execute job J

on its behalf and search for the

required resources. When t expires, S transfers to S

all the information and the results related to J

. If

finds that it needs more resources, it uses the

delegation credential given by R to search them.

Thus, the job transfer is done from S to S

without

disturbing the execution of J

and with respect to

the QoS required by R.

SAGA: AN ADAPTIVE INFRASTRUCTURE FOR SECURE AVAILABLE GRID ON AD-HOC NETWORKS

B. Reactive Infrastructure Modification

The interruption of the GRID service provision may

occur suddenly. Neither the resource, nor the

requester has prior knowledge about this

interruption. This case is critical and happens after a

node crash or a damaging attack on a node involved

in the Grid service provision. To handle this

situation, appropriate mechanisms need to be made

available (at the cluster heads) to discover and

handle any disconnection at any step of Grid service

provision period.

To react to sudden modifications, the cluster

observing a disconnection of a server S should

inform the sources requesting a Grid service to S

that S became unavailable. This can be performed

because a cluster head acts as a router in ad-hoc

networks. It also can maintain the routes established

by nodes belonging to its cluster. However, since it

cannot distinguish between the users and the data

transmitted on the different routes, we propose the

introduction of a new field in the header of IP

packets, called Grid-index field, to distinguish

between routes used in GRID applications. In fact,

each application would be characterized by a unique

number A

that should be maintained on all the

routes related to the same application. This field is

written by the first node initiating a GRID

application and is maintained on all the routes to

GRID servers.

Using this field, one can select an access to a

GRID application by the IP address of the source,

the IP address of the destination and the value A

contained in the new field. Therefore, every cluster

head can select and manage different groups of

routes where each group is attached to a GRID

application and contribute to the reaction to

disconnections as follows:

Announcement: When server S stops suddenly to

offer a GRID service to a requestor R, the first node

that can notice the interruption would be the cluster

head of S, CH

. In addition, CH

can distinguish the

different GRID applications to which S is involved

by using its routing table. After CH

has realized the

unavailability of S, it extracts from its routing table

the different addresses of the nodes present in routes

related to job J

. Then, CH

informs all the actors

involved with S in the Grid service provision that S

(let us call these servers again S

, 1

<m< n) is no

longer available so that they can they can suspend

the execution of tasks related to J

during a period τ

and free their resources to use them for other

purposes during a period of time of length τ. This

allows resources exploitation ever when S is

unavailable. Finally, CH

informs the requester R

about the abrupt interruption.

Information collection: In this phase, CH

requests

from all servers S

, 1

<m< n reports on the usage

related to the Grid service involving S. A report

should contain the nature of the task, the state of the

execution, the intermediate results and the remaining

tasks scheduled, if needed. Each report should refer

to the server responsible of the execution of job J

S then collects all the reports and sends them to the

immediate requester R.

Resource discovery: When receiving the

intermediate reports, R should start a new request for

new nodes (and resources) that are able to replace S

and continue J

execution. R begins by

communicating with servers S

, 1

<m< n. It starts

with the resource that may provide a better QoS in a

secure manner (Abdelkader and Boudriga, 2005). If

one among servers S

accepts the replacement, R

sends it the set of collected reports execution reports.

In addition, R generates a new delegation credential

allowing S

to start service recovery. If no node in

, 1

<m< n } is able to accept the request, R can

get back to the selection phase of S and asks whether

one node among those competing with S can still

handle the replacement, otherwise, it restarts the

discovery process with the initial request published

during the selection phase of S.

In the case where an agreement is concluded, R

presents to the new server the different intermediate

reports related to J

, if a server S

is selected, or the

initial request, if no S

is willing the replacement.

Service recovery: Three cases should be

considered:

1. If one server S

is selected for the

replacement of S, the recovery process

described in the preventive case is applied.

In this case, the 3-tuple (R,S,{S

, 1

<m<

n}) is replaced by the 3-tuple (R, S

,{ S

i≠m and 1

<i< n}) in the Grid service, and

new routes are built.

2. If a server, say S’, that has competed with S

is selected, the procedure used in the first

case is involved, provided that S’ plays the

role of S

. In this case, the 3-tuple

(R,S,{S

, 1

<m< n}) is replaced by the 3-

tuple (R, S’,{S

, 1

<i< n})

ICE-B 2006 - INTERNATIONAL CONFERENCE ON E-BUSINESS

3. If a new server T, servers S

, 1<m< n, are

dropped and the 3-tuple (R,S,{S

, 1

<m<

n}) is replaced by the 3-tuple (R, T,{T

<i< t}) and new routes are built

appropriately.

By receiving the identity of the new job

manager, the servers involved in cases a) and b) give

the priority to suspended tasks and continue their. In

case 3, the server delete all computation made for

the Grid service. We should note, however, that

service recovery is only possible before the

expiration of τ and the release of resources

immediately after τ has expired, if no resume is

engaged.

4 SECURE INFRASTRUCTURE

In this section, we show what makes the presented

infrastructure secure. In fact, security mechanisms

integrated in our solution protect GRID applications

from different types of attacks such as those related

to integrity violation, denial of service, and node

defacement. However, the intrusion tolerance

provided with SAGA guarantees robustness against

a set of attacks that should be maintained.

A. Security Provision

Since the integration of digital credentials such as

the X.509 public key certificates ensures mutual

authentication between ad-hoc nodes, provides

efficient digital signature, and protect the message

exchange related to Grid service provision, SAGA

assumes the nodes contributing to Grid services have

digital credential allowing them to authenticate each

other, provide confidentiality and protect ad-hoc

nodes. Therefore, integrity of transmitted messages

is ensured. Furthermore, a delegation service is

guaranteed through specific credential definition. A

delegation credential specifies identities of

delegating and delegated nodes, delegated rights,

and delegation validity. It may also address

information related to accounting. Protection of

delegation credentials is ensured by a digital

signature. This allows the verification of

authenticity, integrity and non repudiation of the

delegated rights.

On the other hand, Intrusion tolerance in SAGA

is guaranteed through the use of:

1. Preventive mechanisms that are based on

the notion of trust level, which classify

applications according to their requirements

on security and behaviour. The

management of trust guarantees that

requesting nodes (to access a Grid service)

are authorized only when they present a

level of trust higher or equal to the level

required to access the service

2. Detection mechanisms that allow the

employment of cooperative local intrusion

detection systems (IDS), which detect

appropriate events and exchange security

alerts

3. Recovery mechanisms allow dynamic trust

management which is responsible for

maintaining the trust level of node

according to their behaviour and the attack

they are subject to.

The basic idea behind the trust management

assumes that the trust level of a node (or application)

seen by a second node is initially defined by the

digital credential of the node and can be decreased

with the reporting alerts.

B. Protection Against Denial of Service

The deployment of an adaptive GRID on ad hoc

networks introduces new types of attacks. Those

attacks are related to the nature of information and

messages exchanged between nodes participating in

GRID service provision. Among these attacks, one

can mention the denial of service attack (DoS) that

can target the adaptive GRID. The following special

attacks are important to protect SAGA against:

Erroneous-Alert attacks: These attacks are launched

to force reactive infrastructure modification. Such an

attack operates as follows:

• A hacker interrupts all the messages transmitted

between the server S and its cluster head CH

during a period of time lasting sufficiently long.

• After a certain period of time, CH

realizes that S

is no longer reachable and begins the reactive

procedure which induces the abortion of the

GRID jobs handled by S and the waist of

resources on the ad-hoc network.

This attack induces the augmentation of the

execution delay of a GRID service. When repeated

on different servers, these attacks might generate a

distributed denial of service and endanger the system

availability. Different protections can be used

against these attacks. Protections may include; but

are not limited to: (a) the duplication of the role of

; (b) an effective control of the reachability of S

(CH

asks the remaining nodes of its cluster to try to

reach S, for example) and (c) keeping the role and

communication made by S confidential. In fact,

when the reachibility of S is under investigation,

SAGA: AN ADAPTIVE INFRASTRUCTURE FOR SECURE AVAILABLE GRID ON AD-HOC NETWORKS

should not generate the alerts related the needed

reaction, it saves the reports and messages to deliver

to S until investigation completion and delivers them

appropriately.

Alert-Absence attacks: The attacks target the

reactive infrastructure. They operate as follows:

• When a server S involved in a Grid service is no

longer available, its cluster head CH

generates

an alert to inform elementary resources to

suspend the execution of jobs managed by S.

• A hacker interrupts the transmission of the alert.

The resources involved with S (S is a service

operator) continue to be reserved for S although

S is no longer available.

These attacks may induce several damages

including: (a) useless resource locking and other

jobs are delayed; (b) loss of intermediate reports that

continue to be sent to CH

where they are deleted or

ignored and (c) unacceptable overhead for the

network and all the nodes contributing to the Grid

service routing.

A protection against these attacks aims at

imposing that every resource involved with server S

should receive an acknowledgment from S after

sending an intermediate report. Those

acknowledgments should be protected and should

refer to the report they are acknowledging.

Service Interruption Attacks: These attacks can

target the predictive and reactive infrastructure

modification. They aim at interrupting the

initialization of a Grid service, blocking the

communications between a service operator and the

resources (or nodes) {S

}

1<i<n

involved with it,

replaying sensitive messages, or modifying the value

of the new Grid-index field that we have added to

the packet header (see Section 2). Regarding the

latter attack, one can perform it as follows:

• A hacker can distinguish the application that has

a Grid-index A

. Then it can interrupt all the

communications related to this application by

modifying the Grid-index field content.

• It also can copy all messages, reports and

transported results related to the application

associated with index A

• The hacker also can change the index A

and so

neither S nor the nodes {S

}

1<i<n

can reach each

other. This induces the starvation of the GRID

application and the loss of network resources.

To protect against these attacks, various

mechanisms can be added including the protection

of the integrity of the Grid-index content, the

insertion of protected nonce (a sequence number or

time stamp) and IPSec.

5 SAGA APPLICATION

In this section we illustrate the use of the scheme

presented in the previous sections. We consider an

interesting domain of applications that can take

place on an ad hoc network. This is a distributed

application, referred to as micro-payment on ad-hoc

environment.

In (Tewari and O’Mahony, 2003), authors

propose a protocol employing micro-payment

techniques. The protocol allows each ad hoc node

involved in packets relaying to be paid by the sender

as it provides the service. It allows paying all nodes

in the path to a given destination without the

requirement to contact a third trust party or a bank to

issue a new payment contract. The main steps of this

protocol are described as follows:

1. A user buys prepaid tokens through his/her

terminal from a broker whose main purpose is to

aggregate micro-payments between entities. The

user starts by generating an unbalanced one-way

binary tree and sends the set of N defined

anchors to the broker.

2. The broker generates a set of N secret

endorsement values; one for each anchor value

that was sent by the user. A broker endorsement

consists of an anchor value, a random number

corresponding to the endorsement value, the

length of the hash chain, the value of a hash in

the chain, the identity of the user that purchased

the chain and the expiration date of the chain.

All of the above fields are signed with the private

key of the broker. The Grid service associated with

this application assumes the following:

• When it is desired to set up a call to a remote

destination (or asset of call to remote

destinations). The user should have knowledge

of the total costs involved in forwarding the

related packet through the ad hoc network. Each

node in the path to destination(s) must indicate

its charge for packet forwarding.

• With every packet or message sent by the

user, the user should attach the cost of

transmission. Every node in the established

route extracts the value of the cost required.

The unit defined to pay the different nodes

is a single hash token. Thus, every node

presents the number of tokens it wants for

the forwarding.

The integration of this application in a Grid

infrastructure should introduce some modifications

for the sake of flexibility. In fact, we propose the

integration of this application to pay the use of

different resources used in a Grid application (i.e.,

ICE-B 2006 - INTERNATIONAL CONFERENCE ON E-BUSINESS

Grid accounting). Modifications assume that the

requester R knows only the set of immediate servers

}

1<i<n

and it is not supposed to identify the set of

the other nodes contributing to the execution of the

Grid service. In addition, a Grid application can

offer other services than packets forwarding, which

means that every node should determine

dynamically the cost that it requires to contribute to

the Grid service.

To manage the new assumptions, we assume that

a server S

(e.g.;, service provider) is responsible for

paying for the resources,{S

i,j

}

1<j<ni

, that it can get

involved in. In fact, after determining the set of

resources with which S

will collaborate, S

asks for a

total cost including the use of all resources needed to

perform the tasks it is assigned. S

collects all the

costs and adds them to its local costs. The total cost

is then sent to the applicant R. Based on the

delegation credentials initially generated and the

trust levels of R and S

. R presents an appropriate set

of tokens to S

. These tokens are encrypted with the

public key of S

. Then, S

manages these tokens to

cover its own cost and the costs of S

i,j

, for 1<j<n

When paying a contributing S

i,j

, S

should encrypt

the required tokens by the public key of S

i,j

. In

addition tokens should no longer go together with

each packet.

We assume that after collecting the tokens

corresponding to a service provision, a server

presents these tokens to the broker which is

responsible for concluding the payment. Before

making the transfer, the broker should wait for a

period of time. This period is fixed by the

administrator allowing the reception of any

objection. In fact, if a node takes the tokens without

achieving the tasks for which it was paid, the payer

could protest against concluding the payment. If this

period of time expires without receiving any

objection, the transfer is concluded and the server is

paid.

Finally, new security features should be

considered according to the SAGA model. They

include:

• In the case of predictive modification,

before a server S withdraws, it should pay

all the contributing resources for the jobs

they are involved with S. Furthermore, S

should return the unused tokens to requester

R. The latter will give other tokens to the

new server S’. The operation of giving new

tokens can be kept as it was defined in

(Tewari and O’Mahony, 2003).

• In the case of reactive modifications, the

contributing resources {S

}

1<i<n

to a

withdrawing server S should inform R

about the last payment they obtained. R

informs the broker to revoke the remaining

tokens and use new tokens to continue

GRID service provision. In this case, we

believe that there is a need to tolerate very

limited token losses since the applicant can

not define precisely when S was gone away.

Two reasons can justify our tolerance. This

assumption can be made since micro-

payment is a field where such assumptions

are accepted, when they are limited. In fact,

this kind of payment reduces the possible

losses since it divides the payment amount

into small values. In addition, the trust

management provided in SAGA can require

that a node, which does not conclude its

agreements without signalling it, will see a

decrease in its trust level. This will impact

its further works.

6 CONCLUSION

In this paper, we addressed the issue of adaptive

behaviours in a Grid service provision. Our

approach builds systems called SAGA that are able

to define a framework for the design of Grid

application that are secure, tolerant to intrusion and

can cope with the variable nature of ad-hoc

networks.

The framework provides a generic extension

mechanism for integrating multi-level trust

management, QoS, and intrusion tolerance

functionalities into Grid applications and handle

variations in topology and availability.

REFERENCES

Casanova, W. Cirne, H. Dail, M. Faerman, S. Figueira, J.

Hayes, G. Obertelli, J. Schopf, G. Shao, S. Smallen,

N. Spring, A. Su, and D. Zagorodnov,

Adaptive

computing on the Grid using AppleS, IEEE

Transactions on parallel and distributed systems, Vol.

14, No. 4, pp. 369- 382, Apr. 2003

S. Song and K. Hwang, Dynamic Grid security with trust

integration and optimized resource allocation, Int.

Symp. On High-performance distributed computing,

Honolulu, June 4-6, 2004.

A. Butt, S. Adabala, N. Kapadia, R. Figueiredo and J

Fortes, Fine-grain access control for securing shared

resources in computational Grids, 2002 Proc. Int.

SAGA: AN ADAPTIVE INFRASTRUCTURE FOR SECURE AVAILABLE GRID ON AD-HOC NETWORKS

Parallel and distributed processing symposium

(IPDPS’02), pp. 159-165, April 2002,

F. Azzedin and M. Maheswaran, Towards trusted-aware

resource management in Grid computing systems,

Proc. 2

IEEE/ACM Int. Symp. on cluster computing

and the Grid, 2002.

K. Czajkowski, I. Foster, and C. Kesselman,, “Resource

co-allocation in computational Grids”, Proc. 8

IEEE

Int. Symp. on high-performance distributed computing

(HPDC-8), pp. 219-228, 1999.

D. Gefen, V.S. Rao, and N. Tractinsky, “The

conceptualization of trust, risk, and their relationships

in e-commerce”, Proc. 36

Hawaii Int. Conf. on

System science (HICSS’03), 2003.

I. Foster, C. Kesselman, and S. Tuecke, “The anatomy of

the Grid: Enabling scalable virtual organizations”, Int

J. Supercomputer applications, 2001

Manel Abdelkader, Noureddine Boudriga. "Intrusion

Tolerant GRID in Ad-Hoc Networks", 12

IEEE

International Conference on Electronics, Circuits and

Systems, ICECS 2005, Tunis, Dec. 11-14, 2005.

Rui Liu, and Errol L. Lloyd, “A Distributed Protocol For

Adaptive Link Scheduling in Ad-hoc Networks", Proc.

of IASTED Int. Conf. on Wireless and Optical Comm.

(WOC2001), 2001.

Hitesh Tewari, Donal O'Mahony, “Multiparty

Micropayments for Ad Hoc Networks", IEEE Wireless

Communications and Networking Conference, WCNC

2003.

ICE-B 2006 - INTERNATIONAL CONFERENCE ON E-BUSINESS
