Model Quality in the Context of

Model-Driven Development

Ida Solheim and Tor Neple

SINTEF ICT, P.O. Box 124 Blindern, N-0314 Oslo, Norway

Abstract. Model-Driven Development (MDD) poses new quality requirements

to models. This paper presents these requirements by specializing a generic

framework for model quality. Of particular interest are transformability and

maintainability, two main quality criteria for models to be used in MDD. These

two are decomposed into quality criteria that can be measured and evaluated.

Another pertinent discussion item is the positive implication of MDD-related

tools, both on the models in particular and on the success of the MDD process.

1 Introduction

1.1 Characteristics of Model-Driven Development

Model-driven development (MDD) has been around for some years, helping system

engineers to analyze and document the systems to be created and maintained, and to

generate parts of the program code automatically. In MDD, models are the prime

artefacts. That means, models are in use throughout the whole production chain, from

the early capture of user requirements to the production of executable code. Model

transformations are essential, and these should preferably be automated. Indeed, tool

support is by many considered a prerequisite for successful MDD (e.g. [1]).

Although MDD has been practiced for years, it did not gain ground until the Object

Management Group (OMG) launched its Model-Driven Architecture (MDA™)

initiative. Being “an approach to using models in software development” [2], MDA

has boosted the development of tools and thereby (semi)automation of program

development and maintenance. MDA motivates system development with the

following characteristics:

• Many activities have models as input, or output, or both.

• Several of these activities are model transformations (while others are model

analysis, model verification etc.).

• A transformation takes one or several models as input and produces a model (or

models), or text, as output. During transformation, output models are supplied with

domain-related information not present in the input model. An example of such a

domain is the platform concept, often used for “implementation platform”.

Solheim I. and Neple T. (2006).

Model Quality in the Context of Model-Driven Development.

In Proceedings of the 2nd International Workshop on Model-Driven Enterprise Information Systems, pages 27-35

DOI: 10.5220/0002486100270035

 SciTePress

1.2 Model Quality – A Less Mentioned Concern

The authors of this paper believe that successful adoption of MDD depends on high-

quality models, high-quality transformations, and high-quality transformation

languages and tools.

While other authors have contributed to the understanding of quality related to

transformations (e.g. [3]) and transformation languages (e.g. [4]), the quality of

models in MDD has so far been a less mentioned concern.

According to Selic [5], accuracy has been the greatest problem for successful

adoption of MDD. Lack of accuracy means imprecise models or modelling languages,

paired with unclear rules for mapping to underlying implementation technologies.

The authors of this paper agree that Selic has a good point. However, in [5] the

term accuracy is used for a collection of several undefined quality criteria. The

purpose of this paper is to define more precise quality criteria for models to be used in

MDD, and suggest how these criteria may be measured and evaluated.

1.3 The Structure of this Paper

The starting point for this work is a generic quality framework (chapter 2), which is

specialized to a quality framework for MDD models and their environments (chapter

3). The implications of tools are discussed in chapter 4, and a conclusive summary is

given in chapter 5.

2 A Generic Quality Framework

Krogstie and Sølvberg [6] presents a generic framework for discussing the quality of

models. This framework will be used as a reference frame for discussing model

quality in an MDD context, and will be refined for this purpose. Figure 1 depicts the

framework’s building blocks and their interrelationships, as described by Krogstie [7].

The explanation of the building blocks is rendered from [7] (mostly quoted):

• G, the (normally organizationally motivated) goals of the modelling task

• L, the language extension, i.e., the set of all statements that are possible to make

according to the graphemes, vocabulary, and syntax of the modelling languages

used

• M, the externalized model, i.e., the set of all statements in someone’s model of part

of the perceived reality written in a language

Empirical

quality

Social

quality

Physical

quality

Social

pragmatic

quality

Semantic

quality

Syntactic

quality

Technical

pragmatic

quality

Model

externalization

Social

actor

interpretation

Technical

actor

interpretation

Modeling

domain

Language

extension

Modeller

explicit

knowledge

Perceived

semantic

quality

Social actor

explicit

knowledge

Goals of

modelling

Organizational

quality

Fig. 1. Krogstie’s generic framework for discussing the quality of models (rendered by courtesy

of the author).

• D, the domain, i.e., the set of all statements which can be stated about the situation

at hand. Enterprise domains are socially constructed, and are more or less inter-

subjectively agreed. That the world is socially constructed does not make it any

less important to model that world.

• K

, the relevant explicit knowledge of the set of stakeholders involved in modelling

• K

, the relevant explicit knowledge of the set of stakeholders actively involved in

modelling

• I, the social actor interpretation, i.e., the set of all statements which the audience

think that an externalized model consists of

• T, the technical actor interpretation, i.e., the statements in the model as 'interpreted'

by different model activators (e.g., modelling tools, transformation tools)

The various qualities are expressed as relations between pairs of these building

blocks. The next chapter elaborates on model quality aspects related to MDD, refining

the above framework accordingly.

3 Quality Criteria for MDD Models and their Environments

3.1 Overview

A quality framework specialized with respect to MDD is depicted in Figure 2. The

authors of this paper want to emphasize transformability and maintainability as the

two main quality criteria for models to be used in MDD. Models must have the ability

to be transformed – to other models of greater detail (specialization), and at last to

executable pieces of code for selected technical platforms. Transformability may be

decomposed into:

• completeness (semantic quality)

• relevance (technical pragmatic quality)

• precision (technical pragmatic quality)

• well-formedness (syntactic quality)

Also, models for use in MDD need to be maintained during the system’s lifetime. One

of MDD’s strengths is rapid iterations of the development cycle analysis—design—

implementation—test, a feature that supports incremental development strategies.

Given this setting, it is of paramount importance that changes made to the

requirements are rendered correctly in the models and reflected in the code. A means

to keep track of changes is to trace them, from the requirements through the necessary

steps all the way to the code, and back. Therefore, maintainability of models may be

decomposed into:

• traceability (technical pragmatic quality)

• well-designedness (syntactic quality)

Out of the six quality criteria listed above, only one (completeness) is explicitly

mentioned in Krogstie and Sølvberg [6]. The remaining five may be considered

refinements of generic relations shown in Fig. 1. The transformability and

maintainability criteria are explained in the following subsections.

The environments of MDD models are here defined to be the change traces, the

tools, and the MDD process itself. The change traces and the tools belong to the

technical pragmatic quality.

Goals of

modelling

Goals of

modelling

Externalized

model

Technical

actor

interpretation

Technical

actor

interpretation

Modelling

domain

Modelling

domain

Language

extension

Language

extension

Organizational quality:

• productivity

Semantic quality:

• completeness

Syntactic quality:

• well-formedness

•well-designedness

Technical

pragmatic quality:

• relevance

• precision

• traceability

Fig. 2. A specialized framework for model quality in MDD.

Concerning the MDD process as such, we may identify a primary goal of achieving

higher productivity in the development process. Hence,

• productivity (organizational quality)

may be considered a quality criterion. In accordance with [6], this is in Fig. 2

expressed as a relation between the goals of modelling (G) and the externalized model

(M). However, for MDD, productivity should rather appear as a quality of M, L, T

and D in combination. Productivity is hard to measure, and results cannot easily be

generalized. The MODELWARE project [8] of the EU IST programme aims at

measuring the productivity of MDD in industrial trials, based on approaches

described in [9].

3.2 Transformability

Completeness is pointed out by Krogstie and Sølvberg [6] as an essential for the

semantic quality of models. Completeness assures that the model contains all

statements that are correct and relevant about the domain, and can be measured by a

percentage as prescribed in [6].

Whereas Krogstie and Sølvberg [op. cit.] consider relevance to be a property of

completeness, the authors of this paper would like to emphasize relevance as a

distinct quality criterion. However, the relevance of a model used in MDD depends on

both the model itself (M) and its transformation as specified by the technical actor

interpretation (T). High relevance means that no more statements are included in the

model than those which are going to be transformed. Relevance can be measured as

the percentage of model elements actually used in a particular transformation. Making

a larger model than necessary has a negative consequence in MDD; one has to drag

along unused model elements (or code), which may complicate documentation, blur

comprehension and hamper maintenance.

Precision reflects the level of detail and accuracy required for a model to be

transformed successfully. The result of the transformation may be another model,

which in case must be well-formed. Or, the result may be program code which can be

compiled without errors and which constitutes some meaningful result, e.g. a

component, a class structure or an interface. It may be possible to measure precision

on a scale (ordinal or interval). However, these authors prefer to evaluate model

precision as yes/no. This means, either the model is sufficiently precise for

transformation, or it is not.

Well-formedness is a syntactic quality of utmost importance to model

transformation. According to OMG [2], a transformation from one model to another is

dependent on a mapping between the two respective metamodels. Hence, any model

to be transformed must comply with its metamodel. For example, a model written in

UML must comply with UML’s metamodel. Also, there may exist sub-languages with

limitations on the vocabulary and/or grammar rules of the overall language. Examples

of such sub-languages are UML profiles. A well-formed model complies not only to

its metamodel, but also to its sub-language (profile) if appropriate. A measure of well-

formedness should yield 100 % before transformation is started.

3.3 Maintainability

3.3.1 Traceability

Traceability has been pointed out as an important aspect of MDD. One of the

purposes of maintaining traces between model elements is to check a model element’s

origin, e.g. in a requirement model, and to follow a model element through

transformations. In the latter case, the trace can also tell what kind of transformation

was used, and which transformation rule was applied. Albeit traceability doubtlessly

may involve more than one model, and indeed may involve artefacts other than

models, this section discusses traceability as a quality of a model. This means, to what

degree the model is usable in a scenario where traceability is needed.

Traceability may be vital for the management of large MDD projects, and for the

maintenance of systems built according to MDD. Tool-supported traceability may

range from “enterprise-wide” traceability solutions to simple traces maintained by the

modelling workbench. A model’s traceability depends on unique identifiers for the

different elements that constitute the model; otherwise no traces can be established.

Unique identifiers are supported by some modelling tools, but not all. In addition to

the identification of model elements, one will need a mechanism that logs and

documents all transitions undergone by each model element. Such a mechanism is

currently under development in the IST project MODELWARE [8].

A traceability metric for a model could be the model’s trace coverage, defined as a

percentage denoting the proportion of traceable model elements relative to the total

number of model elements.

3.3.2 Well-designedness

The maintainability of object-oriented systems has been studied by several authors,

e.g. Briand [10]. The main approach has been various combinations of measurements,

obtained by counting properties of object-oriented structures found in class diagrams.

Marinescu [11] introduced a quality model for object-oriented systems, applying well-

known metrics for the purpose of revealing particular design flaws. Among the design

flaws that can be revealed by his method, are flaws resulting from not using selected

design patterns described by Gamma et al. [12].

Well-designed models are understandable and tidy. In MDD, well-designedness

deserves much attention because the models are the prime artefacts. Maintenance

should preferably start with the models resulting from the last development cycle. If

changes are made directly to the generated code, they should be reflected in the

models as soon as possible to ensure the correspondence between the models and the

code. Bad model design may complicate the code, confuse the developers, ruin the

model-code correspondence and impede the use of MDD.

4 The Implications of Tools

In MDD, tools are used to create models, to transform one model into another, to

generate non-model software artefacts, to maintain traces, etc. In such a setting, the

human model-creation steps can be heavily guided by the tools. This means that

several quality parameters can be kept at sufficient levels through guides and

constraints in the tooling. It is also probable that the modeller will put most work into

those models that will be subject to usage further down the MDD transformation

chain.

A modelling tool will typically not allow a model to violate its metamodel. At

least, the model will be compliant with the tool’s interpretation of the metamodel.

This is a feature that has been observed in UML tools in the past, when tool vendors

have added capabilities not compliant to the UML metamodel as defined by the

standard. Such extensions may cause problems in an MDD tool chain if a common

non-standard metamodel, shared between the tools, is required.

A positive feature of some UML modelling tools is a mechanism allowing the user

to check whether a model is compliant with the applied profile. In MDD, this is

essential as most UML model transformations use stereotypes and extra properties in

the transformation process. While the profile provides explicit language constraints,

the tool enforces these constraints on the models. The quality of tool support for

profile adherence is thus shared between the profile itself (how explicit are the

constraints) and the tool (how well are these constraints enforced). In these cases, the

quality of the model at hand is therefore a combination of the quality of the model and

the quality of the applied profile.

Modelling tools can also help ensure that the structure (e.g. package organisation) of a

model is in accordance with the expectations of the down-chain tools. This is

typically done by the use of model templates or more formally defined constraints on

the model structure.

5 Conclusion

Models have been used for years without direct influence on system implementation.

However, the adoption of MDD forces system developers to spend more effort on

making high-quality models. This paper has presented a framework for reasoning

about model quality in the context of MDD. Since (automatic) model transformation

is a crucial activity in MDD, several quality measures depend on both the model and

the transformation (or transformation tool). Such dependency is indicated by the

association line between M and T in Fig. 2. Although measures may be obtained on

an ordinal or ratio scale, some quality criteria need to reach a sufficiently high level –

a threshold – in order for transformations to succeed. The table below gives a

summary of the quality criteria and suggestions of how to measure and evaluate them.

Quality

Criterion

Type of

Quality

Explanation

Transformability

Completenes

semantic

The model contains all statements that are correct and

relevant about the domain (from [6]). Suggested

measurement unit: percentage.

Well-

formedness

syntactic

The model complies with its metamodel, and also with its

specified language profile, if appropriate. Suggested

measurement unit: percentage.

Suggested evaluation: yes/no.

Precision

technical

pragmatic

The model is sufficiently accurate and detailed for a

particular automatic transformation.

Suggested evaluation: yes/no.

Relevance

technical

pragmatic

The model contains only the statements necessary for a

particular transformation. Suggested measurement unit:

percentage.

Maintainability

Traceability

technical

pragmatic

The model’s elements can be traced backward to their

origin (requirements), and forward to their result (another

model or program code). Suggested metric: trace

coverage, the proportion of traceable model elements

relative to the total number of model elements.

Well-

designedness

syntactic

The model has a tidy design, making it understandable by

humans and transformable to an understandable and tidy

result. Suggested metric: The quality model of Marinescu

[11], preferably extended with other diagrams than class

diagrams.

The use of tools in MDD serves several purposes. In addition to facilitating the

drawing, maintenance and transformation of models, tools also have some built-in

quality controls. It is desirable that the quality controls performed by tools are

extended to support as many as possible of the quality criteria listed above.

Future work will apply the presented quality framework to models used in MDD

projects within industry or public administration. Such trials are expected to give

valuable feedback to the appropriateness and further refinement of the framework.

Acknowledgements

This work has been conducted in the context of MODELWARE, a project co-funded

by the European Commission under the "Information Society Technologies" Sixth

Framework Programme (2002-2006). Information included in this document reflects

only the author’s views. The European Community is not liable for any use that may

be made of the information contained therein.

References

1. Alanen, M., et al.: Model Driven Engineering: A Position Paper. 1st International

Workshop on Model-Based Methodologies for Pervasive and Embedded Software,

MOMPES'04 (2004)

2. Object Management Group: MDA Guide. Ver. 1.0.1. http://www.omg.org/docs/omg/03-06-

01.pdf (2003).

3. Bézivin, J., et al.: The ATL Transformation-based Model Management Framework. IRIN,

Université de Nantes (2003)

4. Grønmo, R., et al.: Evaluation of the Proposed QVTMerge Language for Model

Transformations. The First International Workshop on Model-Driven Enterprise

Information Systems (MDEIS-2005). Miami (2005)

5. Selic, B., The Pragmatics of Model-Driven Development. In: IEEE Software,

September/October 2003, http://computer.org/software

6. Krogstie, J. and Sølvberg, A.: Information systems engineering - Conceptual modeling in a

quality perspective. Kompendiumforlaget. Trondheim, Norway (2003)

7. Krogstie, J. (2003). Evaluating UML Using a Generic Quality Framework. In: Favre, L.

(ed.): UML and the Unified Process. IRM Press 1-22.

8. IST Project 511731 (2004-2006). MODELWARE. Modeling solution for software systems,

http://www.modelware-ist.org/.

9. MODELWARE: MDD Business Metrics (in prep.). Sixth Framework programme (2006)

10. Briand, L., Daly, J., and Wüst, J.: A Unified Framework for Coupling Measurement in

Object-Oriented Systems. In: IEEE Transactions on Software Engineering, Vol. 25(1), No.

January/February, 1999

11. Marinescu, R.: Measurement and Quality in Object-Oriented Design. University of

Timisoara (2002)

12. Gamma, R., et al.: Design Patterns: Elements of Reusable Object-Oriented Software.

Addison-Wesley (1994)
