CONTEXT OF USE ANALYSIS

Activity Checklist for Visual Data Mining

Edwige Fangseu Badjio, François Poulet

ESIEA Pôle ECD, 38 Rue des Docteurs Calmette et Guerin, 53000 Laval France

Keywords: Visual data mining, activity theory, context of use, requirements.

Abstract: In this paper, emphasis is placed on understanding how human behaviour interacts with visual data mining

(VDM) tools in order to improve their design and usefulness. Computer tools that are more useful assist

users in achieving desired goals. Our objective is to highlight quality in context of use problems with

existing VDM systems that need to be addressed in the design of new VDM systems. For this purpose, we

defined a checklist based on activity theory. The responses provided by 15 potential users are summarised

as design insights. The users respond to questions selected from the activity checklist. This paper describes

the evaluation method and shares lessons learned from its application.

1 INTRODUCTION

Computer capabilities offer means to store very

large databases. All these databases are not useful if

at least a part of information they contain is not

extracted. It is the goal of Knowledge Discovery in

Databases (KDD) process. According to (Fayyad et

al., 1996), KDD is the non-trivial process of

identifying valid, novel, potentially useful, and

ultimately understandable patterns in data. Several

KDD packages offer means to visualize data and

KDD results.

In this paper, emphasis is placed on

understanding how human behaviour interacts with

visual data mining (VDM) tools. A considerable

effort has been done to enhance KDD tasks

performance. High performance algorithms have

been created (Grossman and Yike, 2002), (Freitas

and Lavington, 1998). A considerable effort has

been done to enhance KDD tasks performance. Also,

decision support systems for the appropriate

selection and parameterization of such techniques

have been provided (Michie et al., 1994), (Fangseu

Badjio and Poulet, 2004a). In spite of good results

obtained by VDM tools, there is less interest on

human factors. Few investigations have been done

about for example what would occur when these

powerful systems will be transferred from the

research laboratories to a real use and on a large

scale? What think the end users to who are intended

the data mining tools? (Whiteside et al., 1988) and

(Wolf, 1989) found that although many products

performed well in their laboratory experiments, they

did not work when transferred to the real work. They

put this down to the fact that the research often

overlooked something crucial to the context in

which the product would be used (Maguire, 2001).

Recommendations for more usable VDM tools

and methods allowing the evaluation of this type of

tools using a combination of human-centred, task,

environment oriented approaches, and general

knowledge of Human Computer Interaction (HCI)

design have been proposed (Fangseu Badjio and

Poulet, 2004b, 2005a, 2005b). In this contribution,

we address the VDM context of use analysis for

usability evaluation. Taking human factors into

account in software evaluation involves considering

not only users but also tasks and context of use.

Consequently, the evaluation of VDM tools requires

the analysis of the context of use to understand the

impact of the artefact.

The objective here is to improve the quality of

VDM tools in the design step, increase user

productivity and decrease user errors. For this

purpose, we use a social science theory named

activity theory (AT) which is a philosophical

framework used to analyse and model human

activity. Activity theory provides a robust analytical

framework and a common vocabulary for describing

human activity in context (Nardi, 1996). Context of

use analysis is a technique that assists software

engineering. It is performed in order to resolve

Fangseu Badjio E. and Poulet F. (2006).

CONTEXT OF USE ANALYSIS - Activity Checklist for Visual Data Mining.

In Proceedings of the Eighth International Conference on Enterprise Information Systems - HCI, pages 45-50

DOI: 10.5220/0002456100450050

 SciTePress

problems in the software development process.

VDM tools design could benefit from activity theory

approach to analyse the transformative relationship

between users of a computer system and the activity

in which there are engaged. For this purpose, we

have to establish the means by which the concepts

presented in activity theory can be incorporated in

VDM tools design.

The responses provided by 15 potential users are

summarised as design insights. The users answer

questions selected from the activity checklist.

The overview of this paper is the following:

firstly, we present the VDM domain and the means

allowing an overall analysis of such software and the

activity checklist. Lastly, there is a case study before

conclusion and future works.

2 THE VDM DOMAIN AND

QUALITY OF USE

The first research works treating VDM appear at the

end of 1990s (Cox et al., 1997), (Inselberg, 1998).

VDM relates to the use of visualisation as

communication channel for the discovery of

correlations in data. Being given the increasing

quantity of the data available in the world, a point of

interest of the field consists in the development of

visual representation techniques for massive data

sets and innovative computing techniques. For

example, (Keim, 1996) has proposed a pixel based

method from which an interactive method for

decision trees construction is derived (Ankerst et al.,

1999). Other visualisation methods (self organizing

map (Deboeck and Kohonen, 1998), 2D matrices

(Witten and Eibe, 2000), and parallel co-ordinates

(Yujin et al., 2004)) have been used for VDM.

Except some few works, the VDM field first

results relate much more to technical aspects

development. (Grinstein et al., 1997) for example

was interested in the technical quality of visual

representations used in data mining field. Recently,

an interest was carried towards VDM tools usability

(quality of use). Indeed, in spite of their necessity,

VDM tools have utility only if the end-users accept

to use them. In general, the software acceptability is

related to its quality. In the process of determining

the software quality, the end-user is the most

indicated. The utility of a VDM tool relates to the

adequacy existing between the functions provided

by the system and those necessary to the user in

order to achieve the VDM tasks assigned to him.

There are many design guides ensuring the

quality of software, we have for example HCI

standards (ISO, 1998), and a set of ergonomic

criteria (Nielsen and Landauer, 1993), (Bastien et

al., 1999). Software quality assessment is done by

evaluation which should be considered at all life

cycle stages (design techniques, prototyping and

implementation techniques). The evaluation can be

completed by an expert, the end user or can be

model or task based.

We study the qualitative analysis of a VDM

system for which there could be several approaches:

visual representation oriented approach, data

oriented approach, task oriented approach, interface

oriented approach and then context (activity, event,

regulation) oriented approach. We are interested in

the last one. According to (Suchman, 1987), context

can be seen as a resource upon which users can

draw. It is important to evaluate computer systems in

context. Contextual analysis helps explain the

reasons for an outcome, clarifies a situation, make a

situation more specific. Many authors recommended

representative evaluations in context; we have for

example (Bevan and Macleod, 1994), (Beyer and

Holtzblatt, 1999).

3 ACTIVITY THEORY

3.1 Definition

Activity theory is a theoretical framework that

provides concepts and a vocabulary to analyse and

understand human activity in context. Activity

theory provides an alternative formulation to

information processing as to how people learn and

society evolves, from a material perspective, based

on the concept of human activity as the fundamental

unit of analysis. According to (Nardi, 1996), activity

theory is a powerful and clarifying descriptive tool

rather than a strongly predictive theory. The

pioneers of activity theory are Vygotsky and

Leont’ev (Leont'ev, 1978), further development have

been done by Engeström (Engeström, 1987). Two

basic ideas animate activity theory: (1) the human

mind emerges, exists, and can only be understood

within the context of human interaction with the

world; and (2) this interaction, that is, activity, is

socially and culturally determined (Kaptelinin et al.,

1999).

There are six main principles within activity

theory:

ICEIS 2006 - HUMAN-COMPUTER INTERACTION

Unity of consciousness and activity (state that

human learn by doing and the human consciousness

is formed by interaction with external world),

Object-orientedness (every activity has an object

(purpose) and is performed in order to achieve a

goal),

Mediation (the principle of mediation states that

in any activity there will be tools involved, both

physical and psychological),

Internalisation/Externalisation (Internalisation

is the process by which mental representations are

formed by carrying out external actions.

Externalisation is the opposite: where mental

representations are manifested in external actions),

Hierarchical structure (each activity can be

decomposed into actions and operations),

Development (this principle explains that activity

can only be understood through analysis of its

developmental transformations).

3.2 Activity Theory and VDM

VDM tools cannot be introduced in KDD domain as

a powerful decision support tool without analyzing

the impact from the users’ point of view. Activity

theory is concerned with understanding the

relationship between consciousness and activity

(Nardi, 1996). We must understand how visual data

miners can perceive the VDM tool and their impact

on the work to be achieved. The activity theory is a

general framework for studying different forms of

human activity as development processes (Kuutti,

1996). Within our context, the activity theory is

particularly interesting in that it postulates that an

activity has to be analyzed both as an individual

process and a social process. Activity theory has the

potential to provide a shared vocabulary for

designers and to resolve some of the problems

facing the VDM field. More precisely, activity

theory offers tools for defining user needs and

evaluating usability. Current trends in VDM can

then be understood by: identifying the structure of

activities that undergo transformations, revealing the

most important contradictions typical of the current

stage of development of the above activities,

analyzing the ways technological affordances and

limitations can influence the above contradictions,

considering possible scenarios of resolving the

contradictions with the help of technology, and

anticipating further contradictions.

Figure 1: Structure of the activity (Visual Data Mining).

The Figure 1 presents the application of the basic

activity theory framework to VDM domain. The

subject of the activity would be the data miner, the

mediation tool would be VDM, the object to be

transformed would be a dataset and the result would

be data models ready for usage.

In order to understand the VDM system’s

context of use, we focus on the triad described by

Figure 1. We analyse the impact of VDM

(considered as tool) on Data Miner and specify in a

systematic way the characteristics of the users, the

tasks there will carry out, and the circumstances of

use. First steps are description of the VDM software

and characterisation of its context of use. The Figure

1 shows also that the treatments of datasets will have

an impact on Data Miners. The activity theory helps

to capture the context of software. Features of

activity theory that have implications for visual data

mining tools include recognition of actions,

mediator, historicity, constructivism, dynamics and

others. Finally, Activity Theory offers a promising

avenue for providing a framework and theories to

deal with the developmental and dynamic features of

human practices.

The features and benefits of the activity theory

are: identify the stakeholders in the process; ensure

that technology is designed to benefit the user; work

toward alignment between users’ rewards and

business needs; work toward alignment between the

rewards of the designers of the device and the

business needs.

By using activity theory conceptual framework,

we ensure that quality studies reflect the context of

use.

Usually for context of use analysis, a range of

people who have a stake in the development bought

together at the context meeting. Instead of

contextual meeting, our proposition suggests the

analysis of existing tools in order to find out if the

current user needs are satisfied. For this purpose, a

contextual analysis checklist has been defined. It is a

kind of requirement elicitation process. A

requirement is a criterion that a system must meet; a

desired feature, property, or behaviour of a system.

There are functional and non-functional

requirements. Functional requirements describe the

VDM

a Model

a se

Data

Miner

CONTEXT OF USE ANALYSIS - Activity Checklist for Visual Data Mining

interactions between the system and its environment

independent from implementation. Non-functional

requirements are the user visible aspects of the

system not directly related to functional behaviour.

For recommendations elicitation, we analyze

existing software usefulness and usability. Our

objective is to highlight quality of use problems with

existing systems that need to be addressed in the

design of new systems. The goals are: minimizing

human information processing, minimizing

cognitive demand on the users and avoiding errors

or poor performance. We performed post evaluation

of existing VDM tools which objectives are:

assessing whether stated development goals have

been met and suggesting strategies for future design

changes.

The next section presents the context of use

analysis approach.

4 ACTIVITY THEORY BASED

CONTEXTUAL ANALYSIS

METHOD

The proposed analysis approach based on activity

theory is a checklist which helps to ask meaningful

questions about context of use analysis in VDM

field. The following paragraphs present the main

topics of the activity checklist knowing that context

of use analysis aims at identifying and addressing

user needs that may not be obvious. For this

purpose, during the task, we are interested in the

following subjects concerning the users: understand

task and purpose, choose appropriate strategy,

attention, anticipation and prediction,

comprehension assistance, hesitation, confusion,

new method integration. After the task, we are

interesting in user assimilation and competent

feelings.

Object examination: Every visual data mining

session has an objective and is performed in order to

achieve a goal. In this part, we examine if there are

tasks that users will want to perform that are not

currently supported by visual data mining tools.

Support for Internalisation/Externalisation

and Learning: Internalisation is the process by

which mental representations are formed by carrying

out external actions. Externalisation is the opposite:

where mental representations are manifested in

external actions. The sub-topics of this topic are:

user training for software usage, contain of

documentation, documentation and software

coverage, user background requirement.

Support for Actions and Operations: in this

topic, we are interested in how the user associates

the correct action with the effect to be achieved, how

the user notice the correct action is available. Other

points of interest concern on-line help, paper based

user guide, tool installation (network, floppy or CD)

without assistance.

Support for Mediation: the principle of

mediation states that in any activity there will be

tools involved, both physical and psychological.

Development: users activities can only be

understand through analysis of its development

transformation.

5 CASE STUDY

5.1 Users

The evaluation is based upon the use of VDM

software by 15 master degree students in computer

science and business administration, there are

volunteers. During the recruitment process, these

volunteers were asked to specify the following

details: experience and training with data mining and

VDM, experience and training with WEKA (Witten

and Eibe, 2000). They were also asked to specify

experience and training with graphical

representation and interaction with visualisations,

attitude to task and product.

The selected volunteers have no experience with

the product and basic knowledge about data mining,

VDM, graphical representations and visual

interaction.

5.2 Task

The evaluation consisted of a single task: interactive

construction of a decision tree starting from

representations of the datasets described in table 2

from the UCI (Blake and Merz, 1998). Data sets for

this kind of evaluation can also be found in other

repositories (Jinyan and Huiqing, 2002). The

decision trees allow partitioning a great quantity of

data in small groups or parts by application of a

series of decision rules.

Table 1: Datasets characterisation.

Dataset name Nb of

records

Nb of

Attributes

Nb of

classes

Ionosphere 351 32 2

Vehicle 846 18 4

Segmentation 2310 11 7

SatImage 6435 36 6

Letters 20000 16 26

ICEIS 2006 - HUMAN-COMPUTER INTERACTION

The purpose of this context of use study was to

assess through a set of interviews the design of a

WEKA module for VDM named UserClassifier and

to identify areas for improvement. The volunteers

answer questions whether they were satisfied with

UserClassifier or not and they stated some

improvements directions. Interviews were conducted

following a semi-structured guide extracted from the

activity checklist. Some examples of the semi-

structured guide questions are:

Describe your use of UserClassifier for VDM.

What information and functions of the

UserClassifier module do you find most useful?

What information needs are not currently being

met by the UserClassifier module?

How could any of these unmet information need

be met by the UserClassifier module?

5.3 Environment

Every user worked alone and assistance is provided

about the operating system if requested, although, no

assistance is given about WEKA.

5.4 Evaluation Results

According to the volunteers, more than 40% of their

needs are not obvious in UserClassifier module.

Object examination: tasks needed by the end

users are not currently provided by the tool. For

example, only one algorithm and only one

visualisation method are implemented in

UserClassifier module for VDM. The users can not

assess preferred analysis methods or visualisation

tools. It is not possible to access various data set

formats, only the arff format is supported by the

tool.

Support for Actions and Operations: The

users are not oriented (guided), it misses the on line

help, the contextual menus (focus, overview, detail

on demand), the user manual.

Support for Mediation: the elements disposal

on the screen is very good; graphics and colours are

well used but it is not possible to reuse training data

sets. The users’ workload is high for the treatment of

very large data sets. Only one 2D matrix

(representing 2 attributes and the class) can be

displayed at the same time on the screen, it is

impossible to have the overall contextual

information in the data sets in the same visualisation.

It is impossible to obtain the correlations between

the attributes in the data set without a lot of data

explorations.

Development: the system ease of use and ease

of learning is recognised by the evaluators. The most

difficult for the volunteers was to achieve the

construction of the decision tree with very large data

sets and to obtain an appropriate tree.

The results of this evaluation enable the

designers of UserClassifier module to improve the

aspects related to the context of use usability

(assistance modules, user manual, several

alternatives possible with regard to data analysis

methods and data visualisation, cognitive aspects of

visualisation for data mining, user preferences).

6 CONCLUSION

We have proposed an innovative approach: an

activity checklist based on activity theory for context

of use in VDM field. As stated by (Maguire, 2001),

there are several benefits of context of use in

software design: it provides an understanding of the

circumstances in which a product will be used, it

helps to identify user requirements for a product, it

helps address issues associated with product

usability and provides contextual validity of

evaluation findings.

Visual data mining tools are useful and

necessary. In KDD domain, it is innovative and

stimulating to be able to treat data sets with millions

of observations. The available algorithms that aim at

performing this kind of treatments are developed in

laboratories. Generally, the final end users of those

algorithms are not the designers. In our works, we

are interested in all the things which could happen

after passing VDM tools from laboratories context to

a real context of use, in the absence of the tool

designer who is able for example to modify the

program in order to take account of new

functionalities. It is then necessary to develop a set

of standards for the development of these tools, by

taking account of user, task, activity, and context of

use.

REFERENCES

Ankerst M., Elsen C., Ester M., Kriegel H.-P., 1999.

Visual classification: An interactive approach to

decision tree construction. In Proceedings of ACM

SIGKDD International Conference on Knowledge

Discovery and Data Mining, pp.392-396.

Bastien J.M.C., Scapin D.L., Leulier C., 1999. The

ergonomic criteria and the ISO/DIS 9241-10 dialogue

principles: a pilot comparison in an evaluation task. In

Interacting with Computers, vol. 11(3), pp.299-322.

CONTEXT OF USE ANALYSIS - Activity Checklist for Visual Data Mining

Bevan N., Macleod M., 1994. Usability measurement in

context. In Behaviour & Information Technology, vol.

13(1-2), pp.132-145.

Beyer H., Holtzblatt K., 1999. Contextual design. In ACM

interactions, vol. 6(1), pp.32-49.

Blake C., Merz C., 1998. UCI Repository of machine

learning databases, [www.ics.uci.edu/~mlearn/MLRe

pository.html]. Irvine, University of California,

Department of Information and Computer Science.

Cox K.C., Eick S.G., Wills G.J., Brachman R.J., 1997.

Visual Data Mining: Recognizing Telephone Calling

Fraud. In Data Mining and Knowledge Discovery, vol.

1, pp. 225-231.

Deboeck G., Kohonen T., 1998. Visual Explorations in

Finance with self organizing maps, Springer-Verlag.

Dillon A., Morris M., 1966. User acceptance of

information technology: theories and models. In M.

Williams (ed.), Medford, NJ: Information Today, Vol.

31.

Engeström, Y., 1987. Learning by Expanding: An Activity-

Theoretical Approach to Developmental Research.

Helsinki: Orienta-Konsultit Oy, Finland.

Fangseu Badjio E., Poulet F., 2004a. A decision support

system for data miners. In AISTA'04, International

Conference on Advances in Intelligent Systems -

Theory and Applications in cooperation with IEEE.

Fangseu Badjio E., Poulet F., 2004b. Usability of Visual

Data Mining Tools. In ICEIS'04, 6th International

Conference on Enterprise Information Systems, vol.5,

254-258. ICEIS Press.

Fangseu Badjio E., Poulet F., 2005a. Towards usable

visual data mining environments. In HCII’05, 11th

International Conference on Human-Computer

Interaction.

Fangseu Badjio E., Poulet F., 2005b. Visual data mining

tools: quality metrics definition and application. In

ICEIS'05, 7th International Conference on Enterprise

Information Systems, vol. 5, pp.98-103. ICEIS press.

Fayyad U. M., Piatetsky-Shapiro G., Smyth P., 1996. (ed)

Advances in Knowledge Discovery and Data Mining.

AAAI Press / MIT Press, Menlo Park, CA.

Freitas A., Lavington S. H., 1998. Mining Very Large

Databases with Parallel Processing Series,

International Series on Advances in Database Systems,

vol. 9.

Grinstein G. G., Hoffman P., Laskowski S. J., Pickett R.

M., 1997. Benchmark Development for the Evaluation

of Visualization for Data Mining. In Issues in the

Integration of Data Mining and Data Visualization,

Workshop, Newport Beach, California.

Grossman R. L., Yike Guo, 2002. Parallel Methods for

Scaling Data Mining Algorithms to Large Data Sets.

In Handbook on Data Mining and Knowledge

Discovery, Jan M Zytkow, editor, pp.433-442. Oxford

University Press.

Hasan H., 2001. An Overview of Different Techniques for

applying Activity Theory to Information Systems. In

Information Systems and Activity Theory: Theory and

Practice (Ed, Hasan, H.) University of Wollongong

Press.

Inselberg A., 1998. Visual Data Mining with Parallel

Coordinates. In Computational Statistics Vol. 13(1),

pp.47-63.

ISO (International Organization for Standardization),

1998. ISO 13407: Human-Centered Design Process

for Interactive Systems.

Jinyan L., Huiqing L., 2005. Kent Ridge Bio-medical Data

Set Repository. http://sdmc.lit.org.sg/GEDatasets,

accessed the 2nd October 2005.

Kaptelinin V., Nardi B. A., Macaulay C., 1999. The

Activity Checklist: A Tool For Representing the

"Space" of Context. Interactions, Vol.6, pp. 27-39.

Keim D.A., 1996. Pixel-oriented Visualization Techniques

for Exploring Very Large Databases. In Journal of

Computational and Graphical Statistics, vol. 5(1),

pp.58-77.

Kuutti K., 1996. Activity Theory as a Potential

Framework for Human-Computer Interaction

Research. In Nardi, B.A., (1996) (Ed) Context and

Consciousness: Activity Theory and Human-Computer

Interaction. MIT Press.

Leont'ev A. N., 1978. Activity, Consciousness,

Personality. Englewood Cliffs, NJ, Prentice Hall.

Maguire M., 2001. Context of use within usability

activities. In International Journal Human-Computer

Studies vol. 55.

Marghescu D., Rajanen M., Back B., 2004. Evaluating the

Quality of Use of Visual Data-Mining Tools. In

ECITE’04, 11th European Conference on Information

Technology Evaluation, pp. 239-250.

Nardi B., (Ed.), 1996. Context and Consciousness. Activity

Theory and Human Computer Interaction. MIT Press.

Nielsen J., Landauer T. K., 1993. A mathematical model

of the finding of usability problems. In INTERCHI’93,

4th International Conference on Human-Computer

Interaction, pp. 206-213. ACM Press.

Suchman L.A., 1987. Plans and situated actions: The

problem of human-machine communication.

Cambridge University Press.

Whiteside J., Bennett J., Holtzblatt K., 1988. Usability

engineering: our experience and evolution. In M.

Helander, Ed. Handbook of Human Computer

Interaction, pp.791-817. Amsterdam: Elsevier.

Witten I. H., Eibe F., 2000. Data Mining: Practical

machine learning tools with Java implementations.

Morgan Kaufmann, San Francisco.

Wolf C. G., 1989. The role of laboratory experiments in

HCI: help, hindrance or Ho-hum?. In CHI’89, 6

conference on Human Factors in Computing Systems,

pp.265-268. ACM Press.

Yujin C., Qingyuan Z., Jianming W., 2004. Visual Data

Mining Based on Parallel Coordinates and Rough

Sets. In ICITA’04, 2nd International Conference on

Information Technology for Application.

ICEIS 2006 - HUMAN-COMPUTER INTERACTION
