Architectural Handling of Management Concerns in

Service-Driven Business Processes

Ahmed Al-Ghamdi and José Luiz Fiadeiro

Department of Computer Science, University of Leicester

Leicester LE1 7RH, United Kingdom

Abstract. To be effective and meet organisational goals, service-driven appli-

cations require a clear specification of the management concerns that establish

business level agreements among the parties involved in given business proc-

esses. In this paper, we show how such concerns can be modelled explicitly

and separately from other concerns through a set of new semantic primitives

that we call management laws. These primitives support a methodological ap-

proach that consists in extracting management concerns from business rules and

representing them explicitly as connectors in the conceptual architecture of the

application.

1 Introduction

Service-driven business processes have become one of the topical innovations

through which organisations hope to cope with ever-changing business requirements.

The shift that this new trend represents over typical product-oriented business models

is characterised, among other, by much more flexible, loosely-coupled interactions

that sustain high-levels of agility and adaptability to change.

From a technological point of view, the response to the challenges raised by such

models is relying on the pervasiveness of Internet technologies, namely on Web-

services. These are platform-independent components with explicit interfaces tai-

lored to the Web that can be used in combination with others to form large-scale,

evolvable business applications. Because the ultimate objective of the service-driven

economy is to match customer requests in-time and with optimal services, either ele-

mentary or composed from simpler ones, it becomes clear why the notion of quality

of service (QoS) plays a central role in this new paradigm [1]. It is not surprising that

the notion of Service Level Agreement (SLA) has been placed at the heart of such

Web technologies [2, 3]. Notions of quality addressed by these efforts include avail-

ability, accessibility, accuracy, throughput, and reputation, among others.

However, from the wider point of view of the organisations that adopt such ser-

vices to promote their businesses, there are levels of quality that are more global and

abstract than those that relate to the IT-platform that supports the software applica-

tions, which need to be ensured and to which service-driven business processes have

to contribute. Business SLAs refer to agreements on how specific services are offered

to their customers. They concern, primarily, the business semantics of such services,

Al-Ghamdi A. and Luiz Fiadeiro J. (2006).

Architectural Handling of Management Concerns in Service-Driven Business Processes.

In Proceedings of the 4th International Workshop on Modelling, Simulation, Veriﬁcation and Validation of Enterprise Information Systems, pages

111-120

DOI: 10.5220/0002500701110120

 SciTePress

which cannot be captured through system or application level metrics; they concern

business rules that deal with the way inter-enterprise services and their customers can

be managed in an optimal way.

Most frameworks addressing QoS and SLAs remain at the infrastructural level

provided by proposed IT platforms: an example is SLAng [4], an XML-language

defined over the UML for addressing a number of performance/resource-related qual-

ity metrics. Instead, business-level notions of quality need to be addressed at a

higher-level of abstraction in which they can be formulated independently of any IT

platform. This is essential to enable the participation of the wider community of

partners in the organisation, or across different organisations, that are concerned with

business quality factors (e.g. users, managers, designers, marketers), not just the pro-

grammers [5].

In this paper, we take one step in the direction of enabling business concerns to be

represented explicitly in the conceptual models of service-oriented applications. We

put forward a set of semantic primitives that extend the CCC-architectural approach

proposed in [6] with connectors that capture the management aspects of the applica-

ble business rules. More precisely, CCC focuses on architectural connectors that

coordinate the interactions between business partners that ensure that given business

procedures are followed and policies upheld; we introduce a different kind of connec-

tor through which we can superpose the concerns that relate to the way these interac-

tions ensure required levels of management quality such as deadlines, handling and

financial aspects of business transactions.

Having this in mind, the paper is structured as follows. The next section presents

a running example previously used in literature – selling PCs [7]. The third section

recalls how interaction concerns are modelled in [6, 8] using coordination laws. In

section 4, we start by showing how management concerns can be approached at the

business level and in terms of business rules. Then, we put forward new architectural

concepts to extract management concerns directly from business rules. We close by

discussing the additional research steps that we are taking for addressing Business

SLAs.

2 The Case Study

Our case study deals with a service-driven business process for selling PCs “online”

(PcSelling). We distinguish four categories of services involved in this process: cus-

tomer, provider, shipment, and banking services.

– Customer services (CS) provide PcSelling with front-end interactions with customers.

That is, CS allow customers to post their requests to buy PCs, to pay their dues, and to can-

cel/accept offers.

– Provider services (PS) are used for returning offers to customers that place requests. They

also control delivery and provide key functions for dealing with refunds and penalties.

– Shipment services (SS) are used when there is a need for shipping the goods, allowing the

shipment method to be selected.

– Banking services (BS) accomplish any required payment procedures, including shipment

and any necessary insurance costs.

112

In a typical scenario, when a provider service receives requests for buying PCs

from a customer service, it checks for availability and for customer insurance. At the

same time, the customer service checks quality-level requirements such as delivery

time and payment options. When the different requirements of both parties are

agreed upon, an offer is made by the provider service to the customer service.

The business activities involved take the form:

– Request: This is the first step in the process during which the customer requests a given

number of PCs.

– Offer: This activity consists of an offer made from the provider in reply to the customer’s

request, including details related to management levels such as delivery time and costs.

– Delivery: It notifies the provider to start delivering the goods according to agreed business

levels of quality.

– Cancellation: This business activity may follow if the customer wants to cancel the order

or just part of it. Penalties may apply.

– Shipment: This activity is launched when customer’s location requires shipment instead of

collection.

– Payment: This activity handles cost-related transactions such as direct payments, refunds,

and penalties.

3 Rule-Based Modelling

In order to reach the higher-levels of abstraction required for modelling business

processes, interest has grown in adopting business rule-driven approaches[9]. These

are understood as “projections of organisations’ constraints and declarations of (in-

ternal/external) policy/conditions that must be satisfied for doing business”. They

specify actions to be taken in the event of particular events, including “state of being”

changes concerning individuals, infrastructure, consumables, informational resources

and business activities in general.

Rule-driven approaches offer a number of advantages that are crucial for coping

with dynamically evolving complex business processes. They support the specifica-

tion of business models independently of the specific processes that happen to be

running at any one time. They focus on primary requirements and address business

domain descriptions in a declarative rather than an operational way. Applications of

rule-driven approaches to web-services composition have also been proposed [10]

and [11] but, as far as we know, without including the management aspects that con-

cern us in this paper.

Our architectural approach is also rule-based but takes the separation between

business rules and activity flow one step further: it separates the concerns that relate

to the way interactions among business entities need to be coordinated to fulfil given

business goals from the management concerns that reflect business quality level

agreements. The remaining sections detail the way we model each concern separately

and how they can be brought together to provide an integrated model of a business

process.

113

4 Coordination Concerns

Semantic modelling primitives have been put forward in [6, 8] that rely or architec-

tural connectors for separating the coordination of interactions between business

entities from the computations that entities perform to ensure required services. More

precisely, so-called coordination laws and contracts externalize as first-class entities

any intra- or cross-organisational interactions between business components. This

clean separation permits changes to business rules to be performed at the level that is

required without affecting the other aspects.

– Coordination Laws capture the way business rules require given classes of business enti-

ties (partners) to interact. The law identifies the roles played by these partners through ge-

neric "coordination interfaces". The way interactions between partners are coordinated ac-

cording to the business rule is captured in the form of event-condition-action (ECA) rules.

– Coordination Interfaces identify what are normally understood as the roles of a connec-

tor. They consist of the sets of services, events and invariants that have to be provided by

business entities to become coordinated as described by the rules of the law.

As an example, consider the coordination aspects involved in the request activity:

the provider has to check for the availability of the quantity and type of the requested

PCs to decide whether to accept or reject the request. The business rule that applies

may be informally described as follows:

1. The customer asks for a specific number of particular types of PCs.

2. After checking the availability and types, the provider is entitled to accept or reject the

request.

3. By accepting the request the provider designates the request as pending by assigning it a

reference and notifies the customer in consequence.

4. By rejecting the request, the provider cancels the request and notifies the customer.

A formalisation of this business rule in terms of coordination laws requires the fol-

lowing interfaces:

coordination interface CustReqCI

partner type CUSTOMER

import type Item,Request

events request(i:Item,Qt:nat)

services cancelled(), accepted(r:Request)

coordination interface ProvReqCI

partner type PROVIDER

import type Item, Request

services

makePending(i:Item,Qt:nat,Rq:Request)

typePrv(i:Item):bool

availQt(i:Item):nat

The coordination interface CustReqCI captures the behaviour required of a cus-

tomer so that it can interact with a provider, namely it produces the event request with

parameters i for the kind of PCs that are requested and Qt for the quantity requested.

In the coordination interface ProReqCI, we require the operations that a provider

needs for interacting with the customer: (1) make a request pending – makePend-

ing(i,Qt); (2) cancel a request – cancelRequest(i,Qt); (3) the kinds of PCs offered by

the provider – typePrv(i); and the quantity of PCs currently available for a given kind

–availQt(i).

114

The coordination law that regulates the interaction between customer and provider

during the request activity is described as follows.

coordination law RequestCL

partners Ct:CustReqCI; Pr:ProvReqCI

import type Item, Request

attribute ReqNo:Request

when Ct.request(i,Qt) do

if Pr.availQt(i)≥Qt and Pr.typePrv(i)

then Pr.makePending(i,Qt)

and Ct.accepted(ReqNo)

else Ct.cancelled()

Accordingly, when the customer places a request, the provider checks for avail-

ability of type and quantity; if available, it assigns the request a number, notifies the

customer and makes it pending; otherwise, it notifies the customer that the request

cannot go through. More details about coordination laws, how they are instantiated

and implemented following the CCC-architecture, can be found in [6, 8].

5 Management Concerns

In this section, we address business management concerns that arise between custom-

ers and providers at an abstract, domain level, such as business response/delivery

time, costs and credibility of business partners.

We propose to describe such management concerns in terms of specific business

rules dealing with how inter-enterprise activities are adequately managed. In this

way, management concerns can be evolved and improved at the business level in

conjunction with the relevant stakeholders. This is why we decided to build on the

CCC-approach by proposing an additional architectural dimension in which the main

characteristics of business management concerns can be identified, specified and

analysed as first-class entities.

By investigating several process-aware applications and business processes, we

have come up with the following characteristics, which we argue will lead to better

management of business processes. We do not claim that these characteristics are

complete or exhaustive; more investigation on extensions and refinements is still

going on.

– Customer and provider preferences and degrees of trust are at the heart of service-

based business processes. To satisfy customer, preferences have to be carefully addressed.

In our case study, when requesting PCs the customer may choose some PC providers over

others depending on a number of factors. In addition, the preferences of the provider also

have to be considered.

– Timing issues are also essential elements when it comes to satisfying both the customer

and the provider. One should not confuse business-time issues with system performance-

related ones. The latter have been extensively considered in different approaches [5,

12]but do not address the higher business level agreements. In the case study, the customer,

when requesting goods, has the right to set a time limit for a reply, as well as a time limit

for accepting delivery of the goods. On the other hand, the provider also has the right to set

time requirements such as the duration of the validity of any offer, or the time for shipment

in relation to the delivery time agreed upon with the customer.

115

– History of the state of activities is essential for dealing with management issues while

modelling complex business activities. The aim here is to set appropriate formulae and

primitives at the business level, so that appropriate management strategies can be built. In

our case study, for instance, the formulas which are of most interest include how many re-

quests or offers have been accepted, rejected or ignored; delivery or payment delays, etc.

In the example, when a customer requests a batch of PCs, he/she may first prefer

specific providers over others, possibly depending on previous experience with them

or simply because he prefers their products. Secondly, to obtain a quicker response,

the customer may set a desired response time to be respected by the provider. From

the provider’s side, he has to consider his response time limit, which has to be smaller

than the requested reply time. The day and the time at which the request is ‘posted’

by the customer may also play an important role. For instance, dealing with any

request during the weekend or outside normal working hours is more expensive. The

extracted business rule may then be expressed as follows:

1. The customer asks for a specific number of particular types of PC.

2. The customer has the right to opt for a preferred provider and this may depend on the his-

tory of similar operations.

3. The customer also specifies the response time to be respected, which implies that the day

and the time of the request are to be included.

4. When the customer’s requirements have been fulfilled, the request is considered to be in a

managed state.

5. When the conditions are not met, the request is added to the history for assessment in pos-

sible future transactions.

Such concerns represent a sort of management-driven contracts between different

business partners such as customers, providers, and suppliers. This suggests that

architectural techniques similar to coordination laws and contracts should be investi-

gated to provide mechanisms for specifying business management concerns. More

precisely, we propose to specify such concerns as architectural connectors called

management laws.

6 Management Laws

As for coordination laws, management laws require interfaces through which one can

identify the features (operations and events) that partners are required to provide to

engage in a given business activity. A data type is also associated with every man-

agement interface to identify the class of instances. With respect to a given business

activity, the behaviour governing corresponding management concerns is also mod-

elled using ECA-like rules albeit extended with new management primitives that

capture the aspects discussed in the previous section. The general form of a man-

agement law is as follows:

management law < law-name>

partners <variables typed with

management interfaces>

rule <rule-name >

when <trigger>

who <conditions on partner preferences and operation histo-

ries>

116

at-time <conditions on time issues>

manage <set of operations>

after <set of operations

Under the clauses when, who and at-time we specify the event triggering the con-

cerned business activity, the related management constraints and conditions express-

ing partners preferences, and the degree of trust using the history of previous opera-

tions if necessary. Under the clause manage we specify all management actions to be

undertaken. Finally, when the triggering event happens but some constraints under

who and/or at-time do not hold, the actions identified under after are performed.

With respect to the request business activity, two interfaces are again required,

one for the customer and the other for the provider.

management interface MaCuReMI

partner type CUSTOMER

import type Item, Request

events request(i:Item,Qt:nat)

operations

TmRep(): Time

RqHrs(): Time

RqDay(): Day

PreferListPrv():(ProviderNames)

HistPrv(): List(Operations)

This management interface identifies an event – request(i,Qt) – that will be used

as a trigger in a law (see below). The customer has also to opt for a list of preferred

provider names, captured through the operation PreferListPrv(). Additional require-

ments include the response, TmRep(), which the customer imposes on the provider

within which he is expected to reply. The days and hours of the request order are also

of interest, and captured respectively through RqDay() and OrdHrs(). Finally, be-

cause the history of different operations may also be relevant to the customer this is

considered through the operation HistPrv().

management interface MaPrReMI

partner type PROVIDER

import type Item, Request

operations

NamePrv():Name

TmRepLm():Time

DeliverTm():Time

WrkDays():List(Days)

WrkHrs():interval(Time)

ManageRequest()

This interface requires a number of operations from the provider: name –

NamePrv(), and current availability in terms of time for reply – TmRepLm(). Further

operations are required as to inform the customer of possible time for delivering the

goods, denoted by DeliverTm(), and of the working days and hours, denoted respec-

tively by WrkDays() and WrkHrs(). Finally, there should be an operation for telling

the provider that the management for the activity can proceed – ManageRequest().

A business activity, as expressed in terms of management laws, should initially

adhere to the informal meaning of corresponding business rules, and to the manage-

ment characteristics we identified.

management law RequestML

partners MgCt:MaCuReMI; MgPr:MaPrReMI

attribute Tflexple:Time

117

when MgCt.Request(i,Qt)

who MgPr.NamePrv()in

MgCt.PreferListPrv()

at-time MgCt.TmRsp()+MgCt.Tflexple()

≤MgPr.TmRepLm()

and MgCt.OrdHrs()in MgPr.WrkHrs()

and MgCt.RqDay() in MgPr.WrkDays()

manage MgPr.ManageRequest()

after MgCt.Add(HistPrv,Cancel)

As for the coordination law, the management process is triggered by a request

from the customer as specified by the when clause. The condition part, as already

mentioned, is split into two parts:

– The time part, under the clause at-time, specifies any conditions reporting on timing

issues. The request activity allows us to check that the time for reply requested by the cus-

tomer is not beyond the ability of the provider. Nevertheless, in order to provide flexibility,

there must be an allowance for assessing any specific time lapses denoted by Tflexple. The

day and hour of the customer request should also come within the normal working days

and hours of the provider as stated in this management law.

– The preference and history part is specified under the clause who. As the name suggests,

this conditional part concerns any condition regarding the preferences of the customer or

the provider, as well as giving a history of operations in the business activity concerned.

For the request activity, it is necessary only to check that the name of the provider is

among the providers in the customer-preferred list.

The management actions to perform are declared under the clause manage. In the

case of the request activity, the only action that has to be performed consists of in-

forming the customer and provider “partners” that the request activity has fulfilled all

the requirements from the management perspective.

Finally, the clause after specifies the actions that need to be undertaken when there is

a failure to fulfil all the requirements (whether this is to do with timing, or preference,

or history). In the example, it adds the cancellation to the customer’s history.

7 Integration of Concerns

Being able to model these two concerns separately, with all emphasized benefits, does

not mean that they are independent. The way a business activity is performed within a

process emerges from the coordination and management laws that jointly apply to

that activity. For instance, at runtime, the way a request is processed is captured not

by independent coordination and management partners: both coordination and man-

agement interfaces are instantiated by the same business entities. That is, the request

is executed by a (run-time) customer service that is an instance of both CustReqCI

and MaCuReMI. In other words, both coordination and management interfaces are

instantiated by the same run-time services or components; instantiating coordination

and management laws means binding the coordination and management interfaces to

services that are running on the current system configuration.

In this example, the event that triggers the request business activity is re-

quest(i,Qt) in both the coordination and management interfaces instantiated by the

customer service. The joint execution of the corresponding coordination and man-

118

agement rules reflects the conjunction of the conditions and the parallel composition

of the actions:

when CS.Request(i,Qt) do

if PS.AvailQt(i)≥Qt

and PS.TypePrv(i)

and CS.TmRsp()+CS.Tflexple ≤PS.TmRepLm()

and CS.OrdHrs()inPS.WrkHrs()

and CS.RqDay()inPS.WrkDays()

and PS.NamePrv()in

CS.PreferListPrv.list()

then PS.PendingRequest(i,Qt)

and PS.ManageRequest

else PS.CancelRequest(i,Qt)

and CS.Add(HistPrv,Cancel())

That is to say, the request activity is performed according to both coordination and

management rules, which share the same trigger – CS.request(i,Qt) where CS is the

run-time customer service.

8 Concluding Remarks

With the growing scale and complexity of service-driven applications and business

processes, a methodology is required that allows the concerns mentioned above to be

handled separately and at an early stage when considering business requirements.

Moreover, rigorous approaches are needed for modelling such concerns at higher

levels of abstraction.

Towards this end, we proposed an approach based on architectural techniques and

separation of concerns that builds on previous work on Software Architecture [6, 8].

In this approach, interaction and management concerns are separately modelled, vali-

dated and evolved as architectural connectors. To reflect the semantics of business

activities, both concerns are then integrated.

Our immediate plans are to enhance and consolidate the approach with more case

studies. The modelling of the whole business processes will also be tackled. For this

purpose, different ways of adopting and extending UML-activity diagrams will be

investigated. Finally, we are developing an explicit mapping of our business-level

architectural approach to web-service management over service-oriented architectures

[2, 3].

Acknowledgments

We would like to thank our colleagues Luís Andrade and Georgios Koutsoukos from

ATX Software for many useful remarks. This work was partially supported through

the IST-2005-16004 Integrated Project SENSORIA: Software Engineering for Ser-

vice-Oriented Overlay Computers.

119

References

1. Andrieux, A., Czajkowski, K., Dan, A., Keahey, K., Ludwig, H., Pruyne, J., Rofrano, J.,

Tuecke, S., and Xu, M. (2004) "Web Services Agreement Specification (WS-Agreement)",

Draft, Global Grid Forum.

2. Casati F., Shan E., Dayal U. and Shan M. C. (2003) ''Business-Oriented Management of

Web Services'', Communications ACM, 46, pp. 55-61.

3. Benatallah B., Casati F., Toumani F. and Hamadi R. (2003) ''Conceptual Modeling of Web

Service Conversations'', LNCS, 2681, pp. 449-467.

4. Skene J., Lamanna, D. and Emmerich W. (2004) ''Precise Service Level Agreements'', in

International Conference on Software Engineering, 26, IEEE Computer Society: ICSE

2004, pp. 179-188.

5. Castellanos M., Casati F., Dayal U. and Shan M. C. (2003) ''Intelligent Management of

SLAs for Composite Web Services'', LNCS, 2822, pp. 158-171.

6. Andrade L. F. and Fiadeiro J. L. (2003) ''Service-Oriented Business and System Specifica-

tion: beyond object-orientation'', in Kilov H. and Baclwaski K.(eds), Practical Foundations

of Business and System Specifications, Kluwer Academic Publishers, pp. 1-23.

7. Sahai A., Machiraju V., Sayal M., Moorsel A. v. and Casati, F. (2002) ''Automated SLA

Monitoring for Web Services'', LNCS, 2506, pp. 28-41.

8. Andrade L. F. and Fiadeiro J. L. (2001) ''Coordination Technologies for Managing Infor-

mation System Evolution'', in Advanced Information Systems Engineering, LNCS, 2068,

pp. 374-387.

9. Kardasis P. and Loucopoulos P. (2004) ''Expressing and Organising Business Rules'', In-

formation and Software Technology, 46, pp. 701-718.

10. Orriens B., Yang J. and Papazoglou M. P. (2003) ''A Framework for Business Rule Driven

Service Composition'', LNCS, 2819, pp. 14-27.

11. Charfi, A. and Mezini, M. (2004) "Hybrid web service composition: business processes

meet business rules", in International Conference on Service Oriented Computing ICSOC

'04, ACM Press, pp. 30-38

12. Keller A. and Ludwig H. (2002) ''Defining and Monitoring Service Level Agreements for

Dynamic e-Business'', in Systems Administration Conference 16, pp. 189-204.

120
