WEB SECURITY ENHANCEMENT

BASED ON KEYSTROKE DYNAMICS

Michał Chora

Institute of Telecommunications, University of Technology and Life Sciences, Kaliskiego 7, Bydgoszcz, Poland

Piotr Mroczkowski

Hewlett Packard Polska, Global Delivery Poland Center, Szturmowa 2a, University Business Center, Warsaw, Poland

Keywords:

Web Security, Keystroke Dynamics, Password Hardening.

Abstract:

Many online access systems (e.g. e-banking) require stronger protection than the login-id password pair can

provide. Other, more sophisticated techniques of identity veriﬁcation are in demand: one-time passwords,

smart cards or biometric technologies. Among several biometric approaches the web-based solution that

incorporates keystroke dynamics is the most relevant due to the low cost of the implementation, satisfactory

results as well as the degree of transparency it offers.

1 INTRODUCTION

Rapid growth of e-bank systems and their popularity

within information society as well as the dangers in

the web motivate efforts to create more secure online

services. Other more sophisticated techniques than

eral web-security approaches identiﬁcation based on

keystroke dynamics is the most relevant due to the

low cost of the implementation, satisfactory results as

well as the degree of transparency it offers. More-

over, following the success of other biometrics meth-

ods of identiﬁcation, keystroke dynamics seems to be

a new emerging web technique for web-security en-

hancement.

Keystroke dynamics biometric systems analyze

the way a user types at a terminal by monitoring the

keyboard events, and thus is considered as the behav-

ioral approach. Identiﬁcation is based on the rhythm

of typing patterns, which is considered to be a good

sign of identity (Monrose and Rubin, 2000). In other

words not what is typed, but how it is typed is im-

portant. In this approach several things can be an-

alyzed: time between key-pressed and key-released

events, break between two different keystrokes, dura-

tion for digraphs and trigraphs and many more.

Keystroke veriﬁcation techniques can be divided into

two categories: static and continuous. Static veriﬁ-

cation approaches analyze keyboard dynamics only

at speciﬁc times, for example during the logon pro-

cess. Static techniques are considered as providing a

higher level of security than a simple password-based

veriﬁcation system (Monrose and Rubin, 2000). The

main drawback of such an approach is the lack of

continuous monitoring, which could detect a substi-

tution of the user after the initial veriﬁcation. Nev-

ertheless, the combination of the static approach with

password authentication was proposed in several pa-

pers [e.g. (Leggett et al., 1991)] and it is considered as

being able to provide a sufﬁcient level of security for

the majority of applications. Our web identiﬁcation

system is based on such a combination. Continuous

veriﬁcation, on the contrary, monitors the user’s typ-

ing behavior through the whole period of interaction

(Monrose and Rubin, 2000). It means that even after

a successful login, the typing patterns of a person are

constantly analyzed and when they do not mach user’s

proﬁle access is blocked. This method is obviously

more reliable but, on the other hand, the veriﬁcation

algorithms as well as the implementation process it-

self are much more complex.

337

Chora

s M. and Mroczkowski P. (2007).

WEB SECURITY ENHANCEMENT BASED ON KEYSTROKE DYNAMICS.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Internet Technology, pages 337-340

DOI: 10.5220/0001264903370340

 SciTePress

2 KEYSTROKE DYNAMICS

CHARACTERISTICS

In the proposed and implemented veriﬁcation system

three independent methods of the identity veriﬁcation

are performed every time a user attempts to log in.

First and second method is based on the calculation

of the degree of disorder of digraphs and trigraphs re-

spectively. The last one compares typing paths stored

in the database against a typing path created at the

time of logon process.

1. Digraphs and trigraphs

Digraph is deﬁned as two keys typed one after the

other. In our case the duration of a digraph is mea-

sured between the press event of the ﬁrst key and

release event of the second key.

Trigraph is deﬁned as three keys typed one after

the other. The duration of trigraph is measured

between pressing event of the ﬁrst key and release

of the third key.

2. Degree of disorder Having two sets of key laten-

cies of the same Login − P assword pair, it is

possible to measure their ”similarity”. One way to

calculate that is the degree of disorder (do) tech-

nique (Bergadano et al., 2002).

Let us deﬁne vector V of N elements and vector

′

, which includes the same N elements, but or-

dered in a different way. The degree of disorder

in vector V can be deﬁned as the sum of the dis-

tances between the position of each element in V

with respect to its counterpart vector V

′

. If all the

elements in both vectors are in the same position,

the disorder equals 0.

Maximum disorder occurs when elements in vec-

tor V are in the reverse order to the model vec-

tor V

′

. Maximum disorder (do

max

) is given by

max

|V |

where |V | is the length of V and

it is even, or by do

max

(|V |

−1)

where |V | is

length of V and it is odd.

In order to get the normalized degree of disorder

(do

nor

) of a vector of N elements, we divide do

by the value of the maximum disorder. After nor-

malization, the degree of disorder falls between 0

(V and V

′

have the same order) and 1 (V is in

reverse order to V

′

3. Typing paths Typing paths can be described as a

set of key code/key event pairs stored in order of

occurrence. If some short sequence of chars is be-

ing retyped by a user several times (which is the

case with the ”Login - Password” mode), the anal-

ysis of such paths is likely to show some typical

characteristics of a user’s behavior:

• moments where keys overlap (second key is

pressed before the release of the ﬁrst one)

• the position of the key pressed in the case of

duplicate keys (digits, SHIFT’s, etc.)

3 WEB APPLICATIONS -

PASSWORD HARDENING

Password hardening using keyboard statistics can be

described as login-password pair combined with the

collected typing features during the logon process.

A system that implements the password hardening

not only performs the password veriﬁcation but also

checks the typing patterns. The main advantage of

this approach is the signiﬁcant increase of the secu-

rity. On the other hand the false rejection rate (FRR)

can increase, especially for users that are not very fa-

miliar with typing on a keyboard. Our application is

a remote system of identity veriﬁcation that is based

on password hardening using typing patterns. It is

implemented using J2EE platform (JSP, Servlets) and

MySql database. The logon module is encapsulated

in applet where both login-id password pair as well as

keyboard statistics are collected and send to server for

comparison.

Figure 1: High level architecture of our password hardening

system.

Server performs statistical analysis of typing sam-

ples, generates on the ﬂy the typing path and the vec-

tors of digraphs and trigraphs. Then the newly gener-

ated items are compared to their model counterparts

stored in database. The model vector of digraphs and

trigraphs automatically adapts to gradual changes in a

user’s typing patterns. High level architecture of our

password hardening system designed for increasing

web applications security is presented in Figure 1.

Additional use of keystroke analysis could be encour-

aged in many other applications and situations. Some

of them are presented below:

• Identity Veriﬁcation - keyboard statistics could be

introduced into any veriﬁcation system right after

WEBIST 2007 - International Conference on Web Information Systems and Technologies

338

the user’s login-password pair typing stabilizes.

• Strong Authentication - root password, safety-

critical systems and resources.

• Forgotten Passwords - our algorithms could be

used in forgotten password recovery.

4 EXPERIMENTAL SETUP AND

RESULTS

In our experiments 18 volunteers participated in test-

ing the system. Typing skills varied slightly among

them - the majority of the group type on PC key-

board every day. Every volunteer had assigned unique

dividual was used as her/his login-id, since it is one of

the most frequently typed phrase for most of people.

Collecting keyboard statistics session for single par-

ticipant lasted from 20 to 40 minutes.

In our experiments we calculated False Rejection

Rate (F RR) and False Acceptance Rate (F AR) for

each of the users. We set the systems for different

thresholds: 0.25, 0.3, 0.35 and 0.4. In the ﬁrst stage

every participant performed 15 attempts of log in-

password authentication that were evaluated by the

system in order to calculate the model vector of di-

graphs and trigraphs as well as to collect the typing

paths. After that users performed several another lo-

gon attempts as valid users (F RR tests) and few at-

tempts as impostors (trying to log on somebody’s

else account knowing login and password - F AR

tests).

Table 1: FAR results for digraphs and trigraphs for the 0.25

threshold.

user Digraph FAR Trigraph FAR

user1 0.0000 15.3846

user2 0.0000 0.0000

user6 0.0000 17.5439

user8 0.0000 0.0000

user9 0.0000 12.5000

user10 0.0000 1.9231

user14 1.2346 28.3951

user15 0.0000 9.0909

user17 0.0000 0.0000

user18 0.0000 0.0000

In the experiments a participant was asked to act

as impostor. She/he was trying to logon on somebody

else account. In order to increase the number of lo-

gon attacks per single account, we randomly selected

Table 2: FAR results for digraphs and trigraphs for the 0.3

threshold.

user Digraph FAR Trigraph FAR

user1 1.9231 34.6154

user2 0.0000 15.3846

user6 0.0000 47.3684

user8 0.0000 1.6949

user9 0.0000 50.0000

user10 0.0000 7.6923

user14 9.8765 38.2716

user15 0.0000 45.4545

user17 0.0000 0.0000

user18 9.0909 18.1818

Table 3: FAR results for digraphs and trigraphs for the 0.35

threshold.

user Digraph FAR Trigraph FAR

user1 5..7962 48.0769

user2 7.6923 61.5385

user6 7.0175 66.6667

user8 5.0847 3.3898

user9 12.5000 68.7500

user10 9.6154 19.2308

user14 24.6914 59.2593

user15 0.0000 54.5455

user17 0.0000 0.0000

user18 27.2727 45.4545

10 out of 18 existing accounts to be attacked. This

decision was motivated by the fact that the number

of participants (and thus samples) was limited (users

were not willing to spend hours trying to hack some-

body’s else account). Bigger number of attacks per

single account will picture more clearly the FAR, so

smaller number of accounts to hack was the only rea-

sonable solution. The results showing FAR for each

of the threshold for digraph and trigraph method are

shown in the Tables 1-4. The results for typing path

method and for all the methods combined together are

shown in the Table 5.

5 DISCUSSION OF THE RESULTS

AND CONCLUSION

In the article we presented our keystroke feature

(characteristics) extraction methods. We also proved

that biometrics based on keystroke dynamics is capa-

ble of increasing security in web applications such as

WEB SECURITY ENHANCEMENT BASED ON KEYSTROKE DYNAMICS

339

Table 4: FAR results for digraphs and trigraphs for the 0.4

threshold.

user Digraph FAR Trigraph FAR

user1 19.2308 50.0000

user2 46.1538 69.2308

user6 12.2807 71.9298

user8 15.2542 11.8644

user9 18.7500 81.2500

user10 26.9231 36.5385

user14 33.3333 67.9012

user15 0.0000 63.6364

user17 0.0000 10.0000

user18 54.5455 63.6364

Table 5: FAR results for typing paths and combined meth-

ods.

user Typing Path FAR Combined FAR

user1 0.0000 1.9230

user2 7.6923 0.0000

user6 0.0000 0.0000

user8 3.3898 0.0000

user9 0.0000 0.0000

user10 1.9231 0.0000

user14 0.0000 8.1649

user15 9.0909 0.0000

user17 0.0000 0.0000

user18 0.0000 0.0000

password hardening in e-banking (the combined val-

ues of F AR were equal to %0 for all but 2 users

(Table 5).This means that the presented methods are

effective and could be implemented to increase web

security in applications where logging-in is the neces-

sity for the clients.

It is hard to determine which of the developed and

implemented method gives the best performance for

all users. The best solution is to make the logon al-

gorithm adaptive. The algorithm should check which

method gives the best performance for given user in

order to give it the biggest weight while taking the

access/no access decision. In case of non-adaptive

implementation the best results were observed for

thresholds: 0,25 for trigraphs and 0,3 for digraphs.

The threshold for digraphs and trigraphs should not

be equal. It should be higher for digraphs and lower

for trigraphs. It is also noticeable that longer char

sets (trigraphs) have more stable statistics for a le-

gitimate user (the standard deviation of particular tri-

graph’s durations is small, and thus the distance cal-

culated from the degree of disorder is smaller), but on

the other hand they are easier to forge.

Keystroke dynamics are sensitive to the emotional

and physical state of the person who is veriﬁed. Very

poor typing skills are another factor which can af-

fect the process of authentication. The good thing

is that this method is very likely to achieve a high

level of acceptance among ordinary users. Moreover,

unlike other biometric systems which usually require

additional hardware and thus are expensive to imple-

ment, biometrics based on keystroke dynamics is al-

most for free - the only hardware required is the key-

board (Monrose and Rubin, 2000).

REFERENCES

F. Monrose, A. Rubin, ”Keystroke Dynamics as a Biomet-

ric for Authentication”, Future Generation Computer

Systems, vol. 16 , no. 4, 351 - 359, 2000.

G. Leggett, J. Williams, M. Usnick, ”Dynamic Identity Ver-

iﬁcation via Keystroke Characteristics”, International

Journal of Man-Machine Studies, vol. 35 , no. 6, 859

- 870, 1991.

R. Gaines, W. Lisowski, S. Press, N. Shapiro, ”Authentica-

tion by Keystroke Timing: some preliminary results”,

Rand Report R-256-NSF. Rand Corporation, 1980.

F. Monrose, A. Rubin, ”Authentication via Keystroke Dy-

namics”, Conference on Computer and Communica-

tions Security , 48-56, 1997.

R. Joyce, G. Gupta, ”User authorization based on keystroke

latencies”, Communications of ACM, vol. 33, no. 2,

168-176, 1990.

S. Bleha, C. Slivinsky, B. Hussein, ”Computer-access secu-

rity systems using keystroke dynamics”, IEEE Trans.

on Patt. Anal. Mach. Int, vol. 12, no. 12, 1217–1222,

1990.

M. Brown, S. J. Rogers, ”User identiﬁcation via keystroke

characteristics of typed names using neural networks”,

International Journal of Man-Machine Studies, no. 39,

999-1014, 1993.

F. Bergadano, D. Gunetti, C. Picardi, ”User Authentication

through Keystroke Dynamics”, ACM Transactions on

Information and System Security, vol.5, no. 4, 367 -

397, 2002.

M. Brown, S. J. Rogers, ”Method and apparatus for veri-

ﬁcation of a computer user’s identiﬁcation, based on

keystroke characteristics”, Patent Number 5,557,686,

U.S. Patent and Trademark Ofﬁce, Washington, D.C.,

1996.

E. Yu, S. Cho, ”Biometrics-based Password Identity Veriﬁ-

cation: Some Practical Issues and Solutions,” XVth

Triennial Congress of the International Ergonomics

Association (IEA), Aug 24-29, Seoul, Korea, 2003.

P. Mroczkowski, M. Chora

s, ”Keystroke Dynamics in Bio-

metrics Client-Server Password Hardening System”,

Proc. of Advanced Computer Systems (ACS), vol. II,

75-82, Miedzyzdroje, Poland, October 2006.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

340
