USING RELATIONAL DATABASES IN THE ENGINEERING

REPOSITORY SYSTEMS

Erki Eessaar

Department of Informatics, Tallinn University of Technology, Raja 15,12618 Tallinn, Estonia

Keywords: Relational data model, Object-relational data model, Repository, Metamodeling.

Abstract: Repository system can be built on top of the database management system (DBMS). DBMSs that use

relational data model are usually not considered powerful enough for this purpose. In this paper, we analyze

these claims and conclude that they are caused by the shortages of SQL standard and inadequate

implementations of the relational model in the current DBMSs. Problems that are presented in the paper

make usage of the DBMSs in the repository systems more difficult. This paper also explains that relational

system that follows the rules of the Third Manifesto is suitable for creating repository system and presents

possible design alternatives.

1 INTRODUCTION

"A repository is a shared database of information

about the engineered artifacts." (Bernstein, 1998)

These artifacts can be software engineering artifacts

like models and patterns. Repository system contains

a repository manager and a repository (database)

(Bernstein, 1998). Bernstein (1998) explains that

repository manager provides services for modeling,

retrieving, and managing objects in the repository

and therefore must offer functions of the Database

Management System (DBMS) and also additional

functions.

The repository manager uses custom-built data

manager or general-purpose DBMS in order to

manage artifacts. System Arcadia (Taylor et al.,

1988) is an example of the system that uses custom-

built object manager. Omega (Linton, 1984), The C

Information Abstraction System (Chen et al., 1990),

PARSE (Gray, 1997) and CommonKADS repository

(Allsop et al., 2002) are examples of the repository

systems that use a Relational DBMS (RDBMS).

RDBMS in this case is a system which uses a

database language that conforms to SQL:1992

standard or is even earlier relational database

language. Object-Oriented DBMSs have been often

seen as a suitable platform for building repository

systems (Bernstein, 1998) (Dittrich et al., 2000).

Object-Relational DBMS (ORDBMS) combine

features of the relational data model and object-

oriented programming languages. An example of an

early attempt to combine relational and object

technologies in one data model is ROSE (Hardwick

& Spooner, 1989) that is experimental data

management system for the interactive engineering

applications. Bernstein (2003) envisions that object-

relational systems are good platform for the model

management systems. ORIENT (Zhang et al., 2001)

and SFB-501 Reuse Repository (Mahnke & Ritter,

2002) are examples of the repository systems that

use a commercial ORDBMS. ORDBMS in this case

is a system which uses a database language that

conforms to SQL:1999 or later standard.

Relational data model was introduced by Codd

(1970) and has been extensively studied since then.

One notable revision is the Third Manifesto (Date &

Darwen, 2000), (Date, 2003). Relational model and

relational systems are often criticized because they

are arguably not powerful enough for the repository

system.

In this work we show that these problems are

caused by the shortages of SQL standard and

systems that implement that standard. There exists

analyzes of SQL and comparisons of it with the

proposals of the Third Manifesto (Date & Darwen,

2000), (Pascal, 2000), (Date, 2003) but they don't

discuss problems in the context of specific

application areas like engineering repositories.

In this paper we also explain how a relational

system that follows the rules of the Third Manifesto

can be used in order to create a repository database.

In this case we wouldn't have problems that are

present in current ORDBMSs.

Eessaar E. (2006).

USING RELATIONAL DATABASES IN THE ENGINEERING REPOSITORY SYSTEMS.

In Proceedings of the Eighth International Conference on Enterprise Information Systems - DISI, pages 30-37

DOI: 10.5220/0002455800300037

 SciTePress

We adopt definition (Date, 2003) according to

which the relational data model consists of an

extensible collection of scalar types, relation type

generators, facilities for defining relation variables

(relvars) of such types, assignment operations for

assigning relation values (relations) to relvars and an

extensible collection of generic relational operators

for deriving relation values from other relation

values.

The rest of the paper is organised as follows.

Section 2 contains results of the literature study

about the problems of the relational model and

RDBMSs that hamper their usage in the repository

systems. Section 3 explains how a RDBMS which

data model follows the rules of the Third Manifesto

can be used in a repository system. Nowadays much

attention is paid to the ORDBMSs. Section 4

describes problems of the current ORDBMSs that

make their usage in the repository systems more

difficult. Section 5 summarizes and points to the

future work with the current topic.

2 LITERATURE STUDY

Next we classify problems of the relational model

and RDBMSs based on the literature study and

analyze these problems in terms of the Third

Manifesto. Researchers and developers often present

these problems as reasons why relational database is

not the best choice to use in the engineering systems.

Table 1 presents problems of the relational model

that have been identified by the researchers.

Some issues that have been raised by the

researchers are actually orthogonal to the relational

model. We adopt the approach taken by Date and

Darwen (2000, p. 21): "The question as to what data

types are supported is orthogonal to the question of

support for the relational model." Even Codd (1970)

acknowledged possibility of the nonsimple domains

which permitted values are relations. One reason

why he argues for eliminating nonsimple domains is

that they require more complicated data structures at

the storage level than simple domains. Transaction

model is also orthogonal to the relational model.

Date and Darwen (2000) have requirement for

nested transactions in the section of the Other

Orthogonal Prescriptions.

Hierarchic and networked information can be

represented relationally (Pascal, 2000, chap. 7) Issue

of making queries based on data that represents

graph structure is addressed in the Third Manifesto.

Relational Model Very Strong Suggestion no. 6

(Date & Darwen, 2000, p. 213) requires that

relational language should provide shorthand for

expressing generalized transitive closure query.

Table 1: Problems of the relational model.

Problem Authors who mention

that problem

It is not powerful,

flexible and expressive

enough.

Hardwick and Spooner

(1989),Constantopoulos

et al. (1995).

Fragmentation. Data

about the object is in

the different relations.

Liu et al. (1996),

Gray (1997).

Performance problems

due to fragmentation.

Hardwick and Spooner

(1989), Gray (1997).

Lack of powerful type

system.

Taylor et al. (1988),

Miguel et al. (1990),

Emmerich et al. (1992),

Liu et al. (1996),

Gray (1997).

Poor support to data

that represents graph

structures. Lack of

facilities for making

queries based on such

data including finding

transitive closure.

Hardwick (1984),

Miguel et al. (1990),

Katz (1990),

Emmerich et al. (1992),

Gray (1997),

Lange et al. (2001).

Inappropriate

transaction models for

the engineering

systems.

Hardwick and Spooner

(1989)

Detailed semantics of

the relvars have to be

captured outside the

relational system.

Engle (2003)

Lack of possibility to

preserve semantics of

the relationships.

Zhang et al. (2001)

Fragmentation increases complexity to the user

of database according to Gray (1997). Virtual relvars

(views) help to overcome this problem in the system

that follows the rules of the Third Manifesto. View-

defining expression can join values of relvars that

contain information about the object. It can have

relation-valued attributes which values are

calculated using relational operator GROUP that

provides relation "nest" capability (Date & Darwen,

2000). Gray (1997) writes that fragmentation may

cause performance problems. But "performance is

fundamentally an implementation issue, not a model

issue." (Date, 2005)

Semantics of the relvar that is understandable to

the human user is specified by the external predicate

of the relvar (Date & Darwen, 2000, p. 179). It could

well be recorded in the catalogue of the database that

must be part of the database that it describes.

Semantics of the data that is understandable to the

system is represented by the internal predicate of the

relvar (Date, 2003, p. 262). Constraints to the value

USING RELATIONAL DATABASES IN THE ENGINEERING REPOSITORY SYSTEMS

of relvar specify internal predicate. Therefore

RDBMS should provide means for defining tuple-

attribute-, relvar- and database constraints.

Semantics of the relationship determine

constraints that are used in order to implement this

relationship and operations that may be performed

with the data that participate in the relationships

(Zhang et al., 2001). Relational language may

contain shorthand statements that cause creation of

the database objects that implement particular type

of relationship. An example is a generalization

relationship (Pascal, 2000, p. 158).

Table 2: Problems of the RDBMSs.

Problem Authors who mention

that problem

Views (including

updatable) are

inadequately supported.

Haynie (1981),

Emmerich et al. (1992).

Performance problems. Linton (1984),

Miguel et al. (1990),

Chen et al. (1990),

Lange et al. (2001).

Inappropriate

transaction models.

Katz (1990),

Emmerich et al. (1992),

Gray (1997).

Inadequate

concurrency control

mechanisms.

Constantopoulos et al.

(1995)

Lack of versioning

facilities.

Emmerich et al. (1992),

Gray (1997).

Lack of access control

on a level of single

tuples in a relation

Emmerich et al. (1992)

Lack of distributed and

multi-database

architectures

Gray (1997)

Lack of configuration

management

Gray (1997)

Lack of possibilities to

have cooperative work

processes

Gray (1997)

Table 2 presents problems of the RDBMSs that

are mentioned in the literature. Except problems

with views, all other problems are orthogonal to the

relational model. Problems with the views are

problems of the implementation of the relational

model. Problems that are mentioned in Table 1 and 2

should primarily cause improvement of the

implementation and standards but not necessarily

invention of new data models.

3 USING RELATIONAL DBMS IN

THE REPOSITORY SYSTEM

A repository system permits management of artifacts

that are created using some language that belongs to

the set of its supported languages. Repository system

should allow to add new languages to this set in

order to be most useful. Abstract syntax of the

language can be specified using metamodel

(Greenfield & Short, 2004). Each repository has an

information model that "specifies a model of the

structure and semantics of the artifacts that are

stored in the repository." (Bernstein, 1998)

Information model contains general and

metamodel specific part (see Figure 1). The latter is

union of metamodels of languages that are supported

by the system.

We propose to implement the information model

in the relational database using a set of relation

variables (relvars), data types (types), operators and

integrity constraints. There is more than one possible

design of the repository.

1. Encapsulated artifact types: Each artifact type

has a corresponding scalar type and a base relvar

in a database. Artifact is recorded as a tuple that

is part of the value of this relvar.

2. Encapsulated artifact element types: Each

artifact element type ET has a corresponding

scalar type T and relvar R with an attribute that

has type T.

3. Not-encapsulated artifact element types: Each

artifact element type has a corresponding relvar

where each property of the element is repre-

sented by one attribute with the appropriate type.

Artifact is recorded as a set of tuples that are part

of values of more than one relvar in case of design 2

and 3. Design 1 and 2 don't eliminate complexity.

They require more complex scalar type and scalar

Figure 1: Example of the information model.

ICEIS 2006 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

operator specifications than design 3. In general,

types should correspond to properties and relvars to

entities (Date & Darwen, 2000, appendix C).

Therefore we choose design alternative 3. Next we

explain this design alternative more thoroughly.

Each artifact element type is implemented using

at least following database objects:

1. Exactly one relation type RELATION {H}

where H is heading of the relation in the form

,..., C

). C

... C

are pairs of type name and

attribute name. Each attribute corresponds to one

property of the artifact element type.

2. Scalar types that are used in the pairs C

... C

3. Set of operators that allow selecting and

modifying components of the possible

representation of these scalar types.

4. Exactly one base relvar with the type

RELATION {C

,...,C

5. Let's assume that we have a generalization/

specialization relationships between element

types ET

and ET

in the information model. ET

is supertype and ET

k+1

is its direct subtype (1≤k<

n). Relvar R

that corresponds to ET

and relvar

k+1

that corresponds to ET

k+1

are associated

using foreign key. For each element type where

k>1 we have to create a corresponding virtual

relvar. For example, element type ET

k+1

has

corresponding virtual relvar V

k+1

that joins

values of relvars R

,..., R

k+1

. If one assigns a new

value to V

k+1

, then system must assign a new

value to all the relvars R

,...., R

k+1

Integrity constraints – type-, attribute-, relval-

and database constraints enforce well-formedness

rules of the artifacts. Model management operations

like Merge, Diff, Compose etc. (Bernstein, 2003)

can be implemented using read only relation valued

operators.

We illustrate our ideas by using a simple

software design language SimpleM that was

originally presented by Serrano (1999) in order to

introduce VCt specification language. SimpleM

specifies one diagram type. It is used for creating

simple state diagrams. Diagram is a kind of artifact.

Metamodel of the language is presented in the

metamodel specific part in figure 1.

Serrano (1999) describes well-formedness rules

of the language. We have modified rules R1 and R2.

(R1): Both StartState and State have a label with

a name that is unique amongst all other states. (R2):

There is at most one StartState in the repository.

(R3): "The StartState can only be connected to

States by outgoing Events." (R4): "Any pair of

States is connected at most by two Events, one in

each direction." (R5): "Loop Events, i.e. Events that

connect a State to itself, are not allowed."

Next we present examples of statements for

creating integrity constraints. They are written in

TutorialD relational language and have been tested

in the prototypical DBMS Rel (Voorish, 2005).

Tutorial D language has been proposed in the Third

Manifesto (Date & Darwen, 2000) and dialect used

by Rel is based on that proposal.

CONSTRAINT C_2 (COUNT(StartState)<=1);

CONSTRAINT C_3 IS_EMPTY ((Event RENAME

(element_id# AS el_id#, destination AS

element_id#) JOIN State) JOIN

StartState);

CONSTRAINT C_5 (IS_EMPTY (Event WHERE

origin=destination));

CONSTRAINT C_6 IS_EMPTY (Artifact_

element SEMIMINUS Element_in_artifact);

Each relvar must have at least one candidate key.

Some well-formedness rules can be enforced by

creating appropriate key constraints. Rule R1 can be

enforced by creating the relvar constraint

KEY{name} in the relvar State. It declares, that name

of the State is a candidate key. Rule R4 can be

enforced by creating the relvar constraint

KEY{origin, destination} in the relvar Event.

Constraint KEY {artifact_id#, element_id#} in the

relvar Element_in_artifact ensures, that each

element can participate only once in the artifact.

Together with the constraint C_2 they guarantee that

each diagram (artifact) can contain at most one

StartState.

Rules R2 and R5 are enforced by the relvar

constraints C_2 and C_5, respectively. IS_EMPTY

(<relation exp>) is a scalar operator that evaluates to

true if the body of the relation denoted by <relation

exp> contains no tuples (Date et al., 2003).

Constraints C_3 and C_5 could also be created using

Count operator (Count(<relation exp>)=0).

Rule R3 is enforced by the database constraint

C_3. C_3 is created based on the reformulation of

R3 to the equivalent rule R3'. (R3'): StartState can't

be destination of any event. C_3 is a database

constraint and not a relvar constraint because it

references to more than one relvar.

Database constraint C_6 ensures that each

element is part of at least one artifact. It uses

relational operator SEMIMINUS (Date, 2003) in

order to find tuples of one relation that have no

counterpart in another.

If a relvar in a database gets a new value, then

DBMS checks immediately conformance of this

value to the integrity constraints and rejects invalid

changes. Our earlier article (Eessaar, 2005) explains

principles of the repository system that follows

previously described principles and checks well-

formedness of an artifact only if user of the system

USING RELATIONAL DATABASES IN THE ENGINEERING REPOSITORY SYSTEMS

wants that. It explains also how to implement

versioning in such a system.

4 USING CURRENT ORDBMS IN

THE REPOSITORY SYSTEM

Metamodel of the artifact language can be

implemented in a object-relational database using a

set of built-in- and user-defined data types, domains,

base tables and virtual tables (views), built-in- and

user defined routines, triggers, sequence generators

and integrity constraints.

This section presents analysis of the problems of

SQL that make usage of the current ORDBMSs in

the repository systems more difficult. It is one result

of this paper. Some problems are caused by the

shortages of SQL standard and some are caused by

the incomplete implementation of the standard in the

ORDBMSs. Following description of SQL standard

is based on SQL:1999 (Gulutzan & Pelzer, 1999)

and SQL:2003 (Melton, 2003). We also compare

existing standard and systems to proposals of the

Third Manifesto.

Current ORDBMSs make it difficult to use

declarative constraints in a database in order to

enforce well-formedness rules of the artifacts.

Firstly, separation of "domain" and "type" concept in

SQL causes problems. Let's assume that we want to

specify that names of patterns can't be empty strings

or strings that contain only spaces or underscores.

The Third Manifesto treats concepts "domain" and

"data type" as synonyms. It prescribes that relational

system should allow specification of new scalar

types and scalar operators which declared types of

parameters are scalar types. Type can be specified

using type constraints. System has to enforce strong

typing by checking that operands that participate in

the operation have a right type.

In SQL a data type is "a set of representable

values" (Melton, 2003, p. 11) and a domain is "a set

of permissible values" (Melton, 2003, p. 49).

According to Mattos and DeMichiel (1994)

specialization by constraints should be prohibited

because it requires overloading of operators.

Negative implications of this approach are discussed

by Date and Darwen (2000, appendix G). We add

that if user wants to define a set of valid data values

by adding constraints to the predefine type, then one

has to create a domain object in SQL. It is not

possible to create a new domain based on existing

one. In addition, Türker and Gertz (2001) evaluate

seven DBMSs that use SQL language and note that

only one of them supports domain objects.

If a user wants to define a new type in SQL,

based on one predefined type and achieve strong

typing, then a distinct type has to be created. One

can't use constraint definitions there. One also has to

use a predefined type as a base type for distinct type

and can't use distinct type as a base type for the

domain. In case of using distinct or structured types

one has to check correctness of the attribute values

using the methods of this type. Methods can be

implemented using some imperative language (SQL

procedural extensions or other). Greenfield and

Short (2004, p. 227) adopt definition: "An

imperative specification describes instructions to be

executed without describing the desired results of

execution". Lloyd (1994) shows advantages of the

declarative programming languages compared to

imperative languages which include easier teaching,

clearer semantics, improved programmer

productivity and better support to meta-

programming and parallelism.

Date and Darwen (2000) treat concepts

"operator" and "function" as synonyms but use the

term "operator". SQL (starting from SQL:1999)

specifies statements for creating user defined

functions but don't specify statement for creating

operators. It is not possible to determine more

convenient infix, prefix or postfix notation that is

used in order to call this function. On the other hand,

SQL dialect of PostgreSQL (PostgreSQL, 2005) and

Oracle (Oracle, 2005) allow to create user defined

operators as well as user defined functions.

Date et al. (2003, p. 22) introduces the scalar

operator IS_EMPTY that could be built-in. For

example, it is useful in order to specify constraints

(see section 3). Currently there is not such built-in

operator or function in SQL (Melton, 2003) and one

has to program it using the Count function.

Current ORDBMSs have problems with the

relvar and database constraints. Relvar constraint is

associated with exactly one relvar and database

constraint is associated with two or more relvars

(Date, 2003). Relvar constraint can be implemented

as a CHECK constraint. There exists ORDBMSs

like PostgreSQL (PostgreSQL, 2005) and Oracle

(Oracle, 2005) that don't allow to use subqueries in

the CHECK constraint although SQL standard

permits that. Relvar and database constraints can be

implemented using assertions that constrain the set

of valid values for one or more base tables in SQL

(Gulutzan & Pelzer, 1999). Unfortunately Ceri et al.

(2000) note that many RDBMSs don't support

assertion objects although this type of object is

specified in SQL standard. Türker and Gertz (2001)

note in the review of integrity constraints in the

different DBMS-s: "assertions are in general not

available and are unlikely to be offered in the near

future". Cochrane et al. (1996) write that RDBMSs

don't support assertions because they are "extremely

expensive to support". Maybe it means that assertion

ICEIS 2006 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

reduces performance of the system? But

performance is an issue of the implementation of the

data model. Alternative method for enforcing

constraints in the current ORDBMSs is to use

imperative programs in the SQL-invoked routines or

triggers that where both first time standardized in

SQL:1999. If data in the database is changed using

SQL-invoked routines, then they can check the well

formedness rules. In this case routines must be the

only means for modifying data. Systems like UML-

repository (Marder et al., 1999), and business-rule

enforcer (Zimbrão et al., 2003) use declarative OCL

constraints in order to specify database constraints.

They can't use assertions in order to implement these

constraints and have to generate triggers. Instead of

one declarative constraint we may need many

triggers that are associated with different tables in

order to react to all the relevant events. For example,

constraint C_3 (see section 3) can be implemented

using insert and update triggers that are associated

with the tables Event and StartState.

If triggers have sufficient performance compared

to assertions, then creation of the declarative

constraint at the model level could cause automatic

creation of the imperative programs (triggers) at the

implementation level.

DBMS should have information about semantics

of relationships between entity types in order to be

able enforce properties of the relationships and

answer to the queries (Zhang et al., 2001).

Generalization relationship is an example of a

generic relationship that is often used in the

metamodels. For example, StartState is a State (see

Figure 1). SQL standard defines language constructs

for creating subtables and supertables that seem

suitable in order to implement this kind of

relationship. Both subtable and supertable must be

typed tables and structured type on which subtable is

defined must be subtype of the structured type on

which supertable is defined (Date, 2003). As stated

earlier, it is not possible to use declarative

constraints in the structured type specification.

Non-standard approach is used in PostgreSQL

(PostgreSQL, 2005) where subtable and supertable

don't have to be typed tables. PostgreSQL

implementation of subtable-supertable feature is

immature because many declarative constraints of

the supertable are not inherited by the subtable.

Date and Darwen (2000) show that desired

functionality can be achieve in the relational system

that follows the rules of the Third Manifesto,

without using subtable-supertable feature and

therefore raise question about usefulness it. They

propose that each subtable must have corresponding

virtual relvar that joins relations that correspond to

the subtable and supertable. Value of the virtual

relvar must be updatable and updates must propagate

to the base relvars (Date & Darwen, 2000).

Relational language could have special statement in

order to create relvar that is conceptually associated

with other relvar through generalization relationship

(Pascal, 2000). This kind of statement causes

creation of necessary base- and virtual relvars.

SQL:1992 and earlier standards don't allow to

use joins in the updatable views (Date, 2003).

Starting from SQL:1999 views defined as one-to-

one or one-to-many join of two base tables are

updatable (Date, 2003). Unfortunately there are

ORDBMSs that don't support SQL standard in this

regard. For example, in PostgreSQL all views are

not-updatable without further programming

(PostgreSQL, 2005). In Oracle DML statement must

affect only one underlying table of the updatable

join view (Oracle, 2005). But in this case system

needs to add data to all the base tables that

participate in the join.

Alternative is to use rules (PostgreSQL, 2005) or

instead-of triggers (Oracle, 2005) that are associated

with a view in order to achieve its updatability.

These objects require additional programming and

are not-standardized features.

Yet another possibility is to use triggers

that are

associated with the base tables. Let's assume that

table T

sub

is a subtable and T

sup

is its supertable. For

example, we could create delete and update triggers

that are associated with T

sub

. Their task is to delete

corresponding row from T

sup

then row in T

sub

deleted and update primary key of T

sup

then

corresponding foreign key is updated in T

sub

respectively. This approach also requires insertion of

new rows into T

sub

and T

sub

within one transaction

using two different statements. In contrast, the Third

Manifesto states that constraints must be satisfied at

statement boundaries and relational language must

have multiple form of the assignment operation in

which several individual assignments to relvars are

performed in parallel as a single logical operation

(Date & Darwen, 2000).

Ceri et al. (2000) notes that handcrafted triggers

are error-prone and triggers should be created by the

system. Triggers or rules that implement supertable-

subtable feature must be automatically generated by

the repository system then new base- or virtual table

is added to the repository database. It increases

complexity of the system.

Standardization of some important features that

where strongly suggested by the Third Manifesto has

begun in SQL:1999 or SQL:2003. It takes time

before ORDBMSs start to fully implement the

standard in this regard.

Recursive queries allow to find transitive closure

of graph structure (introduced in SQL:1999).

Information about the associations between artifacts

as well as associations between elements of artifacts

USING RELATIONAL DATABASES IN THE ENGINEERING REPOSITORY SYSTEMS

is recorded in a repository. Associations and

associated elements form a graph structure. Example

of the query that is needed then pattern is modified:

Find all patterns in the pattern language PL which

directly or indirectly depend on pattern P.

Multisets (introduced in SQL:2003) could be

used in the views that allow to present artifact to a

user without fragmentation. SQL specifies UNNEST

operator that allows to present elements of a multiset

as rows of a virtual table. Integrity of these rows can

be checked by the table or database constraints. As

we said earlier, current DBMSs provide limited

support for declarative constraints. It hampers usage

of the columns that have multiset types in the base

tables. Examples of the constraints are restrictions to

the cardinality of a multiset or requirement that a

multiset shouldn't contain repeating elements.

Table-functions (introduced in SQL:2003) allow

to implement parameterized relational operators and

return multiset (bag) of rows. They help to

implement queries that search artifacts or statistical

information from the repository.

Sequence generators generate values for the

candidate keys (introduced in SQL:2003).

Multiset can contain repeating elements. It is not

consistent with the Third Manifesto that prohibits

duplicate tuples in a body of a relation. Developer

who wants to use sets of rows instead of multisets

must be continuously aware that most of SQL

statements must explicitly state it.

5 CONCLUSIONS

In this paper, we showed that current RDBMSs and

ORDBMs have problems that hamper their usage in

the repository systems. Some necessary features like

views and constraints are not object-oriented and are

required by the earlier SQL standards. They are not

implemented correctly or not implemented at all in

the current DBMSs. In addition, SQL is not a correct

implementation of the relational model. These

shortages cause criticism towards SQL and

relational model. They cause addition of new

features to SQL standard and dialects that would be

unnecessary if SQL fully conforms to the relational

model. Some object-oriented features that are added

to the ORDBMSs are actually required by the Third

Manifesto. We explained how the RDBMS that

follows these requirements can be used in the

repository system.

Future work will include the creation of a

prototype repository system that uses RDBMS that

follows the rules of the Third Manifesto.

REFERENCES

Allsop, D. J., Harrison A., & Sheppard, C. (2002). A

database architecture for reusable Common KADS

agent specification components [Electronic version].

Knowledge-Based Systems, Vol. 15, No. 5, 275-283.

Bernstein, P. A. (1998). Repositories and Object-Oriented

Databases [Electronic version]. SIGMOD Rec. Vol. 27,

Issue 1, Mar. 1998), 88-96.

Bernstein, P. A., (2003). Applying Model Management to

Classical Meta Data Problems [Electronic version]. In

Proceedings of the Conference on Innovative Data

Systems Research 2003, 209-220.

Ceri, S., Cochrane, R., & Widom, J. (2000). Practical

Applications of Triggers and Constraints: Success and

Lingering Issues [Electronic version]. In Proceedings

of the 26th international Conference on Very Large

Data Bases, 254-262.

Chen, Y.F., Nishimoto, M. Z., & Ramamoorthy, C. V.

(1990). The C Information Abstraction System

[Electronic version]. IEEE Transactions on Software

Engineering, Vol.16, No. 3, March 1990, 325-334.

Cochrane, R. J., Pirahesh, H., & Mattos, N. M. (1996).

Integrating triggers and declarative constraints in SQL

database sytems [Electronic version]. In Proceedings

of the 22th international Conference on Very Large

Data Bases, 567–578.

Codd, E. F. (1970). A relational model of large shared data

banks [Electronic version]. Comm. ACM, Vol. 13, No.

6, 377-387.

Constantopoulos, P., Jarke, M., Mylopoulos, J., &

Vassiliou, Y. (1995). The Software Information Base:

A Server for Reuse [Electronic version]. VLDB

Journal, 4 (1995), Boxwood Press, Pacific Grove, CA,

1- 43.

Date, C. J., & Darwen, H. (2000). Foundation for Future

Database Systems: The Third Manifesto, Addison-

Wesley. Reading, Massachusetts, 2

edition.

Date, C. J. (2003). An Introduction to Database Systems,

Pearson/Addison Wesley. Boston, 8

edition.

Date, C. J. (2005) Database in depth : relational theory

for practitioners, O'Reilly. Beijing; Cambridge.

Date, C. J., & Darwen, H., & Lorentzos, N. A. (2003).

Temporal Data and the Relational Model, Morgan

Kaufmann. San Diego, CA.

Dittrich, K., Tombros, D., & Geppert, A. (2000).

Databases in Software Engineering: a roadmap

[Electronic version]. In Proceedings of the Conference

on the Future of Software Engineering. ICSE '00.

ACM Press, New York, NY, 293-302.

Eessaar, E. (2005). Truly Relational Databases as a

Platform for the Artifact Management. In Proceedings

of the Fourteenth International Conference on

Information Systems Development: Pre-Conference

14-17 August 2005, Karlstad, Sweden, 207-218.

Emmerich, W., Schäfer, W., & Welsh, J. (1992). Suitable

Databases for Process-centred Environments Do not

yet Exist [Electronic version]. In Proceedings of the

EWSPT '92, 94-98.

ICEIS 2006 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

Engle, P. (2003). Data Modeling – Left and Right. The

Data Administration Newsletter, Issue 24, April 2003.

Retrieved October 07, 2005, from

http://www.tdan.com/i024hy03.htm#_edn15

Gray, P. (1997). CASE tool construction for a parallel

software development methodology [Electronic

version]. Information and Software Technology, Vol.

39, Issue 4, 235-252.

Greenfield, J., & Short, K. (2004). Software Factories:

Assembling Applications with Patterns, Models,

Frameworks, and Tools, John Wiley & Sons.

Indianapolis.

Gulutzan, P., & Pelzer, T. (1999). SQL-99 Complete,

Really, Miller Freeman. Lawrence.

Hardwick, M. (1984). Extending the relational database

data model for design applications [Electronic

version]. In Proceedings of the 21st Conference on

Design Automation. IEEE Press, Piscataway, NJ, 110-

116.

Hardwick, M., & Spooner, D. L. (1989). The ROSE data

manager: Using object technology to support

interactive engineering applications [Electronic

version]. IEEE Transactions on Knowledge and Data

Engineering. Vol. 1, no. 2, 285-290.

Haynie, M. N. (1981). The relational/network Hybrid data

model for Design Automation Databases [Electronic

version]. In Proceedings of the 18th Conference on

Design Automation. IEEE Press, Piscataway, NJ, 646-

652.

Katz, R.H. (1990). Toward a Unified Framework for

Version Modeling in Engineering Databases

[Electronic version]. ACM Computing Surveys 22:4,

1990, 375– 408.

Lange., C., Sneed, H. M., & Winter, A. (2001).

Comparing Graph-based Program Comprehension

Tools to Relational Database-based Tools [Electronic

version]. In Proceedings of the 9th International

Workshop on Program Comprehension. IEEE

Computer Society. Los Alamitos. 209--218.

Linton, M. (1984). Implementing relational views of

programs [Electronic version]. In Proceedings of ACM

SIGSOFT/SIGPLAN Software Engineering Symposium

on Practical Software Development Environments,

132–140.

Liu, C., Li, H., & Orlowska, M. E. (1996). Object-

Oriented Design of Repository for Enterprise

Workflows. Retrieved October 5, 2005 from

University of Queensland, DSTC Web site

http://www.dstc.uq.edu.au/Research

/Distributed_Databases/papers/Liu-OOD-1996.ps

Lloyd, J. (1994) Practical Advantages of Declarative

Programming [Electronic version]. Invited Lecture,

GULP-PRODE '94.

Mahnke, W., & Ritter, N. (2002). The ORDB-based SFB-

501-Reuse-Repository [Electronic version]. In

Proceedings of the 8th International Conference on

Extending Database Technology, 745-748.

Marder, U., Ritter, N., & Steiert, H. P. (1999). A DBMS-

based Approach for Automatic Checking of OCL

Constraints [Electronic version]. In OOPSLA’99-

Workshop "Rigourous Modeling and Analysis with the

UML: Challenges and Limitations", Denver, Co.

Mattos, N., & DeMichiel, L. G., (1994). Recent design

trade-offs in SQL3 [Electronic version]. SIGMOD

Rec. 23, 4 (Dec. 1994), 84-90.

Melton, J., ISO/IEC 9075-2:2003 (E) Information

technology — Database languages — SQL — Part 2:

Foundation (SQL/Foundation). August, 2003.

Retrieved December 26, 2004, from

http://www.wiscorp.com/SQLStandards.html

Miguel, L., Kim, M. H., & Ramaroothy, C. V. (1990). A

Knowledge and Data Base for Software Systems

[Electronic version]. In Proceedings of the 2nd

International IEEE Conference on Tools for Artificial

Intelligence, 417-423.

Oracle® Database SQL Reference 10g Release 1 (10.1)

Part Number B10759-01. Oracle Corp., Retrieved

October 4, 2005, from http://download-

west.oracle.com/docs/cd/B14117_01/server.101/

b10759/toc.htm

Pascal, F. (2000). Practical issues in Database

Management. A Reference for the Thinking

Practioner, Addison-Wesley. Boston, Mass, 1st

edition.

PostgreSQL 8.0.3 Documentation. Retrieved October 4,

2005, from http://www.postgresql.org/docs/8.0/

interactive/index.html

Serrano, J. A. (1999). Formal Specifications of Software

Design Methods [Electronic version]. 3rd Irish

Workshop on Formal Methods.

Taylor, R.N., Belz, F.C., Clarke, L.A., Osterweil, L.,

Selby, R. W., Wileden, J. C., Wolf, A. L., & Young,

M. (1988). Foundations for the Arcadia environment

architecture [Electronic version]. In Proceedings of the

Third ACM SIGSOFT/SIGPLAN Software

Engineering Symposium on Practical Software

Development Environments. SDE 3. ACM Press, New

York, NY, 1-13.

Türker, C., & Gertz, M. (2001) Semantic integrity support

in SQL:1999 and commercial (object-) relational

database management systems [Electronic version].

The VLDB Journal, Vol. 10, No. 4 (Dec. 2001), 241–

269.

Voorish, D. (2005). An Implementation of Date and

Darwen's "TutorialD". Retrieved March 26, 2005 from

http://dbappbuilder.sourceforge.net/Rel.html

Zhang, N., Ritter, N., & Härder, T. (2001). Enriched

Relationship Processing in Object-Relational Database

Management Systems [Electronic version]. In

Proceedings of the 3rd International Symposium on

Cooperative Database Systems for Advanced

Applications, 53-62.

Zimbrão, G., Miranda, R., Souza, J.M., Estolano, M.H., &

Neto, F.P. (2003). Enforcement of Business Rules in

Relational Databases Using Constraints [Electronic

version]. SBBD 2003, 129-141.

USING RELATIONAL DATABASES IN THE ENGINEERING REPOSITORY SYSTEMS
