THE EFFECT OF PACKET LOSS ON

THE RESPONSE TIMES OF WEB SERVICES

Johan Garcia, Per Hurtig and Anna Brunstrom

Department of Computer Science, Karlstad University

Universitetsgatan 2, SE-651 88 Karlstad, Sweden

Keywords:

Web services, performance evaluation, TCP, loss recovery, emulation

Abstract:

Web services have today become an important technology for information exchange over the Internet. Al-

though web services are designed to support interoperable machine-to-machine interaction, humans are often

the ﬁnal recipients of the produced information. This makes the performance of web services important from

a user perspective. In this paper we present a comprehensive experimental evaluation on the response times of

web services. The limited amount of data transfered in a typical web service message makes its performance

sensitive to packet loss in the network and we focus our investigation on this issue. Using a web service re-

sponse time model, we evaluate the performance of two typical web services over a wide range of network

delays and packet loss patterns. The experiments are based on network emulation and two real protocol im-

plementations are examined. The experimental results indicate that a single packet loss may more than double

the response times of the evaluated services and lead to noticeable delays for the end user. We brieﬂy review

previous solutions that can be applied to improve performance and outline an improved approach that is based

on packet loss detection at the receiver.

1 INTRODUCTION

The use of web services (Booth et al., 2004) is con-

tinuously expanding, not only as a means to realize

distributed computing inside an organization but also

as a freely available public service. More and more

web sites provide services to the user that are based

on the underlying use of web services. The ﬂexibil-

ity of the web services architecture allows web ser-

vices to be combined to create new end-user services.

When web services are used in a context where hu-

mans are involved as ﬁnal recipients of information,

the response time of the web service is important as it

directly affects the user experience. In this paper we

present a thorough examination of the response times

of web services as a function of packet loss and trans-

port layer behaviour.

Web services use higher layer protocols such

as SOAP (World Wide Web Consortium (W3C),

2003) and HTTP (Fielding et al., 1999) to trans-

fer messages between clients and servers. On the

transport layer these messages are transported by

TCP (Postel, 1981). TCP provides reliable ordered

delivery, and also protects the network from overload

by virtue of its congestion control mechanisms. The

congestion control is imperative in todays Internet as

it performs the arbitration between competing ﬂows

to ensure that the ﬂows get a reasonably fair fraction

of the bandwidth while at the same time protecting

the network from overload and congestion collapse.

TCP’s congestion control is centered around the use

of packet loss as a signal that congestion is occurring.

Since the congestion control uses losses as congestion

markers, the congestion control also becomes inter-

twined with TCP’s reliability mechanisms.

With regards to web services, the small data sizes

in this request/response type oftrafﬁcleads to reduced

efﬁciency for the congestion control and reliability

mechanisms. Since the data sizes are so small, these

mechanisms often cannot work in the most efﬁcient

manner and are to a large extent inﬂuenced by conser-

vative default estimations of the network conditions.

The effect of these efﬁciency problems on the web

services response times are examined in this work

275

Garcia J., Hurtig P. and Brunstrom A. (2007).

THE EFFECT OF PACKET LOSS ON THE RESPONSE TIMES OF WEB SERVICES.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Internet Technology, pages 275-283

DOI: 10.5220/0001285202750283

 SciTePress

by means of comprehensive emulation-based exper-

iments on real protocol implementations.

The results show that losses at the end of a con-

nection increase the response times of web services

with perceptible amounts in practically all cases, with

some conﬁgurations resulting in response time in-

creases larger than 1,7 seconds.

This paper is structured as follows. In the next

section some background on web services and TCP is

provided. Then follows a section describing the ex-

perimental setup and results. The next section pro-

vides a discussion of possible solutions to the prob-

lems evident in the results, and lastly the conclusions

are provided.

2 BACKGROUND

2.1 Web Services Background

Web services can be seen as a means to enable dis-

tributed computing. In this respect it shares some

of the goals of technologies such as CORBA (Object

Management Group, 2004), RPC (Srinivasan, 1995)

and Java RMI (Sun Microsystems, Inc., 2004). Web

services strive to enable remote execution with a min-

imum of interdependency between the parties. One

way of accomplishing this is by the use of open, plat-

form neutral technologies such as HTTP, SOAP and

XML (Bray et al., 2006). Although web service mes-

sages are typically exchanged between program pro-

cesses without direct involvement of the users in the

web service transaction, a human user is often the ini-

tiator of the action that causes the web service trans-

fer to take place. A human user is often also the end

consumer of the information resulting more or less

indirectly from the web service transaction. In or-

der to minimize the user discomfort caused by having

to wait before receiving any feedback, the response

times of web services are an important component.

Furthermore, the spreading of techniques such as

web services mashups (Lerner, 2006) further high-

lights the delay characteristics. Mashups are compo-

sitions of two or more web services and are typically

intended for direct end-user usage. The more web ser-

vice transactions that are involved in one user interac-

tion, the higher the risk that at least one transaction

will be subject to a packet loss with a resulting unde-

sirable increase in response time. The response time

of a web service can be subdivided into smaller com-

ponents. One subdivision can be made between pro-

cessing delays and network delays. Processing delays

are a function of the processing needed at the client

and server to create messages, parse messages and do

the actual execution. Network delays are caused by

the delays inherent in transferring the requests and re-

sponses between the client and server. In this paper,

the focus is on the network delays, and how they are

affected in the presence of loss.

2.2 Transport Layer Background

TCP is the transport layer protocol used by web ser-

vices. While the original TCP has been existing for

over 30 years, it has continuously been updated, and

continues to be updated, to address new challenges

caused by the evolving communications technology.

In the context of this study, the most relevant aspects

of TCP functionality is the reliability and congestion

control mechanisms as those are related to how TCP

handles losses. A TCP sender has two mechanisms to

detect losses, fast retransmit and timeout.

Fast retransmit (Allman et al., 1999) occurs when

the sender receives three duplicate acknowledge-

ments. The duplicate acknowledgements are sent by

the receiver when it receives packets out-of-order.

The reason for an out-of-order packet is either that

packets have been reordered in the network, or that a

packet has been lost in the network, causing all the

following packets to be out-of-order. The fast retrans-

mit threshold of three was set as a trade-off between

having the sender mistakenly treat reordered pack-

ets as lost, and the delay before retransmission of a

packet that has been lost.

Timeouts occur when the TCP sender has not re-

ceived an acknowledgement for a certain period of

time. In order to avoid having retransmissions for

packets that are not lost but merely delayed in the net-

work, the timeout value is conservatively calculated

as a function of the round-trip time as measured by the

the returning acknowledgments. So, for the timeout

case the trade-off is between having a short enough

timeout that detects losses without unnecessary delay,

but not so short as to induce unnecessary retransmis-

sions when the packet is not lost but delayed.

Out of the two described loss detection mecha-

nisms, fast retransmit is the most desirable as it will

lead to faster loss detection in practically all cases

However, there are cases when fast retransmit cannot

be used, and one important case in the web services

context is at the end of connections. If there are too

few packets to send after a loss, the receiver will not

be able to generate the required number of duplicate

acknowledgements. For the short connections typical

in web services, this sensitive period late in the con-

Fast retransmit also has a gentler congestion response

than timeout, but in the present study this has practically no

effect since the examined web service transfers are so short.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

276

nection is large in relation to the overall transfer. A

detailed examination of how this impacts the web ser-

vices response times is provided in the next section.

3 EXPERIMENTAL EVALUATION

As mentioned in the previous section, packet loss

plays an important role in the congestion control as

well as for the reliability mechanisms. In order to

study the effect of loss handling and congestion con-

trol on web services response times we have per-

formed a comprehensive experimental campaign us-

ing real protocol implementations in an emulated en-

vironment.

3.1 Response Time Model

The web services response time can be divided into

several components. We make a division as shown in

Equation 1.

= t

conn

+ t

req

+ p

req_resp

+ t

resp

(1)

The total response time r

is in this model com-

posed of the TCP connection setup (t

conn

), the re-

quest transmission delay (t

req

), the server-side pro-

cessing delay for request parsing and response gener-

ation (p

req_resp

), and the response transmission de-

lay (t

resp

). In addition to these delays, there can also

be delays at the client side to compose the request

message and to parse the response message, respec-

tively. These delays are dependent on the speciﬁc

client hardware and the software implementation used

in the client, and are not considered in this study.

3.2 Experimental Setup

The experimental setup consists of three PCs with the

roles of client, server and router/emulator. The client

and server communicates via the router/emulator

which delays and drops packets as instructed. The

experimental setup is illustrated in Figure 1. The

client and server machines host programs that create

requests and responses similar to web service clients

and servers respectively. Since this examination has

packet losses as one important variable, a specially

modiﬁed version of the Dummynet emulator (Rizzo,

1997) named KauNet is used. KauNet allows precise

control over packet losses, delays, and bandwidths

with the possibility to specify these on a per packet

basis using precomputed patterns. The ability to pre-

cisely position losses has been shown to be beneﬁcial

Control

Script

TCPdump

Ethernet

TCP

TCPdump

Ethernet

TCP

= Control path

= Data path

Router/Emulator

100Mbps

Client Server

100Mbps

P4−2.4GHzP4−2.4GHz

Dummynet

P4−2.4GHz

FreeBSD 6.0 FreeBSD / LinuxFreeBSD / Linux

W.S. Client W.S. Server

Figure 1: Physical experiment setup.

when performing protocol evaluations (Garcia et al.,

2006).

To guide the conﬁguration of the various experi-

mental parameters, values from a study by Kim and

Rosu (2004) were used. In their study they survey the

length and and response times of a well known web

services provider, Amazon. From the data provided

by Kim and Rosu (2004) we selected two web ser-

vices to use as models for our experiments. The ﬁrst

service was the Author service, which had a request

size of 1438 bytes and a response size of 12974 bytes.

The second service was the Sellerproﬁle which had

a request size of 1283 bytes and a response size of

8031 bytes. Based on the response times reported

by Kim and Rosu (2004) a p

req_resp

of 200 ms was

found to be appropriate.

The transfer of the web service requests and re-

sponses are performed by the transmission of TCP

packets. Two components are used to create the emu-

lated network delay that each packet is to be exposed

to. By using two components it is possible to model

packet delays that are size-dependent as well as size-

independent. The size-dependent delays are mainly

the transmission delays that occur at each network

node. The size-dependent delays are aggregated and

modeled as an effective bandwidth for the emulation.

The second component of network delay is composed

of delays that are independent of packet size such as

propagation and queueing delays. The aggregate of

the packet size independent delays, called end-to-end

delay, were inserted using the delay pattern capabili-

ties of KauNet. Each packet had a unique end-to-end

delay that was drawn from a normal distribution with

a mean according to the conﬁgured value, and a vari-

THE EFFECT OF PACKET LOSS ON THE RESPONSE TIMES OF WEB SERVICES

277

Table 1: Experimental Parameters.

Request size (bytes) 1438 1283

Response size (bytes) 12974 8031

req_resp

(ms) 200

Effective bandwidth 160, 300, 500, 1000

(Kbit/s)

2000, 4000, 10000

End-to-end delay 5, 10, 20, 40

(ms)

60, 100, 150, 200

ance of 50 percent of the mean.

In order to get an indication of how issues spe-

ciﬁc to the particular TCP implementation affects the

web services response times, we performed experi-

ments with two different operating systems, FreeBSD

6.0 and Linux 2.6.15. These operating systems are

commonly used in servers providing web services. A

summary of the experimental parameters is provided

in Table 1.

3.3 FreeBSD Results for Author

To examine the comprehensive results obtained from

the emulation experiments, we start with a repre-

sentative example of a single experimental run for

FreeBSD 6.0 as shown in Figure 2. The ﬁgure shows

the response time as a function of where in the con-

nection the packet loss occurs. The y-axis shows

the total web service response time according to the

model above, including a p

req_resp

of 200 ms. The

x-axis represents the different loss positions possible

for the data transfer in the server-to-client direction.

With a response size of 12974 bytes and a maximum

transfer unit (MTU) of 1500 bytes, this means that 12

packets are transfered

in the server-to-client direc-

tion. Loss position 0 corresponds to no packet loss

and thus has the lowest response time. Similarly, a

loss at position 12 also has a low response time since

that packet is the ﬁnal FIN-ACK required to close the

connection in the opposite client-to-server direction,

and a loss of this packet does not delay the transfer of

data in the server-to-client direction.

The speciﬁc combination of effective bandwidth

and end-to-end delay displayed in Figure 2 was cho-

sen to provide approximately the same lossless re-

sponse time as the one reported by Kim and Rosu

(2004) for the case when both the client and the server

were located in the US (the US-US scenario). The re-

ported response time was 502 ms, and the experimen-

tal value was 610 ms (without losses). It can be seen

This includes the SYN-ACK packet necessary for TCP

connection establishment and the ﬁnal FIN-ACK packet for

connection termination.

that losing the packet in loss position 1 increases the

response time with 3 seconds. This is expected as the

timeout value used during connection establishment

is set to this conservative value (Paxson and Allman,

2000). In the middle of the connection (positions 2-

7) the penalty of a loss is relatively small, as the loss

can be detected using the more efﬁcient fast retrans-

mit mechanism. Losses later in the connection (posi-

tions 8-11) result in larger increases in response times

since they cannot be handled by fast retransmit, but

instead have to be recovered using the slower timeout

mechanism. In the speciﬁc case shown in the ﬁgure,

the response time increase from having a loss late in

the connection as opposed to the middle of the con-

nection is up to 632 ms, or 103 percent

. The web

service transactions that experience losses at the end

of the connection are thus delayed for periods that are

clearly large enough to be negatively perceived.

Figure 3 shows the results for a connection with

the same effective bandwidth but a longer end-to-end

delay to model the connection between an overseas

client and a server in the US (the US-overseas sce-

nario). The resulting response time without loss is

886 ms. The effect of losses late in the connection

shown in Figure 3 is larger in absolute terms (929 ms),

but smaller in relative terms (99 %) as compared to

Figure 2. This of course comes from the fact that the

response time with no losses becomes considerably

longer when the end-to-end delay is increased.

In addition to the results shown in Figures 2 and

3, we conducted experiments for 54 other combina-

tions of end-to-end delay and bandwidth according to

values given in Table 1. To illustrate how the results

vary as the end-to-end delay varies, Figure 4 shows

the results for a bandwidth of 1000 Kbps, covering all

the different delays. To provide an overview of all re-

sults, Figure 5 shows the relative impact of all results

by calculating the percent-wise increase in response

time for losses at the end of a connection. The re-

ported value is calculated as the percent-wise increase

of the mean response times of positions 8-11 over the

response time for position 6.

3.4 Linux Results for Author

To examine the possible variations between differ-

ent TCP implementations we also performed experi-

ments using Linux. The same graphs as discussed for

FreeBSD in the previous section are shown in Figures

6 to 9. These ﬁgures show that Linux has the same

trend of increased response times for losses in the end

of the connection that was visible for FreeBSD. This

This is when comparing the response times for loss po-

sitions 6 and 10.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

278

500

1000

1500

2000

2500

3000

3500

4000

0 2 4 6 8 10 12

Response time (ms)

Loss position

300Kbps - 10ms

Figure 2: One FreeBSD run for US-US scenario, Author

service.

500

1000

1500

2000

2500

3000

3500

4000

0 2 4 6 8 10 12

Response time (ms)

Loss position

300Kbps - 60ms

Figure 3: One FreeBSD run for US-overseas scenario, Au-

thor service.

1000

2000

3000

4000

5000

6000

0 2 4 6 8 10 12

Response time (ms)

Loss position

1000Kbps

5 ms

10 ms

20 ms

40 ms

60 ms

100 ms

150 ms

200 ms

Figure 4: Impact of different delays for FreeBSD with 1000

Kbps bandwidth, Author service.

100

0 50 100 150 200

Additional time required (%)

End-to-end delay (ms)

Response time increase

160Kbit/s

300Kbit/s

500Kbit/s

1000Kbit/s

2000Kbit/s

4000Kbit/s

10000Kbit/s

Figure 5: Free BSD response time increase for late losses,

Author service.

is to be expected since the problem is inherent in the

deﬁnition of TCP’s reliability mechanisms. Although

the trend is similar, there are some differences be-

tween the implementations. Looking at the response

times without losses Linux is slower than FreeBSD

for both of the end-to-end delays shown in Figures

6 and 7, with 661 ms versus 610 ms for the 10 ms

end-to-end delay and 933 ms versus 886 ms for the

60 ms end-to-end delay. However, when looking at

the behavior for losses at the end of the connection,

it can be seen that FreeBSD actually has a sensitive

region of four packets (positions 8-11) where Linux

only has a sensitive region of 3 packets (positions 9-

11), which clearly is beneﬁcial for Linux

. Upon ex-

An examination of this issue by code inspection of the

FreeBSD TCP implementation revealed that FreeBSD has

a tendency to interpret one of the duplicate acknowledge-

ments as a window update. Since window updates are not

counted towards the fast retransmit threshold, FreeBSD ef-

fectively requires four duplicate acknowledgments for this

case.

amination of the results shown in Figures 8 and 9 it

can be seen that although Linux had slightly longer

response times when there were no losses, it also had

considerably less increase in the response time for the

sensitive region at the end of connections. A general

conclusion that can be drawn from the comparison of

the two implementations is that although the behavior

of the implementations differ in the details, they both

share the fundamental problem of increased response

times for losses at the end of connections.

3.5 Results for Sellerproﬁle

In addition to the Author web service, experiments

were also performed for the Sellerproﬁle web ser-

vice. The response size used for this service was

8031 bytes. The smaller size implies that fewer pack-

ets are needed to transfer the response message. Thus,

the sensitive period at the end of a connection will

cover a larger fraction of the total connection length.

For FreeBSD the sensitive positions are now positions

THE EFFECT OF PACKET LOSS ON THE RESPONSE TIMES OF WEB SERVICES

279

500

1000

1500

2000

2500

3000

3500

4000

0 2 4 6 8 10 12

Response time (ms)

Loss position

300Kbps - 10ms

Figure 6: One Linux run for US-US scenario, Author ser-

vice.

500

1000

1500

2000

2500

3000

3500

4000

0 2 4 6 8 10 12

Response time (ms)

Loss position

300Kbps - 60ms

Figure 7: One Linux run for US-overseas scenario, Author

service.

1000

2000

3000

4000

5000

6000

0 2 4 6 8 10 12

Respone time (ms)

Loss position

1000Kbps

5 ms

10 ms

20 ms

40 ms

60 ms

100 ms

150 ms

200 ms

Figure 8: Impact of different end-to-end delays for Linux

with 1000 Kbps bandwidth, Author service.

100

0 50 100 150 200

Additional time required (%)

End-to-end delay (ms)

Response time increase

160Kbit/s

300Kbit/s

500Kbit/s

1000Kbit/s

2000Kbit/s

4000Kbit/s

10000Kbit/s

Figure 9: Linux response time increase for late losses, Au-

thor service.

5-8, and for Linux positions 6-8, as shown in Figures

10 and 12, respectively. Looking at the aggregate re-

sults shown in Figures 11 and 13, it is evident that the

increases in response times are indeed larger than for

the previously examined service. This provides sup-

port for the hypothesis that shorter web service trans-

actions are more sensitive to the problem of losses late

in the connection.

3.6 Discussion

The results highlight the difﬁculty of TCP’s reliabil-

ity mechanism to work efﬁciently for short ﬂows that

are typical for web services. One issue that creates

a large increase in response time is the loss of the

SYN-ACK

, which will increase the response time

with three seconds. However, it is hard to change

this value without cross-layer knowledge of the par-

This is also true for the SYN packet, but it goes in the

direction from the client to the server which is not the focus

of our investigation.

ticular network conditions before connection estab-

lishment. Since this is the ﬁrst packet exchanged this

timeout value must be conservatively set to allow for

low bandwidth/large delay links to work with reason-

able efﬁciency. For the other case where increases in

response times were visible, i.e. losses late in the con-

nection, there will be more knowledge about the net-

work conditions available, which makes it easier to

adapt the behavior to improve performance. Hence,

the focus of this study is on losses which occur late in

the connection.

For all the web service sessions that we have ex-

amined in these experiments, the response time suf-

fered when there were losses late in the connection.

The increase in response time caused by these losses

were in the range of 208 ms to 1781 ms. When inter-

preting these results, it should be noted that they focus

on the behavior in the presence of losses. In typical

Internet conditions, many web services transactions

will not experience any loss at all. However, for those

transactions that do experience losses, the cost in in-

WEBIST 2007 - International Conference on Web Information Systems and Technologies

280

1000

2000

3000

4000

5000

6000

0 2 4 6 8 10

Response time (ms)

Loss position

1000Kbps

5 ms

10 ms

20 ms

40 ms

60 ms

100 ms

150 ms

200 ms

Figure 10: Impact of different end-to-end delays for

FreeBSD with 1000 Kbps bandwidth, Sellerproﬁle service.

100

0 50 100 150 200

Additional time required (%)

End-to-end delay (ms)

Response time increase

160Kbit/s

300Kbit/s

500Kbit/s

1000Kbit/s

2000Kbit/s

4000Kbit/s

10000Kbit/s

Figure 11: Response time increase for late losses,

FreeBSD, Sellerproﬁle service.

1000

2000

3000

4000

5000

6000

0 2 4 6 8 10

Response time (ms)

Loss position

1000Kbps

5 ms

10 ms

20 ms

40 ms

60 ms

100 ms

150 ms

200 ms

Figure 12: Impact of different end-to-end delays for Linux

with 1000 Kbps bandwidth, Sellerproﬁle service.

100

0 50 100 150 200

Additional time required (%)

End-to-end delay (ms)

Response time increase

160Kbit/s

300Kbit/s

500Kbit/s

1000Kbit/s

2000Kbit/s

4000Kbit/s

10000Kbit/s

Figure 13: Response time increase for late losses, Linux,

Sellerproﬁle service.

creased response time may be high. Using the Author

service as an example and assuming a more typical

Internet loss rate such as 2 %, on average 22 % of

the web services transactions will experience losses

Out of those transactions, on average 27 % will have

the loss at the last three packets shown in this study to

be very problematic. For shorter web services trans-

actions, a lower percentage of the transactions will

experience losses. However, for those shorter trans-

actions that do experience losses, the risk of the loss

being in the problematic region is higher. A solution

that address this problem would hence be welcome.

4 POSSIBLE SOLUTIONS

As shown in the previous section there are severe con-

sequences on the web services response times when

Assuming uniformly distributed losses that are inde-

pendent of packet size.

losses occur towards the end of a connection. Al-

though the focus of this study have been web services,

the problem of losses late in the connection is also

present for other client-server applications with short

transfers. Various proposals have been put forth that

to some extent addresses the problem. These proposal

are targeting the TCP behavior, and modify it to work

better for short connections that experiences packet

losses. In this section these proposals are brieﬂy de-

scribed and a new hybrid scheme is outlined.

4.1 Modiﬁed Retransmit Calculations

One approach is to modify the calculation of the re-

transmission timer. This will cause the retransmis-

sion timer to expire earlier, and will decrease the un-

necessary delay until timeout at the end of a connec-

tion. However, modiﬁcations of the timeout calcula-

tion may also lead to a higher frequency of spurious

timeouts, i.e causing a timeout when a packet merely

is delayed and not lost. The frequency of occurrence

THE EFFECT OF PACKET LOSS ON THE RESPONSE TIMES OF WEB SERVICES

281

for spurious timeouts is not well understood over the

range of networks that comprise the Internet of today.

There are several proposed solutions for the spurious

timeout problem (for example (Sarolahti et al., 2003))

that implies that it is a common problem, but other

research has shown very little frequency of spurious

timeouts (Vacirca et al., 2006).

4.2 Smart Framing

The smart framing approach (Mellia et al., 2005) is

based around the idea of splitting larger packets into

smaller ones. More packets may allow better RTT es-

timation and an increased chance of using fast retrans-

mit instead of timeouts. However, if the packet loss

probability is independent of packet size, this scheme

may lead to reduced performance. It also increases

the overhead by requiring more headers and ack traf-

ﬁc.

4.3 Early Retransmit

The early retransmit approach (Allman et al., 2006)

in essence entails the reduction of the duplicate ac-

knowledgments threshold. Such a reduction will de-

crease the number of packets at the end of a connec-

tion that cannot be recovered by fast retransmit. In-

vestigations in connection with this work (Allman,

2005) indicates that the reordering present in ex-

amined traces could make this solution problematic.

However, other research (Jaiswal et al., 2002) indi-

cates that networking reordering is uncommon.

4.4 Adaptive Duplicate

Acknowledgment Generation

All of the schemes discussed above try to improve the

ability of the sender to infer that a loss has occurred.

This allows retransmission to occur which in turn can,

in the current case, reduce the web-server response

time. All these approaches have some disadvantages

as already mentioned. To provide a better solution we

here outline a new approach where the loss inference

instead takes place at the receiver side, and the re-

ceiver then uses an implicit loss notiﬁcation to make

the sender perform a fast retransmission.

The ﬁrst step of this scheme is to use the reception

of the ﬁnal FIN packet to start an adaptive duplicate

acknowledgment generation module. This module

checks if there is a hole in the received packet stream,

i.e. a packet that is lost (or possibly reordered). It then

applies a timer that is based on receiver side measure-

ments of the packet inter-arrival times. This timer is

updated when each packet is received, in contrast to

the RTT estimation which typically is performed only

once per congestion window. When the inter-arrival

timer times out, the module sends additional dup-acks

so that the total amount of dup-acks becomes three,

which upon receipt at the sender will trigger a fast re-

transmit. This scheme has several beneﬁts compared

to the ones above; it will have a lower frequency of

spurious retransmissions than the modiﬁed retransmit

calculations and early retransmit schemes. Also, it

will not have the always present overhead of addi-

tional headers that smart framing produces. The de-

tails of the receiver side timer calculations as well as a

kernel implementation is part of planned future work.

5 CONCLUSIONS

We have examined the impact of packet loss on web

services response times. To do this we have per-

formed experiments on two current TCP implemen-

tations using emulation with precise loss positioning

capabilities. We examined all possible loss positions

for 56 combinations of effective bandwidth and end-

to-end delay, for two different empirically derived re-

quest and response sizes using two different operat-

ing systems. The results show increased response

times of magnitudes that are clearly perceptible to

humans, and thus causes for user dissatisfaction, for

many cases when the losses are placed at the end of a

connection. Due to the relatively small size of many

web services transactions, the sensitive area at the end

is large in relation to overall transaction length. The

increase in response time varied from 208 ms to 1781

ms in absolute value, and in percentage terms the in-

crease ranged between 40 % and 112 %. Possible so-

lutions that reduce the effect of late losses were brieﬂy

discussed, and a new receiver-based hybrid approach

was sketched in order to mitigate some of the disad-

vantages of the other schemes. For future work we

intend to focus on the development and evaluation of

this hybrid approach.

ACKNOWLEDGEMENTS

The authors wish to thank Su Myeon Kim for provid-

ing the detailed measurement data on web service re-

quest and response sizes that were published in (Kim

and Rosu, 2004), and Hubert Baumeister for discus-

sions that helped to shape the content of this paper.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

282

REFERENCES

Allman, M. (2005). Private communication.

Allman, M., Avrachenkov, K., Ayesta, U., and Blanton, J.

(2006). Early retransmit for TCP and SCTP. IETF

Draft: draft-allman-tcp-early-rexmt-04.txt.

Allman, M., Paxson, V., and Stevens, W. (1999). TCP con-

gestion control. RFC2581.

Booth, D., Haas, H., and McCabe, F. (2004). Web Services

Architecture. http://www.w3.org/TR/ws-arch/.

Bray, T., Paoli, J., Sperberg-McQueen, C. M., Maler, E.,

and Yergeau, F. (2006). Extensible Markup Language

(XML) 1.0 (Fourth Edition). W3C Recommendation.

Fielding, R., Gettys, J., Mogul, J., Frystyk, H., Masinter,

L., Leach, P., and Berners-Lee, T. (1999). Hypertext

Transfer Protocol – HTTP/1.1. RFC2616.

Garcia, J., Alfredsson, S., and Brunstrom, A. (2006). The

impact of loss generation on emulation-based pro-

tocol evaluation. In Proc. International Conference

on Parallel and Distributed Computing and Networks

(PDCN 2006).

Jaiswal, S., Iannaccone, G., Diot, C., Kurose, J., and

Towsley, D. (2002). Measurement and classiﬁcation

of out-of-sequence packets in a tier-1 ip backbone. In

IMW ’02: Proceedings of the 2nd ACM SIGCOMM

Workshop on Internet measurment, pages 113–114,

New York, NY, USA. ACM Press.

Kim, S. M. and Rosu, M.-C. (2004). A survey of public

web services. In Proceedings of the 13th international

World Wide Web conference on Alternate track papers

and posters (WWW 2004).

Lerner, R. (2006). Creating mashups. Linux Journal, (147).

Mellia, M., Meo, M., and Casetti, C. (2005). TCP smart

framing: a segmentation algorithm to reduce TCP

latency. IEEE/ACM Transactions on Networking

(TON), 13(2):316–329.

Object Management Group (2004). Common Object

Request Broker Architecture: Core Speciﬁcation.

http://www.omg.org/technology/documents/

corba_spec_catalog.htm.

Paxson, V. and Allman, M. (2000). Computing TCP’s re-

transmission timer. RFC2988.

Postel, J. (1981). Transmission control protocol. RFC793.

Rizzo, L. (1997). Dummynet: a simple approach to the

evaluation of network protocols. ACM Computer

Communication Review, 27(1):31–41.

Sarolahti, P., Kojo, M., and Raatikainen, K. (2003). F-RTO:

an enhanced recovery algorithm for TCP retransmis-

sion timeouts. SIGCOMM Computer Communica-

tions Review, 33(2):51–63.

Srinivasan, R. (1995). RPC: Remote procedure call protocol

speciﬁcation version 2. RFC1831.

Sun Microsystems, Inc. (2004). Java Remote Method Invo-

cation. http://java.sun.com/j2se/1.5.0/docs/guide/rmi/

spec/rmiTOC.html.

Vacirca, F., Ziegler, T., and Hasenleithner, E. (2006). An

algorithm to detect TCP spurious timeouts and its ap-

plication to operational UMTS/GPRS networks. Com-

puter Networks, 50(16):2981–2001.

World Wide Web Consortium (W3C) (2003). Sim-

ple object access protocol (SOAP) version 1.2.

http://www.w3.org/TR/soap.

THE EFFECT OF PACKET LOSS ON THE RESPONSE TIMES OF WEB SERVICES

283
