APPLYING GAMES-BASED LEARNING TO TEACH

SOFTWARE ENGINEERING CONCEPTS

Thomas M. Connolly, Mark Stansfield and Tom Hainey

School of Computing, University of Paisley, High St, Paisley, PA1 2BE, Scotland

Keywords: Games-based learning, software engineering, pedagogical praxis.

Abstract: For some time now, computer games have played an important role in both children and adults’ leisure

activities. While there has been much written on the negative aspects of computer games, it has also been

recognised that they have potential advantages and benefits. There is no doubt that computer games can be

highly engaging and incorporate features that are extremely compelling. It is these highly engaging features

of computer games that have attracted the interests of educationalists. The use of games-based learning has

been growing for some years now, however, within software engineering there is still a dearth of empirical

evidence to support this approach. In this paper, we examine the literature on the use of computer games to

teach software engineering concepts and describe a computer game we have been developing to teach these

concepts.

1 INTRODUCTION

It is generally accepted that computer games are an

extremely motivating and engaging medium and

represent a new form of popular culture. There is

also a growing recognition of the potential benefits

that can be gained in using computer games within

teaching and learning, although there are still many

critics of this approach. We have been attempting to

use a games-based learning approach to support the

teaching of requirements collection and analysis

within a software engineering course in Higher

Education for some years now (Connolly et al.,

2004). Recently we have teamed up with a Scottish

games-based learning company to develop an

expanded version of the game for both the academic

and training communities. In this paper, we examine

the literature on the use of games-based learning

within software engineering and also examine some

of the issues underlying the teaching of the abstract

and complex domain of requirements collection and

analysis and, more generally, software engineering.

We then discuss the high-level requirements for our

game and provide an overview of the game play and

an outline subsystem design.

2 PREVIOUS RESEARCH

Software engineering has been described as a

“wicked problem”, characterized by incomplete,

contradictory and changing requirements, and

solutions that are often difficult to recognize as such

because of complex interdependencies (DeGrace &

Hulet Stahl, 1998). According to Armarego (2002),

there is an educational dilemma in teaching such

problems in software engineering because:

• complexity is added rather than reduced with

increased understanding of the problem;

• metacognitive strategies are fundamental to the

process;

• a rich background of knowledge and intuition

are needed for effective problem-solving;

• a breadth of experience is necessary so that

similarities and differences with past strategies

are used to deal with new situations.

Oh and Van der Hoek (2001) identify a number of

other issues that complicate the teaching of the

software process:

• Software development is non-linear: activities,

tasks and phases are repeated and multiple

events happen at the same time. Managing two

similar projects in the same way may not

produce the same outcome due to the presence

289

M. Connolly T., Stansﬁeld M. and Hainey T. (2007).

APPLYING GAMES-BASED LEARNING TO TEACH SOFTWARE ENGINEERING CONCEPTS.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Society, e-Business and e-Government /

e-Learning, pages 289-295

DOI: 10.5220/0001272702890295

 SciTePress

of several (possibly unexpected) factors (e.g.,

technical advances, client behaviours or

expectations).

• Software development involves several

intermediate steps and continuous choices

between multiple, viable alternatives: even with

careful planning, not all events that can occur

can be anticipated at the start of a project.

Difficult decisions must be made, tradeoffs

considered and conflicts handled.

• Software development may exhibit dramatic

effects with non-obvious causes: while software

development has several cause-and-effect

relationships (e.g., it is more cost-effective to

identify flaws in the earlier phases of

development than to identify them in the later

phases), there are other situations that may arise

in which the cause is not so apparent. For

example, Brook’s Law states that adding people

to a project that is already late typically makes

that project later.

• Software engineering involves multiple

stakeholders: clients and non-development

personnel in an organization all make decisions

that impact development.

• Software engineering often has multiple,

conflicting goals: software development

includes tradeoffs between such things as

quality versus cost, timeliness versus

thoroughness, or reliability versus performance.

Two further issues arise with teaching software

development that we are interested in taking into

consideration in any learning environment we

develop are:

• Communication: software engineers must be

able to communicate, both verbally and in

writing, with staff internal to the project (project

manager, team leaders, analysts, designers,

developers, testers, quality assurance) as well as

with external stakeholders.

• Pedagogical praxis: Shaffer (2004a) proposes a

theory of ‘pedagogical praxis’, which links

learning and doing within an extended

framework of communities of practice (Lave,

1991; Lave & Wenger, 1991). Pedagogical

praxis is based on the concept that different

professions (for example, lawyers, doctors,

software engineers) have different

epistemologies (epistemic frames) – different

ways of knowing, of deciding what is worth

knowing and of adding to the collective body of

knowledge and understanding. For a particular

community, the epistemic frames define

“knowing where to begin looking and asking

questions, knowing what constitutes appropriate

evidence to consider or information to assess,

knowing how to go about gathering that

evidence, and knowing when to draw a

conclusion and/or move on to a different issue”

(Shaffer, 2004b, pp. 4). Implementation of

pedagogical praxis requires a faithful recreation

of the professional community, one that is

“thickly authentic”; that is, one where (a)

learning is personally meaningful for the

learner, (b) learning relates to the real-world

outside the classroom, (c) learning provides an

opportunity to think in the modes of a particular

profession and (d) learning where the means of

assessment reflect the learning process (Shaffer

and Resnick, 1999). Connolly and Begg (2006)

have suggested that the term thickly authentic

be extended to incorporate: (e) learning using

the tools and practices of the modern-day

professional.

According to Schön (

1983, 1987) the following are

some of the key problems in teaching an abstract

subject of this nature:

• It is learnable but not didactically or

discursively teachable: it can be learned only in

and through practical operations.

• It is a holistic skill and parts cannot be learned

in isolation but by experiencing it in action.

• It depends upon the ability to recognize

desirable and undesirable qualities of the

discovered world. However, this recognition is

not something that can be described to learners,

instead it must be learned by doing.

• It is a creative process in which a designer

comes to see and do things in new ways.

Therefore, no prior description of it can take the

place of learning by doing.

Students often have considerable difficulty

comprehending implementation-independent issues

and analyzing problems where there is no single,

simple, well-known, or correct solution (Connolly

and Begg, 2006). They have difficulty handling

ambiguity and vagueness and they can also display

an inability to translate tutorial examples to other

domains with analogous scenarios, betraying a lack

of transferable analytical and problem-solving skills

(Connolly & Stansfield, in press). Kriz (2003)

highlights the point that the majority of students are

not competent enough to put their knowledge into

practice and they are unable to cope successfully

with the everyday tasks associated with the practice

of their chosen field. These problems can lead to

WEBIST 2007 - International Conference on Web Information Systems and Technologies

290

confusion, a lack of self-confidence and a lack of

motivation to continue.

Many of the above characteristics make teaching

requirements collection and analysis and, more

generally, the software development process,

problematic using didactic approaches to teaching

and learning and the practical experience provided

falls far short of what a student can expect “in the

real world”. Instead, these issues suggest that

students can only learn about software engineering

by doing software engineering and rely less on overt

lecturing and traditional teaching. This approach

requires a shift in the roles of both students and

teachers, with the student becoming an apprentice,

exploring and learning about the problem in the

presence of peers (who may know more or less

about the topic at hand) and the teacher moving from

being the “knowledgeable other” towards becoming

a facilitator, who manages the context and setting,

and assists students in developing an understanding

of the material at hand (Koehler & Mishra, 2005).

We advocate an alternative teaching paradigm

for software engineering based on constructivism.

Cognitive constructivism views learning as an active

process in which learners construct new ideas or

concepts based upon their current/past knowledge.

The learner selects and transforms information,

constructs hypotheses and makes decisions, relying

on a cognitive structure to do so (Piaget, 1968).

Social constructivism, seen as a variant of cognitive

constructivism, emphasizes that human intelligence

originates in our culture. Individual cognitive gain

occurs first in interaction with other people and in

the next phase within the individual (Forman &

McPhail, 1993). These two models are not mutually

exclusive but merely focus upon different aspects of

the learning process. In fact, Illeris (2003) believes

that all learning includes three dimensions, namely,

the cognitive dimension of knowledge and skills, the

emotional dimension of feelings and motivation, and

the social dimension of communication and

cooperation – “all of which are embedded in a

societally situated context”.

Figure 1 provides a representation of the

environment we will use as the basis for the

development of the games-based learning

application and the problems to be addressed.

3 THE SDSIM GAME

The development of the SDSim game is being

underpinned by Participatory Design principles with

users and other stakeholders playing a prominent

role in all the stages relating to design, development

and evaluation. The benefits of Participative Design

are that it can provide better project control, better

communication, more satisfied users and

participants, lessens the need for costly corrective

action post implementation and can provide more

innovative and creative solutions than might have

Knowledge &

Understanding

Software Engineering

Skills

Ill-defined

Changing Requirements

Multi-disciplinary

Complex

Ambi

uous

Eclectic

Experience

required

Knowledge & intuition

required

Peo

le-oriented

Problems

Holistic

Creative

Non-linear

Multiple conflicting

goals

Multiple stakeholders

Choice and tradeoff

required

Environment

constructivist

learning by doing practically-oriented

support social structures

(communication)

support development

of metacognition

pedagogical praxis

(ie “thickly authentic”)

support reflection

Figure 1: Environment for teaching software engineering (and problems that need to be addressed).

APPLYING GAMES-BASED LEARNING TO TEACH SOFTWARE ENGINEERING CONCEPTS

291

otherwise been possible (Kensing and Blomberg,

1998; Cherry and Macredie, 1999). To support the

design, development and evaluation of the game, it

was decided to establish a steering committee

comprising senior representatives from industry and

commerce, a number of academic representatives,

the project managers and the developers of the

game. By drawing upon the expertise and views of

senior managers from industry and commerce it is

hoped that the game will have a greater degree of

relevance and significance to a wider audience other

than students in higher education. In addition, it is

hoped the SDSim game will utilise and develop a

wider range of skills and knowledge that might be

transferable across a wider section of industry and

commerce. We now discuss the high-level objectives

of the game, the game play and then provide an

outline design of the game itself.

3.1 High-Level Objectives

The games-based learning environment should

provide a rich learning experience through the

creation of a range of project scenarios that will:

• Promote an engineering ethos that emphasizes

fitness for purpose as the guiding principle in

the design, development and assessment of

information systems and their components.

• Enable the learner to take a disciplined

approach to requirements collection and

analysis, and to the high level specification,

design and implementation of information

systems and their components.

• Enable the learner to handle complexity,

vagueness and ambiguity during the project.

• Enable the learner to develop a range of project

management skills.

• Assist the learner to develop analytical and

problem-solving skills and transferable skills.

• Assist the learner to develop the skills required

for both autonomous practice and team-

working.

• Assist the learner to develop reflection and

metacognitive strategies.

In discussion with the advisory group, the following

requirements were identified:

• The game will be targeted at both university

students in a computing-related subject and also

the professional training market.

• The game must support a number of players

carrying out different roles (for example,

analyst, developer, project manager) as well as a

facilitator. Communication between players

should be supported.

• The facilitator will be able to see what the

players are doing, will be able to intervene in

the game (for example, to modify the frequency

of new projects, to modify the number of people

assigned to a project) and will be able to call

team meetings to discuss issues that have arisen

in the team’s play.

• Ideally, in a team-based activity when a player

is not available the game (AI) should play that

role.

• The game must be scenario-based to allow the

players access to a range of project scenarios to

provide practical experience.

• The game must have a reasonably authentic

underlying business model to model clients,

projects, staff, suppliers and competitors. The

model should take cognisance of a range of

project variables such as project budget, time,

staff, staff specialisations, staff costs, resource

costs. These variables would be scenario-

specific.

• The game should run in an online environment.

• Game play should be recorded wherever

possible to support debriefing, post-game

analysis and evaluation.

3.2 Game Play

The basic idea of the game is for the team

(comprising one or more players) to manage and

deliver a number of software development projects.

Each player has a specific role, such as project

manager, systems analyst, systems designer or team

leader. A bank of scenarios have been created based

on case studies the authors have been using for many

years in teaching and learning; for example, the

DreamHome Estate Agency (Connolly & Begg,

2005), the StayHome Online DVD Rentals company

and the Perfect Pets Veterinary Clinic (Connolly &

Begg, 2002), the Blackwood Library and the Fair

Winds Marina (Connolly et. al., 2004). Each

scenario has an underlying business model; for

example, there will be a budget for the delivery of

the project, a set timescale for the delivery of the

project and a set of resources (for example, staff

with specified technical specilisations) that can be

used on the project. Additional resources can be

brought in for a project although this will have a cost

and timescale (delay) associated with it. The project

manager has overall responsibility for the delivery of

each project on budget and on time and is given a

short brief for each project. Communication is one

of the key aspects of the game and the project

WEBIST 2007 - International Conference on Web Information Systems and Technologies

292

manager must communicate relevant details of the

project to the other players. This will be done using

a message metaphor – any player can communicate

with any other player(s) by sending a message.

Players have a message board that indicates whether

there are any unread messages.

The player(s) assigned to the system analyst role

has to identify the requirements for the project. To

do this, the player must move through the game and

‘talk’ to the non-player characters (NPCs) in the

game, as illustrated in Figure 2. In addition, there are

objects in the game that can also convey relevant

information when found (for example, a filing

cabinet may convey requirements). For the prototype

game we are using written transcripts in place of

NPC speech. We hope shortly to use lip synching

within the game to have the NPCs ‘talk’ to the

system analyst. Each NPC’s ‘speech’ will contain

some general background details and a number of

requirements (the analyst has to distinguish the

requirements from the general details). Visiting the

same NPC may generate the same speech or a new

speech. Each speech will generate a transcript that

the analyst can visit at any point in the game. The

transcript is presented as a numbered list of

requirements. During the play, the analyst can use

the transcripts to produce an initial ‘wishlist’ of

requirements, which can be refined until such time

as the analyst believes all requirements have been

identified, at which point the analyst can send the

completed requirements to the project manager. The

project manager now has two choices: send the

Figure 2: Screen during requirements collection.

Figure 3: Internal subsystems of the SDSim game.

Game Server

Scenario

Builde

Scenario

Game AI

Visualization

User

Comms

subsyste

Business

Model

Postgame

Anal

sis

SDSim

Developers

Players

Facilitato

APPLYING GAMES-BASED LEARNING TO TEACH SOFTWARE ENGINEERING CONCEPTS

293

requirements to the designer to produce an outline

high-level design or consider the requirements to be

incorrect and ask the analyst to rework the

requirements (asking for rework will have a ‘cost’

associated with it).

During this period, the designer will be provided

with some background information relevant to the

design phase (for example, high-level components

that the company might have developed previously,

technical experience of the staff, technical resources

the designer has access to and software and

hardware that can be bought externally). Upon

receiving the requirements, the designer must

produce a high-level design that addresses the

clients’ requirements and must identify what will be

developed ‘in-house’ and what software/hardware

will be bought in. In addition, the designer must

provide some estimate of cost and timescale to

implement the system. Again, the design will go

back to the project manager to accept or reject (in

which case the design must be reworked by the

designer at ‘cost’).

The implementation phase is handled by the

team leader who is given a brief by the project

manager (high level design, available budget,

available staff). The team leader is responsible for

the delivery of the implementation phase. However,

during this period the team leader may have to

handle a number of planned events (such as staff

holidays) and unexpected events (such as staff

becoming ill, leave, and some activities taking

longer than planned). Some events the team leader

may be able to handle autonomously within the

remit provided; however, with others the team leader

may need to consult the project manager to seek a

solution.

The facilitator will have access to the game play and

will be able to intervene during the play. One

intervention is to call a (physical or virtual) team

meeting because of problems identified with the

running of the project. There are a number of other

interventions, such as changing the requirements

during the design or implementation phase, reducing

the number of staff available for the project, making

staff go off sick, making staff leave the company.

3.3 Game Design

The game is based on the traditional multi-

client/single-server architecture. The subsystem

design is shown in Figure 3:

• The Scenario Builder is an offline utility to

allow us to create and update the game

scenarios. These scenarios are stored in the

server-side database.

• The Postgame Analysis is a second offline

utility to allow us to provide data to the

facilitator on how the team has performed. The

utility will also provide us with data to evaluate

the impact of the game and to eventually

produce longitudinal analyses.

• The Game Server consists of four main

subsystems:

 The Comms subsystem, which allows

players to communicate with each other.

 The Visualisation/User Interface, which

handles what the players see on the screen

and what they can do.

 The Business Model, which implements

both the general business rules and the

business rules specific to each scenario.

This will be loosely based on the SESAM

model (Mandl-Striegnitz, 2001).

 The Game AI (Artificial Intelligence),

which implements ‘missing players’. At the

time of writing, this subsystem has not been

fully designed.

The input to date from the advisory group has been

extremely useful and has helped shape the design of

the game. We are currently implementing a

prototype of the game and an early version of the

fully system is due for completion in early 2007.

4 CONCLUSIONS

In this paper we have examined previous approaches

to the application of games-based learning to

software engineering and have found a significant

dearth of empirical research to support this

approach. Software engineering has been described

as a “wicked problem”, characterized by incomplete,

contradictory and changing requirements and

solutions that are often difficult to recognize as such

because of complex interdependencies. Other issues

that complicate the teaching of software engineering

are that software development is non-linear, it

involves several intermediate steps and choices

between multiple, viable alternatives, it may exhibit

dramatic effects with non-obvious causes and it

involves multiple stakeholders. Finally, we have

described the design of a new games-based learning

application aimed at the teaching of requirements

collection and analysis, design and project

management aimed at both the academic and

training markets. We consider evaluation to be key

to the entire development process and have adopted

a Participatory Design approach from the outset. In

the design of the game we have included a Postgame

WEBIST 2007 - International Conference on Web Information Systems and Technologies

294

Analysis utility to support the collection of empirical

evidence on the use of this game.

ACKNOWLEDGEMENTS

The authors would like to acknowledge the Scottish

Executive for their support of this work and TPLD

for their collaboration.

REFERENCES

Armarego, J. 2002. Advanced Software Design: A Case in

Problem-Based Learning. Proceedings of the 15th

Conference on Software Engineering Education and

Training, 25–27 February 2002, Covington, Kentucky,

USA, pp. 44–54.

Cherry, C. and Macredie, R.D. 1999. The importance of

context within information system design: an

assessment of participative design, Requirements

Engineering, 4: 103-114.

Connolly, T.M. & Begg, C.E 2006. A constructivist-based

approach to teaching database analysis and design.

Journal of Information Systems Education, 17(1): 43-

54.

Connolly, T.M. & Begg, C.E 2005. Database Systems: A

practical approach to design, implementation, and

management, 4

edition. Addison Wesley Longman:

England.

Connolly, T.M. & Begg, C.E 2002. Database Solutions: A

step-by-step approach to building databases, 2

edition. Addison Wesley Longman: England.

Connolly, T.M., McLellan, E., Stansfield, M.H., Ramsay

J. & Sutherland J. 2004. Applying Computer Games

Concepts to Teaching Database Analysis and Design.

International Conference on Computer Games, AI,

Design and Education, Reading, UK, November 2004.

Connolly, T.M. & Stansfield, M.H. in press. From

eLearning to games-based eLearning: using interactive

technologies in teaching an IS course. International

Journal of Information Technology and Management.

DeGrace, P. & Hulet Stahl, L. 1998. Wicked Problems,

Righteous Solutions: A Catalog of Modern

Engineering Paradigms, Prentice Hall.

Forman, E. & McPhail, J. 1993. Vygotskian perspectives

on children’s collaborative problem-solving activities.

(In Forman, E.A., Minick, N. & C. Addison Stone

(eds), Contexts for learning. Sociocultural dynamics in

children’s development, Oxford University Press,

Oxford).

Illeris, K. 2003. Towards a contemporary and

comprehensive theory of learning. International

Journal of Lifelong Learning, 22(4): 396-406.

Kensing, F. & Blomberg, J. 1998. Participatory design:

issues and concerns. Computer Supported Cooperative

Work, 7: 167-185.

Koehler, M.J. & Mishra, P. 2005. Teachers Learning

Technology by Design. Journal of Computing in

Teacher Education, 21(3), Spring 2005.

Kriz, W.C. 2003. Creating effective learning environments

and learning organizations through gaming simulation

design. Simulation and Gaming, 34(4): 495–511.

Lave, J. 1991. Situating learning in communities of

practice. Washington, DC: American Psychological

Association.

Lave, J. & Wenger, E. 1991. Situated learning: Legitimate

peripheral participation, Cambridge University Press,

Cambridge, England.

Oh, E. & Van der Hoek, A. 2001. Adapting Game

Technology to Support Individual and Organizational

Learning. Proceedings of the 13th International

Conference on Software Engineering and Knowledge

Engineering, Buenos Aires, Argentina, June 2001.

Piaget, J. 1968. Six Psychological Studies. Vintage Books,

New York.

Schön, D.A. 1983. The Reflective Practitioner: How

Professionals Think in Action. Basic Books, New

York.

Schön, D.A. 1987. Educating the Reflective Practitioner:

Towards a New Design for Teaching in the

Professions. Jossey-Bass Inc., San Fransisco.

Shaffer, D.W. 2004a. Pedagogical Praxis: The Professions

as Models for Postindustrial Education. The Teachers

College Record, 106(7): 1401–1421.

Shaffer, D.W. 2004b. Epistemic frames and islands of

expertise: Learning from infusion experiences. In

Proceedings

International Conference of the Learning

Sciences, Santa Monica, CA. Retrieved 28 July 2005,

from http://www.education.wisc.edu/edpsych/facstaff/

dws/papers/epistemicframesicls04.pdf.

Shaffer, D.W. & Resnick, M. 1999. Thick authenticity:

New media and authentic learning. Journal of

Interactive Learning Research, 10(2): 195–215.

APPLYING GAMES-BASED LEARNING TO TEACH SOFTWARE ENGINEERING CONCEPTS

295
