KNOWLEDGE ENGINEERING USING THE UML PROFILE

Adopting the Model-Driven Architecture for Knowledge-Based

System Development

Mohd Syazwan Abdullah

1,2

, Richard Paige

, Ian Benest

and Chris Kimble

Faculty of Information Technology, Universiti Utara Malaysia, 06010 Sintok, Kedah, Malaysia

Department of Computer Science, University of York, Heslington, York, United Kingdom

Keywords: Knowledge engineering, knowledge modelling, knowledge-based system, UML profile.

Abstract: Knowledge engineering (KE) activities are essential to the process of building intelligent systems; it

conceptual modelling is exploited so that the problem-solving techniques used may be understood. This

paper discusses platform independent conceptual modelling of a knowledge intensive application, focusing

on knowledge-based systems (actually, a rule-based KBS) in the context of a model-driven architecture

(MDA). It emphasises the use of problem-solving methods for developing the knowledge-level models. An

extension to the Unified Modeling Language (UML), using its profile extension mechanism, is presented.

The profile discussed in this paper has been successfully implemented in the eXecutable Modelling

Framework (XMF) – a Meta-Object-Facility (MOF) based UML tool. A case study demonstrates the use of

this profile; the prototype is implemented in the Java Expert System Shell (Jess).

1 INTRODUCTION

Knowledge-based systems (KBS) were developed

for managing codified knowledge (explicit

knowledge) in Artificial Intelligence (AI) systems

(Giarratano and Riley, 2004). These were known as

expert systems and were originally created to

emulate human expert reasoning (Studer et al.,

1998). They have been one of the most successful

outcomes from AI research (Metaxiotis and Psarras,

2003) and have been adopted in the medical,

business, manufacturing, and other domains.

KBS are developed using knowledge engineering

(KE) techniques (Studer et al., 1998), that are

similar to those used in software engineering (SE),

but they emphasize knowledge rather than data or

information processing. Central to this is the

conceptual modelling of the system during the

analysis and design stages of the development

(known as knowledge modelling). A number of KE

methodologies have emphasized the use of models,

for example: CommonKADS, MIKE, KARL and

others (Gomez-Perez and Benjamins, 1999). KBS

continue to evolve as the need to have a stable

technology for managing knowledge grows; its

current role as an enabler in knowledge management

initiatives has led to its wider acceptance (Ergazakis

et al., 2005). It has matured from a non-scalable

technology (Giarratano and Riley, 2004).Once

restricted to the research laboratory, it is now used

for demanding commercial applications and is a tool

widely accepted by industry (Liebowtiz, 2001). As a

result, the Object Management Group (OMG),

which governs object-oriented software modelling

standards, has started the standardisation process for

production rule representation (PRR) (OMG, 2003)

and knowledge-based engineering (KBE) services

(OMG, 2004). Standardising PRR is vital as it will

allow interoperability of rules between different

inference engines – much needed by industry

(McClintock, 2005, Krovvidy et al., 2005).

This paper is organised thus. Section 2 discusses

knowledge modelling. Section 3 explains the

rationale for having an extension in UML. Section 4

overviews the UML extension mechanism, and

section 5 describes the knowledge modelling profile.

With the aid of a case study, section 6 illustrates

how the profile can be used to develop a KBS.

Section 7 concludes with directions for future work.

Syazwan Abdullah M., Paige R., Benest I. and Kimble C. (2006).

KNOWLEDGE ENGINEERING USING THE UML PROFILE - Adopting the Model-Driven Architecture for Knowledge-Based System Development.

In Proceedings of the Eighth International Conference on Enterprise Information Systems - AIDSS, pages 74-81

DOI: 10.5220/0002447100740081

 SciTePress

2 KNOWLEDGE MODELLING

Newell (Newell, 1982) emphasises the importance

of developing problem-solving models of the

domain rather than focusing on knowledge

representation. This is usually referred to as the

knowledge-level principle and differs from the

previous mining view (Motta, 2002). Two strands of

research have been established based on this

knowledge-level modelling principle (Chan, 2004).

One emphasises the refinement of existing

knowledge-level principle formalisation languages

such as KARL (Angele et al., 1996) and KADS’s

ML2 language (Flores-Mendez et al., 1998). The

other area deals with developing knowledge-level

models for a variety of tasks and domains in order to

understand the problem-solving techniques used.

There are two distinct Knowledge Modelling (KM)

approaches: the problem-solving method (PSM), and

the domain ontology (Chan, 2004, Schreiber et al.,

1999, Angele et al., 1996, Dieste et al., 2002). The

PSM exploits domain independent abstract models

that describe the generic inference patterns for

different tasks (Angele et al., 1996); while an

ontology defines the commonly agreed vocabularies

for representing the domain knowledge (Gruber,

1993). The focus of this paper is on using PSM

techniques for developing knowledge-level models.

While it is commonly agreed that conceptual

modelling is an important stage in any software

system construction (Naumenko and Wegmann,

2002), both SE and KE communities have developed

different modelling techniques that are almost

unrelated (Dieste et al., 2002) resulting in

fundamental computational differences in the way

they solve the same problem (Juristo, 1998). This

makes it difficult to interchange their models

(Juristo, 1998). Nevertheless, most KE modelling

notations have adopted those from the more

established SE domain (though KE contributed

object-oriented development through frames).

Among the approaches to KE, CommonKADS is the

most comprehensive and well structured

methodology (Motta, 2002) and is widely used. Its

graphical notation has a strong resemblance to those

used in object languages such as the Unified

Modeling Language (UML) (Dieste et al., 2002).

3 RATIONALE FOR EXTENSION

Research has shown that neither technical nor

economic factors determine whether KBS

technology will be successfully adopted, but rather it

is the organisational and managerial environment

that is the main determinant (Gill, 1995, Tsui, 2005).

Gill (1995) highlights one of the problems: the

management of the development team. KBS projects

are specialised in nature requiring team members to

have knowledge of both the problem domain and the

development tools. As a result, the team members

are skilful individuals and the success of the project

is threatened if one or more leave the team mid-way

through the development or during the maintenance

period. But a KBS that is designed using an

appropriate, well-understood, standard language for

conceptual modelling along with a methodologically

sound representation technique, should be readily

understood by new team members.

The major problem with KM is that there is no

standard language available to model the knowledge

for developing a KBS (Chan, 2004, McClintock,

2005, Krovvidy et al., 2005). Most of the languages

used are adapted from SE. The languages used in

KM are project based using a mix of notations such

as UML, IDEF, SADT etc. The SE community has

adopted UML as the de facto standard for modelling

object-oriented systems and the KE community

should do the same. This would be beneficial in the

long-term as KBS can be easily integrated into other

enterprise systems (Krovvidy et al., 2005,

Giarratano & Riley, 2004) particularly if their

designs were based on a standard language; it would

help facilitate communication and sharing of

blueprints among developers (Abdullah et al, 2002).

OMG’s PRR (OMG, 2003) should go some way to

satisfy this standardisation requirement.

The motivation for the extension was to

accommodate UML for KM in designing KBS.

There was a need for a standardised approach in

designing KBS, and reaping the benefits of using

UML (better tool support, large user base familiar

with the language, and an evolving standard).

4 THE UML EXTENSIONS

The OMG’s Model Driven Architecture (MDA) – a

model-driven engineering framework – provides

integration with, and interoperability between,

different models developed using its standards

(Muller et al., 2003) (such as UML, Meta-Object

Facility (MOF), and others). The growth of MDA

will fuel the demand for more meta-models to cater

for domain specific modelling requirements.

KNOWLEDGE ENGINEERING USING THE UML PROFILE - Adopting the Model-Driven Architecture for

Knowledge-Based System Development

Profiles have ‘precisely’ defined semantics and

syntax, which enables them to be formally integrated

into UML, though of course they must adhere to the

profile requirements proposed by OMG. Previous

profile development for modelling knowledge has

concentrated only on certain task types such as

product design and product configuration. In

contrast, the work described here emphasises the

development of a generic profile.

Developing a meta-model for KM will enable it

to be integrated into the MDA space allowing the

relation between the knowledge models and other

language models to be understood. It provides for

seamless integration of different models in different

applications within an enterprise.

UML is a general-purpose modelling language

(Muller et al., 2003) that may be used in a wide

range of application domains. It can be extended to

model domains that it does not currently support, by

extending the modelling features of the language in

a controlled and systematic fashion. The OMG

(OMG, 2001) defines two mechanisms for extending

UML: profiles and meta-model extensions. Both

extensions have (unfortunately) been called profiles

(Muller et al., 2003).

The “lightweight” extension mechanism of UML

(OMG, 1999) is the profile. It contains a pre-defined

set of Stereotypes, TaggedValues, Constraints, and

notation icons that collectively specialize and tailor

the UML. The main construct in the profile is the

stereotype that is purely an extension mechanism. In

the model, it is marked as «stereotype» and has the

same structure (attributes, associations, operations)

as that defined by the meta-model. However, the

usage of stereotypes is restricted; changes in the

semantics, structure, and the introduction of new

concepts to the meta-model are not permitted (Perez-

Martinez, 2003).

The “heavyweight” extension mechanism for

UML (known as the meta-model extension) is

defined through the Meta-Object Facility (MOF)

specification (OMG, 2002) which involves the

process of defining a new meta-model (Perez-

Martinez, 2003). This approach should be favoured

if the semantic gap between the core modelling

elements of UML and the newly defined modelling

elements is significant (Muller et al., 2003).

It is preferable to create a profile using the

“lightweight” extension since it is easier to use,

easier to introduce new concepts through the

existing meta-model and has better tool support

compared with that of the meta-model extension.

The work presented in this paper exploits the

“lightweight” extension using the XMF approach.

5 THE KM PROFILE

The OMG UML specifications only specifies what

profiles should constitute and not how to design

them. By adopting the XMF (eXecutable Meta-

modelling Framework) approach (Clark et al.,

2005), the profile development is structured into

well-defined stages that are easy to follow and

methodologically sound. The XMF is a newly

developed object-oriented meta-modelling language,

and is an extension to existing standards for meta-

models such as MOF and UML. XMF offers an

alternative approach in profile design, which allows

modification, or addition, of new modelling

constructs; and these are easily integrated into the

core meta-model of UML. The creation of a profile

can be divided into three steps: the derivation of an

abstract syntax model of the profile concepts, a

description of the profile’s semantics, and the

presentation of the profile’s concrete syntax (not

discussed here) if this is different from UML

diagrams.

5.1 Abstract Syntax

The abstract syntax describes the vocabulary of

concepts in the profile and the associations between

those concepts. It also defines the well-formed-ness

rules that determine the models validity. The

processes involved in creating the abstract syntax

are: identifying the domain specific concepts to be

modelled including the related well-formed-ness rules

for constraining the manner in which the concepts may

be used; modelling the concepts by creating an abstract

syntax meta-model of the profile; defining the well-

formed-ness rules of the profile; defining operations and

queries related to the profile where applicable and

validating and testing the profile to ensure the

correctness of the abstract syntax model.

Profile Concept

The concepts for the profile are re-used from the

existing BNF definition of the CommonKADS

Conceptual Modelling Language (CML) (Schreiber et

al., 1999); this provides a well-defined and well-

established main set of concepts for the domain. Most of

these elements are generally adopted in the KBS

literature and are widely used for representing

concepts in KBS in the KE domain. These concepts

ICEIS 2006 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

are itemised in Table 1 and the abstract syntax model of

the profile is shown in Figure 1.

Model Extension

The knowledge modelling profile concept extends

the existing meta-models of UML by defining the

profile’s abstract syntax. There are three places

where the profile can be viewed as an extension to

UML and these are: Class, Named Element and

Constraints, all of which are central to the core UML

meta-model and are also found in UML. The KM

concept class enables the concept to inherit all the

features of a class and allows it to specify attributes

and constraints on the attribute values. Other

concepts such as inference, task, task method,

dynamic role, static role, and the transfer function

are also viewed as a subclass of an UML Class and

inherit the class features. This allows operations

related to objects to be expressed, such as an execute

inference call from the task method, the execution of

the inference process and the access to knowledge in

the knowledge base through the static role. At the

same time, it allows these elements to specify

attributes.

Table 1: Main Knowledge Modelling Concepts.

Modelling Concept Description

Concept (class) Class that represents the category of

things

FactBase/Working

Memory

Collection of information/facts that

will be matched against the rule

Inference The lowest level of functional

decomposition into primitive

reasoning steps

Transfer Function Transfers information between the

reasoning agent and external entities

(system, user)

Task Defines the reasoning function

Task Method Describes the realization of the task

through sub-function decomposition

Static Knowledge Role Specifies the collection of domain

knowledge that is used to make the

inference

Dynamic Knowledge

Role

Run-time inputs and outputs of

inferences

Rule Type Categorization and specification of

knowledge

Rule Expressions that involve an attribute

value of a concept

Knowledge Base Collection of data stores that contain

instances of domain knowledge types

Knowledge base is a subclass of the UML class. It

has a ‘content’ slot for specifying tables. This is a

natural choice for a subclass as the knowledge base

is actually a collection of tables grouped together in

order to store rule type instances. The profile’s tuple

concept is also extended from Class. Constraint class

is a subclass of the UML meta-model, incorporating

profile concepts such as axioms and rule type

expressions. All these concepts need the ability to

express constraints; this class allows for this. Rule

Type is a subclass of the UML Named Element,

allowing rules to be identified using a name. All the

associations described in the profile are extensions

of the UML association class. However, they are not

shown in the profile, as it would clutter the diagram.

Figure 1: Knowledge Modelling Profile.

Well-formed-ness Rules

Defining the well-formed-ness rules of the profile

modelling elements in OCL helps to make

impossible illegal models that might otherwise be

created using the profile concepts. The following

well-formed-ness rules are defined for the concepts

in the profile and listed in Table 2. An example of

one of the rules written in XMF OCL syntax) is as

follows (each inference must have a unique name):

context Inference

@Constraints InferencesHaveUniqueNames

inference->forAll (s1 | states->forAll

(s2 | s1.name = s2.name implies s1 =

s2))end

<<Concept>>

input: String

output: String

<<Task>>

Class

(From XMF)

decomposition: String

intermediate role: string

<<Task Method>>

dynamic input: String

dynamic output: String

static role: String

inferencetype : {foward,backward}

<<Inference>>

communicationtype:

{provide, receive,

obtain, present}

Transfer Function

input: String

<<Static Role>>

input: String

output: String

<<Dynamic Role>>

<<Knowledge

Base>>

Class

(From XMF)

method

1..*

0..1

roles

<<ordered>>

0..1

knowledge

elements

input

output

1..*

Rule Type Expression

<<Tuple>>

1..*

tuples

expressions

Constraint

(From XMF)

roles

<<Axiom>>

axioms

Constraint

(From XMF)

rules

<<Rule>>

<<Decision Table>>

Class

(From XMF)

antecedent: String

consequent: String

connection: String

<<Implication Rule>>

rules

NamedElement

(From XMF)

rules

Knowledge Modelling Profile

<FactBase/

WorkingMemory>>

instances

decomposition

Note:

All association in the profile are extended

from UML association class

KNOWLEDGE ENGINEERING USING THE UML PROFILE - Adopting the Model-Driven Architecture for

Knowledge-Based System Development

Table 2: Profile Well-formed-ness rule.

Class Well-formed-ness rule description

Concept • Concept cannot own operations.

Inference • Inference must have a unique

name.

• Inference can only be associated

with task method, dynamic and

static role.

Transfer

Function

• Transfer function can only be

associated with task method and

dynamic role.

Task • Task must have a unique name.

• Task can only be associated with

task method.

Task Method • Task method must have a unique

name.

• A task method can only be

associated with transfer function

and inference.

• Task method can only be

decomposed to task, inference and

transfer function.

Factbase • Factbase can only be associated

with concept and dynamic role.

Static

Knowledge

Role

• Static role can only be associated

with inference and knowledge-

base.

Dynamic

Knowledge

Role

• Dynamic role can only be

associated with factbase, transfer

function and inference

Rule Type • Any one of the rule types must

exist: constraint, implication and

decision table.

Implication

Rule

• Rule can only be associated with

concept and knowledge-base.

Knowledge

Base

• Knowledge base can only be

associated with tuple, rule and

static role.

All

associations

• Can only be used to join those

concepts that it is linked with in

the profile

5.2 Semantics

The semantics describe the meanings of the concepts

within the profile in terms of behaviour, static

properties or the means by which it may be

translated into another language. Semantics are

important to the profile as they are used to

communicate the meaning of the models amongst its

users and avoid misinterpretation; they are a core

part of the profile’s meta-model and are there

instead of formal (mathematical) methods that are

often difficult to comprehend.

The Dynamic Role class specifies the

‘information’ flow of attribute instances from the

concepts. It also specifies the outputs that arise from

executing the inference sets. The output of this

inference process is the ‘result’ of matching the

antecedent of the rule with the consequent part.

Depending on what the knowledge-based system is

reasoning about, if it is not the final output of the

system, then the output can be used in another

inference.

The Static Role class is the function responsible

for fetching the collection of domain knowledge

(rules) from the knowledge base prior to an active

inference. Inferences do not access the knowledge

base directly, but request the necessary rules related

to the particular inference from the static roles. In

some knowledge-based system shells this is similar

to posting the rules to the inference process or

similar to setting which rule should be fired. This

allows the inference process to handle a specific

reasoning task and invoke those rules that are

appropriate.

An Inference process class executes a set of

algorithms for determining the order in which a

series of non-procedural, declarative statements are

to be executed. The inference process infers new

knowledge from information/facts that are already

known. The Task Method invokes this. The input

(information/fact) used by this process is provided

by the dynamic role. The result of the inference

process is then passed to the dynamic role. The

knowledge element used in the inference is accessed

through the Static Role, which fetches the group of

rules from the knowledge base. There are several

different inference processes for a given task, most

of which are run in the background by the inference

engine.

The Rule class of the profile describes the

modelling of rules within the domain concept. Rule

class is used to represent knowledge elements in

KBS and is viewed as ‘information about

information’. Rule class allows for rules to be in

different formats. There are three types of rule:

implication rule, decision table and constraint rule.

An implication rule is of the form: ‘if-then’ premise

followed by an action. This type of representation is

widely used in KBS; they are known as production

rules. A decision table is an addition to the rule

class. It is introduced here because certain rules are

best expressed in the form of a decision table, even

though they are usually converted to flattened

production rules. This paper only concentrates on

ICEIS 2006 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

rule-based KBS as it is the one widely adopted by

industry.

The knowledge base class contains domain

knowledge, represented as rules, which are used by

the inference process. The contents of the

knowledge base are organized in tuples (records). A

tuple is used to group rules according to their

features. This allows the partitioning of the

knowledge base into modules that enables the

inference process to access the rules faster. The

maintainability of the rules is enhanced when it is

organised in this manner.

6 CASE STUDY – CLINICAL

PRACTICE GUIDELINE

RECOMMENDATIONS

The Clinical Practice Guideline (CPG)

Recommendations contains statements that are

graded according to the following three strengths of

evidence: (a) generally consistent findings in a

majority of multiply acceptable studies; (b) either

based on a single acceptable study, or weak or

inconsistent findings in multiply acceptable studies;

the criteria of acceptable studies of good quality.

The recommendations cover assessment of leg

ulcers, management of venous leg ulcers, cleansing,

removal of medical debris, dressing and contact

sensitivity, education and training, and quality

assurance categories. A KBS for educational

purposes was designed to list the recommendations

based on (a) evidence strength; (b) evidence strength

and category; (c) category only. Figure 2 shows how

the profile has been used to represent part of the

CPG case study.

The profile here only concentrates on showing

the task of making recommendations (considered as

classification task-type), based on the user-selected

criteria. The task is invoked by the task method

“prune set” which is executed by several inferences

and intermediate roles. For the matching process to

provide recommendations, different sets of rules are

used depending on the criteria selected by the user.

To arrive at a recommendation, the inference would

need the pertinent knowledge or rules from the

knowledge base. This is provided by the static role,

and the facts (CPG recommendations in the

factbase) to match them are gathered by the dynamic

role.

Figure 2: CPG Recommendations Case Study Model.

The case study was implemented as a prototype

system in the Java Expert System Shell (Jess), that is

based on the popular CLIPS program (Friedman-

Hill, 2003). Because of the declarative nature of

expert system shell programming, the concepts of

the profile cannot be entirely matched to a Jess

meta-model. However, the KM profile was very

useful in understanding the KBS requirements for

the CPG recommendations. Some sample rules for

listing recommendations based on evidence strength

(in the actual recommendation each recommendation

has a brief explanation rather than ID shown below

as I1, II2, III4, etc.) are:

If evidence.strength = I Then Recommendation = {I1,

I2, I3, I4}

If evidence.strength = II Then Recommendation =

{II1, II2, II3, II4, II5, II6}

If evidence.strength = III Then Recommendation =

{III1, III2, III3, III4, III5,…. to III19}

This rule set is mapped into Jess code as follows:

( defrule strength-I

( user (strength ?i&:(= ?i 1)))

=> assert (recommendation I1 , I2 ,

I3 , I4)

explanation "Strength equals 1"))))

( defrule f strength-II

( user (strength ?i&:(= ?i 2)))

=> (assert (recommendation II1 , II2

, II3 , II4 ,II5 ,II6)

explanation "Strength equals 2"))))

( defrule strength-III

( user (strength ?i&:(= ?i 3)))

dynamic-input: CPG Classification

dynamic-output:CPG Classification + Attribute

<<Dynamic Role>>

dynamic-input: CPG Classification + Attribute

dynamic-input: Attribute_Value

dynamic-output: Recommendation

<<Dynamic Role>>

dynamic-input: CPG Classification

dynamic-output: CPG Classification + attribute

static-input: Attribute Selection

inference-type: {forward}

<<Inference>>

dynamic-input: CPG Classification + attribute

dynamic-input: Attribute_Value

dynamic-output: Recommendation

static-input: Recommendation-Knowledge

inference-type: {foward}

<<Inference>>

input: Attribute Selection

<<Static Role>>

input: Recommendation-

Knowledge

<<Static Role>>

communication_type: {obtain}

input: Recommendation category & Attribute

output:Attribute_Value

<<Transfer Function>>

value: {I1-I3, II1-II6, III1-III17}

<<Dynamic Role>>

decomposition : Generate Inference

decomposition : Specify Inference

decomposition : Match Inference

decomposition : Transfer Function 1

decomposition : Transfer Function 2

intermediate role: CPG classification

intermediate role: attribute

<<Task Method>>

Recommendation

dynamic-input: CPG

dynamic-output: Recommendation

<<Task>>

method

knowledge

decomposition

kn. elements

input

output

roles

recommdendations

knowledge

input

output

<<KnowledgeBase>>

antecedent: Matching Element

consequent: Recommendation

connection: has recommendation

<<Implication Rule>>

decomposition

rules

KNOWLEDGE ENGINEERING USING THE UML PROFILE - Adopting the Model-Driven Architecture for

Knowledge-Based System Development

=> (assert (recommendation III1 ,

III2 , III3 , III4 ,III5 ,III6 ,III7,

III8,III9,III10,III11,III12,III13,III14

,III15,III16,III17, III18, III19)

explanation "Strength equals 3 "))))

7 CONCLUSION AND FUTURE

WORK

KBS development is similar to that experience in

software engineering; both rely on conceptual

modelling of the problem domain to provide an

orientation as to how the system addresses the

problem. UML has been adopted by those working

in the SE domain as a standard for modelling, but

there is still no consensus in the KE domain. This

paper describes an extension to UML using the

(lightweight) profile mechanism for knowledge

modelling that allows KBS to be designed using an

object-oriented approach. The profile has been

successfully tested on several case studies. This

includes designs from scratch and re-engineering

existing KBS. Currently work has concentrated on

building an Eclipse plug-in to support the profile.

The plug-in will allow profile-compliant diagrams to

be drawn and validated, and XML or XMI

representations produced. The infrastructure in the

Eclipse plug-in will make this mapping

straightforward to implement.

The future work in this area involves studying

how to map the profile to a specific inference engine

meta-model and work in this area is in progress

(Wu, 2004). Jess will be used initially as this has

been widely adopted and will help assess not only

the utility of the profile for building realistic KBS,

but also the utility of XMF for capturing the meta-

models and building the transformations.

REFERENCES

Abdullah, M.S., Benest, I., Evans, A., & Kimble, C.

(2002) Knowledge Modelling Techniques for

Developing Knowledge Management Systems. In

Proceedings of the 3

European Conference on

Knowledge Management, Dublin, Ireland.

Angele, J., Decker, S., Perkuhn, R. & Studer, R. (1996)

Modeling Problem-Solving Methods In New Karl. In

Proceedings Of Tenth Knowledge Acquisition For

Knowledge-Based Systems Workshop (Kaw'96).

Calgary, Canada.

Chan, C. W. (2004) Knowledge And Software Modeling

Using UML. Software And Systems Modelling, 3, 294-

302.

Clark, T., Evans, A., Sammut, P. & Willians, J. (2005)

Metamodelling For Model-Driven Development: To

Appear.

Dieste, O., Juristo, N., Moreno, A. M., Pazos, J. & Sierra,

A. (2002) Conceptual Modelling In Software

Engineering And Knowledge Engineering: Concepts,

Techniques And Trends. In Chang, S. K. (Ed.)

Handbook Of Software Engineering & Knowledge

Engineering. World Scientific Publishing Company.

Ergazakis, K., Karnezis, K., Metaxiotis, K. & Psarras, I.

(2005) Knowledge Management In Enterprises: A

Research Agenda. Intelligent Systems In Accounting,

Finance And Management, 13, 17-26.

Flores-Mendez, R. A., Van Leeuwen, P. & Lukose, D.

(1998) Modeling Expertise Using Kads And Model-

Ecs. In Eleventh Workshop On Knowledge

Acquisition, Modeling And Management. Banff,

Canada.

Friedman-Hill, E. (2003) Jess In Action: Rule-Based

System In Java, Greenwich, US, Manning Publication.

Giarratano, J. C. & Riley, G. D. (2004) Expert Systems:

Principles And Programming, Boston, Massachusetts,

Course Technology.

Gill, G. T. (1995) Early Expert Systems: Where Are They

Now? MIS Quarterly, 19, 51-81.

Gomez-Perez, A. & Benjamins, V. R. (1999) Overview Of

Knowledge Sharing And Reuse Components:

Ontologies And Problem-Solving Methods. In IJCAI-

99 Workshop On Ontologies And Problem-Solving

Methods (KRR5). Stockholm, Sweden.

Gruber, T. R. (1993) Toward Principles For The Design

Of Ontologies Used For Knowledge Sharing. Stanford

University. Report No. KSL-93-04.

Juristo, N. (1998) Guest Editor's View. Knowledge Based

System, 11, 77-85.

Krovvidy, S., Bhogaraju, P. & Mae, F. (2005)

Interoperability And Rule Languages. W3C Workshop

On Rule Languages For Interoperability. Washington,

D.C., USA.

Liebowtiz, J. (2001) If You Are A Dog Lover, Build

Expert System; If You Are A Cat Lover, Build Neural

Networks. Expert System With Applications, 21, 63.

McClintock, C. (2005) Ilog's Position On Rule Languages

For Interoperability. W3C Workshop On Rule

Languages For Interoperability. Washington, D.C.,

USA.

Metaxiotis, K. & Psarras, J. (2003) Expert Systems In

Business: Applications And Future Directions For The

Operations Researcher. Industrial Management And

Data System, 103,

361-368.

Motta, E. (2002) The Knowledge Modelling Paradigm In

Knowledge Engineering. In Chang, S. K. (Ed.)

Handbook Of Software Engineering & Knowledge

Engineering. World Scientific Publishing.

Muller, P.-A., Studer, P. & Bezivin, J. (2003) Platform

Independent Web Application Modeling. In Stevens,

P., Whittle, J. & Boochgrady. (Eds.) The Sixth

ICEIS 2006 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

International Conference On The Unified Modeling

Language (Uml 2003). Springer-Verlag.

Naumenko, A. & Wegmann, A. (2002) A Metamodel For

The Unified Modeling Language. In Jezequel, J. M.,

Hussmann, H. & Cook, S. (Eds.) UML 2002. Dresden,

Germany, Springer-Verlag Berlin.

Newell, A. (1982) The Knowledge Level. Artificial

Intelligence, 18, 87-127.

OMG (1999) Requirements For UML Profile.

Framingham, MA, U.S.A., Object Management

Group.

OMG (2001) Unified Modeling Language Specification

(Version 1.4).

OMG (2002) MOF Specification Version 1.4.

OMG (2003) Production Rule Representation - Request

For Proposal. Object Management Group.

OMG (2004) KBE Services For Engineering Design -

Request For Proposal. Object Management Group.

Perez-Martinez, J. E. (2003) Heavyweight Extensions To

The UML Metamodel To Describe The C3

Architectural Style. ACM Sigsoft Software

Engineering Notes, 28.

Schreiber, G., Akkermans, H., Anjewierden, A., De Hoog,

R., Shadbolt, N., De Velde, W. & Wielinga, B. (1999)

Knowledge Engineering And Management: The

Commonkads Methodology, Massachusetts, MIT

Press.

Studer, R., Benjamins, R. & Fensel, D. (1998) Knowledge

Engineering: Principles And Methods. Data &

Knowledge Engineering, 25, 161-197.

Tsui, E. (2005) The Role Of It In KM: Where Are We

Now And Where Are We Heading. Knowledge

Management, 9, 3-6.

Wu, C.G. (2004) Modelling Rule-Based Systems with

EMF. Accessed at http://www.eclipse.org/articles/

KNOWLEDGE ENGINEERING USING THE UML PROFILE - Adopting the Model-Driven Architecture for

Knowledge-Based System Development
