PATTERN-ORIENTED ARCHITECTURE FOR WEB

APPLICATIONS

M. Taleb, A. Seffah

Human-Centred Software Engineering Group Concordia University, Montreal, Quebec, Canada

A. Abran

Software Engineering Department & Information Technology

École de Technologie Supérieure (ÉTS), Montréal, Québec, Canada

Keywords: Design patterns, Pattern-oriented architecture, Software architecture and Web applications.

Abstract: A number of Web design problems continue to arise, such as: (1) decoupling the various aspects of Web

applications (for example, business logic, the user interface, navigation and information architecture; and

(2) isolating platform specifics from the concerns common to all Web applications. In the context of a

proposal for a pattern-oriented architecture for Web applications, this paper identifies an extensive list of

patterns aimed at providing a pool of proven solutions to these problems. The patterns span several levels of

abstraction, from information architecture and interoperability patterns to navigation, interaction,

visualization and presentation patterns. The proposed architecture will show how several individual patterns

can be combined at different levels of abstraction into heterogeneous structures, which can be used as

building blocks in the development of Web applications.

1 INTRODUCTION

The Internet and its languages offer major

opportunities for developing new generation

architecture for Web software systems, the latest of

which are highly interactive, platform-independent

and run on the client Web browser across a network.

This paper is aimed at providing a pool of proven

solutions to many recurring Web design problems.

Examples of such problems include: (1) decoupling

the various aspects of Web applications such as

business logic, the user interface, navigation and

information architecture; and (2) isolating platform-

specific issues from the concerns common to all

Web applications.

In this paper, the definition of software

architecture from (

Buschmann, Meunier, Rohnert,

Sommerlad, and Stal, 1996)

is adopted: “the structure

of the subsystems and components of a software

system and the relationships between them typically

represented in different views to show the relevant

functional and non functional properties.” This

definition introduces both the main architectural

elements (for instance, subsystems, components and

connectors), and covers the ways in which to

represent them, including both functional and non-

functional requirements, by means of a set of views.

A pool of proven solutions is proposed here in

the form of an architecture and the related patterns

for a pattern-oriented architecture for Web

applications to address solving these problems.

These individual patterns can then be combined at

different levels of abstraction into heterogeneous

structures, which can be used as building blocks in

the development of these applications.

This paper is organized as follows: section 2

introduces related work on pattern-oriented

architectures in general, such as the Model-View-

Controller model (3-tier architecture), the Core J2EE

pattern model (5-tier architecture) and the Zachman

117

Taleb M., Seffah A. and Abran A. (2007).

PATTERN-ORIENTED ARCHITECTURE FOR WEB APPLICATIONS.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Web Interfaces and Applications, pages 117-121

DOI: 10.5220/0001259501170121

 SciTePress

model (multi-tier architecture); section 3, based on

Zachman’s work, primarily describes the pattern-

oriented architecture proposed here and some

patterns which we have identified and formalized;

finally, section 4 presents a summary and directions

for future work.

2 RELATED WORK

2.1 MVC Model

The basic architecture we considered as a starting

point is the Model-View-Controller (MVC) pattern,

which is commonly used to structure Web

applications that have significant processing

requirements. This makes them easier to code and

maintain. MVC is used here to describe the core

components of Web application architectures, as it is

a 3-tier architecture that is often used by Web

application designers to maintain multiple views of

the same data. At the design level, the MVC pattern

features a clean separation of three types of objects:

• Model: for maintaining data;

• View: for displaying all or a portion of the

data;

• Controller: for handling events that affect

the model or view(s).

Other patterns may apply in the construction of these

components. For example, in MVC, the views are

tightly coupled with the control. Some authors have

suggested using the “Command Action pattern” to

ensure the separation of views and controls.

In Web applications design, several aspects need to

be considered separately, including dialogs,

persistence, site management and error handling. By

itself alone on its own, the MVC architectural

pattern is does not a sufficient solution that fully

addresses these issues. Other patterns are also

required to:

• Encourage the designer to consider other

aspects of the dialog which are very important

to the user, such as assistance or error

management;

• Facilitate the use for the interface

descriptions, which are highly important to

the designer (

Booch, Rumbaugh and Jacobson,

1999), (Myers, 1986), (Myers and Buxton, 1986)

and

(Meyer, 1990).

2.2 More Advanced Architecture:

Modeling Core J2EE Patterns

Building on the MVC pattern, the Java Sun team has

proposed 5-tier architecture (from Web site

www.developpez.com) to model the Core J2EE

Pattern Architecture (from Web site www.sun.com).

Java also provides support for the implementation of

the MVC architecture using the Observer Interface

and the Observable Classes that together implement

the observer pattern. The Observable Class

represents an observable object, or "data" in the

model-view paradigm. It can be “sub-classed” to

represent an object that the application wants to have

observed. An observable object can have one or

more observers. An observer may be any object that

implements the Observer Interface. The core J2EE

Patterns-oriented Web software architecture

proposed in Web site www.sun.com.

It can be observed that Web architecture needs to

operate at six different levels, which are listed in

Table 1.

Table 1: Six architectural levels of a Web architecture.

Architectural

Level

Function

1. Navigation

Provides proven techniques for

navigation

2. Interaction

Provides dialog styles to

perform tasks

3. Presentation

Provides solutions for how to

visually organize the contents

or the related services into

working areas, the effective

layout of multiple data and the

relationship between them

4. Visualization

Provides different visual

representations/metaphors for

grouping and displaying a large

set of data into cognitively

accessible chunks

5. Interoperability

Provides mechanisms for

decoupling the various layers

of a Web application into

particular information

categories (content) and within

the four higher levels listed

above

6. Information

Provides conceptual models

and architectures for organizing

the underlying content across

multiple pages, servers,

databases and computers

WEBIST 2007 - International Conference on Web Information Systems and Technologies

118

To understand and define these levels in greater

detail, we use the Zachman model, which is a multi-

layer architectural framework.

2.3 Zachman Model as the Basis for a

Multi-Layer Architecture

(Zachman, 1987) and (Sowa and Zachman., 1992)

proposed a multi-tier architecture which was an

Enterprise Architecture schema depicting two

distinct dimensions in a matrix. The columns

classify answers to questions such as What (Data),

How (Function), Where (Network), Who (People),

When (Time) and Why (Motivation). The rows

classify the audience’s perspectives: scope, owner,

designers, builder, trades and functioning

organization. This gives 36 cells that uniquely

classify portions of the organization. The columns in

the Zachman framework represent different areas of

interest for each perspective and describe the

dimensions of the systems development effort.

3 THE PROPOSED

ARCHITECTURE

3.1 Overview

To tackle some of the weaknesses identified in

related work, the Zachman theory, or set of

concepts, proposes a 6-tier architecture of a pattern-

oriented generic classification schema for Web

software architecture. We use the matrix

classification proposed by Zachman, according to

which the columns constitute the questions and the

rows represent the six levels defined in Table 2.

Table 2: Pattern-oriented generic classification schema for

a Web software architecture.

HAT

(Data)

HOW

(Function

)

HERE

(Network)

WHO

(People)

HEN

(Time)

WHY

(Motivation

)

avigation

3 3

nteraction

3 3 3 3 3

resentation

3 3

isualization

3 3

nteroperabilit

3 3 3 3 3 3

nformation

3 3 3 3 3 3

3.2 Pattern Taxonomy

A taxonomy of patterns is proposed next. Examples

of patterns are also presented to illustrate the need to

combine several types of patterns to provide

solutions to complex problems at the six

architectural levels. This list is not exhaustive: there

is no doubt that more patterns are needed, and that

others have yet to be discovered.

A number of Web pattern languages have been

suggested; for example, Van Duyne’s The Design of

Sites (Duyne, Landay, and Hong, 2003), Welie’s

Interaction Design Patterns (Welie, 1999) and

Tidwell’s UI Patterns and Techniques (Tidwell,

1997) play an important role, and specific languages,

such as Laakso’s User Interface Design Patterns

(

Laakso, 2003) and the UPADE Web Language

(Engelberg and Seffah, 2002), have been proposed as

well. Various specific pattern collections have been

published, including patterns for Web page layout

design (Tidwell, 1997), (

Coram and Lee, 1998) and

(Welie, 1999), for navigation around large

information architectures, as well as for visualizing

and presenting information.

In our work, we investigate how these existing

collections of patterns can be used as building

blocks within the context of the proposed six-layer

architecture. Which patterns at which level solve

which problem is the question we try to answer.

An informal survey conducted in 2004 by the HSCE

Research Group at Concordia University identified

at least six types of Web patterns that can be used to

create a pattern-oriented Web software architecture.

Table 3 illustrates these levels, and gives examples

of patterns.

Table 3: Pattern-oriented taxonomy schema for a Web

software architecture.

Architectural Level and

Category of Patterns

Examples of

Patterns

Navigation

Navigation Patterns

This category of patterns

implements proven techniques for

navigating within and/or between

a set of pages and chunks of

information.

- Shortcut

pattern

- Breadcrumb

pattern

- Index

Browsing

pattern

Interaction

Interaction Patterns

This category of patterns focuses

on the interaction mechanisms that

can be used to achieve tasks and

the visual effects they have on the

scene, and, as such they relate

primarily to graphical and

- Search pattern

- Executive

Summary

pattern

PATTERN-ORIENTED ARCHITECTURE FOR WEB APPLICATIONS

119

rendering transforms.

Presentation

Presentation Patterns

This category of patterns provides

solutions for how the contents or

the related services are visually

organized into working surfaces,

the effective layout of multiple

information spaces and the

relationship between them. These

patterns define the physical and

logical layout suitable for specific

Web pages such as home pages,

lists and tables

- Home Page

pattern

- List pattern

- Table pattern

Visualization

Visualization Patterns

This category of patterns suggests

different visual representations

and metaphors for grouping and

displaying information in

cognitively accessible chunks.

They mainly define the format and

content of the visualization, i.e.

the graphical scene, and, as such,

relate primarily to data and

mapping transforms.

- Favourite

Collection

pattern

- Bookmark

pattern

- Frequently

Visited Page

pattern

- Navigation

Space Map

pattern

Interoperability

Interoperability Patterns

This category of patterns is aimed

at decoupling the layers of a Web

application; in particular, between

the content, the dialog and the

views or presentation layers.

These patterns are generally

extensions of the Gamma design

patterns, such as MVC (Model,

View and Controller) observer and

command action patterns.

Communication and

interoperability patterns are useful

patterns to facilitate the mapping

of design between platforms.

- Adapter pattern

- Bridge pattern

- Builder pattern

- Decorator

pattern

- Façade pattern

- Factory pattern

- Method pattern

- Mediator

pattern

- Memento

pattern

- Prototype

pattern

- Proxy pattern

- Singleton

pattern

- State pattern

- Strategy

pattern

- Visitor pattern

Information

Information Patterns

This category of patterns describes

different conceptual models and

architectures for organizing the

underlying content across multiple

pages, servers and computers.

Such patterns provide solutions to

questions such as which

information can be or should be

presented on which device

- Sequence

pattern

- Hierarchy

pattern

- Grid pattern

Some examples of proposed categories of patterns

are presented below.

3.3 Information Patterns

This category shows the need to combine several

types of patterns to provide solutions to complex

problems. Here again, the list of patterns is not

exhaustive: there is no doubt that more patterns still

need to be documented, and that others have yet to

be discovered.

3.4 Navigation Patterns

Navigation patterns are fundamental in Web design,

since they help the user move easily and in a

straightforward manner between information chunks

and pages. They can obviously reduce the user’s

memory load (

Nielsen, 1999) and (Lynch and Horton,

1999

). See also (Tidwell, 1997), (Welie, 1999),

(Engelberg and Seffah, 2002) and (Garrido., Rossi, and

Schwabe, 1997) for an exhaustive list of navigation

patterns.

3.5 Interaction Patterns

A critical design issue for resource-constrained

(small) devices is how long it takes to determine

whether or not a document contains relevant

information. The search pattern with the complicity

of the “Executive Summary pattern” (a page-layout

pattern), provides users with a preview of underlying

information before spending time downloading,

browsing and reading large amounts of information

included in subsequent pages.

3.6 Visualization Patterns

Information overload is another fundamental issue to

tackle through Web software architecture. Web

applications, especially large Web portals, can

provide access to millions of documents. The

designer must consider how best to map the contents

into a graphical representation that conveys

information to the user while facilitating the

exploration of the content of a large site. In addition,

the designer must provide dynamic actions that limit

the amount of information the user receives, while at

the same time keeping the user informed about the

content as a whole.

Information visualization patterns can be used to

solve another complex design problem, which is to

provide a comprehensive map for a large amount of

content that cannot be reasonably presented in a

WEBIST 2007 - International Conference on Web Information Systems and Technologies

120

single view. They are generally combined in such a

way that the underlying content can be organized

into distinct conceptual spaces or working surfaces

which are semantically linked to one another.

3.7 Presentation Patterns

The presentation patterns define the appearance and

the form of presentation of the application on the

Web page. These patterns provide solutions for how

the contents or the related services can be visually

organized into working surfaces, the effective layout

of multiple information spaces and the relationship

between them. They define the physical and logical

layout suitable for specific Web pages such as home

pages, lists and tables.

3.8 Interoperability Pattern

The communication and interoperability patterns are

useful for facilitating the mapping of a design

between platforms. Examples of patterns that can be

considered to ensure the interoperability of Web

applications include all Web patterns of

Interoperability patterns.

4 SUMMARIES AND FUTURE

WORK

In this paper, we have identified and proposed six

categories of patterns, providing examples, for a

pattern-oriented architecture for Web applications to

resolve many recurring Web design problems,

examples of which include: (1) decoupling the

various aspects of Web applications such business

logic, the user interface, navigation and information

architecture; (2) isolating platform-specific problems

from the concerns common to all Web applications.

Our discussion has focused on the way to specify a

pattern-oriented architecture using particular

patterns. Future work will require the classification

of each pattern and the illustration of each of them in

UML class and sequence diagrams. Next, some

relationships will have to be defined between

patterns so that they can be combined to create

models based on the resulting patterns.

REFERENCES

Buschmann, F., Meunier, R., Rohnert, H., Sommerlad, P.

and Stal, I., 1996. A System of Patterns: Pattern-

Oriented Software Architecture. West Sussex,

England, John Wiley & Sons

Zachman, John A., 1987. A Framework for Information

Systems Architecture. IBM Systems Journal, vol. 26,

no. 3, IBM Publication G321-5298

Sowa, J.F. and Zachman, John A., 1992. Extending and

Formalizing the Framework for Information Systems

Architecture. IBM Systems Journal, vol. 31, no. 3.

IBM Publication G321-5488

Architecture multi-tiers. Retrieved 2006, [Online]

available at: http://java.developpez.com/archi_multi-

tiers.pdf

Duyne, D. K. van, Landay, J. A. and Hong, J. I., 2003.

The Design of Sites: Patterns, Principles, and

Processes for Crafting a Customer-Centered Web

Experience. Addison-Wesley

Welie, M.V., 1999. The Amsterdam Collection of Patterns

in User Interface Design,

http://www.cs.vu.nl/~martijn/patterns/index.html

Tidwell, J. Common Ground, 1997. A Pattern Language

for Human-Computer Interface Design,

http://www.mit.edu/~jtidwell/common_ground.html

Engelberg, D. and Seffah, A., 2002. Design Patterns for

the Navigation of Large Information Architectures,

11th Annual Usability Professional Association

Conference, Orlando, Florida, July 8-12, 2002

Laakso, Sari A., 2003. Collection of User Interface Design

Patterns University of Helsinki, Dept. of Computer

Science, September 16, 2003.

http://www.cs.helsinki.fi/u/salaakso/patterns/

Coram, T. and Lee, J., 1998. Experiences – A Pattern

Language for User Interface Design, at

http://www.maplefish.com/todd/papers/experiences

Lynch, P.J. and Horton, S, 1999. Web Style Guide: Basic

Design Principles for Creating Web Sites. New Haven

and London: Yale University Press

Nielsen, J., 1999. Designing Web Usability: The Practice

of Simplicity. New Riders

Garrido, A., Rossi, G. and Schwabe, D., 1997. ‘Pattern

Systems for Hypermedia’, Pattern Language of

Programming Conference

Booch, G., Rumbaugh, J. and Jacobson, I., 1999. The

Unified Modeling Language User Guide, Addison-

Wesley

Myers, B. A., 1986. Visual programming, programming

by example, and program visualization: A taxonomy.

In Proceedings of the ACM CHI’86 Conference on

Human Factors in Computing Systems; ACM New

York, pp. 271-278; April 1986

Myers, B. A. and Buxton, W., 1986. Creating highly-

interactive and graphical user interfaces by

demonstration, International Conference on Computer

Graphics and Interactive Techniques, Proceedings of

the 13th annual conference on Computer graphics and

interactive techniques, Pages: 249 – 258

Meyer, B., 1990. Conception et programmation par objets

pour du logiciel de qualité, Inter-Éditions, Paris

Core J2EE Patterns, Retrieved 2006, [Online] available

at:http://java.sun.com/blueprints/corej2eepatterns/Patt

erns/index.html.

PATTERN-ORIENTED ARCHITECTURE FOR WEB APPLICATIONS

121
