DESIGN OF A MEDICAL DATABASE TRANSFORMATION
ALGORITHM
Karine Abbas
(1)
, Christine Verdier
(2)
, André Flory
(1)
Lyon Research Center for Images and Intelligent Information System
UMR 5205 CNRS/ INSA of Lyon
(1)
, University Claude Bernard Lyon1, University Lumière Lyon 2
(2)
,
Ecole Centrale of Lyon Bat. Nautibus, 43 bld du 11 Novembre 1918, F 69622 Villeurbanne cedex
Keywords: Medical record structure, database reverse engineering, database transformation algorithm.
Abstract: The aim of this article is to create a unique medical record structure from the metabase of any medical
record. The work proposes the design of transformation algorithms which consists in translating the legacy
relational database (RDB) into a unique medical record structure by analysing the correlation between the
legacy RDB keys and the classification of the relations into four types : base relation, dependent relation,
inheritance relation and composite relation.
1 INTRODUCTION
The medical record consists in collecting health
events corresponding to patient’s lifelong. Medical
data are of different types: laboratory test results,
radiology reports, diseases, etc. These data come
from many places: physician practices, hospitals,
nursing facilities, etc. Consequently, for each type
of data and care place, a medical information
system can have its own medical record structure.
Dealing with various record structures requires
much effort and time. Creating a unique medical
record structure becomes a primordial requirement.
In this context, our approach proposes to transform
any medical record towards a unique medical record
structure.
Thus, the aim of our research is the design of a
technique that ensures facility to extract hidden
semantics embedded within database relations and
efficiently to rebuild medical record’s structure.
This paper proposes the design of a medical
database transformation algorithm. This
methodology allows for
- Restructuring the physical schema by using the
data dictionary (métabase).
- Extracting a semantic description in each
relation.
- Analysing of the correlation between primary
keys and foreign keys.
This article is organized as follows. Section 2
presents related works. Section 3 describes the
principle of our reengineering technique by outlining
the database transformation algorithm. Finally,
section 5 concludes with our future work.
2 RELATED WORK
Many database reverse engineering works have been
proposed. (Chiang 1994) proposed an approach
which determines the regular and weak entities,
derives many-to-many and one-to-many
relationships, establishes generalisation hierarchies
and proceeds to the classification of relations,
attributes and their inclusion dependences.
Other works (Anderson 1994), (Petit 1995) based
on query/view analysis have been investigated. These
approaches analyse query language statements.
The method MERCI (Lammari 2001) suggests a
technique in three stages: 1) extract the physical
schema by using the data dictionary 2) design a
conceptual schema in the entity / relation form by
identifying entities, relationships, generalizations,
etc. 3) research hidden semantics embedded within
programs and data.
(Tari 1997) proposes a method which identifies
the relational schema in three categories: base,
dependent and composite relations, and translates
these relations into object-oriented schema by
analyzing the degree of correlation between the keys
of relations and the degree of correlation between the
tuples of the relations.
