AN EXTENDED ROLE-BASED ACCESS CONTROL

FOR WEB SERVICES

Yi-qun Zhu, Jian-hua Li, Quan-hai Zhang

Department of Electronic Engineering, Shanghai JiaoTong Univ.,Shanghai 200030, China

Keywords: Access Control, Web services, Web services security, Authorization.

Abstract: A key challenge in Web services security is the design of effective access control schemes that can

adequately satisfy Web services security requirements. Despite the recent advances in Web based access

control, there remain issues that impede the development of effective access control models for Web

services environments. One of them is the lacks of dynamic role management and attributes access control

for Web services. In this paper, we present a dynamic attribute-based role-based access control model

(DARBAC) to address the issues. The proposed approach introduces authorization group, which is used to

dynamically manages roles and privileges, and attribute based access control mechanism which is used to

protect the services and services parameters. We outline the configuration mechanism needed to apply our

model to the Web services environments.

1 INTRODUCTION

Web services are well known and widely accepted

because of features of reusing and interoperability.

Web services are loosely coupled applications using

well-known XML protocols for representation and

communication across the Internet. Compared to

centralized systems and client-server environments,

Web services are much more dynamic and

distributed, and their security poses unique

challenges. One of the challenges is how to design

effective dynamic access control model in XML-

based Web services.

Several access control models have been

proposed to protect the resources, such as DAC

(Discretionary Access Control), MAC(Mandatory

Access Control), RBAC(Role Based Access

Control) (Sandhu,1996) (Ferraiolo,2001). These

models are designed to protect the resources in static

environments and LAN-based applications, which

make them not really meet security needs of the

complicated Web services environments.

The access control is already becoming the hot

topic in the field of Web services security. Both the

subjects that request Web services and objects that

provide the resources are active and dynamic

entities. Some models that consider dynamic feature

of subject and object are proposed. The paper(

Yan

Han,2000

) introduces the notion of role-playing to

implement the dynamic management of activated

roles and proposes a general role-based object access

control model. Based on the task-based access

control(Deng JB,2003), the paper(

Xu Feng,2005)

proposes a service-oriented access control model

that combines the dynamic object of role-

playing(

Yan Han,2000) and designs its security

architecture(

Xu Feng,2004) A solution of the dynamic

feature of role(

Xu Feng,2005) is provided, and

traditional protected objects are replaced by services.

However, both services and their parameters must be

protected from unauthorized users in global

services(Roosdiana,2004). The model(

Xu Feng,2005)

can not provided a solution for protecting both

services and their parameters. The

paper(Roosdiana,2004) proposes a model that can

protect both services and parameters. However, it

can not take the dynamic feature of role into account

and can not completely express dynamic features of

role.

In this paper an extended role based access

control model is presented to address above

problems. By introducing “authorization group” and

“attribute access control” to the basic RBAC model,

we can address dynamic features of role and protect

the services attributes that consist of services and

parameters. The remainder of the paper is organized

as follows. The second section presents a dynamic

471

Zhu Y., Li J. and Zhang Q. (2006).

AN EXTENDED ROLE-BASED ACCESS CONTROL FOR WEB SERVICES.

In Proceedings of the International Conference on Security and Cryptography, pages 471-474

DOI: 10.5220/0002100404710474

 SciTePress

attribute-based RBAC model (DARBAC model) for

Web services and discusses the related issues. The

section 3 concludes our paper.

2 DARBAC MODEL

2.1 The Elements

Figure 1 depicts elements of DARBAC model and

their relationships with each other. The DARBAC

model introduces authorization group to dynamically

manage privileges in Web services. It protects

attribute of web service by enforcing attribute

access control at two levels, service level and service

attribute level. Service level access control ensures

that only authorized users invoke the web services.

Attribute level access control is applied only when

the authorized users pass the service authorization.

DARBAC model is composed by the below

entity set and the relations. The following definition

formalized the DARBAC model:

(1) U, R, P, and S (users, roles, permissions, and

services respectively).

(2) Service attributes (SA): Service attributes are

objects that are used as parameters or returned

values for Web services.For one service

get_price<title,project>,the attribute consists of

service name get_price and service parameters

title and project.In the process of invoking

services, the required information is passed in to

web services and its operation results are passed

out of web services by using the service

attributes. The service attributes for a service s

are represented SA(s), and SA(s)

⊆ SA.

(3) Access mode: An access mode is a type of

access to service attributes, such as read, write,

modify, etc. For example, a role r is granted

read on param1,which is used by service s. So,

the user who assigned to r can read param1 used

by s as its parameters or returned values for

Web services. param1

∈

SA(s). A role that be

able to execute Web services must be assigned

permissions for the service and access mode for

service attributes. An access mode can be

created by combining one or more access

modes. For example,modify can be the access

mode that combining read and write.

(4) UA,UA

⊆ U

R, a many to many user-to-role

assignment relation. User assignment is defined

as a tuple <user, role>. UA(r) denotes the set of

users that assigned to role r.

(5) RR,RR

⊆ R

R, a role-to-role relation. A

partial order on R is role hierarchy. Roles can be

created and ordered in a hierarchical manner. A

role can contain other roles in a role hierarchy.

When a role contains other roles, it inherits all

of the permissions to the services and service

attributes that the other roles have. When a role

contains other roles, such as r

and r

, the role

can inherit all the permissions of role r

and r

for the services and service attributes. If role r

and r

hold conflicting access modes on the

same service attributes, the role r

has all the

access modes on the service attributes.

(6) Service:A service is an abstraction of the

operations provided by the system on its

objects, and a service is designated by the

service name s. Services use the parameters as

the carrier of information that be passed in to(or

out of) the services. A service assigns a

minimum permission to each of its parameters.

(7) PA, PA

⊆ P

R, a many to many permission-

to-role assignment relation. For a role that be

able to execute service and get the information,

it must be granted permissions to service’s

attribute.

(8) SPA, SPA

⊆ SP

R, a many to many service-

permission-to-role assignment relation. When a

role is able to execute a service, it must be

granted permission to the service. SPA is

defined as a tuple <roles, services>.

(9) SAPA, SAPA

⊆ SAP

R, a many to many

service-attribute-permission-to-role assignment

relation. SAPA is defined as a tuple <roles,

service attributes>. A role must be granted

permissions to both the service and service’s

Figure 1:The Elements of DARBAC and its Relations with Elements in the Model.

Users Roles Access Mode

Service Attributes

Web Services

Actor

UA PA

Dynamic

Access

AMR

Authorization Group

SPA

Constraints

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

472

attribute to be able to execute service. After a

role passes the service authorization, it can get

the service information by using access mode of

service attribute in the SAPA.

(10) Actor: Actor is a dynamic object. Every actor

can be defined as a triple <user, role , t>, where

t is the period time of the actor. When a user u

that is be assigned a role r activates r, system

creates an actor a, which is <u, r, t>. The

constraints of r are passed to the actor a

accordingly.

(11) Authorization group: Authorization group is one

process of authorization. Figure 2 depicts

elements and relations involved in authorization

group. One authorization group consists of a

actor, permissions(P), and its lifecycle.

Authorization group can be defined as a

triple<actor, permissions, lifecycle>. When user

u activates role r that is assigned to u, system

creates an actor a that is <u,r,t>. So the actor a

has permissions of role r , which are represented

P(r). P(r) consists of permissions to the service

and service attribute. In the process of

implementing authorization group, the

permissions of the actor are called enabled

permissions(EP). EP consist of enabled

services(ES) and enabled service

attributes(ESA).

2.2 Dynamic Management

Authorization group has five basic states, which are

dormant, invoked, valid, invalid, hold. Authorization

group transform its state according to the dynamic

system information. Figure 3 depicts state transition

of authorization group.For example, when system is

busy, authorization group transform from valid to

hold and suspended. After completing authorization,

authorization group turns into invalid state.

The lifecycle of authorization group, which is

designated by the variable Lifecycle_AG, is decided

by services providers according to the system state.

For example, there are large numbers of users to

request the Web services, so that the services

provider can not undertake the busy condition. The

Web services providers can adjust the system

condition by adusting the size of Lifecycle_AG. If

AG is invalid state, the actor can not access to the

objects. When AG is in valid state, the role of

corresponding actor can access to the authorization

objects, service and service attributes. At the same

time, t of the actor is the time between the current

time and the time that actor is created. If t is in scope

of Lifecycle_AG, actor is in the work. When t

exceeds the value of Lifecycle_AG, actor is

inactivated and is destroyed. As a result, the role can

not execute the service and attributes.

2.3 Permission Assignment

DARBAC model enforces attribute access control at

two levels, service level and service attribute level.

If user u wants to get information of service s, u

must be assigned one or more roles. Role r, that is

assigned to the user u and can execute service s,

must be granted permissions to both service s and

attributes of s. Once role r passes the service level

access control, it also must pass the service attribute

access control. Roles maintain two lists, one is the

list of services that roles that are assigned to the

users have permissions to execute, the other is the

list of access modes of attributes that roles have

permissions to access. For a role that be able to

execute service and get the information, it must be

granted permissions to both the service and service

attributes.

Services use the attributes as the carrier of

information that be passed in to(or out of) the

services. A service assigns a minimum permission to

each of its parameters in order to enforce service

attribute level access control. That is to say, a

service must at least have read access to its input

parameter, write access to its output parameters.

2.4 Authorization

This section discusses how a user who nominates a

role is granted permissions to get the requested

service. Authorization changes with the context of

web services environments. In the DARBAC model,

Figure 3: State Transition of Authorization Group.

Do r m a nt Invoked Valid

Ho l d

Invali d

Invoke

Suspend Re s t o r e

Failure

Sus pen d

Complete

Us e

Te rmi na t e

Re ad y

Figure 2: Authorization Group.

ESA

SA(s)

AN EXTENDED ROLE-BASED ACCESS CONTROL FOR WEB SERVICES

473

the access control process is partitioned into four

phases, which are user assignment, permission

assignment, role activate, dynamically adjust

privilege. The decision to grant permissions to

invoke a service is based on the following :

(1) DARBAC model enforces service and service

attribute access control. When a user requests a

service, it must be assigned at least one role.

Role r, that is assigned to the user u and can

execute service s, must be granted permissions

both to service s and to attributes of s. Once

role r passes the service control, it also must

pass the service attribute control.

(2) A user is the services requestor. A user is given

a unique identity within a services

provider.When the user u requests the service s,

system passes the user’s identity authentication

and checks whether the user u has assigned the

role r that can execute the service. After user u

activates the role r that is assigned to the user u,

system creates the dynamic actor a to execute

the permissions of service and service

attributes for the user u.

When user u invokes the service, system checks

whether the authorization group(AG) is in valid

state. If AG is in invalid state, the role r of the actor

can not work. If the checking result is positive, the

corresponding actor begins to work and check for

value of t in the actor. If t is in scope of

Lifecycle_AG, actor is in the work. When t exceeds

the value of Lifecycle_AG, corresponding actor also

is destroyed. As a result, the corresponding role and

the permissions of service and service attribute are

revoked, and authorization also is stopped.

3 CONCLUSION

In this paper, we present a DARBAC model for

access control for Web services. It not only supports

dynamic access control based on security

environments condition, but also protects both

services and service attributes. By introducing the

notion of authorization group and attribute access

control mechanism, the model can enforce the

dynamic privileges management for Web services.

Compared to traditional RBAC, the DARBAC

model can manage privileges dynamically, and

suites global service features.

REFERENCES

Ravi S.Sandhu, Edward J.Coyne. Role-Based Access

Control Models, IEEE Computer, 1996,29(2):38-47.

Ferraiolo D.F., Sandhu R., Guirila S., Kuhn D.R.,

Chandramouli R.. Proposed NIST Standard for Role-

Based Access Control,ACM Transactions on

Information and System Security, Pages 224–

274,Vol. 4, No. 3, August 2001.

Yan Han,Zhang Hong,Xu Man-Wu.Object Modeling and

Implementation of Access Control Based on

Role,Chinese Journal of Computers, 2000,Vol.23

No.10.

Deng JB,Hong F. Task-Based Access Control, Journal of

Software,2003,14(1):76-82.

Xu Feng,Lin Guoyuan,Huang Hao,Xie Li. Role-based

Access Control System for Web Services,

In:Proceedings of the Fourth International

Conference on Computer and Information

Technology (CIT’04),Wuhan,2004,357-362.

Xu Feng, Lai Hai-Guang, Huang Hao, Xie Li. Service-

Oriented Role-Based Access Control, Chinese

Journal of Computers,2005,Vol.28 No.4.

Roosdiana Wonohoesodo, Zahir Tari. A Role based Access

Control for Web Services, In:Proceedings of the 2004

IEEE International Conference on Services Computing

(SCC’04), 2004.

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

474
