WEB PAGE CLASSIFICATION CONSIDERING PAGE GROUP

STRUCTURE FOR BUILDING A HIGH-QUALITY HOMEPAGE

COLLECTION

Yuxin Wang and Keizo Oyama

National Institute of Informatics, Hitotsubashi 2-1-2, Chiyoda-ku, Tokyo 101-8430, Japan

Keywords: Surrounding page group, three-way classification, recall and precision, quality assurance.

Abstract: We propose a web page classification method for creating a high quality homepage collection considering

page group structure. We use support vector machine (SVM) with textual features obtained from each page

and its surrounding pages. The surrounding pages are grouped according to connection type (in-link, out-

link, and directory entry) and relative URL hierarchy (same, upper, or lower); then an independent feature

subset is generated from each group. Feature subsets are further concatenated to compose the feature set of a

classifier. The experiment results using ResJ-01 data set manually created by the authors and WebKB data

set show the effectiveness of the proposed features compared with a baseline and some prior works. By

tuning the classifiers, we then build a three-way classifier using a recall-assured and a precision-assured

classifier in combination to accurately select the pages that need manual assessment to assure the required

quality. It is also shown to be effective for reducing the amount of manual assessment.

1 INTRODUCTION

The web is becoming more and more important as a

potential information source for adding value to

high-quality scholarly information services. What is

required here is a web page collection with

guaranteed quality (i.e., recall and precision);

however, the task of building such a collection is

thought to demand a large amount of human effort

because of the diversity in style, granularity and

structure of web pages, the vastness of the web data,

and the sparseness of relevant pages.

Many researchers have investigated classification

of web pages, etc.; however, most of their

approaches are of the best-effort type and pay no

attention to quality assurance. Thus, we are trying to

devise a method to build a homepage collection

efficiently with high quality level assured.

We approach this problem in two steps:

improving web page classification performance by

exploiting information in surrounding pages

considering page group structure, and accurately

selecting web pages requiring manual assessment.

For the first step, we propose a method using

support vector machine (SVM) with features that are

obtained from the textual contents in each page and

its surrounding pages considering their page group

structure. For the second step, we build a three-way

classifier using a recall-assured classifier and a

precision-assured classifier in combination. We can

exploit the first approach’s potential performance by

tuning each classifier independently.

We evaluated the proposed method with

experiments using ‘ResJ-01’, a Japanese data set and

‘WebKB’, an English data set.

We intend to use the resulting web page

collection for extending a guarantee-type

information service such as CiNii (CiNii), not only

as link targets but also as reference data for record

linkage (Aizawa and Oyama, 2005) among papers,

citations, and/or project reports. Considering the

applications, 95% recall and 99% precision, for

example, should be assured.

The rest of the paper is organized as follows.

Related work is introduced in Section 2. The scheme

of the three-way classifier is presented in Sections 3

and the proposed feature is explained in Section 4.

Section 5 presents the experiment results and section

6 discusses the effectiveness of the proposed

method. Finally, we conclude our work in Section 7.

170

Wang Y. and Oyama K. (2007).

WEB PAGE CLASSIFICATION CONSIDERING PAGE GROUP STRUCTURE FOR BUILDING A HIGH-QUALITY HOMEPAGE COLLECTION.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Web Interfaces and Applications, pages 170-175

DOI: 10.5220/0001271701700175

 SciTePress

Scope of the research

Amount of target data ≥ 95%

positive

negative

Web pages

Recall-assured classifier

Assured negative

Assured positive

Proportion of target

data ≥ 99%

negative

Manual assessment

positive

Amount of target

data < 5%

Uncertain

Precision-assured classifier

2 RELATED WORK

The method proposed in this paper belongs to the

web page classification domain, and is closely

related to the web page search and clustering

domains. In these domains, what information

sources to use is the first factor to be considered and

how to use them is the second.

The previous studies tried to exploit, besides

textual content, various web-related information

sources such as html tags (Sun et al., 2002), URLs

(Kan and Thi, 2005), sub-graphs of web pages (Sun

and Lim, 2003; Masada et al., 2005), directory

structure (Sun and Lim, 2003), anchor texts (Sun et

al., 2002), contents of globally link-related pages

(Glover et al., 2002), and contents of local

surrounding pages (Wang and Oyama, 2006;

Masada et al., 2005; Sun and Lim, 2003). All of

these information sources except the last one are

used to capture the features that are characteristic to

the target pages, and are effective for selecting

highly probable pages. The last one, in contrast, is

used to collect information scattered over some

linked pages so that potential target pages can be

comprehensively gathered; however, it also tends to

increase noise. Since comprehensiveness is a key

factor for quality assurance of a web page collection,

we mainly focus on the last one, i.e., the contents of

local surrounding pages as information sources, in

the current work.

Sun et al. (Sun et al., 2003) studied on exploiting

the surrounding pages. They first classify each page

only based on its content and then combine the

results from other information sources, such as the

link structure and directory structure. However, this

approach will not work when an entry page contains

no textual information except hyperlinks. Other

studies first cluster web pages based on the local link

structure and so on, and then merge the score (or

weight) of each word to generate a document vector

(Wang and Oyama, 2006; Masada et al., 2005).

However, the effectiveness of this approach is

limited, probably because it also merges many

irrelevant words from the surrounding pages.

We also exploit the contents in surrounding

pages considering page group and local link

structure, but with a different approach. To reduce

noise, we divide the surrounding pages to groups

according to the structural relation with the target

page, extract features from each group, and

concatenate (rather than merge) the features from the

groups, so that the contexts corresponding to the

structural relation can be represented. We also

propose a very simple method for exploiting html

tag related information.

In addition, almost no previous studies tried to

assure the quality level that would be required for

practical applications. We are trying to solve this

problem by building a three-way classifier using a

recall-assured classifier and a precision-assured

classifier in combination.

3 CLASSIFICATION SCHEME

Figure 1 shows the scheme of our classification

method (95% recall and 99% precision are used as

the quality requirement for illustration). We use two

component classifiers to construct a three-way

classifier. The recall-assured (precision-assured)

classifier assures the target recall (precision) with

the highest possible precision (recall).

All web pages are first input to the recall-assured

classifier and its negative predictions are classified

as “assured negative”. The rest are then input to the

Figure 1: Scheme of the Classification.

WEB PAGE CLASSIFICATION CONSIDERING PAGE GROUP STRUCTURE FOR BUILDING A HIGH-QUALITY

HOMEPAGE COLLECTION

171

precision-assured classifier and its positive

predictions are classified as “assured positive”. The

remaining pages are classified as “uncertain”, and

these require manual assessment in order to keep the

required quality. The target precision is assured in

the “assured positive” output, the target recall is

assured in the “assured positive” and “uncertain”

outputs together, and the “uncertain” output should

be minimized.

4 CLASSIFIER COMPOSITIONS

The support vector machine (SVM) is effective for

text classification. We used the SVM

light

package

developed by Joachims with the linear kernel and

tuned it with options c and j.

4.1 Surrounding Page Group and

Feature Set

In the current work, given a page to be classified

(current page), a surrounding page of the current

page is defined as a page related to the current page

by either of three connection types c: in (in-link), out

(out-link), and ent (directory entry) in the directory

path or in the directory subtree of the current page.

We assign surrounding page groups G

c,l

to each

surrounding page according to the connection type c

and URL hierarchy level l (same, upper and lower)

relative to the current page. The current page alone

constitutes an independent group G

cur

. All defined

surrounding page groups are shown in Table 1. In

view of a logical page group, each group has its own

implicit meaning. For example, G

in,lower

consists of

in-link pages in lower directories which might

represent component pages having back links to the

entry page, and G

ent,upper

consists of directory entry

pages in upper directories which might represent the

organization the entity of the current page belongs to.

We use textual feature f

t,v

(g,w

), where t indicates

a text type plain (plain-text-based) or tagged

(tagged-text-based), v indicates a value type binary

or real, g denotes a surrounding page group, and

∈W

denotes a feature word. A feature set is

composed by concatenating one or more feature

subsets F

t,v

(g) = { f

t,v

(g,w

) | w

∈W

} for each g in

cur

and any number of G

c,l

’s. For instance, the

feature set “u-1” shown in Section 5 consists of

feature subsets on G

cur

and G

*,upper

(surrounding page

groups of upper hierarchy level), the feature set “o-i-

e-1” consists of feature subsets on G

cur

and G

*,*

(all

surrounding page groups), and the feature set

“all_merged” consists of feature subsets on G

cur

and

all,all

(all the surrounding pages merged together).

4.2 Text Type and Feature Word

We use two kinds of textual features and use Chasen

for Japanese data set and Rainbow for English data

set to tokenize the feature words from the texts.

Plain-text-based features f

plain,*

(*,*) are extracted

from textual content excluding tags, scripts,

comments, etc. We use top 2,000 feature words

plain

ranked by mutual information (Cover and

Thomas, 1991).

Tagged-text-based features f

tagged,*

(*,*) are

extracted from “text” segments that match either

“>text<” or “<img…alt= "text"...>” and that are not

more than 16 bytes long omitting spaces for the

Japanese data set and not more than 4 words long for

the English data set. The obtained words with not

less than 1% file frequency for Japanese data set and

all the obtained words for English data set are used

as feature words W

tagged

. We use the tagged-text-

based features because the text segmets are

considered to frequently contain property words.

In the experiments, a feature set is composed by

using feature words either plain alone or plain and

tagged together. The latter case is indicated by the

suffix “_tag” of the run name.

A binary value f

*,binary

(g,w

) represents the

presence of w

in g. A real value f

*,real

(g,w

)

represents the proportion of pages containing w

within g. The real value is tested to see if the feature

word distribution within surrounding page groups is

informative. The two value types are exclusively

used for composing a feature set. Use of the value

type real is indicated by the suffix “_real” in the run

name.

5 EXPERIMENTS

5.1 Experiments on ResJ-01 Data Set

We manually prepared ‘ResJ-01’, a Japanese data

set of researchers’ homepages consisting of 480

positive samples and 20,366 negative samples. Five-

Table 1: Surrounding page groups.

Connection type c

Hierarchy level l

r out in ent merged

same

cur

out,same

in,same

ent,same

all,same

lower

out,low

in,low

all,low

upper

out,upper

in,upper

ent,upper

all,upper

merged

out,all

in,all

ent,all

all,all

WEBIST 2007 - International Conference on Web Information Systems and Technologies

172

fold cross validation was used. A feature set only

composed of F

plain,binary

cur

) was used as the

baseline. Fig. 2 shows the overall performances and

Fig. 3 and 4 zoom up high precision and high recall

areas of the two best performing classifiers. Their

performances compared with the baseline and

all_merged are listed in Table 2. The results show

that, in the high precision area, both o-i-e-1_tag_real

and u-1_tag outperform the others; while in the high

recall region, o-i-e-1_tag_real evidently outperforms

all the others and u-1_tag also performs rather well.

5.2 Experiments on WebKB Data Set

We used the WebKB data set for testing the

effectiveness of the proposed features. It is an

English data set containing 8,282 pages collected

from the computer science departments of 4 major

universities and of other universities, and manually

classified into 7 categories. 4 categories, i.e., student,

faculty, course, and project, were used for our

experiments. The pages of the respective categories

are used as positive samples and the pages of the

other categories are used as negative samples. As

recommended by the project, we used the leave-one-

university-out cross-validation method on the 4

universities and the pages of the other universities

were always used as training data. A feature set

composed by F

plain,binary

cur

) only was used as the

baseline. The results of well performing feature sets

compared with prior works are shown in Table 3.

The overall results show that tagged-text-based

features are consistently effective and the

differences caused by the value types are negligible.

o-i-e-1_tag and o-i-e-1_tag_real performed the best.

The results show that our method outperformed

all the seven prior works based on macro-averaged

F-measure of all the four categories (Macro(4)) and

is a little inferior to only one prior work on macro-

averaged F-measure of the course, faculty, and

student categories (Macro(3)). Our method out-

performed 9 out of 12 on a per-category basis (F-

measures of the individual categories are not

available for four of the previous studies).

Figure 3: Precision in high precision range.

90%

91%

92%

93%

94%

95%

96%

97%

98%

99%

100%

0 100 200 300 400 500 600 700 800 900 1000

#pos. pr edi ct i ons

baseline

o- i - e- 1_t ag_r eal

u- 1_t ag

88%

89%

90%

91%

92%

93%

94%

95%

96%

97%

98%

99%

100%

0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000

#pos. pr edi ct i ons

basel i ne

o- i - e- 1_t ag_r eal

u- 1_t ag

Figure 4: Recall in high recall range.

Table 2: Performance of well performing feature sets.

Feature set

Best

F-measure

Recall at

99% precision

Precision at

95% recall

o-i-e-1_tag_real

.811

.209

.413

u-1_tag .799

.232

.332

all_merged_tag .775 .179 .359

baseline .748 .180 .265

10%

20%

30%

40%

50%

60%

70%

80%

90%

100%

1 10 100 1000 10000 100000

#pos. pr edi ct i ons

basel i ne

o- i - e- 1_t ag_r eal

u- 1_t ag

r ecal l pl ot s

pr eci si on pl ot s

Figure 2: Performance on ResJ-01 data set.

WEB PAGE CLASSIFICATION CONSIDERING PAGE GROUP STRUCTURE FOR BUILDING A HIGH-QUALITY

HOMEPAGE COLLECTION

173

6 CONSIDERATIONS

6.1 Effectiveness of Proposed Features

The experiment results for both the ResJ-01 data set

and the WebKB data set indicate that the proposed

features are effective on improving the basic

performance (in F-measure). In our work, we use the

features on page contents of not only the target

pages (the baseline) but also the surrounding pages

of the target pages. In addition, when using the

surrounding pages, the features on different

surrounding page groups are not simply merged

together (all_merged), but are concatenated so that

the context of the surrounding pages can be

expressed. That is probably the reason why our

method could successfully exploit the surrounding

pages while the prior works were not so successful.

Our experiment results for WebKB data set

shown in Table 3 are not strictly comparable to the

results of the prior works because, although the data

set is the same, they used different parts of data or

different validation methods. However, the proposed

method apparently improved the performance to the

highest level of the prior works. More important is

that the performance of the proposed method is

stable even when the training data size is small.

The proposed feature set is simple and easy to

generate and is potentially applicable to wide range

of web page classification problems together with

various existing classification techniques.

The experiment results for ResJ-01 data set show

that the proposed features improve the performance

of the precision/recall-assured classifiers as well as

the basic performance. The surrounding page groups

are consistently effective, but their contributions

vary.

For precision-assured classifiers, the upper

directory page groups (G

*,upper

) contribute the most

to the recall. This probably indicates that such pages

provide contextual information, e.g., organization

names and research fields, which is lacking in the

current page itself but is very important for

classifying them with very high confidence.

For recall-assured classifiers, all surrounding

page groups (G

*,*

) notably contribute to the

precision. This probably indicates that the

information from all kinds of surrounding page

groups is needed for achieving the high recall, and

that the contexts corresponding to the surrounding

page structure are appropriately expressed by

concatenating the features and successfully reduced

the noise which is otherwise introduced by the

surrounding pages.

6.2 Reduction of Manual Assessment

To assess how our method would reduce the amount

of manual assessment (i.e., the page numbers of

uncertain output ), we compared two compositions

of the three-way classifier, one using the baseline

and the other using the o-i-e-1_tag_real for both the

recall-assured and precision-assured classifiers.

Table 4 shows the estimated page numbers of

classification output from ‘NW100G-01’, a 100GB

web page corpus for three different quality

requirements. Comparing the uncertain class sizes,

the o-i-e-1_tag_real significantly reduced the

amount of pages requiring manual assessment,

especially when the required quality is relaxed.

Table 3: Classification performance on WebKB data set (in percentage of F-measure).

Method course faculty project student Macro(4) Macro(3)

baseline .684 .760 .400

.750

.649 .731

all_merged .731 .791 .365 .734 .655 .752

all_merged_tag

.802 .817

.393 .685 .674 .768

u-1_tag .751 .774 .415 .715 .664 .747

o-i-e-1_tag .778 .796

.595

.745

.729 .773

Proposed

methods

o-i-e-1_tag_real .771 .794 .572

.750

.722 .772

FOIL(Linked Names) (Yang et al., 2002) .629

FOIL(Tagged Words) (Yang et al., 2002) .591

SVM(TA) (Sun et al., 2002)

.682

.659 .325 .730 .599 .690

SVM-FST(XATU) (Kan, 2004) .609 .409

.665

.253 .484 .424

ME(TU) (Kan and Thi, 2005) .627

SVM-iWUM(α =1) (Sun and Lim, 2003)

.547

.876

.171

.958 .638 .794

Prior

works

GE-CKO(FC5) (Sun et al., 2004) .765

Note: The best and the second best results among the proposed methods and among the prior works in each row are shown with bold

face and italic face respectively. The prior works that outperformed either o-i-e-1_tag or o-i-e-1_tag_real are shown with underline.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

174

7 CONCLUSION

We proposed a web page classification method for

building a high quality homepage collection, by

using a three-way classifier composed of recall-

assured and precision-assured component classifiers.

By using the proposed method, not only the basic

performance in F-measure but also the performance

of precision/recall-assured classifiers are improved

evidently. At the same time, the effectiveness for

reducing the number of pages that need manual

assessment to satisfy a required quality given is also

shown.

The current classification performance is still far

below what can be achieved manually. In the future,

we will study a technique to estimate the likelihood

of the surrounding pages to be the component pages

and incorporate it to the current method.

We also need to investigate the processing cost

problem because high performance classifiers

require rather complex feature processing that might

make it impractical to deal with the enormous size of

the web. We have partly tackled this problem with

the rough filtering presented in the reference (Wang

and Oyama, 2006), and we expect to be able to

overcome it by extending the approach.

ACKNOWLEDGEMENTS

This study was partially supported by a Grant-in-Aid

for Scientific Research B (No. 18300037) from the

Japan Society for the Promotion of Science (JSPS).

We used the NW100G-01 document data set with

permission from the National Institute of Informatics

(NII). We would like to thank Professors Akiko

Aizawa and Atsuhiro Takasu of NII for their

precious advice.

REFERENCES

Aizawa, A., Oyama, K., 2005. A fast linkage detection

scheme for multi-source information integration. In

International Workshop on Challenges in Web

Information Retrieval and Integration (WIRI 2005),

Tokyo, Japan.

CiNii. http://ci.nii.ac.jp/.

Glover, E. J., Tsioutsiouliklis, K., Lawrence, S., Pennock,

D. M., Flake, G. W., 2002. Using web structure for

classifying and describing web pages. In 11th

International World Wide Web Conference, Honolulu,

Hawaii, USA.

Cover, T.M., Thomas, J. A., 1991. Elements of

information theory. Willey press.

Kan., M.-Y., 2004. Web page categorization without the

web page. In 13th World Wide Web Conference

(WWW2004), New York, NY, USA, May 17-22.

Kan, M.-Y., Thi, H.O.N., 2005. Fast webpage

classification using URL features. In CIKM’05,

Bremen, Germany.

Masada, T., Takasu, A., Adachi, J., 2005. Improving web

search performance with hyperlink information. IPSJ

Transactions on Databases, Vol.46, No.8.

Sun, A., Lim, E.-P., Ng. W.-K., 2002. Web classification

using support vector machine. In 4th international

workshop on web information and data management.

ACM Press, McLean, Virginia, USA.

Sun, A., Lim, E.-P., 2003. Web unit mining: finding and

classifying subgraphs of web pages. In International

Conference on Information and Knowledge

Management (CIKM2003), New Orleans, Louisiana,

USA.

Sun, J., Zhang, B., Chen, Z., Lu, Y., Shi, C., Ma, W.,

2004. GE-CKO: A method to optimize composite

kernels for web page classification. In 2004

IEEE/WIC/ACM International Conference on Web

Intelligence (WI2004), Beijing, China.

Wang, Y., Oyama, K., 2006. Combining page group

structure and content for roughly filtering researchers’

homepages with high recall. IPSJ Transactions on

Databases, Vol.47, No. SIG 8 (TOD 30).

Yang, Y., Slattery, S., Ghani, R., 2002. A study of

approaches to hypertext categorization. Journal of

Intelligent Information Systems, volume 18. Kluwer

Academic Press.

Table 4: Estimated page numbers of classification output from a 100GB web page corpus.

baseline o-i-e-1_tag_real

Required quality

(precision / recall)

assured

positive

uncertain

)

assured

negative

assured

positive

uncertain

)

assured

negative

Reduction

ratio

)

99.5% / 98% 3,800 461,832 1,618,988 9,206 358,207 1,717,187 77.6%

99% / 95% 6,163 274,524 1,803,913 11,251 156,782 1,916,567 57.1%

98% / 90% 11,116 155,418 1,918,066 15,503 81,157 1,987,940 52.2%

WEB PAGE CLASSIFICATION CONSIDERING PAGE GROUP STRUCTURE FOR BUILDING A HIGH-QUALITY

HOMEPAGE COLLECTION

175
