RANDOMISED DYNAMIC TRAITOR TRACING

Jarrod Trevathan

School of Mathematical and Physical Sciences

James Cook University

Wayne Read

School of Mathematical and Physical Sciences

James Cook University

Keywords:

Restricted multimedia content, piracy, watermarking, complexity analysis.

Abstract:

Dynamic traitor tracing schemes are used to trace the source of piracy in broadcast environments such as ca-

ble TV. Dynamic schemes divide content into a series of watermarked segments that are then broadcast. The

broadcast provider can adapt the watermarks according to the pirate’s response and eventually trace him/her.

As dynamic algorithms are deterministic, for a given set of inputs, the tracing algorithm will execute exactly

the same way each time. An adversary can use this knowledge to ensure that the tracing algorithm is forced

into executing at its worst case bound. In this paper we review dynamic traitor tracing schemes and describe

why determinism is a problem. We ammend several existing dynamic tracing algorithms by incorporating

randomised decisions. This eliminates any advantage an adversary has in terms of the aforementioned attack,

as he/she no longers knows exactly how the tracing algorithm will execute. Simulations show that the ran-

domising modiﬁcations inﬂuence each dynamic algorithm to run at its average case complexity in terms of

tracing time. We provide an efﬁciency analysis of the ammended algorithms and give some recommendations

for reducing overhead.

1 INTRODUCTION

The proliferation of high speed Internet connections,

mobile phones and Cable TV (PayTV) has made

online multimedia content accessible to the masses.

Downloading movies, songs and pay-per-view con-

tent is becoming increasingly popular. While this

technology is convenient, it has also been accompa-

nied by a signiﬁcant rise in piracy. File sharing pro-

grams such as DC++

make it easy to for anyone to

distribute pirated material to countless other illegiti-

mate viewers.

An individual that makes a copy of, and/or views

content in the above context is referred to as a pi-

rate. The traditional method for preventing piracy is

to encrypt the content and issue the users with a de-

coder. The decoder is a program or device that con-

tains a set of keys capable of decrypting the message.

Although this approach prevents unauthorised parties

from eavesdropping on the content, piracy can still

occur in the following ways:

- An authorised user retransmits their copy of the

digital content to an unauthorised user; or

http://www.dcplusplus.sourceforge.net

- A pirate has access to a set of legitimate user’s keys

that allows the pirate to construct a pirate decoder

which is capable of interpreting the encrypted con-

tent.

In either scenario, such legitimate users who willingly

aid a pirate are known as traitors.

While an ideal solution to piracy is to stop it from

occurring in the ﬁrst place, this is almost impossible

to achieve in reality given the presence of traitors. It

is therefore prudent to assume that some piracy will

occur so that counter measures can be taken to deal

with the threat. A traitor tracing scheme is a mech-

anism that is designed to trace and cut off the source

of a pirate decoder or transmission once piracy has

been detected (see (Chor et al, 1994; Pﬁtzmann 1996;

Trevathan et al, 2003)).

A traitor tracing scheme can be considered as ei-

ther static or dynamic. In static schemes, keys found

in a pirate decoder are used to trace the legitimate

user who was originally allocated the keys. Keys

are allocated once and are not changed throughout

the lifetime of the content. This makes static tracing

schemes ideal for distribution of one-off content such

as DVDs, but is of limited use to online/real-time con-

323

Trevathan J. and Read W. (2006).

RANDOMISED DYNAMIC TRAITOR TRACING.

In Proceedings of the International Conference on Signal Processing and Multimedia Applications, pages 323-332

DOI: 10.5220/0001571203230332

 SciTePress

tent.

Dynamic schemes are able to adapt to a pirate’s ac-

tions in real-time by changing key allocations at cer-

tain intervals throughout the content. Watermarks are

embedded in the plaintext content. The tracing algo-

rithm in this case examines the watermark found in a

pirate copy and links this back to the particular users

who received the same watermark. The scheme at-

tempts to isolate suspected traitors by changing the

marking scheme in response to the pirate’s feed back.

When a traitor is identiﬁed the algorithm disconnects

them from future broadcast.

Various schemes for dynamic traitor tracing have

been presented (see (Fiat and Tassa, 1999; Berkman

et al, 2000; Safavi-Naini and Wang, 2000)). How-

ever, all of these schemes are deterministic. This is a

problem as a traitor is able to run through the tracing

algorithm in advance and totally deduce the marking

strategy that will be used. While this does not prevent

a traitor from being caught, this situation is undesir-

able, as it allows a traitor to force the algorithm to run

at its worst case complexity through strategic use of

feedback.

This paper discusses the implications of determin-

ism in dynamic traitor tracing schemes. We pro-

pose several amendments to existing dynamic trac-

ing algorithms that incorporate randomised decisions.

Through the use of random decisions, an adversary is

unable to predetermine the manner in which the trac-

ing algorithm will execute. This effectively removes

any beneﬁt that can be gained from altering the input

data for the tracing process. Simulations have shown

that there is a signiﬁcant gain in tracing efﬁciency and

hence security by making our proposed amendments.

This paper is organised as follows: Section 2 in-

troduces traitor tracing schemes. Section 3 describes

how dynamic traitor tracing schemes operate. Sec-

tion 4 shows how to incorporate randomness into sev-

eral existing dynamic traitor tracing schemes. Sec-

tion 5 provides an efﬁciency analysis of existing dy-

namic schemes and shows the effect on security that

randomisation provides. Section 6 provides some

concluding remarks.

2 TRAITOR TRACING SCHEMES

A traitor tracing scheme is an algorithm employed

by a content provider that enables piracy to be traced

back to its original source (a traitor). Once a traitor

has been discovered the content provider is then able

to take legal or extra-legal measures against them.

The problem of tracing traitors can be addressed via

careful key distribution or marking of content.

Tracing Goals

The goals of traitor tracing schemes and the desir-

able properties they should exhibit include:

• Capable of tracing the source of the piracy;

• Must not harm legitimate users by falsely incrim-

inating them, or by allowing traitors to be able to

frame them;

• The source of piracy should be denied from receiv-

ing future transmissions;

• Supply legal evidence of the pirate’s identity;

• Provide some value in deterring potential traitors.

Terminology/Notation

The following terminology and notation is used

throughout this paper. A user is denoted by u and is

the authorised receiver of the digital content. U is the

set of all authorised users U = {u

, ..., u

}, where u

is the ıth user in U . The broadcast provider encrypts

digital content and distributes it to U. A session is the

period for which the decryption keys are valid e.g., a

few minutes of video. Every user is allocated a set of

decryption keys that allows them to view the content.

This is referred to as a user’s personal key or code-

word. Some users may collude in order to distribute

illegal copies of the content to unauthorised users. We

refer to such users as traitors and to their coalition as

the pirate and denote them by T = {t

, ..., t

}, where

T ⊂ U. Some of the traitors may combine a subset of

their keys and construct a pirate decoder.

When a pirate decoder is found either in hardware

or software, its behaviour can be examined to deter-

mine which keys it is comprised of. By treating a

captured decoder as a black box and observing its

output when given particular inputs, the decryption

keys can be traced back to the members of T . Hence,

there is no need to tamper with the decoder in any

way. It is assumed that there are no mechanisms in

place to thwart the tracing algorithm. The manner in

which the tracing proceeds depends on the type of

scheme used.

Components of a Traitor Tracing Scheme

There are three main components that jointly con-

stitute a traitor tracing scheme:

1. Key generation/distribution scheme: used by

the data supplier to generate and distribute users’ per-

sonal keys. The data supplier has a master key, α, that

deﬁnes a mapping P

: U 7→ K, where U is the set of

possible users and K is the set of all possible personal

keys.

2. Encryption/decryption scheme: an encryption

scheme, E

, is used by the data supplier to encrypt

the session key before broadcasting, and a decryp-

tion scheme, D

, is used by each authorised user

(i.e., its decoder) to decrypt the session key, where

β = P

). The session key is used to encrypt

SIGMAP 2006 - INTERNATIONAL CONFERENCE ON SIGNAL PROCESSING AND MULTIMEDIA

APPLICATIONS

324

Enabling Block Ciphertext Block

Decrypt Session Key s

Decrypt Ciphertext Block

Plaintext Block

Decrypt

User’s personal key s

Figure 1: Encryption/Decryption of a segment.

data content using an off-the-shelf symmetric encryp-

tion scheme such as Advanced Encryption Standard

(AES) (Daemen and Rijmen, 1998).

3. Tracing algorithm: used upon conﬁscation of

a pirate decoder, to determine the identity of one or

more traitors. It is assumed that the contents of a pi-

rate decoder are unknown. Instead, the tracing algo-

rithm must access a pirate decoder as a black box, and

perform the tracing based on the decoder’s response

to different input ciphertexts.

The off-the-shelf encryption scheme E must be a

block cipher. The data supplier divides the content

into sessions whose size is a multiple of a block size

accepted by E. For each content session M, a typical

traitor tracing scheme will output two blocks. A ci-

phertext block B

is the result of encrypting M by the

encryption scheme E using a session key, s, randomly

chosen from the key space of E : B

= E

(M). A

second block is called an enabling block, because it

contains data that enables each authorised user to ob-

tain the session key and decrypt the corresponding ci-

phertext block (see Figure 1.3).

3 DYNAMIC SCHEMES

Static schemes are often limited to one-time mark-

ing of content such as DVDs. Legal recourse is only

taken after a pirate copy has been found which of-

ten involves the entire content being stolen before the

tracing procedure can even begin. In situations where

there is some ongoing relationship between the users

and the content provider (such as PayTV or Internet

multicast applications), static schemes are often too

limited and miss out on opportunities to help trace

and/or punish traitors.

Dynamic traitor tracing assumes there exists an on-

line feedback channel from a pirate to the broadcast

provider. Such feedback may be the detected retrans-

mission of the content by the pirate or the publica-

tion of decryption keys in some publicly accessible

place (such as on the Internet). By observing the feed-

back sequence, a distributor can search for traitors by

adaptively changing the content marking scheme in

response to pirate activity. Eventually an individual

traitor can be isolated and disconnected from future

transmittal of information.

Dynamic tracing can be best described by the fol-

lowing combinatorial game which is an abstraction of

the scenario described above. This game serves as a

model for all dynamic schemes presented throughout

this section.

A session is the duration of a piece of information

to be broadcast. A session is split up into segments

, ..., j

. Each j is divided into ℓ variants v

, ..., v

ℓ

where each variant is unique (i.e., v

6= v

, i 6= k).

All variants have the same information but contain a

robust watermark (using the methods of (Boneh and

Shaw, 1995)). Given any set of variants v

, ..., v

for

a particular segment, it should be impossible to gen-

erate another variant that cannot be traced back to the

original variants from which it was comprised. The

terms colour, mark and variant are used interchange-

ably.

In each round, the algorithm assigns a variant v of

the current segment to every user. This is followed by

the pirate’s response, which is a variant of one of its

supporting traitors. The pirate’s series of responses is

referred to as a feedback sequence and is denoted by

F . When feedback f

, for segment j

is detected from

the pirate (where 1 ≤ i ≤ l), f

is appended to F .

When a particular variant that was only given to

one set of users is found in F , this implies that the

set contains a traitor. A traitor is located if only a

single user (and no one else) was the recipient of a

variant that is given as the pirate’s response. Since

the number of traitors is not known in advance, this is

the only way to locate a traitor. A traitor that has been

RANDOMISED DYNAMIC TRAITOR TRACING

325

located is disconnected, i.e., removed from U thereby

excluding them from all succeeding rounds.

The pirate loses the game when s/he does not an-

swer. This most likely means that s/he has gone out

of business because the algorithm has located and dis-

connected all traitors. The performance of the scheme

is measured by the maximal number of variants used

in any single round (marking alphabet) and also the

number of rounds needed in the worst case (conver-

gence time). There is a trade-off between the two

measures.

A pirate does not have to decide in advance who

the p traitors are. Instead, s/he can choose the traitors

adaptively throughout the game. However, once he

decides to corrupt a user, s/he is committed to this

decision until the end of the game.

(Fiat and Tassa, 1999) present three deterministic

dynamic tracing schemes. These algorithms are re-

ferred to as the FT1, FT2 and FT3 algorithms respec-

tively. (Fiat and Tassa, 1999) establish that the theo-

retical minimum bound on the number of variants re-

quired to trace any number of traitors in the dynamic

model is p + 1. Two of the proposed algorithms use

p + 1 variants, but have an exponential convergence

time. The other algorithm has a convergence time

polynomial in p, but uses 2p + 1 variants.

(Berkman et al, 2000) propose an algorithm that

traces all p traitors in O(p

log n) rounds using p + 1

variants. This is referred to as the clique algorithm.

The clique algorithm is used to construct an optimal

algorithm that is able to trace all traitors in polynomial

time using the minimal number of variants. (Berkman

et al, 2000) show that by increasing the number of

variants used in the optimal algorithm, a measurable

trade-off in convergence time can be obtained.

4 RANDOMISED DYNAMIC

TRACING

All dynamic schemes created so far are determinis-

tic. This means that a pirate is able to run through the

tracing algorithm in advance and totally deduce the

marking strategy that will be used. While this does

not prevent a pirate from being caught, this situation

is undesirable, as it allows a pirate to force the al-

gorithm to run at its worst case complexity through

strategic use of feedback.

This can be best illustrated using the Quicksort al-

gorithm (Hoare, 1961). Given a set of data to sort,

the Quicksort algorithm chooses an element from the

array (referred to as the pivot). The data is partitioned

either side of the pivot such that elements less than the

pivot are below it, and those greater are above it. The

algorithm then recursively sorts the partitions. Quick-

sort is deterministic and given the same set of input,

will execute exactly the same way each time.

The performance of the Quicksort algorithm de-

pends on the pivot point chosen. On average, this al-

gorithm runs in O(n log n) steps where n is the num-

ber of items to be sorted. However, if the set of data is

already nearly sorted, performance degrades to O(n

)

steps.

Consider the case where an adversary of the Quick-

sort algorithm is permitted to order the array. The ad-

versary can in each instance force the Quicksort algo-

rithm to run in its worst case complexity by ensuring

that the array is reverse sorted. By doing so, the array

will always be split into two unbalanced sets, a set of

one element and a set consisting of the remainder of

the array. (Further attacks of this nature on Quicksort

are described in (McIlroy, 1999).)

To protect against this type of attack, random

choices can be introduced into the sorting process.

For example, the array is randomly re-ordered prior

to sorting, and/or the pivot point is randomly chosen.

Under these conditions, the adversary does not beneﬁt

from pre-ordering the input data. Random decisions

ensure that the algorithm runs at its average case com-

plexity, regardless of the initial order of input data.

Dynamic traitor tracing schemes are no different

to the Quicksort algorithm. The traitor can inﬂuence

the algorithm to perform at its worst case complexity,

thereby delaying his/her tracing. Likewise random

decisions can also be used in dynamic traitor tracing

to ensure average case complexity.

This section presents several amended dynamic

schemes from literature. Each algorithm has been

altered to include random decisions during the trac-

ing process. This ultimately removes any advantage a

traitor has in terms of the aforementioned attack.

4.1 FT1 Algorithm

The FT1 Algorithm uses the optimal number of

variants (i.e., p + 1). Traitors are traced by marking

designated combinations of users based on the

current known traitor count t. Either all traitors

will be isolated when the correct combination of

users is selected, or there are more than the current

number of known traitors in the system. The latter

scenario allows us to increment the traitor count by

one and repeat the same process with an extra variant.

Convergence time is O(





+ 2×

p−1

t=0





Algorithm 4.1 - FT1

1. Set t = 0

2. Repeat forever:

(a) For all selections of t users out of U, w

, ..., w

⊂ U,

produce t + 1 distinct variants of the current segment

and transmit the ith variant to w

, 1 ≤ i ≤ t, and

SIGMAP 2006 - INTERNATIONAL CONFERENCE ON SIGNAL PROCESSING AND MULTIMEDIA

APPLICATIONS

326

qq q

Figure 2: FT2 Algorithm using graph notation.

the (t + 1)th variant to all other users, until the pirate

transmits a recognised variant.

(b) If the pirate ever transmits variant i for some i ≤ t,

disconnect the single user w

and decrement t by one.

Otherwise, increment t by one.

In step 2(a), users are added to the suspect group

(i.e., those whom are issued with a unique variant)

according to an ordered sequence. An adversary can

ensure worst case timing by only using traitors that

are towards the end of the sequence. We propose two

methods that can be used to protect this algorithm

from this type of attack. Firstly, the set of users U

in step 1 can be randomised to prevent a pirate from

initially ordering the data (i.e., placing traitors at the

end). Secondly, the selection of the next user added

to the suspect set (step 2(a)) can also be randomised.

This ensures that it is no safer embed traitors at the

end of the group, than it is anywhere else in the group.

4.2 FT2 Algorithm

The FT2 Algorithm uses 2p + 1 variants and locates

all p traitors in O(p log n) rounds. The algorithm

(shown below) uses a recursive approach by continu-

ously dividing and recombining groups of users. This

scheme introduces a ‘trusted’ set of users (denoted

by I). Initially, all users are considered innocent

and are part of I. It is only when piracy is detected

from this set that all its members become suspects,

allowing us to increase the known traitor count.

When piracy is detected from any particular group

(I inclusive) it is evenly divided and the resulting

two subgroups are marked as a pair (L

, R

) forming

part of the partition P of U. The partner set of the

split group is added to I, which in a sense means

that the algorithm also searches for innocent users.

Although this greatly improves convergence time, it

comes at the cost of increasing the number of variants.

Algorithm 4.2 - FT2

1. Set t = 0, I = U, P = I.

2. Repeat forever:

(a) Transmit a different variant for every non-empty set of

users S ∈ P .

(b) If the pirate transmits a variant v of the current seg-

ment then:

- If v is associated with I, increment t by one, split

I into two equal sized subsets, L

and R

, add those

sets to P and set I = ∅.

- If v is associated with one of the sets L

, 1 ≤ i ≤ t,

do as follows:

i. Add the elements in R

to the set I.

ii. If L

is a singleton set, disconnect the single trai-

tor in L

from the user set U, decrement t by one,

remove R

and L

from P and renumber the re-

maining R

and L

sets in P .

iii. Otherwise (L

is not a singleton set), split L

into

two equal sized sets, giving new sets L

and R

- If v is associated with one of the sets R

, 1 ≤ i ≤ t,

do as above while switching the roles of R

and L

Graph notation can also be used to represent the

data structures of dynamic algorithms. For example,

the tracing process of the FT2 algorithm can be de-

picted by an undirected graph G = (V, E). Each ver-

tex represents a set of users and an edge (X, Y ) con-

necting two vertices indicates that the subset X ∪ Y

contains a traitor (see Figure 2). The allocation of

variants effectively colours each vertex of the graph.

When the pirate transmits a colour given to a vertex,

the vertex is split and an edge is added. If the ver-

tex only contains one user (referred to as a singleton

vertex), then that user is a traitor and is disconnected.

As in the FT1 algorithm, users are in an ordered se-

quence and it is possible to determine precisely where

a given set will be split. An adversary can ensure that

s/he selects the traitors in a manner that results in the

most number of splits. We recommend that to prevent

this from occurring, the set of users U in step 1 should

be randomised to prevent a pirate from initially order-

ing the data. Next, the division point for a set must

not occur precisely in the middle of the ordered se-

quence. Instead, we endorse that the members of the

set must be randomly reordered before splitting. This

ensures that the pirate cannot determine where it is

safe to embed traitors in the sequence.

4.3 FT3 Algorithm

The FT3 Algorithm effectively combines the previous

schemes. As this algorithm uses p + 1 variants, at

each step either a group is split, or the FT1 algorithm

is being run on an individual group. In order to do

this, the algorithm keeps a lower bound on both the

current known number of traitors, k, and also t, the

RANDOMISED DYNAMIC TRAITOR TRACING

327

number of subsets of users {L

, R

} in the partition

P of U . Each pair is known to contain at least one

traitor. This algorithm makes progress at every stage

but is still exponential in convergence time, requiring

O(3

p log n) rounds.

Algorithm 4.3 - FT3

1. Set t = 0, k = 0, I = U, P = I.

2. Repeat forever:

(a) For every selection of S

, ..., S

⊂ P where S

∈

, R

, 1 ≤ i ≤ t, and S

, t + 1 ≤ i ≤ k are any

other k − t sets from P , produce k + 1 variants, σ

1 ≤ i ≤ k + 1. Transmit σ

to S

for all 1 ≤ i ≤ k,

while all remaining users get variant σ

k+1

(b) Assume that the pirate transmits at some step a variant

that corresponds to a single set in P (when K <

2t) those are the variants σ

where 1 ≤ i ≤ k; when

k = 2t, on the other hand, all variants correspond to

a single set, since then also σ

k+1

is transmitted to just

one set). In that case:

i. If σ

corresponds to an L

set, then that set must con-

tain a traitor. In that case add the complementary set,

, to I and split L

into two equal sized sets giving

a new L

, R

pair. In this case neither t nor k changes

but eventually, when the size of the incriminated set

is one, disconnect the traitor in that set. When this

happens, restart the loop after decrementing k and t

by one.

ii. If σ

corresponds to an R

set, we act similarly.

iii. If σ

corresponds to I, it allows us to increment t by

one (and k as well, if k was equal to t), split I into a

new L

, R

pair, set I = ∅ and restart the loop.

k+1

, after com-

pleting the entire loop increment k by one and restart

the loop.

To prevent a pre-ordering attack, we recommend

that the set of users U in step 1 be randomised. As

this algorithm is a hybrid of the previous algorithms,

the randomising amendments for the FT1 and FT2 al-

gorithms also apply to this algorithm.

4.4 Clique Algorithm

The clique algorithm uses fully connected subgraphs

in the tracing procedure. The clique algorithm utilises

the basic strategies of (Fiat and Tassa, 1999) and is

employed in the construction of a polynomial algo-

rithm. The clique algorithm itself is not optimal. It

traces all traitors in O(p

log n) rounds, using p + 1

variants.

The data structure for this algorithm is referred

to as a (t, k)-graph where t ≥ k ≥ 0. A graph

G = (V, E) is a (t, k)-graph if G contains t + k + 1

vertices, including I. These vertices form a partition

of U and all (except possibly I) are non-empty. Any

edge (X, Y ) ∈ E, implies that the subset X ∪ Y

contains a traitor. The vertices in V \{I} are par-

titioned into k disjoint cliques {Q

, ..., Q

}, where

| = t

≥ 2 for each 1 ≤ i ≤ k. The number of

vertices in a (t, k)-graph is at most 2t + 1.

At each stage of the algorithm, the centre broad-

casts a segment and observes the pirate’s response.

Based on the feedback, users are partitioned into dis-

joint cliques of suspected traitors (see Figure 3). As

there may not be enough colours to give each vertex a

unique colour, the algorithm pairs the k cliques. This

forces the pirate to either transmit a colour given to

only one vertex, or to disclose an edge given to a pair

of cliques.

A response from a single vertex allows us to

split the vertex creating a new clique of size two.

Alternately, disclosed edges are added to the graph in

order to eventually merge two cliques together. When

a merging of cliques occurs, the users who appear to

be the most innocent at this stage of the algorithm

(least connected vertex in the new larger clique) are

placed in I. The algorithm continues in this fashion

until G only contains one clique of size t + 1. This

then allows us to give each vertex a distinct variant,

limiting the pirate to disclosing only one particular

vertex as its response.

Algorithm 4.4 - Clique

Start with a (0, 0)-graph G = (V, E) with I = U,

V = I, and E = ∅. Repeat the following phases:

Phase 1: Distributing the colours to the vertices of G

Allocate t

− 1 colours to each clique Q

for a total of t

colours. The last colour is allocated to I. We now describe

how to distribute these allocated colours in each zone and

block of G.

1. Colour each block in zone Z

separately, using the

colours allocated to the pair of cliques in it: Let B be

a block in Z

and let Q

and Q

be the two cliques in

B. By the deﬁnition of the blocks in zone Z

, there exist

four distinct vertices X

, X

∈ Q

and Y

, Y

∈ Q

such that (X

, Y

), (X

, Y

) /∈ E. Colour X

∪ Y

with

one colour and X

∪ Y

with another colour. Colour the

remaining t

−t

−4 vertices of Q

, Q

using the remain-

ing t

−t

−4 colours allocated to those two cliques, one

colour per vertex.

2. If Z

contains only the vertex I, then colour I using

the colour allocated to it. Otherwise, Z

contains also

a clique Q

and there exists a vertex X ∈ Q

, such that

(X, I) /∈ E. Use one colour for X ∪ I, and colour the

remaining t

− 1 vertices of Q

using t

− 1 colours, one

colour per index. (If I is empty, all vertices of Q

are

coloured with distinct colours.) Therefore, t

colours are

used, which is the total number of colours allocated to

and I.

Phase 2: Reorganising the graph following the pi-

rate’s response

1. If the pirate broadcasts a colour given to only one vertex

X: Remove X and the edges incident with it from G.

Split X into two new vertices X

, X

of equal size (or

SIGMAP 2006 - INTERNATIONAL CONFERENCE ON SIGNAL PROCESSING AND MULTIMEDIA

APPLICATIONS

328

Zone Z

Block B







Figure 3: Clique Algorithm.

differing in size by one, if |X| is odd), and add the edge

, X

(a) X = I: Deﬁne a new clique Q consisting of the two

vertices X

, X

. Set I = ∅, t = t +1, and k = k + 1.

Incorporate the clique Q into the zones (see step 3).

(b) Otherwise: Let Q

be the clique to which X belongs.

Set Q

= Q

\X.

i. If |Q|

= 1 then remove all edges incident with the

vertex remaining in Q

, remove this vertex from Q

and add it to I. Place X

and X

into Q

. The clique

now consists of the two vertices X

, X

ii. Otherwise, Q

is still a legal clique. In this case the

two sets X

, X

will form a new clique Q. Set k =

k+1 and incorporate the new clique Q into the zones

(see step 3).

2. If the pirate broadcasts a colour given to a pair of vertices

X, Y : Add the edge (X, Y ) to G, and:

(a) If this edge connects vertices belonging to a pair of

cliques Q

, Q

in some block B, and after adding this

edge, the block B contains a large clique Q of size t

− 1: Let Z be the remaining vertex in B that does

not belong to this large clique (i.e., Z /∈ Q). Remove

Z and all edges incident with it from its clique, and

add Z to I. Furthermore, set k = k − 1, remove the

cliques Q

, Q

and their block B . Incorporate the new

clique Q into the zones (in step 3).

(b) If this edge connects I and a vertex of the clique Q

zone Z

, and after adding this edge, Q

and I form a

clique on t

+ 1 vertices: Add I as a vertex to Q

and

create a new special vertex I = ∅. Set t = t+1 (since

was increased by 1).

3. If a new clique Q was created during one of the above

steps, reorganise the zones as follows to incorporateQ: If

zone Z

contains only I, place Q in zone Z

. Otherwise,

zone Z

contains a clique R in addition to I. In this

case, remove all edges incident with I, remove R from

, pair it with the new clique Q, and create in zone Z

a new block containing the cliques Q and R.

We suggest the following randomising amend-

ments to this algorithm. As usual, the set of users U in

step 1 can be randomised to prevent a pirate from ini-

tially ordering the data. Since this algorithm utilises

the approach of FT2, therandom amendments for FT2

also apply to the clique algorithm. That is, before a

vertex is split, the order of the users should be shuf-

ﬂed so that a pirate does not know which of the new

vertices they will end up in.

Furthermore, during the colouring stage, the algo-

rithm pairs vertices that do not have an edge and as-

signs them the same colour. In a sense the algorithm

is probing for traitors. This process occurs in a deter-

ministic manner and therefore the pirate gains some

information about the colouring sequence. We advo-

cate that this step be performed randomly so that the

algorithm spontaneously selects the next pair of ver-

tices for probing.

5 RESULTS

The algorithms described in this paper were imple-

mented in C++. A series of simulations was per-

formed to gauge the effectiveness of the proposed se-

curity enhancements. A pirate was given the task of

engaging in piracy against a content provider within

the scope of the game described in Section 3. The

pirate had complete knowledge of the tracing algo-

rithms and had the ability to run through the execution

sequence of the algorithm in advance.

In order to describe our results, we must ﬁrst

examine the complexity of dynamic traitor tracing

schemes. Table 1 lists the algorithms and their asso-

ciated complexities. The convergence time for a dy-

namic algorithm is a function of the number of users,

n, and the number of traitors, p, in the system. The

number of variants used depends on the number of

traitors p.

Clearly the FT2 algorithm achieves the best con-

vergence time. However, this is at the expense of an

RANDOMISED DYNAMIC TRAITOR TRACING

329

Table 1: Worst case bound on the dynamic algorithms and the performance of the deterministic algorithms vs the randomised

algorithms when run on simulated data.

Scheme Convergence Time Number of Variants Deterministic Randomised

FT1 Algorithm





+2 ×

p−1

t=0





p + 1 100% 4.1%

FT2 Algorithm O(p log n) 2p + 1 100% 4.7%

FT3 Algorithm O(3

p log n) p + 1 100% 3.2%

Clique Algorithm O(p

log n) p + 1 100% 4.5%

increased number of variants. The FT1 algorithm is

exponential and therefore not practical. Neither is the

FT3 algorithm. The clique algorithm uses p + 1 vari-

ants and is an improvement over FT1 and FT3. (Berk-

man et al, 2000) use the clique algorithm to create an

‘optimal’ algorithm that runs in polynomial time with

the minimum number of variants. However, this al-

gorithm is extremely complicated and is outside the

scope of this paper. We believe that while it is desir-

able to use the optimal number of variants, the results

of the FT2 algorithm seem to indicate that it may be

more practical to use a slightly higher number of vari-

ants in the interests of improving convergence time.

In order to test the average efﬁciency of our ran-

domised amendments, both deterministic and ran-

domised algorithms were implemented. Each algo-

rithm was run 250 times and the effectiveness of the

pirate in terms of the convergence time was recorded.

(see right side of Table 1.) Our results show that

the pirate consistently forced each deterministic algo-

rithm to run at its worst case bound for 100% of the

tests. However, the randomised algorithms only run in

their worst case bound on average for 4.125% of the

tests. Clearly this indicates that there is a deﬁnitive se-

curity advantage in performing simple randomisation

tasks in dynamic traitor tracing schemes.

We also found that a reduction in overhead for dy-

namic traitor tracing schemes could be attained via

the following means:

1. Keys do not necessarily have to be changed be-

tween segments for all users. Key updates are re-

ally only required for the users who are in a set

which is split. Using this approach the FT2 algo-

rithm, which typically uses 2p + 1 variants, can

achieve O(np) individual transmissions for all seg-

ments.

2. Not all of a session needs to be protected. Thresh-

old traitor tracing schemes (see (Naor and Pinkas,

1998)) only require a small percentage of the movie

to be protected to enable tracing. It is assumed that

if a pirate copy misses even part of the session, then

is not very valuable.

6 RESULTS/CONCLUSIONS

Dynamic traitor tracing schemes are used to trace the

source of piracy in broadcast environments such as

cable TV. Dynamic schemes divide content into a se-

ries of watermarked segments that are then broadcast.

The broadcast provider can adapt the watermarks ac-

cording to the pirate’s response and eventually trace

him/her. As dynamic algorithms are deterministic, for

a given set of inputs, the tracing algorithm will exe-

cute exactly the same way each time. An adversary

can use this knowledge to ensure that the tracing algo-

rithm is forced into executing at its worst case bound.

In this paper we review dynamic traitor tracing

schemes and describe why determinism is a prob-

lem. Using the Quicksort algorithm as an example,

we show how an adversary can order the input data

and can cause a similar problem to that faced by a

dynamic tracing algorithm. We also show how pre-

vious literature thwarted the Quicksort’s problem by

introducing random decisions at critical points in the

algorithm.

We amend several existing dynamic tracing algo-

rithms by incorporating randomised decisions. This

eliminates any advantage an adversary has in terms of

the aforementioned attack, as s/he no longer knows

exactly how the tracing algorithm will execute. Sim-

ulations show that the randomised amendments were

successfully able to force a dynamic algorithm to run

at its average case complexity.

Existing dynamic traitor tracing schemes strive to

achieve the best convergence time using the mini-

mal number of variants. While p + 1 is the the-

oretical minimum, it may be possible to design a

quicker algorithm if these constraints are somewhat

relaxed. Although (Berkman et al, 2000) provide

bounds for gains in convergence time through increas-

ing the number of variants, this is done in terms of

their somewhat complicated optimal algorithm. Fu-

ture work involves constructing a conceptually simple

tracing algorithm that achieves a better convergence

time than existing tracing algorithms. Ideally the al-

gorithm will aspire to use a number of variants that is

between p + 1 and 2p + 1.

SIGMAP 2006 - INTERNATIONAL CONFERENCE ON SIGNAL PROCESSING AND MULTIMEDIA

APPLICATIONS

330

REFERENCES

Berkman, O., Parnas, M. and Sgall, J. (2000). Efﬁcient

Dynamic Traitor Tracing, in 11th Annual ACM-SIAM

Symposium on Discrete Algorithms (SODA 2000),

586-595.

Boneh, D. and Shaw, J. (1995). Collusion-Secure Finger-

printing for Digital Data, IEEE Transactions of Infor-

mation Theory, vol. 44, no. 5, 452-465.

Chor, B., Fiat, A. and Naor, M. (1994). Tracing Traitors,

in Advances in Cryptology - Proceedings of CRYPTO

1994, vol. 839 of Lecture Notes in Computer Science,

257-270.

Daemen, J. and Rijmen, V. (1998). AES Proposal: Rijndael,

in First Advanced Encryption Standard (AES) Confer-

ence, Ventura, CA.

Fiat, A. and Tassa, T. (1999). Dynamic Traitor Tracing,

in Advances in Cryptology - Proceedings of CRYPTO

1999, vol. 773 of Lecture Notes in Computer Science,

354-371.

Hoare, C. A. R. (1961). ACM Algorithm 64: Quicksort, in

Communications of the ACM, 4(7):321.

McIlroy, M. (1999). A Killer Adversary for Quicksort, in

Software, Practice and Experience, vol. 29, 1-4.

Naor, M. and Pinkas, B. (1998). Threshold Traitor Tracing,

in Advances in Cryptology - Proceedings of CRYPTO

1998, vol. 1462 of Lecture Notes in Computer Sci-

ence, 502-517.

Pﬁtzmann, B. (1996). Trials of Traced Traitors, Information

Hiding, vol. 1174 of Lecture Notes in Computer Sci-

ence, 49-64.

Safavi-Naini, R. and Wang, Y. (2000). Sequential Traitor

Tracing, in Advances in Cryptology - Proceedings of

CRYPTO 2000, vol. 1880 of Lecture Notes in Com-

puter Science, 316-332.

Trevathan, J., Ghodosi, H. and Litow, B. (2003). Overview

of Traitor Tracing Schemes, in Communications of the

CCISA, Selected Topics of Cryptography and Infor-

mation Security, Taiwan, Volume 9, Number 4, 51-63.

RANDOMISED DYNAMIC TRAITOR TRACING

331
