ACTION-TRIGGERED PUBLIC-KEY SYSTEM FOR GSM USING

RSA WITH PHONE-DEPENDENT ENCRYPTION

Rehab K. El Nemr

Computer Science department, Faculty of Media Engineering, German University in Cairo, Egypt

Imane Aly Saroit Ismail, S. H. Ahmed

Information Technology Department, Faculty of Computers and information, Cairo University, Egypt

Keywords: GSM, Authentication, Ciphering, A3/5/8, RSA, Public key and Digital Certificate.

Abstract: Security is a burning issue with intelligent security pausing as the most relevant as it is important in all types

of applications which suffer from security related concerns. Accordingly, Security has become a need rather

than a luxury. GSM Security flaws have been identified several years ago. Some of these flaws have been

mended by the 3GPP but others are left to discussion. In this paper we will integrate a well known technique

in the system; Public-key technique. Yet, we will introduce the solutions in a different point of view; they

are Action-Triggered, meaning; it will work only if the flaw occurs. The original system will work in

normal cases. We will also discuss End-to-End security and propose a mechanism of Key management to

provide the subscribers with private calls’ option. Phone-Dependent technique is conducted to consider

Service provider attacks.

1 INTRODUCTION

Mobile phones are used on a daily basis by hundreds

of millions of users, over radio links. Fixed phones

offer some level of physical security (i.e. physical

access is needed to the phone line for listening in).

Unlike a fixed phone, with a radio link, anyone with

a receiver is able to passively monitor the airwaves.

Therefore it is highly important that reasonable

technological security measures are taken to ensure

the privacy of user’s phone calls and text messages

(data) as well to prevent unauthorized use of the

service (J.

Quirke, 2004).

Global System for Mobile Communication (GSM)

specification 02.09 (GSM 02.09) identifies three

areas of security that are addressed by GSM as

follows:

Authentication of a user: it is the ability for a

mobile phone to prove that it has access to a

particular account with the operator.

Data and signaling confidentiality: this requires

that all signaling and user data are protected against

interception by means of ciphering.

Confidentiality of a user: when the network needs

to address a particular subscriber, or during the

authentication process, the unique IMSI

(International Mobile Subscriber Identity) should not

be disclosed in plaintext. Thus, someone

intercepting communications should not be able to

learn if a particular mobile user is in the area.

A more detailed Security features were specified

by Motorola Corporation (R. Campbell and D.

Mckunas, 2003) in their annual report as follows:

Mutual Authentication: The mobile user and the

serving network authenticate each other

Data Integrity: Signaling messages is protected by

integrity code

Network to Network Security: Secure

communication between serving networks.

User – Mobile Station Authentication: The user

and the mobile station share a secret key, PIN

(Personal Identification Number)

Visibility and Configurability: Users are notified

whether security is on and what level of security is

available

Multiple Cipher and Integrity Algorithms: The

user and the network negotiate and agree on cipher

and integrity algorithms. At least one encryption

algorithm exported on world-wide basis

175

K. El Nemr R., Aly Saroit Ismail I. and H. Ahmed S. (2006).

ACTION-TRIGGERED PUBLIC-KEY SYSTEM FOR GSM USING RSA WITH PHONE-DEPENDENT ENCRYPTION.

In Proceedings of the International Conference on Security and Cryptography, pages 175-182

DOI: 10.5220/0002101701750182

 SciTePress

Lawful Interception: Mechanisms to provide

authorized agencies with certain information about

subscribers

GSM Compatibility: GSM subscribers roaming are

supported by GSM security context

2 EXISTING SECURITY SYSTEM

When a subscriber is added to a home network for

the first time, a Subscriber Authentication Key (Ki)

is assigned in addition to the IMSI to enable the

authentication. Ki must be stored in the user’s SIM

(Subscriber Identity Module). At the network side,

the key Ki is stored in the AuC (Authentication

Center) (Chengyuan Peng,

2003). SIM is the small

smartcard which is inserted into a GSM phone. It

contains all of the details necessary to obtain access

to a particular account. The SIM card contains the

following values: (J. Quirke, 2004)(ETSI TS100

929, November 1999)

•

IMSI: International Mobile Subscriber Identity

– a unique number for every subscriber in the

world. It is saved in the SIM.

•

Ki: the root encryption 128-bit key. This key

seeds the generation of all keys and challenges

used in the GSM system. The Ki is highly

protected, and is only known in the SIM and the

network’s AuC.

The SIM itself is protected by an optional PIN; The

PIN is entered on the phone’s keypad, and passed to

the SIM for verification. Algorithms used in GSM

security architecture are: A3 (Used in the

Authentication procedure), A8 (Used to generate the

Private Key Kc), A5 (Used in Ciphering).

The two main security features offered by GSM

and the role of the above algorithms are discussed in

the following subsections.

a. Authentication

Authentication is needed in a cellular system to

prevent an unauthorized user from logging into the

network claiming to be an authorized mobile

subscriber. If this were possible, it would be easily

possible to “hijack” someone’s account and

impersonate that person (or simply making that

person pay for the services) (J. Quirke, 2004).

Authentication is a function which is triggered

by the network when a subscriber applies for a

change of subscriber-related information (location

updating) element in the VLR (Visiting Location

work together as a database of user information for

all people in the network and the immediate location

area. While the HLR stores the user records

permanently, the VLR dynamically stores the user

records of people in their location area to save time

connecting to the HLR. Also it is triggered when a

subscriber accesses to a service (call setup,

terminating calls, activation or deactivation of a

supplementary service) or when a subscriber

accesses to the network for the first time after

restarting of MSC (Mobile Service Switching

Center) or a VLR. Finally it is triggered when the

cipher key sequence number mismatch (Chengyuan

Peng,

2003). In order to authenticate a user to the

network, the SIM card should prove knowledge of

the correct K

but it will be highly insecure to send

the K

as a plaintext to the network for

authentication. The K

in this case can be

intercepted. Instead the procedure works as

following (O. Benoit1& N. Dabbous, 2004):

1. A connection is attempted between the phone

and the network. The phone submits its identity.

Where possible, it avoids sending its IMSI in

plaintext (to prevent eavesdroppers knowing the

particular subscriber is attempting a

connection). Instead, it uses its TMSI

(Temporary Mobile Subscriber Identity).

2. The network generates a 128-bit random

number, known as the RAND and uses the A3

algorithm to mathematically generate an

authentication token known as the SRES.

3. The network sends the RAND to the phone to

do the same.

4. At the SIM side, a 32-bit SRES is generated

which is returned to the network for

comparison. If the received SRES matches the

network’s generated SRES, then the K

’s must

be the same (to a high mathematical

probability), and the phone has proved

knowledge of the K

and is thus authenticated.

The RAND must obviously be different every

time. Otherwise, an attacker could impersonate the

user by sending the same SRES. If authentication

fails the first time, and the TMSI was used, the

network may choose to repeat the authentication

with the IMSI. If this fails, the network releases the

radio connection and the mobile should consider that

SIM to be invalid (O. Benoit1& N. Dabbous, 2004).

b. Ciphering

Ciphering is highly important to protect user

confidentiality. It is done to protect both data and

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

176

signaling information. The purpose of this function

is to avoid an intruder to identify a subscriber on the

radio path by listening to the signaling exchanges.

This function can be achieved by protecting the

subscriber’s IMSI and any signaling information

elements. Therefore, a protected identifying method

should be used to identify a mobile subscriber

instead of the IMSI on the radio path. The signaling

information elements that convey information about

the mobile subscriber identity must be transmitted in

ciphered form (Chengyuan Peng, 2003).

The GSM system uses symmetric cryptography -

the data is encrypted and decrypted using the same

ciphering key – the Kc. The idea is that the Kc

should only be known by the phone and the network.

If this is the case, the data is meaningless to anyone

intercepting it. The Kc should also frequently

change, in case it is eventually compromised (J.

Quirke, 2004). Whenever the A3 algorithm is run (to

generate SRES), the A8 algorithm is run as well.

The A8 algorithm uses the RAND and K

as input to

generate a 64-bit ciphering key, the Kc, which is

then stored in the SIM and is readable by the phone.

The network also generates the Kc and distributes it

to the Base Station handling the connection.

At any time, the network can then order the

phone to start ciphering the data (once authenticated)

using the Kc generated. The network can pick from

a number of algorithms to use, as long as the phone

supports the one chosen. It can choose from up to 7

different ciphering algorithms (or no ciphering),

however it must choose an algorithm the phone

indicates it supports. Currently there are 3

algorithms defined – A5/1, A5/2 and A5/3. It should

be noted that A5/0 (no encryption) is available for

use in countries where there may be political

obstacles in supplying cryptographic hardware, such

as Middle Eastern or certain former Soviet countries.

This allows roaming to continue to work, and also

offers these countries the ability to use modern GSM

handsets (Bruce Potter, May 2004).

3 EVALUATION OF THE

EXISISTING SECURITY

MEASURES

There are still some potential threats posed in the

GSM system although of these security measures

(GSM 02.09)(R. Campbell & D. Mckunas, 2003)(

Yong LI, Yin CHEN& T. MA, 2002)(L. Ertaul and

B. Kasim, June 2005) summarized as follows:

• Limited encryption scope (Encryption

terminated at the base station)

• Insecure key transmission (Cipher keys and

authentication parameters are transmitted in

clear between and within networks).

• Security through Obscurity- Authentication and

encryption algorithms were never made public.

The whole security model developed in secret

which rises suspicion that cryptographic

algorithms are weak. Although never published,

ciphering algorithm A5 has been reverse

engineered by authors in (A. Biryukov and A.

Shamir, 2000). Authentication algorithms are

also reversed engineered (J. Rao, P. Rohatgi, H.

Scherzer and S. Tinguely, 2002).

• End to end security is not provided.

• If track of TMSI is lost then the mobile needs to

transmit the IMSI, this can be done by the false

base station.

• Using the knowledge of IMSI and using

repeated authentication requests, the Ki can be

broken.

• Network does not authenticate itself to the

phone, making it possible for an attacker to set

up false base station.

• Ciphering is optional and is turned on by the

base station.

• It is believed that GSM is secure for average

users. However it is not secure for high security

transmission.

4 ACTION-TRIGGERED

PUBLIC-KEY SECURITY

SYSTEM (ATPKSS)

In our proposed integration system, public key

technique is the main factor. Public-key algorithms

are based on number theory. It is asymmetric,

involving the use of two separate keys, in contrast to

the symmetric conventional encryption, which uses

only one key (RSA Labs). Each one of the

communicating parties has a pair of keys, “Public

Key” and “Private Key”. Those keys are used in both

Encryption and Authentication (digital signature)

(William Stallings)(Limor Elbaz, 2002).

In this section we will emphasize on some of the

above problems and highlight the solutions in our

proposed system. Of course, using Public-key

technique in mobile communication is not un-

explored before but it was not used due to its high

computations that cause a delay. But our solutions

based on an Action Triggered mode, meaning, if a

ACTION-TRIGGERED PUBLIC-KEY SYSTEM FOR GSM USING RSA WITH PHONE-DEPENDENT ENCRYPTION

177

flow occurs, like losing the IMSI for example, the

use of public key system is triggered.

System to be proposed is based on the idea of

obtaining a digital certificate from a third trusted

party i.e: a CA. A digital certificate is an electronic

identity, constructed of a public key and an

identification of the owner of the corresponding

public key. Digital certificates are issued, managed

and revoked by a CA (Limor Elbaz, 2002). Problems

attached to the existence or the extinction of a CA is

mostly political. Issues like selecting the Certificate

Authority (CA) or selecting a certain public-key

algorithm that is most suitable for GSM are out of

our scope. Proposed system requirements are:

• The SIM/HLR/AuC/VLRs should have Digital

certificates along with their public keys.

• The Digital Certificate of the home network

should be distributed when a new SIM card is

issued to a customer.

• A public key Algorithm should be mounted on

the Mobile Station.

• The files in AuC and HLR should be protected

against attacks using highly secure procedure of

“Password-locking” mechanism in order to

protect the users’ data (Keys and IMSI).

Problem 1: IMSI sent in a plain text

The GSM specifications have gone to great length to

avoid phone’s being addressed (i.e. paged) or

identifying themselves in plaintext by their IMSI.

This is supposed to prevent an eavesdropper

listening in, on the initial plaintext stage of the radio

communication, learning that a particular subscriber

is in the area (and what they are doing). Thus where

possible the network pages users by their TMSI and

maintains a database mapping TMSIs to IMSIs. If

the network somehow loses track of a particular

TMSI, and therefore cannot determine who the user

is, it must then ask the subscriber for his IMSI over

the radio link. Obviously, the connection cannot be

ciphered if the network does not know the identity of

the user, and thus the IMSI is sent in plaintext (J.

Quirke, May 2004).

Triggered Action 1

When this flaw is identified, SIM extracts the HLR

public key from its certificate. In SIM-VLR

communication, the public key of the VLR is

distributed in the initiation process. SIM then

encrypts the IMSI using the public-key and sends it

to the HLR/VLR. The VLR decrypts the ciphered

data using the correspondent private key. This

process is illustrated in figure 1.

Problem 2: Network does not authenticate

itself to a phone

This is the most serious fault with the GSM

authentication system. The network does not have to

prove its knowledge of the K

, or any other

authentication context to the phone. Thus it is

Figure 1: IMSI retreival mechanism.

possible for an attacker to setup a false Network

node. Since the authentication procedure initiation is

up to the network’s discretion, the false network

may choose not to authenticate at all, or simply send

the RAND and ignore the response. It does not have

to activate ciphering either (J. Quirke, May 2004).

Triggered Action 2

The SIM should have the option to initiate the

authentication process, for both Home Network and

a Visiting Network as follows:

1. Authenticating the Home Network: two

scenarios can be presented (illustrated in figure 2):

Scenario A: SIM generates a new RAND and

sends it to the Network. The Network encrypts it

using its Private Key and then sends the ciphered

data to the SIM. The SIM then decrypts the

ciphered data using the extracted Network Public

key and compares the two codes. If the two codes

do not match then the SIM sends a

REJECT_REGISTERATION message and the

connection fails.

Scenario B: authenticity can be proven also by

proving the knowledge of K

, in this case the

procedure is the following: SIM sends a RAND to

the Network and the network produces the

correspondent SRES and sends it back to the SIM.

But this procedure is not safe because an attacker

can obtain both SRES and RAND and perform a

“Known-plaintext attack” to retrieve the K

Therefore RAND should be sent encrypted by the

Network public key; in this case the attacker can

not obtain both RAND and SRES together.

2. Authenticating a foreign network: two scenarios

can be presented

Scenario A: As we mentioned before, authenticity

can be proven by proving the knowledge of the K

2. IDENTITY Response (E

Pub(VLR/HLR)

(IMSI))

Mobile

Station

Network

Node

IDENTITY RE

ert

))

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

178

But If the Mobile Station is authenticating a

foreign VLR, the Home Network will not send the

of the specified SIM in plain. A proposed

scenario is to do the following:

• SIM sends a new RAND along with the TMSI

encrypted using the VLR public key.

• VLR decrypts the message and extracts the

RAND then encrypts it using the home Network

public key and sends it to the HLR/AuC.

• The HLR checks the “Chain of trust” of the

VLR and checks its validity. If it is valid, the

HLR computes the SRES using RAND and K

The Kc is computed as well.

• The Kc and SRES are sent to the VLR

encrypted using the VLR public key.

• The VLR decrypts the message and obtains

SRES and Kc, encrypts SRES using Kc and

sends it to the phone.

• At this stage the SIM has calculated the Kc and

uses it to decrypt the message and compares the

two SRESs then sends either Accept or Reject

RESPONSE.

Since the SIM can not keep all the public keys of

the VLRs dealt with, SIM and the VLR should

exchange public Keys for future use in the

initiation phase.

Scenario B: another scenario to reduce the

computation overhead in the SIM is to change the

first step in scenario A to the following:

• SIM sends the RAND in plain form to the VLR.

The rest of the steps are repeated.

These processes are illustrated in figures 3, 4 and 5.

Advantages of these two approaches are:

• The VLR authentication relies on the HLR

validation procedure now. Note that there is a

list of Forbidden Network operators in the HLR.

Also the HLR checks the validity of the VLR by

sending its information to the CA.

• K

will never be sent in plain or even encrypted

form.

• RAND and SRES are not sent in plain form. So

attacks of getting both SRES and RAND to

calculate the K

is not possible now.

Problem 3: Kc is sent in plain form in

Roaming

Roaming is defined as the ability for a cellular

customer to automatically send & receive data when

traveling outside the geographical coverage area of

the home network, by means of using a visited

network. When a VLR connects to a user, it requests

the Kc from the HLR. HLR sends the Kc of a user in

plain form to the VLR.

Triggered Action 3

HLR identifies the last Kc being used by the user

and encrypts it using VLR public key and sends it to

the VLR. The VLR then decrypts it using the

correspondent private key. This procedure can be

Figure 2: Mobile Station – Home Network Authentication

Procedure.

Figure 3 VLR/ HLR connection to get SRES and Kc.

applied also if Kc is lost from the VLR. If the last

Kc used is not updated in the HLR, then a new

RAND should be sent to the SIM to calculate a new

Kc taking into consideration that RAND in this case

should not be transmitted in plain form. The HLR,

however, sends the Kc to the VLR encrypted using

VLR public key.

Problem 4: End-to-End security is not

available

Although GSM focuses on some of the security

aspects addressed by the 3GPP standards but still

there is no defined procedure to initiate end-to-end

secure communication between two users. This is

acceptable for average users where speed is the most

important factor, but some subscribers will sacrifice

this in favor of getting higher security level.

SPC and Phone-Dependent Key

• “SPC: Special Private Calls” where a certain

subscriber has the ability to transfer data or make

calls in a private mode. The data is transferred in

an encrypted form between the two users. This

option will delay the transfer of data but still will

give subscribers, who prefer security over speed,

the ability to increase the security level. It should

VLR

1. E

pubHLR

(RAND)

Verification

process…..

Home

Network

2. Response (E

pub(VLR)

(SRES,Kc))

Mobile

Station

3. Reject/ Accept registration

2. Auth_ Response (E

Priv(VLR)

(RAND))

1. Auth_ REQUEST (RAND)

Home

Network

ACTION-TRIGGERED PUBLIC-KEY SYSTEM FOR GSM USING RSA WITH PHONE-DEPENDENT ENCRYPTION

179

be optional to the customer to subscribe in this

option.

• Use a built-in key in the phone:

If MS-A would like to communicate with MS-B in

a secure manner then the procedure will be

partitioned into 2 phases:

Figure 4: Mobile Station –Visiting Network authentication

procedure (Scenario A).

Phase 1 Key Management phase

• MS-A asks the network to send a “secret session

key” in order to start a secure session between

A and B

• The network generates a secret key, encrypts it

using the A-Kc then sends it to A. Also it

encrypts the secret key using B-Kc and sends it

to B.

• At this point A and B can communicate securely

using the secret key sent by the network

• Key- deletion procedure should be triggered

immediately in the AuC, where Secret Session

Key is deleted.

Phase 2 Exchanging of Phone-dependent sub-

key

For further security (considering the case that

there is an attacker exists inside the Service provider

Network or attack the service provider Data base),

MS-A sends MS-B a phone-dependent Key that is

encrypted using the secret session key obtained from

the network. Some will argue that an attacker can

clone a user and initiate a session with MS-A in

order to have the Key P to intercept any future

communication for MS-A. This can be solved by

changing the key P for each session. A sub-key P

created each time the session is initiated – creating

sub-keys from the original P-key:

= SUB(P)

, where SUB is the function performed over the root

P-Key to get a new P

each time. Now, A and B can

encrypt their data using both the Session Key S and

the P

key or by using P

key only. It is up to the

network operator to use either A5 or another

symmetric key algorithm as the encryption

algorithm.

Figure 5: Mobile Station –Visiting Network authentication

procedure (Scenario B).

5 PROPOSED SYSTEM

ADVANTAGES

Our Proposed system has the following advantages:

• Our main advantage that our system is action

triggered due to flaws occurrences.

• A new key parameter is presented that is

independent of the SIM and the Network

operator; Built-in Key. The Built-in key is the

root of other sub-keys.

• IMSI and Kc are not sent in plain form

anymore.

• Secure communication between HLR and VLR

can be implemented.

• End-to-End secure communication, for non-

average users, can be implemented.

• Mutual Authentication is possible.

• Known Security algorithms can be used such as

RSA or Elliptic Curves.

In order to apply our system, the SIM components

must change to include user certificate, home

network public key and a public key algorithm. New

SIMs can be provided for the new users of any

network or this system can be applied in future

Mobile Communication systems.

6 IMPLEMENTATION RESULTS

The simulation is implemented in JAVA. Server side

and Client side modules are implemented by J2SE

5. Accept/ Reject registration

Mobile

Station

1. CERT

REQUEST

2. CERT_ RESPONSE(CERTIFICATE)

3. E

pubVLR

( RAND)

4. E

(SRES)

Visiting

Network

.. Contact HLR

.. Validation process

.. Get SRES and Kc

2. E

(SRES)

1. RAND

3. Accept/ Reject registration

Mobile

Station

Visiting

Network

.. Contact HLR

.. Validation process

.. Get SRES and Kc

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

180

v1.5. The codes run on Intel Centrino 1.7 Ghz

machine with 512MB RAM. We have implemented

the RSA as our public key system for its popularity.

Time taken for Encrypting/Decrypting: IMSI,

RAND, Kc and a 64bit session key is measured to

evaluate the delay that will be caused by applying

the RSA algorithm.

System parameters like RANDs and K

s are real

test data taken from 3GPP technical specification

(3GPP TS 55.205 V6.1.0) to test our system. We run

the simulation for 100 times and computation times

are recorded for 512, 1024 and 2048 bit RSA keys.

We recorded the standard Authentication time

(Creating both SRES and Kc). We also recorded the

time taken to Encrypt/Decrypt data (84 and 160

bytes) using A5. Algorithms are seeded using 20

different RANDs and 20 different K

For an efficient security system to work in a

mobile environment, the time taken to generate a

new public key pair, key generation process, should

be minimized as much as possible. The process of

selecting the primes and generating the

corresponding encryption and decryption keys is

large, but it is worth mentioning that Key Generation

in our system is done for each run. This is conducted

for the sake of testing our system versus several

public key values. Table 1 illustrates the average

time in milliseconds taken to select p, q, e, d and n.

Table 1.

Key size 512 bit 1024 bit 2048

Time 164.4334 1120.894 11333.304

As JAVA calls the garbage collector in

undefined periods, which will affect the time

records, we eliminated the best and the worst results.

In the following, the results are summarized.

Table 2: describes the time taken in m-seconds to

encrypt/ decrypt an IMSI (10 and 15 digits) using

RSA algorithm.

Table 2.

RSA (average processing time in msec)

512 bit key 1024 bit key 2048 bit key

Enc Dec Enc Dec Enc Dec

10 3.19 6.65 28.7 46.48 264.2 383.12

15 4.46 6.7 29.9 46.92 266.12 383.24

Table 3 describes the time taken in m-seconds to

encrypt/decrypt a 64 bit Kc using RSA algorithm.

Table 3.

RSA (average processing time in msec)

512 bit key

1024 bit

key

2048 bit key

Enc Dec Enc Dec Enc Dec

4.55 6.69 28.7 46.5 265.31 367.643

Table 4 describes the time taken in m-seconds to

encrypt/ decrypt a 64 bit Session Key using RSA

algorithm.

Table 4.

RSA (average processing time in msec)

512 bit key 1024 bit key 2048 bit key

Enc Dec Enc Dec Enc Dec

2.93 6.56 21.2 46.59

306.77 352.623

Table 5 describes the time taken in m-seconds to

encrypt/ decrypt a 64 bit Session Key using A5.

Table 5.

A5 (average processing time in msec)

SESSION

KEY

Encryption Decryption

64 bit

0.298 0.224

Table 6: describes the time taken in m-seconds for

authentication by signing a generated RAND, where

Network encrypts the RAND using its Private Key/

SIM decrypts RAND using Network Public Key.

Table 6.

RSA (average processing time in msec)

512 1024 2048 bit key

Enc Dec Enc Dec Enc Dec

6.67 4.46 47.15 28.7

387.91 294.54

Table 7: describes Authentication Scenario A with

additional step; where row 1 denotes that SIM

encrypts a 128 bit RAND using network Public key/

Network decrypts RAND using network Private

Key. Row 2 denotes that Network encrypts RAND

using network private key /SIM decrypts RAND

using network public key.

Table 7.

RSA (average processing time in msec)

512 bit key 1024 bit key 2048 bit key

Enc Dec Enc Dec Enc Dec

4.48 6.66 28.6 46.62

264.88 363.23

6.71 4.46 46.7 28.87 350.761 297.24

Table 8.1: describes the time taken in m-seconds for

Authentication by proving knowledge of Ki; where

SIM encrypts RAND using Network Public Key/

Network decrypts RAND using Network Private

Key. Table 8.2 Row 1 denotes the time taken to

ACTION-TRIGGERED PUBLIC-KEY SYSTEM FOR GSM USING RSA WITH PHONE-DEPENDENT ENCRYPTION

181

encrypt/decrypt SRES using A5. Row 2 denotes the

time taken to create SRES using RAND and Ki.

Table 8.1.

RSA (average processing time in msec)

512 bit key 1024 bit key 2048 bit key

Enc Dec Enc Dec Enc Dec

4.52 6.75 28.56 46.6 265.50 360.392

Table 8.2.

Average Time in Milliseconds

Encryption Decryption

0.2888 0.2537

SRES

0.20229381

8 CONCLUSION AND FUTURE

WORK

In this paper we discussed some of the flaws occur

in the existing GSM security system. We also

presented an application for Public Key techniques.

Action-Triggered Public Key Security System

(ATPKSS). It is a way to solve some of the flaws

occur in GSM security system without overloading

the system with a whole public key technique. Our

approach presents a hybrid system; where the

original system works in normal conditions and only

when a flaw occurs, the ATPKSS is triggered. RSA

is implemented as our public key technique. Time

(in milliseconds) is recorded for using RSA with

three key lengths; 512 bit, 1024 bit and 2048 bit. By

analyzing our results for 512 bit key; the highest

delay that will be caused by using ATPKSS is 6.75

milliseconds in average which is a very few price to

pay in terms of ensuring security. For 1024 bit key

the highest delay will be 47.15 milliseconds and for

2048 the delay is .

Also we presented a new end-to-end approach

where a key agreement phase takes place between

the network and the two users first, then in the

second phase, the initiating user sends a built-in

phone sub-key. The original built in phone key is the

root of the sessions’ sub-keys. Each time a new

session is opened, a function is applied to the root

key to obtain a sub-key. The data is transferred

between the two users afterwards encrypted by this

key only or a combination key between the phone

key and the network session key. This will address

the problem of attacking the Service provider itself.

Since in reference (Julio Lo`pez and Ricardo

Dahab) the authors states that ECC is preferable in

mobile systems due to the use of smaller key, we

suggest as a further research that an ECC

implementation is tested instead of RSA and see

whether the time measured is decreased or not.

REFERENCES

J. Quirke, May 2004. Security in the GSM system,

http://www.ausmobile.com

GSM 02.09 - Digital cellular telecommunications system

(Phase 2+); Security aspects (GSM 02.09 version 8.0.1

Release 1999).

R. Campbell and D. Mckunas, 2003. Analysis of Third

Generation Mobile Security, Annual Motorola Project

Review, Computer Science Dept., University of

Illinois.

Chengyuan Peng, 2003. GSM and GPRS Security,

Telecommunications Software and Multimedia

Laboratory, Helsinki University.

ETSI TS 100 929.Digital Cellular Telecommunication

System (Phase 2); Security related network functions.

European Telecommunications Standards Institute.,

November 1999.

O. Benoit1, N. Dabbous, 2004. Mobile Terminal Security,

Report in the International Association for Cryptologic

Research (IACR) Vol. 21, No. 3.

Bruce Potter, May 2004. GSM Security, Network

Security, vol. 2004, no.5, pp.4-5.

Yong LI, Yin CHEN, Tie-Jun MA, Feb 2002.

Security in

GSM,www.gsm-

security.net/papers/securityingsm.pdf.

L. Ertaul and B. Kasim, June 2005. GSM Security,

Proceedings of the 2005 International Conference on

Wireless Networks, ICWN’05.

A. Biryukov and A. Shamir, , April 2000. Real Time

Cryptanalysis of A5/1 on a PC, Fast Software

Encryption Workshop 2000, NY.

J. Rao, P. Rohatgi, H. Scherzer and S. Tinguely, May

2002. Partitioning Attacks: Or how to rapidly clone

some GSM cards, IEEE Symposium on Security and

privacy, Okaland, p. 31.

RSA Labs. RSA PKCS documents,

http://www.rsasecurity.com/rsalabs/node.asp?id=2124

William Stallings, Cryptography and Network Security:

Principles and Practice, Prentice Hall, ISBN:

0130914290.

Limor Elbaz, October 2002. Using Public Key

Cryptography in Mobile Phones, Discretix

Technologies Ltd,VP. Research.

3GPP TS 55.205 V6.1.0 (2003-12): Specification of the

GSM-MILENAGE algorithms: An example algorithm

set for the GSM Authentication and Key Generation

Functions A3 and A8.

Julio Lo`pez and Ricardo Dahab. An overview of Elliptic

Curve Cryptography, Institute of Computing, State

University of Campians, Brazil.

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

182
