SUPPORTING EFFECTIVE AND USEFUL WEB-BASED

DISTANCE LEARNING

Santi Caballé, Thanasis Daradoumis

Department of Computer Science, Multimedia, and Telecommunication, Open University of Catalonia

Rbla. Poblenou, 156, 08018, Barcelona, Spain

Fatos Xhafa, Joan Esteve

Department of Languages and Informatics Systems and Computing Laboratory, Faculty of Informatics of Barcelona

Polytechnic University of Catalonia, Jordi Girona 1-3, 08034 Barcelona, Spain

Keywords: Web-based Education, User Modelling, Grid Computing, Distributed and Parallel Applications.

Abstract: Learners interacting in a Web-based distance learning environment produce a variety of information

elements during their participation; these information elements usually have a complex structure and

semantics, which makes it rather difficult to find out the behavioural attitudes and profiles of the users

involved. User modelling in on-line distance learning is an important research field focusing on two

important aspects: describing and predicting students’ actions and intentions as well as adapting the learning

process to students’ features, habits, interests, preferences, and so on. This work provides an approach that

can be used to greatly stimulate and improve the learning experience by tracking the students’ intentions

and helping them reconduct their actions that could evolve accordingly as the learning process moves

forward. In this context, user modelling implies a constant processing and analysis of user interaction data

during long-term learning activities, which produces large and considerably complex information. In this

paper we show how a Grid approach can considerably decrease the time of processing log data. Our

prototype is based on the master-worker paradigm and is implemented using a peer-to-peer platform called

Juxtacat running on the Planetlab nodes. The results of our study show the feasibility of using Grid

middleware to speed and scale up the processing of log data and thus achieve an efficient and dynamic user

modelling in on-line distance learning.

1 INTRODUCTION

Online learning constitutes a complex task both as

regards its utility and its capability to reach an

effective and useful learning. The more and more

frequent employment of constructive learning

requires the support and use of modern educational

tools that allow learners to be aware of their own

knowledge-building activities and other learners’

collaboration in order to achieve effective learning

and performance (Horton, 2000).

Information and communication technologies

have shown a significant advance and fast progress

as regards performance and usability. At the same

time, new educational needs demand more

innovative ways to work, collaborate, and learn.

These aspects justify the grown interest and

development of technology for knowledge

management, mobility and conceptual awareness in

the area of distributed collaborative work and

learning (Begole et al., 2002).

As a consequence of the complex processes

involved in learning, we need to capture all and each

type of possible data gathered in log files. However,

the information generated in web-based learning

applications can be of a great variety of type and

formats (Xhafa et al., 2004). Moreover, these

applications are characterized by a high degree of

user-user and user-system interaction which stresses

the amount of interaction data generated. Therefore,

there is a strong need for powerful solutions that

record the large volume of interaction data and can

be used to perform an efficient interaction analysis

and knowledge extraction.

536

Caballé S., Daradoumis T., Xhafa F. and Esteve J. (2007).

SUPPORTING EFFECTIVE AND USEFUL WEB-BASED DISTANCE LEARNING.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Society, e-Business and e-Government /

e-Learning, pages 536-539

DOI: 10.5220/0001284105360539

 SciTePress

As a matter of fact, the computational cost is the

main obstacle to processing data in real time. Hence,

in real learning situations, this processing tends to be

done offline so as to avoid harming the performance

of the logging application, but as it takes place after

the completion of the learning activity has less

impact on it (Caballé et al., 2005).

Based on the Grid vision (Foster and Kesselman,

1998), a preliminary study was conducted (Xhafa et

al., 2004). This study showed that a parallel

approach based on the Master-Worker (MW)

paradigm might increase the efficiency of processing

a large amount of information from user activity log

files (for more information about MW, please follow

the link: http://www.cs.wisc.edu/condor/mw).

In this paper we show, first, the main challenges

to be faced in modelling students’ behaviour in

Web-based learning environments, and, then, how a

Grid-based approach can deal with them. In order to

show the feasibility of our approach, we use the log

data from the internal campus of the Open

University of Catalonia (the UOC is found at:

http://www.uoc.edu), though our approach is generic

and can be applied for reducing the processing time

of log data from web-based applications in general.

Our ultimate objective is to make it possible to

continuously monitor and adapt the learning process

and objects to the actual students’ learning needs as

well as to validate the campus’ usability by

analyzing and evaluating its actual usage.

2 MODELING STUDENTS’

BEHAVIOR IN WEB-BASED

DISTANCE LEARNING

Our real web-based learning context is the Open

University of Catalonia (UOC), which offers

distance education through the Internet in different

languages. As of this writing, about 40,000 students,

lecturers, and tutors from everywhere participate in

some of the 23 official degrees and other PhD and

post-graduate programs, resulting in more than 600

official courses. The campus is completely

virtualized. It is made up of individual and

community areas (e.g. personal electronic mailbox,

virtual classrooms, digital library, on-line bars,

virtual administration offices, etc.), through which

users are continuously browsing in order to fully

satisfy their learning, teaching, administrative and

social needs.

From our experience at the UOC, the description

and prediction of our students’ behaviour and

navigation patterns when interacting with the

campus is a first issue. Indeed, a well-designed

system’s usability is a key point to stimulate and

satisfy the students’ learning experience. In addition,

the monitoring and evaluation of real, long-term,

complex, problem-solving situations is a must in our

context. The aim is both to adapt the learning

process and objects to the actual students’ learning

needs as well as to validate the campus’ usability by

monitoring and evaluating its actual usage.

In order to achieve these goals, the analysis of

the campus activity and specifically the users' traces

captured while browsing the campus is essential in

this context. The collection of this information in log

files and the later analysis and interpretations of this

information provide the means to model the actual

user's behaviour and activity patterns.

2.1 The Collection of Information from

On-line Learning Activity

The on-line web-based campus of the UOC is made

up of individual and community virtual areas such as

mailbox, agenda, classrooms, library, secretary's

office, and so on. Students and other users (lecturers,

tutors, administrative staff, etc.) continuously

browse these areas where they request for services to

satisfy their particular needs and interests. For

instance, students make strong use of email service

so as to communicate with other students and

lecturers as part of their learning process.

All users' requests are chiefly processed by a

collection of Apache web servers as well as database

servers (Apache is found at:

http://httpd.apache.org)

and other secondary applications, all of which

provide service to the whole community and thus

satisfy a great deal of users’ requests. For load

balance purposes, all HTTP traffic is smartly

distributed among the different Apache web servers

available. Each web server stores in a log file all

users’ requests received in this specific server as

well as the information generated from processing

the requests. Once a day (namely, at 01:00 a.m.), all

web servers in a daily rotation merge their logs

producing a single very large log file containing the

whole user interaction with the campus performed in

the last 24 hours.

A typical daily log file size may be up to 10 GB.

This great amount of information is first pre-

processed using filtering techniques in order to

remove a lot of futile, non relevant information (e.g.

information coming from automatic control

processes, the uploading of graphical and format

elements, etc.). However, after this pre-processing,

SUPPORTING EFFECTIVE AND USEFUL WEB-BASED DISTANCE LEARNING

537

about 1.8 GB of potentially useful information

corresponding to 3,500,000 of log entries in average

still remains (Carbó at al., 2005).

For the purpose of registering the campus

activity, log files entries were set up with the

purpose of capturing the following information: who

performed a request (i.e. user’s IP address along

with a session key that uniquely identifies a user

session); when the request was processed (i.e.

timestamp); what type of service was requested (a

URL string format description of the server

application providing the service requested along

with the input values) and where (i.e. an absolute

URL containing the full path to the server

application providing the service requested).

At this point, we point out some problems arisen

by dealing with these log files. Each explicit user

request generates al least an entry in the log file and

after being processed by a web server, other log

entries are generated from the response of this user

request; certain non-trivial requests (e.g. user login)

involve in turn requesting others and hence they may

implicitly trigger new log entries; the what and

where fields contain very similar information

regarding the URL strings that describe the service

requested and the parameters with the input values;

certain information is found in a very primitive form

and is represented as long text strings (e.g. user

session key is a long 128-character string).

Therefore, there is a high degree of redundancy,

tedious and ill-formatted information as well as

incomplete as at some cases certain user actions do

not generate any log entry (e.g. user may leave the

campus by either closing or readdressing the

browser) and have to be inferred. As a consequence,

treating this information is very costly in terms of

time and space needing a great processing effort.

3 AN EFFICIENT PROCESSING

OF LOG DATA

In order to deal with the above mentioned problems

and inconvenients, we have developed a simple

application in Java, called UOCLogsProcessing that

processes log files of the UOC. In particular, this

application runs offline on the same machine as the

logging application server. It uses, as an input, the

daily log files obtained as a result of merging all

web servers’ log files. The following process is run:

(i) identify the log entries boundaries and extract the

fields that make up each entry, (ii) capture the

specific information contained in the fields about

users, time, sessions, areas, etc., (iii) infer the

missing information, (iv) map the information

obtained to typed data structures, and (v) store these

data structures in a persistent support.

However, as the processing is done sequentially,

it takes too long to complete the work and it has to

be done after the completion of the learning activity,

which makes the construction of effective real-time

user models not possible.

3.1 Juxta-CAT: a JXTA-based Grid

Platform

In this section, we briefly introduce the main aspects

of the grid platform, called Juxta-CAT (Esteve and

Xhafa, 2006), which we have used for parallelizing

the processing of log files.

The Juxta-CAT platform has been developed

using the JXTA protocols and offers a shared Grid

where client peers can submit their tasks in the form

of java programs stored on signed jar files and are

remotely solved on the nodes of the platform (JXTA

web page is found at: http://www.jxta.org). The

architecture of Juxta-CAT platform is made up of

two types of peers: common client peers and broker

peers. The former can create and submit their

requests using a GUI-based application while the

later are the administrators of the Grid, which are in

charge of efficiently assigning client requests to the

Grid nodes and notify the results to the owner's

requests. To assure an efficient use of resources,

brokers use an allocation algorithm, which can be

viewed as a price-based economic model, to

determine the best candidate node to process each

new received petition.

The Juxta-CAT platform has been deployed in a

large-scale, distributed and heterogeneous P2P

network using nodes from PlanetLab platform

(PlanetLab web page is found at http://www.planet-

lab.org). At the time of this writing, PlanetLab’s

node distribution is: 715 nodes over 338 sites

(Polytechnic University of Catalonia has joined

PlanetLab with several proper nodes). Juxta-CAT

Project and its official web site have been hosted in

Java.NET community (please see the following link:

https://juxtacat.dev.java.net).

3.2 Experimental Results

We present, in this section, the main experimental

results obtained for a test battery in order to measure

the efficiency obtained by the grid processing. This

battery test uses both large amounts of log

information (i.e. daily log files) and well-stratified

short samples consisting of representative daily

periods with different activity degrees (e.g. from 7

WEBIST 2007 - International Conference on Web Information Systems and Technologies

538

p.m. to 1 a.m. as the most active lecturing period and

from 1 a.m. to 7 a.m. as the period with least activity

in the campus). On the other hand, other tests

involved a few log files with selected file size

forming a sample of each representative stratum.

This allowed us to obtain reliable statistical results

using an input data size easy to use.

The battery test was processed by the

UOCLogsProcessing application executed on single-

processor machines involving usual configurations.

The battery test was executed several times with

different workload in order to have more reliable

results in statistical terms involving file size, number

of log entries processed and execution time along

with other basic statistics. On the other hand, the

same battery test was processed by Juxta-CAT using

different number of nodes, specifically, 2, 4, 8, and

16 nodes, using PlanetLab nodes. A sample of the

results is shown in Figure 1, while Table 1 shows the

gain in parallel speed-up and efficiency we achieved

Figure 1: An execution time result for log files with sizes

of 36MB; x-axis indicates the number of processors and y-

axis the processing time (mm:ss).

Table 1: Parallel speed-up and efficiency.

Log file size Speed-up Efficiency

12 MB 6.1 38.2 %

24 MB 7.4 46,2 %

36 MB 9.1 56.8 %

4 CONCLUSIONS AND

FURTHER WORK

In this paper, we have shown how to model the

learner's behaviour and activity pattern by using user

modelling tracking-based techniques. However, the

information generated from tracking the learners

when interacting with the virtual learning

environment is usually very large, tedious,

redundant and ill-formatted and as a result

processing this information is time-consuming. In

order to overcome this problem, in this paper we

have proposed a Grid-aware implementation that

considerably reduces the processing time of log data

and makes it possible to build and constantly

maintain user models, even in real time. For the

purposes of both showing the problem of dealing

with log data and testing our grid prototype we have

described and used the log data coming from the

virtual campus of the Open University of Catalonia.

Further work will include the implementation of a

more thorough mining process of the log files, which

due to the nature of the log files of our virtual

campus will require more processing time in

comparison to the log processor used in this work.

ACKNOWLEDGEMENTS

This work has been partially supported by the

Spanish MCYT project TSI2005-08225-C07-05.

REFERENCES

Begole, J.; Tang, J.; Smith, R.; Yankelovich, N., 2002.

Work rhythms: analyzing visualizations of awareness

histories of distributed groups. Computer Supported

Cooperative Work; In proceedings of the 2002 ACM

conference on Computer Supported Cooperative

Work, p 334 - 343; New Orleans, Louisiana, USA.

Caballé, S., Paniagua, C., Xhafa, F., and Daradoumis, Th.,

2005. A Grid-aware Implementation for Providing

Effective Feedback to On-line Learning Groups. In:

proc. of the GADA'05, Cyprus.

Carbó, JM., Mor, E., Minguillón, J., 2005. User

Navigational Behavior in e-Learning Virtual

Environments. The 2005 IEEE/WIC/ACM

International Conference on Web Intelligence’05, pp.

243-249.

Esteve J., Xhafa F., 2006. Juxta-CAT: A JXTA-based

Platform for Distributed Computing. The ACM

International Conference on Principles and Practice

of Programming in Java’06.

Foster, I. and Kesselman, C., 1998. The Grid: Blueprint

for a Future Computing Infrastructure. pp. 15-52.

Morgan Kaufmann, San Francisco, CA.

Horton, W., 2000. Designing Web-Based Training. Ed.

Wiley, New York.

Xhafa, F., Caballé, S., Daradoumis, Th. and Zhou, N.,

2004. A Grid-Based Approach for Processing Group

Activity Log Files. In: proc. of the GADA'04, Cyprus.

SUPPORTING EFFECTIVE AND USEFUL WEB-BASED DISTANCE LEARNING

539
