SEARCHING MOVIES BASED ON USER DEFINED SEMANTIC

EVENTS

Bart Lehane

Centre for Digital Video Processing

Dublin City University

Noel E. O’Connor

Adaptive Information Cluster

Centre for Digital Video Processing

Dublin City University

Hyowon Lee

Centre for Digital Video Processing

Dublin City University

Keywords:

Video Retrieval, Event-Based Movie Indexing, Video Searching.

Abstract:

The number, and size, of digital video databases is continuously growing. Unfortunately, most, if not all, of the

video content in these databases is stored without any sort of indexing or analysis and without any associated

metadata. If any of the videos do have metadata, then it is usually the result of some manual annotation

process rather than any automatic indexing. Locating clips and browsing content is difﬁcult, time consuming

and generally inefﬁcient. The task of managing a set of movies is particularly difﬁcult given their innovative

creation process and the individual style of directors. This paper proposes a method of searching video data in

order to retrieve semantic events thereby facilitating management of video databases. An interface is created

which allows users to perform searching using the proposed method. In order to assess the searching method,

this interface is used to conduct a set of experiments in which users are timed completing a set of tasks using

both the searching method and an alternate, keyframe based, retrieval method. These experiments evaluate the

searching method, and demonstrate it’s versatility.

1 INTRODUCTION

Decreasing production costs as well as widespread

availability of content creation tools have led to an in-

crease in the amount of digital video being produced.

As the video databases which store this content con-

tinue to grow, they are becoming increasingly difﬁcult

to manage. This difﬁculty is largely due to the lack of

information about the stored video. Manually asso-

ciating metadata to video is both labor intensive and

time consuming, so is impractical in many cases. Ide-

ally, some automatic process is required in order to

structure the data so that the video can be efﬁciently

managed. This paper presents an approach which fa-

cilitates searching of video data in order to retrieve

semantic events.

There are many video content types that are in need

of indexing. Sporting programs, news programs, or

documentaries are just some of the content genres

created each day. However, ﬁctional video content,

speciﬁcally movies, are a medium particularly dif-

ﬁcult to manage for a number of reasons. Firstly,

their temporally long nature means that it is difﬁ-

cult to manually locate particular portions of a movie,

as opposed to, say, a thirty minute news program.

Most movies are at least one and a half hours long,

with many as long as three hours. Summarisation of

movies is also hindered due to its challenging nature.

Each movie is created differently, using a different

mix of directors, editors, cast, crew, plots etc., which

results in varying styles. Filmmakers are given am-

ple opportunity to be creative in how they shoot each

scene, which results in diverse and innovative video

styles. This is in direct contrast to the way most news

and sports programs are created, where a rigid broad-

casting technique must be followed as the program

makers have an extremely short time span in which to

make their program.

There have been many approaches to movie sum-

marisation, although most focus on segmenting the

232

Lehane B., E. O’Connor N. and Lee H. (2006).

SEARCHING MOVIES BASED ON USER DEFINED SEMANTIC EVENTS.

In Proceedings of the International Conference on Signal Processing and Multimedia Applications, pages 232-239

DOI: 10.5220/0001569802320239

 SciTePress

movie or detecting speciﬁc occurrences rather than

implementing a searching strategy. Many approaches

aim to summarise movies by detecting scene bound-

aries and creating a scene based index. For exam-

ple, (Yeung and Yeo, 1996; Yeung and Yeo, 1997;

Rui et al., 1998; Zhou and Tavanapong, 2002) all

aim to cluster similar shots together, and locate ar-

eas where one set of clusters does not relate to any

previous clusters. Other approaches, such as (Li and

Kou, 2003; Rasheed and Shah, 2003; Sundaram and

Chan, 2000), use the concept of shot coherence to lo-

cate scene boundaries. In general, this involves locat-

ing areas where fundamental changes in audiovisual

features occur. However, a scene based index does

not carry any semantic meaning, and it is difﬁcult to

locate a sought part of a movie with scene bound-

ary information alone, unless each individual scene

is viewed.

Many other movie summarisation approaches fo-

cus on detecting individual event types from the

video. (Leinhart et al., 1999) detect dialogues in

video based on the common shot/reverse shot shoot-

ing technique, which results in detectable repeating

shots. This approach however, is only applicable to

dialogues involving two people, since if three or more

people are involved the shooting structure will be-

come unpredictable. Also, there are many other event

types in a movie or television program apart from di-

alogues. (Li and Kou, 2003; Li and Kou, 2001) ex-

pand on this idea to detect three types of events, 2-

person dialogues, multi-person dialogues and hybrid

events (where a hybrid event is everything that isn’t

a dialogue). However, only dialogues are treated as

meaningful events and everything else is declared as

a hybrid event. (Chen et al., 2003) aim to detect both

dialogue and action events in a movie, however the

same approach is used to detect both types of events,

and the type of action events that are detected is re-

stricted. (Nam et al., 1998) detect violent events in

a movie by searching for visual cues such as ﬂames

or blood pixels, or audio cues such as explosions or

screaming. This approach, however, is quite restricted

as there may be violent events that do not contain their

chosen features. (Kang, 2003) extract a set of colour

and motion features from a video, and then use rele-

vance feedback from individual users to class events

into ‘fear’, ‘sadness’, or ‘joy’. (Zhai et al., 2004) gen-

erate colour, motion and audio features for a video,

and then use ﬁnite state machines to class scenes into

either conversation scenes, suspense scenes or action

scenes. However, this approach relies on the pres-

ence of known scene breaks, and classiﬁes a whole

scene into one of the categories, while in reality an en-

tire scene may contain a number of important events.

Previous work by the authors (Lehane and O’Connor,

2006), created an event based index of an entire movie

by devising a set of event classes that cover all of the

meaningful events in a movie. By detecting each of

the events in an event class, the entire movie is in-

dexed.

The object of the searching method proposed in this

paper is to retrieve sought events a movie. An event is

something which progresses the story onward. Events

are the portions of a movie which viewers remember

as a semantic unit after the movie has ﬁnished. A

conversation between a group of characters, for exam-

ple, would be remembered as a semantic unit ahead of

a single shot of a person talking in the conversation.

Similarly, a car chase would be remembered as ‘a car

chase’, not as 50 single shots of moving cars. A single

shot of a car chase carries little meaning when viewed

independently, it may not even be possible to deduce

that a car chase is taking place from a single shot,

however, when viewed in the context of the surround-

ing shots in the event, its meaning becomes apparent.

Events are components of a single scene, and a scene

may contain a number of different events. For exam-

ple, a scene may contain a conversation, followed by

a ﬁght, which are two distinct events. Similarly, there

may be three different conversations (between three

sets of people) in the same scene, corresponding to

three different events. The searching system in this

paper aims to return events to a user, rather than spe-

ciﬁc shots. This allows for efﬁcient retrieval.

Previous work by the authors focused on the detec-

tion of speciﬁc events in movies. (Lehane et al., 2005)

proposed a method of detecting dialogue events,

while (Lehane et al., 2004a) proposed an exciting

event detection method. The approach in (Lehane and

O’Connor, 2006) built upon previous work in order to

generate a complete event-based summary of a movie.

In each of the approaches above, a set of audiovi-

sual features were generated, and ﬁnite state machines

were utilised in order to detect the relevant events.

Each of the approaches examined ﬁlm grammar prin-

ciples in order to assist in the event detection process.

The work presented in this paper extends upon the

event detection structure in order to allow user spec-

iﬁed searching. This allows a human browser to re-

trieve events based on their requirements, rather than

on a predeﬁned structure. As this paper presents an

extension of previous work, the explanation of por-

tions of the system design elements is reduced, in par-

ticular the feature generation process.

The presented approach only utilises audiovisual

searching. No textual information is used, and the re-

sults are solely based on the extracted features. Sec-

tion 2 describes the feature generation part of the

search system, which includes the feature selection

process, and the creation of a shot-level feature vector.

Section 3 describes the actual search method. This is a

two step process. Firstly, ﬁnite state machines (FSMs)

are utilised in order to generate a set of sequences, and

secondly, a layer of ﬁltering is undertaken and a set

SEARCHING MOVIES BASED ON USER DEFINED SEMANTIC EVENTS

233

of events is returned. A user interface which allows

searching using the proposed method is presented in

Section 4. Following this, a set of experiments and re-

sults in which the search based system is compared to

a shot-based retrieval system are presented in Section

5. Finally, Section 6 contains a set of conclusions and

future work.

2 FEATURE GENERATION

This section describes the features extracted in or-

der to retrieve events. As the system is used for re-

trieval of events within movies, the features were cho-

sen based on the amount of information they convey

regarding the occurrences in movies. By examining

ﬁlm making principles it is possible to select a set of

features that indicate a ﬁlm makers intent, and there-

fore contain the most information as to the occur-

rences in the movie. These features are extracted and

combined into a shot-level feature vector. All of the

analysis in this paper is undertaken on MPEG-1 video

and PCM encoded WAV audio, but could be applied

to other formats.

2.1 Feature Selection

The techniques used by directors and editors to cre-

ate ﬁlms were examined, and the resultant observa-

tions were utilised in order to aid in the design of

the searching system. Thus, the audiovisual features

which can be used to garner the most information

from a movie are extracted and incorporated into the

system. For example, the use of camera movement

is often used in order to show excitement during an

event. If an event such as a ﬁght is taking place, typ-

ically the camera moves rapidly to follow the action.

Contrarily, a lack of camera movement is used in or-

der to show relaxation, and to allow users to focus

on the occurrences on screen (Bordwell and Thomp-

son, 1997). Therefore, knowledge of the amount of

camera motion present in a given shot, or sequence of

shots, is important.

The type of audio present is also useful for search-

ing as it allows a user to infer activities of characters.

For example, if a user is searching for a conversa-

tion between characters, then knowing the areas of a

movie where the audio type is ‘speech’ is useful. Sim-

ilarly, if a montage

event is sought, then areas with

musical shots will be of interest to a searcher. Thus,

a set of audio features were chosen that can be used

to classify the audio into a number of classes that de-

scribe the different types of audio present in a movie.

A montage is a collection of shots that span space

and/or time. Montages usually have a strong musical back-

ground

These classes are: Speech, Music, Silence, Quiet Mu-

sic and Other.

Colour information can also be used to infer se-

mantics from a movie. Firstly, colour information can

be used in order to detect shot boundaries and select

keyframes for each shot, which is a ﬁrst step for most

video indexing systems. The frequency of shot cuts

can also be detected using the shot boundary informa-

tion. Increased editing pace is often used by ﬁlm mak-

ers to create excitemtent. When shooting a particular

event, lighting and colour typically remain consistent

throughout. This can be utilised to locate boundaries

between events, as when the overall colour changes

signiﬁcantly it is a strong indication that an new event

has begun (Bordwell and Thompson, 1997). Thus,

similar shots can be clustered together in order to ﬁnd

locations in a movie where one event ends and an-

other begins. The clustering information can also be

used to determine how much shot repetition is taking

place in a given sequence of shots. This may indicate

interactions between characters.

2.2 Feature Extraction

The aim of the feature extraction process is to gener-

ate a set of features for each shot in a movie. This set

of features is termed the shot-level feature vector.

2.2.1 Colour Features

The aim of colour analysis is to generate a feature that

represents a frame of video so that it can be com-

pared to other frames, both for frame matching and

for shot boundary detection. In order to achieve this,

colour histograms are utilised. A 64-bin colour his-

togram is extracted for each frame of video. In order

to detect shot boundaries, the inter frame histogram

difference is calculated. If it is greater than a prede-

ﬁned threshold, a shot boundary is declared (Lehane

et al., 2004b). One keyframe is selected per shot by

examining the average values of the frames in a shot

and locating the frame which is closest to the average.

Using the shot boundary information, the shot lengths

are found and inserted into the shot-level feature vec-

tor.

Once the shot boundaries are located, keyframes

that have similar colour are clustered together. There

are two reasons for clustering shots together, the ﬁrst

is to locate boundaries between events. Using a tech-

nique adapted from (Yeung and Yeo, 1996) (explained

more thoroughly in (Lehane et al., 2005)), it is pos-

sible to locate areas in the movie where the camera

moves from shooting in one location to another, signi-

fying an event boundary. The second reason for clus-

tering shots is so that shots ﬁlmed with the same cam-

era angle (for example, repeating shots in a conversa-

tion) can be identiﬁed. This gives information about

SIGMAP 2006 - INTERNATIONAL CONFERENCE ON SIGNAL PROCESSING AND MULTIMEDIA

APPLICATIONS

234

the type of occurrence on screen. For example, an

area populated with repeating shots is more likely to

involve interaction between characters than one with

many different shots. A measure of shot repetition

can be generated for a sequence of shots by examin-

ing the cluster to shot ratio (C:S ratio), ﬁrst presented

in (Lehane et al., 2004b). If there are many repeat-

ing shots (and therefore many clusters), the C:S ratio

will be quite low. If, however, most of the shots in

a sequence are visually different, there will be many

clusters, giving a higher C:S ratio.

2.2.2 Motion Feature

As outlined previously, MPEG-1 video is used for the

analysis, thus the motion vectors created during en-

coding can be used. Due to the fact that motion vec-

tors are compressed in the MPEG-1 data stream, a full

decode of the video is not required, which means that

analysis can be extremely fast. The motion informa-

tion from each P-frame is extracted.

The amount of camera movement in each shot is

detected. This method was previously presented in

(Lehane et al., 2005). This approach involves ex-

amining the motion vectors across the entire frame.

A threshold is used to distinguish between P-frames

with/without camera movement. In order to generate

a shot-based value for camera movement, the percent-

age of P-frames with camera movement in each shot

is calculated.

2.2.3 Audio Features

Each audio feature is generated at a rate of one per

second. In total, four audio features are extracted.

The High Zero Crossing Rate Ratio, the Silence Ra-

tio, the Short Term Energy, and the Short-Term En-

ergy Variation. The effectiveness of these features in

distinguishing between speech and music has previ-

ously been demonstrated (Chen et al., 2003; Lehane

et al., 2005). In order to classify each second of audio,

a set of support vector machines (SVMs) are utilised.

Details are provided in (Lehane et al., 2005). In sum-

mary, the SVMs classify each second of audio into an

audio class. These values are then up-sampled in or-

der to create a value for each shot. At the end of this

process, for each shot of a movie, there is a value for

the percentage of speech, music, silence, quiet music,

and other sound present.

3 SEARCHING TECHNIQUE

After feature generation, the shot-level feature vec-

tor contains the following values for every shot in a

movie: [shot length, % static camera frames, % non-

static camera frames,% speech, % music, % silence,

% quiet music, % other audio]. This feature vector

is used in order to conduct searching. There are two

steps involved in the search process. Firstly, an ar-

ray of ﬁnite state machines is created which allow a

user to locate areas where particular features domi-

nate. So for example, a music FSM locates the areas

where a large number of music shots occur in succes-

sion (termed a music sequence). Following this, an

optional ﬁltering step reduces the set of sequences re-

turned by the the FSM. So, for example, a user might

be interested in locating all of the areas in a movie

where there is a musical track combined with high

amounts of camera movement. In this case, the ﬁlter-

ing would involve removing all of the returned mu-

sic sequences from the music FSM that contain low

amounts of camera motion. The searching process is

depicted graphically in Figure 1.

3.1 Sequence Generation

Finite state machines are used in order to generate se-

quences of shots in which a particular feature domi-

nates. As can be seen from Figure 1, six FSMs are

created, corresponding to the features in the feature

vector. There is a speech FSM, a music FSM, a non-

speech FSM, a static camera FSM, a non-static cam-

era FSM and a high motion/short shot (HSMM) FSM.

The speech, music, static camera, and non-static cam-

era FSMs all locate areas where that particular fea-

ture dominates. The non-speech FSM locates areas

where there is no speech present (i.e. the audio type

is either silence, music or other). The HMSS FSM

was designed due to the strong link between increased

editing pace and camera movement when ﬁlm makers

want to depict excitement, and therefore it locates ar-

eas where both of these features are present. Each

FSM produces a list of start and end times (i.e. se-

quences) throughout the movie where the input fea-

ture(s) are dominant. The presence of an event bound-

ary resets the FSM, and signals the end of a particular

sequence. For further explanation of the FSMs, in-

terested readers are advised to consult (Lehane et al.,

2005; Lehane et al., 2004a).

3.2 Filtering

The second step in the searching process involves ﬁl-

tering the set of sequences generated by a FSM. For

example, the speech FSM may locate forty sequences

in a movie where speech shots are dominant (i.e. there

is somebody talking). The ﬁltering step allows users

to reduce this by rejecting sequences which do not

contain a certain feature. For example, ﬁltering al-

lows a user to select the maximum or minimum per-

centage of static camera shots that must be present

in a sequence. Thus, a user can place a constraint in

SEARCHING MOVIES BASED ON USER DEFINED SEMANTIC EVENTS

235

which at least, say, 60% of the shots in a generated

speech sequence must contain a static camera for it to

be retained. In total there are seven ﬁltering options,

which allow users to set boundaries for: the percent-

age of static shots, the percentage of non-static shots,

the percentage of speech shots, the percentage of mu-

sic shots, the percentage of non-speech shots, the per-

centage of short shots, and the amount of shot repe-

tition. Any sequences that are retained after ﬁltering

are termed events.

After the two-step search, a list of start and end

times of events is generated. Each of these events

corresponds to an area in which the selected features

dominate. In order to prepare these events for presen-

tation, a set of ﬁve keyframes are chosen to represent

the entire event. These keyframes are chosen at equal

time increments throughout the event. Section 4 il-

lustrates how these events are presented to a user for

browsing.

3.3 Discussion

Typically, when shooting an event, a ﬁlm maker will

remain consistent in shooting style for the duration

of an event. Thus, the use of FSMs to locate areas

where particular features are dominant is central to

the event retrieval process. For example, a conversa-

tion will typically contain speech throughout. When

the speech ends, it indicates that the conversation it-

self is ﬁnished. So in order to locate a particular con-

versation, a searcher can use the speech FSM, which

returns all of the areas with high amounts of speech,

and possibly ﬁlter the returned vales to only retain

sequences of shots with a high amount of repetition.

This would remove many areas of speech that are not

conversations (voiceovers etc.).

Each time the search system is used, the user must

ﬁrst decide on which FSM to use. This involves se-

lecting a feature that occurs throughout the sought

event. So, for example if a searcher wants to ﬁnd a

particular event, say a conversation that takes place

in a moving car, he/she could use the non-static cam-

era FSM to ﬁnd all the non-static camera sequences

(as there will be camera movement due to the moving

car), and then ﬁlter the results by only accepting the

sequences with a high amount of speech shots. In this

way, a number of events will be returned, all of which

contain high amounts of moving camera shots and

high amounts of speech. The user can then browse

the returned events and view the desired conversation.

Note that another way of retrieving the same event

would be to use the speech FSM and then ﬁlter the re-

turned sequences by only allowing the ones with high

amounts of non-static shots through.

Similarly, a searcher could be looking for an event

in a nightclub, where two people’s eyes meet and they

stare at each other across the dance ﬂoor. To ﬁnd

this event, the sequences generated by the music FSM

could be used, and then ﬁltered by only accepting the

sequences with a high amount of shot repetition, or

by only accepting sequences with a high amount of

static camera shots. Figure 1 illustrates this two-step

approach. In the ﬁrst step, the set of music poten-

tial sequences is selected. Secondly, these potential

sequences are ﬁltered by only retaining potential se-

quences with a user deﬁned amount of static camera

shots. This results in a retrieved event list as indicated

in the ﬁgure.

In some cases no ﬁltering may be desired, and the

sequences returned by the FSM may be the desired

events. For example, a ﬁlm student may be interested

in analysing how music is used in a particular ﬁlm.

The student could use the music FSM to ﬁnd all of

the areas where music is present, with no ﬁltering re-

quired.

4 MOVIEBROWSER SYSTEM

A system, called the MovieBrowser, that allows

searching movies as described above was developed.

A sample screen from this system can be seen in Fig-

ure 2. On the top of the screen, the search feature

selection interface can be seen. Using this panel, it

is possible to select the FSM and ﬁltering options as

outlined in Section 3. Figure 2 shows the system pre-

senting a set of search results. In this ﬁgure, the mu-

sic FSM is chosen, and the ﬁltering only retains se-

quences with high amounts of static camera shots (as

can be seen by the checkbox in the top right). Five

keyframes from each returned event are displayed.

Some other information about the event (timing, num-

ber of shots etc.) is also displayed. It is possible to

play the retrieved events in an external video player

by clicking on the ‘Play’ button.

The MovieBrowser system also allows users to

browse every shot in a particular movie. This simply

displays the keyframe from each shot to the browser.

Thus, if a user knows that a particular event occurs

at a certain point in the movie, he/she can browse all

shots in the movie in order to locate the event.

A number of movies were used as input to the

MovieBrowser system. The movies were chosen to

represent a broad range of origins, and span different

geographical locations including America, Australia,

Japan, England and Mexico. The test data in total

consists of ten movies corresponding to over eighteen

hours of video.

SIGMAP 2006 - INTERNATIONAL CONFERENCE ON SIGNAL PROCESSING AND MULTIMEDIA

APPLICATIONS

236

Table 1: Average time in seconds taken for each browsing

method.

Average time for all tasks = 132.4 S

Average time for keyframe based method = 155.7 S

Average time for search based method = 98.9 S

5 EXPERIMENTAL ANALYSIS

5.1 Experimental Setup

In order to assess the effectiveness of searching for

user deﬁned events in a movie and presenting them

to a user as an indexing solution, a set of experi-

ments using the MovieBrowser were devised. The

experimental process involves a number of users com-

pleting a set of tasks. Each task asks the user to

retrieve a particular clip using either the proposed

searching method, or the keyframe based browsing

method. Each task was completed by four volunteers,

two users using the keyframe based method and two

users using the searching method. The time taken to

complete each task was noted, so the results are di-

rectly comparable. In total, thirty tasks were created.

For example, one task was “In the ﬁlm High Fidelity,

Find the part where Barry sings ‘Lets get it on’ with

his band”, while another was “In the ﬁlm Reservoir

Dogs, Find the getaway scene when Mr. Pink is run-

ning away from the cops”.

An automatic timing program was implemented

that recorded how long it takes a user to complete

each task, and also to check whether users have lo-

cated the correct event. Once a user has located a

clip in the movie that he/she considers to be correct,

they enter the time of the event into the system (which

compares this time with the manually annotated start

and end times of the tasks). If the supplied time is

correct (i.e. between the start and end time of the

relevant part of the movie) the time taken to com-

plete the task is automatically recorded. If a user sup-

plies an incorrect time, he/she is instructed to continue

browsing in order to ﬁnd the correct time of the event.

If a user cannot complete a task, there is an option

to give up searching. If this happens, an arbitrarily

large completion time (ﬁve minutes) is assigned for

the task. This heavily penalises non-completion of

tasks. In order to compare results for different users,

a pre-test questionnaire was created in which the vol-

unteers were required to state which ﬁlms they had

seen before, and how long ago. Also, for equality,

each user was supplied with thumbnail pictures of the

main characters in each movie. Each user was brieﬂy

trained on the two retrieval methods, and then asked

to begin their tasks.

Table 2: Average task completion times by browsing

method, where the average results are shown for users that

had, and had not seen the ﬁlm previously.

Method Used Average Time Average Time

For Unseen For Seen

Movies (s) Movies (s)

Keyframe method 187.5 145.11

Search method 124.3 92.7

5.2 Results

The average task completion times are presented in

Table 1. As can be seen, the average task completion

time for the search based system is signiﬁcantly lower

than the average completion time for the keyframe

based retrieval method. On two occasions users gave

up whilst using the search based method, thus the

maximum time was allocated (ﬁve minutes). These

were the only two tasks that were not completed. In

both cases, the users were not familiar with the movie,

and although the results returned from searching con-

tained the sought event, these were not recognised.

Table 2 presents the average task completion times

for users that had, and had not, viewed the movie pre-

viously. Predictably, when the movie had not been

viewed previously, the retrieval times are longer. In

both cases the search based method results in supe-

rior performance. The slower retrieval time for un-

seen movies is largely due to the aforementioned non-

completion of two tasks, as, if the ﬁve minute time

was not allocated, then the average time would have

been 89.2 Seconds.

The search-based method performed well in most

cases. When the users chose features appropriately

it provided for efﬁcient retrieval. The user selection

of features is central to the success of each search. It

was observed that, in general, users had no difﬁculty

in selecting appropriate features.

The users that performed best using the search

based method were the ones that did low amounts

of ﬁltering, and relied heavily on the FSMs. This

usually meant a slightly larger amount of events to

browse through, but, as the results show, the returned

events can be navigated quickly. In some cases the

best search method involved selecting a FSM with

a feature that the user knows is prevalent in the de-

sired event, and then browsing all results. The results

for the search based method may improve if the user

interface is altered, as some volunteers noted that it

could be made more user friendly. Also, as the search

based system requires the most user input, a larger

amount of training time may help users familiarise

themselves with the system and result in better search

queries.

SEARCHING MOVIES BASED ON USER DEFINED SEMANTIC EVENTS

237

6 CONCLUSIONS

This paper presented a method of searching movies

based on user deﬁned events. A set of audiovisual

features were chosen and extracted from movie ﬁles.

A searching method was developed that facilitates re-

trieval of events in a movie using a combination of ﬁ-

nite state machines and ﬁltering. A system, called the

MovieBrowser, implemented this searching method

in the form of a graphical user interface. In order

to assess the searching method, a set of user exper-

iments were conducted which timed users complet-

ing a task using both the searching method and a

keyframe based retrieval method. These experiments

shows the effectiveness of this method of searching.

Future work will involve reﬁning the ﬁltering

process in order to allow for different combinations

of features. Also, the search interface will be altered

to make it more user friendly. Although this paper

focused on investigating audiovisual retrieval, the ad-

dition of textual data (obtained from movie subtitles)

would signiﬁcantly aid the retrieval process and result

in improved performance.

ACKNOWLEDGEMENTS

The support of the Irish Research Council for Sci-

ence, Engineering and Technology is gratefully ac-

knowledged. This material is based on works sup-

ported by Science Foundation Ireland under Grant

No. 03/IN.3/I361.

REFERENCES

Bordwell, D. and Thompson, K. (1997). Film Art: An In-

troduction. McGraw-Hill.

Chen, L., Rizvi, S. J., and

Otzu, M. (2003). Incorporating

audio cues into dialog and action scene detection. In

Proceedings of SPIE Conference on Storage and Re-

trieval for Media Databases, pages 252–264.

Kang, H.-B. (2003). Emotional event detection using rele-

vance feedback. In Proceedings of the International

Conference on Image Processing.

Lehane, B. and O’Connor, N. (2006). Workshop on image

analysis for multimedia interactive services (wiamis),

incheon, korea. In Movie Indexing via Event Detec-

tion.

Lehane, B., O’Connor, N., and Murphy, N. (2004a). Action

sequence detection in motion pictures. In The inter-

national Workshop on Multidisciplinary Image, Video,

and Audio Retrieval and Mining.

Lehane, B., O’Connor, N., and Murphy, N. (2004b). Dia-

logue scene detection in movies using low and mid-

level visual features. In International Workshop on

Image, Video, and Audio Retrieval and Mining.

Lehane, B., O’Connor, N., and Murphy, N. (2005). Di-

alogue scene detection in movies. In International

Conference on Image and Video Retrieval (CIVR),

Singapore, 20-22 July 2005, pages 286–296.

Leinhart, R., Pfeiffer, S., and Effelsberg, W. (1999). Scene

determination based on video and audio features. In In

proceedings of IEEE Conference on Multimedia Com-

puting and Systems, pages 685–690.

Li, Y. and Kou, C.-C. J. (2001). Movie event detection by

using audiovisual information. In Proceedings of the

Second IEEE Paciﬁc Rim Conferences on Multimedia:

Advances in Multimedia Information PRocessing.

Li, Y. and Kou, C.-C. J. (2003). Video Content Analysis us-

ing Multimodal Information. Kluwer Academic Pub-

lishers.

Nam, J., Alghoniemy, M., and Tewﬁk, A. H. (1998). Audio-

visual content-based violent scene characterization.

In Proceedings of International Conference on Image

Processing (ICIP), volume 1, pages 351–357.

Rasheed, Z. and Shah, M. (2003). Scene detection in holly-

wood movies and tv shows. In IEEE Computer Society

Conference on Computer Vision and Pattern Recogni-

tion.

Rui, Y., Huang, T. S., and Mehrotra, S. (1998). Constructing

table-of-content for video. In ACM Journal of Multi-

media Systema, pages 359–368.

Sundaram, H. and Chan, S.-F. (2000). Determining com-

putable scenes in ﬁlms and their structures using

audio-visual memory models. In ACM Multimedia

2000.

Yeung, M. and Yeo, B.-L. (1996). Time constrained clus-

tering for segmentation of video into story units. In

Proceedings of International Conference on Pattern

Recognition.

Yeung, M. and Yeo, B.-L. (1997). Video visualisation for

compact presentation and fast browsing of pictorial

content. In IEEE Transactions on Circuits and Sys-

tems for Video Technology, pages 771–785.

Zhai, Y., Rasheed, Z., and Shah, M. (2004). A framework

for semantic classiﬁcation of scenes using ﬁnite state

machines. In International Converence on Image and

Video Retrieval.

Zhou, J. and Tavanapong, W. (2002). Shotweave: A shot

clustering technique for story browsing for large video

databases. In Proceedings of the Workshops XMLDM,

MDDE, and YRWS on XML-Based Date Management

and Multimedia Engineering-Revised Papers.

SIGMAP 2006 - INTERNATIONAL CONFERENCE ON SIGNAL PROCESSING AND MULTIMEDIA

APPLICATIONS

238

Step 2: Select FilteringStep 1: Select Set of

Sequences

Static Camera

Sequences

0.30 - 3.10

4.05 - 4.50

9.10 - 15.07

.....

Non-Static

Camera

Potential

Sequences

0.30 - 3.10

4.05 - 4.50

9.10 - 15.07

.....

HMSS

Sequences

0.30 - 3.10

4.05 - 4.50

9.10 - 15.07

.....

Non-Speech

Sequences

0.30 - 3.10

4.05 - 4.50

9.10 - 15.07

.....

Music

Sequences

0.30 - 3.10

4.05 - 4.50

9.10 - 15.07

.....

Speech

Sequences

0.30 - 3.10

4.05 - 4.50

9.10 - 15.07

.....

% Non-Static Shots

% Short Shots

% Speech Shots

% Music Shots

% Non-Speech

Shots

Filtering Of

Sequences

Retrieved Event

List

3.10 - 4.05

8.30 - 9.02

17.03 - 18.55

.....

CS Ratio

% Static Shots

Sequences

Figure 1: The user deﬁned searching process.

Figure 2: The search panel used to ﬁnd events with a set of speciﬁed features.

SEARCHING MOVIES BASED ON USER DEFINED SEMANTIC EVENTS

239
