LOG4P: AN INNOVATIVE LOGGER FRAMEWORK FOR WEB

PORTALS

Towards New Metrics For Web Portals

Gennaro Costagliola, Filomena Ferrucci, Vittorio Fuccella, Luigi Zurolo

Dipartimento di Matematica e Informatica, Università di Salerno, Via Ponte Don Melillo, I-84084 Fisciano (SA)

Keywords: Web, www, metrics, portal, portlet, JSR 168, WSRP, logging, log, query, log4p.

Abstract: Content Management Systems and Web Portal Frameworks are more and more widely adopted in Web

development. Those kinds of software often produce web pages whose layout is divided in sections called,

in the case of Web Portals, “portlets”. Portlets can be produced by different sources and then aggregated in

the same page by the portal. For Web portals, traditional web metrics based on page visits can be inadequate

for fully understanding user’s interest, due to the heterogeneity of content and the variety of sources. This

paper proposes a system for evaluating the web traffic at a deeper level than the page visit one: the level of

the sections, or of the portlets. The interest of the user in the sections of the page is gauged through implicit

interest indicators, such as, section visibility, mouse movements and other client-side interactions. Our

system is composed of two different products: a framework that, opportunely instantiated in a web portal,

allows the production of a log, and a log analyzer. The possible uses and benefits gained by research in the

fields of web traffic analysis, portal design and usability are investigated in depth.

1 INTRODUCTION

Content Management Systems (CMS, in the sequel)

and Web Portal Frameworks are more and more

widely adopted in the development of Web sites,

mainly due to their characteristic of allowing the

web designers to rapidly develop a web site and the

portal administrators to rapidly update its contents.

CMS and portal frameworks produce web pages

whose layout is divided in sections called portlets.

This division is not only a layout concern, but it

occurs in all the steps of the generation of the pages:

in the case of many portals, the portlets can be

produced by different, eventually remote, sources

and then aggregated in the same page. Thus, we are

on the way towards the creation of a portlet market,

where content, or part of it, is produced by third

parties and then shown on the publisher’s web site.

The technical solution to achieve this

organization, is based on the production of markup

fragments (a concern of the portlet), and their

aggregation in a single page (a concern of the

portal). The development of standards and

specifications, such as JSR 168 (2003) and WSRP

(2003), has helped to this extent. A noteworthy

example of a Web site, whose layout demonstrates

the use of a portal framework in its development, is

that of Yahoo. A screenshot of its home page is

shown in figure 1.

Figure 1: The Yahoo home page and its sections.

As a result of the aggregation, a portal page can

contain a highly heterogeneous content, taken from

Costagliola G., Ferrucci F., Fuccella V. and Zurolo L. (2007).

LOG4P: AN INNOVATIVE LOGGER FRAMEWORK FOR WEB PORTALS - Towards New Metrics For Web Portals.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Web Interfaces and Applications, pages 98-105

DOI: 10.5220/0001289300980105

 SciTePress

various portlet producers. For web sites developed

with CMS and portal framework technology,

traditional metrics based on page visits can be

inadequate to fully understand user’s interest: new

forms of metrics are needed. What we need are

metrics which can give information at a deeper level

than that of page visits: the level of the sections, or

of the portlets. Unfortunately, at present there is a

lack of these metrics.

This paper presents some tools which make use

of new metrics suitable for describing the behaviour

of the visitors on the portal pages. The gathering of

such information is carried out through the use of a

framework directly instantiated in the portal. The

framework produces an XML log, which includes

raw data, such as the implicit interest indicators (i. e.

any interaction of the user with the portlets) and the

visibility of the portlets in the pages, captured when

the users browse the portal pages.

The logs are analyzed through a suitable log

analyzer that obtains some higher level information

by performing several queries on the logs, such as:

 An estimation of the visibility of the portlets

in the page.

 The interactivity level of the portlets.

From this information we can obtain an estimation

of the interest shown by the users in the portlets. The

analysis can be made available per single user visit

and session, across multiple visits of the same user

or for all the users.

Once obtained, this data can be used for multiple

purposes. The possible uses and benefits gained by

research in fields of web traffic analysis, portal

design and web usability are investigated in depth.

The rest of the paper is organized as follows:

section 2 gives the knowledge background necessary

to understand some concepts on which the system is

based. The system is presented in section 3: the

section is composed in two sub-sections, the first to

describe the logger framework and the second for

the log analyzer. Finally, in section 4, we briefly

discuss possible uses and benefits of our system.

Several final remarks and a discussion on future

work conclude the paper.

2 BACKGROUND

A portal is a web site which constitutes a starting

point, a gate to a consistent group of resources and

services in the Internet or in an intranet. Most of the

portals were born as Internet directories (as Yahoo)

and/or as search engines (as Excite, Lycos, etc.). The

offer of services has spread in order to increment the

number of users and the time they spend browsing

the site. These services, which often require user

registration, include free email, chat rooms, and

personalization procedures. In the history of portals,

many authors identify two generations. Second

generation Web portals distinguish themselves from

first generation ones for their architecture, which is

component-oriented. In particular, the basic

component constituting them, is often referred to as

portlet. The portal is responsible for aggregating

information coming from different sources, local or

remote, available in the form of mark-up fragments.

Each of these fragments is produced by a portlet. In

the context of web portals, the possibility to deploy a

portlet in any portal is particularly significant. To

this extent, that is, to achieve interoperability among

portals, it has been necessary to define a standard

way to develop and deploy portlets. Two main

standards have been defined and widely adopted by

producers: the Web Services for Remote Portlets

(WSRP) and the Java Portlet Specification and API

(JSR 168). The former is more oriented to the

definition of rules about the use of remote portlets,

the latter is focused on the definition of interfaces

for the development of portlets which can run in

Java-based portals.

WSRP defines a Web service interface through

which portals can interact with the remote

producer’s portlets. The WSRP 1.0 specification was

approved as an OASIS standard in August, 2003.

Being based on Web services, several interfaces to

adopt the standard have been developed for the most

used technologies (e.g. J2EE, .NET, and so on).

Most of the Java technologies, part of the Java 2

Enterprise Edition, the platform for the development

and deployment of distributed enterprise

applications, follow a consolidated architectural

model, called container/component architecture.

This model offers the chance to develop components

and deploy them on different containers. Both

component and containers compliant to

specifications can be developed independently and

commercialized by different software vendors, thus

creating a market economy on Java software.

Furthermore, several good-quality Open Source

products compete with them. The JSR 168 follows

the container/component model and its adoption has

grown until it has become an important reference-

point which cannot be excluded from the projects

aimed at the development of Web portals. Among

other things, it defines the architecture model of

conformant portals. Its main constituents are the

portlet, which produces content mark-up, the portal,

which aggregates the mark-up, and the portlet

container, which manages the portlet lifecycle and

provides an API to the portlets for accessing to a set

of services. The typical architecture for a JSR 168

conformant web portal is shown in figure 2.

LOG4P: AN INNOVATIVE LOGGER FRAMEWORK FOR WEB PORTALS - Towards New Metrics For Web Portals

Figure 2: JSR 168 compliant portal architecture.

3 THE SYSTEM

Our system is aimed at obtaining detailed statistics

in order to have a deep analysis of the user’s interest

in the Web portal and, in particular, in the sections

which compose its pages.

Our system is composed of two different pieces

of software:

1 A framework, to be used by Web portal

developers, which, instantiated in the Web

portal, is in charge of capturing information

about user’s behaviour during the navigation of

the portal and storing it in an XML log.

2 A logger analyzer, to be used by Web portal

administrators, developed as a stand-alone

application, which is responsible for analyzing

the data gathered by the logger.

3.1 The Logging Framework

The purpose of the Logger Framework is to gather

all of the user actions during the browsing of the

portal and to store raw information in a set of log

files in XML format.

The framework is composed of a server-side and

a client-side module. The client-side module is

responsible for “being aware” of the behaviour of

the user while he/she is browsing the portal pages.

The server-side module receives the data from the

client and creates and stores log files on the disk.

Despite the required interactivity level, due to

the availability of AJAX (Asynchronous JavaScript

and XML), the new technology for increasing the

interactivity of Web content, it has been possible to

implement the client-side module of our framework

without developing plug-in or external modules for

Web browsers. Javascript has been used on the client

to capture user interactions and the text-based

communication between the client and the server has

been implemented through AJAX method calls. The

client-side scripts are added to the portal pages with

a light effort by the programmer.

The events captured by the framework are the

following:

 Actions undertaken on the browser window

(open, close, resize)

 Actions undertaken in the browser client area

(key pressed, scrolling, mouse movements)

The event data is gathered on the browser and

sent to the server at regular intervals. It is worth

noting that the event capture does not prevent other

scripts present in the page to run properly.

The server-side module has been implemented as

a Java servlet which receives the data from the client

and prepares an XML document in memory. At the

end of the user session the XML document is written

to the disk. To reduce the size of log files, a new file

is used every day.

The information model used for the log data is

shown in figure 3. All the information is organized

per user session. At this level, an identifier (if

available) and the IP of the user are logged as well

as agent information (browser type, version and

operating system). A session is composed of page

visits data. For every page, the referrer is logged and

a list of events is present. The data about the user

interactions are the following:

 Event type

 HTML source object involved in the event

 Portlet containing the HTML object and its

position in the page (coordinates of the

corners)

 Mouse coordinates

 Timing information (timestamp of the event)

 More information specific of the event

Figure 3: The information model for log data.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

100

An important concern in web metrics is the log size.

In very crowded web sites, even simple HTTP

request web logs can reach big sizes. A

configuration system, including the following

configuration settings has been conceived in order to

reduce log sizes:

 List of events to capture

 List of portlets to monitor

 Time interval between two data transmissions

from the client to the server

 Sensitivity for mouse movements

 Sampling factor (only for a random user every

n logging is activated)

The configuration is read by the server-side

module but affects the generation of the javascript

modules run on the client-side. The architecture of

the framework is graphically represented in figure 4.

On the client machine, everything can be done in

the web Browser. The Javascript modules for event

capturing, dynamically generated on the server, are

downloaded and run in the browser interpreter. Data

is sent to the server through an AJAX request. On the

server-side, a module called RequestHandler

receives it. Once received, a module called

LoggerHandler organizes the XML document in

memory and flushes it to the disk every time a user

session finishes.

3.2 The Log Analyzer

The next phase of the data gathering is the data

analysis. In our system this is done through a web-

based stand-alone application, optionally hosted on

the same server of the logging framework, which

takes in input the log files.

The analysis phase consists of a series of

analysis on the behaviour of the user, starting from

the data stored in the log. The analysis can have

several aims. Among them we can cite:

 Giving a better organization to the portal

 The choice of the contents more suitable to the

user or to group of users.

 Usability analysis of the portal.

A deeper analysis on the uses that our system can

offer is contained in the next section.

The analyzer performs queries on the logs to

obtain the desired data and then calculates statistical

indicators, shown in the form of charts and tables.

Since the log files are in XML, the query engine has

been developed to understand XQuery (2006)

language, and has been carried out using an

implementation of the JSR 225 (2006). In the next

sub-sections we will show some useful statistics we

can obtain using the system. The module for

drawing charts has been developed using a free Java

library, named jCharts (2006).

3.2.1 Page Counts

A generic analysis is given by the simple count of

page visits. Even though such a task is easily

performed by a lot of already existing tools, page

visits count is an important statistic for our system,

since it allows us to understand on which page the

interest of the user is mostly concentrated. Starting

from this data, we could focalize our attention on a

subset of the portal pages and perform a deeper,

portlet-based, analysis on them. This statistic is

easily obtainable with our analyzer through a count

query on the page elements of our logs.

A sample of page visits chart, drawn using our

analyzer, is shown in figure 5.

3.2.2 Portlet Visibility Time

A more specific analysis can be obtained by

calculating the visibility time for each level of

portlet visibility (total, partial, invisible). Portal

layouts are usually organized in columns. A

commonly used layout organizes portlets in two

columns of the same size (50%, 50%). Another

common layout is composed of three columns (i.e.

Figure 5: Page count chart sample

Figure 4: Logging framework architecture

LOG4P: AN INNOVATIVE LOGGER FRAMEWORK FOR WEB PORTALS - Towards New Metrics For Web Portals

101

25%, 50%, 25% in size). The portal page can

contain some other elements, such as, a header, a

footer and an horizontal or a vertical menu or both

of them. If the number and size of portlets is such

that the portal page exceeds the size of the browser

window, only part of the page is shown, while some

other parts are hidden and can be shown through

scrolling. Thus, at any time some portlets can have

full visibility, some others partial visibility (only a

percentage of the portlet area is visible), while the

remaining are completely hidden to the user.

Every time a scrolling event occurs, our logger

records its timestamp and the position of the portlet

in the page. The availability of this data allows us to

precisely calculate the amount of time the portlets

were fully visible, partially visible or completely

invisible.

This information, in the context of a portal, is

very useful, since, after knowing which page has

attracted the user more, it let us know his/her interest

in the single content units of the page. Figure 6

contains a chart showing the visibility percentage of

the portlet.

Figure 6: Portlet visibility chart sample.

When a portlet is partially visible, the chart of

figure 6 does not exactly tell us the extent of the

visible and hidden areas of the portlet. Thus, in order

to complete the visibility analysis, we considered it

opportune to show another chart summarizing the

visibility percentage of the portlet across users’ page

views. This indicator is calculated as the weighted

mean of all the visibility times, using the following

formula:

(1)

V is the total visibility indicator for the portlet, t

and

are, respectively, its time and percentage of

visibility in the i-th interval, T is the total time of the

page visit.

Figure 7: Portlet visibility percentage chart sample.

A sample of the chart is shown in figure 7. For the

sake of readability, the bars are shown in green for

high visibility, in yellow for low visibility and in red

for scarce visibility. The elaboration and the queries

performed on the log for obtaining the parameters in

(1) , have been reported in appendix.

3.2.3 Portlet Interactions

Some portlets can be more informative while others

can be more interactive. For example, an article of

an on-line news magazine is supposed to be

informative, while a section containing a form

should be more interactive, that is, it should receive

more user interactions than the former. Many people

use the mouse as a pointer while reading on-line

news.

Figure 8: Portlet interactivity level chart sample.

With our tool, we can obtain an information

about portlet interaction from a bar chart. An

example is shown in figure 8. In the chart, each bar

∑

)*(

WEBIST 2007 - International Conference on Web Information Systems and Technologies

102

is composed of three sections of different color.

They represent three different types of interactions:

window, mouse and keyboard events.

Another interest indicator to be considered is the

total time a portlet has the mouse pointer in it. An

eye tracking study (Chen et al., 2001) shows that

there is a significant correlation between the eye

movements and the mouse movements: tracking the

trajectory drawn by the mouse pointer could be

useful for obtaining the probable trajectory of user’s

eyes, that is, what the user is interested in.

Figure 9: Portlet mouse pointer focus.

While eye tracking cannot be performed, if not

in ad hoc equipped laboratories, mouse tracking can

be easily performed by our tool. All of the mouse

movements can be reconstructed from the log

analysis.

With a great number of users, the reconstruction

of all mouse movements can be too onerous. A

similar interest indicator can be obtained by just

calculating the amount of mouse movements and the

amount of time spent by the user with the mouse

pointer inside a portlet. The number of movements

has already been described and charted in figure 8.

As for the amount of time the portlet has the mouse

pointer in it, a pie chart, showing the times of

presence of the mouse pointer inside the portlets of

the same page, is the most appropriate to this extent.

A sample is shown in figure 9.

4 RELATED WORK, USES AND

APPLICATIONS

The effectiveness of implicit interest indicators is

witnessed by several studies in literature (Claypool

et al., 2001; Shapira et al., 2006). These works

demonstrate the correlation of implicit indicators

and the actual interest of the user. Furthermore, they

produce a list of the most used interest indicators.

Some works propose the development of tools for

determining user’s interests. For example, in

(Atterer et al., 2006), a proxy server based system is

used to capture client-side interactions.

Some works are aimed at understanding the

structure of web pages in order to determine page

sections. Many algorithms have been presented to

this extent. The purposes of determining sections

include the following.

Wenyn et al. (2005) divide pages in sections to

detect similarities between two pages, in order to

prevent phishing. Chen et al. (2005) do the same

thing in order to better view web pages on small

screen devices. Blocks in the pages are detected for

identifying the informative sections of the page to

reduce storing sizes for search engines (Debnath et

al., 2005) or to eliminate redundant information for

Web mining (Taib et al., 2005). It is clear that, if

efforts have been made to divide pages in sections,

where the pages are explicitly divided in sections,

we can pursue the above discussed purposes and

more. Once determined, the indication of user

interest, calculated from the log analysis, can be

used for several purposes. The next sub-sections

analyze the possible practical uses of our system in

several Web research fields.

4.1 Integrating Web Metrics

Web metrics tell us how the users are using the web

site. E-commerce sites need to know this

information in order to improve their selling

capacity. Some of the most commonly used web

metrics are: the number of page visits, the number of

banner or link clicks, the percentage of users who

complete an action, etc.

Unfortunately, clickstream analysis metrics,

have the following limitations, as remarked by

Weischedel and Huizingh (2006):

 They report activity on the server and not user

activity

 They can overestimate the actual use of web

sites due to spiders activity

 They do not include the real time spent on the

page by the user.

Our system overcomes these problems, in fact, it

captures client side activity, can easily recognize

spiders from the absence of mouse movements and

records times, in such a way that it is easy to detect

inactivity time due to user absence from the screen.

4.2 Portal Design

The location of the portlets in the portal page has a

great importance, since some portlets can have more

visibility than others. An eye tracking study

(Goldberg et al., 2002), analyzing the behaviour of

users in some browsing tasks, has shown that user’s

LOG4P: AN INNOVATIVE LOGGER FRAMEWORK FOR WEB PORTALS - Towards New Metrics For Web Portals

103

interest is more concentrated, at least in the initial

phases of page browsing, in the portlets placed on

the top of the first column. In the same study, a

complete classification of the places which are

candidates to gain more user interest has been

performed. It is advisable that, if the portal holder

wants to emphasize the content of a portlet more

than another, he/she should put these portlets in

those places.

Our tool can help in determining the portlets

which attract user’s interest more and, on the basis

of this data, it can help portal administrator in

placing the portlets in the pages.

4.3 Personalization of the Portal

Web portal customization is often used to tailor the

services of the portal to a single user or to a group of

users. In some cases, the user has the freedom of

choosing his/her favourite portlets to place in his/her

home page. In other cases, the interest of the user

can be inferred from the logs, and the pages of the

portal constructed in order to give more visibility to

content which matches user’s interests.

In the case of groups of users, groups can be

obtained through clustering procedures. Our system

can be useful for gathering data to obtain cluster of

users.

4.4 Portal and Portlet Usability

Due to their characteristic of being considered small

Web applications, usability can be defined for

portlets as well. Diaz et al. (2004) define portlet

usability as the capability of the portlet to be

understood, learned or used under specified

conditions. The implicit interest indicators can be

used to facilitate the task of usability evaluators.

(Atterer et al., 2006) shows many situations in which

this is true, for example using true users instead of

volunteers in the lab.

Portlet position affects the usability of the portal.

Let us suppose that a task can be performed by

interacting with more than one portlet. Their

position can affect the amount of time necessary to

perform the task. A usability study can be aimed at

finding the best location for each of these portlets.

Another study (Moraga et al., 2006) states the

possibility of performing a choice among different

portlets with similar features, choosing on the basis

of their usability. Our tool can be useful to this

extent, in order to isolate the interactions relative to

this portlet thus to evaluate its usability.

Among others, our tool captures key press

events. In the case of portlets with forms, the data

can be used to understand if the user had problems

in filling the form. This is valid for any kind of web

site and not only for portals.

5 CONCLUSIONS

In this paper we have presented a system aimed at

obtaining and analyzing the data about the behaviour

of the users of web portals. The system overcomes

the limitation of the simple page visit-based metrics,

giving more valuable information related to the

portlets, such as their visibility and interactivity and,

consequently, the interest of the user in them.

The system is composed of two components: a

framework for obtaining XML-based log files and

an application for log analyzing. Several charts,

drawn using the latter have been shown.

Referencing some recent work in literature, we

have argued that our system can be useful for

numerous purposes, such as, integrating web

metrics, optimizing portlet layout both for all users

and for personalization, and usability studies. Future

work is aimed at practically demonstrating the use of

our system in these fields.

Finally, an aspect that has been considered, but

not yet put into practice, is the availability of the log

data both to the portal and to the portlet producer. At

present some architecture and secure schemas are

taken into account, as the one proposed by Blundo

and Cimato (2004), applied for determining banner

clicks in advertising campaigns.

The system has been tested on a portal

developed with Apache Jetspeed II (2006) Portal

framework.

REFERENCES

Atterer, R., Wnuk, M., Schmidt, A., 2006. Knowing the

User’s Every Move – User Activity Tracking for

Website Usability Evaluation and Implicit Interaction.

In Proceedings of the 15th international conference on

World Wide Web WWW '06. ACM Press

Bellas, F., 2004. Standards for Second-Generation Portals.

IEEE Internet Computing. 8(2): pp. 54-60.

Blundo, C. and Cimato, S., 2004. A Software

Infrastructure for Authenticated Web Metering. IEEE

Computer.

Chen, Y., Xie, X., Ma, W. Y., Zhang, H. J., 2005.

Adapting Web pages for small-screen devices. IEEE

Internet Computing.

Claypool, M., Le, P., Wased, M., Brown, D., 2001.

Implicit interest indicators. In Proceedings of the 6th

international conference on Intelligent user interfaces.

ACM Press.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

104

Chen, M. C., Anderson, J. R., Sohn Moore, M. H., 2001.

What can a mouse cursor tell us more?: correlation of

eye/mouse movements on web browsing. In CHI '01

extended abstracts on Human factors in comp. syst.

Debnath, S., Mitra, P., Pal, N., Giles, C.L., 2005.

Automatic identification of informative sections of

Web pages. In IEEE Transactions on Knowledge and

Data Engineering.

Diaz, O., C. Calero, M. Piattini, and A. Irastorza. Portlet

usability model. 2004. IBM Research Report.

RA221(W0411-084). ICSOC 2004.pp. 11-15.

Goldberg, J. H., Stimson M. J., Lewenstein, M., Scott, N.,

Wichansky, A. M., 2002. Eye tracking in web search

tasks: design implications. In Proceedings of the 2002

symposium on Eye tracking research & applications.

jCharts, 2006. Krysalis Community Project – jCharts.

http://jcharts.sourceforge.net/

Jetspeed 2, 2006. Apache Group. Jetspeed 2 Enterprise

Portal. http://portals.apache.org/jetspeed-2/

JSR 225, 2006. JSR 225: XQuery API for JavaTM (XQJ).

http://jcp.org/en/jsr/detail?id=225

JSR 168, 2003. JSR-000168 Portlet Specification.

http://jcp.org/aboutJava/communityprocess/review/jsr

168/

Moraga, M. A., Calero, C., Piattini, M., 2006. Ontology

driven definition of a usability model for second

generation portals. In Workshop proceedings of the

sixth int. conference on Web engineering, ICWE’06.

Shapira, B., Taieb-Maimon, M., Moskowitz, A., 2006.

Study of the usefulness of known and new implicit

indicators and their optimal combination for accurate

inference of users interests. In Proceedings of the 2006

ACM symposium on Applied computing SAC '06.

Taib, S.M., Yeom, S. J., Kang, B. H., 2005. Elimination of

Redundant Information for Web Data Mining. In

Proceedings of ITCC 2005, Int. Conf. on Information

Technology: Coding and Computing, Vol 1.

Weischedel, B., Huizingh, E. K. R. E., 2006. Website

Optimization with Web Metrics: A Case Study. In

Proceedings of ICEC '06, the 8th international

conference on Electronic commerce. ACM Press.

Wenyin, L., Huang, G., Xiaoyue, L., Deng, X., Min Z.,

2005. Phishing Web page detection, In Proceedings of

Eighth International Conference on Document

Analysis and Recognition.

WSRP, 2003. OASIS Web Services for Remote Portlets.

http://www.oasis-

open.org/committees/tc_home.php?wg_abbrev=wsrp

XQuery, 2006. XQuery 1.0: An XML Query Language

W3C Candidate Recommendation.

http://www.w3.org/TR/xquery/

APPENDIX

Here is, as an example, the pseudo-code procedure

used in the log analyzer for obtaining the

portlet

visibility percentage chart, shown in figure 7. Each bar in

the chart represents the percentage of visibility of a portlet

across all page views.

Those values are calculated

using (1). The procedure assume, simplistically, that

all the analyzed pages contain the same portlets.

Their number is passed as a parameter to the

procedure (line 1), and is used to associate the

correct event timestamp (lines 15-17) to portlet data

(name and coordinates).

Every time a user scrolls the page, the percentage

of visibility of a portlet changes, since part or all of

its area can fall inside/outside the browser’s client

area. On the initial page load event, and on every

scroll event, our logger registers the coordinates of

each portlet (through the portlet element of the

information model, see figure 3). Through our

sample code, for each event element and for each

portlet element, portlet names, coordinates and event

timestamps are obtained by querying the log and

storing the results in the

portletNames,

coordinates and timestamps vectors,

rispectively (lines 3-6).

Once obtained event timestamps and portlet

coordinates, the numerator in (1) is calculated

through the iteration of lines 11-22. The partial sum

is kept by the sum associative array (line 22), whose

keys are portlet names. The calculation of the

visibility percentage in the i-th time interval v

delegated, as shown in line 13, to the

calculateVisibilityPercentage sub-routine.

The time intervals t

can be easily calculated by

subtracting the (i+1)-th and the i-th timestamps (line

18). Those time intervals are summed in line 19 to

obtain the total time T.

The final results are put in the visibility

associative array, as shown in line 25. Those results

are obtained by dividing the partial sums by T.

At last, visibility is passed to the

createChart

sub-routine, which is responsible for drawing the bar

chart (line 27).

LOG4P: AN INNOVATIVE LOGGER FRAMEWORK FOR WEB PORTALS - Towards New Metrics For Web Portals

105
